Graphene quantum dots (GQDs) obtained by microwave-induced pyrolysis of glutamic acid and triethylenetetramine (trien) are fairly stable, emissive, water-soluble, and positively charged nano-systems able to interact with negatively charged
meso-tetrakis(4-sulfonatophenyl) porphyrin (TPPS
4). The stoichiometric control during the preparation affords a supramolecular adduct, GQDs@TPPS
4, that exhibits a double fluorescence emission from both the GQDs and the TPPS
4 fluorophores. These supramolecular aggregates have an overall negative charge that is responsible for the condensation of cations in the nearby aqueous layer, and a three-fold acceleration of the metalation rates of Cu
2+ ions has been observed with respect to the parent porphyrin. Addition of various metal ions leads to some changes in the UV/Vis spectra and has a different impact on the fluorescence emission of GQDs and TPPS
4. The quenching efficiency of the TPPS
4 emission follows the order Cu
2+ > Hg
2+ > Cd
2+ > Pb
2+ ~ Zn
2+ ~ Co
2+ ~ Ni
2+ > Mn
2+ ~ Cr
3+ >> Mg
2+ ~ Ca
2+ ~ Ba
2+, and it has been related to literature data and to the sitting-atop mechanism that large transition metal ions (e.g., Hg
2+ and Cd
2+) exhibit in their interaction with the macrocyclic nitrogen atoms of the porphyrin, inducing distortion and accelerating the insertion of smaller metal ions, such as Zn
2+. For the most relevant metal ions, emission quenching of the porphyrin evidences a linear behavior in the micromolar range, with the emission of the GQDs being moderately affected through a filter effect. Deliberate pollution of the samples with Zn
2+ reveals the ability of the GQDs@TPPS
4 adduct to detect sensitively Cu
2+, Hg
2+, and Cd
2+ ions.
