Special Issue "Modeling and Control of Crystallization"

A special issue of Processes (ISSN 2227-9717). This special issue belongs to the section "Materials Processes".

Deadline for manuscript submissions: closed (30 June 2019).

Special Issue Editors

Dr. Christopher L. Burcham
Website
Guest Editor
Small Molecule Design and Development (SMDD), Eli Lilly and Company, Lilly Corporate Center, Indianapolis, IN 46285, USA
Assist. Prof. Dr. Meenesh R. Singh
Website1 Website2
Guest Editor
Department of Chemical Engineering, University of Illinois at Chicago, Chicago, 60607, USA
Interests: Artificial Photosynthesis; Carbon Capture and Sequestration; Solar-Energy Conversion; Environmental Engineering; Computational Materials

Special Issue Information

Dear Colleagues,

Crystallization is an industrially important unit operation for the isolation, purification, and synthesis of a wide range of inorganic and organic materials, including pharmaceuticals, agrochemicals, semiconductors, catalysts, metal–organic frameworks, and other fine or specialty chemicals. Developing and subsequently controlling a crystallization process can be challenging and is often complicated by the solute coming from a multicomponent solution and the interactions of the solute with the solvents. Often, it is required that the solids be isolated consistently in a desired polymorphic form or as a specific solvate, while ensuring that high product purity is attained. The control of particle size and shape distribution may also be needed to avoid difficult filtrations, improve the activity of catalysts, modulate band gaps of semiconductors, or ensure product performance. Modeling and control of crystallization is one of the dominant research areas in materials science, with a rapidly growing number of publications at a current rate of ~2000 per year and a citation rate of ~ 17325 per year.

The objective of this Special Issue is to provide an opportunity for scientists and engineers all over the world to publish their latest and original findings on theoretical and practical approaches to the modeling and control of crystallization processes, during both development and routine commercial manufacture. Potential topics include, but are not limited to:

  • Process analytical technology (PAT) methods and tools that can lead to a more efficient development and control of robust crystallization processes
  • Case studies and examples of how commercial crystallization processes are developed.
  • Design and control of crystallization processes
  • Examples of integration of crystallization with other unit operations—distillation, liquid–liquid separation, membrane separation, solid–liquid separation and filtration, drying, wet milling, reactions
  • Population balance modeling for nucleation, growth, breakage, and aggregation processes
  • Computational schemes to simulate the crystallization process
  • Identification of parameters and kernels to predict size and shape distribution of crystals

Dr. Christopher L. Burcham
Dr. Meenesh R. Singh
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All papers will be peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Processes is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 1200 CHF (Swiss Francs). Please note that for papers submitted after 31 December 2019 an APC of 1400 CHF applies. Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Published Papers (10 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

Jump to: Review

Open AccessFeature PaperArticle
A Thermodynamic Approach for the Prediction of Oiling Out Boundaries from Solubility Data
Processes 2019, 7(9), 577; https://doi.org/10.3390/pr7090577 - 01 Sep 2019
Abstract
Many pharmaceutical molecules, fine chemicals, and proteins exhibit liquid–liquid phase separation (LLPS, also known as oiling out) during solution crystallization. LLPS is of significant concern in crystallization process development, as oiling out can compromise the effectiveness of a crystallization and can lead to [...] Read more.
Many pharmaceutical molecules, fine chemicals, and proteins exhibit liquid–liquid phase separation (LLPS, also known as oiling out) during solution crystallization. LLPS is of significant concern in crystallization process development, as oiling out can compromise the effectiveness of a crystallization and can lead to operational problems. A comprehensive methodology that allows a process scientist/engineer to characterize the various phase boundaries relevant to oiling out is currently lacking. In this work, we present a modeling framework useful in predicting the binodal, spinodal, and gelation boundaries starting from the solubility data of a solute that is prone to oiling out. We collate the necessary theoretical concepts from the literature and describe a unified approach to model the phase equilibria of solute–solvent systems from first principles. The modeling effort is validated using experimental data reported in the literature for various solute–solvent systems. The predictive methods presented in this work can be easily implemented and help a process engineer establish the design space for a crystallization process that is affected by liquid–liquid phase separation. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Modeling and Simulation of Crystallization of Metal–Organic Frameworks
Processes 2019, 7(8), 527; https://doi.org/10.3390/pr7080527 - 09 Aug 2019
Cited by 2
Abstract
Metal–organic frameworks (MOFs) are the porous, crystalline structures made of metal–ligands and organic linkers that have applications in gas storage, gas separation, and catalysis. Several experimental and computational tools have been developed over the past decade to investigate the performance of MOFs for [...] Read more.
Metal–organic frameworks (MOFs) are the porous, crystalline structures made of metal–ligands and organic linkers that have applications in gas storage, gas separation, and catalysis. Several experimental and computational tools have been developed over the past decade to investigate the performance of MOFs for such applications. However, the experimental synthesis of MOFs is still empirical and requires trial and error to produce desired structures, which is due to a limited understanding of the mechanism and factors affecting the crystallization of MOFs. Here, we show for the first time a comprehensive kinetic model coupled with population balance model to elucidate the mechanism of MOF synthesis and to estimate size distribution of MOFs growing in a solution of metal–ligand and organic linker. The oligomerization reactions involving metal–ligand and organic linker produce secondary building units (SBUs), which then aggregate slowly to yield MOFs. The formation of secondary building units (SBUs) and their evolution into MOFs are modeled using detailed kinetic rate equations and population balance equations, respectively. The effect of rate constants, aggregation frequency, the concentration of organic linkers, and concurrent crystallization of organic linkers are studied on the dynamics of SBU and MOF formation. The results qualitatively explain the longer timescales involved in the synthesis of MOF. The fundamental insights gained from modeling and simulation analysis can be used to optimize the operating conditions for a higher yield of MOF crystals. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Direct Observation of Growth Rate Dispersion in the Enzymatic Reactive Crystallization of Ampicillin
Processes 2019, 7(6), 390; https://doi.org/10.3390/pr7060390 - 22 Jun 2019
Abstract
Prediction and control of crystal size distributions, a prerequisite for production of consistent crystalline material in the pharmaceutical industry, requires knowledge of potential non-idealities of crystal growth. Ampicillin is one such medicine consumed in crystal form (ampicillin trihydrate). Typically it is assumed that [...] Read more.
Prediction and control of crystal size distributions, a prerequisite for production of consistent crystalline material in the pharmaceutical industry, requires knowledge of potential non-idealities of crystal growth. Ampicillin is one such medicine consumed in crystal form (ampicillin trihydrate). Typically it is assumed that all crystals of the same chemical and geometric type grow at the same rate, however a distribution of growth rates is often observed experimentally. In this study, ampicillin produced enzymatically is crystallized and a distribution of growth rates is observed as individual crystals are monitored by microscopy. Most studies of growth rate dispersion use complex flow apparatuses to maintain a constant supersaturation or imprecise measurements of size distributions to reconstruct growth rate dispersions. In this study, the controllable enzyme reaction enables the same information to be gathered from fewer, less complicated experiments. The growth rates of individual ampicillin trihydrate crystals were found to be normally distributed, with each crystal having an intrinsic growth rate that is constant in time. Differences in the individual crystals, such as different number and arrangement of dislocations and surface morphology, best explain the observed growth rates. There is a critical supersaturation below which growth is not observed, thought to be caused by reactants adsorbing to the crystal surface and pinning advancing growth steps. The distribution of critical supersaturation also suggests that individual crystals’ surface morphologies cause a distribution of growth rates. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Advantages of Utilizing Population Balance Modeling of Crystallization Processes for Particle Size Distribution Prediction of an Active Pharmaceutical Ingredient
Processes 2019, 7(6), 355; https://doi.org/10.3390/pr7060355 - 10 Jun 2019
Abstract
Active pharmaceutical ingredient (API) particle size distribution is important for both downstream processing operations and in vivo performance. Crystallization process parameters and reactor configuration are important in controlling API particle size distribution (PSD). Given the large number of parameters and the scale-dependence of [...] Read more.
Active pharmaceutical ingredient (API) particle size distribution is important for both downstream processing operations and in vivo performance. Crystallization process parameters and reactor configuration are important in controlling API particle size distribution (PSD). Given the large number of parameters and the scale-dependence of many parameters, it can be difficult to design a scalable crystallization process that delivers a target PSD. Population balance modeling is a useful tool for understanding crystallization kinetics, which are primarily scale-independent, predicting PSD, and studying the impact of process parameters on PSD. Although population balance modeling (PBM) does have certain limitations, such as scale dependency of secondary nucleation, and is currently limited in commercial software packages to one particle dimension, which has difficulty in predicting PSD for high aspect ratio morphologies, there is still much to be gained from applying PBM in API crystallization processes. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Graphical abstract

Open AccessArticle
On Molecular Descriptors of Face-Centered Cubic Lattice
Processes 2019, 7(5), 280; https://doi.org/10.3390/pr7050280 - 13 May 2019
Cited by 4
Abstract
Face-centered cubic lattice F C C ( n ) has received extensive consideration as of late, inferable from its recognized properties and non-poisonous nature, minimal effort, plenitude, and basic creation process. The graph of a face-centered cubic cross-section contains cube points and face [...] Read more.
Face-centered cubic lattice F C C ( n ) has received extensive consideration as of late, inferable from its recognized properties and non-poisonous nature, minimal effort, plenitude, and basic creation process. The graph of a face-centered cubic cross-section contains cube points and face centres. A topological index of a molecular graph G is a numeric amount identified with G, which depicts its topological properties. In this paper, using graph theory tools, we computed the molecular descriptors (topological indices)—to be specific, Zagreb-type indices, a forgotten index, a Balaban index, the fourth version of an atom–bond connectivity index, and the fifth version of a geometric arithmetic index for face-centered cubic lattice F C C ( n ) . Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Thermodynamic vs. Kinetic Basis for Polymorph Selection
Processes 2019, 7(5), 272; https://doi.org/10.3390/pr7050272 - 09 May 2019
Cited by 1
Abstract
Ratios of equilibrium solubilities rarely exceed two-fold for polymorph pairs. A model has been developed based on two intrinsic properties of polymorph pairs, namely the ratio of equilibrium solubilities of the individual pairs (C*me/C*st) and [...] Read more.
Ratios of equilibrium solubilities rarely exceed two-fold for polymorph pairs. A model has been developed based on two intrinsic properties of polymorph pairs, namely the ratio of equilibrium solubilities of the individual pairs (C*me/C*st) and the ratio of interfacial energies (γst/γme) and one applied experimental condition, namely the supersaturation identifies which one of a pair of polymorphs nucleates first. A domain diagram has been developed, which identifies the point where the critical free energy of nucleation for the polymorph pair are identical. Essentially, for a system supersaturated with respect to both polymorphs, the model identifies that low supersaturation with respect to the stable polymorph (Sst) leads to an extremely small supersaturation with respect to the metastable polymorph (Sme), radically driving up the critical free energy with respect to the metastable polymorph. Generally, high supersaturations sometimes much higher than the upper limit of the metastable zone, are required to kinetically favour the metastable polymorph. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessFeature PaperArticle
Exploring New Crystal Structures of Glycine via Electric Field-Induced Structural Transformations with Molecular Dynamics Simulations
Processes 2019, 7(5), 268; https://doi.org/10.3390/pr7050268 - 08 May 2019
Cited by 2
Abstract
Being able to control polymorphism of a crystal is of great importance to many industries, including the pharmaceutical industry, since the crystal’s structure determines significant physical properties of a material. While there are many conventional methods used to control the final crystal structure [...] Read more.
Being able to control polymorphism of a crystal is of great importance to many industries, including the pharmaceutical industry, since the crystal’s structure determines significant physical properties of a material. While there are many conventional methods used to control the final crystal structure that comes out of a crystallization unit, these methods fail to go beyond a few known structures that are kinetically accessible. Recent studies have shown that externally applied fields have the potential to effectively control polymorphism and to extend the set of observable polymorphs that are not accessible through conventional methods. This computational study focuses on the application of high-intensity dc electric fields (e-fields) to induce solid-state transformation of glycine crystals to obtain new polymorphs that have not been observed via experiments. Through molecular dynamics simulations of solid-state α -, β -, and γ -glycine crystals, it has been shown that the new polymorphs sustain their structures within 125 ns after the electric field has been turned off. It was also demonstrated that strength and direction of the electric field and the initial structure of the crystal are parameters that affect the resulting polymorph. Our results showed that application of high-intensity dc electric fields on solid-state crystals can be an effective crystal structure control method for the exploration of new crystal structures of known materials and to extend the range of physical properties a material can have. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Graphical abstract

Open AccessFeature PaperArticle
Mechanism and Modelling of Reactive Crystallization Process of Lithium Carbonate
Processes 2019, 7(5), 248; https://doi.org/10.3390/pr7050248 - 28 Apr 2019
Abstract
The reactive crystallization of lithium carbonate (Li2CO3) from lithium sulfate (Li2SO4) and sodium carbonate (Na2CO3) solutions is a key process in harvesting solid lithium, whether from ores, brines, or clays. However, [...] Read more.
The reactive crystallization of lithium carbonate (Li2CO3) from lithium sulfate (Li2SO4) and sodium carbonate (Na2CO3) solutions is a key process in harvesting solid lithium, whether from ores, brines, or clays. However, the process kinetics and mechanism remain poorly understood and the modelling of the reactive crystallization of Li2CO3 is not available. Hence, this work aims to determine the kinetics and mechanisms of the nucleation and growth of Li2CO3 reactive crystallization by induction time measurements and to model and optimize the crystallization process using response surface methodology. Induction time measurements were carried out as functions of initial supersaturation and temperature using a laser method. It was found that the primary nucleation mechanism of Li2CO3 varies with solution supersaturations, in which, expectedly, the heterogenous nucleation mechanism dominates at low supersaturations while the homogeneous nucleation mode governs at high supersaturations. The transition point between heterogenous and homogenous nucleation was found to vary with temperatures. Growth modes of Li2CO3 crystals were investigated by relating induction time data with various growth mechanisms, revealing a two-dimensional nucleation-mediated growth mechanism. The modelling and optimization of a complex reactive crystallization were performed by response surface methodology (RSM), and the effects of various crystallization parameters on product and process performances were examined. Solution concentration was found to be the critical factor determining the yield of crystallization, while stirring speed was found to play a dominant role in the particle size of Li2CO3 crystals. Our findings may provide a better understanding of the reactive crystallization process of Li2CO3 and are critical in relation to the crystallization design and control of Li2CO3 production from lithium sulfate sources. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1

Open AccessArticle
Microstructure and Resistivity Analysis of Silver Nanoparticle-Based Crystalline Conductive Films Synthesized using PEG Surfactant
Processes 2019, 7(5), 245; https://doi.org/10.3390/pr7050245 - 27 Apr 2019
Abstract
Silver nanoparticle-based crystalline conductive films were synthesized using a simple and environmentally friendly method centered on chemical reduction. A stoichiometric balance of three different molecular weights of polyethylene glycol (PEG) was used as a capping agent. Resistivity, and its correlation with temperature and [...] Read more.
Silver nanoparticle-based crystalline conductive films were synthesized using a simple and environmentally friendly method centered on chemical reduction. A stoichiometric balance of three different molecular weights of polyethylene glycol (PEG) was used as a capping agent. Resistivity, and its correlation with temperature and the particle size of nanoparticle films, was probed. The silver nanoparticles were characterized using thermogravimetric analysis (TGA) and field emission scanning electron microscopy (FESEM). Further silver films deposited on a glass substrate were characterized by FESEM, Fourier transform infrared spectroscopy (FTIR), X-ray diffraction (XRD) and resistivity measurements. Particle size distribution and room temperature electrical conductivity were also investigated. The high conductivity of sintered films suggested applications for the ink-jet printing of electronic circuitry on thermally sensitive substrates. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Graphical abstract

Review

Jump to: Research

Open AccessFeature PaperReview
Review and Modeling of Crystal Growth of Atropisomers from Solutions
Processes 2019, 7(9), 611; https://doi.org/10.3390/pr7090611 - 10 Sep 2019
Abstract
In this paper, theories on anisotropic crystal growth and crystallization of atropisomers are reviewed and a model for anisotropic crystal growth from solution containing slow inter-converting conformers is presented. The model applies to systems with growth-dominated crystallization from solutions and assumes that only [...] Read more.
In this paper, theories on anisotropic crystal growth and crystallization of atropisomers are reviewed and a model for anisotropic crystal growth from solution containing slow inter-converting conformers is presented. The model applies to systems with growth-dominated crystallization from solutions and assumes that only one conformation participates in the solute integration step and is present in the crystal lattice. Other conformers, defined as the wrong conformers, must convert to the right conformer before they can assemble to the crystal lattice. The model presents a simple implicit method for evaluating the growth inhibition effect by the wrong conformers. The crystal growth model applies to anisotropic growth in two main directions, namely a slow-growing face and a fast-growing face and requires the knowledge of solute crystal face integration coefficients in both directions. A parameter estimation algorithm was derived to extract those coefficients from data about temporal concentration and crystal size during crystallization and was designed to have a short run time, while providing a high-resolution estimation. The model predicts a size-dependent growth rate and simulations indicated that for a given seed size and solvent system and for an isothermal anti-solvent addition crystallization, the seed loading and the supersaturation at seeding are the main factors impacting the final aspect ratio. The model predicts a decrease of the growth inhibition effect by the wrong conformer with increasing temperature, likely due to faster equilibration between conformers and/or a decrease of the population of the wrong conformer, if of low energy, at elevated temperatures. Finally, the model predicts that solute surface integration becomes the rate-limiting mechanism for high solute integration activation energies, resulting in no impact of the WC on the overall crystal growth process. Full article
(This article belongs to the Special Issue Modeling and Control of Crystallization)
Show Figures

Figure 1
