Energy Efficiency Improvement of Electric Machines without Rare-Earth Magnets

A special issue of Energies (ISSN 1996-1073). This special issue belongs to the section "F: Electrical Engineering".

Deadline for manuscript submissions: closed (31 December 2022) | Viewed by 29685

Printed Edition Available!
A printed edition of this Special Issue is available here.

Special Issue Editors

Dr. Vladimir Prakht

E-Mail Website
Guest Editor
Department of Electrical Engineering, Ural Federal University, 620002 Yekaterinburg, Russia
Interests: energy efficiency; electric machines; electric motors; electric generators; electric drives; gearless generators; gearless motors; high-speed electric machines
Special Issues, Collections and Topics in MDPI journals
Dr. Mohamed N. Ibrahim

E-Mail Website
Guest Editor
Department of Electromechanical, Systems and Metal Engineering, Ghent University, 9052 Ghent, Belgium
Interests: synchronous reluctance machine; permanent magnet assisted synchronous reluctance motors; field-oriented control; winding function; harmonic analysis; star-delta; magnetic steel grade and optimization techniques
Special Issues, Collections and Topics in MDPI journals
Dr. Vadim Kazakbaev

E-Mail Website
Guest Editor
Department of Electrical Engineering, Ural Federal University, 620002 Yekaterinburg, Russia
Interests: electric drives; electrical machines; energy efficiency; energy saving; modeling; optimization

Special Issue Information

Dear Colleagues,

Electric motors consume about 70% of industrial electricity and about 40%–45% of produced electricity in the world. This reveals that using high-efficiency electric motors will reduce energy consumption and the environmental impact, resulting in saving a lot of money and reducing the emissions of CO2. In addition, it will significantly reduce the need for new power plants, thus reducing the invested resources to do so. Electric machines with rare-earth magnets have the highest efficiency and power density.

However, rare-earth magnets are expensive, and their manufacturing process, as well as mining rare-earth raw materials, is harmful for the environment. Therefore, developing energy-efficient electric machines without rare-earth magnets is of great interest. Topics of interest for this Special Issue include but are not limited to:

- Modeling and design of energy-efficient electric machines without rare-earth magnets;

- Synchronous reluctance machines;

- Permanent magnet assisted synchronous reluctance machines;

- Switched reluctance machines;

- Hybrid switched reluctance machines;

- DC excited flux-switching machines;

- PM excited flux-switching machines;

- DC excited synchronous machines;

- Direct-on-line and line start motors;

- Induction machines;

- Electric generators without rare-earth magnets for wind turbines;

- Other electric machines without rare-earth magnets;

- Control techniques for electric machines without rare-earth magnets.

Dr. Vladimir Prakht
Dr. Mohamed N. Ibrahim
Dr. Vadim Kazakbaev
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Energies is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • electric machines
  • electric motors
  • electric generators
  • control techniques for electric machines
  • electric drives

Related Special Issue

Published Papers (11 papers)

Download All Papers
Order results
Result details
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Editorial

Jump to: Research

3 pages, 162 KiB
Editorial
Energy Efficiency Improvement of Electric Machines without Rare-Earth Magnets
by Vladimir Prakht, Mohamed N. Ibrahim and Vadim Kazakbaev
Energies 2023, 16(8), 3573; https://doi.org/10.3390/en16083573 - 20 Apr 2023
Cited by 1 | Viewed by 1049
Abstract
Electric motors are one of the largest consumers of electricity and are responsible for 40–45% of the world’s energy consumption [...] Full article
(This article belongs to the Special Issue Energy Efficiency Improvement of Electric Machines without Rare-Earth Magnets)
