Aerospace, Volume 4, Issue 3 (September 2017) – 17 articles

Cover Story (view full-size image): In full-scale wind tunnel tests, aerodynamic characteristics of helicopter engine side air intakes are investigated. The experimental data is obtained by testing of a helicopter fuselage section model (complete fuselage in grey, section model displayed in orange and blue). Engine mass flow rates are reproduced to simulate realistic engine operation. Five-hole pressure probe data of the aerodynamic interface plane and surface pressure distributions are applied to evaluate different intake shapes. The optimization potential of retrofit modifications such as a rear spoiler and an inlet guide vane is assessed in reference to a baseline geometry. View the paper here.
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
1660 KiB
Article
Rarefication Effects on Jet Impingement Loads
by Shiying Cai, Chunpei Cai, Kai Zhang and Jun Li
Aerospace 2017, 4(3), 48; https://doi.org/10.3390/aerospace4030048 - 19 Sep 2017
Cited by 6 | Viewed by 5875
Abstract
Rarefication effects on jet impingement loads are studied by comparing recent new formulas at the collisionless flow limit and numerical simulations. The jet exit size is finite, and can be either planar or round. In the simulations, the jets have different degrees of [...] Read more.
Rarefication effects on jet impingement loads are studied by comparing recent new formulas at the collisionless flow limit and numerical simulations. The jet exit size is finite, and can be either planar or round. In the simulations, the jets have different degrees of rarefication, with a Knudsen (Kn) number ranging from 0 to infinity; i.e., the jet flows can be continuum, collisional, or collisionless. The comparison results indicate that (1) the new surface load formulas are accurate at the collisionless flow limit; (2) in general, the formulas offer upper limits for the peak loads; (3) however, it is improper to assert that local loads always decrease. The new formulas can offer fast estimations of impingement loads. This may be quite helpful for applications in space engineering by significantly reducing the amount of simulations and experiment costs. Those expressions explicitly include non-dimensional parameters, and their contribution and influence on the loads can be studied in a systematic manner (e.g., with a swift parameter study). Full article
Show Figures

Figure 1

5101 KiB
Article
Analysis of Radar and ADS-B Influences on Aircraft Detect and Avoid (DAA) Systems
by William Semke, Nicholas Allen, Asma Tabassum, Matthew McCrink, Mohammad Moallemi, Kyle Snyder, Evan Arnold, Dawson Stott and Michael G. Wing
Aerospace 2017, 4(3), 49; https://doi.org/10.3390/aerospace4030049 - 18 Sep 2017
Cited by 16 | Viewed by 11688
Abstract
Detect and Avoid (DAA) systems are complex communication and locational technologies comprising multiple independent components. DAA technologies support communications between ground-based and space-based operations with aircraft. Both manned and unmanned aircraft systems (UAS) rely on DAA communication and location technologies for safe flight [...] Read more.
Detect and Avoid (DAA) systems are complex communication and locational technologies comprising multiple independent components. DAA technologies support communications between ground-based and space-based operations with aircraft. Both manned and unmanned aircraft systems (UAS) rely on DAA communication and location technologies for safe flight operations. We examined the occurrence and duration of communication losses between radar and automatic dependent surveillance–broadcast (ADS-B) systems with aircraft operating in proximate airspace using data collected during actual flight operations. Our objectives were to identify the number and duration of communication losses for both radar and ADS-B systems that occurred within a discrete time period. We also investigated whether other unique communication behavior and anomalies were occurring, such as reported elevation deviations. We found that loss of communication with both radar and ADS-B systems does occur, with variation in the length of communication losses. We also discovered that other unexpected behaviors were occurring with communications. Although our data were gathered from manned aircraft, there are also implications for UAS that are operating within active airspaces. We are unaware of any previously published work on occurrence and duration of communication losses between radar and ADS-B systems. Full article
(This article belongs to the Special Issue Radar and Aerospace)
Show Figures

Figure 1

1004 KiB
Article
Evolutionary Approach to Lambert’s Problem for Non-Keplerian Spacecraft Trajectories
by David W. Hinckley, Jr. and Darren L. Hitt
Aerospace 2017, 4(3), 47; https://doi.org/10.3390/aerospace4030047 - 11 Sep 2017
Cited by 5 | Viewed by 6836
Abstract
In this paper, we use differential evolution (DE), with best-evolved results refined using a Nelder–Mead optimization, to solve boundary-value complex problems in orbital mechanics relevant to low Earth orbits (LEO). A class of Lambert-type problems is examined to evaluate the performance of this [...] Read more.
In this paper, we use differential evolution (DE), with best-evolved results refined using a Nelder–Mead optimization, to solve boundary-value complex problems in orbital mechanics relevant to low Earth orbits (LEO). A class of Lambert-type problems is examined to evaluate the performance of this evolutionary method in its application to solving nonlinear boundary value problems (BVP) arising in mission planning. In this method, we evolve impulsive initial velocity vectors giving rise to intercept trajectories that take a spacecraft from given initial position in space to specified target position. The positional error of the final position is minimized subject to time-of-flight and/or energy (fuel) constraints. The method is first validated by demonstrating its ability to recover known analytical solutions obtainable with the assumption of Keplerian motion; the method is then applied to more complex non-Keplerian problems incorporating trajectory perturbations arising in low Earth orbit (LEO) due to the Earth’s oblateness and rarefied atmospheric drag. The viable trajectories obtained for these challenging problems demonstrate the ability of this computational approach to handle Lambert-type problems with arbitrary perturbations, such as those occurring in realistic mission trajectory design. Full article
(This article belongs to the Special Issue Feature Papers in Aerospace)
Show Figures

Graphical abstract

3816 KiB
Article
Modelling Airport Pollutants Dispersion at High Resolution
by Claire Sarrat, Sébastien Aubry, Thomas Chaboud and Christine Lac
Aerospace 2017, 4(3), 46; https://doi.org/10.3390/aerospace4030046 - 25 Aug 2017
Cited by 10 | Viewed by 7523
Abstract
Local air quality is a major concern for the population regularly exposed to high levels of air pollution. Due mainly to its aircraft engine activities during taxiing and take-off, the airport is often submitted to heterogeneous but important concentrations of NO x and [...] Read more.
Local air quality is a major concern for the population regularly exposed to high levels of air pollution. Due mainly to its aircraft engine activities during taxiing and take-off, the airport is often submitted to heterogeneous but important concentrations of NO x and Particulate Matter (PM). The study suggests an innovative approach to determining the air traffic impact on air quality at the scale of the airport, its runways, and its terminals, to be able to locate the persistent high-concentration spots, for example. The pollutant concentrations at 10 m resolution and 1 s time step are calculated in order to identify the most affected areas of an airport platform and their contributors. A real day of air traffic on a regional airport is simulated, using observations and aircraft trajectories data from radar streams. In order to estimate the aircraft emissions, the Air Transport Systems Evaluation Infrastructure (IESTA) is used. Regarding local air quality, IESTA relies on the non-hydrostatic meso-scale atmospheric model Meso-NH using its grid-nesting capabilities with three domains. The detailed cartography of the airport distinguishes between grassland, parking, and terminals, allowing the computation of exchanges of heat, water, and momentum between the different types of surfaces and the atmosphere as well as the interactions with the building using a drag force. The dynamic parameters like wind, temperature, turbulent kinetic energy, and pollutants concentration are computed at 10 m resolution over the 2 km × 4 km airport domain. The pollutants are considered in this preliminary study as passive tracers, without chemical reactions. This study aims at proving the feasibility of high-scale modelling over an airport with state-of-the-art physical models in order to better understand the repartition of pollutants over an airport, taking into account advection and turbulence in interactions with buildings and regional trends, emissions, Auxiliary Power Units (APU), taxiing, parking, take off. All these processes drive the model at each time step and are not averaged over one hour or more like in Gaussian or Lagrangian ones. This study is investigating the feasibility of high spatio-temporal air quality modelling for research purposes but not for operational forecasting. Full article
Show Figures

Figure 1

6139 KiB
Article
Hybrid Electric Aircraft Propulsion Case Study for Skydiving Mission
by Richard Glassock, Michael Galea, Warren Williams and Tibor Glesk
Aerospace 2017, 4(3), 45; https://doi.org/10.3390/aerospace4030045 - 18 Aug 2017
Cited by 29 | Viewed by 17563
Abstract
This paper describes a case study for applying innovative architectures related to electrified propulsion for aircraft. Electric and hybrid electric propulsion for aircraft has gained widespread and significant attention over the past decade. The driver for industry interest has principally been the need [...] Read more.
This paper describes a case study for applying innovative architectures related to electrified propulsion for aircraft. Electric and hybrid electric propulsion for aircraft has gained widespread and significant attention over the past decade. The driver for industry interest has principally been the need to reduce emissions of combustion engine exhaust products and noise, but increasingly studies revealed potential for overall improvement in energy efficiency and mission flexibility of new aircraft types. In this work, a conceptual new type for a skydiver lift mission aircraft is examined. The opportunities which electric hybridisation offers for this role is analysed in comparison with conventional legacy type propulsion systems. For a conventional commercial skydiving mission, an all-electric propulsion system is shown as viable, and a hybrid-electric system is shown to reduce aircraft fuel costs and CO2 emissions whilst maintaining conventional aero-engine operational benefits. The new paradigm for aircraft development which hybrid electric propulsion enables has highlighted significant issues with aircraft certification practices as they exist today. The advancement of aircraft design and production to harness the value of new propulsion systems may require adaption and development of certification standards to cater for these new technologies. Full article
Show Figures

Figure 1

18112 KiB
Article
GPS Based Navigation Performance Analysis within and beyond the Space Service Volume for Different Transmitters’ Antenna Patterns
by Endrit Shehaj, Vincenzo Capuano, Cyril Botteron, Paul Blunt and Pierre-André Farine
Aerospace 2017, 4(3), 44; https://doi.org/10.3390/aerospace4030044 - 15 Aug 2017
Cited by 20 | Viewed by 8427
Abstract
In recent years, global navigation satellite system (GNSS)-based navigation in high earth orbits (HEOs) has become a field of research interest since it can increase the spacecraft’s autonomy, thereby reducing the operating costs. However, the GNSS availability and the GNSS-based navigation performance for [...] Read more.
In recent years, global navigation satellite system (GNSS)-based navigation in high earth orbits (HEOs) has become a field of research interest since it can increase the spacecraft’s autonomy, thereby reducing the operating costs. However, the GNSS availability and the GNSS-based navigation performance for a spacecraft orbiting above the GNSS constellation are strongly constrained by the signals’ power levels at the receiver position and the sensitivity. The simulated level of signal power at the receiver’s position may considerably increase or decrease when assuming different gain/attenuation values of the transmitter antenna for a certain azimuth and elevation. Assuming a slightly different antenna pattern therefore may significantly change the simulated signal’s availability results and accordingly the simulated navigation accuracy, leading to an inexact identification of the requirements for the GNSS receiver. This problem particularly concerns the case of orbital trajectories above the GNSS constellation, where most of the signals received are radiated from the secondary lobe of the transmitters’ antennas, for which typically very little information is known. At the time of this study, it was possible to model quite accurately the global positioning system (GPS) L1 antenna patterns for the IIR and IIR-M Blocks because of the precise information available. No accurate information was available for the GPS L1 antenna patterns of the IIF Block. Even less accurate information was available on the GPS L5 antenna patterns. In this context, this paper aims at investigating the effect of different antenna pattern assumptions on the simulated signal availability and on the consequent simulated navigation performance of a spaceborne receiver orbiting in a very highly elliptical orbit from the Earth to the Moon. Initially the impact of averaging the transmitter’s antenna gain over the azimuth, a typical assumption in many studies, is analyzed. Afterwards, we also consider three different L5 antenna patterns assumed in the literature (the precise L5 patterns are unfortunately not yet fully available). For each of the considered antenna pattern assumptions, we simulate received signal power level, availability, geometric dilution of precision (GDOP), and navigation accuracy in order to evaluate their different effects. After identifying the most conservative assumptions for the transmitters’ antenna patterns, for each elevation of the receiver antenna, we also compute the number of available GNSS observations and analyze their distribution. Moreover, possible aiding of the acquisition process using the prediction of the elevation at which the signal is transmitted, as well as the elevation at which the signal is received, are discussed. Finally, the impact on the GDOP of using only signals transmitted from certain angle intervals of the transmitter antenna pattern and the importance of selecting the transmitters that provide the best GDOP (in the case of a receiver with a limited number of channels) are considered and discussed. Full article
Show Figures

Graphical abstract

414 KiB
Article
Efficient Algorithm for a k-out-of-N System Reliability Modeling-Case Study: Pitot Sensors System for Aircraft Velocity
by Wajih Ezzeddine, Jérémie Schutz and Nidhal Rezg
Aerospace 2017, 4(3), 43; https://doi.org/10.3390/aerospace4030043 - 2 Aug 2017
Cited by 2 | Viewed by 5979
Abstract
The k-out-of-N system is widely applied in several industrial systems. This structure is a part of fault-tolerant systems for which both parallel and series systems are special cases. Because of the importance of industrial systems reliability determination for production and maintenance [...] Read more.
The k-out-of-N system is widely applied in several industrial systems. This structure is a part of fault-tolerant systems for which both parallel and series systems are special cases. Because of the importance of industrial systems reliability determination for production and maintenance management purposes, a number of techniques and methods are incorporated to formulate and estimate its analytic expression. In this paper, an algorithm is put forward for a k-out-of-N system with identical components under information about the influence factors that affect the system efficiency. The developed approach is applied in the case of the Pitot sensors system. However, the algorithm application could be generalized for any device which during a mission is subject to environmental and operational factors that affect its degradation process. Full article
Show Figures

Figure 1

1815 KiB
Article
A Concept for Multi-Criteria Environmental Assessment of Aircraft Trajectories
by Sigrun Matthes, Volker Grewe, Katrin Dahlmann, Christine Frömming, Emma Irvine, Ling Lim, Florian Linke, Benjamin Lührs, Bethan Owen, Keith Shine, Stavros Stromatas, Hiroshi Yamashita and Feijia Yin
Aerospace 2017, 4(3), 42; https://doi.org/10.3390/aerospace4030042 - 1 Aug 2017
Cited by 44 | Viewed by 10566
Abstract
Comprehensive assessment of the environmental aspects of flight movements is of increasing interest to the aviation sector as a potential input for developing sustainable aviation strategies that consider climate impact, air quality and noise issues simultaneously. However, comprehensive assessments of all three environmental [...] Read more.
Comprehensive assessment of the environmental aspects of flight movements is of increasing interest to the aviation sector as a potential input for developing sustainable aviation strategies that consider climate impact, air quality and noise issues simultaneously. However, comprehensive assessments of all three environmental aspects do not yet exist and are in particular not yet operational practice in flight planning. The purpose of this study is to present a methodology which allows to establish a multi-criteria environmental impact assessment directly in the flight planning process. The method expands a concept developed for climate optimisation of aircraft trajectories, by representing additionally air quality and noise impacts as additional criteria or dimensions, together with climate impact of aircraft trajectory. We present the mathematical framework for environmental assessment and optimisation of aircraft trajectories. In that context we present ideas on future implementation of such advanced meteorological services into air traffic management and trajectory planning by relying on environmental change functions (ECFs). These ECFs represent environmental impact due to changes in air quality, noise and climate impact. In a case study for Europe prototype ECFs are implemented and a performance assessment of aircraft trajectories is performed for a one-day traffic sample. For a single flight fuel-optimal versus climate-optimized trajectory solution is evaluated using prototypic ECFs and identifying mitigation potential. The ultimate goal of such a concept is to make available a comprehensive assessment framework for environmental performance of aircraft operations, by providing key performance indicators on climate impact, air quality and noise, as well as a tool for environmental optimisation of aircraft trajectories. This framework would allow studying and characterising changes in traffic flows due to environmental optimisation, as well as studying trade-offs between distinct strategic measures. Full article
Show Figures

Figure 1

6807 KiB
Article
Assessing the Ability of the DDES Turbulence Modeling Approach to Simulate the Wake of a Bluff Body
by Matthieu Boudreau, Guy Dumas and Jean-Christophe Veilleux
Aerospace 2017, 4(3), 41; https://doi.org/10.3390/aerospace4030041 - 1 Aug 2017
Cited by 13 | Viewed by 9230
Abstract
A detailed numerical investigation of the flow behind a square cylinder at a Reynolds number of 21,400 is conducted to assess the ability of the delayed detached-eddy simulation (DDES) modeling approach to accurately predict the velocity recovery in the wake of a bluff [...] Read more.
A detailed numerical investigation of the flow behind a square cylinder at a Reynolds number of 21,400 is conducted to assess the ability of the delayed detached-eddy simulation (DDES) modeling approach to accurately predict the velocity recovery in the wake of a bluff body. Three-dimensional unsteady Reynolds-averaged Navier–Stokes (URANS) and DDES simulations making use of the Spalart–Allmaras turbulence model are carried out using the open-source computational fluid dynamics (CFD) toolbox OpenFOAM-2.1.x, and are compared with available experimental velocity measurements. It is found that the DDES simulation tends to overestimate the averaged streamwise velocity component, especially in the near wake, but a better agreement with the experimental data is observed further downstream of the body. The velocity fluctuations also match reasonably well with the experimental data. Moreover, it is found that the spanwise domain length has a significant impact on the flow, especially regarding the fluctuations of the drag coefficient. Nonetheless, for both the averaged and fluctuating velocity components, the DDES approach is shown to be superior to the URANS approach. Therefore, for engineering purposes, it is found that the DDES approach is a suitable choice to simulate and characterize the velocity recovery in a wake. Full article
(This article belongs to the Special Issue Computational Aerodynamic Modeling of Aerospace Vehicles)
Show Figures

Figure 1

3064 KiB
Article
Vibratory Reliability Analysis of an Aircraft’s Wing via Fluid–Structure Interactions
by Rabii El Maani, Bouchaïb Radi and Abdelkhalak El Hami
Aerospace 2017, 4(3), 40; https://doi.org/10.3390/aerospace4030040 - 1 Aug 2017
Cited by 9 | Viewed by 6976
Abstract
The numerical simulation of multiphysics problems has grown steadily in recent years. This development is due to both the permanent increase of IT resources and the considerable progress made in modeling, mathematical and numerical analysis of many problems in fluid and solid mechanics. [...] Read more.
The numerical simulation of multiphysics problems has grown steadily in recent years. This development is due to both the permanent increase of IT resources and the considerable progress made in modeling, mathematical and numerical analysis of many problems in fluid and solid mechanics. The phenomena related to fluid/structure mechanical coupling occurs in many industrial situations, and the influence it may have on the dynamic behavior of mechanical systems is often significant. In this paper, a numerical vibratory study is conducted on a three-dimensional aircraft’s wing subjected to aerodynamic loads. Finite volume method (FVM) is used for the discretization of the fluid problem, and finite element method (FEM) is used for the structure’s approximation. In this context, a deterministic model has been proposed in our study, then stochastic analysis has been developed to deal with the statistical nature of fluid–structure interaction parameters. Moreover, probabilistic-based reliability analysis intends to find safe and cost-effective projects. Full article
Show Figures

Figure 1

4083 KiB
Article
Numerical and Experimental Investigations of an Elasto-Flexible Membrane Wing at a Reynolds Number of 280,000
by Julie Piquee and Christian Breitsamter
Aerospace 2017, 4(3), 39; https://doi.org/10.3390/aerospace4030039 - 27 Jul 2017
Cited by 7 | Viewed by 7767
Abstract
This work presents numerical and experimental investigations of an elasto-flexible membrane wing at a Reynolds number of 280,000. Such a concept has the capacity to adapt itself to the incoming flow offering a wider range of the flight envelope. This adaptation is clearly [...] Read more.
This work presents numerical and experimental investigations of an elasto-flexible membrane wing at a Reynolds number of 280,000. Such a concept has the capacity to adapt itself to the incoming flow offering a wider range of the flight envelope. This adaptation is clearly observed in the numerical study: the camber of the airfoil changes with the dynamic pressure and the angle of attack, which permits a smoother and delayed stall. The numerical results, obtained from Fluid Structure Interaction (FSI) simulations, also show that the laminar-turbulent transition influences the aerodynamic characteristics of the wing, as it directly affects the pressure distribution on the membrane and the geometry of the airfoil. Two different turbulence models were therefore tested. Furthermore, experimental investigations are considered in this paper to estimate the precision of the FSI simulations. It appears that the FSI study overestimates the lift coefficient, and the drag coefficient is undervalued, which can be explained by dynamic calibration of the model. Nevertheless, the velocity field obtained with the hot-wire anemometry system shows good agreement on the upper side of the model. The membrane deflection measurements also appear to be consistent with the expected geometry of the deformed airfoil from the FSI simulations. Full article
(This article belongs to the Special Issue Adaptive/Smart Structures and Multifunctional Materials in Aerospace)
Show Figures

Figure 1

7134 KiB
Article
METRIC: A Dedicated Earth-Orbiting Spacecraft for Investigating Gravitational Physics and the Space Environment
by Roberto Peron and Enrico C. Lorenzini
Aerospace 2017, 4(3), 38; https://doi.org/10.3390/aerospace4030038 - 20 Jul 2017
Cited by 3 | Viewed by 7206
Abstract
A dedicated mission in low Earth orbit is proposed to test predictions of gravitational interaction theories and to directly measure the atmospheric density in a relevant altitude range, as well as to provide a metrological platform able to tie different space geodesy techniques. [...] Read more.
A dedicated mission in low Earth orbit is proposed to test predictions of gravitational interaction theories and to directly measure the atmospheric density in a relevant altitude range, as well as to provide a metrological platform able to tie different space geodesy techniques. The concept foresees a small spacecraft to be placed in a dawn-dusk eccentric orbit between 450 and 1200 km of altitude. The spacecraft will be tracked from the ground with high precision, and a three-axis accelerometer package on-board will measure the non-gravitational accelerations acting on its surface. Estimates of parameters related to fundamental physics and geophysics should be obtained by a precise orbit determination, while the accelerometer data will be instrumental in constraining the atmospheric density. Along with the mission scientific objectives, a conceptual configuration is described together with an analysis of the dynamical environment experienced by the spacecraft and the accelerometer. Full article
Show Figures

Figure 1

23784 KiB
Article
Bio-Inspired Flexible Flapping Wings with Elastic Deformation
by Tien Van Truong, Quoc-Viet Nguyen and Heow Pueh Lee
Aerospace 2017, 4(3), 37; https://doi.org/10.3390/aerospace4030037 - 15 Jul 2017
Cited by 24 | Viewed by 11337
Abstract
Over the last decades, there has been great interest in understanding the aerodynamics of flapping flight and development of flapping wing Micro Air Vehicles (FWMAVs). The camber deformation and twisting has been demonstrated quantitatively in a number of insects, but making artificial wings [...] Read more.
Over the last decades, there has been great interest in understanding the aerodynamics of flapping flight and development of flapping wing Micro Air Vehicles (FWMAVs). The camber deformation and twisting has been demonstrated quantitatively in a number of insects, but making artificial wings that mimic those features is a challenge. This paper reports the development and characterization of artificial wings that can reproduce camber and twisting deformations. By replacing the elastic material at the wing root vein, the root vein would bend upward and inward generating an angle of attack, camber, and twisting deformations while the wing was flapping due to the aerodynamic forces acting on the wing. The flapping wing apparatus was employed to study the flexible wing kinematics and aerodynamics of real scale insect wings. Multidisciplinary experiments were conducted to provide the natural frequency, the force production, three-dimensional wing kinematics, and the effects of wing flexibility experienced by the flexible wings. The results have shown that the present artificial wing was able to mimic the two important features of insect wings: twisting and camber generation. From the force measurement, it is found that the wing with the uniform deformation showed the higher lift/power generation in the flapping wing system. The present developed artificial wing suggests a new guideline for the bio-inspired wing of the FWMAV. Full article
(This article belongs to the Special Issue Aircraft Design (SI-1/2017))
Show Figures

Graphical abstract

161 KiB
Book Review
Time Series Analysis Methods and Applications for Flight Data. By Jianye Zhang and Peng Zhang. Springer: Berlin, Heidelberg, Germany, 2017; pp. 1–240; ISBN: 978-3-662-53430-4
by Guinsly Mondésir
Aerospace 2017, 4(3), 36; https://doi.org/10.3390/aerospace4030036 - 14 Jul 2017
Viewed by 6083
Abstract
This book [1] aims to present the best application for managing and clearly representing the massive amount of Flight Data (FD) that exists. [...] Full article
Show Figures

Graphical abstract

16418 KiB
Review
Constructal Theory and Aeroelastic Design of Flexible Flying Wing Aircraft
by Pezhman Mardanpour and Siavash Rastkar
Aerospace 2017, 4(3), 35; https://doi.org/10.3390/aerospace4030035 - 7 Jul 2017
Viewed by 9481
Abstract
The aeroelastic behavior of high-aspect-ratio very flexible flying wing is highly affected by the geometric nonlinearities of the aircraft structure. This paper reviews the findings on how these nonlinearities influence the structural and flight dynamics, and it shows that the aeroelastic flight envelope [...] Read more.
The aeroelastic behavior of high-aspect-ratio very flexible flying wing is highly affected by the geometric nonlinearities of the aircraft structure. This paper reviews the findings on how these nonlinearities influence the structural and flight dynamics, and it shows that the aeroelastic flight envelope could significantly be extended with proper choices of design parameters such as engine placement. Moreover, in order to investigate the physics behind the effects of design parameters, constructal theory of design is reviewed. The constructal theory advances the philosophy of design as science, it states that the better structural design emerges when stress flow strangulation is avoided. Furthermore, it shows that airplanes, through their evolution, have obeyed theoretical allometric rules that unite their designs. Full article
(This article belongs to the Special Issue Aircraft Design (SI-1/2017))
Show Figures

Figure 1

26603 KiB
Project Report
Mitigating the Climate Impact from Aviation: Achievements and Results of the DLR WeCare Project
by Volker Grewe, Katrin Dahlmann, Jan Flink, Christine Frömming, Robin Ghosh, Klaus Gierens, Romy Heller, Johannes Hendricks, Patrick Jöckel, Stefan Kaufmann, Katrin Kölker, Florian Linke, Tanja Luchkova, Benjamin Lührs, Jesper Van Manen, Sigrun Matthes, Andreas Minikin, Malte Niklaß, Martin Plohr, Mattia Righi, Simon Rosanka, Angela Schmitt, Ulrich Schumann, Ivan Terekhov, Simon Unterstrasser, Margarita Vázquez-Navarro, Christiane Voigt, Kai Wicke, Hiroshi Yamashita, Andreas Zahn and Helmut Ziereisadd Show full author list remove Hide full author list
Aerospace 2017, 4(3), 34; https://doi.org/10.3390/aerospace4030034 - 29 Jun 2017
Cited by 77 | Viewed by 17211
Abstract
The WeCare project (Utilizing Weather information for Climate efficient and eco efficient future aviation), an internal project of the German Aerospace Center (Deutsches Zentrum für Luft- und Raumfahrt, DLR), aimed at finding solutions for reducing the climate impact of aviation based on an [...] Read more.
The WeCare project (Utilizing Weather information for Climate efficient and eco efficient future aviation), an internal project of the German Aerospace Center (Deutsches Zentrum für Luft- und Raumfahrt, DLR), aimed at finding solutions for reducing the climate impact of aviation based on an improved understanding of the atmospheric impact from aviation by making use of measurements and modeling approaches. WeCare made some important contributions to advance the scientific understanding in the area of atmospheric and air transportation research. We characterize contrail properties, show that the aircraft type significantly influences these properties, and how contrail-cirrus interacts with natural cirrus. Aviation NOx emissions lead to ozone formation and we show that the strength of the ozone enhancement varies, depending on where within a weather pattern NOx is emitted. These results, in combination with results on the effects of aerosol emissions on low cloud properties, give a revised view on the total radiative forcing of aviation. The assessment of a fleet of strut-braced wing aircraft with an open rotor is investigated and reveals the potential to significantly reduce the climate impact. Intermediate stop operations have the potential to significantly reduce fuel consumption. However, we find that, if only optimized for fuel use, they will have an increased climate impact, since non-CO2 effects compensate the reduced warming from CO2 savings. Avoiding climate sensitive regions has a large potential in reducing climate impact at relatively low costs. Taking advantage of a full 3D optimization has a much better eco-efficiency than lateral re-routings, only. The implementation of such operational measures requires many more considerations. Non-CO2 aviation effects are not considered in international agreements. We showed that climate-optimal routing could be achieved, if market-based measures were in place, which include these non-CO2 effects. An alternative measure to foster climate-optimal routing is the closing of air spaces, which are very climate-sensitive. Although less effective than an unconstrained optimization with respect to climate, it still has a significant potential to reduce the climate impact of aviation. By combining atmospheric and air transportation research, we assess climate mitigation measures, aiming at providing information to aviation stakeholders and policy-makers to make aviation more climate compatible. Full article
Show Figures

Graphical abstract

7828 KiB
Article
Aerodynamic Testing of Helicopter Side Intake Retrofit Modifications
by Florian Knoth and Christian Breitsamter
Aerospace 2017, 4(3), 33; https://doi.org/10.3390/aerospace4030033 - 23 Jun 2017
Cited by 3 | Viewed by 8236
Abstract
Aerodynamic characteristics of helicopter engine side air intakes are investigated. The experimental data set is obtained by wind tunnel testing of a full-scale helicopter fuselage section model. For the simulation of realistic engine operation, engine mass flow rates are reproduced. Five-hole pressure probe [...] Read more.
Aerodynamic characteristics of helicopter engine side air intakes are investigated. The experimental data set is obtained by wind tunnel testing of a full-scale helicopter fuselage section model. For the simulation of realistic engine operation, engine mass flow rates are reproduced. Five-hole pressure probe data of the aerodynamic interface plane as well as local surface pressure distributions are compared for different geometries and operation conditions. Previous investigations indicate that unshielded, sideways-facing air intakes yield lowest distortion and highest total pressure levels in low speed conditions. In fast forward flight condition, however, forward-facing intake shapes are more beneficial. On this basis, the current research assesses the optimization potential of retrofit modifications such as a rear spoiler (small scoop) and an intake guide vane. Two optimal configurations of retrofit modifications are identified, combining benefits of the various basic intake and plenum chamber shapes. Full article
(This article belongs to the Special Issue Propulsion/Airframe Integration)
Show Figures

Figure 1
