Reinforced concrete slab-column structures, despite their advantages such as architectural flexibility and easy construction, are susceptible to punching shear failure. In addition, punching shear failure is a typical brittle failure, which introduces difficulties in assessing the functionality and failure probability of slab-column structures. Therefore, the prediction of punching shear resistance and corresponding reliability analysis are critical issues in the design of reinforced RC slab-column structures. In order to enhance the computational efficiency of the reliability analysis of reinforced concrete (RC) slab-column joints, a database containing 610 experimental data is used for machine learning (ML) modelling. According to the nonlinear mapping between the selected seven input variables and the punching shear resistance of slab-column joints, four ML models, such as artificial neural network (ANN), decision tree (DT), random forest (RF), and extreme gradient boosting (XGBoost) are established. With the assistance of three performance measures, such as root mean squared error (RMSE), mean absolute error (MAE), and coefficient of determination (R
2), XGBoost is selected as the best prediction model; its RMSE, MAE, and R
2 are 32.43, 19.51, and 0.99, respectively. Such advantages are also reflected in the comparison with the five empirical models introduced in this paper. The prediction process of XGBoost is visualized by SHapley Additive exPlanation (SHAP); the importance sorting and feature dependency plots of the input variables explain the prediction process globally. Furthermore, this paper adopts Monte Carlo simulation with a machine learning-based surrogate model (ML-MCS) to calibrate the reliability of slab-column joints in a real engineering example. A total of 1,000,000 samples were obtained through random sampling, and the reliability index
β of this practical building was calculated by Monte Carlo simulation. Results demonstrate that the target reliability index requirements under design provisions can be achieved. The sensitivity analysis of stochastic variables was then conducted, and the impact of that analysis on structural reliability was deeply examined.
