Applications of Geodesy in Meteorological, Hydrological and Climatic Environments

The Integrated Multi-satellitE Retrievals for the Global Precipitation Measurement (IMERG) provides new-generation satellite precipitation datasets with high spatio-temporal resolution and accuracy, which is widely applied in hydrology and meteorology. However, most examinations of the IMERG were conducted on daily, monthly, and annual scales, and inadequate research focused on the sub-daily scale. Thus, this study set up four sub-daily scales (1 h, 3 h, 12 h, and 24 h at 0.1° spatial resolution) and four spatial scales (0.1°, 0.25°, 0.5°, and 1° at 1 h temporal resolution) to finely evaluate the performance of IMERG products in the summer seasons from 2014 to 2019 over mainland China. The precipitation amount (PA), frequency (PF), and intensity (PI) were adopted to assess the performance of the IMERG referenced by the ground-based precipitation product of the China Meteorological Administration (CMA). The results show that the IMERG can capture the spatial patterns of precipitation characters over mainland China, but the PA and PI are overestimated and the PF is underestimated, and the evaluation results are highly sensitive to the different temporal and spatial resolutions. Compared with fine spatio-temporal scales, the performance of the IMERG is significantly improved when scaled up to coarser scales. Moreover, the IMERG shows a better performance of PA and PI in larger regions and during longer periods. This study provided a reference for the application of IMERG products in different spatial and temporal scales. Full article

Observations from the Gravity Recovery and Climate Experiment (GRACE) and GRACE Follow-On (GRACE-FO) missions can be used to estimate gravimetric excitation of polar motion (PM), which reflects the contribution of mass changes in continental hydrosphere and cryosphere to PM variation. Many solutions for Earth’s gravity field variations have been developed by institutes around the world based on GRACE/GRACE-FO data; however, it remains inconclusive which of them is the most reliable for the determination of PM excitation. In this study, we present a combined series of GRACE/GRACE-FO-based gravimetric excitation of PM computed using the three-cornered-hat (TCH) method, wherein the internal noise level in a combined solution is reduced to a minimum. We compare the combined series with results obtained from the combined GRACE/GRACE-FO solution provided by COST-G (International Combination Service for Time-variable Gravity Fields) and from the single solution elaborated by the Center for Space Research (CSR). All the gravimetric excitation series are evaluated by comparison with the sum of hydrological and cryospheric signals in geodetically observed PM excitation (called GAO). The results show that by minimizing the internal noise level in the combined excitation series using the TCH method, we can receive higher consistency with GAO than in the case of COST-G and CSR solutions, especially for the non-seasonal oscillations. For this spectral band, we obtained correlations between GAO and the best-combined series as high as 0.65 and 0.72 for the χ₁ and χ₂ equatorial components of PM excitation, respectively. The corresponding values for seasonal oscillation were 0.91 for χ₁ and 0.89 for χ₂. The combined series developed in this study explain up to 68% and 60% of overall GAO variability for χ₁ and χ₂, respectively. Full article

To understand the activity of gravity waves (GWs) over the Tibetan Plateau (TP) is of great significance for improving global climate models. Considering that the lower stratosphere is the main level of GWs activity, this paper first established a 14-year 2° × 2° longitude–latitude monthly mean GWs model in the lower stratosphere (18~20 km) of the TP by combining post-processed dry temperature profiles provided by the multi-Global Navigation Satellite System (GNSS) radio occultation (RO) missions: The Constellation Observing System for Meteorology, Ionosphere, and Climate (COSMIC) and the Meteorological Operational (METOP) series polar-orbiting meteorological satellites (METOP-A, METOP-B, and METOP-C) from August 2006 to September 2020. Based on this model, this paper analyzed the characteristics of GWs activity around TP and the effects of topography, background wind, and zonal wind on GWs activity and summarized the general process of topographic wave excitation and upward propagation around TP. The spatial distribution of the lower stratospheric GW Ep is highly correlated with the spatial distribution of background wind and the topography of TP during GWs excitation. The GW Ep is obviously filtered by the zero-speed wind. The change in GW Ep is strongly correlated with the change in topography. These phenomena indicate that the GWs of TP are mainly topographic waves. Moreover, the lower stratospheric GW Ep of TP shows that periodic changes are mainly affected by the periodic background wind, and the GW Ep value is larger in February and smaller in August. The large GW Ep in the lower stratosphere of TP is not only related to the GWs strongly generated by the interaction between the strong background wind and the large elevation or large topographic changes but also related to the strong zonal westerly winds that promote the propagation of GWs upward. Multivariable linear regression models were used to reconstruct the lower stratospheric GW Ep over TP based on the background wind and the zonal wind and a goodness of fit of 81.1% was achieved. It indicates that the GW Ep is dominated by the topographic wave over TP in the lower stratosphere and the background wind has a greater influence on the GWs than the zonal wind. Full article

Ocean tidal variation is a key parameter for ensuring coastal safety, monitoring marine climate, and maintaining elevation datum. Recently, the ground-based global navigation satellite system reflectometry (GNSS-R) technique has been applied for regional tidal measurements, which is somewhat restricted in terms of temporal and spatial resolutions. A convenient method to improve temporal resolution of measurements is to combine multi-GNSS observations. This paper proposes a new sea-surface altimetry method using the posterior errors (PE) of dual-frequency carrier-phase signals derived from the ionosphere-free Precise Point Positioning (IF-PPP). Considering that the number of initial retrievals is obviously unsuitable for minute-level tidal measurements, both the time sliding window based on the Lomb–Scargle periodogram and a weighted cubic spline smoothing function are significant processing steps for estimating the reflector heights between the sea surface and antenna center. Measurements from two coastal GNSS stations with different tidal amplitudes are used to test the proposed method and compare it with the tide gauge and the signal-to-noise ratio (SNR) methods, respectively. The experimental results show that the multi-GNSS PE combination method can be used to estimate a minute-level sea level time series, and its root-mean-squared errors (RMSE) are about 12.5 cm. In terms of correlation, for all results, the corresponding coefficients exceed 0.97. Moreover, this combined PE method demonstrates a significant advantage in increasing temporal resolution, which is beneficial for application on high-frequency sea-level monitoring. Full article

The validity of the results obtained within different permanent GNSS reference station networks (GNSS Network) must be periodically controlled using criteria that are generally known from statistical analyzes or prescribed by International Standards. Procedures for evaluating the uncertainty of measurements are defined in accordance with the purpose of the GNSS Network. The authors of this paper want to point out the need to establish requirements for periodical and systematical control of GNSS coordinates within the same permanent GNSS Network and control of GNSS coordinates between different permanent GNSS Networks measured on the same/unique point on the ground. This paper presents control procedures for three permanent GNSS reference station Networks established and operating in the Republic of Serbia. Special attention is on the analysis of data consistency within one permanent GNSS Network and the mutual consistency of GNSS data between different networks. The paper aims to promote reliance on the different GNSS Networks and contains suggestions on how GNSS Networks may prove that they are performing competently and that they can provide valid results for field measurements. Particularly highlighted is the need to plan and implement measures related to increasing the effectiveness of the GNSS system, achieving improved results, and preventing negative effects while performing field measurements. The paper presents the results for comparison, selected according to the rules for creating a Digital Cadastral Map features, i.e., points, lines, and polygon. The results for comparing point features are the GNSS coordinates. The results for comparing line features are the lengths of the line, i.e., distances, and the results for comparing polygon features are the areas of the polygons. Full article

Satellite altimetry technology has unparalleled advantages in the monitoring of hydrological resources. After decades of development, satellite altimetry technology has achieved a perfect integration from the geometric research of geodesy to the natural resource monitoring research. Satellite altimetry technology has shown great potential, whether solid or liquid. In general, this paper systematically reviews the development of satellite altimetry technology, especially in terms of data availability and program practicability, and proposes a multi-source altimetry data fusion method based on deep learning. Secondly, in view of the development prospects of satellite altimetry technology, the challenges and opportunities in the monitoring application and expansion of surface water changes are sorted out. Among them, the limitations of the data and the redundancy of the program are emphasized. Finally, the fusion scheme of altimetry technology and deep learning proposed in this paper is presented. It is hoped that it can provide effective technical support for the monitoring and application research of hydrological resources. Full article

Egypt’s climate is generally dry all over the country except for the Northern Mediterranean Coast. The Egyptian Meteorological Authority (EMA) uses few meteorological stations to monitor weather events in the entire country within the area of one million square kilometers, which makes it scarce with respect to spatial distribution. The EMA data are relatively expensive to obtain. Open access rainfall products (RP) are commonly used to monitor rainfall as good alternatives, especially for data-scarce countries such as Egypt. This paper aims to evaluate the performance of 12 open access rainfall products for 8 locations in the northern part of Egypt, in order to map the rainfall spatial distribution over the northern part of Egypt based on the best RP. The evaluation process is conducted for the period 2000–2018 for seven locations (Marsa-Matrouh, Abu-Qeir, Rasheed, Port-Said, Tanta, Mansoura, and Cairo-Airport), while it is conducted for the period 1996–2008 for the Damanhour location. The selected open access rainfall products are compared with the ground stations data using annual and monthly timescales. The point-to-pixel approach is applied using four statistical indices (Pearson correlation coefficient (r), Nash–Sutcliffe efficiency (NSE), root mean square error (RMSE) and bias ratio (Pbias)). Overall, the results indicate that both the African Rainfall Estimation Algorithm (RFE) product and the Climate Prediction Center (CPC) product could be the best rainfall data sources for the Marsa-Matrouh location, with relatively higher r (0.99–0.93 for RFE and 0.99–0.89 for CPC) and NSE (0.98–0.79 for RFE and 0.98–0.75 for CPC), in addition to lower RMSE (0.94–7.78 for RFE and 0.92–12.01 for CPC) and Pbias (0.01–11.95% for RFE and −2.22–−12.15% for CPC) for annual and monthly timescales. In addition, the Global Precipitation Climatology Centre (GPCC) and CPC give the best rainfall products for the Abu-Qier and Port-Said locations. GPCC is more suitable for the Rasheed location. The most appropriate rainfall product for the Tanta location is CHIRPS. The current research confirms the benefits of using rainfall products after conducting the recommended performance assessment for each location. Full article

Global navigation satellite system (GNSS) refractometry enables automated and continuous in situ snow water equivalent (SWE) observations. Such accurate and reliable in situ data are needed for calibration and validation of remote sensing data and could enhance snow hydrological monitoring and modeling. In contrast to previous studies which relied on post-processing with the highly sophisticated Bernese GNSS processing software, the feasibility of in situ SWE determination in post-processing and (near) real time using the open-source GNSS processing software RTKLIB and GNSS refractometry based on the biased coordinate Up component is investigated here. Available GNSS observations from a fixed, high-end GNSS refractometry snow monitoring setup in the Swiss Alps are reprocessed for the season 2016/17 to investigate the applicability of RTKLIB in post-processing. A fixed, low-cost setup provides continuous SWE estimates in near real time at a low cost for the complete 2021/22 season. Additionally, a mobile, (near) real-time and low-cost setup was designed and evaluated in March 2020. The fixed and mobile multi-frequency GNSS setups demonstrate the feasibility of (near) real-time SWE estimation using GNSS refractometry. Compared to state-of-the-art manual SWE observations, a mean relative bias below 5% is achieved for (near) real-time and post-processed SWE estimation using RTKLIB. Full article

Tropospheric delay is one of the key factors that may affect high-precision satellite navigation and positioning and water vapor retrieval performance. Its variation in the vertical direction is much greater than that in the horizontal direction. Therefore, the vertical profile model of zenith total delay (ZTD) is important for the spatial interpolation of high-precision ZTD products and the development of ZTD models. However, in China, low spatial and temporal resolutions remain persistent in ZTD vertical profile models and limit their application. In this study, ZTD vertical profile grid models (CZTD-H model: CZTD-HM and CZTD-HE models) were developed by considering the time-varying height scale factor for China and employing ZTD layered profile information with high temporal-spatial resolution calculated using MERRA-2 data and ERA5 data based on the integration method during 2012–2016. The CZTD-H model accuracy was verified using the global navigation satellite system (GNSS) data acquired from the Crustal Movement Observation Network of China (CMONOC) and radiosonde data as reference and was compared with the canonical GPT3 model accuracy. The applicability of CZTD-HM and CZTD-HE models was discussed. The results showed that: (1) CZTD-HM and CZTD-HE models exhibited excellent performance for ZTD layered vertical interpolation in northwestern and southeastern China, respectively. Among ZTD layered profiles from 84 radiosonde stations, the RMSE of ZTD data interpolated using CZTD-HM and CZTD-HE models improved by 12.9/16.23% and 13.8/17.16% compared with GPT3-1 and GPT3-5 models, respectively. (2) The CZTD-H model maintained high performance for the spatial interpolation of GGOS grid ZTD data. Validation with ZTD data from 249 GNSS stations showed that the RMSEs of both CZTD-HM and CZTD-HE models improved by 2.8 mm (19.7%) and 2.6 mm (18.6%) compared with those of the GPT3-1 and GPT3-5 models, respectively. The CZTD-HE model showed excellent performance in summer among all the models. Only the location and day of the year were required for the application of the CZTD-H model, which showed excellent ZTD vertical correction performance in China. With the different performances of the CZTD-HE and CZTD-HM models in China, the ERA5 model can be recommended for practical applications. Therefore, these results can provide a reference for the data source selection of ZTD vertical profile model construction on the basis of high-precision reanalysis data, GNSS real-time high-precision positioning, and GNSS meteorology in China. Full article
