Search Results (1,766)

Search Parameters:
Keywords = voltage follower

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 7663 KB
Article
Simulation Study on Contact Stress at Copper Busbar Surface Microstructures and Polymer Interfaces
by Mengfu Zhao, Yiming Wen, Changle Xiao, Fei Hai and Hongyan Wu
Coatings 2026, 16(6), 638; https://doi.org/10.3390/coatings16060638 - 25 May 2026
Abstract
Copper busbar inserts are critical components of high-voltage connectors in new energy vehicles. The interfacial contact stress between the insert and the polymer directly affects the sealing reliability and service life of the connector. To address the interfacial stress concentration caused by the [...] Read more.
Copper busbar inserts are critical components of high-voltage connectors in new energy vehicles. The interfacial contact stress between the insert and the polymer directly affects the sealing reliability and service life of the connector. To address the interfacial stress concentration caused by the mismatch in thermal expansion coefficients between metal and polymer, this study employs COMSOL Multiphysics 6.2 simulations to investigate the regulation laws of arc-shaped and trapezoidal microstructures on the interfacial stress of copper–polyphenylene sulfide (PPS)/polypropylene (PP). The response surface methodology (RSM) is introduced to verify simulation reliability and optimize parameters. The simulation results indicate that both structures can effectively reduce interfacial stress, and the stress exhibits a significant nonlinear relationship with the structural parameters. Due to its high temperature resistance and polar thioether bond, PPS demonstrates better interfacial compatibility than PP. Under the same structural position, the maximum stress reduction exceeds 20% (from 0.689 MPa to 0.539 MPa). Moreover, the arc-shaped structure is more effective in alleviating stress concentration than the trapezoidal structure. At the same position, compared to the trapezoidal surface, the arc-shaped surface reduces the valley contact stress of PPS from 0.527 MPa to 0.5 MPa (a decrease of 5.12%) and that of PP from 0.679 MPa to 0.605 MPa (a decrease of 10.9%). The optimal parameters are as follows: an arc-shaped radius width of 1.0 mm, a depth of 0.8 mm; a trapezoidal bottom base of 2.0 mm, a height of 1.2 mm. This study provides a basis for the interface design of metal–polymer composite components and holds significant engineering value for the reliability optimization of high-voltage connectors. Full article
Show Figures

Figure 1

21 pages, 2549 KB
Review
Review of the Gate Structure for Normally Off p-GaN High-Electron-Mobility Transistors Towards High Performances
by Taofei Pu, Xiaobo Li, Liuan Li and Jin-Ping Ao
Materials 2026, 19(11), 2205; https://doi.org/10.3390/ma19112205 - 23 May 2026
Abstract
As a representative wide-bandgap semiconductor material, gallium nitride (GaN) has attracted increasing attention because of its superior material properties (e.g., high electron mobility, high electron saturation velocity, and critical electric field). For power electronics applications, and to take full advantage of the superiorities [...] Read more.
As a representative wide-bandgap semiconductor material, gallium nitride (GaN) has attracted increasing attention because of its superior material properties (e.g., high electron mobility, high electron saturation velocity, and critical electric field). For power electronics applications, and to take full advantage of the superiorities of the GaN material, the normally off operation is required based on an AlGaN/GaN heterostructure. For a commercial approach, GaN HEMTs with a p-GaN gate have become a research hotspot. The characteristics of p-GaN gate HEMTs have a significant relationship with gate structure, especially the contact type on the p-GaN layer. In this review, the necessity of normally off operation and the advantages of adopting a p-GaN gate are elaborated, followed by the theory of achieving normally off operation by p-GaN and critical fabrication processes. The various gate structures are discussed, including metal gate, junction gate and hybrid gate structures on the p-GaN layer, to improve threshold voltage. Meanwhile, the methods required to optimize breakdown voltage and monolithically integrated technologies are also demonstrated. This review outlines the development and future trends of p-GaN gate HEMTs for power systems. Full article
(This article belongs to the Special Issue Advanced Composite Materials for Next-Generation Electronic Devices)
Show Figures

Figure 1

18 pages, 10921 KB
Article
Column-Parallel Adaptive-Gain Single-Slope ADC Using a Single Global Ramp and Column-Local Capacitive Attenuation for High-Speed HDR Imaging
by Hyunyoung Yoo, Chanhyuk Park, Minhyun Jin and Myonglae Chu
Electronics 2026, 15(11), 2266; https://doi.org/10.3390/electronics15112266 - 23 May 2026
Abstract
This paper presents a column-parallel adaptive-gain single-slope (SS) analog-to-digital converter (ADC) for high-speed high-dynamic-range (HDR) CMOS image sensors. Conventional adaptive-gain approaches often rely on dual-ramp generation or duplicated column circuits, which increase area and power overhead. In contrast, the proposed architecture achieves adaptive-gain [...] Read more.
This paper presents a column-parallel adaptive-gain single-slope (SS) analog-to-digital converter (ADC) for high-speed high-dynamic-range (HDR) CMOS image sensors. Conventional adaptive-gain approaches often rely on dual-ramp generation or duplicated column circuits, which increase area and power overhead. In contrast, the proposed architecture achieves adaptive-gain operation using a single global ramp shared across all columns. A reconfigurable capacitive attenuation network embedded inside each column comparator locally scales the ramp at the comparator input, enabling seamless transition between high-gain operation for low-level signals and unity-gain operation for large signals within a single exposure and readout cycle. To suppress mode-dependent offsets while maintaining low noise, a configurable dual-source-follower ramp buffer symmetrically buffers the ramp and reference voltages during auto-zeroing and is reconfigured as a full-sized buffer during unity-gain conversion. Switching-induced column offsets are compensated using optical black pixels and lightweight digital processing. The ADC is implemented in a 110 nm CMOS image sensor process and validated through post-layout simulations including extracted parasitics and Monte Carlo mismatch analysis. The core ADC consumes 36.8 µW per column. Simulation results demonstrate linearity error below 1% without missing codes and show that the proposed AGx8-to-AGx1 configuration extends the effective dynamic range up to 78.3 dB. Full article
Show Figures

Figure 1

17 pages, 1187 KB
Article
Wire Electrode Wear in WEDM of Inconel 718: Gravimetric Evaluation Using a 33 Full Factorial Design
by Vladimír Šimna, Marcel Kuruc, Barbora Ludrovcová, Adam Belanec, Vitalii Kolesnyk and Oleksandr Berezniak
Appl. Sci. 2026, 16(11), 5235; https://doi.org/10.3390/app16115235 - 23 May 2026
Abstract
Wire electrical discharge machining (WEDM) is widely used for the precision cutting of difficult-to-machine materials, including nickel-based superalloys. Wire electrode wear, however, remains a practical limitation, because it affects process stability, wire consumption, and machining cost. This work examines the wear behaviour of [...] Read more.
Wire electrical discharge machining (WEDM) is widely used for the precision cutting of difficult-to-machine materials, including nickel-based superalloys. Wire electrode wear, however, remains a practical limitation, because it affects process stability, wire consumption, and machining cost. This work examines the wear behaviour of a gamma-phase Cu5Zn8-coated copper-core wire electrode (Elecut X, ø 0.25 mm) during the WEDM of Inconel 718 using direct gravimetric measurement. A 33 full factorial experiment was carried out with three electrical parameters: pulse-on time (A), pulse-off time (B), and servo reference voltage (Aj). The discharge process was monitored with an oscilloscope so that measurements only started after the programmed pulse-off time had been reached. Electrode wear was evaluated as the mass loss Δm of 4 m wire segments after 5 min cutting intervals on a Charmilles Robofil 310 machine, and factor significance was assessed by analysis of variance (ANOVA). Pulse-on time was the dominant factor, accounting for 88.45% of the total variation in Δm, followed by servo reference voltage and pulse-off time. SEM/EDS examination showed material transfer from the Inconel 718 workpiece to the worn electrode surface, with local nickel content reaching 16.84 wt.% on the frontal face of the most worn sample. The results provide a quantitative basis for reducing wire consumption during the WEDM of Inconel 718 while recognising the trade-off with cutting productivity. Full article
15 pages, 1073 KB
Article
Effect of Secondary Crosslinking Time on the Interfacial Insulation Performance of Crosslinked Polyethylene/Semiconductive Shielding Layer
by Ming Hu, Hongliang Zhang, Xufei Ge, Yan Yan, Yuanhang Yang, Xiaoyan Cao, Zerui Li and Wenbo Huo
Polymers 2026, 18(11), 1277; https://doi.org/10.3390/polym18111277 - 22 May 2026
Viewed by 85
Abstract
To investigate the influence of secondary crosslinking time on the interfacial insulation performance between crosslinked polyethylene (XLPE) and a semiconductive shielding layer, XLPE sheets and semiconductive EVA pellets were selected. XLPE/semiconductive shielding layer interfacial specimens with secondary crosslinking times of 10 min, 15 [...] Read more.
To investigate the influence of secondary crosslinking time on the interfacial insulation performance between crosslinked polyethylene (XLPE) and a semiconductive shielding layer, XLPE sheets and semiconductive EVA pellets were selected. XLPE/semiconductive shielding layer interfacial specimens with secondary crosslinking times of 10 min, 15 min, 30 min, 45 min and 60 min were prepared. Polarization and depolarization current (PDC) measurements, breakdown voltage tests, peel adhesion strength evaluation and scanning electron microscopy (SEM) observations were systematically performed. The interfacial polarization current, characteristic breakdown voltage and interfacial peel adhesion strength of the specimens were obtained and analyzed. The experimental results indicate that, with increasing secondary crosslinking time, the interfacial polarization current showed an initial decrease followed by an increase, and the characteristic breakdown voltage and the interfacial peel adhesion strength showed an initial increase followed by a decrease. Further analysis suggests that an excessively long secondary crosslinking time reduces the area of the interfacial interpenetration region between XLPE and the semiconductive shielding layer, which is the primary factor responsible for the deterioration of interfacial insulation performance. The results provide experimental evidence and theoretical support for optimizing flexible joint manufacturing processes and improving their operational reliability and service lifetime. Full article
(This article belongs to the Section Polymer Analysis and Characterization)
20 pages, 2293 KB
Article
Resonance Mechanism Analysis and Suppression of Grid-Connected Energy Storage Power Station Inverter
by Weiheng Kuang, Jinchuan Guo, Lianhui Ning, Junyuan Zhang, Xinmei Gu, Sisi Chen, Shihong Shi, Weihan Hao, Min Zhou, Tiantian He and Qingxin Wang
Electronics 2026, 15(10), 2221; https://doi.org/10.3390/electronics15102221 - 21 May 2026
Viewed by 147
Abstract
The increasingly prominent “double-high” characteristics (high penetration of renewable energy and high proportion of power electronic devices) in modern power systems pose severe challenges to secure and stable operation, especially due to wideband oscillations induced by grid-connected inverters. In view of the fact [...] Read more.
The increasingly prominent “double-high” characteristics (high penetration of renewable energy and high proportion of power electronic devices) in modern power systems pose severe challenges to secure and stable operation, especially due to wideband oscillations induced by grid-connected inverters. In view of the fact that existing impedance modeling for grid-forming control often neglects the decoupling effect of the LC filter capacitor and the dynamics of inner voltage/current loops, leading to inaccurate characterization of mid-to-high frequency impedance, this paper aims to establish more accurate impedance models for grid-connected inverters and to develop effective oscillation mitigation methods accordingly. First, the harmonic linearization method is adopted to derive refined positive- and negative-sequence impedance analytical models for NPC inverters under both grid-following and grid-forming control. Second, simulation-based frequency scanning is conducted to validate the accuracy of the proposed models, and the differences in system resonance characteristics under the two control modes are comparatively analyzed. Finally, oscillation suppression strategies based on active damping and virtual impedance are, respectively, designed. The results show that the proposed models can accurately characterize mid-to-high frequency impedance, reveal the distinct resonance mechanisms of different control modes, and the proposed suppression strategies can effectively attenuate wideband oscillations. These findings provide theoretical foundations and practical technical pathways for stability analysis and optimization design of inverter-grid systems in high-renewable-penetration scenarios. Full article
(This article belongs to the Special Issue Advanced Technologies for Future Electric Power Transmission Systems)
Show Figures

Figure 1

60 pages, 2695 KB
Review
Renewable Energy Integration in Emerging Electricity Grids: Technologies, Challenges, and System-Level Perspectives
by Paolo Di Leo, Gabriele Malgaroli, Filippo Spertino and Alessandro Ciocia
Appl. Sci. 2026, 16(10), 5124; https://doi.org/10.3390/app16105124 - 21 May 2026
Viewed by 98
Abstract
The rapid growth of renewable energy is driving a profound transformation of electricity grids toward architectures characterized by high shares of inverter-based generation, increased decentralization, and extensive digitalization. While wind and solar technologies have matured at the component level, their large-scale integration introduces [...] Read more.
The rapid growth of renewable energy is driving a profound transformation of electricity grids toward architectures characterized by high shares of inverter-based generation, increased decentralization, and extensive digitalization. While wind and solar technologies have matured at the component level, their large-scale integration introduces technical, operational, and institutional challenges that extend beyond conventional power-system design paradigms. This review provides an integrated synthesis of the technologies, control strategies, and management processes that enable renewable energy integration into emerging electricity grids. Key challenges are analyzed across multiple timescales: fast frequency and voltage dynamics in low-inertia systems (milliseconds to seconds), forecasting, optimization, and automated control (real-time to near-real-time), and long-term planning of transmission, storage, and flexibility resources (years to decades). The synthesis covers grid-forming and grid-following inverter control, with quantitative comparison across short-circuit-ratio regimes; HVDC and HVAC transmission technologies; energy storage systems, including emerging electrochemical and mechanical solutions; smart-grid digitalization through EMS, SCADA, and digital twins; artificial intelligence and machine-learning deployments at major transmission system operators; sector coupling involving hydrogen and carbon capture; and cybersecurity considerations. Real-world case studies are used to illustrate practical lessons, with explicit attention to the brownfield–greenfield distinction between modernization of legacy systems and the design of new networks in developing regions. The review concludes by identifying key research and development priorities for achieving reliable, resilient, and economically efficient high-renewable energy systems. Full article
Show Figures

Figure 1

25 pages, 45989 KB
Article
Transient Stability Assessment of a 9-Bus Power System with High Solar PV Penetration: An IEEE Benchmark Case Study
by Marvens Jean Pierre, Emmanuel Hernández-Mayoral, Oscar Alfredo Jaramillo Salgado, Manuel Madrigal-Martínez, Reynaldo Iracheta-Cortez, Jorge Sanchez-Jaime and Gregorio Martínez-Reyes
Electricity 2026, 7(2), 46; https://doi.org/10.3390/electricity7020046 - 20 May 2026
Viewed by 194
Abstract
This study examines the impact of increasing photovoltaic (PV) penetration on the transient stability of the IEEE 9-bus power system. Synchronous machines are modeled with standard subtransient dynamics, while PV units are represented as current-limited grid-following inverters. Transient stability is assessed through the [...] Read more.
This study examines the impact of increasing photovoltaic (PV) penetration on the transient stability of the IEEE 9-bus power system. Synchronous machines are modeled with standard subtransient dynamics, while PV units are represented as current-limited grid-following inverters. Transient stability is assessed through the Critical Clearing Time (CCT) and the post-fault dynamic behavior, obtained from time-domain simulations carried out in MATLAB/Simulink® R2023b. Two permanent three-phase faults are considered: a primary contingency on line 7–5 and a secondary contingency on line 9–6, introduced to assess the robustness of the observed trends across different fault locations. The results show an increase in CCT as PV generation progressively replaces the active power supplied by synchronous machines, whose inertia is therefore maintained: from 210 ms (0% PV) to 440 ms (25%)/1080 ms (40%) at bus 5, 410 ms (25%)/1130 ms (40%) and 290 ms (25%)/650 ms (40%) at buses 6 and 8, respectively, demonstrating that the penetration site is a key factor for system stability. For distributed penetration among the three buses, CCT values of 340 ms (25%) and 1020 ms (40%) highlight the significant influence of PV placement at bus 8. The fault on line 9–6 consistently yields higher CCT values across all scenarios, confirming the robustness of these trends independently of fault location. Although an overall increase in CCT was observed, higher PV penetration also led to more pronounced oscillations and operability issues after the fault. In particular, 75% of the penetration scenarios under the fault on line 9–6 do not meet the active power recovery requirements of IEEE 1547-2018 and IEEE 2800-2022, a result more severe than that observed for the fault on line 7–5. These results underscore that a higher CCT does not guarantee operational compliance, and that stability-oriented control strategies—such as grid-forming operation, fast active power support, and dynamic voltage control—remain essential. They also suggest that planning practices should favor interconnections electrically closer to the slack generator. Overall, a high PV penetration level—modifying only the operating point of synchronous machines—allows longer fault durations to be tolerated; however, appropriate siting of PV units and the adoption of advanced inverter controls could mitigate the observed oscillations and post-fault operability challenges. Full article
(This article belongs to the Topic Power System Dynamics and Stability, 2nd Edition)
Show Figures

Figure 1

19 pages, 3709 KB
Article
An Energy-Efficient LiDAR Receiver Using Time-to-Voltage Converter and SAR ADC in 180 nm CMOS
by Bobin Seo and Sung-Min Park
Micromachines 2026, 17(5), 622; https://doi.org/10.3390/mi17050622 - 19 May 2026
Viewed by 101
Abstract
This paper proposes an energy-efficient LiDAR receiver topology based on a time-to-voltage converter (TVC) followed by a 5-bit SAR ADC. By converting the time-interval between START and STOP signals into the voltage domain, the proposed topology avoids the complexity of conventional TDC-based designs [...] Read more.
This paper proposes an energy-efficient LiDAR receiver topology based on a time-to-voltage converter (TVC) followed by a 5-bit SAR ADC. By converting the time-interval between START and STOP signals into the voltage domain, the proposed topology avoids the complexity of conventional TDC-based designs and enables the use of a moderate-speed, energy-efficient SAR ADC. The proposed TVC in the proposed LiDAR receiver consists of an on-chip avalanche photodiode (APD), a CMOS transimpedance-limiting amplifier (CTLA), a time-gating circuit, a ramp generator, and a peak-and-hold (PDH) block. Thereafter, the converted voltages are digitized by a VCM-based single-ended SAR ADC with a binary-weighted CDAC, a strong-arm latch comparator, and custom digital logic. A reset generator is also incorporated to coordinate the sampling, comparison, and settling phases. The proposed LiDAR receiver is implemented in a 180 nm CMOS process, where the TVC occupies an area of 171 μm × 98.8 μm, while the TVC-SAR receiver occupies 417 μm × 356 μm, respectively. The proposed LiDAR receiver consumes 13 mW from a single 1.8 V supply, in which the SAR ADC consumes 3.68 mW only. The TVC-SAR receiver resolves the time-intervals ranging from 7 ns to 32.1 ns with a resolution of 0.81 ns. Hence, the proposed topology provides an energy-efficient solution along with its reduced circuit complexity and chip implementation for short-range LiDAR applications. Full article
(This article belongs to the Special Issue Photonic and Optoelectronic Devices and Systems, 4th Edition)
Show Figures

Figure 1

14 pages, 9048 KB
Article
Evolution and Failure Mechanism of Moisture Absorption, Mechanical, and Electrical Insulation Properties of Glass Fiber/Epoxy Resin (GF/EP) Composites Under Hygrothermal Aging
by Bowen Xu, Chenglu Wang, Jinghan Wang and Chen Cao
Energies 2026, 19(10), 2436; https://doi.org/10.3390/en19102436 - 19 May 2026
Viewed by 172
Abstract
Glass fiber/epoxy (GF/EP) composites are widely used in high-voltage electrical equipment due to their excellent specific strength, durability and dielectric properties. However, long-term exposure to hygrothermal environments will lead to performance degradation of the material, which seriously threatens its service reliability. To solve [...] Read more.
Glass fiber/epoxy (GF/EP) composites are widely used in high-voltage electrical equipment due to their excellent specific strength, durability and dielectric properties. However, long-term exposure to hygrothermal environments will lead to performance degradation of the material, which seriously threatens its service reliability. To solve this problem, accelerated aging tests were systematically carried out in this study by immersing GF/EP specimens in deionized water at room temperature and 80 °C. The performance evolution laws and failure mechanisms of the material were investigated through moisture absorption kinetic analysis, tensile property testing, scanning electron microscope (SEM) fracture observation and breakdown voltage testing. The results show that the initial moisture absorption behavior of the material follows the Fickian diffusion mechanism, and the water diffusion rate at 80 °C is 31.8 times that at room temperature. After 35 days of aging, the retention rate of the maximum tensile force is 86.6% for the room temperature group, while it decreases to 38.2% for the 80 °C group. SEM observations show that the failure mode of the material changes from ductile fracture to brittle fracture after aging at 80 °C, accompanied by serious interfacial debonding. Temperature is the dominant factor for insulation performance degradation: the breakdown voltage retention rate is above 91% at room temperature, while it decreases to about 37% at 80 °C, and the influence of 60% maximum tensile force (Fmax) preloading is relatively small. This study provides experimental data and theoretical support for the performance evaluation and life prediction of GF/EP composites in harsh hygrothermal service environments of high-voltage electrical equipment. Full article
(This article belongs to the Special Issue Advanced Control and Monitoring of High Voltage Power Systems)
Show Figures

Figure 1

14 pages, 3986 KB
Article
Enhanced Properties of Electrodes Based on Ti/TiO2-Au/rGO Composite Structures for Electrochemical Application
by Cornelia Bandas, Mina-Ionela Morariu, Corina Orha, Carmen Lazau and Mircea Nicolaescu
Crystals 2026, 16(5), 338; https://doi.org/10.3390/cryst16050338 - 16 May 2026
Viewed by 154
Abstract
The increasing environmental pollution with emergent pollutants has led to the necessity to develop various structures for sensory applications used in water monitoring processes. In this context, this study presents a composite structure based on titanium foil/titanium dioxide/reduced graphene oxide functionalized with gold [...] Read more.
The increasing environmental pollution with emergent pollutants has led to the necessity to develop various structures for sensory applications used in water monitoring processes. In this context, this study presents a composite structure based on titanium foil/titanium dioxide/reduced graphene oxide functionalized with gold ions (Ti/TiO2-Au/rGO) obtained by a simple and efficient spin-coating method, successfully applied in electrochemical doxorubicin detection processes. The synthesis protocol first involves etching the titanium foil to form a Ti/TiO2 substrate, followed by the synthesis of the TiO2-Au/rGO solution, which was deposited by a spin-coating technique on the surface of the Ti/TiO2 support, to form electrodes based on a Ti/TiO2-Au/rGO composite structure. The structure and morphology of the as-synthesized composites were investigated in detail using X-ray analysis, Raman spectroscopy, and scanning electron microscopy coupled with an EDX. Furthermore, to determine the electroactive surface area and apparent diffusion coefficient of the composite structures, the electrochemical behavior was evaluated by CV in a 1 M KNO3 and in the presence of 4 mM K3Fe(CN)6. By using electrochemical impedance spectroscopy (EIS) in 0.1 M NaOH supporting electrolyte and within a frequency range of 0.1–10,000 Hz and a voltage of 10 mV, the charge transfer resistance was also investigated. The potential application in electroanalysis of the electrodes was tested by CV for the detection of the DOX pollutant in 0.1 M NaOH and 1–5 mg L−1 DOX. The obtained results provide new insights into the development of electrochemical sensors for applications in water treatment processes. Full article
(This article belongs to the Special Issue Synthesis and Applications of Crystalline Nanoporous Materials)
Show Figures

Figure 1

19 pages, 11307 KB
Article
An Advanced Control Strategy for a Grid-Connected Reduced Number of Switches T-Type Inverter-Based Photovoltaic System
by Aouse Abdulwahid Khalaf Khalaf and Cenk Yavuz
Electronics 2026, 15(10), 2142; https://doi.org/10.3390/electronics15102142 - 16 May 2026
Viewed by 238
Abstract
Grid-connected photovoltaic (PV) systems can serve not only as sources of active power but also as active power conditioners for improving power quality. This paper proposes an integrated control strategy for a single-phase grid-connected reduced-switch-count T-type inverter that simultaneously performs maximum power point [...] Read more.
Grid-connected photovoltaic (PV) systems can serve not only as sources of active power but also as active power conditioners for improving power quality. This paper proposes an integrated control strategy for a single-phase grid-connected reduced-switch-count T-type inverter that simultaneously performs maximum power point tracking (MPPT) without a DC-DC conversion stage, compensates for nonlinear load harmonics, and minimises switching losses through a tailored multi-carrier pulse-width modulation (PWM) algorithm. A novel reference current derivation method based on a single-phase dq transformation framework unifies MPPT and active power filtering within a single control loop. The proposed system was validated through MATLAB/Simulink 2025b simulations for a 3500 W PV array supplying a nonlinear RL load with a full-bridge diode rectifier exhibiting a load current total harmonic distortion (THD) of approximately 46%. Simulation results demonstrate an MPPT efficiency of 99.8% at full irradiance (1000 W/m2), an overall system efficiency above 97%, and a grid current THD below 4% across the full irradiance operating range (0–1000 W/m2). Dynamic performance under step irradiance changes was also evaluated: the DC bus voltage deviation remains within 5 V for P&O step sizes between 0.00005 V and 0.0002 V, and the grid current THD recovers to below 5% within 2–6 grid cycles following each irradiance transition. Full article
(This article belongs to the Section Power Electronics)
Show Figures

Figure 1

12 pages, 2977 KB
Article
Hybrid Surgical–Catheter Epicardial Ablation of Ventricular Tachycardia: A Case Series
by Alessandro Telesca, Roberto Scacciavillani, Gemma Pelargonio, Cristina Conte, Federico Ballacci, Federica Giordano, Francesco Perna, Gianluigi Bencardino, Francesco Spera, Gaetano Pinnacchio, Andrea Scapigliati, Massimo Massetti, Francesco Burzotta, Massimo Imazio and Maria Lucia Narducci
J. Clin. Med. 2026, 15(10), 3782; https://doi.org/10.3390/jcm15103782 - 14 May 2026
Viewed by 213
Abstract
Background: Epicardial mapping and ablation of ventricular tachycardia (VT) are used in different clinical situations but pericardial adhesions following prior cardiac surgery or previous epicardial procedures may limit a percutaneous approach. The objective of this case series is to evaluate the safety and [...] Read more.
Background: Epicardial mapping and ablation of ventricular tachycardia (VT) are used in different clinical situations but pericardial adhesions following prior cardiac surgery or previous epicardial procedures may limit a percutaneous approach. The objective of this case series is to evaluate the safety and feasibility of a hybrid approach with surgical epicardial access as a valid alternative when pericardial space is not accessible percutaneously. Methods: After a complete preprocedural evaluation, four patients with prior cardiac surgery underwent hybrid VT ablation under general anesthesia. Surgical subxiphoid access was performed in three cases and one patient was subjected to median resternotomy for concomitant open-heart surgery. Epicardial electroanatomic voltage maps were acquired using the CARTO 3 system (Biosense Webster) or NavX (St. Jude Medical) and VT ablations with irrigated catheters were performed. The procedural endpoint was VT non-inducibility and/or LAVA/LP abolition. Results: No serious periprocedural complications occurred after hybrid VT ablation. Three patients had no complex ventricular arrhythmias after a median follow-up of 43 months. A symptomatic sustained VT relapsed in one patient, without requiring a redo ablation procedure but responded to escalation of antiarrhythmic therapy. Conclusions: A carefully planned hybrid VT ablation with surgical epicardial access is a safe and feasible procedure in patients with epicardial scar-related re-entry circuits and pericardial adhesions that limit a percutaneous approach. Full article
Show Figures

Figure 1

24 pages, 19844 KB
Article
Instrumentation Techniques for Nuclear Pulse Shaping and Calibration in Geiger–Müller-Based Gamma Detectors
by Wilson Pavon, Diego Guffanti, Jorge Bastidas-Pazmiño, Erika Pavón and William Chamorro
Electronics 2026, 15(10), 2093; https://doi.org/10.3390/electronics15102093 - 14 May 2026
Viewed by 161
Abstract
This work presents the design and validation of a low-cost electronic architecture for nuclear pulse conditioning and radiation exposure measurement using a Geiger–Müller tube. The main contribution is a structured three-stage conditioning system capable of transforming high-voltage analog nuclear pulses into standardized TTL-compatible [...] Read more.
This work presents the design and validation of a low-cost electronic architecture for nuclear pulse conditioning and radiation exposure measurement using a Geiger–Müller tube. The main contribution is a structured three-stage conditioning system capable of transforming high-voltage analog nuclear pulses into standardized TTL-compatible digital signals for real-time acquisition and pulse counting. The proposed architecture integrates a regulated 500 V high-voltage supply, voltage coupling and limitation, CMOS-based inversion, and monostable pulse shaping using a 555 timer to generate stable 5 V output pulses with approximately 1600 μs duration. Experimental evaluation included oscilloscope-based pulse characterization, plateau-region verification, and calibration tests performed with a certified gamma radiation source under controlled laboratory conditions. The measured exposure response followed the expected inverse-distance radiation behavior, with relative deviations within ±13% compared with certified reference values. The results demonstrate the feasibility of implementing reliable radiation instrumentation using commercially available electronic components, providing an accessible solution for environmental, laboratory, and educational monitoring applications. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

18 pages, 6393 KB
Article
The Failure of Voltage Divider Induced by Insulating Material Degradation Under Coupling Effect of High-Frequency Field and Temperature
by Xuan Li, Chuang Zhang, Zixi Liu, Jiajie Song, Huidong Tian, Qijia Xie, Zhengmao Zhang and Shengtao Li
Materials 2026, 19(10), 2047; https://doi.org/10.3390/ma19102047 - 14 May 2026
Viewed by 209
Abstract
This paper systematically investigates the failure characteristics and mechanisms of insulating materials in DC voltage dividers under combined high-frequency voltage and high-temperature conditions via simulations and experiments. The results showed that high-frequency harmonics severely degrade the insulation strength of polypropylene/paper/polypropylene (PPLP) at 10 [...] Read more.
This paper systematically investigates the failure characteristics and mechanisms of insulating materials in DC voltage dividers under combined high-frequency voltage and high-temperature conditions via simulations and experiments. The results showed that high-frequency harmonics severely degrade the insulation strength of polypropylene/paper/polypropylene (PPLP) at 10 kHz, in which the bulk breakdown strength of PPLP decreases by over 50%. Furthermore, the surface flashover voltage in oil is reduced by 17.7% under high-frequency voltage alone, and by as much as 51% when white flocculent substances are present in the oil. The dielectric properties of PPLP strongly depend on frequency and temperature, which aggravate the heat accumulation of the divider under high-frequency voltage. Furthermore, the multilayer structure of PPLP introduces deeper trap levels due to interfacial states, which reduce the breakdown strength and flashover voltage of PPLP. Electro-thermal coupling induces a rapid temperature rising to 98 °C at 25 kHz caused by dielectric loss, leading to oil turbidity and white precipitation, consistent with finite element simulations. Consequently, a failure mechanism is proposed as follows: prolonged electro-thermal stress causes chain scission in styrene-containing materials, releasing monomers that repolymerize into white polystyrene deposits. Their porous structure and dielectric mismatch distort the interfacial field, trigger partial discharge, and aggravate surface flashover. Full article
(This article belongs to the Section Polymeric Materials)
Show Figures

Graphical abstract
