This study addresses collision detection in the unmanned loading of ore from load-haul-dump (LHD) machines into mining trucks in underground metal mines. Such environments present challenges like heavy dust, confined spaces, sensor occlusions, and poor lighting. This work identifies two primary collision risks and proposes corresponding detection strategies. First, for collisions between the bucket and tunnel walls, LiDAR is used to collect 3D point cloud data. The point cloud is processed through filtering, downsampling, clustering, and segmentation to isolate the bucket and tunnel wall. A KD-tree algorithm is then used to compute distances to assess collision risk. Second, for collisions between the bucket and the mining truck, a kinematic model of the LHD’s working device is established using the Denavit–Hartenberg (DH) method. Combined with inclination sensor data and geometric parameters, a formula is derived to calculate the pose of the bucket’s tip. Key points from the bucket and truck are then extracted to perform collision detection using the oriented bounding box (OBB) and the separating axis theorem (SAT). Simulation results confirm that the derived pose estimation formula yields a maximum error of 0.0252 m, and both collision detection algorithms demonstrate robust performance. Full article

Natural gas storage is an effective solution to address the energy supply–demand imbalance, and underground gas storage (UGS) is a primary method for storing natural gas. The overarching goal of this study is to monitor and analyze surface deformation at the Hutubi underground gas storage facility in Xinjiang, China, which is the largest gas storage facility in the country. This research aims to ensure the stable and efficient operation of the facility through long-term monitoring, using remote sensing data and advanced modeling techniques. The study employs the SBAS-InSAR method, leveraging Synthetic Aperture Radar (SAR) data from the TerraSAR and Sentinel-1 sensors to observe displacement time series from 2013 to 2024. The data is processed through wavelet transformation for denoising, followed by the application of a Gray Wolf Optimization (GWO) algorithm combined with Variational Mode Decomposition (VMD) to decompose both surface deformation and gas pressure data. The key focus is the development of a high-precision predictive model using a Gated Recurrent Unit (GRU) network, referred to as GWO-VMD-GRU, to accurately predict surface deformation. The results show periodic surface uplift and subsidence at the facility, with a notable net uplift. During the period from August 2013 to March 2015, the maximum uplift rate was 6 mm/year, while from January 2015 to December 2024, it increased to 12 mm/year. The surface deformation correlates with gas injection and extraction periods, indicating periodic variations. The accuracy of the InSAR-derived displacement data is validated through high-precision GNSS data. The GWO-VMD-GRU model demonstrates strong predictive performance with a coefficient of determination (R²) greater than 0.98 for the gas well test points. This study provides a valuable reference for the future safe operation and management of underground gas storage facilities, demonstrating significant contributions to both scientific understanding and practical applications in underground gas storage management. Full article

Remote drilling technologies play a crucial role in automating both underground and open-pit hard rock mining operations. These technologies enhance efficiency and, most importantly, improve safety in the mining sector. Autonomous drilling rigs can navigate to pre-determined positions and utilize the appropriate parameters to drill boreholes effectively. This article explores various aspects of automation, including the integration of advanced data collection methods that monitor the drilling parameters and facilitate the creation of 3D models of rock hardness. The shift toward machine automation involves transitioning from human-operated machines to systems powered by artificial intelligence, which are capable of making real-time decisions. Navigating underground environments presents unique challenges, as traditional RF-based localization systems often fail in these settings. New solutions, such as constant localization and mapping techniques like SLAM (simultaneous localization and mapping), provide innovative methods for navigating mines, particularly in uncharted territories. The development of robotic exploration rigs equipped with modules that can operate autonomously in hazardous areas has the potential to revolutionize mineral exploration in underground mines. This article also discusses solutions aimed at validating and improving existing methods by optimizing drilling strategies to ensure accuracy, enhance efficiency, and ensure safety. These topics are explored in the context of the Horizon Europe-funded PERSEPHONE project, which seeks to deliver fully autonomous, sensor-integrated robotic systems for deep mineral exploration in challenging underground environments. Full article

The Industry Foundation Class (IFC)-based sensor monitoring information expression mechanism is discussed, and an IFC-based tunnel entity definition and sensor monitoring information expansion method are proposed. Based on the existing IFC standards, by introducing the description dimensions of the tunnel’s spatial and geometric structure, the definition of IFC tunnel entities is creatively supplemented. For the first time, the expansion of IFCs in the field of tunnels is achieved, significantly expanding the boundaries of IFCs in complex underground engineering applications. The IFC-based tunnel monitoring information model is constructed using IfcSensor as the sensor entity and extending the sensor entity attribute set. Aiming at the problems of complicated tunnel monitoring data and difficult storage, this paper studies the tunnel monitoring information integration and visual early warning method based on IFCs. A Building Information Modeling (BIM)-based monitoring information integration system is developed, and the engineering application is carried out with the Jianyuan–Kaiyuan Road tunnel project in Xi‘an as a demonstration case. The advantages of BIM technology in a model visualization application are verified, and the risk perception and visual warning of tunnel construction are realized. Full article

Potatoes, as the world’s fourth-largest staple crop, are vital for global food security. Efficient methods for assessing yield and quality are essential for policy-making and optimizing production. Traditional yield assessment techniques remain destructive, labor-intensive, and unsuitable for large-scale monitoring. While remote sensing has offered a promising alternative, current approaches largely depend on empirical correlations rather than physiological mechanisms. This limitation arises because potato tubers grow underground, rendering their traits invisible to aboveground sensors. This study investigated the mechanisms underlying hyperspectral remote sensing for assessing belowground yield traits in potatoes. Field experiments with four cultivars and five nitrogen treatments were conducted to collect foliar biochemistries (chlorophyll, nitrogen, and water and dry matter content), yield traits (tuber yield, fresh/dry weight, starch, protein, and water content), and leaf spectra. Two approaches were developed for predicting belowground yield traits: (1) a direct method linking leaf spectra to yield via statistical models and (2) an indirect method using structural equation modeling (SEM) to link foliar biochemistry to yield. The SEM analysis revealed that foliar nitrogen exhibited negative effects on tuber fresh weight (path coefficient b = −0.57), yield (−0.37), and starch content (−0.30). Similarly, leaf water content negatively influenced tuber water content (0.52), protein (−0.27), and dry weight (−0.42). Conversely, chlorophyll content showed positive associations with both tuber protein (0.59) and dry weight (0.56). Direct models (PLSR, SVR, and RFR) achieved higher accuracy for yield (R² = 0.58–0.84) than indirect approaches (R² = 0.16–0.45), though the latter provided physiological insights. The reduced accuracy in indirect methods primarily stemmed from error propagation within the SEM framework. Future research should scale these leaf-level mechanisms to canopy observations and integrate crop growth models to improve robustness across environments. This work advances precision agriculture by clarifying spectral–yield linkages in potato systems, offering a framework for hyperspectral-based yield prediction. Full article

Integrating autonomous haulage systems into underground mining has revolutionized safety and operational efficiency. However, deploying 3D detection systems for autonomous truck navigation in such an environment faces persistent challenges due to dust, occlusion, complex terrains, and low visibility. This affects their reliability and real-time processing. While existing reviews have discussed object detection techniques and sensor-based systems, providing valuable insights into their applications, only a few have addressed the unique underground challenges that affect 3D detection models. This review synthesizes the current advancements in 3D object detection models for underground autonomous truck navigation. It assesses deep learning algorithms, fusion techniques, multi-modal sensor suites, and limited datasets in an underground detection system. This study uses systematic database searches with selection criteria for relevance to underground perception. The findings of this work show that the mid-level fusion method for combining different sensor suites enhances robust detection. Though YOLO (You Only Look Once)-based detection models provide superior real-time performance, challenges persist in small object detection, computational trade-offs, and data scarcity. This paper concludes by identifying research gaps and proposing future directions for a more scalable and resilient underground perception system. The main novelty is its review of underground 3D detection systems in autonomous trucks. Full article

In this article, the current state of the art in the area of autonomously working and mobile robots used for inspections in deep underground mining and exploration is described, and directions for future development are highlighted. The increasing demand for CRMs (critical raw materials) and deeper excavations pose a higher risk for people and require new solutions in the maintenance and inspection of both underground machines and excavations. Mitigation of risks and a reduction in accidents (fatal, serious and light) may be achieved by the implementation of mobile or partly autonomous solutions such as drones for exploration, robots for exploration or initial excavation, etc. This study examines various types of mobile unmanned robots such as ANYmal on legs, robots on a tracked chassis, or flying drones. The main scope of this review is the evaluation of the effectiveness and technological advancement in the aspect of improving safety and efficiency in deep underground and abandoned mines. Notable possibilities are multi-sensor systems or cooperative behaviors in systems which involve many robots. This study also highlights the challenges and difficulties of working and navigating (in an environment where we cannot use GNSS or GPS systems) in deep underground mines. Mobile inspection robots have a major role in transforming underground operations; nevertheless, there are still aspects that need to be developed. Further improvement might focus on increasing autonomy, improving sensor technology, and the integration of robots with existing mining infrastructure. This might lead to safer and more efficient extraction and the SmartMine of the future. Full article

The advent of digital mining has become a tangible reality in recent years. This digital evolution requires a predictive understanding of key elements, particularly considering the reliable communication infrastructures needed for autonomous machines. The LoRa technology and its underground propagation behavior can make an important contribution to this digitalization. Since LoRa operates with a high signal budget and long ranges in sub-GHz frequencies, its behavior is very promising for underground sensor networks. The aim of the development and series of measurements was to observe LoRa’s applicability and propagation behavior in active salt mines and to detect and identify effects arising from the special environment. The propagation of LoRa was measured via packet loss and signal strength in line-of-sight and non-line-of-sight configurations over entire mining sections. The aim was to analyze the performance of LoRa at the macroscopic level. LoRa operated at 868 MHz in the free band, and units were equipped with omni-directional antennas. The K+S Group’s active salt and potash mine Werra, Germany, was kindly opened as a distinctive experimental setting. The LoRa exhibited characteristics that were highly distinctive in this environment. The presence of the massive salt allowed the signal to bounce along drift edges with near-perfect reflection, which enabled travel over kilometers due to a waveguide-like effect. A packet loss of below $15\%$ showed that LoRa communication was possible over distances exceeding 1000 m with no line-of-sight in room-and-pillar structures. Measured differences of $\Delta 50\mathrm{dBm}$ values confirmed consistent path loss across different materials and tunnel geometries. This effect occurs due to the physical structure of the mining drifts, facilitating the containment and direction of signals, minimizing losses during propagation. Further modeling and measurements are of great interest, as they indicate that LoRa can achieve even better outcomes underground than in urban or indoor environments, as this waveguide effect has been consistently observed. Full article

Underground coal mines face increasing challenges in the scheduling of Electric Rubber-Tired Vehicles (ERTVs) due to confined spaces, dynamic production demands, and the need to coordinate multiple constraints such as complex roadway topologies, strict time windows, and limited charging resources in the context of clean energy transitions. This study presents a Constraint Programming (CP)-based optimization framework that integrates Virtual Charging Station Mapping (VCSM) and sensor fusion positioning to decouple spatiotemporal charging conflicts and applies a dynamic topology adjustment algorithm to enhance computational efficiency. A novel RFID–vision fusion positioning system, leveraging multi-source data to mitigate signal interference in underground environments, provides real-time, reliable spatiotemporal coordinates for the scheduling model. The proposed multi-objective model systematically incorporates hard time windows, load limits, battery endurance, and roadway regulations. Case studies conducted using real-world data from a large-scale Chinese coal mine demonstrate that the method achieves a 17.6% reduction in total transportation mileage, decreases charging events by 60%, and reduces vehicle usage by approximately 33%, all while completely eliminating time window violations. Furthermore, the computational efficiency is improved by 54.4% compared to Mixed-Integer Linear Programming (MILP). By balancing economic and operational objectives, this approach provides a robust and scalable solution for sustainable ERTV scheduling in confined underground environments, with broader applicability to industrial logistics and clean mining practices. Full article

Navigation technologies are becoming more advanced, helping to solve complicated problems in various fields. Navigation can be classified as global, in which predefined data and reference points from the working environment are used to generate a path, and local, where the map is generated momentarily by acquiring data from outside using sensors. As navigation tasks become more demanding, working environments can become very complicated with an increasing number of dynamic obstacles or, in some cases, a lack of global references, which may have particularly notable impacts on communication. Inspection robots that are required to work in underground sewers are often required to work completely locally, relying on sensor data. For this reason, in this study, a cost-efficient laser marker-based obstacle detection and measurement system is designed and tested for future use in autonomous sewer robot local path generation. Our experiments show the convenience of applying four linear laser markers with an RGB camera to fully inspect upcoming obstacles in the region covering the front robot dimensions. The results show distance measurement accuracy of up to ±1.33 mm and obstacle width accuracy of up to ±0.28 mm measured from a 130 mm range. Nevertheless, accuracy is strongly dependent on the segmentation of image resolution, lighting, and reflection of the inspected surfaces. Also, it depends on the configuration of laser markers and the RGB camera position. Full article

The navigation of Unmanned Ground Vehicles (UGVs) in underground mining environments is critical for enhancing operational safety, efficiency, and automation in hazardous and constrained conditions. This paper presents a thorough review of path-planning algorithms employed for the navigation of UGVs in underground mines. It outlines the key components and requirements that are essential for an effective path planning framework, including sensors and the Robot Operating System (ROS). This review examines both global and local path-planning techniques, encompassing traditional graph-based methods, sampling-based approaches, nature-inspired algorithms, and reinforcement learning strategies. Through the analysis of the extant literature on the subject, this study highlights the strengths of the employed techniques, the application scenarios, the testing environments, and the optimization strategies. The most favorable and relevant algorithms, including A*, Rapidly-exploring Random Tree (RRT*), Dijkstra’s, Ant Colony Optimization (ACO), were identified. This paper acknowledges a significant limitation: the over-reliance on simulation testing for path-planning algorithms and the computational difficulties in implementing some of them in real mining conditions. It concludes by emphasizing the necessity for full-scale research on path planning in real mining conditions. Full article

In response to the need for cable outer sound source localization, this paper proposes a collaborative localization method based on an improved generalized cross-correlation phase transform (GCC-PHAT) and multi-sensor fusion. By constructing a secondary cross-shaped sensor array model, employing a phase transform weighting function to suppress environmental noise, and incorporating an adaptive environmental compensation algorithm to eliminate multipath effects, a set of spatial localization equations is established. Innovatively, a dynamic weighting factor linked to the startup threshold is introduced; the Levenberg–Marquardt optimization algorithm is then used to iteratively solve the nonlinear equations to achieve preliminary localization in a single-pile coordinate system. Finally, a dynamic weighted fusion model is constructed through DBSCAN spatial clustering to determine the final sound source position. Experimental results demonstrate that this method reduces the mean square error of time delay estimation by 94.7% in a 90 dB industrial noise environment, decreases the localization error by 65.4% in multi-obstacle scenarios, and ultimately maintains localization accuracy within 3 m over a range of 100 m. This performance is significantly superior to that of traditional TDOA and SRP-PHAT methods, offering a high-precision localization solution for underground cable protection. Full article

The gradual deterioration of underground water infrastructure requires constant condition monitoring to prevent catastrophic failures, reduce leaks, and avoid costly unexpected repairs. However, given the large scale and tight budgets of water utilities, it is essential to implement strategies for optimal selection and deployment of monitoring technologies. This article introduces a unified framework and methods for optimally selecting condition monitoring technologies while locating their deployment at the most vulnerable pipe segments. The approach is underpinned by an R-E-R-A-V (Redundant, Established, Reliable, Accurate, and Viable) principle and asset management concepts. The proposed method is supported by a thorough review of assessment and monitoring technologies, as well as common sensor placement approaches. The approach selects optimal technology using a combination of technology readiness levels and SFAHP (Spherical Fuzzy Analytic Hierarchy Process). Optimal placement is achieved with a k-Nearest Neighbors (kNN) model tuned with minimal topological and physical pipeline system features. Feature engineering is performed with OPTICS (Ordering Points to Identify the Clustering Structure) by evaluating the pipe segment vulnerability to failure-prone areas. Both the optimal technology selection and placement methods are integrated through a proposed algorithm. The optimal placement of monitoring technology is demonstrated through a modified benchmark network (Net3). The results reveal an accurate model with robust performance and a harmonic mean of precision and recall of approximately 65%. The model effectively identifies pipe segments requiring monitoring to prevent failures over a period of 11 years. The benefits and areas of future exploratory research are explained to encourage improvements and additional applications. Full article

Underground winter bamboo shoots, prized for their high nutritional value and economic significance, face harvesting challenges owing to inefficient manual methods and the lack of specialized detection technologies. This review systematically evaluates current detection approaches, including manual harvesting, microwave detection, resistivity methods, and biomimetic techniques. While manual methods remain dominant, they suffer from labor shortages, low efficiency, and high damage rates. Microwave-based technologies demonstrate high accuracy and good depths but are hindered by high costs and soil moisture interference. Resistivity methods show feasibility in controlled environments but struggle with field complexity and low resolution. Biomimetic approaches, though innovative, face limitations in odor sensitivity and real-time data processing. Key challenges include heterogeneous soil conditions, performance loss, and a lack of standardized protocols. To address these, an integrated intelligent framework is proposed: (1) three-dimensional modeling via multi-sensor fusion for subsurface mapping; (2) artificial intelligence (AI)-driven harvesting robots with adaptive excavation arms and obstacle avoidance; (3) standardized cultivation systems to optimize soil conditions; (4) convolution neural network–transformer hybrid models for visual-aided radar image analysis; and (5) aeroponic AI systems for controlled growth monitoring. These advancements aim to enhance detection accuracy, reduce labor dependency, and increase yields. Future research should prioritize edge-computing solutions, cost-effective sensor networks, and cross-disciplinary collaborations to bridge technical and practical gaps. The integration of intelligent technologies is poised to transform traditional bamboo forestry into automated, sustainable “smart forest farms”, addressing global supply demands while preserving ecological integrity. Full article

The Urban Drainage Network (UDN) is a type of underground municipal infrastructure responsible for transporting sewage and rainwater. To keep abreast of the hydraulic and water quality conditions of the pipes and to detect problems such as pipe clogging, pollution and leakage, real-time monitoring sensors have been widely adopted, accomplished with the development of IoT technologies. However, the intricate topology and numerous nodes of drainage pipes complicate IoT sensor placement strategies, especially in the selection of sensors and the location of monitoring points. This review examines application cases of IoT sensors in UDNs and some other hydraulic networks, evaluating the characteristics and applicability of various optimal placement methods and theories. A general framework was proposed applicable to the optimal placement of IoT sensors in the UDN, including object classification–method selection–quantitative evaluation. Currently, the quantitative evaluation of monitoring schemes lacks a systematic process, and existing layout methods may not be optimal. Future research can explore dynamic optimization strategies through phased deployment and feedback iteration, which can enhance the accuracy and objectivity of sensor layout design and evaluation. Full article
