Search Results (352)

This paper presents an integrated techno–economic framework for coordinated grid-to-vehicle and vehicle-to-grid (G2V–V2G) operation in unbalanced distribution networks. A hardware-compatible bidirectional charger with nested AC/DC and DC/DC control loops, together with a rule-based energy management system (EMS), enables seamless mode transitions while enforcing state-of-charge (SoC) and network constraints. A probabilistic Monte Carlo study on the IEEE 13-bus feeder shows that uncoordinated G2V charging induces adverse grid impacts such as voltage stress, line-ampacity violations, and transformer overloading, whereas EMS-driven V2G support improves voltage by 2–4%, reduces line loading by 15–25%, and lowers transformer stress by up to 10%. To align these technical benefits with economic incentives, a bi-level Stackelberg model is formulated where the utility updates locational energy prices based on combined voltage, line ampacity, transformer loading stress indices and EVs choose profit-maximizing nodes, modes and power levels. The interaction converges to a Stackelberg equilibrium with a clear win–win situation; the feeder’s average locational energy price falls entirely within the win–win region, yielding positive per-session profits for both the EV (≈$0.80) and the utility (≈$0.48) while reducing feeder stress. These results demonstrate that stress-aware locational pricing, combined with detailed converter-level control provides a technically robust and economically sustainable pathway for large-scale EV integration. Full article

The expansion and ongoing refinement of control solutions for three-phase microgrids are key enablers in the transition from conventional distribution networks to smart microgrids. By integrating distributed generation, a microgrid can operate in either grid-connected or island mode. One of the major technical challenges in microgrid operation is mitigating or eliminating phase power unbalances. Unbalanced single-phase loads, combined with unbalanced and intermittent single-phase generation, can produce adverse effects on both energy efficiency and power quality. Unlike conventional distribution networks, microgrids may exhibit bidirectional power flows, which can occur simultaneously on all phases or differ from phase to phase. This paper introduces new analytical expressions for sizing a balancing capacitive compensator (BCC) for three-phase four-wire systems and derives a simplified sizing algorithm. The approach is validated through a numerical study using a Matlab/Simulink model of a low-voltage three-phase microgrid with high penetration of single-phase loads and single-phase distributed sources. The BCC is installed at the point of common coupling (PCC) between the microgrid and the main grid. Three operating regimes (cases) of the microgrid were analyzed, considering three compensation scenarios (sub-cases) for each: 1—without compensation, 2—with balanced capacitive compensation (classical), and 3—with unbalanced capacitive compensation (with BCC). For each of the three regimes (cases), the use of the BCC determines, at the PCC, in addition to the cancellation of the reactive component of the positive sequence current, the cancellation of the negative- and zero-sequence currents. In other words, the BCC–microgrid assembly is seen from the main grid either as a perfectly balanced active power load or as a perfectly balanced active power source. Thus, the BCC prevents the propagation of the unbalance disturbance in the main grid; in the considered case study, this also results from the cancellation of the negative- and zero-sequence components of the phase voltages measured at the PCC. The results show that the load-balancing capability of the BCC can be extended to power-flow balancing in any network section, including cases where the phase power directions differ. Implemented as a BCC-type SVC or as an automatically adjustable variant (ABCC), the proposed unbalanced shunt capacitive compensation method is effective for mitigating or eliminating bidirectional phase power-flow unbalances. Full article

This paper investigates a five-level active neutral-point-clamped (5L-ANPC) converter operating in rectifier mode with unbalanced DC-side loads, where neutral-point (NP) deviation may deteriorate grid-current quality. Conventional space-vector pulsewidth modulation (SVPWM) is typically derived under the split-capacitor-voltage symmetry assumption; when NP deviation occurs, fixed sector boundaries and ideal volt–second balance calculations can lead to sector misclassification and synthesis errors. To address this issue, an NP-aware SVPWM scheme is proposed by reconstructing sector criteria using real-time capacitor voltages and correcting the vector dwelling-time computation to improve modulation accuracy under imbalance. Based on the power-transfer mechanism, an average-power boundary condition is further derived to quantify the admissible upper/lower load power ratio that allows NP regulation without additional hardware, and its validity is examined under resistive-load cases. Moreover, for battery-type loads exhibiting voltage-source characteristics, the control objective is extended from voltage symmetry to controllable power/charge allocation by establishing a mapping between the small-vector duty ratio and the branch average-power ratio, with constrained online solution and smoothing to mitigate coefficient jitter. Experimental validation is conducted on an OPAL-RT OP5707-based hardware-in-the-loop platform, where both single-phase and three-phase 5L-ANPC systems are implemented according to different verification objectives. The derived boundary condition for resistive loads is examined in the single-phase system, while the proposed modulation and battery-load power-allocation strategy are verified in the three-phase system. The three-phase arrangement is adopted for the battery-load case in order to avoid the second-order power ripple inherent to single-phase operation. Full article

Flywheel energy storage systems exhibit superior performance in electric vehicle regenerative braking, railway traction power supply, and grid frequency regulation due to their high instantaneous power and fast dynamic response. However, systems supported by conventional mechanical bearings face severe radial structural coupling; unbalanced excitation and gyroscopic effects drastically amplify vibrations during critical speed traversal, undermining operational reliability and engineering scalability. To tackle this challenge, this paper proposes a full-speed vibration suppression scheme for active–passive supported flywheel energy storage systems integrated with a damping ring, combined with an inverse system decoupling controller to eliminate structural coupling, unbalance-induced vibration, and gyroscopic effects. A dynamic model of the integrated system is established using Lagrange’s equations, and four-degree of freedom decoupling expressions are derived to achieve complete radial decoupling. A speed-stage-based control strategy is further developed for full-speed adaptation. Comprehensive simulations validate the scheme’s decoupling performance, vibration suppression efficacy, and robustness. Results demonstrate that the proposed controller achieves full radial decoupling, reducing the average steady-state tracking error by 99.86%. The segmented control enables stable operation across 100–20,000 rpm and cuts critical speed resonance peaks by 81.23%. Compared with pure mechanical and magnetic bearing systems, the integrated active–passive support reduces resonance peaks by 94.72% and 42.25%, respectively. Under current perturbation and parameter variation, the scheme reduces the average steady-state error by 75.89% relative to the coupled system, confirming its strong engineering applicability. Full article

The fast growth of electric vehicles (EVs) and renewable energy motivates reliable charging infrastructure with balanced energy management and good power quality. However, conventional converter controllers like proportional and integral (PI) and fuzzy logic controllers (FLCs) exhibit slow dynamic response, poor adaptability to varying solar conditions, unbalanced energy management, low power quality, and higher total harmonic distortion (THD). To overcome these limitations, this work proposes an adaptive neuro-fuzzy inference system (ANFIS) controller for balanced energy management and improved power quality in EV charging stations. The ANFIS controller is a combination of a fuzzy inference system (FIS) and a neural network (NN). The FIS provides the best maximum power point tracking and robust control during changing solar PV conditions. The NN optimally controls the flow of power between the solar PV system, energy storage battery (ESB), EV, and utility grid. The entire system is simulated in MATLAB/Simulink. It consists of a PV system with a capacity of 2 kW, an ESB with a capacity of 10 kWh and an EV battery with a capacity of 4 kWh, which are linked by bidirectional DC/DC converters. A 30 kVA bidirectional inverter, along with an LCL filter, is connected between the 500 V DC bus and 440 V utility grid, allowing for both directions. The results validate the effectiveness of the proposed ANFIS controller in terms of DC bus voltage stability, faster dynamic response, enhanced renewable energy utilization, improved efficiency to 98.86%, reduced voltage and current THD to 4.65% and 2.15% respectively, reduced utility grid stress, and enhanced energy management compared to conventional PI and FLCs. Full article

In grid-connected inverter systems, the Phase-Locked Loop (PLL) is fundamental for achieving and maintaining precise synchronization between the inverter and the electrical grid. Developing an efficient and robust PLL is essential to ensure reliable operation, particularly in the presence of abnormal grid conditions. Among the existing synchronization methods, the Synchronous Reference Frame-based PLL (SRF-PLL) is widely adopted due to its robust performance; however, it suffers from degraded accuracy under unbalanced voltage conditions. To address this limitation, the Second-Order Generalized Integrator-Quadrature Signal Generator (SOGI-QSG) was proposed in previous studies as an alternative approach. Despite its advantages, the SOGI-PLL exhibits weak filtering capability for lower-order harmonics and remains sensitive to DC offset, both of which can affect synchronization quality. As a result, numerous advanced PLLs based on SOGI-QSG have been proposed in the literature to address SOGI-QSG limitations by enhancing DC offset rejection, filtering capability, and dynamic response. This article provides a comprehensive assessment of various three-phase PLLs based on SOGI-QSG under unbalanced grid conditions, focusing on peak-to-peak frequency error, filtering performance, and DC offset rejection. The operational principles and mathematical models of each technique are discussed, and their performances are validated using MATLAB/Simulink (R2025b). The results show that the SRF-PLL exhibits oscillatory behavior under unbalanced conditions, whereas the PLLs based on SOGI-QSG demonstrate stable synchronization with different trade-offs between filtering strength and dynamic response. Therefore, the selection of the appropriate PLLs based on SOGI-QSG depends on the priorities of the specific application. Full article

As the oil price has skyrocketed, the attraction towards electric vehicles has gone up. This scenario has also increased the demand for charging infrastructure. This paper proposes a novel charging infrastructure for electric vehicles which is energized by a solar photovoltaic unit, integrated with a distribution static compensator. The output of the photovoltaic array is regulated by a DC–DC converter, which uses maximum power point tracking to support optimal solar energy conversion. The compensator is integrated into the grid through a zigzag-star transformer, which helps with neutral current compensation, promoting balanced and distortion-free operation. The control algorithm is designed to ensure superior power quality during grid synchronization and sustainable energy management. This novel architecture ensures bidirectional power flow, enabling the charge–discharge dynamics of the electric vehicles, which can be termed Grid-to-Vehicle and Vehicle-to-Grid modes. Better grid flexibility and resilience are ensured by this dynamic power exchange. The control strategy based on the Linear Kalman Filter provides reactive power balance and maintains steady voltage at the point of common coupling, and it ensures enhanced power quality during power flow, resulting in efficient and reliable grid operations. The effectiveness of the control algorithm is tested and validated under Grid-to-Vehicle, Vehicle-to-Grid, nonlinear, unbalanced, and isolated solar conditions. Analytical tuning of the gains in the controller, by using the conventional methods, is not efficient under dynamic conditions and nonlinear loads. An optimization technique is used to estimate the proportional–integral control gains, which avoids the difficulty of tuning the controllers. Simulation of the system is carried out using MATLAB 2022b/SIMULINK. Simulation results under diverse operating scenarios confirm the system’s capability to sustain superior power quality, maintain grid stability, and support a robust and reliable charging infrastructure. By enabling regulated bidirectional energy exchange and autonomous operation during grid disturbances, the charger operates as a resilient grid-support asset rather than as a passive electrical load. Full article

Large-scale grid integration of renewable generation is facilitated by resource abundance and advancements in power electronics. The high penetration of power electronics-based devices reduces system inertia, threatening grid stability. The Virtual Synchronous Generator (VSG) provides an effective solution. However, when the grid is unbalanced, problems such as unbalanced output current, overcurrent, and power fluctuations occur. Thus, a VSG power–current collaborative control strategy based on improved second-order generalized integrator (SOGI) is proposed. Firstly, the generation of power fluctuation and unbalanced current in VSG output under an unbalanced power grid is analyzed. Secondly, to suppress the DC component and high-order harmonics, an improved SOGI method is proposed for positive and negative sequence separation by introducing a difference node and adding an extra SOGI module on the basis of the traditional SOGI. To achieve the collaborative control of active/reactive power constant and current balance, a correlation coefficient μ is introduced and a unified equation is constructed. To prevent overcurrent during fault, virtual impedance and reactive power reference are introduced. Simulations have verified the effectiveness of the proposed method. It shows superiority in effective sequence separation, smooth power–current collaborative control, and safe operation without overcurrent. Full article

The rapid rise of inverter-based resources (IBRs) such as solar, wind, and battery energy storage is transforming power grids and creating new challenges for protection. Unlike synchronous generators, many IBRs are interfaced through grid-following (GFL) inverters that operate as controlled current sources and rely on an external voltage reference, resulting in fault responses that are current-limited and controller-shaped. These characteristics reduce fault current magnitude and can undermine conventional protection schemes. In contrast, emerging grid-forming (GFM) inverters behave as voltage sources that establish local voltage and frequency, offering improved disturbance support but still transitioning to current-limited operation under severe faults. This review summarizes GFL versus GFM operating principles and deployments, compares their behavior under balanced and unbalanced faults, and evaluates protection impacts using a protection-relevant taxonomy supported by illustrative electromagnetic transient (EMT) case studies. Key challenges, including underreach/overreach of impedance-based elements, reduced overcurrent sensitivity, and directional misoperation, are identified. Mitigation options are discussed, spanning adaptive/supervised relaying, communication-assisted and differential protection, and inverter-side fault current shaping and GFM integration. The implications of IEEE 1547-2018 and IEEE 2800-2022 are reviewed to clarify ride-through and support requirements that constrain protection design in high-IBR systems. Full article

As the three-phase four-bridge inverter (3P4B) can effectively compensate for the unbalanced three-phase loads in the grid, it is an important converter option for distributed generation grid connection. As in a three-phase three-bridge inverter (3P3B), the wide variation in grid impedance also poses instability issues for 3P4B. This issue has been well-addressed for 3P3B, which can be seen as a differential-mode circuit. However, 3P4B has an extra common-mode circuit, and the solution to the instability problem has not been investigated so far. To address this issue, this paper first analyzes the mechanism of 3P4B common-mode circuit instability and discovers its stability range difference from its differential-mode circuit. Then, an equivalent control delay compensator is independently introduced into the common-mode loop, which extends its stable range. This paper also conducts a detailed analysis of the control delay compensator’s impacts on the common-mode control loop and proposes a quantitative design method for the compensator accordingly. Experimental results validate that the proposed method effectively mitigates common-mode loop instability even under a wide range of grid impedance variations. Full article

This study investigated the fault ride through capability of inverter-based resources in weak distribution networks and proposes a fault-oriented reactive power compensation strategy using only point of common coupling voltage measurements. The proposed strategy determines the reactive power command based on the minimum phase voltage, which represents the most severely depressed phase during unbalanced faults, without fault type detection or sequence component analysis. As a result, the same control framework can be applied to single-line-to-ground, double-line-to-ground, and three-phase faults. A detailed MATLAB/Simulink model of a Korean distribution feeder was developed using actual system parameters. The proposed strategy was compared with a no control case and a conservative fixed capacity reactive power injection scheme derived from commonly adopted power factor limits. Simulation results show that the no control case provides no voltage support, while the fixed capacity approach yields limited improvement in weak grids. In contrast, the proposed strategy maintains stable inverter operation and improves voltage recovery. At locations with an extremely low weighted short circuit ratio of 0.303, the proposed strategy prevents inverter tripping during temporary faults and satisfies low voltage ride through requirements, demonstrating its practical effectiveness. Full article

The rapid integration of solar power into distribution grids has intensified challenges related to frequency instability caused by fluctuating renewable generation. These unexpected frequency variations are difficult to capture using traditional or supervised methods because they emerge from nonlinear, rapidly changing inverter grid interactions and often lack labelled examples. To address this, the present work introduces a unique, frequency-centric framework for unsupervised detection and root cause analysis of grid anomalies using high-resolution micro-Phasor Measurement Unit ($\mu$PMU) data. Unlike previous studies that focus primarily on voltage phasors or rely on predefined event labels, this work employs SpectralNet, a deep spectral clustering approach, integrated with autoencoder-based feature learning to model the nonlinear interactions between frequency, ROCOF, voltage, and current. These methods are particularly effective for unexpected frequency variations because they learn intrinsic, hidden structures directly from the data and can group abnormal frequency behavior without prior knowledge of event types. The proposed model autonomously identifies distinct root causes such as unbalanced loads, phase-specific faults, and phase imbalances behind hazardous frequency deviations. Experimental validation on a real solar-integrated distribution feeder in the UK demonstrates that the framework achieves superior cluster compactness and interpretability compared to traditional methods like K-Means, GMM, and Fuzzy C-Means. The findings highlight SpectralNet’s capability to uncover subtle, nonlinear patterns in $\mu$PMU data, offering an adaptive, data-driven tool for enhancing grid stability and situational awareness in renewable-rich power systems. Full article

This paper presents a novel multi-loop control strategy for Vienna rectifiers that eliminates coordinate transformations while achieving superior performance under adverse grid conditions. Unlike conventional $dq$-frame controllers that suffer from computational complexity and degraded performance during unbalanced conditions, the proposed $abc$-frame scheme achieves a power factor of $98\%$ with total harmonic distortion (THD) below $5\%$ across all operating conditions. The system exhibits a settling time under 120 μs for $90\%$ load transients and ensures robust operation during Type A voltage sags while maintaining a $94\%$ power factor. Furthermore, it guarantees zero steady-state neutral point deviation. The controller employs a dual-loop architecture with high-gain current tracking and PI-based voltage regulation, validated through extensive PSIM/C++ co-simulations at 120 kw. Comparative analysis demonstrates a $35\%$ reduction in computational burden relative to $dq$-frame alternatives, while fully complying with IEEE-519:2022 standards. These results highlight the proposed method as a practical and robust solution for industrial rectification applications requiring grid-fault tolerance. Full article

Under unbalanced grid conditions, the three-phase Vienna rectifier exhibits significant voltage fluctuations in dc-link and asymmetric input currents. Traditional control methods cannot simultaneously suppress the voltage ripples in dc-link and balance the input currents. Therefore, a weighted control strategy based on the degree of current imbalance is proposed in this paper. The strategy is implemented within a dual closed-loop architecture, featuring a finite-set model predictive control (FS-MPC) method in the current loop and a sliding mode control (SMC) method in the voltage loop. In the current loop, the two control objectives of voltage in dc-link and input current are weighted, and the weighting factor is dynamically adjusted based on the degree of current imbalance. This strategy can simultaneously achieve control for input current symmetry and dc-link voltage balance under unbalanced grid conditions. Finally, a 2 kW Vienna rectifier experimental platform was independently constructed. Simulation and experimental results indicate that under unbalanced grid conditions, the proposed control strategy achieves approximately 10% lower total harmonic distortion (THD) and maintains DC-link voltage fluctuation within 5 V, compared to traditional control methods. Full article

The ongoing decarbonisation of power systems is displacing synchronous generators (SGs) with converter-based plants, requiring a consistent assessment of grid-following inverters (GFLIs) and grid-forming inverters (GFMIs). Using an openly available four-bus root-mean-square (RMS) benchmark modelled in DIgSILENT PowerFactory, this work compares three generation configurations: (i) a single local SG connected at the point of common coupling; (ii) the same generator combined with a GFLI; and (iii) the generator combined with a GFMI. These configurations are evaluated under three disturbance scenarios: (1) a balanced load step, (2) an unbalanced double line-to-ground fault at low short-circuit ratio (SCR) with temporary islanding and single-shot auto-reclose, and (3) full islanding with under-frequency load shedding (UFLS), partial resynchronisation, and staged restoration. For the tested tuning ranges and within this RMS benchmark, the grid-forming configuration behaves as a low-impedance source at the point of common coupling in the phasor sense, yielding higher frequency nadirs during active-power disturbances and faster positive-sequence voltage recovery under weak and unbalanced conditions than the SG-only and SG+GFLI cases. During islanding, it supports selective UFLS, secure resynchronisation, and orderly load restoration. Rather than introducing new control theory, this work contributes a reproducible RMS benchmarking framework that integrates low-SCR operation, unbalance, and restoration sequences with a documented cross-technology tuning procedure. The findings indicate system-level improvements in frequency resilience and voltage recovery for the tested benchmark relative to the alternative configurations, while recognising that instantaneous device-level effects and broader generality will require electromagnetic-transient (EMT) or hybrid EMT/RMS validation in future work. Full article
