Search Results (28)

This investigation examines the decline in breaking performance observed in 550 kV high-speed circuit breakers, tracing the cause to insufficient coordination between the operating mechanism and the arc-extinguishing chamber. It proposes a coordinated adjustment of the buffer strategy mechanism and the structural parameters of the arc-extinguishing chamber, revealing their interaction under high-speed opening conditions. To address the impact loads and unstable airflow field during the mechanism’s high-speed opening, the buffer strategy was revised by increasing the gaps in the first four steps by 0.3 mm and 0.5 mm in two respective optimization schemes. Set the step size to 3 mm, and assign a decrease of zero for each of the final three steps. A 1 mm gap reduces the pressure drop near the end of the opening phase. The axial airflow velocity and the breaking performance were compared at the moment of 1 ms before current zero for three nozzle throat lengths (L_u): 22 mm, 27 mm, and 32 mm. Nozzle throat length has a clear effect on the main parameters of short-arc quenching. With a 27 mm throat length, the measured values remain relatively high. The proposed length scheme achieves a balanced trade-off between the airflow velocity distribution and the efficiency of arc cooling. Downstream of the nozzle, the axial airflow velocity is 18% higher than in the 32 mm scheme, and the pressure decays 22% more slowly than in the 22 mm scheme. This improves heat removal from the arc and shortens the short-arc phase to under 6 ms. Prototype tests provided by the manufacturer indicate that the circuit breaker with a 27 mm nozzle throat can achieve a minimum arcing time of approximately 6 ms, which is consistent with the simulation prediction. Full article

The SF₆ circuit breaker is an essential piece of high-voltage equipment in ensuring the safe operation of the power grid. Regarding the arc-extinguishing chamber, as the most essential component, its performance is directly related to the breaking capacity of the circuit breaker. This study applies the Double Distribution Function Lattice Boltzmann Method (DDF-LBM), combined with the Smagorinsky sub-grid scale (SGS) model, to systematically simulate the dynamic breaking process of a 252 kV SF₆ arc-extinguishing chamber under 50 kA breaking current conditions. Two independent distribution functions are employed to describe the fluid field and the temperature field, respectively, thereby simulating the physical flow–heat coupling process. A dynamic simulation framework is constructed using the D2Q9 model to describe the mechanical motion of the contacts and the fluid flow. The description of contact movement is achieved by dynamically updating the geometric mesh, thereby realizing fluid–solid transformation. The research results indicate that the proposed method can simulate the pressure variation of the fluid field during the breaking process. The value of the Smagorinsky constant (C_s) exhibits a non-negligible influence on the pressure field predictions. The optimal value of C_s = 0.10 is determined through analysis, and the peak pressures at the upstream and throat measurement points reach 1.11 MPa and 1.37 MPa, respectively. Numerical simulations are conducted on the dynamic breaking process of the arc-extinguishing chamber, revealing the evolution of the pressure field upstream of the nozzle and at the throat regions. This study provides new numerical simulation methods for the investigation of SF₆ arc-extinguishing chambers and establishes a foundation for the application of the Lattice Boltzmann Method in the field of high-voltage electrical appliances. Full article

Variable geometry ejectors (VGEs) offer passive, compact, and energy-efficient solutions for fluid transport and thermal management in applications such as refrigeration, hydrogen fuel cells, and solar-driven desalination. By adjusting internal geometries, VGEs maintain high performance under off-design and transient conditions, overcoming limitations of fixed-geometry ejectors. This systematic review synthesizes experimental, numerical, and hybrid research on VGEs published between 30 June 1995 and 1 July 2025. Peer-reviewed journal and conference papers were identified through structured searches of Scopus, Web of Science, and Google Scholar, followed by PRISMA-guided screening. Forty-eight studies were qualitatively synthesized with respect to modulation mechanisms, actuation and control strategies, working fluids, modeling approaches, validation practices, performance metrics, and Technology Readiness Levels (TRLs). Risk of bias was assessed using the Mixed Methods Appraisal Tool (MMAT), complemented by an engineering-specific extension for experimental and numerical studies. Results indicate a strong reliance on numerical modeling, predominantly 2D axisymmetric CFD, with limited high-fidelity experimental validation. Adjustable nozzle throats dominate current designs, while multi-variable geometries and real-time closed-loop control remain underexplored. Most studies cluster at TRLs 2–4, with only two demonstrating full system-level integration. Overall, VGEs show strong potential for energy-efficient operation, but progress toward deployment requires integrated geometry–control co-design, standardized benchmarking, uncertainty-aware validation, and scalable experimental demonstration. This review was not registered. Full article

To address the real-time performance issue of the zero-dimensional nozzle model for gas turbine engines, a non-iterative computational method is proposed that determines the flow regime (subcritical vs. choked) via characteristic Mach number and characteristic flow factor. This method eliminates iterative solution procedures, thereby reducing computational time, and solves the problem of discontinuous throat mass flow rate calculation at the transition flow regime from subcritical to choked in traditional nozzle models. The method is applied to improve a component-level turbofan engine model and is validated through numerical simulation. Simulation results indicate that, compared with traditional nozzle models requiring two and eight iterations, the non-iterative nozzle model reduces computation time by $69.7\%$ and $85.71\%$, respectively. The turbofan engine model incorporating the non-iterative nozzle model achieves a 24.58% reduction in maximum per-step computation time and a 13.7% reduction in average per-step computation time compared with the traditional model, while maintaining comparable simulation accuracy. The proposed method substantially enhances the real-time simulation performance of the component-level turbofan engine model, and can be readily extended to other component-level models—whether based on iterative-solution schemes or on volume-based modeling approaches. Full article

In this paper, a novel venturi jet reactor is innovatively proposed for the process of hydrazine hydrate production using the urea method. In order to investigate the performance of this reactor in depth, we used the computational fluid dynamics method to optimize the design of the structure of the new venturi jet reactor based on the flow field condition, the degree of mixing uniformity, and the efficiency of the reactor using the component transport model. The results showed that the moderate increase of the distance of mixing tube to nozzle and nozzle diameter seven could help to improve the efficiency of the jet reactor; however, in terms of the mixing effect, the increase of the distance of mixing tube to nozzle led to the mixing effect to be enhanced and then weakened, while the increase in the nozzle diameter was not conducive to the full mixing of the two fluids. In addition, the effects of ratio of throat length to diameter and constriction angle on the efficiency of the jet reactor showed nonlinear characteristics, and the optimal values existed in the study range. Based on the above analysis, this paper determines the optimal range of structural parameters, i.e., the distance of mixing tube to nozzle of 7–13 mm, the nozzle outlet diameter of 5–7 mm, the ratio of throat length to diameter of 3–5, and the constriction angle of 30–40°, and the study provides guidance for the industrial application of the venturi jet reactor. Full article

Hemolysis, or the breakdown of red blood cells, observed in medical devices has been a significant concern for many years, particularly when mechanical stress on the cells is considered. This study focuses on evaluating extensional stresses in two configurations of the U.S. Food and Drug Administration (FDA) nozzle: the Gradual Cone (GC) and Sudden Contraction (SC) models. The nozzle geometries were created as 3D models using Ansys Fluent 18.2 and its pre-processing software ICEM CFD. The mesh was constructed with hexahedral elements with O-grid topologies. Effects of varying flow conditions were observed by modeling five experimental cases of the FDA nozzles, including throat Reynolds numbers of 500, 2000, 3500, 5000, and 6500. Hemolysis potentials of FDA nozzle configurations were examined by analyzing the whole domains. Turbulent modeling was used by applying the shear stress transport k-ω (SST k-ω) model. A threshold of 2.8 Pa for extensional stress was observed. Moreover, the most commonly used power law models were applied to the FDA nozzle to see the effect of extensional stress on power law models. Zhang’s power law models gave the lowest standard error, while Giersiepen’s model gave the highest error on hemolysis predictions. Full article

This study presents a comprehensive finite element investigation into the design optimization of an ultra-high temperature ceramic matrix composite thruster for green bipropellant systems. Focusing on ZrB₂–SiC–Cfiber composites, it explores their thermal and mechanical response under realistic transient combustion conditions. Two geometries, a simplified and a complex full-featured model, were evaluated to assess the impact of geometric fidelity on stress prediction. The complex thruster model (CTM) offered improved resolution of temperature gradients and stress concentrations, especially near flange and convergent regions, and was adopted for optimization. A parametric study with nine wall thickness profiles identified a 2 mm tapered configuration in both convergent and divergent sections that minimized mass while maintaining structural integrity. This optimized profile reduced peak thermal stress and overall mass without compromising safety margins. Transient thermal and strain analyses showed that thermal stress dominates initially (≤3 s), while thermal strain becomes critical later due to stiffness degradation. Damage risk was evaluated using temperature-dependent stress margins at four critical locations. Time-dependent failure maps revealed throat degradation for short burns and flange cracking for longer durations. All analyses were conducted under hot-fire conditions without cooling. The validated methodology supports durable, lightweight nozzle designs for future green propulsion missions. Full article

To meet the increasingly stringent performance indicators of gas turbines, the turbine inlet temperature has increased, and variable geometry turbine technology is widely applied. Therefore, this study developed a quasi-two-dimensional (quasi-2D) method for variable geometry turbine performance considering cooling air mixing based on the elementary blade method and the cooling airflow mixing model. To address the high-dimensional, multi-variable data fitting problem of variable geometry turbines considering the effects of cooling air, this study adopted a BP neural network to further establish a surrogate model for variable geometry turbine performance. A sensitivity analysis of a single-stage turbine was conducted. The variable geometry cooling performance of a single-stage turbine and an E³ five-stage low-pressure air turbine were calculated, and the corresponding surrogate models were established. The relative errors between the calculated mass flow rate and efficiency of the single-stage turbine and the experimental values were no more than 0.70% and 4.44%, respectively; for the five-stage air turbine, the maximum relative errors in mass flow rate and efficiency were no more than 1.67% and 1.385%, respectively. When the throat area of the single-stage turbine nozzle changed by ±30%, the maximum relative errors between the calculated mass flow rate and efficiency and their experimental values were 3.602% and 4.228%, respectively; thus, the determination coefficients of the constructed BP neural network model for the training samples were all greater than 0.999, indicating that the surrogate model has high prediction accuracy and strong generalization ability and can quickly predict variable geometry turbine cooling performance. Full article

The bypass dual-throat nozzle is based on the dual-throat nozzle, which is a fluidic thrust vector nozzle suitable for integration into rocket motors in a symmetrical manner. As the effects of gas–solid two-phase flows are essential for solid rocket motors (SRMs), this study employs the RNG k–ε turbulence model and a particle trajectory model to numerically simulate the three-dimensional flow field inside a fixed-geometry axisymmetric bypass dual-throat nozzle to investigate its two-phase flow characteristics and thrust vectoring performance. Numerical results reveal that the smaller-diameter particles exhibit better flow-following characteristics and have a more significant impact on nozzle performance. As particle size increases, particle trajectories gradually rise within the cavity and converge toward the nozzle axis until a critical value is exceeded, after which the distribution tends to disperse. Particle deposition occurs at the bends of the bypass channel, the upstream converging section of the nozzle, and the converging section of the cavity, underscoring the need for a reinforced geometric design and thermal protection. In addition, the introduction of the particle phase into the flow reduces the thrust-vectoring angle of the nozzle and results in a loss of thrust coefficient. This research has the potential to guide the design of engines according to the incorporation of metal powder in propellants and combustion control. Full article

For decades, studies have been conducted on the efficiency of gas purification processes with wet scrubbers, including the Venturi scrubbers, and this is the most commonly addressed issue in the field literature. The Venturi scrubber consists of a Venturi nozzle and a cyclone. The article addresses the empirical and analytical studies on the annular–mist flow regime that exists in the throat of the Venturi nozzle with a square cross-section. The uniform distribution of droplets over the cross-section area of the Venturi’s throat strongly correlates with the efficiency of the gas cleaning process using Venturi scrubbers. Due to the above, studies on the physics of the phenomena that affect the quantity of small droplets present in the core of the flow are highly justified. The influence of body forces and diffusive mechanisms impacting the number of droplets in the core flow were investigated to tackle the problem in question. Consequently, the fractions of droplets susceptible to turbulent or inertial–turbulent diffusion mechanisms can now be predicted using the outcomes of the research carried out. The droplets were divided into three fractions that differed by their sizes as follows: airborne droplets I confirm thar italic can be removed in all cases. $(d_d\le$ 10 µm), medium-sized droplets $(d_d\le$ 20 µm), and largest droplets $(d_d$ = (50–150) µm). The estimation of diffusion coefficients $\left({\epsilon }_{d,M},{\epsilon }_{d,ref}\right)$ and stopping distances $\left(s_M,s_{ref}\right)$ of all fractions of droplets was carried out with the inclusion $\left({\epsilon }_{d,M},s_M\right)$ and exclusion $\left({\epsilon }_{d,ref},s_{ref}\right)$ of the Magnus lift force $\left(M\right)$ in equations of both the droplet’s stopping distance and its diffusion coefficient. The outcomes revealed that the inclusion of the M force translates significantly to the growth in values of ${\epsilon }_{d,M},s_M$ compared to ${\epsilon }_{d,ref},s_{ref}$. Hence, it was concluded that the M force impacts the increase in the speed of the diffusion of the droplets with $d_d\ge$ 16.45 µm, which is favorable. Hence, the inertial–turbulent diffusion of larger droplets and the turbulent diffusion of medium ones seem to be supported by the M force. The local velocity gradient, which varied within the region of the flow’s hydraulic stabilization also impacted the mass content of droplets with diameter $d_d\le$ 10 µm in the core of the flow. As the flow development progressed, the number of droplets measured at n = 5 Hz varied nonlinearly up to the point where the boundary layer thickness reached the channel radius. The quantity of small droplets in the main flow was significantly influenced by turbulence intensity $\left(Tu\right)$. The desired high number of small droplets in the core of the flow (mist flow) was estimated empirically, and it was achieved when gas flows at high speed and has a mean value of Tu. The former benefits the efficiency of gas purification. Investigations on the effects of body forces of inertia of the continuous phase on the separation of droplets with diameters of a few microns and sub-microns from the flow were performed by employing two channel elbows, namely $e_4$ and $e_1$. The curved channels were subsequently mounted at the end of the straight channel ($SC{h}_2$). The curvature angle ($\alpha$) of the $e_4$ and $e_1$ equaled 90 °C and 30 °C, respectively. The number of droplets existing in the mist flow was higher in value, as desired, when the $e_4$ was used, unlike $e_1$. Two-dimensional flow fields of the mist have been obtained using the Particle Imaging Velocimetry (PIV) technique and analyzed further. Topas LAP 332 Aerosol Spectrometer was used for the determination of droplet ($d_d\le$ 40 µm) size distribution (DSD) and particle concentrations, while the Droplet Size Analyzer D Kamika Instruments (DSA) was exploited to ascertain DSD of droplets with diameter $d_d>40$ µm. Full article

This study serves as a research endeavor aiming to explore the behavior of the coupling flow effects of the single expansion ramp nozzle (SERN) in over-expansion conditions during the static start-up process. The open-source program OpenFOAM and its solver “rhoCentralFoam” are employed in the 2D simulation and the two critical geometric variations, the shape of the ramp and the length of the flap beyond the throat, are considered in the geometric variation. The result shows the preferable propulsion performance in the FSS (Free Shockwave Separation) state compared to RSS (Restricted Shockwave Separation). FSS also plays the role of the initial, albeit transient, separation, which originates from the shockwave from the throat and will eventually transform into a stabler RSS state. For the 100% flap length configuration in this study, the axial thrust can achieve a high value of 500 N/m in the FSS state and decrease to around 450 N/m, on average, in the RSS state. The trust angle also shows a preferable performance of around −13° in FSS compared to −30° in RSS. Regarding geometric modifications, both modifications, shorting the flap and bell-shaped ramp adjustments, manifest similar effects. Both conical and bell-shaped short flap configurations demonstrate an axial thrust from around 1750 to 1900 N/m and a thrust angle of around −45°. However, the flap shortening, which may demonstrate an attitude compensation effect, exhibits a more pronounced effect compared to the bell-shaped modification. Full article

This article proposes a heating method based on heat pump technology to address the large amount of low-grade waste heat generated by a certain type of ultra-high voltage direct current (UHVDC) converter valve. Thermal performance calculations for two systems, a basic vapor compression heat pump system (BVCHPS) based on thermal expansion valve throttling and an ejector-enhanced heat pump system (EEHPS) are analyzed. The research results show that the EEHPS exhibits superior COP and exergy efficiency when generating hot water above 80 °C using a heat source below 50 °C. Additionally, mathematical modeling analysis identifies optimal structural parameters such as nozzle throat diameter, throat area ratio, and nozzle outlet diameter for the ejector in its design state. The low-temperature waste heat recovered from the UHVDC converter valves can be further used in engineering applications such as heating, refrigeration, seawater desalination, and sewage treatment. Full article

Fluid thrust vectoring (FTV) control has obvious advantages in structural quality and stealth performance because of its fast response and light weight. However, improving FTV vector performance will cause a loss in engine performance due to the need to draw airflow from the engine. In order to alleviate the above problems and further improve the vector performance of FTV, a nozzle combined with throat skewing and shock vector control is proposed, and the secondary flow of the nozzle comes from the throat and is injected into the nozzle divergence section. The numerical results indicate that compared with the original configuration, the vector angle and vector efficiency of the new configuration are more linear with the nozzle pressure ratio (NPR), and the vector angle and vector efficiency are improved by 163% and 218%, respectively, while experiencing a maximum reduction in the thrust coefficient of 1.4%. Compared with the only bypass-type shock vector nozzle, the new configuration utilizes the diversion of the two jets to eliminate the reattachment of the separation bubble after the jet and its resulting abrupt change in vector performance, improving the performance while having good control characteristics. Additionally, a sensitivity analysis of the spacing between two jets is also carried out. The spacing between two jets should be increased to make the flow pass through two weaker shock waves to improve the vector performance while ensuring that the separation after the jet is no longer attached. Full article

This paper aims to study the influence of the structure of spray holes and throats on the flow field and the internal trajectory of the gas–steam ejection device. The compressible Navier–Stokes equations, discrete ordinate methods and RNG k-ε turbulence model are utilized to simulate the two-phase flow of the rocket gas with multispecies and the water sprays. The comparison between numerical results and experimental data confirms the accuracy and effectiveness of this model. The simulation analysis on the cases of the ejection process with multiple spray hole diameters, number of spray holes, total spray area, and throat diameter are conducted. The shock wave structure inside the gas–steam ejection device is examined. The simulation results show that, instead of the spray hole diameter and number, the total spray area and secondary nozzle throat diameter are the key factors that affect the flow field and internal trajectory of the gas–steam ejection device. Under the existing spray structure, the maximum number of spray holes is 300 to achieve the stability of the flow field and internal ballistic trajectory of gas–steam ejection devices. By comparing the throat diameters of multiple secondary nozzles, it was found that the minimum throat diameter of the secondary nozzles should be no less than 100 mm. The results could be valuable for the design of gas–steam ejection devices. Full article

Flashing flows of initially sub-cooled water in a converging–diverging nozzle is investigated numerically in the framework of the two-fluid model (TFM). The thermal non-equilibrium effect of phase change is considered by an interfacial heat transfer model, while the pressure jump across the interface is ignored. The bubble size distribution induced by nucleation, bubble growth/shrinkage, coalescence, and breakup is described based on the interfacial area transport equation (IATE) and constant bubble number density model (CBND), respectively. The results are compared with the experimental data. Satisfactory prediction of the axial pressure distribution along the nozzle as well as the flashing inception, is achieved by the TFM-IATE coupling method. It was also found that the vapor production in the diverging section was overpredicted, and the radial gas volume fraction distribution deviated from the experiment. The radial diameter profiles exhibit opposite patterns at the nozzle throat and near the outlet, and similar trends can be observed for the superheated degree. A poly-disperse method is suggested to be introduced to describe the evolution of interfacial area concentration. Full article
