Circular deep excavations, characterized by their symmetrical geometry, are commonly employed in constructing foundations for large-span suspension bridges and as launching shafts for shield tunneling. However, the mechanical behavior of such excavations under asymmetric surface surcharge remains inadequately understood due to a paucity of relevant investigations. This study addresses this knowledge gap by establishing a three-dimensional finite element model (3D-FEA) based on the anchor deep excavation project of a specific bridge. The model is utilized to investigate the influence of asymmetric surcharge on the forces and deformations within the supporting structure. The results show that both the internal force and displacement cloud diagrams of the support structure exhibit asymmetric characteristics. The distribution of displacement and internal forces has spatial effects, and the maximum values all occur in the areas where asymmetric loads are applied. The maximum values of the displacement, axial force, and shear force of underground continuous walls increase with the increase in the excavation depth. The total displacement curves all show the feature of a “bulging belly”. The maximum displacement is 13.3 mm. The axial force is mainly compression, with a maximum value of −9514 kN/m. The maximum positive and negative values of the shear force are 333 kN/m and −705 kN/m, respectively. The bending moment diagram of different monitoring points shows the characteristics of “bow knot”. The maximum values of the positive bending moment and negative bending moment are 1509.4 kN·m/m and −2394.3 kN·m/m, respectively. The axial force of the ring beam is mainly compression, with a maximum value of −5360 kN, which occurs in ring beams 3, 4, and 5. The displacement cloud diagram of the support structure under symmetrical loads shows symmetrical characteristics. Under different load conditions, the displacement curve of the diaphragm wall shows the characteristics of “bulge belly”. The forms of loads with displacements from largest to smallest at the same position are as follows: asymmetric loads, symmetrical loads, and no loads. These findings provide valuable insights for optimizing the structural design of similar deep excavation projects and contribute to promoting sustainable urban underground development. Full article

In order to study the influence of the difference between the center of mass and shear center position of the main girder cross-section on the coupled vibration response of a vehicle–bridge, and in accordance with the theory of finite element analysis, we derive the stiffness matrix of the spatial girder unit with the main girder cross-section mass–shear center heterocentricity, use finite element software to establish a bridge model, select a three-axle heavy vehicle, and solve the coupled vibration equation of the vehicle–bridge by the separation method. A large-span self-anchored suspension bridge is taken as the research object, and a self-programming program is used to calculate and analyze the influence of the main girder cross-section mass–shear center heterocentricity, driving lanes, and speed on the coupled vibration response of the vehicle–bridge. The results show the following: the main girder cross-section mass–shear center heterocentricity has a significant effect on the transverse dynamic response of the bridge, and the peak values of transverse displacement and acceleration in the main span are increased by about 87% and 136%; the outward shift of lanes has a greater effect on the transverse dynamic response of the bridge; and the vibration response of the bridge while considering mass–shear center heterocentricity is more affected under different vehicle speeds. Full article

Precise finite element modeling is critically important for the construction and maintenance of long-span suspension bridges. During the process of modeling, shape-finding and model calibration directly impact the accuracy and reliability. Scholars have provided numerous alternative proposals for the shape-finding of main cables in suspension bridges from both theoretical and finite element analysis perspectives. However, it is difficult to apply these solutions to suspension bridges with special components. Seeking a viable solution for such suspension bridges holds practical significance. The Nanjing Qixiashan Yangtze River Bridge is the first three-span suspension bridge in China. To maintain the configuration of the main cable, the suspension bridge is equipped with specialized suspenders near the anchors, referred to as displacement-limiting suspenders. It is the first suspension bridge in China to use displacement-limiting suspenders and their anchorage system. Taking the suspension bridge as a research background, this paper introduces a refined finite element modeling approach considering the effect of geometric nonlinearity. Firstly, based on the loop adjustment and temperature correction, the shape-finding and force assessment of the main cables are carried out. On this basis, a nonlinear finite element model of the bridge was established and calibrated, taking into account factors such as pylon settlement and cable saddle precession. Finally, the static and dynamic characteristics of the suspension bridge were thoroughly investigated. This study aims to provide a reference for the design, construction and operation of the three-span continuous suspension bridge. Full article

The reasonable expression of live load and its accuracy are important to the safety and design rationality of highway bridge structures. In this study, the optimization issue of the traffic load model for the suspenders of large-scale suspension bridges is studied. Taking a 2300-m main span suspension bridge as an example, a method for suspender classification based on the geometric feature of the influence lines is proposed, and the extreme traffic load effect scenarios are analyzed and used as an optimization reference. Multi-objective optimization based on a genetic algorithm is used to explore the improvement of the traffic load model of the suspender. The traffic load model of the suspender is optimized with three objectives, i.e., accuracy, convenience, and improvement, and the optimization results regarding the load value and loading length are obtained. The value of the uniformly distributed load of the optimized model ranges from 6.4 kN/m to 8.9 kN/m, and the maximum value of the concentrated force could reach 1433 kN. By comparing the obtained optimized model with the current specification model and the extreme load effect scenario model, the improved applicability of the optimized model in the analysis of the load effect of the suspender can be verified. The optimized method and relevant conclusions can provide useful references for the improved design and operation management of similar bridge structures. Full article

Long-span bridges are susceptible to damage, aging, and deformation in harsh environments for a long time. Therefore, structural health monitoring (SHM) systems need to be used for reasonable monitoring and maintenance. Among various indicators, bridge displacement is a crucial parameter reflecting the bridge’s health condition. Due to the simultaneous bearing of multiple environmental loads on suspension bridges, determining the impact of different loads on displacement is beneficial for the better understanding of the health conditions of the bridges. Considering the fact that extreme gradient boosting (XGBoost) has higher prediction performance and robustness, the authors of this paper have developed a data-driven approach based on the XGBoost model to quantify the impact between different environmental loads and the displacement of a suspension bridge. Simultaneously, this study combined wavelet threshold (WT) denoising and the variational mode decomposition (VMD) method to conduct a modal decomposition of three-dimensional (3D) displacement, further investigating the interrelationships between different loads and bridge displacements. This model links wind speed, temperature, air pressure, and humidity with the 3D displacement response of the span using the bridge monitoring data provided by the GNSS and Earth Observation for Structural Health Monitoring (GeoSHM) system of the Forth Road Bridge (FRB) in the United Kingdom (UK), thus eliminating the temperature time-lag effect on displacement data. The effects of the different loads on the displacement are quantified individually with partial dependence plots (PDPs). Employing testing, it was found that the XGBoost model has a high predictive effect on the target variable of displacement. The analysis of quantification and correlation reveals that lateral displacement is primarily affected by same-direction wind, showing a clear positive correlation, and vertical displacement is mainly influenced by temperature and exhibits a negative correlation. Longitudinal displacement is jointly influenced by various environmental loads, showing a positive correlation with atmospheric pressure, temperature, and vertical wind and a negative correlation with longitudinal wind, lateral wind, and humidity. The results can guide bridge structural health monitoring in extreme weather to avoid accidents. Full article

Structural displacement monitoring is one of the major tasks of structural health monitoring and it is a significant challenge for research and engineering practices relating to large-scale civil structures. While computer vision-based structural monitoring has gained traction, current practices largely focus on laboratory experiments, small-scale structures, or close-range applications. This paper demonstrates its applications on three landmark long-span suspension bridges in Turkey: the First Bosphorus Bridge, the Second Bosphorus Bridge, and the Osman Gazi Bridge, among the longest landmark bridges in the world, with main spans of 1074 m, 1090 m, and 1550 m, respectively. The presented studies achieved non-contact displacement monitoring from a distance of 600 m, 755 m, and 1350 m for the respective bridges. The presented concepts, analysis, and results provide an overview of long-span bridge monitoring using computer vision-based monitoring. The results are assessed with conventional monitoring approaches and finite element analysis based on observed traffic conditions. Both displacements and dynamic frequencies align well with these conventional techniques and finite element analyses. This study also highlights the challenges of computer vision-based structural monitoring of long-span bridges and presents considerations such as the encountered adverse environmental factors, target and algorithm selection, and potential directions of future studies. Full article

A low stiffness makes long-span suspension bridges sensitive to loads, and this sensitivity is particularly significant for wind-induced nonlinear vibrations. In the present paper, nonlinear vibrations of suspension bridges under the combined effects of static and vortex-induced loads are explored using the nonlinear partial differential–integral equation that models the plane bending motion of suspension bridges. First, we discretized the differential–integral equation through the Galerkin method to obtain the nonlinear ordinary differential equation that describes the vortex-induced vibrations of the bridges at the first-order symmetric bending mode. Then, the approximate analytical solution of the ordinary differential equation was obtained using the multiple scales method. Finally, the analytical solution was applied to reveal the relationships between the vibration amplitude and other parameters, such as the static wind load, the frequency of dynamic load, structural stiffness, and damping. The results show that the static wind load slightly impacts the bridge’s vibrations if its influence on the natural frequency of bridges is ignored. However, the bridge’s vibrations are sensitive to the load frequency, structural stiffness, and damping. The vibration amplitude, as a result, may dramatically increase if the three parameters decrease. Full article

The frequently conventional assumption that bridge temperature is uniformly distributed on long-span bridges could lead to uncertainty when analyzing temperature effects. This study investigated the surface temperature of steel box girders on a long-span suspension bridge, emphasizing the distribution characteristics in the longitudinal (spanwise) direction. The girder surface temperature distribution was monitored using the long-term structural health monitoring system (SHMS). First, the probability density functions (PDF) of the girder surface temperature were analyzed. The results showed that the PDFs had bimodal characteristics and could be well-fitted using the weighted superposition of two normal distributions. Meanwhile, there was an obvious difference between the PDFs of the measuring points at different longitudinal sections of the bridge, which is inconsistent with the assumption that the temperature was uniformly distributed in the longitudinal direction. Subsequently, the longitudinal distributions of the girder surface temperature were statistically analyzed, and polynomial functions were introduced to fit the distribution curves along the left and right sides of the mid-span. A correlation analysis was then performed, highlighting the variability in temperature in the longitudinal direction. Additionally, the longitudinal temperature distribution pattern could be summarized as (i) the highest in the mid-span, the lowest in the tower, and increasing along the side span; (ii) there were also significant differences between the left and right sides of the mid-span. Finally, the time- and space- distributions of the temperature were studied, and a contour map was displayed. The results showed that the girder surface temperature had significant three-dimensional spatial characteristics and was not only non-uniformly distributed in space but also in time. This work is useful for a more accurate analysis of temperature effects on long-span bridges. Full article

Suspension bridges’ in-plane extended configuration makes them vulnerable to wind-induced vibrations. Vortex shedding is a kind of aerodynamic phenomenon causing a bridge to vibrate in vertical and torsional modes. Vortex-induced vibrations disturb the bridge’s serviceability limit, which is not favorable, and in the long run, they can cause fatigue damage. In this condition, vibration control strategies seem to be essential. In this paper, the performance of a tuned mass damper (TMD) is investigated under the torsional vortex phenomenon for an ultra-span streamlined twin-box girder suspension bridge. In this regard, the sensitivity of TMD parameters was addressed according to the torsional responses of the suspension bridge, and the reached appropriate ranges are compared with the outputs provided by genetic algorithm. The results indicated that the installation of three TMDs could control all the vulnerable modes and reduce the torsional rotation by up to 34%. Full article

Historically, monitoring possible deformations in suspension bridges has been a crucial issue for structural engineers. Therefore, to understand and calibrate models of the “load-structure-response”, it is essential to implement suspension bridge monitoring programs. In this work, due to increasing GNSS technology development, we study the movement of a long-span bridge structure using differenced carrier phases in adjacent epochs. Many measurement errors can be decreased by a single difference between consecutive epochs, especially from receivers operating at 10 Hz. Another advantage is not requiring two receivers to observe simultaneously. In assessing the results obtained, to avoid unexpected large errors, the outlier and cycle-slip exclusion are indispensable. The final goal of this paper is to obtain the relative positioning and associated standard deviations of a stand-alone geodetic receiver. Short-term movements generated by traffic, tidal current, wind, or earthquakes must be recoverable deformations, as evidenced by the vertical displacement graphs obtained through this approach. For comparison studies, three geodetic receivers were positioned on the Assut de l’Or Bridge in València, Spain. The associated standard deviation for the north, east, and vertical positioning values was approximately 0.01 m. Full article

The main cable shape control confronts new challenges when a suspension bridge’s span exceeds two kilometers. As a suspension bridge’s primary load-bearing component, it is difficult to alter the alignment once the erection is completed. Hence, the accurate calculation and control of the main cable shape has significant scientific research value from various aspects. This paper systematically reviews the research progress of the suspension bridge’s main cable shape control technology. The current research progress is introduced from three aspects of main cable shape-finding, construction control technology, and control analysis, and both the current shortcomings and future research directions are summarized. This review paper is expected to be a solid reference for investigators and experts in this crucial field of structural engineering. Full article

Determining a reasonable main cable curve is the foundation of suspension bridge design, and the accuracy and efficiency of the curve-finding problem are key to the design of a suspension bridge. To accurately obtain the completed curve of a main cable, force equations, which are nonlinear equations, need to be solved. In this study, the improved particle swarm optimization (IPSO) algorithm with inertia weight is presented to solve these nonlinear equations. Then, taking a double-tower three-span steel-box girder suspension bridge as the research background, the accuracy and efficiency of the IPSO method in finding the main cable curve are studied and then compared with those of the N-R iteration method and the finite element method (FEM). The results show that the proposed IPSO method has a high accuracy and a fast computing speed. Furthermore, the convergence under different bridge parameters is discussed, which demonstrates that the IPSO method has a strong adaptability. Full article

The traditional method for calculating the buffeting response of long-span bridges follows the strip assumption, and is carried out by identifying aerodynamic parameters through sectional model force or pressure measurement wind tunnel tests. However, there has been no report on predicting the buffeting response based on the sectional model vibration test. In recent years, the author has proposed a method, based on the integrated transfer function, for predicting the buffeting response of long-span bridges through theoretical and full-bridge tests. This provided an idea for predicting the buffeting response based on the sectional model vibration test. Unfortunately, the effectiveness and accuracy of this method have not been proven or demonstrated through effective tests. To solve this problem, a long-span suspension bridge was taken as a background. Parameters such as aerodynamic admittance were identified through a sectional model force measurement test and the integrated transfer functions were identified through a sectional model vibration test. A taut strip model test was also conducted. Furthermore, the buffeting response prediction results based on three kinds of wind tunnel test techniques were compared. The results showed that if the strip assumption was established, the results of the three methods aligned well, and that selecting a reasonable model aspect ratio for the test could effectively reduce the influence of the 3D effect; moreover, identifying the integrated transfer function by the sectional model vibration test could effectively predict the long-span bridge buffeting response. Furthermore, when the strip assumption failed, the results of the traditional calculation method using 3D aerodynamic admittance became smaller. A larger result would be obtained by neglecting the influence of aerodynamic admittance. Full article

In order to ensure driving safety and comfort, it is necessary to figure out the complex interaction between continuous welded rail (CWR) and suspension bridges for high-speed railway. A spatial finite element model for a 1092 m main span suspension bridge was established based on the bridge-track interaction theory. A specific correction method was put forward to keep the rail in a zero-stress state when just laid. Three rail expansion joint (REJ) layout schemes were proposed according to practical engineering experience. Both static and dynamic analysis methods were used to evaluate the feasibility of these schemes. The results show that the REJ should be laid at the position with a distance away from the primary beam end, and the beam with more substantial integral stiffness should be preferentially selected. For the recommended scheme, the REJ expansion reaches more than 380 mm under expansion load. The factors affecting the REJ expansion from major to minor are temperature, earthquake, rail fracture, braking, and bending load. The superposition effect of the above factors is suggested to be considered in the selection of REJ range. Full article

The determination of the final cable shape under the self-weight of the suspension bridge enables its safe construction and operation. Most existing studies solve the cable shape segment-by-segment in the Lagrangian coordinate system. This paper develops a novel shape finding method for the main cable of suspension bridge using nonlinear finite element approach with Eulerian description. The governing differential equations for a three-dimensional spatial main cable is developed before a one-dimensional linear shape function is introduced to solve the cable shape utilizing the Newton iteration method. The proposed method can be readily reduced to solve the two-dimensional parallel cable shape. Two iteration layers are required for the proposed method. The shape finding process has no need for the information of the cable material or cross section using the present technique. The commonly used segmental catenary method is compared with the present method using three cases study, i.e., a 1666-m-main-span earth-anchored suspension bridge with 2D parallel and 3D spatial main cables as well as a 300-m-main-span self-anchored suspension bridge with 3D spatial main cables. Numerical studies and iteration results show that the proposed shape finding technique is sufficiently accurate and operationally convenient to achieve the target configuration of the main cable. Full article
