This paper presents an experimental study on the cyclic performance of large-scale composite plate shear walls–concrete encased (C-PSW/CE). Three C-PSW/CE specimens with concrete panels of different thicknesses were tested under cyclic loading. Their failure mode, lateral load–drift ratio relationship, strength and stiffness deterioration, and hysteretic energy dissipation were systematically analyzed. Initial concrete cracking occurred at a drift ratio of approximately 0.24%, while the three specimens reached their load-bearing capacities at a drift ratio of 1.34%. The results demonstrated that concrete panel thickness significantly influences the buckling behavior of the steel web plate. Thicker concrete panels provide enhanced out-of-plane restraint stiffness, delaying steel plate buckling and shifting the failure mode from overall to local buckling. Furthermore, an increased concrete thickness improves both the load-bearing and hysteretic energy dissipation capacities of the walls. These findings offer valuable insights for the design and application of C-PSW/CE in seismic-resistant structures. Full article

Standard materials for middle clavicle implants are limited to Titanium and Stainless Steel; their high Young’s Modulus promotes stress shielding, which causes complications such as malunion or implant failure. This study investigates alternative materials, Cobalt Chromium, Polyether ether ketone (PEEK), Magnesium, and Polylactic Acid (PLA), along with the standard materials, to understand their stress distributions, assess the likelihood of stress shielding, and evaluate their viability through the use of ANSYS 2025 R1 Finite Element Analysis (FEA). The materials are tested with four plate variations: Superior Plate, Anteroinferior Plate, Thin Dual Plate, and Thick Dual Plate, subjected to a simultaneous load of 100 N compressive, 100 N bending, and 1 Nm torsional, and were compared according to their maximum von Mises Stresses in plate, bone, and fracture line. High Young’s Modulus materials (Titanium, Stainless Steel, and Cobalt Chromium) had maximum von Mises plate stresses ranging from 200 to 265 MPa. In contrast, lower Young’s Modulus materials (Magnesium, PEEK, and PLA) showed maximum von Mises stresses of only around 115 to 170 MPa. PLA showed insufficient material strength, with bone stresses being around 30 MPa greater than plate stresses. PEEK showed viability but failed in material strength for the superior plate variation, as its maximum von Mises Stress of 168.13 MPa exceeded the yield strength of 125 MPa. Magnesium showed the best results, with bone and plate stresses near each other, and passed all viability criteria, demonstrating good material strength and a low risk of stress shielding. The results reinforce the use of Titanium and Stainless Steel as standards, show the viability of Cobalt Chromium for patients needing increased stability but with risks of stress shielding, demonstrate Magnesium for bioabsorbability and low stress shielding risk, suggest PEEK for low load applications, and reveal that PLA has insufficient strength. The study provides a comprehensive comparison of different materials with various variations, which provides a foundation for future studies to analyze material behavior. Full article

Special-shaped concrete-filled steel tube (CFST) columns are increasingly adopted as efficient vertical load-carrying members in integrated residential structural systems. However, their intrinsically nonuniform confinement promotes early local buckling and bulging of tube plates and limits deformation stability under axial compression. This study presents an experimental assessment of an L-shaped CFST column enhanced by a fully bolted threaded-rod transverse tie (RT) system, which is intended to strengthen confinement delivery and delay tube instability. Two 1500 mm-high specimens with identical cross-sectional dimensions (400 mm × 200 mm legs; 6 mm wall thickness) were fabricated using Q235 steel and C30 concrete: one conventional baseline (L1) and one RT-improved column (L2) with pre-drilled bolt holes at 150 mm spacing and installed threaded rods (10 mm nominal diameter) to provide a distributed transverse restraint. Monotonic axial compression tests were conducted under staged load control while recording the axial shortening, mid-height lateral deflection, and longitudinal and transverse steel strains. The RT detailing postponed the onset of visible local buckling, tightened the lateral deflection envelope, and increased the measured peak axial resistance from 4354 kN (L1) to 5354 kN (L2), corresponding to an increase of approximately 23%. The combined deformation and strain evidence indicates that the RT system improves the confinement effectiveness by stabilizing the tube dilation and promoting a more controlled instability evolution. Overall, the fully bolted RT approach offers a practical and fabrication-compatible pathway for enhancing the axial strength and deformation performance of L-shaped CFST columns. Full article

We report on the non-contact characterization of various plate materials (including aluminum and steel) using a high-pressure, micrometer-scale air jet as a broadband ultrasound source and an optomechanical microphone as a receiver. Through-plate transmission spectra are dominated by zero-group-velocity (ZGV) Lamb modes. We attribute this to the ‘point-like’ nature of both the source and receiver, since ZGV modes are spatially localized and comprise a range of non-normal wave numbers. As is well known, the properties of the ZGV modes, including their frequency and amplitude, are sensitive to thickness variations or the presence of defects. The continuous nature and high acoustic power of the gas jet source enabled us to perform uninterrupted scanning of non-uniform steel plates. Given the ubiquitous and low-cost nature of compressed air systems, our approach might be of interest for the rapid inspection of industrial parts. Full article

In the production of clad rolled plates from asymmetric sandwich-type slab for pipeline applications, achieving both target mechanical properties and high geometric flatness remains a critical challenge due to differential thermal stresses between the dissimilar steel layers during accelerated cooling. This study aims to develop an optimal cooling schedule for a 25 mm thick clad plate, comprising a X70-grade steel base layer and an AISI 316L cladding, to ensure required strength and minimal bending. A comprehensive approach was employed, integrating a 3D finite element model (Ansys) for simulating thermoelastic stresses with a CatBoost machine learning model trained on industrial data to predict heat transfer coefficients accurately. A parametric analysis of cooling strategies was conducted. Results showed that a standard cooling strategy caused unacceptable bending of plate after cooling exceeding 130 mm. An optimized strategy featuring delayed activation of the lower cooling headers (on the cladding side) created a compensating thermoelastic moment, successfully reducing bending to approximately 20 mm while maintaining the base layer’s requisite mechanical properties. The findings validate the efficacy of the combined FEM-machine learning methodology and propose a viable, industrially implementable cooling strategy for high-quality clad plate production. Full article

This study investigated a 460 MPa marine engineering steel’s microstructure and low-cycle fatigue (LCF) behavior along the thickness direction. The results showed that the low-cycle fatigue life was reduced from 9681, 4395, 2107, 1020, 829 to 7222, 1832, 1015, 630, 242 with the specimen taken from the surface to the middle of steel plate, increasing grain size and decreasing the content of high-angle grain boundaries (HAGBs). All specimens showed notable cyclic hardening and softening. This was related to the dislocation movement, interaction, accumulation, annihilation, and dynamic recovery during fatigue tests. Furthermore, the crack propagation paths in the fatigue specimens were also observed and discussed. Finally, the Basquin and Coffin–Manson relationships were used to suggest a prediction model for the LCF life at strain amplitudes ranging from 0.4% to 1.2%, and the anticipated outcomes agreed well with the test results. Full article

The size of offshore wind turbine towers is increasing, and they are subjected to larger and more complex loads, which imposes more stringent requirements on the fatigue performance of welded plates in new offshore wind turbine towers. This study investigated the axial fatigue performance of 25 mm thick welded plates made of the new Q420 steel grade. Fractures in the Q420 welded plates occurred at the junction of the coarse-grained zone of the filler metal and the heat-affected zone. By analyzing the fatigue striation spacing across multiple regions, it was found that the proportion of cycles in the crack propagation stage within the total fatigue life did not exceed 11%, indicating that the crack initiation stage is the decisive factor in the fatigue life of the specimens. Removing surface quality defects at the weld toe significantly increased both the fatigue life and the fatigue strength limit of the Q420 welded plates. Full article

To reduce manual operation and enhance the intelligence of the high-altitude maintenance wall-climbing robot during its operation, path planning and autonomous navigation need to be implemented. Due to non-uniform magnetic adhesion between the wall-climbing robot and the steel plate, often caused by variations in steel thickness or surface pitting, the wall-climbing robot may experience motion deviations and deviate from its planned trajectory. In order to obtain the actual deviation from the expected trajectory, it is necessary to accurately locate the wall-climbing robot. This allows for the generation of precise control signals, enabling trajectory correction and ensuring high-precision autonomous navigation. Therefore, this paper proposes an external visual localization system based on a pan–tilt laser tracker unit. The system utilizes a zoom camera to track an AprilTag marker and drives the pan–tilt platform, while a laser rangefinder provides high-accuracy distance measurement. The robot’s three-dimensional (3D) pose is ultimately calculated by fusing the visual and ranging data. However, due to the limited tracking speed of the pan–tilt mechanism relative to the robot’s movement, we introduce an Extended Kalman Filter (EKF) to robustly predict the robot’s true spatial coordinates. The robot’s three-dimensional coordinates are periodically compared with the predefined route coordinates to calculate the deviation. This comparison generates closed-loop control signals for the robot’s movement direction and speed. Finally, based on the LoRa communication protocol, closed-loop control of the robot’s movement direction and speed are achieved through the upper-level computer, ensuring that the robot returns to the predefined track. Extensive comparative experiments demonstrate that the localization system achieves stable localization with an accuracy better than 0.025 m on a 6 m × 2.5 m steel structure surface. Based on this high-precision positioning and motion correction, the robot’s motion deviation is kept within 0.1 m, providing a reliable pose reference for precise motion control and high-reliability operation in complex structural environments. Full article

The self-riveting friction stir lap welding (SRFSLW) method was utilized to improve the bonding strength of lap welding joints with medium-thick aluminum/steel plates and to realize structural lightweighting. The effect of plunge depth on the shear force and the microstructure of the joint was studied, and the influence of groove structure (rectangular groove and dovetail groove) on the failure behavior of the joint under shear load was obtained, simultaneously. The EBSD results indicate that the aluminum alloy grains in the stir zone (SZ) of groove joints have been refined compared to the non-groove joint. Meanwhile, due to the presence of grooves, the proportion of high-angle grain boundaries of the SZ is increased, and more dynamic recrystallization has emerged; thus, the KAM value of the SZ is reduced to a certain extent. The non-groove joint exhibits {111}//ND fiber texture, while the groove joint shows F-plate texture. In self-riveting joints, due to the increased metallurgical bonding area and the weakened effect of external loads, the failure of metallurgical bonding in the joint requires higher external load, and the separation of the self-riveted structure from the groove requires greater bending moment, thereby improving the strength of the joint. Full article

Special-shaped, concrete-filled steel tubes (SCFSTs) enhance the space efficiency of residential structures and improve aesthetics by avoiding exposed columns. However, the flat steel-plate connection sections are susceptible to local buckling. To mitigate this, corrugated steel plates are incorporated to enhance the local buckling resistance of the structure. This study examines the axial-compression performance and damage characteristics of SCFSTs connected by double-corrugated steel plates (DCP-SCFST) through full-scale static-loading tests. A finite element analysis explores the impact of column height, corrugated plate thickness, material strength, and connection length on the load-carrying capacity of DCP-SCFSTs. The study also presents the sectional strength and design method for these structures. The results indicate that the DCP-SCFSTs exhibit high bearing capacity and ductility under axial compression. The corrugated plates effectively restrain the concrete, markedly improving the buckling behavior of the connection section. Moreover, the corrugation wave size does not significantly affect the bearing capacity, whereas increasing the corrugated plate’s thickness enhances both the bearing capacity and ductility. This is attributed to the indirect confinement effect of corrugated plates. Additionally, the paper proposes design methods for sectional strength and overall stability, offering accurate formulas that offer valuable reference for the design of concrete-filled, corrugated plate members. Full article

Reinforced concrete (RC) beams strengthened with carbon-fabric-reinforced cementitious matrix (CFRCM) systems have shown potential for restoring flexural performance, yet their effectiveness under different corrosion levels remains insufficiently understood. This study presents a numerical investigation of the flexural behaviour of simply supported RC beams externally strengthened with CFRCM plates. Refined finite element models (FEMs) were developed by explicitly incorporating the steel–concrete bond-slip behaviour, the carbon fabric (CF) mesh–cementitious matrix (CM) interface, and the CFRCM–concrete substrate interaction and were validated against experimental results in terms of failure modes, load–deflection responses, and flexural capacities. A parametric study was then conducted to examine the effects of CFRCM layer number, steel corrosion level, and longitudinal reinforcement ratio. The results indicate that the baseline flexural capacity can be fully restored only when the corrosion level remains below approximately 15%; beyond this threshold, none of the CFRCM configurations achieved full recovery. The influence of the reinforcement ratio was found to depend on corrosion severity, while increasing CFRCM layers enhanced flexural performance but exhibited saturation effects for thicker configurations. In addition, corrosion level and CFRCM thickness jointly influenced the failure mode. Comparisons with design predictions show that bilinear CFRCM constitutive models are conservative, whereas existing FRP-based design codes provide closer agreement with numerical and experimental results. Full article

This study presents an experimental and numerical investigation into the mechanical behavior of corrugated steel–concrete composite bridge decks with composite dowel shear connectors. Four full-scale specimens were fabricated and subjected to flexural tests to obtain and analyze the load–deflection and load–strain curves. A finite element model was developed and validated against the experimental results. The validated model was subsequently applied to analyze the load-carrying process and to perform parametric sensitivity analysis. The effects of the concrete strength grade, steel strength, corrugated steel plate thickness, concrete slab thickness, and corrugated steel plate height on the ultimate bearing capacity were evaluated. The results indicate that corrugated steel–concrete composite bridge decks were subjected to concrete shear failure. The ultimate bearing capacity of the bridge deck reached approximately 3.36 times the design value, demonstrating a high safety reserve. Throughout the entire flexural failure process, the shear connectors performed effectively, with only minimal relative slip observed at the steel–concrete interface. At the instance of failure, only partial areas of the corrugated steel plate yielded. To fully exploit the structural potential, the key design parameters require rational coordination. Full article

Conventional non-intumescent fire-resistive coatings often require excessive thickness and exhibit poor adhesion. To address these limitations, this study developed a novel geopolymer-based aerogel composite (GBAC) coating. The effects of aerogel content, water-to-binder (W/B) ratio, curing age, latex powder, basalt fibers, and an expansive agent on the physical and mechanical properties of GBAC were systematically investigated. The results have indicated that increasing the aerogel content and W/B ratio reduces the dry density, thermal conductivity, and compressive strength. Both basalt fibers and expansive agent significantly inhibit drying shrinkage while enhancing tensile and tensile bonding strength. Although latex powder shows a negligible effect on shrinkage reduction, it effectively improves tensile and bonding strength. The incorporation of 2.5% of latex powder, 1.0% of basalt fibers, and 4.0% of expansive agent results in a remarkable reduction in shrinkage strain by 85.23%, an increase in tensile strength by 90.93%, and an enhancement in tensile bonding strength by 64.89%. GBAC coatings with thicknesses of 20 and 25 mm can extend thermal insulating efficiency of steel plates by 84 and 108 min and make steel beams satisfy the requirements of Classes II and I fire resistance, respectively. Full article

The production of heavy gauge quenched and tempered steel plates requires alloying strategies that ensure adequate hardenability and microstructural uniformity under limited cooling rates. Molybdenum (Mo) and nickel (Ni) are key elements in this context, as they influence both hot-working behavior and phase transformation kinetics. This study investigates the effect of Mo (0.25–0.50 wt%) and Ni (0–1.00 wt%) additions on static recrystallization and transformation behavior using laboratory thermomechanical simulations representative of thick plate rolling conditions. Multipass and double-hit torsion tests were performed to determine the non-recrystallization temperature (Tnr) and quantify softening kinetics, while dilatometry was employed to construct Continuous Cooling Transformation (CCT) diagrams and assess hardenability. Results indicate that Mo significantly increases Tnr and delays recrystallization through a solute drag mechanism, whereas Ni exerts a minor but measurable effect, likely associated with stacking fault energy rather than classical solute drag. Both elements reduce ferrite and bainite transformation temperatures, enhancing hardenability; however, Mo alone cannot suppress ferrite formation at practical cooling rates, requiring combined Mo–Ni additions to achieve fully martensitic microstructures. These findings provide insight into alloy design for thick plate applications and highlight the limitations of existing predictive models for Ni-containing steels. Full article

Research on the configuration and mechanical performance of arch-column-tie beam joints, which combine features of arch-tie beam joints and tubular joints, remains limited, particularly for long-span structures subjected to heavy loads at high building stories. This study focuses on a joint in an engineering structure comprising a circular arch beam, a square-section inclined column, and a tie beam, where both the arch and the inclined column are concrete-filled steel tube (CFST) members. A novel joint configuration was proposed, then a refined finite element model was established. The joint’s mechanical mechanism and failure mode under axial compression in the arch beam were investigated, considering two conditions: the presence of prestressed high-strength rods and the failure of the rods. Subsequently, a parametric study was conducted to investigate the influence of variations in the web thickness of the tie beam, the steel tube wall thickness of the arched beam, the steel tube wall thickness of the supporting inclined column, and the strength grades of steel and concrete on the bearing capacity behavior and failure modes. Numerical simulation results indicate that the joint remains elastic under the design load for both conditions, meeting the design requirements. The joint reaches its ultimate capacity when extensive yielding occurs in the tie beam along the junction region with the circular arch beam, as well as in the steel tube of the arch beam. At this stage, the steel plates and concrete within the joint zone remain elastic, ensuring reliable load transfer. The maximum computed load of the model with prestressed rods was 2.28 times the design load. The absence of prestressed rods could lead to a significant increase in the high-stress area within the web of the tie beam, decreasing the joint’s stiffness by 12.4% at yielding, but have a limited effect on its maximum bearing capacity. Gradually increasing the wall thickness of the arch beam’s steel tube shifts the failure mode from arch-beam-dominated yielding to tie-beam-dominated yielding along the junction region. Increasing the steel strength grade is more efficient in enhancing the bearing capacity than increasing the concrete strength grade. Finally, a design methodology for the joint zone was established based on three aspects: local stress transfer at the bottom of the arch beam, force equilibrium between the arch beam and the tie beam, and the biaxial compression state of the concrete in the joint zone. Furthermore, the construction process and mechanical analysis methods for various construction stages were proposed. Full article
