The displacement of synchronous generators by inverter-based renewable energy sources (RES) has eroded system inertia, weakening frequency stability even as voltage stability improves. This paradox poses a major challenge for modern grids. Battery Energy Storage Systems (BESS) offer synthetic inertia and rapid frequency response, but their stabilising impact depends critically on placement. Using dynamic simulations on the IEEE 9-bus system, this study demonstrates the voltage–frequency paradox across increasing RES penetration. Results show that strategic siting prevents frequency collapse while enhancing voltage recovery, providing a unified mitigation strategy for high-renewable systems. Full article

The increasing penetration of inverter-based renewable energy sources has significantly reduced system inertia, leading to faster frequency deviations in low-inertia power systems. This paper proposes an asynchronous distributed model predictive control (AD-MPC) strategy to coordinate flywheel energy storage systems (FESSs) and battery energy storage systems (BESSs) for enhanced frequency stability in low-inertia power grids. A modified IEEE 39-bus system integrating a 3 MW wind energy conversion system (WECS), a 2 MW PV solar unit, and an electric vehicle (EV) load emulator unit was simulated to evaluate the system performance of the controller under a 30% increase in load disturbance. The results show that the coordinated FESS–BESS operation using the proposed AD-MPC controller achieves faster frequency recovery and reduces frequency deviation by 4% compared to single storage configurations. The proposed approach demonstrates that the high-speed FESS can provide a rapid inertial response, while the BESS delivers primary frequency support, offering a promising solution for maintaining dynamic stability in future renewable-dominated power systems. Full article

Converter-interfaced wind generation reduces the effective inertial response of modern power systems and makes frequency dynamics more sensitive to load variability, measurement processing, and support-control tuning. This paper proposes a data-driven and measurement-aware framework to evaluate frequency support in a low-inertia system with doubly fed induction generator-based wind generation. Measured load and wind-speed data are converted into a reproducible scenario library and evaluated with an aggregated frequency model including droop support, synthetic inertia, reserve limitation, filtering, delay, and rate of change of frequency estimation. Results show that unsupported operation produces the largest frequency degradation, with a median nadir-point deviation of 2.208 Hz, while conventional droop reduces it to 0.714 Hz. Droop plus inertia and the proposed robust setting reduce this value to 0.493 Hz and 0.502 Hz, respectively, indicating comparable performance under the selected measurement- ware assessment, with a median rate of change of frequency close to 0.040 Hz/s. The load-model analysis shows that frequency-dependent load behavior changes the final frequency deviation, reducing it from 0.329 Hz to 0.318 Hz in the tested cases. Full article

Electromagnetic spectrum planning is a critical challenge in modern wireless communication systems, characterized by multiple conflicting objectives including spectrum utilization efficiency, interference minimization, and fairness among users. This paper proposes an Enhanced Discrete Multi-Objective Particle Swarm Optimization (EDMOPSO) algorithm specifically designed for spectrum assignment problems. The proposed method introduces a novel probabilistic discrete velocity update mechanism with adaptive dynamic bounds, an adaptive inertia weight strategy based on normalized population diversity, and an improved archiving technique with enhanced diversity preservation. To handle the discrete nature of spectrum allocation, we develop a binary encoding scheme combined with a problem-specific repair mechanism for constraint satisfaction. The algorithm is evaluated on both synthetic benchmark problems and real-world spectrum planning scenarios. Experimental results demonstrate that EDMOPSO achieves competitive performance advantages over seven established multi-objective evolutionary algorithms, with Hypervolume improvements of 18.7% and Inverted Generational Distance reductions of 23.4% compared to the second-best-performing algorithm. A comprehensive ablation study with 15 configurations validates the synergistic interaction between components. The proposed method provides an effective solution for macro-level periodic spectrum management in complex electromagnetic environments. Full article

The energy transition is rapidly increasing the penetration of inverter-based resources (IBRs), thereby reducing the share of conventional directly grid-connected synchronous generation in modern power systems. In scenarios with very high shares of IBRs, potentially reaching 100% inverter-based operation, key features that have traditionally guaranteed power system stability and security, such as inertia, short circuit strength, fault response, and damping of oscillations, are significantly changing. This review paper examines the main challenges of operating and planning power systems with a high penetration of inverter-based resources. These challenges are grouped into three main areas: (i) technical issues, including frequency and voltage stability, system strength, fault behavior, control interactions and oscillations; (ii) regulatory issues, such as the evolution of grid codes, ride-through requirements, grid-forming specifications and testing, compliance assessment, and model validation; and (iii) market issues, focusing on how non energy services, like synthetic inertia, damping, voltage support, and stability services, are defined, measured, and procured. The paper discusses the compromises between system performance, implementation costs, and overall system robustness, relying on lessons learned from existing specifications and international standards. Finally, it outlines key research needs and provides recommendations for developing coherent technical requirements and market mechanisms to support the reliable operation of inverter-dominated power systems. Full article

The main purpose of electrical transmission and distribution networks is to carry electrical energy from the places where it is produced to the places of consumption, where the energy is used. Electrical energy is produced in power plants by generating units, which convert a form of primary energy into electrical energy. Primary energy comes from a number of sources, such as fossil fuels, nuclear energy, hydropower, wind, and solar. The carbon neutrality targets set by the European Union and several countries around the world have driven a transformation characterized by the gradual replacement of synchronous thermal generation based on fossil fuels with Renewable Energy Sources (RES), such as wind and solar. The energy transition, while necessary to achieve the established targets, introduces significant challenges to the stability of Electrical Power Systems (EPS) and electrical grids, since RES do not yet contribute to stability at levels comparable to the generating units of large thermal power plants, whether in terms of inertia, which has seen a notable reduction in recent years, or in voltage control or short-circuit power. This article presents and discusses solutions to mitigate the effect of this reduction in inertia in power plants using synchronous compensators and synthetic inertia emulation using battery storage. Full article

With the large-scale integration of wind power, modern power systems are facing reduced equivalent inertia, weakened primary frequency regulation capability, and insufficient coordination between wind turbines and energy storage during joint frequency support. To address these issues, this paper investigates a wind–storage hybrid system composed of doubly fed induction generators (DFIG) and supercapacitor energy storage and proposes a coordinated primary frequency regulation strategy combining fuzzy logic control (FLC) and model predictive control (MPC). Considering the variations in rotor kinetic energy reserve and frequency support capability under different wind speed regions, a coordinated regulation mechanism is developed for multiple operating conditions. In addition, a variable-coefficient synthetic inertia control scheme with rotor speed safety constraints is designed to adaptively adjust the turbine regulation coefficients, while an SOC-feedback-based adaptive virtual droop strategy is introduced to improve the sustained support capability of the energy storage unit. On this basis, a multi-objective model predictive control framework is established to optimize the reference power allocation between the wind turbine and the energy storage unit in a rolling manner. The proposed method is characterized by three coordinated features, namely, multi-region wind–storage frequency regulation, rotor-speed-safe adaptive support of the wind turbine and SOC-aware adaptive support of the storage unit, as well as MPC-based rolling power allocation. Simulation results show that the proposed strategy improves the frequency nadir, reduces the steady-state frequency deviation, and enhances coordinated power sharing, thereby improving the primary frequency regulation performance and overall frequency stability of the wind–storage hybrid system. Full article

Synchronous Alternating Current (AC) power systems are increasingly supported by embedded High-Voltage Direct Current (HVDC) links to enhance operational flexibility and ensure security of supply. However, the loss of High-Voltage Alternating Current (HVAC) interconnections in these synchronous areas may lead to transmission network splitting, posing serious challenges to frequency stability due to the reduction in overall system inertia and stiffness. In this paper, a supplementary control layer is proposed to enable embedded HVDC systems, particularly those based on modern Voltage Source Converters (VSCs), to support frequency stability under post-splitting conditions. The proposed control strategy combines Angle-Difference Control (ADC), Frequency-Difference Control (FDC), and feedforward action, enabling fast and coordinated active-power modulation. A single-bus, dynamic multi-area Load Frequency Control (LFC) model is developed, combining the regulation of thermal units, Renewable Energy Sources’ (RESs’) Fast Frequency Response (FFR) with Synthetic Inertia (SI), and VSC-HVDC modulation. The effectiveness of the proposed control layer is demonstrated by applying it to the East Tyrrhenian Link (ETL), an embedded VSC-HVDC interconnection connecting Sicily with the mainland of Italy, under a post-splitting low-inertia condition in which Sicily operates as an islanded synchronous system, i.e., after losing synchronism with the mainland of Italy, in a 2030 scenario condition. The simulation results demonstrate that the proposed controller enables embedded VSC-HVDC systems to actively participate in post-splitting frequency containment and damping, as well as coordinated active power reallocation, thereby enhancing overall system stability and resilience. Full article

Islanded photovoltaic microgrids with limited inertial support can undergo steep frequency excursions after sudden generation loss or abrupt load changes. This paper develops and evaluates a synthetic inertia strategy supported by a supercapacitor energy storage unit for fast frequency containment in this type of system. The proposed approach commands rapid active-power injection or absorption from the measured rate of change of frequency, thereby emulating the immediate inertial contribution usually associated with rotating machines while preserving a simple and physically interpretable control structure. The supercapacitor is represented through a resistance–capacitance model that includes equivalent series resistance and is interfaced through a bidirectional buck–boost power converter subject to practical current, voltage, and power limits. Rather than claiming a fundamentally new storage-support concept, the contribution of this paper lies in providing a transparent and constraint-consistent benchmark that integrates measured operating profiles, explicit supercapacitor limits, hybrid frequency–RoCoF support, and stress-aware comparative assessment under a common set of plant assumptions. The methodology is assessed in time-domain simulations under representative benchmark disturbances, including an approximately ten percent photovoltaic generation loss, a ten percent load increase, and a combined event. Performance is evaluated through the peak rate of change of frequency, frequency nadir, integral error indices, time outside the admissible band, and supercapacitor stress indicators such as current peaks, voltage depletion, and energy throughput. An additional non-ideal assessment is also included to examine the behavior of the RoCoF-based support law under bounded frequency-measurement perturbations and delayed control action. A complementary variability-driven case based on a highly fluctuating measured irradiance window is also used to examine the behavior of the adaptive energy-management mechanism under repeated photovoltaic-power variations. A local small-signal analysis is also included to show that the selected gain region is dynamically plausible in the unsaturated regime. The results show that the proposed adaptive hybrid strategy improves the overall frequency response while maintaining admissible supercapacitor operation, thus providing a stronger methodological basis for rapid frequency support in islanded photovoltaic microgrids. Full article

The increasing penetration of renewable energy technologies such as wind and solar photovoltaics has displaced conventional synchronous generation, resulting in reduced system inertia. Low-inertia conditions degrade frequency stability and limit the power system’s disturbance response capability. Accurate inertia estimation is therefore essential to prevent over-frequency events, unintended protection actions, load shedding, and cascading failures. Moreover, the variability of renewable energy sources complicates inertia dynamics, rendering traditional approximation-based estimation methods inadequate for modern power systems. This paper proposes a novel hybrid optimization-based inertia estimation method that combines particle swarm optimization (PSO) and genetic algorithm (GA) for grid-scale energy storage systems. Unlike conventional approaches, the proposed framework systematically integrates inertia formulations applicable to both synchronous generators and converter-interfaced resources within a unified estimation structure. The performance of the proposed method is evaluated and compared with PSO and GA using the IEEE 39 bus system in two disturbance scenarios. The results demonstrate that the proposed hybrid PSO–GA approach achieves superior robustness, estimation accuracy, and adaptability for operational inertia awareness and near real-time inertia applications. The results confirm that the proposed method provides an effective and reliable inertia estimation tool to support frequency regulation, enhance disturbance response, and ensure secure operation of low-inertia power systems. Full article

The rapid integration of inverter-based renewable energy sources (RES), particularly solar photovoltaic (PV) and wind power plants (WPPs), together with the large-scale deployment of battery energy storage systems (BESSs) is fundamentally reshaping modern power systems. While these technologies are essential for decarbonization, their converter-dominated and variable characteristics introduce new challenges for grid stability, operational security, and regulatory compliance. As a result, grid codes are being continuously revised to define advanced technical requirements, including fault ride-through (FRT) capability, reactive power support, frequency response, voltage control, and active power management for RESs and energy storage systems (ESS). This study presents a systematic comparative assessment of international grid codes, examining the technical and operational requirements imposed on inverter-based resources (IBR) and ESSs across multiple jurisdictions. In parallel, the current Turkish Grid Code is evaluated from a future-oriented perspective, and recommendations that can improve the existing regulatory framework are proposed, particularly regarding high-voltage ride-through capability, synthetic inertia provision, fast frequency response (FFR), hybrid power plant (HPP) coordination, and ESS-specific performance criteria. Based on the comparative analysis, the study proposes targeted amendments to the Turkish Grid Code aimed at enhancing system resilience under high renewable penetration levels. Furthermore, field-testing methodologies, model-based validation practices, and emerging digitalized compliance monitoring architectures are investigated to assess their applicability to next-generation power systems. By integrating international best practices with country-specific recommendations, this work contributes to the development of transparent, adaptive, and technically robust grid code compliance frameworks, supporting both academic research and practical grid modernization efforts. Full article

The increasing penetration of converter-interfaced generation raises critical concerns for power system stability, especially during rapid transients and system split events that are not yet adequately addressed in current grid code compliance tests. This paper assesses the resilience of a Virtual Synchronous Machine (VSM) in comparison with a grid-following photovoltaic (PV) inverter through a combined framework of standardized benchmark tests and realistic system split scenarios. In benchmark testing, the VSM provided synthetic inertia by delivering a transient-power burst from a 0.30 p.u. setpoint to 0.545 p.u. (on a 20 MVA base, representing 54.5% of rated capacity) under a $-0.4$ Hz/s frequency ramp, corresponding to an equivalent inertia constant of approximately 15 s. With the limited frequency-sensitive mode–underfrequency (LFSM-U) function enabled, it sustained additional active power up to 0.61 p.u. once the frequency fell below 49.8 Hz. The PV inverter, by contrast, demonstrated compliance with conventional grid requirements: it curtailed power through LFSM-O during overfrequency conditions and injected 0.25 p.u. of reactive current during a fault ride-through (FRT) event at 1.129 p.u. voltage. In system split tests, the VSM absorbed surplus PV generation, stabilizing frequency after a transient rise to 52.8 Hz and containing voltage excursions beyond 1.2 p.u. During imbalance stress, it absorbed 1.266 MW against its 1.0 MW rating for approximately 2–3 s, corresponding to a 26.6% overload that falls within typical IGBT transient thermal capability but would require supervisory intervention (e.g., PV curtailment or load management) if sustained. These results demonstrate that while the PV inverter contributes valuable voltage support, only the grid-forming VSM maintains frequency stability and ensures secure islanded operation. The novelty of this study lies in integrating standardized compliance tests with system split scenarios, providing a comprehensive framework for evaluating grid-forming controls under both regulatory and resilience-oriented perspectives and informing the evolution of future grid codes. Full article

With power systems becoming increasingly dominated by inverter-based resources (IBRs), spatial–temporal frequency dynamics have emerged as a significant challenge due to the loss of mechanical inertia and increasing heterogeneity in inverter controls. Conventional models grounded in center-of-inertia (COI) frequency and system frequency response (SFR) fail to capture localized frequency behavior under disturbances, particularly in systems with non-uniform synthetic inertia and weak electrical coupling. This paper develops an analytical modeling framework for the characterization and mitigation of spatial–temporal frequency patterns in fully inverter-based systems. Local frequency dynamics are explicitly derived from the control characteristics of grid-forming (GFM) and grid-following (GFL) inverters and incorporated into a network-aware formulation using topology-dependent state-space equations. The proposed model elucidates the interplay between local control parameters and network structure in shaping the propagation of frequency disturbances. A coordinated mitigation approach is further introduced, leveraging the tuning of local inverter settings and system topology parameters to suppress spatial frequency deviations. The proposed mitigation method is developed under an analytically assumed disturbance scenario in which the disturbance location is considered known for modeling and analysis purposes. The framework establishes a principled foundation for the analysis, prediction, and mitigation of frequency dynamics in low-inertia power systems. Full article

This study investigates the physical and cyber-physical resilience of smart grids with a high share of renewable energy sources (RESs) dominated by permanent magnet synchronous generators (PMSGs). The originality of this work lies in the development and unified evaluation of five integrated control strategies, the PLL with grid following, VSG with grid shaping, VSG+BESS, VSG+STATCOM, and VSG+BESS+STATCOM, implemented within a coherent simulation framework based on Python. Unlike previous works that analyze these methods in isolation, this study provides a comprehensive quantitative comparison of their dynamic characteristics, including frequency root mean square deviation, maximum deviation, and composite resilience index (RI). To extend the analysis beyond static conditions, a multi-generator (multi-PMSG) scenario with heterogeneous inertia constants and variable load profiles is introduced. This dynamic model allows the evaluation of natural inertia diversity and the effects of inter-generator coupling compared to the synthetic inertia emulation provided by VSG-based control. The combined VSG+BESS+STATCOM configuration achieves the highest synthetic resilience, improving frequency and voltage stability by up to 15%, while the multi-PMSG system demonstrates comparable or even higher RI values due to its inherent mechanical inertia and decentralized response behavior. In addition, a cyber-physical scenario is included to evaluate the effect of communication delays and false data injection (FDI) on VSG frequency control. The results show that a communication delay of 50 ms reduces RI by approximately 0.2%, confirming that even minor cyber disturbances can affect synchronization and transient recovery. However, hybrid control architectures with local energy buffering (BESS) show superior resilience under such conditions. The main technical contribution of this work is the establishment of an integrated analytical and simulation framework that enables the joint assessment of synthetic, natural, and cyber-physical resilience in converter-dominated smart grids. This framework provides a unified basis for the analysis of dynamic stability, hybrid control interaction, and the impact of cyber uncertainty, thereby supporting the design of low-inertia, resilient, and secure next-generation power systems. Full article

Virtual synchronous generator (VSG) technology introduces synthetic rotational inertia and damping into inverter-based systems, thereby enhancing regulation performance under grid-connected operation. However, the output characteristics of VSGs are strongly influenced by virtual inertia and damping. This paper develops a self-tuning inertia–damping coordination mechanism for VSGs. The coupling between virtual inertia and damping with respect to grid power quality is systematically investigated, and a power-angle dynamic response model for synchronous generators (SGs) under extreme operating conditions is established. Building on these results, an improved adaptive control strategy for the VSG’s virtual inertia and damping is proposed. The proposed strategy detects changes in frequency and load power, enabling adaptive tuning of virtual inertia and damping in response to system variations, thereby reducing frequency overshoot while accelerating the dynamic response. The effectiveness of the proposed strategy is validated by hardware-in-the-loop real-time simulations. Full article
