Recent advancements in synchrophasor measurement technologies have introduced an unprecedented level of visibility in power distribution networks (PDNs), providing a high-quality data foundation for the accurate perception of event source locations. However, the high cost and deployment expense pose a significant challenge in balancing system observability and event source location identification (ESLI) accuracy. In this paper, we propose a staged ESLI scheme based on voltage measurement deviation (VMD), which can achieve high-precision ESLI and event current calculations under extremely low-observability conditions, where the measurement devices are deployed only at the head substation and terminal buses. By setting an unknown event injection current and traversing each bus along the target feeder to derive the terminal bus voltage and its outgoing current, an ESLI model based on virtual event current injection (VCI) is constructed, which not only assists in the ESLI task but also confers the solving capability of the event current. Leveraging the event current calculation ability of the ESLI model, a VMD-based staged ESLI algorithm is developed, achieving an ordered and accurate search for the exact location of the event source in a goal-oriented manner. The effectiveness of the developed ESLI algorithm is evaluated on the IEEE 33-bus test system. Experimental results demonstrate that our VMD achieves high-precision ESLI and event current solving in PDNs under extremely low observability, significantly outperforming the state-of-the-art ESLI methods. Full article

To ensure the reliability and security of Colombia’s national power system, there is an ongoing necessity for upgrades in monitoring and protection mechanisms. Approximately sixteen years ago, the introduction of synchrophasor measurements enabled the swift detection of potentially network-detrimental events. Subsequent advancements have seen the deployment of Phasor Measurement Units (PMUs), currently tallying 150 across 25 substations, facilitating real-time monitoring and analysis. The growth of the PMU network is pivotal for the modernization of the National Control Center, particularly in the face of complexities introduced by renewable energy sources. There is an increasing demand for data analytics platforms to support operators in responding to threats. This paper explores the development of the Colombian Wide-Area Measurement System (WAMS) network, highlighting its milestones and advancements. Significant contributions include the technological evolution of the WAMS for real-time monitoring, an innovative high-speed data analytics strategy, and tools for the monitoring of frequency, rate of change of frequency (RoCoF), angular differences, oscillations, and voltage recovery, alongside industry-specific criteria for real-time assessment. Implemented within an operational WAMS, these tools enhance situational awareness, thereby assisting operators in decision-making and augmenting the power system’s reliability, security, and efficiency, underscoring their significance in modernization and sustainability initiatives. Full article

With the growing concern over climate change and energy security, the Government of India expedited enhancing the share of renewable energy (RE) derived from solar, wind and biomass sources within the energy blend. In this paper, a techno-economic and environmental analysis of a microgrid-integrated electric vehicle charging stations fueled by renewable energy is proposed for a typical area in the State of Karnataka, South India. The power transaction with the grid and the sell-back price to the national grid were investigated. Carbon emissions were also assessed, and 128,406 CO₂ kg/Yr can be saved in the grid-connected mode. Also, in this work, different scenarios such as injecting active power, reactive power, and active and reactive power, and injecting active and absorbing reactive power to the grid are comprehensively assessed. Out of four types, type 3 (inject real and reactive power) provides significant reduction in power losses by up to 80.99%. The synchrophasor-technology-based monitoring method is adopted in order to enhance the microgrid system’s overall performance. The execution times for different cases with distributed generators (DGs) and electric vehicle charging stations (EVCSs) for conventional systems and micro-phasor measurement units (µPMU) were observed to be 19.07 s and 5.64 s, respectively, which is well accepted in the case of online monitoring. Full article

Smart Grid 3.0 is the latest evolution of the smart grid and incorporates advanced computing and communication technologies. The synchrophasor communication system plays a critical role in wide-area measurement systems (WAMS) for real-time protection and control of power systems, supporting the objectives of Smart Grid 3.0. This system relies on synchrophasor communication technologies, where Phasor Measurement Units (PMUs) transmit synchrophasor data to Phasor Data Concentrators (PDCs) over the synchrophasor communication network. The communication infrastructure of this network is based on the TCP/IP protocol stack, which, unfortunately, is susceptible to cyberattacks, posing security threats such as data tampering and false data injection. These vulnerabilities undermine the intended benefits of synchrophasor applications in terms of situational awareness, observability, grid reliability, resiliency, and synchronized monitoring and control in the smart grid. To address these challenges, it is crucial to enhance the security, integrity, and confidentiality of synchrophasor data within the communication system. This paper proposes a blockchain-based synchrophasor communication system that preserves the security and integrity of synchrophasor data. In this paper, an architecture is proposed for a synchrophasor communication system based on blockchain technology. The proposed architecture aims to enhance the security and integrity of synchrophasor measurements. Furthermore, the architecture is developed as a peer-to-peer distributed blockchain network, leveraging the robustness of a distributed, decentralized, hierarchical PDC architecture. To evaluate the efficacy of the proposed architecture, two case studies, one using the IEEE 9 bus and the other using IEEE 14 bus systems are considered. Moreover, various challenges with potential solutions are also recommended. The proposed work is envisioned to contribute to the advancement of Smart Grid 3.0 by adopting blockchain technology for synchrophasor applications. Full article

Synchrophasor-driven smart grid applications aiming to orchestrate a diverse set of Distributed Energy Resources (DERs) require extensive infrastructure including substantial instrumentation hardware, communication network extensions and controller installations for coordinated operation. This can make the overall installation expensive. Additionally, due to the computational complexity and data-intensive nature of the PDC functionality, most of the existing PDC implementations are on a purely software level, making them unsuitable for the real-time applications. To address this, the current paper proposes an alternate architecture for the real-time synchrophasor-based control of DER applications (e.g., microgrids) incorporating a centralized synchronization hardware designed to replace aggregation Phasor Data Concentrators (PDCs) and supplementary control algorithms into a singular reconfigurable hardware. This particular hardware is termed a Synchrophasor Synchronization Gateway and Controller (SSGC). The robustness of the proposed architecture is tested by using real-time (RT) Controller Hardware-In-the-Loop (CHIL) simulation-based experiments by manipulating the communication network that connects the SSGC with multiple Phasor Measurement Unit (PMU) streams broadcasting data through the IEEE C37.118.2 protocol in real time. These PMU streams were generated by using a real-time microgrid model running on a Typhoon HIL 604 simulator. To manipulate the communication interface between the proposed SSGC hardware and the PMU streams, a configurable Wide Area Network (WAN) emulator and communication network impairment appliance deployed in the Candela Technologies CT910 external hardware was utilized. The real-time control system was expanded by incorporating a low-pass filter to eliminate the potential overswitching of a Battery Energy Storage System (BESS). The proposed architecture demonstrated a reliable performance under ideal to moderately tampered communication networks. However, under a significantly corrupted network, the performance of this architecture is acutely affected. Full article

The emerging smart-grid and microgrid concept implementation into the conventional power system brings complexity due to the incorporation of various renewable energy sources and non-linear inverter-based devices. The occurrence of frequent power outages may have a significant negative impact on a nation’s economic, societal, and fiscal standing. As a result, it is essential to employ sophisticated monitoring and measuring technology. Implementing phasor measurement units (PMUs) in modern power systems brings about substantial improvement and beneficial solutions, mainly to protection issues and challenges. PMU-assisted state estimation, phase angle monitoring, power oscillation monitoring, voltage stability monitoring, fault detection, and cyberattack identification are a few prominent applications. Although substantial research has been carried out on the aspects of PMU applications to power system protection, it can be evolved from its current infancy stage and become an open domain of research to achieve further improvements and novel approaches. The three principal objectives are emphasized in this review. The first objective is to present all the methods on the synchro-phasor-based PMU application to estimate the power system states and dynamic phenomena in frequent time intervals to observe centrally, which helps to make appropriate decisions for better protection. The second is to discuss and analyze the post-disturbance scenarios adopted through better protection schemes based on accurate and synchronized measurements through GPS synchronization. Thirdly, this review summarizes current research on PMU applications for power system protection, showcasing innovative breakthroughs, addressing existing challenges, and highlighting areas for future research to enhance system resilience against catastrophic events. Full article

Compared to traditional measurement devices, the micro-synchrophasor measurement unit (D-PMU or μPMU) in the distribution power system has great differences in data acquisition frequency, data format, data dimension, time-stamped information, etc. Hence, it is imperative to research the integration mechanism of heterogeneous data from multiple sources. Based on the analysis of the current technology of multi-source information fusion, this paper proposes a novel approach, which considers two aspects: the interoperability of multi-source data and the real-time processing of large-scale streaming data. To solve the problem of data interoperability, we have modified the model of D-PMU data and established a unified information model. Meanwhile, an advanced distributed processing technology has been deployed to solve the problem of real-time processing of streaming data. Based on this approach, a smart distribution power system wide-area measurement and control station can be established, and the correctness and practicality of the proposed method are verified by an on-field project. Full article

In recent years, the Smart Grid (SG) has been conceptualized as a burgeoning technology for improvising power systems. The core of the communication infrastructure in SGs is the Synchrophasor Communication Network (SCN). Using the SCN, synchrophasor data communication is facilitated between the Phasor Measurement Unit (PMU) and Phasor Data Concentrator (PDC). However, the SCN is subjected to many challenges. As a result, the components, such as the links, PMUs, PDCs, nodes, etc., of the SCN are subjected to failure. Such failure affects the operation of the SCN and results in the performance degradation of the SG. The performance degradation of the smart grid is observed either temporarily or permanently due to packet loss. To avoid dire consequences, such as a power blackout, the SCN must be resilient to such failures. This paper presents a novel analytical method for the resiliency analysis of SCNs. A graph-theoretic approach was used to model SCN from the resiliency analysis perspective. Furthermore, we proposed a simulation framework for validating the analytical method using the Network Simulator-3 (ns-3) software. The proposed non-intrusive simulation framework can also be extended to design and analyse the resiliency of generic communication networks. Full article

The advent of synchrophasor technology has completely revolutionized the modern smart grid, enabling futuristic wide-area monitoring protection and control. The Synchrophasor Communication Network (SCN) is a backbone that supports communication of synchrophasor data among Phasor Measurement Units (PMUs) and Phasor Data Concentrators (PDCs). The operator at the control center can visualize the health of the smart grid using synchrophasor data aggregated at PDCs from several PMUs. Since the core of the SCN is the existing IP network as an underlying communication infrastructure, the synchrophasor data is subjected to attacks that can compromise its security. The attacks, such as denial-of-service (DoS), can result in degradation of performance and even can disrupt the entire operation of the smart grid, if not controlled. Thus, a resilient SCN is a pertinent requirement in which the system continues to operate with accepted levels of performance even in response to the DoS. This article endeavors to propose a comprehensive resiliency framework for the SCN with enhanced resiliency metrics based on hardware reliability and data reliability. The proposed framework is deployed for a SCN pertaining to a practical power grid in India for its resiliency analysis. The proposed work can be regarded as a significant contribution to smart grid technology, as it provides a framework for resiliency analysis covering different aspects such as hardware reliability, data reliability, and parameters validation using the QualNet network simulator. Nevertheless, an analytical design of the hybrid SCN proposed in this work can even be extended to other topological designs of SCN. Full article

The smart grid (SG), which has revolutionized the power grid, is being further improved by using the burgeoning cyber physical system (CPS) technology. The conceptualization of SG using CPS, which is referred to as the smart grid cyber physical system (SGCPS), has gained a momentum with the synchrophasor measurements. The edifice of the synchrophasor system is its communication network referred to as a synchrophasor communication network (SCN), which is used to communicate the synchrophasor data from the sensors known as phasor measurement units (PMUs) to the control center known as the phasor data concentrator (PDC). However, the SCN is vulnerable to hardware and software failures that introduce risk. Thus, an appropriate risk assessment framework for the SCN is needed to alleviate the risk in the protection and control of the SGCPS. In this direction, a comprehensive risk assessment framework has been proposed in this article for three types of SCNs, namely: dedicated SCN, shared SCN and hybrid SCN in an SGCPS. The proposed framework uses hardware reliability as well as data reliability to evaluate the associated risk. A simplified hardware reliability model has been proposed for each of these networks, based on failure probability to assess risk associated with hardware failures. Furthermore, the packet delivery ratio (PDR) metric is considered for measuring risk associated with data reliability. To mimic practical shared and hybrid SCNs, the risk associated with data reliability is evaluated for different background traffics of 70%, 80% and 95% using 64 Kbps and 300 Kbps PMU data rates. The analytical results are meticulously validated by considering a case study of West Bengal’s (a state in India) power grid. With respect to the case study, different SCNs are designed and simulated using the QualNet network simulator. The simulations are performed for dedicated SCN, shared SCN and hybrid SCN with 64 Kbps and 300 Kbps PMU data rates. The simulation results are comprehensively analyzed for risk hedging of the proposed SCNs with data reliability and hardware reliability. To summarize, the mean risk with data reliability (RwDR) as compared to the mean risk with hardware reliability (RwHR) increases in shared SCN and hybrid SCN by a factor of 17.108 and 23.278, respectively. However, minimum RwDR increases in shared and hybrid SCN by a factor of 16.005 and 17.717, respectively, as compared to the corresponding minimum RwHR. The overall analysis reveals that the RwDR is minimum for dedicated SCN, moderate for shared SCN, and highest for hybrid SCN. Full article

Synchrophasor technology opens a new window for power system observability. Phasor measurement units (PMUs) are able to provide synchronized and accurate data such as frequency, voltage and current phasors, vibration, and temperature for power systems. Thus, the utilization of PMUs has become quite important in the fast monitoring, protection, and even the control of new and complicated distribution systems. However, data quality and communication are the main concerns for synchrophasor applications. This study presents a comprehensive survey on wide-area monitoring systems (WAMSs), PMUs, data quality, and communication requirements for the main applications of PMUs in a modern and smart distribution system with a variety of energy resources and loads. In addition, the main challenges for PMU applications as well as opportunities for the future use of this intelligent device in distribution systems will be presented in this paper. Full article

Phasor measurement units (PMUs), which are the key components of a synchrophasor-based wide area monitoring system (WAMS), were historically conceived for transmission networks. The current trend to extend the benefits of the synchrophasor technology to distribution networks requires the PMU to also provide trustworthy information in the presence of signals that can occur in a typical distribution grid, including the presence of severe power quality (PQ) issues. In this framework, this paper experimentally investigates the performance of PMUs in the presence of one of the most important PQ phenomena, namely the presence of voltage fluctuations that generate the disturbance commonly known as flicker. The experimental tests are based on an ad-hoc high-accuracy measurement setup, where the devices under test are considered as “black boxes” to be characterized in the presence of the relevant signals. Two simple indices are introduced for the comparison among the different tested PMUs. The results of the investigation highlight possible critical situations in the interpretation of the measured values and provide a support for both the design of a new generation of PMUs and the possible development of an updated synchrophasor standard targeted to distribution systems. Full article

The proliferation of nonlinear loads and integration of renewable energy sources require attention for accurate harmonic estimation along with estimation of fundamental amplitude, phase, and frequency for protection, improving power quality, and managing power effectively in a smart distribution grid. There are currently different Windowed Interpolated Fast Fourier Transform (WIFFT) algorithms for harmonic voltage estimation, but estimation of current harmonics using WIFFT is not explored sufficiently. The existing WIFFT algorithms, when used for current harmonic estimation result in low accuracy due to spectral leakage and picket fence effect. On the other hand, Interpolated Discrete Fourier Transform (DFT) is used for synchrophasor quality metrics, but it is effective only when there are no harmonics and the fundamental frequency is constant. This paper proposes a unified solution, comprising of peak location index search (PLIS)-based Dual-Spectrum Line Interpolated Fast Fourier Transform (DSLIFFT) algorithm with 4-Term Minimal Sidelobe Cosine Window (4MSCW) for estimating both low-amplitude voltage or current harmonics and synchrophasor under variable frequency conditions for high-penetration renewable energy utility grids. The effectiveness of the proposed algorithm is validated by simulation studies and real-time experimentation using the National Instruments reconfigurable embedded system under nonlinear loading conditions. Full article

More and more countries and utilities are trying to develop smart grid projects to make transformation of their power infrastructure towards future grids with increased share of renewable energy production and near zero emissions. The intermittent nature of solar and wind power can in general cause large problems for power system control. Parallel to this process, the aging of existing infrastructure also imposes requirements to utility budgets in the form of a need for large capital investments in reconstruction or maintenance of key equipment. Synchrophasor and other synchronized measurement technologies are setting themselves as one of the solutions for larger wind power integration. With that aim, in this paper one possible solution for wind power control through data mining algorithms used on a large quantity of data gathered from phasor measurement units (PMU) is described. Developed model and algorithm are tested on an IEEE 14 bus test system as well as on real measurements made on wind power plants currently in operation. One such wind power plant is connected to the distribution grid and the other one to the transmission grid. Results are analyzed and compared. Full article

This study develops an analytical method for assessing the voltage stability margins of a decentralized load shedding scheme; it then examines the challenges related to the existing load shedding scheme. It also presents a practical application for implementing the proposed method, based on the synchrophasor measurement technology in modern power grid operations. By applying the concept of a continuously-computed voltage stability margin index to the configuration of the Thévenin equivalent system, the maximum transfer power could be used as an index to monitor the voltage instability phenomenon and thus determine the required load shedding amount. Thus, the calculated voltage stability margin might be a useful index for system operators in the critical decision-making process of load shedding. Dynamic simulations are performed on real Korean power systems as case studies. Simulation results, when comparing the existing and proposed methods, showed that there was a considerable reduction in the amount of load shedding in the voltage instability scenario. This indicates that the synchrophasor measurement technology has a considerable effect on the proposed load shedding method. The simulation results have validated the performance of the proposed method. Full article
