Addressing the issue of boundary layer separation and flow instability caused by shock wave–boundary layer interaction in supersonic compressor cascades, this work presents a novel aerodynamic design and optimization method for supersonic cascades. This method is based on a design philosophy of enhancing control over the shock wave and boundary layer by employing a blade channel with a curvature-continuous profile. An aerodynamic redesign and optimization methodology was conducted on the ARL-SL19 supersonic cascade, aiming to improve its aerodynamic performance and widen the stable operating range. The results indicate that for a low-loss diffusing channel, the design principle for the suction surface profile involves controlling the shock strength via the curvature of the forward section, while the aft section should feature a smooth and negative curvature variation. This approach facilitates the control of the boundary layer flow, thereby improving the overall aerodynamic performance of the supersonic cascade. Compared to the baseline, the aerodynamically optimized cascade demonstrates a 10.74% reduction in the total pressure loss coefficient at the design point. Furthermore, its performance at off-design conditions is also significantly enhanced: the near-stall total pressure loss coefficient is reduced by 6.66%, the maximum total pressure ratio is increased by 6.32%, and the stable operating range with low flow loss is considerably extended. Full article

Low-saturated hydraulic conductivity covers (LSHCC) or hydraulic barriers are one of the reclamation techniques used to control the acid mine drainage generation (AMD). These covers are intended to limit the infiltration of water into reactive tailings. Compacted clays are among the materials used as LSHCC. The performance of clay-based hydraulic barriers can be affected by their geotechnical and hydrogeological properties. Freeze–thaw cycles can increase their saturated hydraulic conductivity (k_sat). However, these effects can be minimized by adding amendments. To evaluate the performance of these clay-based covers, four field experimental cells were built. The first one simulates a cover composed entirely of clay, the second a clay–silt mixture, the third a clay–sand mixture and the last two layers of clay with an intermediate layer of silt. Each cell has been equipped with a monitoring station with continuous measurements of volumetric water content, suction and temperature. In situ permeability tests were also conducted to assess field hydraulic conductivity. Numerical simulations were also conducted to evaluate the water balance for each cover scenario. The laboratory results showed low-saturated hydraulic conductivity values meeting waterproofing criteria, whereas field measurements and calibrated model values were consistently higher and exceeded the waterproofing criteria. Infiltration monitoring indicated that 15 to 40% of precipitation infiltrated the covers, with possible overestimation due to preferential flow. Discrepancies between laboratory and field-saturated hydraulic conductivity values were mainly attributed to inadequate compaction, unfavorable weather conditions, and excessive water content during cover installation. Variations in saturated hydraulic conductivity over time were generally within statistical variability, although differences among cells and responses to wetting–drying cycles highlight the influence of construction conditions on field performance. Full article

Steam turbines with controlled extraction require a flow control device to keep extraction pressure constant when the extraction mass flow rate is changed. An attractive option is an adaptive turbine stage with throttling nozzles. Flow measurements with a throttling nozzle are performed in a cascade wind tunnel. A linear cascade with seven blades is operated at an inlet flow angle of 90° and an exit Reynolds number of about 4 × 10⁵. Since the maximum exit Mach number is about 0.2, flow is essentially incompressible. A three-hole pressure probe is traversed at half span over one blade pitch 0.33 axial chord lengths downstream of the cascade. Degree of closing is gradually changed from zero (fully open) to 0.3 (partially closed). Two principal options, closing to the suction side as well as closing to the pressure side, are investigated. Local flow quantities as well as pitchwise mass averaged quantities are extracted from the measurement data. The major outcomes are as follows: If the throttling nozzle is closed, depth and width of the blade wake increase. With increasing degree of closing, pitchwise mass averaged flow angle decreases and total pressure losses increase. Concerning total pressure losses, closing to the pressure side is the preferred option. A semi-empirical flow model is presented to explain the influence of degree of closing on exit flow angle and total pressure loss. Full article

The present numerical study simultaneously investigates the aerodynamic performance, shape optimization, and aeroacoustic characteristics of modified leading-edge wavy wings for the NACA 0020 airfoil. Unlike conventional passive flow-control approaches, the present study proposes a collaborative vortex–slot control strategy, where streamwise vortices induced by a wavy leading edge interact constructively with momentum injection from upper-surface slot channels. Flow field is analyzed at a Reynolds number of 290,000 and various angles of attack (AoA) utilizing Computational Fluid Dynamics (CFD). Three leading-edge wavy wing configurations, namely A3L11, A3L40 and A11L40, are examined and further modified by introducing streamwise slots near the leading edge on the upper surface of the wing. Three slot diameters (0.07c, 0.10c, and 0.13c) are examined at a constant draft angle of 7.5°, which represents the inclination of the slot relative to the wing surface. The numerical results are validated against experimental data available in the literature. The findings indicate that the A3L11 configuration with a 0.07c slot diameter, as well as the A11L40 configuration at high angles of attack, outperform the baseline wavy wing. This improvement is attributed to the slotting mechanism, which enhances surface suction and streamwise momentum, thereby improving boundary-layer behavior. An increase in aerodynamic efficiency, quantified by the lift-to-drag ratio, is observed at 20° AoA for all configurations. To further enhance performance, shape optimization is performed by optimizing the slot diameter and the distance between the chord line and the slot center using a Genetic Algorithm (GA), with the A11L40 configuration at 20° AoA identified as the optimal design. The optimized configuration yields an overall aerodynamic performance improvement of approximately 27.76% compared to the smooth wing, while broadband aeroacoustic source modeling indicates a relative reduction in predicted noise-source intensity relative to the baseline modified wing. The results are presented through combined quantitative metrics and qualitative flow analyses, demonstrating the potential applicability of the proposed optimization framework to low-Reynolds-number aerodynamic and aeroacoustic design problems, such as those encountered in small-scale air vehicles, bio-inspired wings, and noise-sensitive systems. Full article

Flow tubes are key rescue devices used to respond to explosions and fires caused by blowouts. Improperly designed flow tubes can cause buckling failures, which can result in injuries or fatalities, particularly during high-speed blowouts, so optimizing the design based on the mechanism of high-speed blowout flow near the flow tube can improve rescue efficiency and reduce risk. This study investigated the flow control mechanism and analyzed the lift force of variable-diameter flow tubes. Simultaneously, the suction effect generated by the flow tubes was also quantified. The effect of flow tube structure and posture parameters on the flow field near a blowout well was numerically investigated using Fluent CDF software 2020R2, and the realizable k-ε turbulent model was used to account for turbulence. The inlet velocity was set to 300 m/s in order to simulate a high-speed blowout flow. The diameter ratio of the upper and lower parts of the flow tube changed from 1:1 to 1:2.4, and the ratio of the lower part to the total length changed from 1:10 to 3:10. The effects of the diameter ratio and length ratio on the distribution of the velocity and pressure in the flow tube were investigated. A strong negative pressure profile was observed in the equal-diameter flow tube. As the diameter ratio increased from 1:1.6 to 1:2.4, the negative pressure decreased from −1094 Pa to −214 Pa. In addition, the risk of personal suction due to negative pressure at the bottom of the flow tube was evaluated, and the effectiveness of drainage and the capability of flow control were analyzed. When the diameter ratio was increased by approximately 12.5%, the flow rate of entrainment decreased by 4% compared to the equal-diameter tube. Furthermore, the flow tube was subjected to significant upward lift forces during the snapping process, thereby increasing the risk of dislodgment. The effect of the changes in height and angle on the lift forces on the flow tube during buckling-up-installation was examined. It was found that the lift force decreases with height and is sensitive to the angle of inclination. Overall, it was concluded that the diameter ratio of the flow tube and the length of the lower section are key parameters for flow tube design. Full article

In the context of increasingly complex offshore drilling operations and stricter environmental regulations, the efficient handling and volume reduction of drilling cuttings has emerged as a crucial focus in the advancement of solids control equipment. “Airflow-assisted screening” is a technique that uses directed air currents to enhance the separation of solid cuttings from drilling fluid on a shaker screen, thereby improving dewatering efficiency and reducing waste volume during drilling. This study proposes and designs novel negative-pressure suction-type cuttings reduction equipment by integrating this technology with screw conveying principles. The system features a compact, vacuum-generator-centered design that integrates suction and screening. Key components were optimized, and a monitoring scheme was implemented for real-time performance evaluation. In the mechanism analysis, the relationship between inlet pressure, geometric parameters, and suction performance was explored based on Bernoulli’s principle and Laval nozzle characteristics, and internal flow field characteristics were revealed through computational fluid dynamics (CFDs) simulations. In the experimental section, a prototype system and testing platform were constructed to evaluate the effects of inlet pressure and screen mesh configurations on suction and screening performance. The results indicate that the system achieved optimal performance at an inlet pressure of 400 kPa with a 100-mesh screen, reaching a cuttings reduction efficiency of 9.225%. This study effectively validates the theoretical and simulation findings, providing technical support for the application of this equipment in complex drilling environments and demonstrating strong potential for practical implementation. Full article

Frequent extreme rainfall events in northwestern China have made loess–mudstone composite slopes highly susceptible to progressive failure, posing serious threats to infrastructure and public safety. This study investigates the deformation–failure mechanisms and evolutionary characteristics of such slopes under rainfall infiltration by integrating indoor physical model tests with long-term SBAS-InSAR time-series deformation monitoring. The physical model experiments reveal pronounced hydro-mechanical heterogeneity within the composite slope: surface fissures act as preferential flow paths, the mudstone interface exerts a significant water-blocking effect, and hydrological responses differ markedly between shallow and deep layers. The wetting front exhibits a distinct dual-layer migration pattern, characterized by rapid lateral expansion in the shallow layer and delayed advancement in the deep layer. Rainfall infiltration induces a progressive failure process, evolving from toe infiltration softening and mid-slope local erosion to differential crest erosion and ultimately overall sliding, forming a typical failure pattern of frontal creeping, central shearing, and rear tensile deformation. SBAS-InSAR results indicate that the natural landslide experienced a similar long-term progressive evolution, developing from shallow, localized deformation to deep-seated and slope-wide acceleration under multi-year rainfall. Despite differences in spatial deformation patterns influenced by natural microtopography, the failure stages and dominant deformation zones identified by both approaches show strong consistency. The combined results demonstrate that rainfall-induced suction decay, interface softening, pore water pressure accumulation, and stress redistribution jointly control the progressive instability of loess–mudstone slopes. This study highlights the effectiveness of integrating physical modeling and InSAR monitoring for elucidating rainfall-induced landslide mechanisms and provides scientific insights for hazard assessment and mitigation in composite-structure slopes. Full article

To address the technical challenge where traditional high-pressure, large-flow emulsion pump stations cannot adapt to the drastic flow rate changes in hydraulic supports due to the fixed displacement of their quantitative pumps—leading to frequent system unloading, severe impacts, and damage—this study proposes an intelligent flow control method based on the digital flow distribution principle for actively perceiving and matching support demands. Building on this method, a compact, electro-hydraulically separated prototype with stepless flow regulation was developed. The system integrates high-speed switching solenoid valves, a piston push rod, a plunger pump, sensors, and a controller. By monitoring piston position in real time, the controller employs an optimized combined regulation strategy that integrates adjustable duty cycles across single, dual, and multiple cycles. This dynamically adjusts the switching timing of the pilot solenoid valve, thereby precisely controlling the closure of the inlet valve. As a result, part of the fluid can return to the suction line during the compression phase, fundamentally achieving accurate and smooth matching between the pump output flow and support demand, while significantly reducing system fluctuations and impacts. This research adopts a combined approach of co-simulation and experimental validation to deeply investigate the dynamic coupling relationship between the piston’s extreme position and delayed valve closure. It further establishes a comprehensive dynamic coupling model covering the response of the pilot valve, actuator motion, and backflow control characteristics. By analyzing key parameters such as reset spring stiffness, piston cylinder diameter, and actuator load, the system reliability is optimized. Evaluation of the backflow strategy and delay phase verifies the effectiveness of the multi-mode composite regulation strategy based on digital displacement pump technology, which extends the effective flow range of the pump to 20–100% of its rated flow. Experimental results show that the system achieves a flow regulation range of 83% under load and 57% without load, with energy efficiency improved by 15–20% due to a significant reduction in overflow losses. Compared with traditional unloading methods, this approach demonstrates markedly higher control precision and stability, with substantial reductions in both flow root mean square error (53.4 L/min vs. 357.2 L/min) and fluctuation amplitude (±3.5 L/min vs. ±12.8 L/min). The system can intelligently respond to support conditions, providing high pressure with small flow during the lowering stage and low pressure with large flow during the lifting stage, effectively achieving on-demand and precise supply of dynamic flow and pressure. The proposed “demand feedforward–flow coordination” control architecture, the innovative electro-hydraulically separated structure, and the multi-cycle optimized regulation strategy collectively provide a practical and feasible solution for upgrading the fluid supply system in fully mechanized mining faces toward fast response, high energy efficiency, and intelligent operation. Full article

This paper presents the design, manufacturing, instrumentation and validation by tests (ground and icing wind tunnel) of a full-scale Hybrid Laminar Flow Control (HLFC) leading-edge demonstrator based on Airbus A330 outer wing plan-form. The Ground-Based Demonstrator (GBD) was developed to reproduce a full-scale, realistic wing section integrating into the leading-edge three key systems: micro-perforated skin for the hybrid laminar flow control suction system (HLFC), the hot-air Wing Ice Protection System (WIPS) and a folding “bull nose” Krueger high-lift device. The demonstrator combines a superplastic-formed and diffusion-bonded (SPF/DB) perforated titanium skin mounted on aluminum ribs jointed with a carbon-fiber-reinforced polymer (CFRP) wing box. Titanium internal ducts were designed to ensure uniform hot-air distribution and structural compatibility with composite components. Manufacturing employed advanced aeronautical processes and precision assembly under INCAS coordination. Ground tests were performed using a dedicated hot-air and vacuum rig delivering up to 200 °C and 1.6 bar, thermocouples and pressure sensors. The results confirmed uniform heating (±2 °C deviation) and stable operation of the WIPS without structural distortion. Relevant tests were performed in the CIRA Icing Wind Tunnel facility, verifying the anti-ice protection system and Krueger device. The successful design, fabrication, testing and validation of this multifunctional leading edge—featuring integrated HLFC, WIPS and Krueger systems—demonstrates the readiness of the concept for subsequent aerodynamic testing. Full article

Synthetic jets, generated through the periodic suction and ejection of fluid without net mass addition, offer distinct benefits, such as compactness, ease of integration, and independence from external fluid sources. These characteristics make them well-suited for flow control and convective heat transfer applications. However, conventional single-actuator configurations are constrained by limited jet formation, narrow surface coverage, and diminished effectiveness in the far field. This review critically evaluates the key limitations and explores four advanced configurations developed to mitigate them: dual-cavity synthetic jets, single-actuator multi-orifice jets, coaxial synthetic jets, and synthetic jet arrays. Dual-cavity synthetic jets enhance volume flow rate and surface coverage by generating multiple vortices and enabling jet vectoring, though they remain constrained by downstream vortex diffusion. Single-actuator multi-orifice designs enhance near-field heat transfer through multiple interacting vortices, yet far-field performance remains an issue. Coaxial synthetic jets improve vortex dynamics and overall performance but face challenges at high Reynolds numbers. Synthetic jet arrays with independently controlled actuators offer the greatest potential, enabling jet vectoring and focusing to enhance entrainment, expand spanwise coverage, and improve far-field performance. By examining key limitations and technological advances, this review lays the foundation for expanded use of synthetic jets in practical engineering applications. Full article

As the global environment continues to deteriorate, water blooms and red tides occur more frequently, making it increasingly important to control eutrophication in water bodies. This study focuses on optimizing an adjustable vortex well alga extractor for deep-well alga removal to reduce the risks associated with algal blooms and red tides. Numerical simulation was employed to model the working process of the vortex well alga extractor and to determine its most efficient structural parameters. The optimal dimensions of the adjustable vortex well alga collector optimized by the PSO-GP model are as follows: during the experiment, the water depth at the suction inlet is 200 mm, the diameter of the suction inlet is 480 mm, the distance of the fence is 2000 mm, and the average flow velocity of the water area is 0.12 m/s. Under these conditions, the working flow rate of the pressurizer can reach up to 18,400 cubic meters per hour at a maximum. Under these conditions, the collection efficiency for blue-green algae can reach 92%. The proposed optimization method can assist project managers in improving the design and operation of deep-well alga removal systems, achieving higher accuracy and efficiency, conserving energy, and enhancing overall alga removal performance. Full article

The fluctuating nature of renewable energy sources such as wind and solar power poses significant challenges to the stability of power grids, while pumped-storage hydropower, with its advantages in peak regulation and frequency control, has become an essential component of modern energy strategies. However, sediment in rivers adversely affects the operational efficiency and stability of PSH units, leading to accelerated wear and shortened service life. In this study, the low-pressure stage of a two-stage pump turbine was selected as the research object, and the Euler–Euler numerical method was employed to investigate the solid–liquid two-phase flow characteristics of the pump turbine in pump mode. The results show that, compared with the clear-water condition, the head and efficiency decrease by up to 7.9% and 15%, respectively, after the addition of sand particles. The average pressure within the flow-passage components increases, while the streamlines become more non-uniform, accompanied by the formation of vortices and backflow in the guide and return vanes. The total entropy generation increases with rising particle concentration but decreases with larger particle size. Among the components, the high-entropy regions are mainly located on the suction surface and trailing edges of the impeller blades, the inlet and blade surfaces of the guide vanes, and the inlet and trailing edges of the return vanes. Moreover, the pressure pulsation amplitudes at monitoring points in the vaneless region, guide vane–return vane interaction region, and leading edge of the return vane increase progressively with both particle size and concentration. The dominant and secondary frequencies at all monitoring points correspond to the blade-passing frequency (BPF) and its harmonics, indicating that rotor–stator interaction is the principal cause of pressure pulsations under pump operating conditions. Full article

As key emergency equipment, high-flow pump devices play a vital role in urban flood control and drainage, and their hydraulic performance directly influences the safety and stability of the entire system. To meet diverse drainage demands during emergency operations, a new type of high-flow drainage pump, capable of operating in series, parallel, and variable-speed modes, has been developed. Using the SST k-ω turbulence model combined with entropy production theory and pressure pulsation analysis, unsteady numerical simulations were conducted to investigate the transient internal flow under series and parallel operating conditions. The numerical model was verified through comparison with experimental hydraulic-performance data, demonstrating good agreement. The results show that under series operation, the pump speed decreases from 1500 r/min to 193 r/min before reversing to −1748 r/min, while under parallel operation the runaway speed reaches −1657 r/min. The flow rate and torque exhibit strong nonlinear variations, with reverse flow and oscillatory behavior appearing in the impeller passages. During the runaway stage, entropy production peaks at 28.17 W/K under series conditions and 29.09 W/K under parallel conditions, with turbulent dissipation accounting for more than 69% of the total. High-entropy regions extend toward the impeller outlet, while energy losses are predominantly concentrated in the secondary suction chamber, contributing 47.56% and 57.12% under the respective conditions. Pressure pulsation analysis indicates that the dominant frequency components are concentrated at the blade-passing frequency (100 Hz) and its harmonics, with the strongest fluctuations near the primary impeller outlet. These results provide theoretical and engineering guidance for improving the efficiency and stability of emergency drainage systems. Full article

Toroidal propellers have emerged as a promising substitute for next-generation marine propulsors due to their potential advantages in hydrodynamic efficiency and noise control. This article presents a hydrodynamic analysis of toroidal propellers using a potential-based boundary element method (BEM) that enables rapid computations of complex geometries when compared with computationally demanding viscous simulations. The method predicts the inviscid flow characteristics, forces, and circulation distributions of toroidal propellers and is validated against Reynolds-averaged Navier–Stokes (RANS) simulations under various loading conditions and geometric configurations. The comparison shows that the BEM successfully reproduces the overall thrust and torque trends observed in the viscous simulations, although discrepancies arise due to flow separation and the absence of leading-edge vortices that dominate the suction side dynamics in RANS results. The wake alignment model in the BEM captures the overall trajectories of the shed vortices with good consistency, though its concentrated wake representation occasionally brings the trailing wake substantially close to the rear blade surface, which causes locally low pressures that are not present in RANS where boundary layers prevent direct wake impingement. The BEM was further extended for a parametric study that varied pitch, axial spacing, and lateral angle, showing that pitch variations have the most significant influence on propeller loading and thrust characteristics. Overall, the present work demonstrates that the proposed BEM provides a computationally efficient and physically reasonable framework for predicting the performance of toroidal propellers, especially for early-stage geometric design and optimization. Full article

As aviation operations extend into complex natural environments, dust particles present significant challenges to flight stability and safety, particularly in dust-prone regions like southern Xinjiang. This study employs high-fidelity computational fluid dynamics (CFD) simulations, combined with the SST turbulence model and the Lagrangian discrete phase model, to analyze the aerodynamic response of the NACA 0012 airfoil at varying wind speeds (5, 15, and 30 m/s) and angles of attack (3°, 8°, and 12°). The results indicate that, at low speeds and moderate to high angles of attack, dust particles reduce lift by over 70%, primarily due to boundary layer instability, weakened suction-side pressure, and premature flow separation. Higher wind speeds slightly delay flow separation, but cannot counteract the disturbances caused by the particles. At higher angles of attack, drag increases by more than 60%, driven by wake expansion, shear dissipation, and delayed pressure recovery. Pitching moment frequently reverses from negative to positive, reflecting a forward shift in the aerodynamic center and a loss of pitching stability. An increase in dust concentration amplifies these effects, leading to earlier moment reversal and more abrupt stall behavior. These findings underscore the urgent need to improve aircraft design, control, and safety strategies for operations in dusty environments. Full article
