Search Results (626)

Overhead power lines (OHPLs) are currently widely used to generate power from various types of traditional power plants and transmit power between electric power systems (EPSs). OHPLs are known to be susceptible to climatic, meteorological, man-made, and other factors, which leads to more frequent outages with damage of varying severity. Ensuring reliable operation of the EPS requires rapid and accurate fault location (FL) for emergency restoration operations and the subsequent restoration of the OHPL. This article presents the results of an analysis of various methods for FL of OHPLs under conditions of deviations in power quality indicators (PQI), which leads to additional FL errors in emergency mode parameters (EMP). The objective of the study is to develop a new method for FL on OHPLs with unsynchronized measurements from both ends under conditions of current and voltage deviations from a sinusoidal shape, based on the least-squares method. The developed method for FL on OHPLs is based on differential equations describing the currents and voltages in emergency conditions at both ends, taking into account distributed transverse (capacitive) conductivity. This significantly improves the accuracy of FL on OHPLs with unsynchronized measurements at both ends under conditions of fluctuating power quality parameters. The article presents calculation results for a specific OHPL, demonstrating the improved accuracy of FL based on the EMP. The developed method can be implemented in digital protection and automation devices for OHPLs, as well as in software for power system control centers. Full article

We developed an arbitrary Lagrangian–Eulerian (ALE)-based multiphysics model for evaporation from a contact-line-pinned sessile drop of neat water subject to a vertically oriented sinusoidal alternating current (AC) electric field applied across parallel-plate electrodes. The framework fully couples electrostatics, incompressible flow, heat transfer with evaporative cooling, and transient vapour transport in air, and includes an instantaneous, voltage-controlled electrowetting contact-angle response under constant-contact-radius conditions. Validation against published data shows that the model captures both pinned-droplet evaporation and electrically induced deformation. Because Maxwell traction scales with the squared electric-field magnitude, droplet height and contact angle exhibit a robust 2:1 frequency-doubled response, producing two peak–trough events per voltage period. The resulting periodic deformation drives oscillatory interfacial shear and internal recirculation, yielding a synchronous double-peaked evaporative-flux waveform. Gas-side analysis quantifies a time-varying diffusion-layer thickness via a characteristic diffusion length; two thinning events per period coincide with flux maxima, indicating that AC enhancement is dominated by periodic compression of the vapour boundary layer and reduced gas-side mass-transfer resistance. Increasing voltage amplitude (0–60 kV) strongly accelerates volume loss, while frequency has a secondary effect: the cycle-averaged flux rises from 1 to 10 Hz but decreases slightly at 20 Hz due to phase lag and weaker boundary-layer modulation. Full article

Rigid-body chain following on piecewise analytic paths is a fundamental subroutine in motion planning and multibody simulation. The problem is nontrivial when only the leader trajectory of the first node is available: enforcing fixed inter-node distances reduces to circle–curve intersection, which is generally multi-valued and becomes particularly challenging near non-smooth junctions. We present a Dichotomy Geometric Path Search (DGPS) framework that converts each constraint into a one-dimensional root-finding task and resolves the branch selection through no-backtracking ordering: at every time step, the admissible solution for the current node is the nearest feasible root in the past relative to its immediately preceding node. DGPS combines backward bracketing with bisection, achieving robust convergence. Compared with the inverse Jacobian method, which maps end-effector velocities to joint velocities via explicit inversion, the proposed approach avoids Jacobian inversion and globally coupled nonlinear solves. We further characterize the local structure of the zero set and establish monotonicity/uniqueness conditions that justify stable root selection across piecewise junctions. Extensive tests on representative piecewise trajectories (line–arc–line, polylines with corners, piecewise sinusoids, and time reparameterization) show that DGPS enforces distance constraints to near machine precision, produces interpretable speed/acceleration transients around non-smooth events, and exhibits computational costs consistent with iteration difficulty. The results support DGPS as a general, efficient solver requiring only the prescribed leader trajectory. Full article

Multiport DC–AC converters are widely used in photovoltaic-energy storage–charging systems, but traditional two-stage schemes face challenges in circuit cost and efficiency improvements. To address this issue, a novel three-port single-stage DC–AC converter is proposed for grid-connected applications. The proposed converter integrates two DC ports and one AC port through circuit multiplexing, eliminating the high-voltage DC bus and reducing system complexity. An unfolding bridge is employed at the AC port, and full bridge circuits are used at DC ports, reducing the number of high-frequency switches. The proposed single-stage topology inherently achieves galvanic isolation and bidirectional power conversion. To achieve accurate grid current regulation and wide-range zero-voltage-switching, a multiple-phase-shift modulation method is developed to ensure a sinusoidal current waveform. The effectiveness of the proposed converter and modulation method is verified through simulation results, demonstrating a peak efficiency of 97% and a total harmonic distortion of 2.91%. Full article

This article presents an online additive fault-detection system for the speed sensor of a 200 W shunt-type direct current (DC) motor, integrated into a power module controlled by an Insulated Gate Bipolar Transistor (IGBT). The system is designed to trigger an alarm signal when an additive fault occurs by comparing the Kalman Filter (KF) residual against a predefined detection threshold. Three specific fault types in the speed sensor were analyzed: offset, disconnection, and sinusoidal noise. Experimental results demonstrate effective fault detection across a speed range of 80 to 690 rpm under no-load conditions. However, when a constant torque of 0.5 Nm is applied, both the detection threshold and the subset of reliably identifiable faults must be adjusted. The main contribution of this study is the development of a customized real-time fault detection framework and the characterization of residual variations caused by unmodeled load disturbances in actual hardware. This approach improves the monitoring and fault-diagnosis capabilities of sensor systems in DC motors by quantifying the stochastic behavior of residuals under different operating constraints. Full article

This paper presents a bench-top occupational power-assist robot aimed at reducing biomechanical effort during repetitive material handling. The prototype adopts a SCARA-like structure with three degrees of freedom and provides assistance on the vertical (z) axis through a three-phase brushless DC (BLDC) motor driven in field-oriented control with inner-loop current regulation. The user interacts with the robot through a single handle-mounted load cell. The measured interaction force is converted, via a calibration-based mapping, into a motor current reference that enforces a prescribed force-sharing ratio. In this way, the drive’s embedded current loop acts as the low-level torque regulator, and the system can share gravitational and inertial loads without additional environment force sensing or explicit high-level impedance/admittance dynamics. A coupled electro-mechanical model is derived and used to select the assistance gain and to verify feasibility in simulation. A pilot experimental campaign with eight participants and two payloads (0.5 kg and 1.5 kg) was carried out on sinusoidal and random tracking tasks. With assistance enabled, the operator contribution was reduced to about 15% of the total load, and the mean bicep brachii EMG amplitude decreased by about 60%, while tracking accuracy was generally preserved and often improved. Full article

With the evolution of new power systems, harmonic sources in distribution networks have become increasingly dispersed, thus requiring lower-cost harmonic mitigation devices suitable for large-scale deployment. With its simple control architecture, the one-cycle controlled active power filter (APF) is better adapted to meet the aforementioned requirements. That said, under non-ideal voltage conditions like voltage distortion or unbalance, the compensating target current of the APF that relies on traditional one-cycle control (OCC) will undergo distortion as well, resulting in a substantial reduction in the compensation effect. This paper introduces a modified OCC method based on a positive-sequence filter, which allows for the control of a reduced-switch three-phase APF. This control method eliminates the negative sequence and harmonic components in the target current of the APF, and makes the compensated current maintain a good sinusoidal waveform. A one-cycle control equation applied to the reduced-switch APF was derived. The modified one-cycle control method allows the active filter to retain a favorable compensation effect when operating under non-ideal voltage conditions. Meanwhile, it preserves the inherent advantages of traditional one-cycle control, including the elimination of a phase-locked loop (PLL), a fixed switching frequency, and a straightforward control structure. Finally, an APF simulation model and a dSPACE-based APF experimental circuit were built to verify the proposed control method. In simulation, with the adoption of the modified OCC, the THD of the current was reduced from 8.25% before improvement to 3.79% after improvement. In experiments, according to the spectrum analysis function of the oscilloscope, the third-order current harmonic caused by voltage distortion was decreased from 500 mA to 100 mA, representing a reduction of 80%. Both simulation and experimental results verify that the proposed modified one-cycle control method can effectively solve the problem that control performance is susceptible to voltage quality. Full article

This paper presents a compact floating memtranstor (MT) emulator, a memory element characterized by a direct φ–q relationship, realized without analog multipliers or complex circuitry. The proposed design employs only two active blocks—a voltage differential transconductance amplifier (VDTA) and a voltage differential current conveyor (VDCC)—along with three grounded capacitors and a single grounded electronically tunable resistor. The emulator accurately reproduces the fundamental φ–q dynamics, exhibiting origin-crossing pinched hysteresis loops under sinusoidal excitation, and operates at a low supply voltage of ±0.9 V. Electronic tunability is achieved via bias-controlled transconductance modulation, enabling flexible adaptation across excitation frequencies and operating conditions. Validation is performed through analytical modeling, Monte Carlo simulations, temperature sensitivity analysis, and full LTspice post-layout simulations using a 180 nm CMOS process. The full-custom layout occupies 2529.49 μm², with robust performance confirmed under parasitic and process variations. Adaptive learning simulations demonstrate the emulator’s artificial synaptic plasticity, highlighting its suitability for neuromorphic computing, chaos-based circuits, and nonlinear dynamical systems. The compact, low-power, and multiplier-free architecture establishes the proposed MT emulator as a practical platform for emerging analog memory-centric applications. To validate the feasibility of the proposed solution, experimental tests are performed using commercially available components. Full article

Background: Arterial stenosis produces nonlinear changes in vascular impedance that are challenging to investigate in real time using either benchtop flow phantoms or high-fidelity computational fluid dynamics (CFD) models. Objective: This study aimed to develop and evaluate a low-cost printed circuit board (PCB) analog capable of reproducing the hemodynamic effects of progressive arterial stenosis through an R–L–C mapping of vascular mechanics. Methods: A lumped-parameter (0D) electrical network was constructed in which voltage represented pressure, current represented flow, resistance modeled viscous losses, capacitance corresponded to vessel compliance, and inductance represented fluid inertance. A variable resistor simulated focal stenosis and was adjusted incrementally to represent progressive narrowing. Input U_in, output U_out, peak-to-peak V_pp, and mean V_avg voltages were recorded at a driving frequency of 50 Hz. Physiological correspondence was established using the canonical relationships. $R={\displaystyle \frac{8\mu l}{\pi r^4}}$, $L={\displaystyle \frac{pl}{\pi r^2}}$, $C={\displaystyle \frac{3\pi r^3}{2Eh}}$, where μ is blood viscosity, ρ is density, E is Young’s modulus, and h is wall thickness. A calibration constant was applied to convert measured voltage differences into pressure differences. Results: As simulated stenosis increased, the circuit exhibited a monotonic rise in U_out and V_pp, with a precise inflection beyond mid-range narrowing—consistent with the nonlinear growth in pressure loss predicted by fluid dynamic theory. Replicate measurements yielded stable, repeatable traces with no outliers under nominal test conditions. Qualitative trends matched those of surrogate 0D and CFD analyses, showing minimal changes for mild narrowing (≤25%) and a sharp increase in pressure loss for moderate to severe stenoses (≥50%). The PCB analog uses a simplified, lumped-parameter representation driven by a fixed-frequency sinusoidal excitation and therefore does not reproduce fully characterized physiological systolic–diastolic waveforms or heart–arterial coupling. In addition, the present configuration is intended for relatively straight peripheral arterial segments and is not designed to capture the complex geometry and branching of specialized vascular beds (e.g., intracranial circulation) or strongly curved elastic vessels (e.g., the thoracic aorta). Conclusions: The PCB analog successfully reproduces the characteristic hemodynamic signatures of arterial stenosis in real time and at low cost. The model provides a valuable tool for educational and research applications, offering rapid and intuitive visualization of vascular behavior. Current accuracy reflects assumptions of Newtonian, laminar, and lumped flow; future work will refine calibration, quantify uncertainty, and benchmark results against physiological measurements and full CFD simulations. Full article

This article proposes a parallel current-summing LCC multilevel inverter (MLI) to suppress harmonic distortion of radiated EMI for wireless power transfer. Traditionally, ZVS has been an issue for staircase voltage output multilevel inverters because a shared current output became faster than some of the voltage transitions in staircase voltage output. The other common problem was capacitor voltage imbalance and resultant output voltage distortion if a sophisticated voltage balancing function is not used. The proposed LCC MLI ensures ZVS by separating each voltage transition into multiple bridge legs. Each bridge leg outputs different phases of currents for each voltage transition. The individual output currents are summed at the matching network of wireless power transfer, generating a near-sinusoid output current to suppress harmonic distortions. In this way, each leg achieves ZVS even though the summed output current at the LCC network is faster than some of the voltage transitions. To avoid the capacitor voltage imbalance issue, the proposed MLI eliminated the flying capacitor. Instead, the four parallel legs are supplied by a shared DC input link. Therefore, the four legs can output identical voltages without using a typical DC flying capacitor. The necessity of multiple input voltage sources is, therefore, also eliminated. Measurement demonstrates that the proposed method effectively reduces radiated harmonic EMI by up to 14 dB. Full article

In recent years, improving the energy efficiency of induction machines (IM) has become a key research focus, with particular attention to loss reduction. Losses in IM are significantly influenced by two design-related factors: the nonlinear magnetization characteristic and the non-sinusoidal distribution of the magnetomotive force (MMF) in stator slots. These effects lead to harmonic distortions in stator and rotor currents as well as pulsations of the electromagnetic torque. This paper presents a comprehensive harmonic analysis of the interaction between the nonlinear magnetization curve and the non-sinusoidal MMF distribution in induction machines. A mathematical model in phase coordinates was developed, incorporating both effects through the introduction of harmonic components into the magnetizing inductance. The proposed model enables the evaluation of the impact of these phenomena on stator and rotor currents, as well as on the electromagnetic torque. The validity of the model is verified by experimental results, which show close agreement with simulations. The analysis demonstrates that the nonlinearity of the magnetization curve results in the appearance of the third harmonic in stator currents and the second harmonic in torque, while the non-sinusoidal MMF distribution produces the fifth and seventh harmonics in stator currents and the sixth harmonic in torque. Additionally, the study reveals that in no-load conditions, the third harmonics are dominant, whereas with increasing load, their magnitudes decrease, and the amplitudes of the fifth and seventh harmonics increase due to the interaction between stator and rotor currents. The proposed modeling approach provides an effective tool for accurate performance evaluation and design optimization of induction motor drives Full article

Due to the brittleness and volume sensitivity, segmentation is necessary for the cement concrete pavement slabs currently in widespread use to mitigate thermal stress and deformation. The dimensions of segmented pavement slabs are typically constrained to 4∼6 m, which results in a large number of joints. These joints cause damages such as corner spalling and fracture under the impact of repeated loads and environmental factors. In addition, maintenance costs are significantly increased due to the numerous joints. To enhance pavement performance and extend service lifespan, this paper proposes a design methodology for large pavement slabs. This method breaks the dimensional constraint and significantly reduces the number of joints, thereby improving comfort and durability, lowering maintenance costs, and meeting the operational requirements of new aircraft types. In this paper, pavement slab thermal stress is divided into curling stress and thermal expansion stress according to different deformation types. The diurnal and annual distributions of these two types of stresses are also investigated. Moreover, the maximum dimension design of pavement slabs comprehensively considers aircraft loads, thermal stresses, and fatigue characteristics. The results indicate that the diurnal and annual distributions of curling and thermal expansion stresses exhibit sinusoidal patterns. Under different temperature gradients and slab thicknesses, the allowable maximum slab dimension is presented. It is feasible to break the 4∼6 m limit for the maximum dimension of the pavement slab, which provides a new reference for improving pavement performance and lifespan. Full article

Plasma power supplies find extensive applications across industrial, energy, environmental, and medical domains. This study addresses limitations of conventional plasma power supplies, including high harmonic current content, neutral-point potential imbalance, and manufacturing complexity. A novel design approach for high-frequency, high-voltage plasma power supplies is proposed, based on three-level sinusoidal pulse width modulation (SPWM) technology. First, the design distinctions between the input-side Boost power factor correction circuit and Diode Rectifier circuits are analyzed. Subsequently, an integrated SPWM driver-controller architecture and a design methodology for high-frequency transformers are introduced. A single-phase three-level SPWM modulation strategy is then presented. Based on this modulation technique, a high-frequency, high-voltage plasma power supply prototype incorporating air pumps and rotary motors was developed. Experimental validation demonstrated stable generation of plasma gas at a frequency of 25 kHz, with an output voltage of 10.79 kV and an output power of 1.75 kW. Results indicate that the refined power supply enhances electrical utilization efficiency, resolves neutral-point imbalance issues, and simplifies manufacturing through its integrated driver-controller design. This work offers a valuable reference for advancing high-frequency, high-voltage plasma technologies. Full article

The integration of renewable energy sources, including photovoltaic (PV) and fuel cell (FC) systems, into AC grids has attracted immense research interest in recent times. Furthermore, incorporating these renewable sources of energy into medium-voltage grids is garnering increased attention because of the obvious benefits of medium-voltage integration at elevated power levels. Photovoltaic applications entail the arrangement of solar panels capable of outputting voltages up to 1.5 kV; nonetheless, fuel cells display restricted output voltage, with a maximum market range of 400 to 700 V. Hence, the efficient integration of renewable energy sources into low-voltage or medium-voltage grids demands the utilization of a step-up direct current (DC–DC) inverter and a converter for connection to the alternating current (AC) grid, in which an efficient step-up converter is critical for the medium-voltage grid. Therefore, this study presents a three-phase buck-boost split-source inverter (BSSI) that resolves the constrained output voltage of the fuel cells. This study focuses on modifying the configuration of a conventional three-phase split-source inverter (SSI) circuit by adding a few components while maintaining the inverter’s modulation. This novel circuit design enables the reduction in voltage strains on the inverter switch components and improves DC-link use in relation to a traditional SSI configuration. For an 800 bus, maximal voltage stress on the primary inverter switches is lowered when compared with the standard SSI that delivers entire DC-bus voltage to switches. A rectifier-based model is employed to simulate the behavior of a renewable energy source. Combining these advantages with the conventional modulation of the inverter offers a more effective design. The buck-boost split-source inverter (BSSI) was analyzed using three distinct modulation techniques: the sinusoidal pulse-width modulation scheme (SPWM), the third-harmonic injected pulse-width modulation (THPWM) scheme, and space vector modulation (SVM). The proposed analysis was validated through MATLAB-SIMULINK and practical outcomes on a 5.0 kW model. The practical and SIMULINK data were found to be closely aligned with the analysis. The circuit developed in this study also ensures efficient DC-to-AC conversion, specifically with regard to low-voltage sources, like fuel cells or photovoltaic (PV) systems. Full article

This study systematically investigates the structural optimization and control strategies of a plasma power supply-based rotating electrical machine. Firstly, stress simulation analysis was conducted on both conventional and optimized motor structures using ANSYS 2025 R1 software. The results demonstrate the maximum stress at the motor bearings decreased from 1.295 MPa to 0.865 MPa after optimization, representing a 33.2% reduction. Secondly, dynamic balance simulation performed with Adams 2024 software revealed that the centroid offset range of the optimized motor was reduced from ±0.05 mm to ±0.0175 mm, achieving a 65% improvement. Furthermore, a motor driver board supporting SVPWM and FOC algorithm was designed and implemented, featuring wide voltage input, multiple output channels, and comprehensive protection functions. Experimental verification confirmed that the developed control system could generate ideal three-phase saddle wave and sinusoidal current waveforms, ensuring smooth motor operation. The system demonstrated excellent dyne pen test results on plasma-sprayed acrylic plates, effectively validating the feasibility of both structural optimization and control strategies. The research outcomes provide theoretical foundations and technical support for high-performance motor design in demanding applications such as plasma spraying. Full article
