Search Results (26)

Over the past several decades, extensive research has advanced the understanding of liquefaction in clean sands and sand–silt mixtures under seismic loading. However, the influence of plastic (i.e., clayey) fines on the liquefaction behavior of sandy soils remains less well understood. This study investigates how the quantity and plasticity of fines affect both the susceptibility to liquefaction and the resulting failure mode. A series of stress-controlled cyclic triaxial tests were conducted on sand specimens containing varying proportions of non-plastic silt, kaolinite, and bentonite. Specimens were prepared at a constant relative density with fines content ranging from 0% to 37%. Two liquefaction modes were examined: flow liquefaction, characterized by sudden and large strains under undrained conditions, and cyclic mobility, which involves gradual strain accumulation without complete strength loss. The results revealed a clear relationship between soil plasticity and liquefaction mode. Specimens containing non-plastic fines or fines with a liquid limit (LL) below 20% and a plasticity index (PI) of 0 exhibited flow liquefaction. In contrast, specimens with LL > 20% and PI ≥ 7% consistently displayed cyclic mobility behavior. These findings help reconcile the apparent contradiction between laboratory studies, which often show increased liquefaction susceptibility with plastic fines, and field observations, where clayey soils frequently appear non-liquefiable. The study emphasizes the critical role of plasticity in determining liquefaction type, providing essential insight for seismic risk assessments and design practices involving fine-containing sandy soils. Full article

The emphasis on sustainable and environmentally friendly practices in geotechnical engineering has generated interest in alternative soil stabilizing techniques. The present study examines the application of xanthan gum (XG) and guar gum (GG) to enhance the strength of a sand–bentonite composite and explore their potential for use as landfill liners or impervious barriers. The mixtures, consisting of 25% bentonite and 75% sand, were treated with XG and GG concentrations of different percentages (0.5%, 1%, 2%, and 3% by dry mass). The test results indicated that a 2% addition was optimal for both biopolymers. Using this optimum value of XG and GG significantly increased the unconfined compressive strength (UCS) by almost 3-fold compared to the strength of untreated samples. Meanwhile, XG demonstrated a slightly higher impact on strength attributed to its robust gel-forming and binding properties. Comparisons between the two biopolymers highlighted XG’s superior performance, with UCS improvements of up to 20% over GG-treated samples. These results underscore the potential of biopolymers as effective, sustainable alternatives to traditional stabilizers, providing both mechanical enhancements and environmental benefits. The present study contributes valuable insights into green soil stabilization techniques, supporting the development of more sustainable construction practices. Fourier Transform Infrared Spectroscopy (FTIR) was conducted to analyze the chemical interactions between sand–bentonite mixtures and biopolymers, which possibly provide insights into the bonding mechanisms responsible for the observed improvements in mechanical and volumetric behavior. Full article

Molding sand mixtures in the foundry industry are typically composed of fresh and reclaimed sands, water, and additives such as bentonite. Optimizing the control of these mixtures and the recycling of used sand after casting requires an efficient in-line monitoring method, which is currently unavailable. This study explores the potential of an AI-enhanced electrical impedance spectroscopy (EIS) system as a solution. To establish a fundamental dataset, we characterized various sand mixtures containing quartz sand, bentonite, and deionized water using EIS in the frequency range from 20 Hz to 1 MHz under laboratory conditions and also measured the water content and density of samples. Principal component analysis was applied to the EIS data to extract relevant features as input data for machine learning models. These features, combined with water content and density, were used to train regression models based on fully connected neural networks to estimate the bentonite content in the mixtures. This led to a high prediction accuracy (R² = 0.94). These results demonstrate that AI-enhanced EIS has promising potential for the in-line monitoring of bulk material in the foundry industry, paving the way for optimized process control and efficient sand recycling. Full article

In the first part of this publication, selected technological and strength properties of synthetic molding sand bound with sodium bentonite with the addition of a new lustrous carbon carrier (R_c^w, R_m^w, R_k, W_f, P^w, Z, P_D, P_S, S_LS, ρ₀) were determined. The introduction of polyethylene as a substitute for hydrocarbon resin, and shungite as a replacement for coal dust, demonstrated the achievement of an optimal molding sand composition for practical use in casting technology. The sand containing a new lustrous carbon carrier (SH/PE) demonstrates the highest permeability and flowability. Based on the analysis of the obtained results, it should be concluded that to achieve the desired level of the measured properties in the sand with the mixture of precursors SH/PE, the moisture content should be in the range of 1.5% to 1.7%. Full article

The ground surface and subsurface of green parks in arid and desert areas may be subjected to desiccation as a result of weather and hot temperatures. It is not wise to wait until plants are turning pale and yellow before watering is resumed. Given the scarcity of water in typical desert zones, we recommend full control of irrigation water. This study presents a method of recycling irrigation water using 5TE sensors, employing time-domain reflectometry (TDR) technology. A trial test section was constructed along the coast of the eastern province of Saudi Arabia. Water recycling involves using clay–sand liners placed below the top agricultural soils to intercept excess water and direct it towards a collection tank, and then it is pumped out to a major water supply tank. The main properties of soils and clay–sand liners normally taken into account include moisture content, density, and hydraulic conductivity. An assessment of geotechnical properties of clay–sand mixtures containing 20% clay content was conducted. The profiles of moisture and temperature changes were monitored using 5TE sensors and data loggers. The 5TE sensors provided continuous measurements at varying temperatures and watering cycles. Twenty-nine watering cycles were conducted over a six-month period. An additional section was considered with a liner consisting of the same clay but enhanced with bentonite as one-third of the clay content. The volumetric water content was found to vary from 0.150 to 0.565 following changing weather and direct watering cycles. The results indicated that the use of a TDR instrumentation is a cost-effective and time-saving technique to construct a system for saving irrigation water. Full article

Molding sand mixtures used in the foundry industry consist of various sands (quartz sands, chromite sands, etc.) and additives such as bentonite. The optimum control of the processes involved in using the mixtures and in their regeneration after the casting requires an efficient in-line monitoring method that is not available today. We are investigating whether such a method can be based on electrical impedance spectroscopy (EIS). To establish a database, we have characterized various sand mixtures by EIS in the frequency range from 0.5 kHz to 1 MHz under laboratory conditions. Attempts at classifying the different molding sand mixtures by support vector machines (SVM) show encouraging results. Already high assignment accuracies (above 90%) could even be improved with suitable feature selection (sequential feature selection). At the same time, the standard uncertainty of the SVM results is low, i.e., data assigned to a class by the presented SVMs have a high probability of being assigned correctly. The application of EIS with subsequent evaluation by machine learning (machine-learning-enhanced EIS, MLEIS) in the field of bulk material monitoring in the foundry industry appears possible. Full article

Trafficability gives tracked vehicles adaptability, stability, and propulsion for various purposes, including deep-sea research in rough terrain. Terrain characteristics affect tracked vehicle mobility. This paper investigates the soil mechanical interaction dynamics between rubber-tracked vehicles and sedimental soils through controlled laboratory-simulated experiments. Focusing on Bentonite and Diatom sedimental soils, which possess distinct shear properties from typical land soils, the study employs innovative user-written subroutines to characterize mechanical models linked to the RecurDyn simulation environment. The experiment is centered around a dual-tracked crawler, which in itself represents a fully independent vehicle. A new three-dimensional multi-body dynamic simulation model of the tracked vehicle is developed, integrating the moist terrain’s mechanical model. Simulations assess the vehicle’s trafficability and performance, revealing optimal slip ratios for maximum traction force. Additionally, a mathematical model evaluates the vehicle’s tractive trafficability based on slip ratio and primary design parameters. The study offers valuable insights and a practical simulation modeling approach for assessing trafficability, predicting locomotion, optimizing design, and controlling the motion of tracked vehicles across diverse moist terrain conditions. The focus is on the critical factors influencing the mobility of tracked vehicles, precisely the sinkage speed and its relationship with pressure. The study introduces a rubber-tracked vehicle, pressure, and moisture sensors to monitor pressure sinkage and moisture, evaluating cohesive soils (Bentonite/Diatom) in combination with sand and gravel mixtures. Findings reveal that higher moisture content in Bentonite correlates with increased track slippage and sinkage, contrasting with Diatom’s notable compaction and sinkage characteristics. This research enhances precision in terrain assessment, improves tracked vehicle design, and advances terrain mechanics comprehension for off-road exploration, offering valuable insights for vehicle design practices and exploration endeavors. Full article

In recent years, because of the continuous expansion of urban areas, an increased necessity to isolate historically polluted sites by means of artificial, flexible, low-permeability barriers has emerged. Moreover, due to cost and efficiency considerations, various combinations of materials that fulfill the previously stated requirements have been proposed. On the basis of a literature review, this paper analyses the relationships between water, cement, and bentonite, and the physical and mechanical properties of the resulting material created in combination with standard sand introduced in the mixture using a ratio of 2:1 with respect to the solid part of the mixture (cement and bentonite). The quantity of standard sand was established following previous research conducted by the authors. The relation between water, cement, and bentonite is analyzed through properties such as viscosity, permeability, and undrained cohesion, and the representation of mixtures and their corresponding parameters was carried out using a ternary diagram. This paper provides a graphical approach to finding the optimum water/bentonite/cement mixture required for barrier design, taking into account permeability, undrained cohesion, and mixture viscosity. Full article

A typical deep geological repository (DGR) design consists of a multi-barrier system, including the natural host rock and the engineered barrier system. Understanding the swelling behavior of bentonite-based sealing materials (BBSM), as a candidate material for the engineered barrier system, is crucial for DGR’s long-term safety. In this study, a hydromechanical (HM) column-type test was designed to model the hydration of BBSM from the underground water and determine the resulting swelling pressure in vertical and radial directions. Five hydration tests were carried out on identical compacted samples of 70% bentonite and 30% sand (70-30 bentonite-sand) mixtures with a dry density of 1.65 g/cm³ for varied durations of hydration, between 1 day and 120 days. The experiments were performed parallel to the compaction direction. Following each HM column-type test, the advancement of the wetting front was determined for each test. After 120 days, 56,339 mm³ of water infiltrated the sample and the wetting front reached over 50% of the sample height. The evolution of axial swelling pressure revealed an initial increase in swelling pressure with time in all tests, followed by a reduction in the rate at later times. After early stages of swelling, radial sensors showed an increase in swelling pressure. After 120 days, the radial pressure sensor closest to the hydration front showed 52% more radial pressure than the axial swelling pressure. Full article

A method to predict the swellability of clay-sand mixtures is proposed. This model is a modified form of the Studds (1997) prediction model for clay-sand mixtures. The new proposed model uses the laboratory fall cone penetration technique to produce a characterization chart. This chart presents slope levels that can be used to obtain an equation for the final clay void ratio versus the vertical effective stress for clays. The porosity of the clay-sand mixtures was worked out based on a correction factor obtained from compression and porosity measurements in the laboratory. The porosity of the mixture was merged into the clay profile equation to compute the final clay void ratio at a specified stress level, which made it possible to predict the swelling behavior for different and variable stress levels. The swellability slope was obtained using fall cone tests conducted on the fine portion. Mixtures of kaolinite and bentonite were introduced to represent soils with different swell potentials. The fall cone measurements of a few points can be used to establish the swellability relationships for natural clay. Merging fall cone points with the swellability slope chart can define the profile of the vertical effective stress versus the clay void ratio. Full article

With the growing demands of human beings, sanitary landfill, along with the increase in landfill depth and leachate water pressure, has put forward new and higher requirements for the impermeable layer. In particular, it is required to have a certain adsorption capacity of harmful substances from the perspective of environmental protection. Hence, the impermeability of polymer bentonite–sand mixtures (PBTS) at different water pressure and the adsorption properties of polymer bentonite (PBT) on contaminants were investigated through the modification of PBT using betaine compounded with sodium polyacrylate (SPA). It was found that the composite modification of betaine and SPA could reduce the average particle size of PBT dispersed in water (reduced to 106 nm from 201 nm) and enhance the swelling properties. As the content of SPA increased, the hydraulic conductivity of PBTS system decreases and the permeability resistance improves, while the resistance to external water pressure increases. It is proposed a concept of the potential of osmotic pressure in a constrained space to explain the impermeability mechanism of PBTS. The potential of osmotic pressure obtained by linear extrapolation of the trendline of colloidal osmotic pressure versus mass content of PBT could represent the external water pressure that the PBT resist. Additionally, the PBT also has a high adsorption capacity for both organic pollutants and heavy metal ions. The adsorption rate of PBT was up to 99.36% for phenol; up to 99.9% for methylene blue; and 99.89%, 99.9%, and 95.7% for low concentrations of Pb²⁺, Cd²⁺, and Hg⁺, respectively. This work is expected to provide strong technical support for the future development in the field of impermeability and removal of hazardous substances (organic and heavy metals). Full article

In this work the adsorption and immobilization of copper ions of four different Technosols constructed with wastes were tested. These soils were made from mixtures of limestone wastes, organic matter, sand, and bentonite. The methods used were “batch” and columns experiments, where the soils were in contact with a Copper (Cu) rich solution for 24 h and afterwards for 24-weeks. Total concentration of adsorbed Cu, sequential extraction in the Technosols and Cu concentration in the leachates were evaluated. The results showed that the Technosols have high efficiency to rapidly immobilize Cu ions, and the percentage of adsorption varied between 87 and 99% in the batch experiment after 24 h. The sequential extraction showed that the materials used in the construction of technosols demonstrated high affinity for the metal, especially the carbonates and organic matter, which adsorbed 14–16% and 10–16% respectively of total Cu added via solution. However, most of the adsorbed Cu was found in the residual fraction (50–64%), which represented the less labile form of Cu. These results demonstrate that in addition to adsorb great part of the Cu added via solution, the Technosols immobilize Cu in a highly stable form, representing a great option for the reclamation of contaminated-Cu areas. However, the decrease in pH with time (24 weeks) showed a strong influence on the adsorption of Cu in Technosols, influencing the amount of leached copper. We therefore recommend the design of Technosols with limestone wastes, bentonite, and organic matter with periodical control of pH for fast and efficient retention of Cu. Full article

A series of studies related to the production of organobentonite, i.e., bentonite-poly(acrylic acid), and its use as a matrix grain-binding material in casting moulding sand is presented. In addition, a new carbon additive in the form of shungite was introduced into the composition of the moulding sand. Selected technological and strength properties of green sand bond with the obtained organobentonite with the addition of shungite as a new lustrous carbon carrier ($R_c^w$, $R_m^w$, $P^w$, $P^w$, $P_D$) were determined. The introduction of shungite as a replacement for coal dust in the hydrocarbon resin system demonstrated the achievement of an optimum moulding sand composition for practical use in casting technology. Using chromatographic techniques (Py-GC/MS, GC), the positive effect of shungite on the quantity and quality of the gaseous products generated from the moulding sand during the thermal destruction of its components was noted, thus confirming the reduced environmental footprint of the new carbon additive compared to the commonly used lustrous carbon carriers. The test casting obtained in the mould of the organobentonite moulding sand and the shungite/hydrocarbon resin mixture showed a significantly better accuracy of the stepped model shape reproduction and surface smoothness compared to the casting obtained with the model moulding sand. Full article

This article presents experimental research focusing on the structural failure of the central core of a rockfill dam using sand-bentonite mixtures. It comprised an extensive geotechnical characterization of soil materials and mixtures, including compaction and strength tests, as well as the construction of 1 m high and 1.5 m wide physical models. The displacements of the cohesive cores were recorded using a tailored measuring system, based on a laser pointer and a mirror, designed to amplify the real displacements. The cohesive cores were extremely sensitive to small oscillations and behaved as rigid bodies, similar to concrete slabs with three fixed sides and another free. The shape and dimensions of the breach formed on the cohesive cores had roughly the same shape and dimensions as the unprotected area. This experimental research has the potential to be used as validation tool for several models available in the literature to predict the failure of embankment dams. Full article

The ASTM D6951 suggests a test method using the dynamic cone penetrometer (DCP) for the assessment of shallow pavement strength. This study is dedicated to evaluating a similar test method to be used for fine-grained clay–sand mixtures, which are commonly used to construct liners and fluid barriers. The liner layers include clay, which is water-sensitive. The shear strength of the liners depends mainly on the composition and proportions of the mixtures adopted. A series of tests were conducted in the laboratory for compacted clay–sand mixtures, including 5% and 10% bentonite material. The responses to advancing a dynamic probe into compacted material at three various moisture conditions—namely, the optimum, dry of optimum, and wet of optimum water contents—are investigated. The penetration profiles are compared for the two clay content levels selected and for three moisture state conditions. The clay–sand liners support vehicles and vibratory compactors during construction and when waste material is placed. The shear strengths of the mixtures are evaluated in the laboratory using direct shear tests. From the results obtained in this investigation, general guidelines and recommendations are presented to help with the efficient assessment of liners consisting of clay–sand mixtures. A cheap and quick approach to assess the density and shear strength of landfill liners or clay–sand layers can be achieved using a hand-held dynamic cone penetrometer. The state of moisture during compaction was found to influence the DCP results. The compaction of layers in a wet of optimum state is not expected to be an ideal alternative. Full article
