Search Results (32)

Air-shielding radial ultrasonic rolling electrochemical micromachining (AS-RUREMM) is proposed to fabricate high-quality micro-dimple textures on cylindrical SS304 surfaces while suppressing stray corrosion. In AS-RUREMM, an annular air sheath coaxially envelopes the electrolyte jet to confine the wetting footprint, and radial ultrasonic vibration is superimposed on a rolling cathode with micro-protrusions to intensify local mass transport and stabilize the interelectrode environment. A conductivity-centered theoretical framework is established to link air-sheathing-induced gas–liquid distribution, ultrasonic gap modulation, and the resulting current-density localization. Multiphysics simulations in COMSOL 5.3 clarify that moderate air pressure forms a stable confined gas–liquid structure that narrows the effective conductive pathway, whereas excessive air pressure increases intermittency and weakens effective gap conductivity. Experiments on SS304 tubes validate the confinement mechanism: compared with RUREMM, AS-RUREMM produces smaller pit width and depth but a higher depth-to-width ratio, indicating enhanced localization and reduced peripheral over-etching. The simulated cross-sectional profiles agree with measurements, with an overall deviation within 6%. Parameter studies identify an optimal operating window, and the combination of 0.18 MPa air pressure and 12 V pulse voltage provides the highest aspect ratio while maintaining stable machining. SEM/EDX analyses further support the improved process controllability under air shielding through reduced stray corrosion and composition changes consistent with a more regulated electrochemical dissolution environment. Full article

This study investigates a metal-contact etching process that differs from conventional device contact etching by focusing on the film-stack configuration and the associated super-contact etching characteristics. Because metal-contact etching is closely linked to both physical profiles and electrical performance, evaluating a single parameter provides limited insight; thus, the physical profile characteristics of metal-contact etching and 3D-integrated super-contacts were comprehensively examined. In the first-step etch, the target depth in the wafer left region was approximately 2365 Å, and the bottom surface exhibited a desirable rounded profile. Following the removal of liner TEOS and nitride, the stopping margin was evaluated under three conditions: (1) metal-contact etching with a ~22 s target reduction, (2) a CMOS image-sensor baseline incorporating an interlayer-dielectric-reduction scheme, and (3) a high-selectivity condition achieved by increasing the C₅F₈/O₂ ratio with a reduced etch target. Under all three conditions, the bit-line contact (BLC) nitride experienced punch-through. To address this limitation, a three-step etch sequence was implemented, in which the first two steps achieved the required etch depth and the final step utilized a high-selectivity over-etch to secure a sufficient stopping margin. This approach demonstrated robust process windows, favorable CD control, and reliable nitride stopping performance, thereby establishing a practical methodology for stable super-contact etching in advanced 3D-integrated logic applications. Full article

Background: Adhesion to enamel is influenced by surface preparation, which affects the micromechanical retention of resin-based materials. Sodium hypochlorite (NaOCl) deproteinization has been proposed as a pretreatment to improve acid etching efficacy, but the optimal application time remains unclear. Methods: This in vitro study evaluated the effect of 5% NaOCl pretreatment at three exposure times (15, 30, and 60 s) on shear bond strength (SBS), the adhesive remnant index (ARI), and enamel etching patterns. Extracted human premolars (n = 140) were divided into four groups: the control (acid etching only) and three experimental groups. SBS was tested per ISO 11405, while ARI scores were assessed under stereomicroscopy, and surface morphology was examined by scanning electron microscopy (SEM). Results: The 30-s NaOCl group exhibited the highest SBS (20.9 MPa) compared with the control (15.9 MPa, p < 0.05) and 15-s (14.9 MPa, p < 0.05) groups. SEM analysis showed predominantly Type I–II etching patterns for the 30-s group, irregular Type III for 15 s, and overetched Type IV with loss of prism definition for 60 s, compromising the adhesive interface. ARI scores indicated 86.7% of samples in the 30-s group retained all adhesive on enamel (score 3). Conclusions: A 30-s 5% NaOCl pretreatment before acid etching improved enamel micromorphology and bonding performance compared to shorter or longer exposures. The intermediate duration provided effective deproteinization without structural damage, whereas prolonged exposure degraded the enamel microstructure. This protocol may offer a simple, cost-effective method to enhance clinical adhesive procedures, though prolonged exposure (60 s) should be avoided due to structural degradation of the enamel microstructure. Full article

Actuating monolithic photonic components (particularly slab waveguides) requires higher force due to their inherent stiffness. However, two primary constraints must be addressed: actuator footprint and fabrication limits. Increasing the number of fingers to provide the required force is not a viable solution due to space constraints, and we must also adhere to the process design kits of standard fabrications and respect their design limits. Therefore, it is crucial to increase the actuator force output without significantly enlarging the actuator footprint while maintaining the necessary travel range. In order to achieve this, we utilize arrays of electrostatic comb drives, with each repeating cell geometry optimized to produce the highest force per actuator footprint. Our optimization strategy focuses on finger geometry, the arrangement of fingers and arms design in the comb structure, including the number of fingers per arm and arm length, ensuring that each repeating cell delivers maximum force per unit area or force intensity. Co-optimizing a repeatable, footprint-optimized comb-array unit cell (arm length, arm width, finger pitch, finger count) and validating it against an asymmetric slab waveguide load, we reach a maximum pre-pull-in force intensity of about 342 N m⁻² at 70 V with about 6 µm travel, confirmed by analytical modeling, numerical simulation, and measurement. Despite fabrication challenges such as over-etching and variations in electrode dimensions, detailed SEM analyses and correction functions ensure that the theoretical models closely match the experimental data, confirming the robustness and accuracy of the design. These optimized actuators, capable of achieving substantial force output without sacrificing travel range or mechanical stability, are particularly effective for applications in optical beam steering for in-plane silicon-photonics and related optical microsystems applications. Full article

Background: This study investigated a new multi-acid-etching formulation for zirconia ceramics, containing hydrochloric, hydrofluoric, nitric, orthophosphoric, and sulfuric acids. The solution was tested on polycrystalline (5Y-TZP zirconia), lithium disilicate, hybrid ceramic, and feldspathic porcelain to assess compatibility, etching selectivity, and surface conditioning. Methods: Two-hundred-and-forty CAD/CAM specimens were etched for 20 s, 60 s, 30 min, or 1 h, and their surface roughness and etching patterns ware evaluated using 3D optical profilometry and scanning electron microscopy (SEM). Results: A positive correlation was observed between etching time and surface roughness (Ra values). The most pronounced changes were observed in lithium disilicate and feldspathic porcelain, with Ra values increasing from 0.733 ± 0.082 µm (Group 5) to 1.295 ± 0.123 µm (Group 8), and from 0.902 ± 0.102 µm (Group 13) to 1.480 ± 0.096 µm (Group 16), respectively. Zirconia increased from 0.181 ± 0.043 µm (Group 1) to 0.371 ± 0.074 µm (Group 4), and the hybrid ceramic from 0.053 ± 0.008 µm (Group 9) to 0.099 ± 0.016 µm (Group 12). Two-way ANOVA revealed significant effects of material and etching time, as well as a significant interaction between the two factors (p < 0.001). SEM observation revealed non-selective etching pattern for the lithium disilicate groups, indicating a risk of over-etching. Conclusions: The tested etching solution increased surface roughness, especially for the lithium disilicate and feldspathic porcelain specimens. In zirconia, one-hour etching improved surface characteristics with minimal observable damage. However, additional studies are necessary to validate the mechanical stability and bond effectives of this approach. Full article

Laser marking on wafers can introduce various defects such as inconsistent mark quality; under- or over-etching, and misalignment. Excessive laser power and inadequate cooling can cause burning or warping. These defects were inspected using machine vision, confocal microscopy, optical and scanning electron microscopy, acoustic/ultrasonic methods, and inline monitoring and coaxial vision. Machine learning has been successfully applied to improve the classification accuracy, and we propose a random forest algorithm with a training database to not only detect the defect but also trace its cause. Four causes have been identified as follows: unstable laser power, a dirty laser head, platform shaking, and voltage fluctuation of the electrical power. The object-matching technique ensures that a visible image can be utilized without a precise location. All inspected images were compared to the standard (qualified) product image pixel-by-pixel, and then the 2D matrix pattern for each type of defect was gathered. There were 10 photos for each type of defect included in the training to build the model with various labels, and the synthetic testing images altered by the defect cause model for laser marking defect inspection had accuracies of 97.0% and 91.6% in sorting the error cause, respectively Full article

The current investigation evaluated a novel acid-etching solution containing hydrochloric acid (HCl), hydrofluoric acid (HF), nitric acid (HNO₃), orthophosphoric acid (H₃PO₄), and sulfuric acid (H₂SO₄) designed for etching zirconia ceramics. Achieving reliable bonding to zirconia is challenging due to its chemical inertia, unlike lithium disilicate, which can be effectively conditioned with HF etching. One hundred and twenty specimens of zirconia and lithium disilicate underwent etching with the experimental solution for six different durations: control, 20 s, 60 s, 5 min, 30 min, and 1 h. Surface roughness was assessed using 3D optical profilometry and scanning electron microscopy (SEM). The roughness of both materials increased with etching time; however, lithium disilicate demonstrated a significantly greater response, with Ra values rising from 0.18 µm (control) to 1.26 µm (1 h), while zirconia increased from 0.21 µm to 0.60 µm. ANOVA revealed significant effects depending on the ceramic type, time, and their interaction (p < 0.001). SEM images revealed non-selective etching of lithium disilicate, suggesting potential over-etching. The novel acid-etching solution improved surface roughness, especially in lithium disilicate ceramics. An application duration of one hour appears optimal for zirconia, improving surface characteristics while reducing damage; however, further research is required to assess its clinical safety and long-term effects on the mechanical properties of this dental ceramic. Full article

Conventional etchants for multi-metal/alloy stacked structures often suffer from nonuniform etching, residual layers, or undercutting, failing to meet high-generation production standards. This study presents a stable copper-molybdenum (Cu-Mo) etchant with extended bath life for thin film transistor liquid crystal display (TFT-LCD) applications, achieved through compositional optimization. Systematic investigations have been conducted on the effects of etching time, copper ion (Cu²⁺) loading (bath life) and storage time on the etch performance, alongside evaluations of sudden-eruption point and material compatibility. Results demonstrate that over-etching beyond the “detected endpoint” by 10% to 90% maintains critical dimension (CD) bias and taper angle of MoNiTi(MTD)/Cu/MTD three-layer and Cu/MTD two-layer within process specifications, as well as the difference between the CD bias of the three-layer and two-layer structures at the same over-etch time. The optimized formulation exhibits a 20% broader process window and 20% longer bath life compared to the process-of-record (POR) etchant. Shelf stability exceeds 15 days with minimal performance degradation, while maintaining compatibility with industrial equipment materials. These advancements address key challenges in high-precision etching for advanced TFT-LCD manufacturing, providing a scalable solution for next-generation display production. Full article

On the way toward MEMS miniaturization, the quantification of geometric uncertainties stands as a primary challenge. In this paper, an approach that combines genetic algorithms and proper orthogonal decomposition with kriging surrogate modeling was proposed to accurately predict over-etch measures through an on-chip test device. Despite being fabricated on a single wafer under nominally identical manufacturing conditions, MEMS can display different responses under the same actuation, due to a different characteristic geometry. It is shown that the uncertainties, given in terms of over-etch values, were not only different from die to die but also within the same die, depending on the local geometric features of the device. Therefore, the proposed method provided an alternative solution to estimate the uncertainties in MEMS devices, relying only on the capacitance–voltage response. A statistical analysis was carried out based on a batch of devices tested in the laboratory. These tests and the estimation procedure allowed us to quantify the mean values of the over-etch relative to the target as +12.2 % at comb fingers, +10.0 % at the supporting springs, and −4.8 % at stoppers, showing noteworthy variability induced by the environment. Full article

The ability to manufacture complex 3D structures with nanometer-scale resolution, such as Fresnel Zone Plates (FZPs), is crucial to achieve state-of-the-art control in X-ray sources for use in a diverse range of cutting-edge applications. This study demonstrates a novel approach combining Electron Beam Lithography (EBL) and cryoetching to produce silicon-based FZP prototypes as a test bench to assess the strong points and limitations of this fabrication method. Through this method, we obtained FZPs with 100 zones, a diameter of 20 µm, and an outermost zone width of 50 nm, resulting in a high aspect ratio that is suitable for use across a range of photon energies. The process incorporates a chromium mask in the EBL stage, enhancing microstructure precision and mitigating pattern collapse challenges. This minimized issues of under- and over-etching, producing well-defined patterns with a nanometer-scale resolution and low roughness. The refined process thus holds promise for achieving improved optical resolution and efficiency in FZPs, making it viable for the fabrication of high-performance, nanometer-scale devices. Full article

The electro-thermal performance of silicon nanosheet field-effect transistors (NSFETs) with various parasitic bottom transistor (tr_pbt)-controlling schemes is evaluated. Conventional punch-through stopper, trench inner-spacer (TIS), and bottom oxide (BOX) schemes were investigated from single-device to circuit-level evaluations to avoid overestimating heat’s impact on performance. For single-device evaluations, the TIS scheme maintains the device temperature 59.6 and 50.4 K lower than the BOX scheme for n/pFETs, respectively, due to the low thermal conductivity of BOX. However, when the over-etched S/D recess depth (T_SD) exceeds 2 nm in the TIS scheme, the RC delay becomes larger than that of the BOX scheme due to increased gate capacitance (C_gg) as the T_SD increases. A higher TIS height prevents the C_gg increase and exhibits the best electro-thermal performance at single-device operation. Circuit-level evaluations are conducted with ring oscillators using 3D mixed-mode simulation. Although TIS and BOX schemes have similar oscillation frequencies, the TIS scheme has a slightly lower device temperature. This thermal superiority of the TIS scheme becomes more pronounced as the load capacitance (C_L) increases. As C_L increases from 1 to 10 fF, the temperature difference between TIS and BOX schemes widens from 1.5 to 4.8 K. Therefore, the TIS scheme is most suitable for controlling tr_pbt and improving electro-thermal performance in sub-3 nm node NSFETs. Full article

A wet-etching technique based on a mixture of hydrochloric (HCl) and nitric (HNO₃) acids is introduced, demonstrating exceptional 42:1 selectivity for etching N-polar GaN over Al_0.24Ga_0.76N. In the absence of an AlGaN etch stop layer, the etchant primarily targets N-polar unintentionally doped (UID) GaN, indicating its potential as a suitable replacement for selective dry etches in the fabrication of GaN high-electron-mobility transistors (HEMTs). The efficacy and selectivity of this etchant were confirmed through its application to a gate recess module of a deep-recess HEMT, where, despite a 228% over-etch, the 2.6 nm AlGaN etch stop layer remained intact. We also evaluated the proposed method for the selective etching of the GaN cap in the n+ regrowth process, achieving a contact resistance matching that of a BCl₃/SF₆ ICP process. These findings underscore the applicability and versatility of the etchant in both the electronic and photonic domains and are particularly applicable to the development of N-polar deep-recess HEMTs. Full article

Anode bonding is a widely used method for fabricating devices with suspended structures, and this approach is often combined with deep reactive-ion etching (DRIE) for releasing the device; however, the DRIE process with a glass substrate can potentially cause two critical issues: heat accumulation on the suspended surface and charging effects resulting from the reflection of charged particles from the glass substrate. In particular, for torsional bars with narrow widths, the heat accumulated on the suspended surface may not dissipate efficiently, leading to photoresist burning and, subsequently, resulting in the fracture of the torsional bars; moreover, once etching is finished through the silicon diaphragm, the glass surface becomes charged, and incoming ions are reflected towards the back of the silicon, resulting in the etching of the back surface. To address these issues, we proposed a method of growing silicon oxide on the back of the device layer. By designing, simulating, and fabricating electrostatic torsional micromirrors with common cavity silicon-on-glass (SOG) structures, we successfully validated the feasibility of this approach. This approach ensures effective heat dissipation on the suspended surface, even when the structure is over-etched for an extended period, and enables the complete etching of torsional bars without adverse effects due to the overheating problem; additionally, the oxide layer can block ions from reaching the glass surface, thus avoiding the charging effect commonly observed in SOG structures during DRIE. Full article

The proton exchange membrane water electrolyzer (PEMWE) requires a high operating voltage for hydrogen production to accelerate the decomposition of hydrogen molecules so that the PEMWE ages or fails. According to the prior findings of this R&D team, temperature and voltage can influence the performance or aging of PEMWE. As the PEMWE ages inside, the nonuniform flow distribution results in large temperature differences, current density drops, and runner plate corrosion. The mechanical stress and thermal stress resulting from pressure distribution nonuniformity will induce the local aging or failure of PEMWE. The authors of this study used gold etchant for etching, and acetone was used for the lift-off part. The wet etching method has the risk of over-etching, and the cost of the etching solution is also higher than that of acetone. Therefore, the authors of this experiment adopted a lift-off process. Using the flexible seven-in-one (voltage, current, temperature, humidity, flow, pressure, oxygen) microsensor developed by our team, after optimized design, fabrication, and reliability testing, it was embedded in PEMWE for 200 h. The results of our accelerated aging test prove that these physical factors affect the aging of PEMWE. Full article

The voltage, current, temperature, humidity, pressure, flow, and hydrogen in the high-pressure proton exchange membrane water electrolyzer (PEMWE) can influence its performance and life. For example, if the temperature is too low to reach the working temperature of the membrane electrode assembly (MEA), the performance of the high-pressure PEMWE cannot be enhanced. However, if the temperature is too high, the MEA may be damaged. In this study, the micro-electro-mechanical systems (MEMS) technology was used to innovate and develop a high-pressure-resistant flexible seven-in-one (voltage, current, temperature, humidity, pressure, flow, and hydrogen) microsensor. It was embedded in the upstream, midstream, and downstream of the anode and cathode of the high-pressure PEMWE and the MEA for the real-time microscopic monitoring of internal data. The aging or damage of the high-pressure PEMWE was observed through the changes in the voltage, current, humidity, and flow data. The over-etching phenomenon was likely to occur when this research team used wet etching to make microsensors. The back-end circuit integration was unlikely to be normalized. Therefore, this study used lift-off process to further stabilize the quality of the microsensor. In addition, the PEMWE is more prone to aging and damage under high pressure, so its material selection is very important. Full article
