Search Results (36)

This paper presents an experimental and numerical investigation of continuous reinforced concrete (RC) beams made of self-compacting concrete (SCC) strengthened with fiber-reinforced polymer (FRP) bars using the Near-Surface Mounted (NSM) method. While the majority of previous studies have focused on simply supported beams, this work examines two-span continuous beams, which are more representative of real structural behavior. Four SCC beams were tested under static loading to evaluate the influence of the FRP reinforcement position on flexural capacity and deformational characteristics. The beams were strengthened using glass FRP (GFRP) bars embedded in epoxy adhesive within pre-cut grooves in the concrete cover. Experimental results showed that FRP reinforcement significantly increased the ultimate load capacity, while excessive reinforcement reduced ductility, leading to a more brittle failure mode. A three-dimensional finite element model was developed in Abaqus/Standard using the Concrete Damage Plasticity (CDP) model to simulate the nonlinear behavior of concrete and the bond–slip interaction at the epoxy–concrete interface. The numerical predictions closely matched the experimental load–deflection responses, with a maximum deviation of less than 3%. The validated model provides a reliable tool for parametric analysis and can serve as a reference for optimizing the design of continuous SCC beams strengthened by the NSM FRP method. Full article

The embedded through-section (ETS) technique is a promising method for fiber-reinforced polymer (FRP)-strengthening reinforced concrete (RC) structures, offering higher bond resistance and reduced surface preparation compared to externally bonded or near-surface mounted FRP systems. A common failure in ETS applications is debonding at the FRP bar-to-concrete interface. However, current design standards often assume uniform bond stress and lack predictive models that account for debonding propagation and its effect on load capacity. Furthermore, a detailed analysis of interfacial stress development, including debonding initiation and progression along varying bond lengths, remains limited. To address these gaps, this study introduces an analytical model that describes the complete debonding process in ETS FRP bar-to-concrete joints, incorporating both long and short bond lengths and frictional effects. Based on a trilinear cohesive material law (CML), closed-form expressions are deduced for the load–slip response, maximum load, interfacial shear stress and strain distribution along the FRP bar. The proposed model is validated experimentally through pull-out tests on glass FRP (GFRP) bars adhesively bonded to concrete with different strength grades. The results show that the analytical predictions agree well with both the self-conducted experimental data for short joints and existing test results for long joints given in the literature. Therefore, the developed design-oriented solution enables accurate evaluation of the actual contribution of ETS FRP reinforcement to RC members by explicitly modeling debonding behavior. This provides a rigorous and mechanics-based tool for performance-based design of ETS FRP-to-concrete joints, addressing a critical gap in the future refinement of current design standards. Full article

Strain monitoring during the service life of a nuclear containment structure is an effective means to evaluate whether the structure is operating safely. Due to the failure of embedded strain sensors, surface-mounted strain sensors should be installed on the outer wall of the structure. However, whether the data from these substitute sensors can reasonably reflect the internal deformation behavior requires further investigation. To ensure the feasibility of the added strain sensors, a refined 3D model of a Chinese Pressurized Reactor (CPR1000) nuclear containment structure was developed in ANSYS 19.1 to study the internal and external deformation laws during a containment test (CTT). Solid reinforcement and cooling methods were employed to simulate prestressed cables and pre-tension application. The influence of ordinary steel bars in concrete was modeled using the smeared model, while interactions between the steel liner and concrete were simulated through coupled nodes. The model’s validity was verified against embedded strain sensor data recorded during a CTT. Furthermore, concrete and prestressed material parameters were refined through a sensitivity analysis. Finally, the variation law between the internal and external deformation of the containment structure was investigated under typical CTT loading conditions. Strain values in the wall thickness direction exhibited an essentially linear relationship. Near the equipment hatch, however, the strain distribution pattern was significantly influenced by the spatial arrangement of prestressed cables. Refined FEM and sensor systems are vital containment monitoring tools. Critically, surface-mounted strain sensors offer a feasible approach for inferring internal stress states and deformation behavior. This study provides theoretical support and a technical foundation for the safe assessment and maintenance of nuclear containment structures during operational service. Full article

Strengthening lapped spliced reinforced concrete (RC) beams using tiny-diameter steel wires as near-surface-mounted (NSM) rods has not been carried out previously. Thus, the purpose of this work is to examine the behavior of RC beams with insufficient lap splices that are strengthened by NSM steel wires with different schemes to improve durability, efficiency, and effectiveness. At the middle of the beam, a splice length equal to 25 times the diameter of the rebar was used to join two tension bars. Many different schemes were implemented in strengthening the splice region, such as attaching longitudinal wires to the sides and/or bottom of the beam in different quantities with/without end anchorage, placing perpendicular and inclined U-shaped wires at the splice region in different quantities, and implementing a network of intersecting and opposite wires in two different directions. The effect of variables on the behavior of strengthened beams was studied. The findings proved that when the longitudinal wire reinforcement-to-lapped rebars area ratio was 9.4%, 18.7%, and 28%, the ultimate load of the beams was improved by 15.71%, 71.43%, and 104.57%, respectively. When the transverse U-shaped wire reinforcement ratio was 0.036, 0.051, 0.064, 0.075, and 0.150, the ultimate load of the beams was improved by 3.7%, 20%, 31.4%, 50%, and 80%, respectively, and the ultimate deflection was enhanced by 2%, 32%, 19%, 67%, and 62.4% compared to the unstrengthened beam. Full article

The aim of this experimental study was to develop and evaluate the effectiveness of a new strengthening system for reinforced concrete slabs employing external jackets consisting of ultra-high-performance fiber-reinforced-concrete (UHPFRC) and mechanical anchor systems. The issue of debonding between old and fresh concrete layers, as well as the efficiency of utilizing CFRP rods, is the primary challenge of applying the UHPFRC jackets with embedded CFRP rods. In this study, we propose a novel retrofitting technique for implementing a mechanical anchor system to improve the binding of fresh UHPFRC jackets with old RC slabs. An experimental test was conducted by subjecting three slabs to cyclic loads by utilizing a dynamic actuator: a reference slab, a retrofitted slab with an external UHPFRC layer, and a retrofitted slab with an external UHPFRC layer incorporating CFRP bars. Furthermore, finite element models (FEMs) were utilized to investigate the responses of the retrofitted slabs and compare the novel method with traditional strengthening techniques, including near-surface-mounted (NSM) CFRP rods, externally bonded CFRP strips, and epoxy-bonded UHPFRC jackets, as well as two models that were the same as the experimental strengthened slab specimens except for the fact that they did not have a mechanical anchor system. Additionally, analytical mechanistic models were employed to determine the flexural moment capacity of the RC slabs. The experimental findings demonstrated that the proposed strengthening strategy considerably prevented premature debonding and enhanced the maximum load of retrofitted RC slabs by over 82%. Also, the FEM and analytical results are significantly consistent with the experimental outcomes. In conclusion, the newly suggested strengthening technique is a reliable system for enhancing the efficacy of slabs, effectively preventing early debonding between existing and new components. Full article

Reinforced concrete (RC) walls are mainly used in RC structures to resist gravity and lateral forces. These structural elements may need to be upgraded to withstand additional forces and extend their life cycle. Therefore, it is crucial to provide effective strengthening techniques using low-cost sustainable materials under optimal conditions to rehabilitate RC walls. This study presents an experimental and numerical investigation of reinforced normal concrete (NC) walls strengthened with near-surface mounted (NSM) steel bars, confined with or without an externally bonded reinforced (EBR) galvanized steel sheets (GSSs). A total of six RC walls were constructed, loaded, and tested to failure. The examined parameters included the type of strengthening technique, materials used, and the position and configuration of the strengthening. Both EBR and NSM techniques were applied using GSSs and steel bars, respectively. The configurations were introduced in vertical and horizontal positions to resist gravity and lateral forces, respectively. The experiments revealed that these parameters significantly influenced the crack control, energy absorption, mode of collapse, and ultimate load capacity. Nonlinear three-dimensional finite element models were developed and verified against experimental results, achieving a validation accuracy of 95% on average. This was followed by a parametric study investigating the effect of confinement with or without vertical reinforcements. Both experimental and numerical results confirmed that the strengthening could increase the ultimate load capacity from 20% to 38%. Full article

Pile splicing is generally considered in construction because of transportation limits, length requirements, construction means and methods, and strength capacity. A major challenge in the use of precast prestressed UHPC piles is the lack of efficient and effective splicing solutions. To address the problem, this study evaluated different pile splicing methods for UHPC H-piles and their constructability. The analysis and design for strength capacity and detailing presented here are based on relevant established guidelines and design codes for UHPC. This study assessed two pile splicing methods: epoxy-bonded dowels and near-surface mounted bars (NSMBs). The analysis demonstrated that the epoxy-bonded dowel method provides a moment capacity that is 127% of the pile moment capacity in the strong direction and 139% of the pile moment capacity in the weak direction. In comparison, the NSMB method achieved 121% in the strong direction and 106% in the weak direction. Both methods developed the established strength capacity requirements. The constructability of both pile splicing options was evaluated to provide practical guidelines for their preparation in preplanned and unplanned situations. The results reported are for 18-inch UHPC H-piles; however, the construction and analytical approach applies to other pile sizes as well. The pile splicing options developed are recommended for further experimental investigations. Full article

In this study, shear-critical reinforced concrete (RC) beams were strengthened by combining the prestressing and near-surface mounted (NSM) rods approaches. The potential danger of failure in such RC beams is a substantial concern as it is considered a potential threat. This study addresses its careful mitigation through experimental identification and numerical analysis to enhance the safety and sustainability of buildings by reducing the probability of failure risk for these RC beams. Nine of the ten RC beams that were tested had strengthened, and one had not. Internal prestressing (IP) within the beam body, external prestressing NSM (PNSM), internal embedment (IE) inside the beam with or without prestressing, and NSM are the strengthening technologies that were employed. The range of the extra shear reinforcement ratios (μs) was 0.87% to 1.60%. We investigated how strengthened beams behaved structurally in terms of the cracking load, ultimate load, load–deflection response, ultimate deflection, and stiffness. The insertion of five pairs of PNSM rods (μs = 1.45%) and five pairs of IP rods (μs = 1.6%), respectively, increased the beams’ shear capacity by 57.8% and 70.4%. Shear capacity increased by 23.2% when three pairs of IE rods (μs = 1.02%) were installed. The prestressing location had an impact on shear capacity, with the interior case surpassing the external one. Compared to the control, the stiffness of the strengthened beams rose by 20%, 82%, and 84.4% when three, four, or five pairs of internal prestressing rods were added. A formula is proposed to calculate the shear capacity of all beams strengthened using various methods. Full article

This paper investigates, experimentally and numerically, the shear strengthening of Normal Concrete (NC) beams using post-tensioning steel bars and Engineered Cementitious Composite (ECC) reinforced with chemically cured Palm Fronds (PFs). The benefits of strain-hardening ECC and the tensile strength of PFs cured with 6% wt Alkali NaOH solution beside post-tensioned bars have been employed herein. Seven full-scale Reinforced Concrete (RC) beams were fabricated and experimented with under three-point loading until failure. The test parameters include the strengthening technique, type, and configuration of the material used for strengthening. The strengthening process has been implemented through two techniques: Externally Bonded Reinforcement (EBR) and Near-Surface Mounted (NSM) Reinforcement. The strengthening materials have been configured and placed in horizontal, vertical, and inclined positions. The effectiveness of the strengthening methods has been evaluated by examining their cracking propagations, load-deflection responses, collapse modes, elastic stiffness, and absorbed energy. It was found that the proposed strengthening systems could significantly control the crack pattern and failure mode, and they could enhance the ultimate load amplitude up to 37% and 50% for NSM ECC with PFs and EBR post-tensioning steel bars, respectively. Nonlinear three-dimensional finite element models of the tested beams were developed and validated with the test data, where it was found that finite element models predict the structural performance of tested beams with a maximum error of only 2%. Full article

Reinforced concrete (RC) infrastructure is an essential part of modern civilization. However, the serviceability of RC infrastructure in extreme weather has become challenging due to the susceptibility of the initiation of cracks. Hence, the demand for strengthening and retrofitting RC infrastructure is rapidly increasing. The RC specimens strengthened with existing externally bonded reinforcement (EBR) and near-surface mounted (NSM) techniques; however, they suffered a prematurely brittle or debonding failure. Hence, the merging of side near surface mounting (SNSM) and side externally bonded reinforcement (S-EBR) methods ended up resulting in the development of an innovative side hybrid (SH) strengthening approach that is designed to overcome these drawbacks. In this investigation, six rectangular RC beam specimens were flexurally strengthened utilizing carbon fiber-reinforced polymer (CFRP) with the SH technique, and then four-point bending experiments were performed to failure. The beam specimens were categorized into two types: (I) control specimens and (II) specimens strengthened with the SH technique applying CFRP varying bonded length from 1600 mm to 1900 mm. The initial cracking, yield, and ultimate load-bearing capabilities, deflection, failure modes, cracking characteristics, stiffness, energy absorption capacity, and strain on the utmost fiber of concrete, the tensile strain of major steel rebars, SNSM bars, and S-EB plates were assessed from the experimental investigation. The SH technique substantially improved the flexural performance of the beam specimens. The initial cracking load, yield, and ultimate load-bearing capabilities were enhanced remarkably by 387%, 108%, and 163%, respectively, over the reference specimen. The flexural stiffness and energy absorption capacity substantially improved by 120% and 103%, respectively, compared with the reference specimen. Full article

The demand for strengthening reinforced concrete (RC) structures has increased considerably. Implementing carbon-fiber-reinforced polymer (CFRP) bars and concrete jacketing are the most effective techniques for RC beam retrofitting. Using the mechanical anchorage system (MAS) to attach CFRP bars to old concrete is highly recommended to avoid any debonding when it is applied to cyclic loads. However, the design of strengthening details is the most challenging issue because it involves many effective parameters. In this study, a design process for strengthening beams using CFRP bars with new MASs and concrete jacketing is proposed, and various design schemes are studied. The number of applied MASs and the thickness and grade of the concrete jacket were investigated through experimental testing and finite element (FE) simulations to define strengthening design details, such as the number and size of employed CFRP bars. Accordingly, an analytical technique was formulated to predict the performance of the strengthened beam in terms of the nominal ultimate load. The results demonstrated the high performance of the proposed system in preventing premature debonding. The proposed system enhances the beam capacity from 44 kN to 83 kN, representing an increase of more than 90%. In contrast, the conventional near-surface mounted (NSM) system exhibits a lower percentage increase at less than 37%. Both FE simulations and analytical approaches can be effectively employed to predict the behavior and capacity of the strengthened beam while considering various design parameters. Full article

A 3D-finite element analysis within the numerical program ABAQUS is adopted in order to simulate the seismic behavior of reinforced concrete beam-column joints and beam-column joints strengthened with CFRP ropes. The suitability of the adopted approach is investigated herein. For this purpose, experimental and numerical cyclic tests were performed. The experiments include four reinforced concrete (RC) joints with the same ratio of shear closed-stirrup reinforcement and two different volumetric ratios of longitudinal steel reinforcing bars. Two joints were tested as-built, and the other two were strengthened with CFRP ropes. The ropes were applied as Near Surface Mounted (NSM) reinforcement, forming an X-shape around the joint body and further as flexural reinforcement at the top and bottom of the beam. The purpose of the externally mounted CFRP ropes is to allow the development of higher values of concrete principal stresses inside the joint core, compared with the specimens without ropes, and also to reduce the developing shear deformation in the joint. From the results, it is concluded that X-shaped ropes reduced the shear deformation in the joint body remarkably, especially in high drifts. Further, as a result of the comparisons between the yielded outcome from the attempted nonlinear analysis and the observed response from the tests, it is deduced that the adopted method sufficiently describes the whole behavior of the RC beam-column connections. In particular, comparisons between experimental and numerical results of principal stresses developing in the joint body of all examined specimens, along with similar comparisons of force displacement envelopes and shear deformations of the joint body, confirmed the adequacy of the applied finite element approach for the investigation of the use of CFRP-ropes as an efficient and easy-to-apply strengthening technique. The findings also reveal that the connections that have been strengthened with the FRP ropes demonstrated improved performance, and the crack system preserved its load capacity during the reversal loading tests. Full article

The objective of this research was to explore the mechanical properties and failure mechanisms of reinforced concrete beams (RC beams) strengthened with near-surface mounted (NSM) glass fiber-reinforced polymer (GFRP) bars. This study focused on evaluating the effect of various factors on the load-deflection response and failure patterns of RC beams, including pre-existing damage, end anchorage, bar length, bar number, and the condition of concrete cover. The tested RC beams were divided into three groups. The first group included undamaged and damaged control beams. The second group involved the strengthening of beams after inducing damage, with variations in bar length, number, and cross-sectional area. This group also included beams strengthened by GFRP bars with and without anchors. In the third group, the effects of different cover materials, cover bonding techniques, and anchor bolts on the strengthening bars were examined. The results of the experiment indicated a notable decrease in both cracking and maximum load capacity for beams that were pre-damaged. The inclusion of anchor bolts appeared to have a noticeable effect, enhancing the load-carrying capacity and reducing mid-span deflection. Opting for two bars proved to be more effective than using three bars, leading to a higher maximum load and improved ductility. Moreover, prioritizing the bonding of the concrete cover at the end of the bars was found to be more important than bonding in the area of maximum moment. Full article

This paper aims to investigate the interface efficiency of Carbon Fiber Reinforced Polymers (CFRP) adhesively bonded on concrete, a commonly used retrofitting measure applied for enhancing the deformability and strength of decaying structures or existing ones with low capacity. The efficiency quantification is expressed with the Interface Capacity Index (IC). The index correlates the thickness and strength of each layer of the strengthening system and accounts for the transferred loads (IC_L) and the strain distribution that causes the failure propagation on the concrete substrate (IC_fp). The investigation focuses on different CFRP strengthening schemes (laminated fabrics, prefabricated plates, Near Surface Mounted bars-NSM) applied to concrete substrates using different adhesive layers. Two cases were studied for different levels of concrete’s integrity: (a) healthy and (b) containing corrosion products. The experimental results were used to calibrate the numerical models and to evaluate the effects of different strengthening strategies. The results show the tendency of the strengthening systems to shift the interface performance from fully elastic to non-linear. Further, the quantification of the efficiency of retrofitting can be addressed by accounting for the mechanical and geometrical properties at the interface level, representing different failure modes and integration levels. Full article

The use of fibre-reinforced polymer materials (FRPs) for the retrofitting of reinforced concrete (RC) structures has become very popular. However, the main concern for the exploitation of FRPs is their premature debonding failure modes. This paper presents two different universal models for calculating flexed RC elements strengthened with externally bonded and near-surface mounted FRP reinforcements, which were derived by coupling principles of the fracture mechanics of solids and generally accepted assumptions. The first model allows a complete analysis of the behaviour, development, and propagation of rupture of the joint. The main advantages of the proposed model, compared to existing ones, are that it does not require additional bond shear tests to identify missing factors, and it is versatile and suitable for both externally bonded reinforcements (EBR) and near surface mounted (NSM) strengthening techniques. In addition, the concrete–FRP connection is divided into zones and the current phase and length of each zone are determined, allowing for more detailed analysis of the connection at different load stages. The proposed computational model and its derivation focus on the performance of the joint between the two cracks and the distribution of the shear stresses in that joint. The second one requires fewer computations and can be fully exploited when the joint is treated as a unit, without division. The results of the calculations have been validated using the experimental database of 77 RC beams and strengthened with externally bonded and near-surface mounted carbon fibre reinforced polymer (CFRP) and glass fibre reinforced polymer (GFRP) sheets, plates, strips, and bars taken from 13 different studies. Both the prestress force and the initial stress state before strengthening were evaluated. Full article
