Search Results (26)

Cold bending provides a cost-effective method for fabricating triangular glass units for free-form architectural envelopes. Replacing conventional continuous edge constraints with discrete point clamps reduces over-constraint but introduces pronounced bending–membrane coupling in the unsupported spans between adjacent clamps. Consequently, the mechanisms governing local instability and optical-quality degradation remain insufficiently understood. In this study, cold-bending tests were performed on isosceles triangular fully toughened glass plates to measure out-of-plane deflection and surface-strain evolution. The experimental data were then used to establish and validate an Abaqus finite element model for systematic parametric analysis. Based on von Kármán’s large-deflection theory, a semi-empirical reduced-order framework that combines modal superposition with the response-surface method was developed to identify instability-sensitive configurations. The results show that, under weak constraints and large vertex angles, the panel response changes from a bending-dominated regime to a strongly nonlinear large-deflection regime governed by membrane effects; this transition is marked by a reversal of mid-span deflection and a compressive-to-tensile stress transition. Increasing the number of clamps from two to four substantially suppresses both global and local distortion by shortening the free spans and redistributing membrane strain energy, reducing peak mid-span deflection by 47–68%, and satisfying the EN 12150-1 limits for both bow deformation and local distortion. The height-to-base ratio is the dominant geometric parameter controlling instability. Under two-point support, a critical response turning point occurs at a height–base ratio of approximately 0.5 before the material fracture limit is reached, defining a geometric boundary below which optical serviceability failure accelerates. These findings provide a theoretical basis and quantitative engineering guidance for optimizing the cold-bending process of isosceles triangular fully toughened glass plates. Full article

Methods of single-point diamond turning and chemical mechanical polishing can achieve an ultra-flat substrate. However, these methods which rely on mechanical interactions to achieve material removal can easily lead to defects such as abrasive embedding and scratches on the surface. In addition, for low-rigidity and thin-plate workpieces, clamping deformation and force deformation are critical factors affecting the machining accuracy. This paper proposes a two-step polishing chain that uses controllable electrochemical and chemical etching to correct the shape error of the workpiece. With the optimized parameters, the jet electrochemical machining (Jet-ECM), which uses the electrochemical etching mechanism, is applied to the computer-controlled optical surfacing (CCOS) to achieve the rapid convergence of the shape accuracy. In addition, electrogenerated chemical polishing (EGCP) is implemented as a follow-up process which uses the mechanism of diffusion-controlled chemical etching to reduce the mid-spatial-frequency (MSF) error caused by the computer-controlled optical surfacing. Based on this two-step polishing chain and the self-developed devices, the peak-to-valley (PV) value of the φ 50 mm workpiece (valid dimensions = 90% of the central region) is reduced from 2.678 μm to 0.384 μm. This study has great implications for further understanding the mechanism of Jet-ECM and EGCP, which expands the applications of stress-free polishing to solve the processing problems of the low-rigidity workpiece. Full article

This paper presents a yarn tension sensor based on Surface Acoustic Waves (SAW). To enhance the detection accuracy of the sensor, an improved beam structure is designed for tension measurement, along with intelligent algorithms for temperature compensation. Firstly, regarding the sensor structure, a simply supported beam with a hyperbolic surface is designed to achieve stress concentration by reducing the section modulus at the beam’s midpoint. Secondly, by incorporating an unbalanced split-electrode Interdigital Transducer (IDT) design, the sensor effectively suppresses signal sidelobe interference and significantly improves the structure’s tension sensitivity. Finally, in terms of signal processing, to eliminate the influence of environmental temperature fluctuations on measurements, a temperature-compensation algorithm based on Bayesian Optimization Least Squares Support Vector Machine (BO-LSSVM) with Gaussian Process regression is proposed. Experimental results show that the tension sensitivity of the improved structure was 8.2% higher than that of the doubly clamped beam and 12.7% higher than that of the cantilever beam. For temperature compensation, the BO-LSSVM model reduced the Mean Relative Error (MRE) by 5.67 percentage points relative to raw data and by 2.04 percentage points relative to the fixed-parameter LSSVM model, lowering the temperature sensitivity coefficient from 4.09 $(\times {10}^{-3}/°\mathrm{C})$ to 0.41 $({10}^{-3}/°\mathrm{C})$. Full article

To enhance the operational efficiency of energy storage converters in grid-connected systems with high renewable penetration, this study systematically investigates key technologies of active neutral-point clamped (ANPC) topology under “electrical–thermal–mechanical” multi-physical field coupling. The study reviews recent progress in structural design, modulation strategies, and fault-tolerant control, highlighting their impact on efficiency, reliability, and power density. At the structural stage, a hybrid SiC/IGBT device configuration combined with a three-dimensional stacked bus reduces conduction loss and achieves parasitic inductance. In the modulation stage, improved finite-set model predictive control and adaptive space vector modulation shorten computation time to 20 µs and keep total harmonic distortion (THD) within 2.8%. System-level evaluations demonstrate that a 250 kW ANPC converter attains a peak efficiency of 99.1%, a power density of 4.5 kW/kg, and a mean time between failure exceeding 150,000 h. These findings reveal a clear transition from single-objective performance improvement toward integrated multi-physics co-design. By unifying advanced modulation, intelligent fault-tolerant control, and multi-field coupling optimization, ANPC-based converters advance converters to a new stage of higher efficiency, reliability, and stability. The results provide essential technical support for next-generation power conversion systems in renewable-rich grids. Full article

This paper presents a cascaded control strategy for neutral-point-clamped three-level (NPC-3L) inverter-fed permanent magnet synchronous motors (PMSMs), integrating continuous-control-set model-predictive control (CCS-MPC) with mid-point voltage regulation and an online Lyapunov-stable neural-network (NN) disturbance observer. The outer CCS-MPC loop optimizes voltage vector application for accurate current tracking and harmonic suppression, while the inner loop balances mid-point voltage by adjusting the dwell times of P/N small-voltage vectors (VVs). The NN-based disturbance observer compensates parameter mismatches in real time, reducing steady-state dq-axis current errors. To validate the effectiveness of the proposed strategy, experiments are conducted using a three-phase PMSM fed by three-phase NPC-3L inverters. Experimental results demonstrate substantial improvements in mid-point voltage balance, current quality, and robustness against model uncertainties. Full article

This study presents an exact analytical investigation into the static response of helical single-walled carbon nanotube (SWCNT) beams based on Eringen’s differential nonlocal elasticity theory, which captures nanoscale effects arising from interatomic interactions. A key contribution of this work is the derivation of the governing equations for helical SWCNT beams, based on the nonlocal Euler–Bernoulli theory, followed by their exact analytical solution using the initial value method. To the best of the authors’ knowledge, this represents the first closed-form formulation for such complex nanostructures using this theoretical framework of nonlocal elasticity theory. The analysis considers both cantilevered and clamped–clamped boundary conditions, under various concentrated force and moment loadings applied at the ends and midpoint of the helical beam. Displacements and rotational components are expressed in the Frenet frame, enabling direction-specific evaluation of the deformation behaviour. Parametric studies are conducted to investigate the influence of geometric parameters—such as the winding angle ($\alpha$) and aspect ratio ($R/d$) and the nonlocal parameter ($R/\gamma$). Results show that nonlocal elasticity theory consistently predicts higher displacements and rotations than the classical local theory, revealing its importance for accurate modelling of nanoscale structures. The proposed analytical framework serves as a benchmark reference for the modelling and design of nanoscale helical structures such as nano-springs, actuators, and flexible nanodevices. Full article

This study examines the impact of midpoint voltage fluctuations on the performance of multilevel converters and proposes an advanced control strategy to reduce the required DC bus capacitance while maintaining system stability. The research demonstrates that active voltage imbalance control in active neutral-point-clamped (ANPC) topologies allows for stable operation with significantly reduced capacitor values. A hybrid control approach, combining fuzzy logic control and third-harmonic injection PWM (THIPWM), is developed to enhance voltage balancing, and modulation techniques are systematically optimized. Both simulation and experimental analyses confirm the efficacy of the proposed method, which achieves superior voltage regulation compared to conventional PI-based control schemes. Specifically, experimental results show a reduction in peak-to-peak DC-link voltage fluctuation from 116 V to just 4 V, and the phase current THD is reduced from 3.6% to 0.8%. The results indicate a substantial reduction in voltage fluctuations, contributing to a total harmonic distortion (THD) as low as 0.8%. Furthermore, the proposed strategy facilitates an approximate 26-fold decrease in DC bus capacitor size without compromising system stability. The reduction in capacitance not only lowers the overall system costs and hardware complexity but also improves reliability. The inverter was tested at a rated power of 62.5 kW using 0.3 mF capacitors instead of the theoretically required 7.8 mF. This work advances power electronics by presenting an efficient voltage balancing methodology, offering a cost-effective and robust solution for multilevel converter applications. The findings are validated through comprehensive simulations and experimental tests, ensuring practical applicability. Full article

To ensure the connection performance of precast concrete square piles, a screw clamping and welding joint connection is applied to the solid square piles. By conducting full-scale bending performance tests on six solid square pile specimens with cross-sectional side lengths of 300, 450, and 600 mm, including pile bodies, screw clamping joints, screw clamping, and welding joints, the bending load-bearing capacity, deformation capacity, and failure characteristics of the screw clamping–welding joint connection are compared and studied. The results show that the bending failure mode of the pile body specimens is shear failure in the flexural shear section and concrete crushing in the compression zone of the pure bending section; the bending failure mode of the screw clamping joint specimens are the pull-out of steel bar heads at the joint end plate; the bending failure mode of the screw clamping and welding joint specimens are concrete crushing in the compression zone of the pure bending section, steel bar breakage in the tension zone of the flexural shear section, and pull-out of steel bar heads at the end plate. It is worth noting that no significant damage occurred at the joints. The cracks in the pure bending section of the bending specimens mainly develop vertically and are evenly distributed, while some cracks in the flexural shear section develop obliquely towards the loading point, with branching. Compared to the pile body specimens, the cracking moment of the joint specimens is up to 16% higher, the ultimate moment is within 15% lower, and the maximum mid-span deflection is within 25% lower, indicating that the provision of anchorage reinforcement can increase the stiffness and cracking moment of the specimens. Full article

Standardized testing methods for the mechanical characterization of biological soft tissues remain underdeveloped in several domains. Existing clamping methods often induce high stress levels in the clamping region, thereby affecting experimental outcomes. This study introduces a 3D-printed clamping system based on the capstan principle. The capstan system was designed and manufactured using 3D printing technology and optimized to minimize the required gripping pressure while maintaining the natural, non-tapered state of specimens. This optimization helps reduce experimental artifacts and prevents premature tissue failure in the clamping region caused by local stress peaks. Usability trials were conducted using human flexor digitorum profundus (FDP) tendons (n = 15). Results showed that 80% of the tendons failed at the midpoint region, indicating the desired load distribution achieved by the clamping mechanism. The elastic moduli, averaging 316.18 ± 86.73 MPa, and failure load properties, averaging 79.25 ± 19.10 MPa, fell within the range of FDP values reported by other researchers, thereby supporting the validity of the capstan design. Capstan clamping offers a promising add-on for biomechanical testing of soft tissues. Further development is necessary to tailor the clamping design to various tissue geometries and to address issues related to tissue moisture regulation, thereby enhancing the reliability and versatility of the clamping system. Full article

Multilevel inverters with improved voltage quality are widely used in applications such as motor control and electric vehicles. The four-level active neutral point clamped (4L-ANPC) inverter effectively meets the demands for high power density and low device voltage stress. However, balancing the capacitor voltage and reducing its low-frequency voltage fluctuation are critical challenges that need to be addressed. To address these challenges, this paper proposes a “variable reference + zero-sequence injection” method that requires only three reference voltage signals to determine the injected zero-sequence components. Particularly, the expression of the midpoint current, regarding the modulation index and phase current amplitude, is theoretically derived. This reveals the fundamental connection between the zero-sequence voltage signal and the midpoint current, providing a theoretical foundation for the zero-sequence injection method in four-level inverters. Subsequently, a simulation model and an experimental platform of the 4L-ANPC inverter were developed to compare and analyze the waveforms of the upper and lower capacitor voltages, phase currents, and line voltages under different modulation methods. Additionally, the upper and lower capacitor voltage waveforms were examined for various modulation indices. The results indicate that as the modulation index increases, the low-frequency voltage fluctuation in the upper and lower capacitor voltages also rises. At a modulation index of 0.95, the “variable reference + zero-sequence injection” method effectively suppresses the fluctuation in the upper and lower capacitor voltages to be no more than 1 V. These experimental findings validate the effectiveness of the proposed method. Full article

Currently, the escalating integration of renewable energy sources is causing a steady weakening of grid strength. When grid strength is weak, interactions between inverters or those between inverters and grid line impedance can provoke widespread oscillations in the power system. Additionally, the diverse DC voltage application characteristics of power converter systems (PCS) may lead to over-modulation, generating narrow pulse issues that further impact control of the midpoint potential balance. Existing dead-time elimination methods are highly susceptible to current polarity judgments, rendering them ineffective in practical use. PCS, due to inherent dead-time effects, midpoint potential imbalances in three-level topologies, and narrow pulses, can elevate low-order harmonic content in the output voltage, ultimately distorting grid-connected currents. This is particularly susceptible to causing resonance in weak grids. To enhance the output voltage waveform of PCS, this article introduces a comprehensive compensation control strategy that combines dead-time elimination, midpoint potential balance, and narrow pulse suppression, all based on an active neutral point clamped (ANPC) three-level topology. This strategy gives precedence to dead-time elimination and calculates the upper and lower limits of the zero-sequence available for midpoint potential balance while fully compensating for narrow pulses. By prioritizing dead-time elimination, followed by narrow pulse suppression and finally midpoint potential balance, this method decouples the coupling between these three factors. The effectiveness of the proposed method is validated through semi-physical simulations. Full article

Targeting the issue of high losses of individual switching tubes in Neutral-Point Clamped (NPC) three-level inverters, an Active Neutral-Point Clamped (ANPC) three-level inverter is used, and a model predictive control strategy using the loss equalization of the inverter is proposed. This method organizes and analyzes multiple zero-state current pathway commutation modes and adds mode three under the original two commonly used zero-state commutation modes. On this basis, the three modes are flexibly switched by model predictive control, and the output is optimized according to the value function for the space vector in each operation, while the midpoint voltage control is added to the value function. The simulation results suggest that the recommended strategy in this study may effectively realize the loss equalization control and midpoint voltage control of the ANPC inverter, which improves the operation efficiency of the electromechanical actuator. Full article

Increased performance requirements in new power electronics areas of application, such as electric aircraft, make innovations on different design levels necessary. In order to quickly compare different topologies, analytical loss equations provide a fast and straightforward way to narrow down the possible solution space. The approach widely used in the literature results in long and complex terms, which can only be compared between different literature sources with great effort. Moreover, the literature lacks a detailed summarizing description of these analytical equations and their derivation, starting from the standard two-level VSI up to three-level midpoint clamped inverter topologies, such as the ANPC topology in its different modulation schemes. The application of such higher-level inverter topologies allows hybrid device configurations to become performant solutions. This work aims to give a closed-form description of the analytical loss modeling and the theoretical background and provide an implementation approach for a wide span of inverter topologies and for different modulation methods. Full article

One innovative composite fault-tolerant control tactic is presented for the reliable operation of a power transmission system, which consists of both an asymmetric six-phase permanent magnet synchronous motor (PMSM) and a T-type mid-point clamp type (T-NPC) three-level inverter. First, in order to inherit the better harmonic property of simplified space vector modulation (SVM) and the rapid dynamic capability of direct torque control (DTC), the SVM-DTC control scheme was determined, and the harmonic electric current suppression unit was added to the basic control scheme to obtain good harmonic electric current suppression. In addition, a strategy for open-circuit fault-tolerant control under the SVM-DTC scheme was designed by analyzing the mutual influence between the stator flux linkage and the stator voltage of each phase under an open-circuit fault. Finally, the PMSM drive system principle prototype was tested. By comparing the waveforms of output torque and current of each phase before and after fault tolerance, it shows that the large torque fluctuation (±5%) before fault tolerance was suppressed to ±2% and smoothed out, verifying the effectiveness of fault tolerance control. Full article

The uses of grid-connected photovoltaic (PV) inverters are increasing day by day due to the scarcity of fossil fuels such as coal and gas. On the other hand, due to their superior efficiency, lower cost, smaller size, and lighter weight when compared to inverters with transformers, transformerless inverters for low-voltage single-phase grid-tied photovoltaic (PV) systems have recently attracted more interest. However, there are some specific challenges, especially leakage current issues, which must be adequately addressed to ensure the safety standards of the grid codes. A variety of topologies has been presented in the literature to eliminate the leakage current using the decoupling or clamping technique. However, choosing an appropriate topology after comparison is challenging because each topology has a unique set of parameters. In this paper, the authors have selected a common set of parameters and simulated all the selected eighteen well-known topologies in MATLAB/Simulink to fairly analyze and compare their common mode characteristics and other output parameters. In addition, the power loss distribution of every switch of each of the eighteen topologies was calculated and presented to better understand the insight of the topologies. Full article
