Search Results (76)

This paper presents an electromechanical coupling model integrating an equivalent magnetic network (EMN) model of a dual three-phase permanent magnet synchronous motor (DTP-PMSM) with the dynamic model of a helical planetary gear transmission system. Using this model, this study analyzes the dynamic characteristics of an electric drive system, specifically motor phase current, electromagnetic torque, and gear meshing force, under self-fault-tolerant control strategies. Simulation and experimental results demonstrate that the self-fault-tolerant control strategy enables rapid fault tolerance during open-phase faults, significantly reducing system fault recovery time. Meanwhile, compared to the open-phase faults conditions, the self-fault-tolerant control effectively suppresses most harmonic components within the system; only the second harmonic amplitude of the electromagnetic torque exhibited an increase. This harmonic disturbance propagates to the gear system through electromechanical coupling, synchronously amplifying the second harmonic amplitude in the gear system’s vibration response. This study demonstrates that self-fault-tolerant control strategies significantly enhance the dynamic response performance of the electric drive system under open-phase faults conditions. Furthermore, this study also investigates the electromechanical coupling mechanism through which harmonics generated by this strategy affect the gear system’s dynamic response, providing theoretical support for co-optimization electromechanical coupling design and fault-tolerant control in high-reliability electric drive transmission systems. Full article

Magnetic gears (MGs) are attracting increasing attention in power transmission systems due to their contactless operation principles, low frictional losses, and high efficiency. However, the broad application potential of these technologies requires a comprehensive evaluation of engineering parameters, such as material selection, energy efficiency, and structural design. This review focuses solely on solid-core magnetic gear systems designed using laminated electrical steels, soft magnetic composites (SMCs), and high-saturation alloys. This review systematically examines the topological diversity, torque transmission principles, and the impact of various core materials, such as electrical steels, soft magnetic composites (SMCs), and cobalt-based alloys, on the performance of magnetic gear systems. Literature-based comparative analyses are structured around topological classifications, evaluation of material properties, and performance analyses based on losses. Additionally, the study highlights that aligning material properties with appropriate manufacturing methods, such as powder metallurgy, wire electrical discharge machining (EDM), and precision casting, is essential for the practical scalability of magnetic gear systems. The findings reveal that coaxial magnetic gears (CMGs) offer a favorable balance between high torque density and compactness, while soft magnetic composites provide significant advantages in loss reduction, particularly at high frequencies. Additionally, application trends in fields such as renewable energy, electric vehicles (EVs), aerospace, and robotics are highlighted. Full article

To collect the energy generated by rotational motion in the natural environment, a piezoelectric electromagnetic hybrid energy harvester (HEH) based on a planetary gear system is proposed. The harvester combines piezoelectric and electromagnetic effects and is mainly used for collecting low-frequency rotational energy. The HEH has a compact structure and contains four sets of piezoelectric energy harvesters (PEHs) and electromagnetic energy harvesters (EMHs) inside. The working principle of the energy harvester is analyzed, its theoretical model is established, and a simulation analysis is conducted. To verify the effectiveness of the design, an experimental device is constructed. The results indicate that the HEH can generate an average output power of 250 mW under eight magnets and an external excitation frequency of 7 Hz. In actual power supply testing, the HEH can light up 60 LEDs and provide stable power supply for the temperature–humidity meter. Full article

The mechanical connection between a transmission system and an electric motor gives rise to a strong interaction between their respective dynamics. In particular, the coupling between an electric motor and a nonlinear spur gear transmission significantly influences the overall dynamic behavior of the integrated system. This study presents a detailed investigation into the electromechanical coupling effects between a permanent magnet synchronous machine (PMSM) and a nonlinear spur gear transmission. To focus on these effects, three configurations are analyzed: (i) a standalone gear pair model without motor interaction, (ii) a combined gear–motor system without dynamic coupling, and (iii) a fully coupled electromechanical system where the mechanical feedback influences motor control. The dynamic interaction between the motor’s torsional vibrations and the gear transmission is captured using the derivative of the transmission error as a feedback signal, enabling a closed-loop electromechanical model. Numerical simulations highlight the critical role of this coupling in shaping system dynamics, offering insights into the stability and performance of electric drive–gear transmission systems under different operating conditions. It also underscores the limitations of traditional modeling approaches that neglect feedback effects from the mechanical subsystem. The findings contribute to a more accurate and comprehensive understanding of coupled motor–gear dynamics, which is essential for the design and control of advanced electromechanical transmission systems in high-performance applications. Full article

As the core component of modern mechanical transmission, the precision rotary motion mechanism and its drive system have wide applications in aerospace, robotics, and other fields. This article systematically reviews the design principles, performance characteristics, and research progress of various rotational motion mechanisms and their driving technologies. The working principles, advantages, disadvantages, and applicable scenarios of gears, drive belts, sprockets, camshafts, ratchet claw mechanisms, and linkage mechanisms were analyzed in terms of traditional mechanisms. In terms of new mechanisms, we focused on exploring the innovative design and application potential of intermittent indexing mechanisms, magnetic gears, 3D-printed spherical gears, and multi-link mechanisms. In addition, the paper compared the performance differences of electric, hydraulic, pneumatic, and piezoelectric drive methods. Research has shown that through material innovation, structural optimization, and intelligent control, there is still significant room for improvement in the load capacity, accuracy, and reliability of precision rotary motion mechanisms, providing theoretical support and practical reference for innovative design and engineering applications of future mechanical transmission technologies. Full article

The aim of this work is the design of a 200 W transmitting coil for a high-power wireless power transfer (WPT) system based on magnetic resonant coupling (MRC) to charge the battery of a drone in 1 h equipped with a WPT receiving coil integrated into the landing gear. This innovative solution is based on the use of the landing gear as the receiving coil, thereby obviating the need for an additional component (e.g., separate receiving coil). The proposed landing gear is fabricated from aluminum, to reduce weight, and to improve mechanical robustness and electrical performance. Consequently, the design reduces overall weight and system complexity while minimizing potential destabilization of the drone’s flight dynamics. However, a specific design of the primary coil is required to ensure high efficiency even in case of an inaccurate landing of the drone on a ground pad. To this aim, a double-D configuration is here proposed and optimized for the transmitting coil, while a double coil receiver in combination with a charge controller that uses a maximum power point tracking (MPPT) algorithm is integrated into the landing gear. The results obtained from the simulations demonstrate that the proposed WPT system has excellent electrical efficiency and very high tolerance to coil misalignment in terms of the coupling coefficient due to imprecise landing. The transmission efficiency of the final test prototype can reach 95% with a coupling coefficient of k = 0.16, and it can drop to a minimum of 85% when misalignment occurs resulting in k = 0.06. Full article

This study presents a comprehensive analysis and optimization methodology for bridge-connected modulators in coaxial magnetic gears. A novel harmonic modeling method incorporating magnetic saturation through permeability convolution matrices and multiple-layer radial subdivision is developed, achieving computational efficiency 20 times greater than finite element analysis with comparable accuracy (deviation < 3.2%). The research establishes an electromagnetic–structural coupling framework that captures the complex interactions between the magnetic field distribution and mechanical deformation, revealing critical trade-offs between electromagnetic performance and structural integrity. Multi-objective optimization using an improved NSGA-II algorithm identifies Pareto-optimal solutions balancing torque density, structural safety, efficiency, and thermal stability. Experimental testing validates that bridge width ratios between 0.05 and 0.07 provide optimal performance, delivering torque densities exceeding 80 kNm/m³ while maintaining stress ratios below 0.65 of material yield strength. Thermal analysis demonstrates that optimized configurations maintain operating temperatures below 70 °C with reduced thermal gradients. Vibration characteristics exhibit a strong correlation with bridge width, with wider bridges providing enhanced stability at higher speeds. The findings establish practical design guidelines for high-performance magnetic gears with improved reliability and manufacturability, advancing the fundamental understanding of electromagnetic–structural interactions in field-modulated magnetic gear systems. Full article

Variable frequency drives (VFDs) are widely used in industry as an efficient means to control the rotational speed of AC motors by varying the supply frequency to the motor. VFD signatures can be detected in vibration signals in the form of sidebands (modulations) induced on tonal components (carrier frequencies). These sidebands are spaced at twice the “pseudo line” VFD frequency, as the magnetic forces in the motor have two peaks per current cycle. VFD-related signatures are generally less susceptible to interference from other mechanical sources, making them particularly useful for deriving speed variation information and obtaining a “pseudo” tachometer from the motor’s synchronous speed. This tachometer can then be employed to accurately estimate the speed profile and to facilitate order tracking in mechanical systems for vibration analysis purposes. This paper presents a signal processing technique designed to extract a pseudo tachometer from the VFD signature found in a vibration signal. The algorithm was tested on publicly available vibration data from a test rig featuring a two-stage gearbox with seeded bearing faults operating under variable-speed conditions with no load, i.e., with minimal slip between the induction motor’s synchronous and actual speed. The results clearly demonstrate the feasibility of using VFD signatures both to extract an accurate speed profile (root mean square error, RMSE of less than 2.5%) and to effectively perform order tracking, leading to the identification of bearing faults. This approach offers an accurate and reliable tool for the analysis of vibration in mechanical systems driven by AC motors with VFDs. However, it is important to note that some inaccuracies may occur at higher motor slip levels under heavy or variable loads due to the mismatch between the synchronous and actual speeds. Slip-induced variations can further distort tracked order frequencies, compromising the accuracy of vibration analysis for gear mesh and bearing defects. These issues will need to be addressed in future research. Full article

This paper investigates the potential of a magnetic gear wireless power transfer (WPT) system for electric vehicle (EV) charging, with the advantages of low-frequency operation, low foreign object interference, low electromagnetic emissions, and high misalignment tolerance. The study explores the novel impact of Halbach arrays that enhance the flux density in desirable locations while decreasing the flux in undesirable locations, which provides the benefit of decreased foreign object attraction. The initial prototype results demonstrate that the Halbach system can transmit approximately 34.65 W with a transfer efficiency of 64% across a gap of 104 mm. The Halbach system is experimentally compared to a conventional magnet arrangement, which achieved a maximum power transfer of 88 W over 104 mm. The Halbach system is applied to a personal mobility EV to enable wireless charging at low frequency. The axial design of this WPT system has the unique benefit of a 360° radial coupling angle that maintains constant, near-maximum levels of power transfer and efficiency. This full circle coupling angle allows the personal EV to park in any direct vicinity of the charger and achieve the same level of charging given a certain distance. This study delivers important contributions to advancing a low-frequency wireless EV charging technology based on magnetic gears, that sets the stage for future innovations focused on optimizing efficiency, increasing safety, and simplifying the charging process. Full article

In this paper, a variable gear ratio for active steering systems with a double planetary gear configuration is presented to optimize the steering performance of commercial vehicles. First, a variable transmission ratio system with a dual-row planetary gear mechanism is developed in ADAMS/Car, where the steering mechanism’s transmission ratio can be adjusted according to different driving conditions, thereby improving the vehicle’s stability and sensitivity. Second, a new type of dual-inverter permanent magnet synchronous motor (DPMSM) has been designed to solve the power limitation problem in the electric drive steering of commercial vehicles. Finally, the step steering and lane change driving scenarios are chosen for co-simulation using ADAMS/Car and MATLAB to evaluate the proposed method’s effectiveness. The co-simulation results show that the proposed variable transmission ratio and control strategy can effectively improve the steering sensitivity and stability of commercial vehicles. Full article

A magnetic-wheeled robot is a type of robot that inspects large steel structures instead of humans, and it can run on a three-dimensional path by using wheels with built-in permanent magnets. For the robots to work safely, their magnetic wheels require both magnetic attractive forces and friction forces. Planetary-geared magnetic wheels, which we have developed, make direct contact with their yokes on the running surface to ensure their magnetic attractive force. However, this design decreases their frictional performance more than common magnetic wheels covered with soft materials. Therefore, the yokes require methods that can improve their frictional performance without decreasing their attractive force. To consider the best method for the use of magnetic wheels, this study has run experiments with five types of yokes, which have different processing. As a result, the yokes with corroded surfaces could have maintained the attractive force more than 90% of the time and increased their traction forces by about 36% in static conditions and about 30% in dynamic conditions compared to yokes with no machining. The main reasons for these experimental results are that the rust layer has stable irregularities on the surface and includes ferromagnetic materials. Full article

In this study, a novel magnetic gear design is introduced. Unlike conventional magnetic gears that can only achieve a single gear ratio using permanent magnetic poles, the proposed design incorporates electromagnetic coils that can adapt to various control strategies, resulting in a multiple gear ratio for the same machine design. We selected a gear system with five gear ratios to validate the new design. The performance of the proposed design was compared with that of the conventional magnetic gear. While permanent magnet poles offer high torque transmission with a small volume, they cannot provide different gear ratios for the same configuration. Therefore, this work suggests using a single-gear machine based on a fixed number of electromagnetic coils to achieve different gear ratios. This research outlines the design steps, simulation process, and detailed analysis. The results demonstrate the effectiveness of the proposed design strategy, which can be potentially applied to wind turbines, transportation, and other scenarios with comparable success. Full article

This study presents a two-dimensional analytical method for fast optimization, taking into consideration the influence of the eddy current in a magnet and iron loss within a coaxial magnetic gear. Subdomain modeling was utilized to obtain vector potentials in the air-gap, magnet, and modulation regions by solving Maxwell’s equations. After that, the magnet, rotor, and modulation losses were predicted and then compared using a finite element method simulation within three topologies with gear ratios ranging from five to six. The authors improved the machine performance, specifically the torque density, by employing a multi-objective function with particle swarm optimization. The flux density obtained using subdomain modeling in just 0.5 s benefits the optimization process, resulting in a torque-density optimal model after around 3 h. A 3/19/16 prototype targeting a low-speed, high-torque, permanent generator application was fabricated to verify the analytical and simulation results. Full article

Induction heating is a clear, cheap, and highly effective technology used for many industrial and commercial applications. Generally, a time-varying magnetic field produces the required heat in the workpiece with a specially designed coil. The efficiency of the heating process depends highly on the coil design and the geometrical arrangement. A detailed and accurate finite element analysis of the induction heating process usually needs to resolve a coupled thermoelastic–magnetic problem, whose parameters values depend on the solution of another field. The paper deals with a shrink-fitting process design problem: a gear should be assembled with an axe. The interesting part of this case study is given the prescribed low limits for critical stress, the temperature of the gear material, and the heat-treated wearing surfaces. A coupled finite-element-based model and a genetic algorithm-based parameter determination methodology were presented. A thermal imaging-based measurement validated the presented numerical model and parameter determination task. The results show that the proposed methodology can be used to calibrate and validate the numerical model and optimize an induction heating process. Full article

An electrical motors, together with its appropriate drive system, is one of the most important elements of electromobility. In recent years, there has been a particular interest by academic researchers and engineers in permanent-magnet motors (PMSMs) in various applications, such as electric vehicles, Unmanned Aerial Vehicles (UAVs), elevator systems, etc., as the main source of drive transmission. Nowadays, the elevator industry, with the evolution of magnetic materials, has turned to gearless PMSMs over geared induction motors (IMs). One of the most important elements that is given special emphasis in these applications is proper motor design in consideration of the weight and speed of the chamber to be served during operation. This paper presents a design of a high-efficiency PMSM, in which finite elements analysis (FEA) and the study of the lift operating cycle provided useful conclusions on the magnetic field of the machine in different operating states. In addition, a simulated model was compared with experimental results of test operations. Furthermore, the drive system also required the use of appropriate electrical power and controls to drive the PMSM. Especially in elevator applications, the control of the motor speed by the variable voltage variable frequency technique (VVVF) is the most common technology used to avoid endangering the safety of the passengers. Thus, suitable speed and current controllers were used for this purpose. In our research, we focused on studying different control techniques using a suitable inverter to compare the system operation in each case studied. Full article
