Search Results (515)

Modern dentistry increasingly relies on light-curing units (LCUs) and lasers in essential clinical procedures such as composite resin polymerization, caries treatment, and periodontal therapy. This review aims to outline the evolution of light-emitting technologies and to assess their potential biological risks, with particular emphasis on effects on the visual system, oral tissues, and microbiome. The development of curing devices is presented chronologically, from the first-generation ultraviolet (UV-A) lamps introduced in the 1970s to current light-emitting diode (LED-LCU) systems and dental lasers (e.g., Er:YAG, Nd:YAG). The progressive increase in light intensity—now exceeding 3000 mW/cm²—has shortened curing times but simultaneously raised safety concerns. Major hazards include the so-called blue-light hazard, where exposure to high-energy visible (HEV) blue light may accelerate macular degeneration, and temperature elevations in the pulp chamber, which may damage the dentin–pulp complex. Laser radiation also exerts significant microbiological effects: Er:YAG and diode lasers demonstrate bactericidal activity against biofilms and oral pathogens (e.g., P. gingivalis), although therapeutic outcomes depend on wavelength, dose, and exposure time. Suboptimal parameters may lead to microbiome disturbances, whereas low-level laser therapy (LLLT; 600–1200 nm) supports tissue regeneration and helps restore microbial balance. The individualization of irradiation parameters, combined with thorough theoretical knowledge, operator expertise, and technical understanding of LCUs and lasers, is essential for maximizing clinical benefits while minimizing health risks and preserving oral microbiome homeostasis. Full article

Previous studies have shown that the external quantum efficiency (EQE) of conventional red Micro-Light emitting diodes(Micro-LEDs) decreases markedly with reducing chip size. This degradation is generally attributed to enhanced non-radiative recombination at sidewall defects, which leads to increased carrier loss in size-scaled LEDs. In this work, AlGaInP quaternary semiconductor epitaxial wafers incorporating multiple quantum wells (MQWs) with different well-layer strain states were grown by metal–organic chemical vapor deposition (MOCVD). Through wafer bonding, photolithography, etching, and metal evaporation, these epitaxial structures were fabricated into Micro-LED arrays with single-pixel pitches of 10, 20, 50, and 100 μm. The experimental results reveal that, with increasing indium (In) composition in the GaInP well layers—corresponding to a gradual increase in lattice mismatch (Δa/a) from 0% to 1%—smaller-sized Micro-LED arrays exhibit superior EQE performance. For devices with a pixel pitch of 10 μm, the EQE of Micro-LED arrays with a 1% lattice mismatch in the well layer is approximately three times higher than that of lattice-matched (0%) counterparts. In contrast, for devices with a pixel pitch of 100 μm, the EQE of lattice-matched (0%) Micro-LED arrays is about 1.3 times higher than that of devices with a 1% lattice mismatch. These results indicate that, to achieve maximum EQE in Micro-LEDs, the strain state of the MQW-layer material must be carefully considered as a priority factor. Optimal device performance requires appropriate matching between LED size and the well-layer growth strain. Full article

Inspired by the growing demand for small and effective optoelectronic devices, this paper presents a simulation-based analysis of InGaN/GaN quantum dot light-emitting diode, focusing on the effects of systematic variation in both anode and cathode contact regions, as well as overall device size. Two-dimensional simulations using APSYS software were used to examine the impact of scaling the device dimensions as well as the individual contact dimensions on significant performance parameters like internal quantum efficiency (IQE), optical output power, and current-voltage (IV) response. We simulated five LED device sizes that is 50 × 50 µm², 100 × 100 µm², 200 × 200 µm², 300 × 300 µm², and 400 × 400 µm². As device size grows, so does the total current at each voltage. The highest current measurement is achieved by the device with dimensions 400 × 400 µm² while the lowest is observed on the device with dimensions 50 × 50 µm². In addition to changing the device dimensions, we ran extensive simulations on the sizes of p-type and n-type contacts. Notable changes were seen in the efficiency, optical power, and emission profile of the p-contact. The behavior of p-side contacts from 0 to 50 µm was the same, while contacts between 60 and 100 µm showed significant differences. The significant performance parameters were unaffected by changes to n-contact dimensions. The results of this study illustrate how the configuration of contacts and dimensions greatly influences the electrical and optical performance of quantum dot light-emitting diode. The results are believed to be helpful to researchers working on the design of next-generation compact and efficient solid-state lighting devices. Full article

Daily exposure to blue light emitted by digital devices has raised concerns about oxidative stress-mediated damage to the ocular surface. Despite growing interest, validated in vitro models to study blue light-induced oxidative stress in corneal epithelial cells remain limited. A reproducible in vitro method was developed using rabbit corneal epithelial (RCE) cells exposed to blue LED light (405 nm). Irradiation parameters were optimized to induce oxidative stress without causing overt cytotoxicity. Cellular viability, intracellular ROS production, and mitochondrial oxidative stress were assessed. The model was validated using reference antioxidants (ascorbic acid and oleuropein), oleuropein formulated in a drug-in-cyclodextrin-in-liposome system (OLE-DCL), and two commercial ophthalmic formulations applied before or after irradiation. Blue light irradiation at 4.57 W/m² for 30 min significantly increased intracellular and mitochondrial ROS levels while preserving cell viability, indicating sublethal photo-oxidative stress. Ascorbic acid effectively suppressed ROS generation, whereas free oleuropein showed reduced efficacy, likely due to photosensitivity. OLE-DCL significantly enhanced antioxidant activity under irradiation. The model also discriminated between protective and restorative treatment strategies. This study establishes a validated in vitro blue light-induced oxidative stress model for corneal epithelial cells, suitable for screening antioxidant compounds, formulations, and application strategies relevant to ocular surface protection. Full article

Metal–organic chemical vapor deposition (MOCVD) is a crystal growth technique used to achieve high-purity thin films, especially III–V materials, for fabricating semiconductor devices. It allows for thickness tunability, controlled doping, and composition of epilayers. This review focuses on the principle of MOCVD, its historical background, and its applications in III–V semiconductor devices such as solar cells, high electron mobility transistors (HEMTs), light-emitting diodes (LEDs), laser diodes (LDs), and photonic integrated circuits (PICs). This review highlights the recent developments in MOCVD aimed at improving its efficiency, performance, and sustainability. Finally, we emphasize emerging trends and challenges in MOCVD process innovation, reactor design, and material integration that are poised to drive the development of next-generation optoelectronic, photonic, and quantum technologies. Together, these findings underscore MOCVD’s pivotal role in enabling high-performance devices and sustaining leadership in post-Moore semiconductor technologies. Full article

LED diffuse-illumination systems are widely used in industrial inspection and real life because of their scattering properties. However, there has been little research on secondary optical designs for diffuse illumination. Considering the need for diffuse light in real life and work, combined with existing specular-reflection technology, this study proposes a design method for a combined-freeform-surface illumination system with specular and diffuse reflections. Considering that a separate diffusing device cannot effectively control the diffusion area of the light source, the unique properties of the specular-reflective device were utilized in this study. First, the specular-reflection device directs the light from the central portion of the LED to the diffuse-reflection device, and the light collected is then redistributed by the diffuse-reflection device. Two mathematical models were established according to the light-emitting angle of the LED, which corresponded to two freeform surfaces. In addition, when evaluating the uniformity of the target-plane illumination, a set of constraint equations was added to obtain the diffuse freeform surface contour of the target plane. Finally, the ratio of the diameter to the thickness of the resulting illumination system exceeded six, and the illumination uniformity increased to over 56% (with a uniformity improvement ratio of ≥6% compared to traditional single-freeform-surface systems and ≥10% compared to integrating sphere systems). It is specifically designed for industrial precision inspection scenarios, has higher illumination uniformity than other diffuse illumination systems, and has better compactness, making it suitable for high-precision inspection lighting applications. Full article

Carbon dots have emerged as promising luminescent materials for solid-state lighting and color-conversion applications; however, their photoluminescence efficiency in the solid state is often limited by aggregation-induced quenching phenomena. In this work, we systematically investigate the role of the molar precursor ratio on the optical properties of green-emitting carbon dots, with the aim of establishing a direct link between synthesis parameters, photoluminescence optimization, and device-level performance. By carefully tuning the precursor ratio during synthesis, a significant enhancement of photoluminescence intensity and a strong suppression of solid-state quenching are achieved while preserving spectral stability in the green region. The optimized carbon dots exhibit improved radiative recombination and favorable optical characteristics for solid-state integration. Building on these results, the carbon dots are successfully employed as color-conversion layers in the fabrication of green light-emitting diodes, demonstrating efficient green emission under electrical excitation. This study highlights precursor ratio engineering as a simple and effective strategy to tailor carbon dot photoluminescence and provides a clear pathway from materials optimization to the realization of green color-conversion LED devices. Full article

Solar panels are an important device converting light energy into electricity not only from the sun but also from artificial light sources such as light emitting diodes (LEDs) or lasers. Recent advances in solar cell technologies enable them to be flexible, allowing them to be attached to things with different sizes and shapes. Therefore, it is challenging for AI-equipped systems to automatically recognize and distinguish flexible solar panels from other surrounding objects in realistic, complicated environments. Traditional recognition methods usually suffer from low recognition accuracy and high computational cost. Hence, this paper proposes a deep learning method for solar panel recognition using a complete work flow that includes data acquisition and dataset construction, YOLOv8-based model training, real-time solar panel recognition, and extended functionality. The proposed method demonstrates the accurate identification of realistic flat and flexible solar panels, including bent and partially shaded panels, with a mean average precision (mAP)@0.5 of 99.4% and an mAP@0.5:0.95 of 90.4%. The Pareto front for the multi-objective loss function minimization problem is also investigated to determine the optimal set of weighting parameters for the loss components. Furthermore, another functionality is added to detect the sizes of different solar panels if multiple ones co-exist. These features provide a promising foundation for further usage of the proposed deep learning approach to recognize flexible solar panels in realistic contexts. Full article

Perovskite quantum dots (PeQDs) are highly promising luminescent materials for next-generation displays owing to their excellent optoelectronic properties, such as narrow emission linewidth, high photoluminescence quantum yield, tunable bandgap, and solution processability. Blue-emitting PeQDs are particularly crucial for realizing full-color displays with high color purity. This review systematically summarizes synthesis strategies for blue-emitting PeQDs and their recent advances in perovskite light-emitting diodes (PeLEDs). We first introduce the working principles of PeLEDs and detail three primary approaches to achieving blue emission through mixed-halide engineering, quasi-two-dimensional structure construction via A-site cation substitution, and quantum size effect utilization. We then review mainstream synthesis methods, including hot-injection, ligand-assisted reprecipitation, and post-synthetic anion exchange, discussing their respective advantages and limitations. Key device optimization strategies are also outlined, covering surface passivation, core–shell structures, interface engineering, and light outcoupling enhancement. Finally, we address current challenges in material stability, efficiency roll-off, and charge imbalance and provide an overview of future research directions for high-performance blue PeLEDs based on PeQDs. Full article

Perovskite quantum dots (PQDs) based on CsPbX₃ (X = Cl, Br, I) have attracted extensive attention due to their outstanding optoelectronic properties; however, their practical applications are hindered by poor environmental stability. In this work, a sequential surface-modification strategy is developed to address these limitations. First, CsPbBr₃ PQDs are passivated with (3-aminopropyl) triethoxysilane (APTES), which reduces surface defects and enhances the photoluminescence quantum yield (PLQY) from 38.5% to 74.4%. Subsequently, a dense silica shell is constructed via in situ hydrolysis of tetramethyl orthosilicate (TMOS), further improving the PLQY to 95.6% and significantly boosting environmental stability. Structural and optical characterizations confirm effective defect passivation and suppress non-radiative recombination, with carrier lifetimes extended from 2.5 ns to 36.9 ns. Remarkably, the silica-coated PQDs retain over 50% of their initial emission intensity after 100 min of water immersion, far exceeding the stability of uncoated counterparts. Furthermore, when integrated with a commercial K₂SiF₆: Mn⁴⁺ red phosphor and a blue light-emitting diode (LED) chip, the resulting white LED (WLED) exhibits a wide color gamut covering 104% of the National Television System Committee (NTSC) standard and Commission Internationale de l’Éclairage (CIE) coordinates of (0.323, 0.331), closely matching standard white light. Importantly, only the silica-coated PQDs maintain a stable electrically driven device emission spectrum after water exposure. Full article

The strategic selection of lens geometry—spherical versus plane—decisively shapes the opto-thermal performance boundary of deep ultraviolet light-emitting diodes (DUV-LEDs), thereby governing their efficacy in application-specific photochemical processes. This study demonstrates that spherical lenses, by virtue of their superior light-collecting geometry, significantly enhance optical extraction efficiency and thermal management performance compared to conventional plane lenses. These engineered performance characteristics translate directly into divergent functional outcomes: spherical lenses enable rapid, high-intensity processing, while plane lenses are better suited for controlled, sustained operation. The findings establish a fundamental principle for DUV-LED packaging design: lens geometry can be tailored to optimize efficiency for distinct photochemical tasks, providing a clear pathway from device engineering to application-driven performance. Full article

In this study, the optical gain characteristics of a green laser sample based on a III-Nitride InGaN single-quantum-well structure were investigated. The Green gap phenomenon, caused by bandgap fluctuations due to inhomogeneous indium composition and the quantum-confined Stark effect (QCSE), has been a major obstacle in achieving high efficiency and high output in green-light-emitting devices. To address these issues, a sample grown on a (0001)-oriented GaN substrate with a single-quantum-well active layer was fabricated to suppress In composition non-uniformity and enhance the overlap of electron and hole wavefunctions. The optical gain behavior was analyzed using the Variable Stripe Length Method (VSLM) under various excitation densities and stripe lengths ($L_{cav}$). The results showed that as the stripe length increased, the spectral linewidth decreased and stimulated emission occurred at lower excitation densities. However, excessive cavity length led to gain saturation and a red shift in the peak wavelength due to Joule heating effects. These findings provide essential insights for determining the optimal cavity length in laser diode fabrication and are expected to serve as fundamental guidelines for improving the efficiency and output power of III-Nitride-based green laser diodes. Full article

Organic optoelectronic devices receive appreciable attention due to their low cost, ecology, mechanical flexibility, band-gap engineering, brightness, and solution process ability over a broad area. In this study, we designed and studied organic light-emitting diodes (OLEDs) consisting of an assembly of natural dyes, extracted from noble fir leaves (evergreen) and blue hydrangea flowers mixed with poly-methyl methacrylate (PMMA) as light emitters. We experimentally demonstrate the effective conversion of blue light emitted by an inorganic laser/photodiode into longer-wavelength red and green tunable photoluminescence due to the excitation of natural dye–PMMA nanostructures. UV-visible absorption and photoluminescence spectroscopy, ellipsometry, and Fourier transform infrared methods, together with optical microscopy, were performed for confirming and characterizing the properties of light-emitting diodes based on natural dyes. We highlighted the optical and physical properties of two different natural dyes and demonstrated how such characteristics can be exploited to make efficient LED devices. A strong pure red emission with a narrow full-width at half maximum (FWHM) of 23 nm in the noble fir dye–PMMA layer and a green emission with a FWHM of 45 nm in blue hydrangea dye–PMMA layer were observed. It was revealed that adding monolayer MoS₂ to the nanostructures can significantly enhance the photoluminescence of the natural dye due to a strong correlation between the emission bands of the inorganic–organic emitters and back mirror reflection of the excitation blue light from the monolayer. Based on the investigation of two natural dyes, we demonstrated viable pathways for scalable manufacturing of efficient hybrid OLEDs consisting of assembly of natural-dye polymers through low-cost, purely ecological, and convenient processes. Full article

Tandem white organic light-emitting diodes (OLEDs), formed by stacking red, green, and blue organic electroluminescent units, offer a promising route toward high-resolution microdisplays. However, their performance is constrained by the intrinsically short lifetime of blue OLED sub-units. Replacing the unstable blue OLED with a long-lived GaN-based LED could address this limitation, but practical hybridization remains difficult because of incompatible fabrication routes and significant current imbalance between the inorganic and organic units. Here, we demonstrate the first hybrid GaN–OLED tandem white LEDs enabled by an interface-engineered charge-generation unit (CGU). By introducing an ITO/HAT-CN/LiNH₂-doped Bphen CGU, we simultaneously enhance the work function, strengthen the built-in electric field, and smooth the interfacial morphology. These synergistic effects promote efficient charge generation, yielding near-ideal voltage summation and well-balanced electron–hole injection. As a result, the hybrid tandem device shows a nearly twofold increase in current efficiency (from 28.1 to 58.6 cd A^–1) and significantly reduced spectral shift under varying current densities. We further demonstrate the generality of this approach by integrating the GaN emission with yellow OLEDs to produce stable blue–yellow hybrid white emission. This work establishes an applicable strategy for integrating GaN-LEDs and OLEDs, opening a pathway toward efficient, stable, and compact white light engines for next-generation microdisplay technologies. Full article

Metal halide perovskite (MHP)-based heterojunctions have become a forefront area in the research of optoelectronic functional materials due to their unique layered crystal structure, tunable band gaps, and exceptional optoelectronic properties. Recent studies have demonstrated that interface charge transfer is a crucial factor in determining the optoelectronic performance of the heterojunction devices. By constructing heterojunctions between MHPs and two-dimensional (2D) materials such as graphene, MoS₂, and WS₂, efficient electron–hole separation and transport can be achieved, significantly extending carrier lifetimes and suppressing non-radiative recombination. This results in enhanced response speed and energy conversion efficiency in photodetectors, photovoltaic devices, and light-emitting devices (LEDs). In these heterojunctions, the thickness of the MHP layer, interface defect density, and band alignment significantly influence carrier dynamics. Furthermore, techniques such as interface engineering, molecular passivation, and band engineering can effectively optimize charge separation efficiency and improve device stability. The integration of multilayer heterojunctions and flexible designs also presents new opportunities for expanding the functionality of high-performance optoelectronic devices. In this review, we systematically summarize the charge transfer mechanisms in MHP-based heterojunctions and highlight recent advances in their optoelectronic applications. Particular emphasis is placed on the influence of interfacial coupling on carrier generation, transport, and recombination dynamics. Furthermore, the ultrafast dynamic behaviors and band-engineering strategies in representative heterojunctions are elaborated, together with key factors and approaches for enhancing charge transfer efficiency. Finally, the potential of MHP heterojunctions for high-performance optoelectronic devices and emerging photonic systems is discussed. This review aims to provide a comprehensive theoretical and experimental reference for future research and to offer new insights into the rational design and application of flexible optoelectronics, photovoltaics, light-emitting devices, and quantum photonic technologies. Full article
