Search Results (44)

The rapid growth of the machining market and advancements in additive manufacturing (AM) present new opportunities for innovative tool designs. This preliminary study proposes a design for additive manufacturing (DfAM) approach to redesign a milling cutter head in 17-4 PH stainless steel by integrating topology optimization (TO) and internal coolant channel optimization, enabled by laser powder bed fusion (LPBF). An industrial eight-insert milling cutting tool was reimagined with conformal cooling channels and a lightweight topology-optimized structure. The design process considered LPBF constraints and was iteratively refined using computational fluid dynamics (CFD) and finite element analysis (FEA) to validate fluid flow and structural performance. The optimized milling head achieved approximately 10% weight reduction while improving stiffness (reducing maximum deformation under load from 160 μm to 151 μm) and providing enhanced coolant distribution to the cutting inserts. The results demonstrate that combining TO with internal channel design can yield a high-performance and lightweight milling tool that leverages the freedom of additive manufacturing. As proof of concept, this integrated CFD–FEA validation approach under DfAM guidelines highlights a promising pathway toward superior cutting tool designs for industrial applications. Full article

To improve the convective heat transfer in internal cooling channels of heavy-duty gas turbine blades, this study experimentally and numerically investigates the thermal performance of rectangular channels with hybrid pin-fins and micro V-ribs turbulators. The transient thermochromic liquid crystal (TLC) technique and ANSYS 2019 R3 (ICEM CFD 2019 R3, Fluent 2019 R3, CFD-Post 2019 R3) were employed under Reynolds numbers ranging from 10,000 to 50,000, with the numerical model rigorously validated against experimental data (the maximum RMSE is 2.5%). It is found that hybrid pin-fins and continuous V-ribs configuration exhibits the maximum heat transfer enhancement of 27.6%, with an average friction factor increase of 13.3% and 21.9% improvement in thermal performance factor (TPF) compared to the baseline pin-fin channel. In addition, compared to the baseline pin-fin channel, hybrid pin-fins and broken V-ribs configuration exhibits average heat transfer enhancement (Nu/Nu0) of 24.4%, an average friction factor increase of 7.2% and 22.5% improvement across the investigated Reynolds number range (10,000~50,000) based on computational results. The synergistic effects of hybrid pin-fin and micro V-rib structures demonstrate superior coolant flow control, offering a promising solution for next-generation turbine blade cooling designs. This work provides actionable insights for high-efficiency gas turbine thermal management. Full article

High density old districts at the urban fringes of Asian megacities, such as Shenzhen, face significant thermal challenges due to dense building clusters, limited airflow, and heat retention. This study adopts an integrated approach combining Phoenics wind simulation, geographic information system (GIS) modeling, and spatial prototype analysis to assess and optimize the wind and thermal environments in these urban areas. It investigates how spatial configurations, including building density, height distribution, orientation, and green space integration, influence wind flow and thermal comfort. The results demonstrate that optimized spatial arrangements, including reduced building density, height adjustments, and strategic landscape design, improve ventilation and temperature regulation. Comparative analyses of different spatial prototypes reveal that radial configurations effectively channel external winds into the urban core, enhancing internal airflow, whereas rectangular layouts create wind shadows that hinder ventilation. Adjustments to building façades and vertical arrangements further mitigate pedestrian-level heat accumulation. Interventions in public spaces, including green roofs and vertical greening, offer cooling benefits and mitigate urban heat island effects. This study underscores the importance of aligning urban design with natural wind flow and offers a framework for sustainable landscape and architectural strategies in high-density, heat-prone environments. The findings offer valuable insights for urban planners and policymakers seeking sustainable development in similar megacities. Full article

In this study, a conceptual turbine blade model with internal cooling channels was designed and fabricated using the selective laser melting (SLM) process. The optimal manufacturing orientation was evaluated through simulations, and the results indicated that vertical orientation yielded the best outcomes, minimizing support material usage and distortion despite increased manufacturing time. Two configurations were produced, namely, an entire-turbine blade model and a cross-sectional model. Non-destructive analyses, including 3D laser scanning for dimensional accuracy, surface roughness measurements, and liquid penetrant testing, were conducted. Visual inspection revealed manufacturing limitations, particularly in the cooling channels at the leading and trailing edges. The trailing edge was too thin to accommodate the 0.5 mm channel diameter, and the channels in the leading edge were undersized and potentially clogged with unmelted powder. The dimensional deviations were within the acceptable limits for the SLM-fabricated metal parts. The surface roughness measurements were aligned with the literature values for metal additive manufacturing. Liquid penetrant testing confirmed the absence of cracks, pores, and lack-of-fusion defects. The SLM is a viable manufacturing process for turbine blades with internal cooling channels; however, significant attention should be paid to the design of additive manufacturing conditions to obtain the best results after manufacturing. Full article

The trailing edge of gas turbine blades encounters concentrated heat loads, necessitating cooling techniques distinct from those used in mid-chord regions. Narrow cooling channels in these areas typically incorporate pin fins or dimples for internal cooling. In contrast, external cooling relies on cutback film cooling configurations, which differ significantly from mid-chord designs. Large eddy simulation (LES) has emerged as a powerful tool for investigating heat transfer in these challenging environments, capturing intricate flow phenomena and turbulence effects that Reynolds-Averaged Navier–Stokes (RANS) simulations often cannot resolve. This review synthesizes findings from 54 LES-based studies on trailing edge cooling, focusing on three key configurations: pin fin arrays, dimpled surfaces, and cutback film cooling. LES consistently demonstrated higher accuracy in predicting heat transfer and cooling effectiveness, outperforming RANS by resolving complex flow structures such as horseshoe vortices, shear layer vortices, and unique flow interactions inherent to these geometries. Furthermore, LES provided detailed turbulence statistics and local heat transfer distributions, offering critical insights for optimizing and improving predictive models. Beyond its demonstrated capabilities, this review underscores the future potential of LES in advancing shape optimization, transient flow analysis, and multi-physics simulations, including conjugate heat transfer and flow-structure interactions. Full article

The use of parts containing internal channels fabricated by laser powder bed fusion (LPBF) in maraging steel is gaining attention within industry, due to the promising application of the material in molds and forming tools. However, LPBF processing has issues when it comes to unsupported channels, leading to defects that can result in a limited performance and shortened component life. The present study aims to provide a detailed evaluation of the metallurgical effects arising from the LPBF printing of channels made of maraging 300 steel. The results show that channel distortion occurs due to the lack of support, associated with increased roughness at the top part of the channel profile caused by partial melting and loosening of the powder. Statistical analyses showed that distortion is significantly affected by channel length. A high level of porosity derived from a lack of fusion was observed in the region above the channel and was attributed to layer irregularities caused by the absence of support, with a predominance of large and irregular pores. Residual stresses, always of a tensile nature, present a behavior opposed to that of distortion, increasing with increases in length, meaning that higher levels of distortion lead to an enhanced effect of stress accommodation/relief, with porosity having a similar effect. All these phenomena, however, did not seem to affect crystallographic orientation, with a nearly random texture in all cases, most likely due to the energy input used and to an optimized laser scanning strategy. These findings are vital to increase the amount of attention paid towards the design of internal channels, especially with those with the purpose of coolant circulation, since distortions and poor surface finishing can reduce cooling efficiency due to a defective fluid flow, while porosity can have the same effect by hindering heat transfer. Residual stress, in its turn, can decrease the life of the component by facilitating cracking and wear. Full article

This study numerically investigates the thermal performance of a refrigerant-based battery thermal management system (BTMS) under various operating conditions. A validated numerical model is used to examine the effects of cooling channel rib configurations (rib spacing and rib angles) and refrigerant parameters (mass flow rate and saturation temperature) on battery thermal behavior. Additionally, the impact of discharge C-rates is analyzed. The results show that a rib spacing of 11 mm and a rib angle of 60° reduce the maximum battery temperature by 0.8 °C (cooling rate of 2%) and improve temperature uniformity, though at the cost of a 130% increase in pressure drop. Increasing the refrigerant mass flow rate lowers the maximum temperature by up to 10%, but its effect on temperature uniformity diminishes beyond 20 kg/h. A lower saturation temperature enhances cooling but increases internal temperature gradients, while a higher saturation temperature improves uniformity at the expense of a slightly higher maximum temperature. Under high discharge rates (12C), the system’s cooling capacity becomes limited, leading to significant temperature rises. These findings provide insights that can aid in optimizing BTMS design to balance cooling performance, energy efficiency, and temperature uniformity. Full article

The paper presents a numerical analysis of the possibilities of replacing the aluminum serpentines in the current construction of battery thermal management systems (BTMS) with cooling serpentines made of fireproof composite materials with high heat transfer parameters (fireproof epoxy resin + nano boron nitride). This approach was given by the need to replace aluminum (which, in case of fire, maintains and accelerates the combustion process) with fireproof materials that reduce/eliminate the fire risk due to improper battery operation. Numerical analysis methods were used through simulation to identify the most efficient design among the single-channel, multichannel, multiflow and multiple coolant inlet–outlet solutions for cooling serpentine. In addition to these geometric constructive parameters, the variation of the coolant flow rate (9, 12, 15 and 18 L/min) and coolant inlet temperature (17, 20 and 25 °C) was also considered. The obtained results showed that the single-inlet nanocomposite resin cooling serpentine four-channel configuration presents the highest cooling efficiency of the cells that form the battery module while ensuring very good thermal uniformity as well. These findings are supported by the lowest average heat absorption by the batteries, of 34.44 kJ, as well as the lowest average internal resistance difference (caused by thermal gradients), of 5.23%. Future research is needed to identify the degree of structural resistance of serpentines made of fireproof composite material to external stresses (vibrations characteristic of the operation of electric vehicles). Full article

The complex multi-stage process of meat processing encompasses critical phases, including slaughtering, cooling, cutting, packaging, warehousing, and logistics. The quality and nutritional value of the final meat product are significantly influenced by each processing link. To address the major challenges in the meat processing industry, including device heterogeneity, model deficiencies, rapidly increasing demands for data analysis, and limitations of cloud computing, this study proposes an Internet of Things (IoT) architecture. This architecture is centered around an intelligently decoupled gateway design and edge-cloud collaborative intelligent meat inspection. Pork freshness detection is used as an example. In this paper, a high-precision and lightweight pork freshness detection model is developed by optimizing the MobileNetV3 model with Efficient Channel Attention (ECA). The experimental results indicate that the model’s accuracy on the test set is 99.8%, with a loss function value of 0.019. Building upon these results, this paper presents an experimental platform for real-time pork freshness detection, implemented by deploying the model on an intelligent gateway. The platform demonstrates stable performance with peak model memory usage under 600 MB, average CPU utilization below 20%, and gateway internal response times not exceeding 100 ms. Full article

Turbine blades for modern turbomachinery applications often exhibit complex twisted designs that aim to reduce aerodynamic losses, thereby improving the overall machine performance. This results in intricate internal cooling configurations that change their spanwise orientation with respect to the rotational axis. In the present study, the local heat transfer in a generic two-pass turbine cooling channel is investigated under engine-similar rotating conditions ($Ro=\{0\dots 0.50\}$) through the transient Thermochromic Liquid Crystal (TLC) measurement technique. Three different angles of attack ($\alpha =\{-{18.5}^{°};+8^{°};+{46.5}^{°}\}$) are investigated to emulate the heat transfer characteristics in an internal cooling channel of a real turbine blade application at different spanwise positions. A numerical approach based on steady-state Reynolds-averaged Navier–Stokes (RANS) simulations in ANSYS CFX is validated against the experimental method, showing generally good agreement and, thus, qualifying for future heat transfer predictions. Experimental and numerical data clearly demonstrate the substantial impact of the angle of attack on the local heat transfer structure, especially for the radially outward flow of the first passage, owing to the particular Coriolis force direction at each angle of attack. Furthermore, results underscore the strong influence of the rotational speed on the overall heat transfer level, with an enhancement effect for the radially outward flow (first passage) and a reduction effect for the radially inward flow (second passage). Full article

The plastic injection moulding industry is a constantly developing industrial field. This industrial process requires the manufacturing of metal moulds using complex heating and cooling systems. The purpose of this research is to optimize both the plastic injection moulding process and the mould manufacturing process itself by combining practices in this industry with current additive manufacturing technologies, specifically Wire Arc Additive Manufacturing (WAAM) technology. A mould punch was manufactured by using both WAAM technology, whose internal cooling system has been designed under the concept of Conformal Cooling, and conventional cooling channel designs and manufacturing techniques in order to carry out a comparative analysis. Theoretical results obtained by CAE methods showed an improvement in heat extraction in the WAAM mould. In addition, the WAAM mould was able to achieve better temperature homogeneity in the final part, minimizing deformations in the final part after extraction. Finally, the WAAM manufacturing process was proven to be more efficient in terms of material consumption than the conventional mould, reducing the buy-to-fly ratio of the part by 5.11. Full article

The pin-fin is one of the main technologies in enhancing heat transfer. The accelerated flow and vortex structures are produced, which can disrupt the development of the flow boundary layer. The configuration of the pin-fin is obvious for heat transfer and flow characteristics, including its shape, size, and arrangement in the cooling channel. This work provides a detailed introduction to the application of pin-fins in enhancing heat transfer and reducing flow resistance, including the conventional shapes, improved shapes based on circular pin-fins and irregular shapes. At the same time, the influence of the diameter, height and density of pin-fins on heat transfer and flow performance is studied, and the influence mechanism is analyzed from the perspective of boundary layers. In addition, some applications that combine pin-fins with other cooling methods to further improve performance are analyzed. In terms of the optimization technology, the structure optimization for pin-fin shape and the layout optimization for pin-fin array are summarized. Therefore, this review provides a wide range of literature for the design of internal cooling channel pin-fins. Full article

Against the backdrop of climate policy goals and the EU’s aim for a resource-efficient economy, the foundry industry must rethink product range, energy consumption, and production technologies. Light metal casting, which is performed through processes like gravity die casting and high-pressure die casting, requires effective thermal management, which is crucial for optimising mould filling, solidification, cycle times, and part quality. Against this background, this study presents the development and characterisation of a cooling system that completely dispenses with energy-intensive heating/cooling devices. The system is based on a mask shape combined with internal spray cooling. This paper shows the simulation workflow for developing the mould mask and the design of the cooling system and compares the performance with conventional temperature control using channels. In the tests, an 82% higher cooling rate was achieved with Cool-Spray than with conventional temperature control, which was approx. 2.5 mm below the cavity surface. In addition to the more dynamic temperature control, the potential for process control was utilised, and the component quality of the test part was significantly improved compared to conventional temperature control. Full article

Cutting tool coolant channels play a pivotal role in machining processes, facilitating the efficient supply of cooling agents to high-stress areas and effective heat dissipation. Achieving optimal cooling at the tool’s cutting-edge is essential for enhancing production processes. Experimental investigations into tribological stress analysis can be limited in accessing complex tool–workpiece contact zones, prompting the use of numerical modelling to explore fluid dynamics and tribology. In this study, the coolant flow dynamics and heat dissipation in drilling operations were comprehensively investigated through computational fluid dynamics (CFD) modelling. Four twist drill models with varying coolant channel arrangements were studied: standard model drill, standard model drill with notch, profile model drill, and profile model drill with notch. Two distinct approaches are applied to the coolant inlet to assess the impact of operating conditions on fluid flow and heat dissipation at the cutting-edge. The findings emphasize that cutting-edge zones have insufficient coolant supply, particularly in modified drill models such as the standard model drill with notch and profile model drills with and without notch. Moreover, enhanced coolant supply at the cutting-edge is achieved under high-pressure inlet conditions. The standard model drill with a notch exhibited exceptional performance in reducing thermal load, facilitating efficient coolant escape to the flute for improved heat dissipation at the cutting-edge. Despite challenges like dead zones in profile models, the standard-with-notch model yielded the most promising results. Further analyses under constant pressure conditions at 40 and 60 bar exhibited enhanced fluid flow rates, particularly at the cutting-edge, leading to improved heat dissipation. The temperature distribution along the cutting-edge and outer corner demonstrated a decrease as the pressure increased. This study underscores the critical role of both coolant channel design and inlet pressure in optimizing coolant flow dynamics and heat transfer during drilling operations. The findings provide valuable insights for designing and enhancing coolant systems in machining processes, emphasizing the significance of not only coolant channel geometry but also inlet pressure for effective heat dissipation and enhanced tool performance. Full article

Ni-base superalloys operate in harsh service conditions where cyclic heating and cooling introduce deformation fields that need to be investigated in detail. We used the high-angular-resolution electron backscatter diffraction method to study the evolution of internal stress fields and dislocation density distributions in carbides, dendrites, and notch tips. The results indicate that the stress concentrations decay exponentially away from the notch, and this pattern of distribution was modified by the growth of cracks and the emission of dislocations from the crack tip. Crack initiation follows crystallographic traces and is weakly correlated with carbides and dendrites. Thermal cycles introduce local plasticity around carbides, the dendrite boundary, and cracks. The dislocations lead to higher local stored energy than the critical value that is often cited to induce recrystallization. No large-scale onset of recrystallization was detected, possibly due to the mild temperature (800 °C); however, numerous recrystallized grains were detected in carbides after 50 and 80 cycles. The results call for a detailed investigation of the microstructure-related, thermally assisted recrystallization phenomenon and may assist in the microstructure control and cooling channel design of turbine blades. Full article
