A novel method for controlling the speed of interior permanent magnet synchronous motors (IPMSMs), known as the current-sensing-based dynamic direct voltage control method under the maximum torque per ampere (MTPA) concept, is introduced. This technique achieves precise tracking of machine velocity by determining the optimal combination of voltage amplitude and angle for each specific motor velocity and current/load condition. Unlike previous studies, this approach takes into account the transient model of the machine, resulting in improved accuracy during dynamic operating conditions compared with existing methods in the literature. Moreover, a comparative analysis is conducted involving different direct voltage MTPA speed drive approaches: the current-sensing dynamic direct voltage control (CS-DDVC) methodology, the simplified DDVC technique, and the static direct voltage MTPA control strategy. The well-known field-oriented control method is also included in the analysis. The dynamic methodology employs two tuning parameters to achieve the same MTPA objective while eliminating transient effects. Experimental results and quantitative assessment demonstrate that the proposed MTPA control methodology is a highly effective strategy, offering a respectable alternative to existing MTPA methods for driving IPMSMs. It enables the operation of IPMSMs under MTPA working conditions with high efficiency, making it suitable for a wide range of industrial applications. Experimental results demonstrate a reduction in speed dip from 120 rpm to 50 rpm at full load application and a 128% improvement in IAE compared to conventional DVC. From an engineering design perspective, the proposed control framework simplifies the drive-system architecture by eliminating cascaded current-control loops while maintaining effective transient dynamic performance suitable for embedded electric vehicle applications. Full article

The paper deals with a finite element analysis (FEA) of the occurrence of an inflection point in the power loss vs. torque curve of permanent magnet synchronous machines (PMSM), related to optimal torque distribution in multi-motor all-wheel drive electric vehicles. Simplified, analytical power-loss models of the electric motor suggest that the power loss curve is convex, and consequently, the equal front/rear torque distribution is optimal. On the contrary, experimental studies usually point to a non-convex power loss curve containing an inflection point, which leads to more complex torque distribution laws. With the aim of explaining the experimentally observed effects, a first-principle, FEA approach is applied to PMSMs of different types (interior vs. surface permanent magnets, IPM vs. SPM) and different vector control strategies (maximum torque per ampere vs. maximum efficiency). Additionally, the impact of vehicle transmission losses on the power loss curve inflection point occurrence is analyzed. The results demonstrate that in the IPM motors, the inflection point occurs more readily than in the SPM motors due to the greater reluctance torque capabilities, which can strongly saturate the q-axis even under flux-weakening conditions, thus creating a highly nonlinear iron loss torque dependency. Also, the rising transmission efficiency vs. torque curve contributes to the occurrence of an inflection point. Full article

In electric vehicle thermal management systems, direct measurement of the internal motor temperature is difficult. Therefore, the coolant pressure drop is an important indicator for estimating the motor thermal state. However, manufacturing and operating uncertainties in water-cooled interior permanent magnet synchronous motors (IPMSMs) can cause variability in cooling performance and pressure drop, requiring a reliability-based design approach. In this study, reliability-based design optimization (RBDO) is performed by considering manufacturing tolerances in the cooling channels and uncertainty in the inlet coolant flow rate. Based on coupled electromagnetic–thermal–fluid analysis and Kriging surrogate models, RBDO is applied to minimize the maximum temperature while satisfying the allowable pressure-drop limit at a target reliability level. The proposed RBDO improves the probability of satisfying the pressure-drop constraint from 54.1% in the baseline design to 99.9%, while increasing the mean maximum temperature by only 0.17 K. These results indicate that RBDO can improve the reliability of the pressure-drop constraint in IPMSM water-cooling systems under practical manufacturing and operating uncertainties, with only a limited change in thermal performance. Full article

Interior permanent magnet synchronous motor (IPMSM) has advantages with high power density, wide speed range, small size, and high efficiency, and is widely used in the drive system of electric vehicles. Compared to other types of motors, permanent magnet synchronous motors (PMSMs) have some irreplaceable advantages, but there are also some disadvantages. As a type of PMSM, IPMSMs have problems with large fluctuations in permanent magnet (PM) magnetic field and demagnetization. At present, irreversible demagnetization of PMs is the most serious problem faced by IPMSMs. Once irreversible demagnetization of PMs occurs, it can cause a decrease in the performance of IPMSMs and can even damage the entire drive system. This paper takes an IPMSM with 48 slots, 8 poles, and 66 kW as the research object. Based on the reasons for PM demagnetization, a PM demagnetization model is established to obtain the demagnetization law of PMs. Firstly, the magnetic properties of PM materials were described based on their characteristic curves. The demagnetization mechanism of PMs was analyzed, and the demagnetization process of PMs was studied in combination with the reasons for demagnetization. Secondly, the basic parameters and torque performance of IPMSMs were calculated and analyzed. We analyzed the demagnetization curves of PM materials at different temperatures, calculated the operating points of PMs under various working conditions, and analyzed whether PMs undergo irreversible demagnetization based on the relationship between the operating points of PMs and the knee points of demagnetization curves. A high-fidelity electromagnetic–thermal coupling simulation model has been established, combined with the characteristics of electric vehicle driving conditions, to accurately characterize the temperature rise distribution and electromagnetic parameter changes of IPMSMs under different operating conditions and achieve multi-physics field collaborative analysis. Finally, a finite element model is adopted to simulate uniform and local demagnetization of PMs, and the changing characteristics of motor performance parameters under demagnetization are summarized. Different magnitudes of d-axis reverse current are applied as demagnetization excitation to analyze PM behaviors under various demagnetization degrees. The variations in magnetic flux density, output torque, and no-load back electromotive force (EMF) before and after demagnetization are simulated and analyzed. For the investigated motor and specific magnet grade, this work summarizes the irreversible demagnetization characteristics and corresponding practical judgment references. Full article

This paper presents an application-oriented evaluation of a 130 kW interior permanent magnet synchronous motor (IPMSM) for C-segment electric vehicle (EV) traction by linking sequentially coupled multiphysics analysis with WLTP-based vehicle system-level simulation. Conventional motor performance evaluation is based on single-physics analysis at a limited number of operating points. This approach is insufficient to capture nonlinear characteristic variations under changing operating conditions or to reflect realistic driving environments. To overcome this limitation, sequentially coupled multiphysics analysis incorporating electromagnetic, thermal, and structural characteristics was performed, and the resulting loss data were incorporated into a vehicle system-level simulation model. The WLTP Class 3b driving cycle was applied to quantitatively evaluate energy performance under realistic driving conditions. The results show that the designed IPMSM satisfies the target output power of 130 kW, while its electromagnetic, thermal, and structural characteristics, including torque ripple, back-EMF, winding temperature, permanent magnet temperature, and rotor stress, remain within acceptable limits. The system-level analysis further indicates that the motor operating points during driving are predominantly distributed in the high-efficiency region, and that the final energy economy considering regenerative braking reaches 5.59 km/kWh, with an estimated maximum driving range of 352.58 km on a single charge. These results indicate that the combined motor-level and vehicle-level numerical evaluation can provide useful design-stage information for assessing high-power-density EV traction motors. Full article

Traditional optimization methods for interior permanent magnet synchronous motors (IPMSMs) often treat the stator and rotor as independent design domains, which limits the potential for suppressing torque fluctuations due to the neglected electromagnetic coupling between these components. This paper proposes a synergistic optimization strategy for a 120 kW IPMSM, aiming to overcome the inherent limitations of conventional unilateral optimization in design space exploration and achieve global performance enhancement through cross-domain collaboration. By establishing a unified surrogate model incorporating both stator slot geometries and rotor pole topologies, the collaborative effect of seven high-sensitivity design variables is systematically analyzed. The NSGA-II algorithm, coupled with a Kriging surrogate model, is employed to navigate the complex trade-offs among average torque, torque ripple, and cogging torque. Results demonstrate that the synergistic approach achieves a 28.1% reduction in torque ripple while maintaining high average torque, demonstrating superior improvement over conventional stator-only or rotor-only optimization schemes. Analysis based on Maxwell stress tensors and air-gap permeance functions reveals that the proposed method achieves simultaneous suppression of cogging torque and torque ripple by effectively harmonizing the 24th and 48th spatial harmonics. This study provides an efficient synergistic design methodology for the comprehensive performance enhancement of traction motors, offering practical reference value for the engineering development of high-performance electric vehicles. Full article

Interior permanent magnet synchronous motors (IPMSMs) offer performance advantages such as saliency effect, high mechanical strength, and a wide speed regulation range. The magnetic and mechanical properties of the core material significantly influence IPMSM performance. By investigating the effects of different core materials on IPMSM performance, an optimal material combination can be identified to enhance the overall motor performance. This paper takes a $\overline{\mathrm{V}}$-shaped IPMSM for use as a main drive motor in new energy vehicles as the research object. First, the influence of the iron loss characteristics of non-oriented silicon steel (NOSS) on IPMSM performance is analyzed, and the material selection principles for the stator and rotor cores under this condition are summarized. Subsequently, the influence of the magnetic flux density characteristics of NOSS on IPMSM performance is analyzed, and the corresponding material selection principles for the stator and rotor cores are summarized. Furthermore, ultra-high-yield-strength NOSS is applied as the motor core material to reduce the width of the rotor magnetic flux barrier, and the resulting performance advantages for the IPMSM are analyzed. Finally, prototypes of the IPMSM are manufactured and tested to validate the results of the analysis. Full article

Due to the widespread adoption of high-performance electric vehicles (EVs), Interior Permanent Magnet (IPM) machines have achieved significant advancement in the field of electric motors due to their high torque density and efficiency. However, research has been ongoing for many decades to suppress the rare-earth permanent magnet (PM) usage without sacrificing electromagnetic performance while still achieving the required torque, power, and efficiency. In this regard, various EV manufacturers, such as Honda, Toyota, Chevrolet, BMW, and Nissan, have developed different types of IPM topologies; however, the rare-earth PM usage is extensively high, and the torque density is lower. Thus, to reduce the PM consumption and improve the electromagnetic performance, especially torque density, this paper proposes a novel segmented delta-shaped IPM (SΔ-IPM) with a three-notched rotor pole shape having two different specifications and featuring embedded circular flux barriers and an intermediate flux bridge. Secondly, torque performance is analytically discussed, and electromagnetic performance has been evaluated using 2D finite element analysis (FEA). Due to its unique design featuring improved magnetic field shifting, an average torque of 393.7 Nm with torque ripples of 5.1% and a cogging torque of 0.57 Nm has been achieved. Finally, an extensive comparative analysis of the aforementioned ten state-of-the-art industry models has been conducted, which confirms the effectiveness of the proposed design for high torque density with minimum PM usage. Full article

Dual three-phase interior permanent magnet synchronous motors (DT-IPMSMs) are widely used in high-power and high-reliability applications, and accurate rotor polarity identification at startup is a critical prerequisite for their stable and efficient operation. This study aims to address the problem of initial position acquisition during the startup of DT-IPMSMs by proposing a simple and fast rotor polarity identification method. The proposed method is based on the high-frequency square-wave voltage injection (HFSWVI) in the vector space decomposition (VSD) space, where both the current and voltage are injected into the d-axis. The single-pulse direct current (DC) injection is used to alter the magnetic saturation. Then, the change rates of the d-axis high-frequency response current are compared before and after DC injection to identify the rotor magnetic polarity. In addition, a moving average filter (MAF) is applied to suppress the fluctuations in the current change rate, which increases the accuracy of polarity identification. Moreover, a simple compensation technique is designed to make the estimated d-axis current change smoothly when the estimated angle changes from N-pole to S-pole. The effectiveness of the proposed method is proved by the experimental results in both standstill and free-running states for the prototyped DT-IPMSMs. This method provides a practical and efficient solution for initial position identification of DT-IPMSMs, contributing to the advancement of control technology for dual three-phase motor systems in related fields. Full article

This study explores an integrated multi-physics design approach for a high-speed Interior Permanent Magnet Synchronous Motor (IPMSM) optimized for marine diesel engine Exhaust Gas Recirculation (EGR) blower systems. To satisfy the rigorous operational demands of marine environments, an IPMSM with a rated output of 150 kW and a base speed of 9000 rpm was developed. The design validity was rigorously verified through a comprehensive multi-physics framework using the Finite Element Method (FEM), ensuring a balance between electromagnetic, thermal, and mechanical performance. The investigation established a mathematical model for the IPMSM driven by a Space Vector Pulse-Width Modulation (SVPWM) inverter, facilitating a detailed analysis of steady-state characteristics within the EGR system. To guarantee long-term reliability at high rotational speeds, the study performed an integrated thermal analysis based on precise electrical loss separation and a rotor-dynamic evaluation focusing on unbalanced vibration responses of the shaft. Finally, the proposed design was validated by integrating the IPMSM into a full-scale EGR blower system. Experimental evaluations across the entire operating range confirm that the integrated design successfully achieves the high power density and mechanical robustness required for marine diesel applications. Full article

Driven by the evolution of electric drive systems in electric vehicles, aerospace, and industrial machine tools, high-speed operation has become a key direction in motor development. While progress in emerging manufacturing technologies and novel materials has partially alleviated the inherent contradiction between electromagnetic performance and mechanical strength in high-speed rotors, traditional approaches—including geometric optimization of flux bridges and center posts, macroscopic material replacement, and structural reinforcements—tend to make the multi-physics trade-offs increasingly complex. The application of dual-phase soft magnetic laminate presents a promising alternative. By achieving localized regulation of rotor characteristics, this approach effectively decouples electromagnetic performance from mechanical constraints. Although the technical merits have been verified, the existing literature lacks a systematic overview of the fabrication technologies and application status of dual-phase soft magnetic material laminate. Hence, this paper aims to provide a comprehensive review of recent fabrication approaches and development trends, thereby serving as a fundamental reference for researchers aiming to integrate this material into innovative rotor topologies. Full article

The electric cylinder has become a research hotspot in the future because of its high energy efficiency and excellent dynamic performance. The electric cylinder is driven by a permanent magnet synchronous motor (PMSM). However, the existing high-performance control strategies of permanent magnet synchronous motor, such as sliding mode variable structure control (SMC), model predictive control (MPC), and load torque feedforward, often face the challenge of unknown load torque when improving dynamic performance. The traditional load observation methods of PMSM involve the dq-axis inductance, which neglects the impact of inductance variation in interior PMSM (IPMSM) caused by the cross-coupling effect, flux weakening, or magnetic saturation effect. In this paper, a super-twisting sliding mode robust load observer (ST-RLO) is proposed, which performs load torque observation without reliance on inductance parameters. The feasibility and stability of the observer are analyzed theoretically. Experiments are carried out. The results show that compared with the conventional Luenberger load observer (CLLO) involving inductance, a better observation of the load torque is achieved by the ST-RLO, which has a better robustness for inductance variations and mismatching of inductance and inertia parameters. Full article

High-performance speed regulation of interior permanent magnet synchronous motor (IPMSM) drives in electric vehicle (EV) applications becomes particularly challenging in the field-weakening region, where voltage constraints, parameter variations, and nonlinear aerodynamic loads significantly affect the closed-loop stability. To address these challenges, this paper proposes a stability-aware adaptive fractional-order speed control framework for EV traction systems. The framework integrates a fractional-order PI (FOPI) core to provide iso-damping robustness, a bounded fuzzy gain-scheduling mechanism for real-time adaptation, and an offline multi-objective optimization layer for systematic parameter tuning. A Lyapunov-based qualitative analysis is provided to justify closed-loop ultimate boundedness under adaptive gain modulation and field-weakening constraints. The fuzzy scheduler is explicitly structured to regulate the error energy dissipation rate by modulating the proportional and integral gains while preserving the gain boundedness. The controller parameters are optimized using a diversity-driven fractional-order multi-objective PSO algorithm to balance the tracking accuracy and control effort. The proposed framework was validated using a high-fidelity MATLAB/Simulink–CarSim 2023 co-simulation platform under the aggressive US06 driving cycle. The results demonstrated a zero-overshoot transient response, robustness against a 2.5× inertia mismatch, and sustained performance under flux-linkage and inductance variations in deep field-weakening operation. Compared with conventional PI-based strategies, the proposed approach reduced the speed RMSE by 82%, lowered the current THD from 18.5% to 3.2%, and reduced the cumulative DC-link current-squared index by 6.7%. These results validate the practical robustness and computational feasibility of the proposed stability-aware framework for EV traction control. Full article

This study proposes an electromagnetic design strategy to improve the energy efficiency of electric-vehicle (EV) traction motors by defining an operating region with high energy contribution using Urban Dynamometer Driving Schedule (UDDS) data and targeting efficiency improvement within that region. For distributed-winding (DW) and concentrated-winding (CW) IPMSM models, the stator-to-rotor diameter ratio varied, and the resulting change in the loading ratio was used as an indicator to evaluate loss and efficiency variations in the energy-weighted region of the efficiency map via two-dimensional finite element analysis (2D FEA). The results show that the losses within the weighted region decreased by up to 16.64% compared with the reference model, and the UDDS-cycle-based overall energy efficiency improved by up to 0.423%. These findings demonstrate that combining electromagnetic geometric design with driving-cycle data can serve as a practical metric for improving EV energy efficiency. Full article

Energy scarcity has evolved into one of the most pressing challenges confronting the global community today. Fuel-driven loaders suffer from drawbacks such as high fuel consumption, low energy conversion efficiency, and heavy pollution, which not only aggravate atmospheric environmental pollution but also exacerbate the global energy crisis, directly undermining sustainable development goals. In contrast, permanent magnet synchronous motors (PMSMs) have become the preferred choice for the electrification of loaders owing to their exceptional torque density, strong overload capacity, and high reliability. However, during the optimal design of high-power interior permanent magnet synchronous motors (IPMSMs), traditional methods encounter issues with inadequate optimization efficiency and excessive computational expenses, thus hindering the large-scale deployment of power systems for eco-friendly loaders. Therefore, this paper takes a 125 kW, 3000 rpm IPMSM as the research object and proposes a multi-objective optimization strategy integrating a high-precision surrogate model with modern intelligent algorithms. This approach not only enhances motor performance but also cuts down computational overhead, which holds considerable significance for reducing industrial carbon emissions and driving the sustainable development of the manufacturing industry. Taking the key performance of IPMSM as the optimization objective and the related structural parameters as the optimization variables, the multi-performance characteristic index, interaction effect and comprehensive sensitivity of the variables are calculated and analyzed by fuzzy Taguchi experiment, and the hierarchical dimension reduction in the variables is completed. The Multicriteria Optimal-Latin Hypercube Sampling (MO-LHS) method is adopted to construct the sample data space, and a back-propagation neural network (BPNN) surrogate model is used to predict and fit the motor performance. The second-generation non-dominated sorting genetic algorithm (NSGA-II) is employed for iterative optimization, and the optimized motor dimension parameters are obtained through the Pareto optimal solution. Finally, through finite element analysis (FEA) and experiments, the rated torques obtained are 417.6 N·m and 425.1 N·m, respectively, with an error not exceeding 1.8%. This verifies the correctness and effectiveness of the proposed multi-objective optimization method based on the surrogate model. Full article
