FY-4B/GIIRS (Geostationary Interferometric Infrared Sounder) is a new-generation infrared hyperspectral atmospheric vertical sounder onboard a Chinese geostationary meteorological satellite. Its observations with high spatial and temporal resolution play an important role in high-impact weather forecasts. The GIIRS data assimilation module is developed in the GSI (Gridpoint Statistical Interpolation) assimilation system. Super Typhoon Doksuri in 2023 (No. 5) is taken as an example based on this module in this paper. Firstly, the sensitivity of analysis fields to five data thinning schemes at four daily assimilation times from 22 to 28 July 2023 is analyzed: the wavelet transform modulus maxima (WTMM) scheme, the grid-distance schemes of 30 km, 60 km, and 120 km in the GSI assimilation system, and a center field of view (FOV) scheme. Taking the ERA5 reanalysis fields as true, it is found that the mean error of temperature and humidity analysis for the WTMM scheme is the smallest, followed by the 120 km thinning scheme. Subsequently, a 72 h cycling assimilation and forecast experiments are conducted for the WTMM and 120 km thinning schemes. It is found that the root mean square error (RMSE) profiles of temperature and humidity forecast fields with no thinning scheme are the largest at all pressure levels and forecast times. The temperature forecast error decreases after data thinning at altitudes below 300 hPa. Since the WTMM scheme has assimilated more observations than the 120 km scheme, the accuracy of its temperature and humidity forecast fields gradually increases with the forecast time. In terms of typhoon track and intensity forecast, the typhoon intensities are underestimated before landfall and overestimated after landfall for all thinning schemes. As the forecast time increases, the advantage of the WTMM is increasingly evident, with both the forecast intensity and track being closest to the actual observations. Similarly, the forecasted 24 h accumulated precipitation over land is overestimated after typhoon landfall compared with the IMERG Final precipitation products. The location of precipitation simulated by no thinning scheme is more westward overall. The forecast accuracy of the locations and intensities of severe precipitation cores and the typhoon’s outer spiral rain bands over the South China Sea has been improved after thinning. The Equitable Threat Scores (ETSs) of the WTMM thinning scheme are the highest for most precipitation intensity thresholds. Full article

Ship targets are usually high-value targets, and synthetic aperture radar (SAR) moving ship indication is of great importance in maritime traffic monitoring. However, due to the motion of the ocean, maritime ships may have rotational motion in addition to the conventional translational motion. The rotational motion, including the yaw, pitch, and roll, will cause the signal characteristics of the ship to become very complex, which increases the difficulty of designing moving target indication methods. This paper studies the effect of each rotation motion on the ship’s signal characteristics in image domain for spaceborne multichannel SAR. Firstly, the range equation of an arbitrary scatterer on the ship with both rotational and translational motions is developed. Then, the influences of each rotation motion on the coefficients of the range equation and the scatterer’s along-track interferometric (ATI) phase are revealed. Finally, numerical experiments are conducted to investigate the effect of each rotation motion on the scatterer’s azimuth position shift, azimuth defocusing, azimuth sidelobe symmetry, and ATI phase, which are important parameters for moving target indication. Full article

This study presents the experimental optimization of an interferometric optical fiber sensor for acoustic emission (AE) detection. The system employs a simple and low-cost structure composed of sensing and reference fibers, enabling interference-based detection without specialized components such as fiber Bragg gratings or Fabry–Perot cavities. A narrowband laser source was selected through comparative experiments for its superior stability and interference performance. The influence of fiber-loop parameters, including the number of turns and the optical-path intensity ratio, was systematically evaluated to clarify their effects on AE sensitivity and frequency response. The experimental results demonstrate that detection performance and bandwidth can be flexibly tuned by optimizing the loop configuration. Finally, the sensor was validated using a tensile test, successfully detecting AE signals in the range of 20 kHz to 1 MHz. The proposed system provides a robust, EMI-resistant, and cost-effective interferometric solution for AE monitoring. Full article

Periodic nonlinear error (PNE) is a key factor limiting the accuracy of displacement measurement instruments. For grating interferometers, which are widely used in high-precision displacement measurement, reliable characterization of PNE is essential. Conventional evaluation methods that rely on higher-precision instruments become unsuitable for ultra-high-accuracy systems. Although the self-evaluation method based on Lissajous figures are commonly used, their results inherently depend on the grating parameters and the interferometric signals themselves, leading to a lack of traceability and reduced credibility of the results. In this work, we propose a traceable self-evaluation method for assessing the PNE of a directly traceable grating interferometer (DTGI). The DTGI employs a chromium (Cr) atom lithography grating, whose pitch is directly traceable to the atomic transition frequency of Cr (⁷S₃ → ⁷P₄), as its displacement reference, thereby overcoming the traceability deficiencies of conventional self-evaluation methods. Numerical simulations confirm the validity of the proposed method, and experiments performed on a laboratory-built DTGI demonstrate 10-picometer-level PNE after Heydemann correction within micrometer range displacements. These results confirm the method’s suitability for metrological applications requiring stringent linearity performance in nanometric displacement measurement. Full article

Phase optimization, aimed to enhance phase signal-to-noise ratio, is a critical component of the distributed scatterer interferometric synthetic aperture radar technique and directly determines the fineness and reliability of deformation monitoring. As a state-of-the-art method that balances computational efficiency and optimization performance in high-dimensional data environments, sequential phase optimization has been widely studied. However, the improper matrix partitioning and discontinuous sequence compensation in current sequential methods severely restrict their optimization performance. To address these limitations, an adaptive sequential phase optimization method (AdSeq) based on coherence stability detection and adjustment correction is proposed. A submatrix dimension adaptive estimation model driven by coherence stability detection is first established based on persistent exceedance detection analysis. Then, a covariance matrix adaptive sequential partitioning strategy is developed by introducing the submatrix overlap criterion. Finally, a phase reference correction model based on weighted least squares adjustment is proposed to improve phase continuity and overall optimization performance. Experiments with simulated and real datasets are performed to comprehensively evaluate the optimization performance. Experimental results demonstrate that, compared with traditional phase optimization methods, the monitoring point density obtained by AdSeq increased by over 21.07%, and the deformation monitoring accuracy reached 16.49 mm, representing an improvement exceeding 10.09%. These results confirm that the proposed AdSeq method achieves superior noise robustness and phase optimization performance, and provides a higher deformation monitoring accuracy. Full article

Controlling light’s polarization through disordered media is crucial for advanced optical applications but remains challenging due to scattering and depolarization. Most existing approaches either require interferometric or multi-path measurements, or they recover only part of the polarization response. We present a comprehensive approach for spatially resolved polarization control by accurately retrieving the vector transmission matrix (VTM) of a scattering system from intensity-only, full-Stokes polarimetric measurements. Using a simple single-path setup comprising a liquid-crystal spatial light modulator (SLM) with a tunable retarder after it, we achieve spatial polarization modulation at the input, thereby enabling probing of the medium’s polarization–scattering characteristics. The VTM is retrieved with an adapted Gerchberg–Saxton procedure that enforces not only the measured output amplitudes but also the relative phase between the two orthogonal output polarization components obtained from the Stokes parameters. We show that a single retarder setting results in inter-block correlations in the retrieved VTM due to input coupling, while two linearly independent retarder settings decouple the intrinsic blocks and recover the full VTM. In our experiment, for a $16\times 16$ set of input–output spatial modes, the VTM is retrieved with about $90\%$ accuracy, enabling polarization-resolved focusing with up to $10\times$ enhancement for horizontal, vertical, arbitrary linear, and circular states. This work offers a compact framework for active polarization shaping and for polarimetric characterization of complex media, advancing our understanding of vectorial light–matter interactions. Full article

Owing to their high vertical resolution, remote sensing data from meteorological satellite hyperspectral infrared sounders are well-suited for the identification, monitoring, and early warning of high-impact weather events. The effective utilization of full field-of-view (FOV) observations from satellite infrared sounders in high-impact weather applications remains a major research focus and technical challenge worldwide. This study proposes a generalized variational retrieval framework to estimate full FOV cloud fraction and precipitable water vapor (PWV) from observations of the Geostationary Interferometric Infrared Sounder (GIIRS) onboard the Fengyun-4A (FY-4A) satellite. Based on this method, experiments are performed using high-frequency FY-4A/GIIRS observations during the landfall periods of Typhoon Lekima (2019) and Typhoon Higos (2020). A three-step channel selection strategy based on information entropy is first designed for FY-4A/GIIRS. A constrained generalized variational retrieval method coupled with a cloud cost function is then established. Cloud parameters, including effective cloud fraction and cloud-top pressure, are initially retrieved using the Minimum Residual Method (MRM) and used as initial cloud information. These parameters are iteratively optimized through cost-function minimization, yielding full FOV cloud fields and atmospheric profiles. Full FOV brightness temperature simulations are conducted over cloudy regions to quantitatively evaluate the retrieved cloud fractions, and the derived PWV is further applied to the identification and analysis of hazardous weather events. Experimental results demonstrate that incorporating cloud parameters as auxiliary inputs to the radiative transfer model improves the simulation of FY-4A/GIIRS brightness temperature in cloud-covered areas and reduces brightness temperature biases. Compared with ERA5 Total Column Water Vapour (TCWV) data, the PWV derived from full FOV profiles containing cloud parameter information shows closer agreement and, at certain FOVs, more effectively indicates the occurrence of high-impact weather events. The simplified methodology proposed in this study provides a robust basis for the future assimilation and operational utilization of infrared data over cloud-affected regions in numerical weather prediction models. Full article

Ground deformation monitoring in mining areas is essential for hazard prevention and environmental protection. Although interferometric synthetic aperture radar (InSAR) provides detailed phase information for accurate deformation measurement, its performance is often compromised in regions experiencing rapid subsidence and strong noise, where phase aliasing and coherence loss lead to significant inaccuracies. To overcome these limitations, this paper proposes JOTGLNet, a guided learning network with joint offset tracking, for multiscale deformation monitoring. This method integrates pixel offset tracking (OT), which robustly captures large-gradient displacements, with interferometric phase data that offers high sensitivity in coherent regions. A dual-path deep learning architecture was designed where the interferometric phase serves as the primary branch and OT features act as complementary information, enhancing the network’s ability to handle varying deformation rates and coherence conditions. Additionally, a novel shape perception loss combining morphological similarity measurement and error learning was introduced to improve geometric fidelity and reduce unbalanced errors across deformation regions. The model was trained on 4000 simulated samples reflecting diverse real-world scenarios and validated on 1100 test samples with a maximum deformation up to 12.6 m, achieving an average prediction error of less than 0.15 m—outperforming state-of-the-art methods whose errors exceeded 0.19 m. Additionally, experiments on five real monitoring datasets further confirmed the superiority and consistency of the proposed approach. Full article

Leveraging multi-source remote sensing datasets and dynamic groundwater monitoring well observations, this study explores the multiscale spatiotemporal linkages of groundwater storage changes and land deformation in North China Plain (NCP) after the South-to-North Water Diversion Project (SNWDP). Firstly, we employed Gravity Recovery and Climate Experiment (GRACE) and interferometric synthetic aperture radar (InSAR) technology to estimate groundwater storage (GWS) and land deformation. Secondly and significantly, we proposed a novel GRACE statistical downscaling algorithm that integrates a weight allocation strategy and GWS estimation applied with InSAR technology. Finally, the downscaled results were employed to analyze spatial differences in land deformation across typical ground fissure areas. The results indicate that (1) between 2018 and 2021, groundwater storage in the NCP exhibited a declining trend, with an average reduction of −3.81 ± 0.53 km³/a and a maximum land deformation rate of −177 mm/a; (2) the downscaled groundwater storage anomalies (GWSA) showed high correlation with in situ measurements (R = 0.75, RMSE = 2.91 cm); and (3) in the Shunyi fissure area, groundwater storage on the northern side increased continuously, with a maximum growth rate of 28 mm/a, resulting in surface uplift exceeding 70 mm. Full article

Persistent scatterer (PS) pixel selection is crucial in the PS-InSAR technique, ensuring the quality and quantity of PS pixels for accurate deformation measurements. However, traditional methods like the amplitude dispersion index (ADI)-based method struggle to balance the quality and quantity of PS pixels. To adequately select high-quality PS pixels, and thus improve the deformation measurement performance of PS-InSAR, the multi-temporal feature extraction network (MFN) is constructed in this paper. The MFN combines the 3D U-Net and the convolutional long short-term memory (CLSTM) to achieve time-series analysis. Compared with traditional methods, the proposed MFN can fully extract the spatiotemporal characteristics of complex SAR images to improve PS pixel selection performance. The MFN was trained with datasets constructed by reliable PS pixels estimated by the ADI-based method with a low threshold using ∼350 time-series Sentinel-1A SAR images, which contain man-made objects, farmland, parkland, wood, desert, and waterbody areas. To test the validity of the MFN, a deformation measurement experiment was designed for Tongzhou District, Beijing, China with 38 SAR images obtained by Sentinel-1A. Moreover, the similar time-series interferometric pixel (STIP) index was introduced to evaluate the phase stability of selected PS pixels. The experimental results indicate a significant improvement in both the quality and quantity of selected PS pixels, as well as a higher deformation measurement accuracy, compared to the traditional ADI-based method. Full article

The Geostationary Interferometric Infrared Sounder (GIIRS) on board FengYun-4B (FY-4B), a Chinese second-generation hyperspectral infrared, enables the provision of critical data for forecasting high-impact weather events such as typhoons. To evaluate the reliability of FY-4B/GIIRS data, this study conducted three comparative assimilation trials for both Typhoon Gaemi and Typhoon Doksuri, assimilating observations from the Infrared Atmospheric Sounding Interferometer (IASI), Advanced Microwave Sounding Unit-A (AMSU-A), and FY-4B/GIIRS, respectively. Results demonstrate that the assimilation of GIIRS observations yields more stable forecasts of the wind field at 300 hPa and 500 hPa compared to AMSU-A and IASI, with biases within ±6 m/s relative to NCEP FNL data. However, GIIRS assimilation produces systematic underprediction of vertical velocity, whereas AMSU-A forecasts align more closely with reanalysis. For track forecasts, the GIIRS-assimilated trajectory exhibits closer alignment with observations than AMSU-A and IASI experiments, maintaining biases below 50 km throughout 48 h forecast period of Gaemi. This study provides valuable experience for the application of FY-4B/GIIRS data assimilation. Full article

In this study, we propose a novel pixel-level non-local similarity (PNS)-based reconstruction method for millimeter-wave interferometric synthetic aperture radiometer (InSAR) imaging. Unlike traditional compressed sensing (CS) methods, which rely on predefined sparse transforms and often introduce artifacts, our approach leverages structural redundancies in InSAR images through an enhanced sparse representation model with dynamically filtered coefficients. This design simultaneously preserves fine details and suppresses noise interference. Furthermore, an iterative refinement mechanism incorporates raw sampled data fidelity constraints, enhancing reconstruction accuracy. Simulation and physical experiments demonstrate that the proposed InSAR-PNS method significantly outperforms conventional techniques: it achieves a 1.93 dB average peak signal-to-noise ratio (PSNR) improvement over CS-based reconstruction while operating at reduced sampling ratios compared to Nyquist-rate fast fourier transform (FFT) methods. The framework provides a practical and efficient solution for high-fidelity millimeter-wave InSAR imaging under sub-Nyquist sampling conditions. Full article

The Geostationary Interferometric Infrared Sounder (GIIRS) onboard the Fengyun-4B satellite plays a critical role in numerical weather prediction and extreme weather monitoring. To meet the requirements of quantitative remote sensing and high-precision operational applications for radiometric calibration accuracy, this study, based on pre-launch calibration experiments, conducts a novel modeling analysis of the coupling between stray radiation at the input side and the system’s nonlinearity, and proposes a correction method for nonlinear coupling errors. This method explicitly models and physically traces the calibration residuals caused by stray radiation introduced via non-nominal optical paths under the effect of system nonlinearity, which are related to the radiance of the observed target. Experimental results show that, within the brightness temperature range of 200–320 K, the calibration bias is reduced from approximately 0.7 to 0.3–0.4 K, with good consistency and stability observed across channels and pixels. Full article

Sea ice is highly dynamic. Differences in the sea ice drift velocity and direction can cause deformations such as ridges and rubble fields or open up leads. These and other deformations have a major impact on the interaction between the atmosphere, sea ice and the ocean, and strongly influence ship navigability in polar waters. Spaceborne Synthetic Aperture Radar (SAR) data is well suited to observing the sea ice and retrieving sea ice drift vector fields at a small scale (<1 km), revealing deformation zones. This paper introduces a software processor designed to retrieve high-resolution sea ice drift vector fields from pairs of subsequent SAR acquisitions using phase correlation embedded in a multiscale Gaussian image pyramid. We assess the accuracy of the algorithm by using drift buoys and landfast ice boundaries manually outlined from large series of TerraSAR-X acquisitions taken during winter and spring sea ice break up. In particular, we provide a first analysis of the localization accuracy in deformation zones. Overall, our experiments show that deformation zones are well detected, but can be misplaced by up to 1.1 km. An additional interferometric analysis narrows down the location of the landfast ice boundary. Full article

In the field of interferometric fiber-optic sensing, the phase-shifting technique is well known as a highly efficient method for retrieving the phase signal from the interference light intensity. The rectangular-pulse binary phase modulation (RPBPM) method is a typical phase-shifting method with the advantages of high efficiency, low complexity, and easy array multiplexing. Exploring the impact of the parameters on the performance is of great significance for guiding its application in practical systems. In this study, the influence of the sampling interval and modulation depth deviation involved in the method is analyzed in detail. Through a comparative simulation analysis with the traditional heterodyne and phase-generated carrier methods, the superiority of the RPBPM method is effectively validated. Meanwhile, an improved method based on the ellipse fitting of the Lissajous figure is proposed to compensate for the error and improve the signal-to-noise-and-distortion ratio (SINAD) from 26.3 dB to 37.1 dB in a specific experiment. Finally, the experimental results guided by the above method show excellent performance in a practical vibration system. Full article
