Search Results (21)

Search Parameters:
Keywords = helical blade turbine

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
17 pages, 4162 KiB
Article
Evaluation of Wake Structure Induced by Helical Hydrokinetic Turbine
by Erkan Alkan, Mehmet Ishak Yuce and Gökmen Öztürkmen
Water 2025, 17(15), 2203; https://doi.org/10.3390/w17152203 - 23 Jul 2025
Viewed by 188
Abstract
This study investigates the downstream wake characteristics of a helical hydrokinetic turbine through combined experimental and numerical analyses. A four-bladed helical turbine with a 20 cm rotor diameter and blockage ratio of 53.57% was tested in an open water channel under a flow [...] Read more.
This study investigates the downstream wake characteristics of a helical hydrokinetic turbine through combined experimental and numerical analyses. A four-bladed helical turbine with a 20 cm rotor diameter and blockage ratio of 53.57% was tested in an open water channel under a flow rate of 180 m3/h, corresponding to a Reynolds number of approximately 90 × 103. Velocity measurements were collected at 13 downstream cross-sections using an Acoustic Doppler Velocimeter, with each point sampled repeatedly. Standard error analysis was applied to quantify measurement uncertainty. Complementary numerical simulations were conducted in ANSYS Fluent using a steady-state k-ω Shear Stress Transport (SST) turbulence model, with a mesh of 4.7 million elements and mesh independence confirmed. Velocity deficit and turbulence intensity were employed as primary parameters to characterize the wake structure, while the analysis also focused on the recovery of cross-sectional velocity profiles to validate the extent of wake influence. Experimental results revealed a maximum velocity deficit of over 40% in the near-wake region, which gradually decreased with downstream distance, while turbulence intensity exceeded 50% near the rotor and dropped below 10% beyond 4 m. In comparison, numerical findings showed a similar trend but with lower peak velocity deficits of 16.6%. The root mean square error (RMSE) and mean absolute error (MAE) between experimental and numerical mean velocity profiles were calculated as 0.04486 and 0.03241, respectively, demonstrating reasonable agreement between the datasets. Extended simulations up to 30 m indicated that flow profiles began to resemble ambient conditions around 18–20 m. The findings highlight the importance of accurately identifying the downstream distance at which the wake effect fully dissipates, as this is crucial for determining appropriate inter-turbine spacing. The study also discusses potential sources of discrepancies between experimental and numerical results, as well as the limitations of the modeling approach. Full article
(This article belongs to the Special Issue Optimization-Simulation Modeling of Sustainable Water Resource)
Show Figures

Figure 1

18 pages, 11288 KiB
Article
Quality Evaluation of Micro-Holes Processed by Efficient One-Step Femtosecond Laser Helical Drilling Method in Nickel-Based Superalloy
by Mingquan Li, Yiyu Chen, Li Dong, Dan Liu and Xudong Sun
Appl. Sci. 2025, 15(8), 4384; https://doi.org/10.3390/app15084384 - 16 Apr 2025
Viewed by 365
Abstract
This research work details the main factors affecting the orifice and profile morphology of micro-holes processed by the one-step femtosecond laser helical drilling method. Cylindrical holes or even inverted cone holes can be obtained with the appropriate deflection angle and translation distance. The [...] Read more.
This research work details the main factors affecting the orifice and profile morphology of micro-holes processed by the one-step femtosecond laser helical drilling method. Cylindrical holes or even inverted cone holes can be obtained with the appropriate deflection angle and translation distance. The orifice morphology of the micro-hole is mainly influenced by the rotation speed of the Dove prism installed inside the hollow motor, laser output power, and laser repetition frequency. A higher instantaneous power density can improve the outlet morphology and produce sharper cutting edges and thinner recast layers, although it may increase the splashing around the inlet to some extent. Subsequent to the experiment, it was determined that in order to enhance the quality of the holes, it was necessary to select a higher laser power and a lower repetition frequency, such as 10 W and 100 kHz, according to the experiments. A recast layer thickness of less than 5 µm and a surface roughness value of less than 0.8 µm were obtained within 3–5 s processing time, which can satisfy the requirements for aircraft application of efficiency and quality. Full article
(This article belongs to the Section Additive Manufacturing Technologies)
Show Figures

Figure 1

19 pages, 3362 KiB
Article
DyTAM: Accelerating Wind Turbine Inspections with Dynamic UAV Trajectory Adaptation
by Serhii Svystun, Lukasz Scislo, Marcin Pawlik, Oleksandr Melnychenko, Pavlo Radiuk, Oleg Savenko and Anatoliy Sachenko
Energies 2025, 18(7), 1823; https://doi.org/10.3390/en18071823 - 4 Apr 2025
Viewed by 573
Abstract
Wind energy’s crucial role in global sustainability necessitates efficient wind turbine maintenance, traditionally hindered by labor-intensive, risky manual inspections. UAV-based inspections offer improvements yet often lack adaptability to dynamic conditions like blade pitch and wind. To overcome these limitations and enhance inspection efficacy, [...] Read more.
Wind energy’s crucial role in global sustainability necessitates efficient wind turbine maintenance, traditionally hindered by labor-intensive, risky manual inspections. UAV-based inspections offer improvements yet often lack adaptability to dynamic conditions like blade pitch and wind. To overcome these limitations and enhance inspection efficacy, we introduce the Dynamic Trajectory Adaptation Method (DyTAM), a novel approach for automated wind turbine inspections using UAVs. Within the proposed DyTAM, real-time image segmentation identifies key turbine components—blades, tower, and nacelle—from the initial viewpoint. Subsequently, the system dynamically computes blade pitch angles, classifying them into acute, vertical, and horizontal tilts. Based on this classification, DyTAM employs specialized, parameterized trajectory models—spiral, helical, and offset-line paths—tailored for each component and blade orientation. DyTAM allows for cutting total inspection time by 78% over manual approaches, decreasing path length by 17%, and boosting blade coverage by 6%. Field trials at a commercial site under challenging wind conditions show that deviations from planned trajectories are lowered by 68%. By integrating advanced path models (spiral, helical, and offset-line) with robust optical sensing, the DyTAM-based system streamlines the inspection process and ensures high-quality data capture. The dynamic adaptation is achieved through a closed-loop control system where real-time visual data from the UAV’s camera is continuously processed to update the flight trajectory on the fly, ensuring optimal inspection angles and distances are maintained regardless of blade position or external disturbances. The proposed method is scalable and can be extended to multi-UAV scenarios, laying a foundation for future efforts in real-time, large-scale wind infrastructure monitoring. Full article
(This article belongs to the Special Issue Recent Advances in Wind Turbines)
Show Figures

Figure 1

24 pages, 16319 KiB
Article
Influence of Airfoil Curvature and Blade Angle on Vertical Axis Hydraulic Turbine Performance in Low Flow Conditions
by Chunyun Shen, Yubing Han, Shiming Wang and Zekun Wang
Water 2025, 17(1), 11; https://doi.org/10.3390/w17010011 - 24 Dec 2024
Cited by 1 | Viewed by 1455
Abstract
The vertical axis hydrokinetic turbine is increasingly being used as a renewable energy device to harness tidal energy. In coastal regions with low tidal flow velocities, vertical-axis hydrokinetic turbines often exhibit low energy conversion efficiency, limiting their engineering applications. However, research in this [...] Read more.
The vertical axis hydrokinetic turbine is increasingly being used as a renewable energy device to harness tidal energy. In coastal regions with low tidal flow velocities, vertical-axis hydrokinetic turbines often exhibit low energy conversion efficiency, limiting their engineering applications. However, research in this field lacks systematic reviews and reliable solutions for improving efficiency. The paper, based on the traditional vertical axis hydrokinetic turbines, utilized numerical calculations and experimental methods to investigate the effects of blade helicity and airfoil curvature on the energy conversion efficiency of vertical axis hydrokinetic turbines in low flow velocity conditions. Additionally, an improved vertical-axis turbine model is proposed to enhance energy conversion efficiency in low-flow environments. The results indicate that increasing the blade helical angle and airfoil curvature can better optimize the flow conditions around the turbine, significantly improving the energy conversion efficiency of vertical axis turbines. The airfoil blade with a 20% curvature performs best at blade angle, with its power coefficient curve reaching higher peak values at several azimuth angles. At this point, the maximum efficiency reaches 24.42%. Compared to the conventional straight-blade design, the improved turbine model exhibits 6.13% increase in average energy capture efficiency, 3.70% increase in average dynamic torque, and 11.1% improvement in self-starting performance. Comparative analysis reveals that vertical-axis helical blade turbines exhibit superior hydrodynamic performance under low-flow conditions, effectively overcoming the limitations of conventional straight-blade turbines, including poor self-starting capability and low efficiency. This research provides valuable insights into improving the performance of vertical-axis turbines in low-flow environments and suggests innovative solutions for optimizing turbine design. Full article
(This article belongs to the Section Hydraulics and Hydrodynamics)
Show Figures

Figure 1

21 pages, 3854 KiB
Article
Optimization of a Gorlov Helical Turbine for Hydrokinetic Application Using the Response Surface Methodology and Experimental Tests
by Juan Camilo Pineda, Ainhoa Rubio-Clemente and Edwin Chica
Energies 2024, 17(22), 5747; https://doi.org/10.3390/en17225747 - 17 Nov 2024
Cited by 2 | Viewed by 1580
Abstract
The work presents an analysis of the Gorlov helical turbine (GHT) design using both computational fluid dynamics (CFD) simulations and response surface methodology (RSM). The RSM method was applied to investigate the impact of three geometric factors on the turbine’s power coefficient (C [...] Read more.
The work presents an analysis of the Gorlov helical turbine (GHT) design using both computational fluid dynamics (CFD) simulations and response surface methodology (RSM). The RSM method was applied to investigate the impact of three geometric factors on the turbine’s power coefficient (CP): the number of blades (N), helix angle (γ), and aspect ratio (AR). Central composite design (CCD) was used for the design of experiments (DOE). For the CFD simulations, a three-dimensional computational domain was established in the Ansys Fluent software, version 2021R1 utilizing the k-ω SST turbulence model and the sliding mesh method to perform unsteady flow simulations. The objective function was to achieve the maximum CP, which was obtained using a high-correlation quadratic mathematical model. Under the optimum conditions, where N, γ, and AR were 5, 78°, and 0.6, respectively, a CP value of 0.3072 was achieved. The optimal turbine geometry was validated through experimental testing, and the CP curve versus tip speed ratio (TSR) was determined and compared with the numerical results, which showed a strong correlation between the two sets of data. Full article
(This article belongs to the Section B: Energy and Environment)
Show Figures

Figure 1

22 pages, 8775 KiB
Article
Analysis of the Accuracy of CAD Modeling in Engineering and Medical Industries Based on Measurement Data Using Reverse Engineering Methods
by Paweł Turek, Wojciech Bezłada, Klaudia Cierpisz, Karol Dubiel, Adrian Frydrych and Jacek Misiura
Designs 2024, 8(3), 50; https://doi.org/10.3390/designs8030050 - 24 May 2024
Cited by 5 | Viewed by 2464
Abstract
The reverse engineering (RE) process is often necessary in today’s engineering and medical industries. Expertise in measurement technology, data processing, and CAD modeling is required to ensure accurate reconstruction of an object’s geometry. However, errors are generated at every stage of geometric reconstruction, [...] Read more.
The reverse engineering (RE) process is often necessary in today’s engineering and medical industries. Expertise in measurement technology, data processing, and CAD modeling is required to ensure accurate reconstruction of an object’s geometry. However, errors are generated at every stage of geometric reconstruction, affecting the dimensional and geometric accuracy of the final 3D-CAD model. In this article, the geometry of reconstructed models was measured using contact and optical methods. The measurement data representing 2D profiles, 3D point clouds, and 2D images acquired in the reconstruction process were saved to a stereolithography (STL) model. The reconstructed models were then subjected to a CAD modeling process, and the accuracy of the parametric modeling was evaluated by comparing the 3D-CAD model to the 3D-STL model. Based on the results, the model used for clamping and positioning parts to perform the machining process and the connecting rod provided the most accurate mapping errors. These models represented deviations within ±0.02 mm and ±0.05 mm. The accuracy of CAD modeling for the turbine blade model and the pelvis part was comparable, presenting deviations within ±0.1 mm. However, the helical gear and the femur models showed the highest deviations of about ±0.2 mm. The procedures presented in the article specify the methods and resolution of the measurement systems and suggest CAD modeling strategies to minimize reconstruction errors. These results can be used as a starting point for further tests to optimize CAD modeling procedures based on the obtained measurement data. Full article
Show Figures

Figure 1

18 pages, 9366 KiB
Article
Analysis of the Sand Erosion Effect and Wear Mechanism of Wind Turbine Blade Coating
by Jian Wang, Jin Gao, Yong Zhang and Hongmei Cui
Energies 2024, 17(2), 413; https://doi.org/10.3390/en17020413 - 15 Jan 2024
Cited by 2 | Viewed by 2730
Abstract
The wind–sand climate prevalent in the central and western regions of Inner Mongolia results in significant damage to wind turbine blade coatings due to sand erosion. This not only leads to a decline in power generation but also poses safety risks. This study [...] Read more.
The wind–sand climate prevalent in the central and western regions of Inner Mongolia results in significant damage to wind turbine blade coatings due to sand erosion. This not only leads to a decline in power generation but also poses safety risks. This study replicated the wind–sand environment of Alashan and numerically simulated the erosion and wear process of the blade coatings of a 1.5 MW horizontal axis wind turbine under rotational conditions using the DPM model. Additionally, erosion tests were conducted on the operating wind rotor in a wind tunnel. The simulation results demonstrate that sand particle trajectories in the rotating domain are influenced by vortex, incoming wind speed, and sand particle size. For small-sized sand particles, variations in wind speed do not substantially alter the number of particles in contact with the wind turbine blades. However, alterations in the momentum of these particles lead to changes in the impact force on the coating surface. Conversely, the change of wind speed will not only alter the number of large-size sand particles in contact with the wind rotor but also modify the impact force on the coating surface. Furthermore, after impacting the blade, small sand particles continue to move along an approximate helical trajectory with the airflow, while large-size sand particles swiftly rebound. Through statistical analysis of erosion pits on the blade surface after the erosion experiments, it was observed that, in comparison among the leading edge, windward side, trailing edge, and leeward side, the leading edge presents the greatest number of erosion pits, whereas the leeward side has the fewest. Along the spanwise direction, the 0.7R-blade tip segment exhibits the highest count, while the blade root-0.3R section displays the fewest number of pits. The wear morphology of the blade coating was observed from the blade root to tip. The leading edge coating exhibits a range from shallow pits to coating flaking and deeper gouge pits. On the windward side, the coating displays wear patterns varying from tiny cutting pits to cutting marks, and then to gouge pits and coating flaking. Erosion morphology of the trailing edge evolves from only minor scratches to spalling pits, further deepening and enlarging. These research findings provide a basis for the study of zoning-adapted coating materials for wind turbine blades in wind–sand environments. Full article
(This article belongs to the Section A3: Wind, Wave and Tidal Energy)
Show Figures

Figure 1

22 pages, 16393 KiB
Article
Analysis of the Energy Loss Mechanism of Pump-Turbines with Splitter Blades under Different Characteristic Heads
by Zhonghua Gui, Zhe Xu, Dongkuo Li, Fei Zhang, Yifeng Zhao, Lianchen Xu, Yuan Zheng and Kan Kan
Water 2023, 15(15), 2776; https://doi.org/10.3390/w15152776 - 31 Jul 2023
Cited by 5 | Viewed by 1928
Abstract
The operating efficiency of high-head pump turbines is closely related to the internal hydraulic losses within the system. Conventional methods for calculating hydraulic losses based on pressure differences often lack detailed information on their distribution and specific sources. Additionally, the presence of splitter [...] Read more.
The operating efficiency of high-head pump turbines is closely related to the internal hydraulic losses within the system. Conventional methods for calculating hydraulic losses based on pressure differences often lack detailed information on their distribution and specific sources. Additionally, the presence of splitter blades further complicates the hydraulic loss characteristics, necessitating further study. In this study, Reynolds-averaged Navier–Stokes (RANS) simulations were employed to analyze the performance of a pump turbine with splitter blades at three different head conditions and a guide vane opening (GVO) of 10°. The numerical simulations were validated by experimental tests using laser doppler velocimetry (LDV). Quantitative analysis of flow components and hydraulic losses was conducted using entropy production theory in combination with an examination of flow field distributions to identify the origins and features of hydraulic losses. The results indicate that higher heads are associated with lower growth rates of total hydraulic losses. In particular, the significant velocity gradients at the trailing edge of the splitter blades contribute to higher hydraulic losses. Furthermore, the hydraulic losses in the runner (RN) region are predominantly influenced by velocity gradients and not by vortices, with the flow conditions in the RN region impacting the hydraulic losses in the draft tube (DT). Full article
(This article belongs to the Special Issue Advances in Hydrodynamics of Water Pump Station System)
Show Figures

Figure 1

16 pages, 10807 KiB
Article
Preliminary Test for 3D Surface Strain Measurement in the Tower and Foundation of Offshore Wind Turbines Using DOFS
by Taolue Yang, Tao Tao, Xinran Guo, Yi Yang and Shi Liu
Sensors 2023, 23(15), 6734; https://doi.org/10.3390/s23156734 - 27 Jul 2023
Cited by 3 | Viewed by 2049
Abstract
Subjected to the relentless impacts of typhoons and rough seas, offshore wind turbines’ structures, particularly the tower, foundation, and blade, are at constant risk of damage. Full-field strain monitoring helps to discover potential structural defects, thereby reducing disasters caused by overall structural failure. [...] Read more.
Subjected to the relentless impacts of typhoons and rough seas, offshore wind turbines’ structures, particularly the tower, foundation, and blade, are at constant risk of damage. Full-field strain monitoring helps to discover potential structural defects, thereby reducing disasters caused by overall structural failure. This study introduces a novel method for assessing strain and temperature fields on these kinds of 3D surfaces of cylindrical structures. The method harnesses the capabilities of a high spatial resolution (0.65 mm) Optical Frequency Domain Reflectometer (OFDR)-based Distributed Optical Fiber Sensor (DOFS) in conjunction with a unique helical wiring layout. The core process begins with mapping the fiber optic path onto a plane corresponding to the unfolded cylinder. Fiber optic signals are then differentiated on this plane, deriving a two-dimensional strain distribution. The plane strain field is subsequently projected onto the 3D side of the cylinder. An experiment was carried out in which a 3.5 m long optical fiber was helically wound with a 10 mm pitch on the surface of a cantilever beam of a cylinder shell with a diameter of 36 mm and a length of 300 mm. The experiment collected about 5400 measurement points on the cylindrical surface of 340 cm2, approximately 15.9 measurement points per square centimeter. The reconstructed results successfully reveal the strain field of the pipe cantilever beam under bending and torsional loads, as well as the palm-shaped temperature field. This experimental validation of the method’s efficacy lays the theoretical groundwork for its application to real wind turbines. Full article
Show Figures

Figure 1

9 pages, 3534 KiB
Proceeding Paper
Experimental Comparison between Hydrokinetic Turbines: Darrieus vs. Gorlov
by Rodolfo Espina-Valdés, Ahmed Gharib-Yosry, Roberta Ferraiuolo, Aitor Fernández-Jiménez and Victor Manuel Fernández-Pacheco
Environ. Sci. Proc. 2022, 21(1), 26; https://doi.org/10.3390/environsciproc2022021026 - 20 Oct 2022
Viewed by 3204
Abstract
In this research, the influence of blade geometry on the power stage characterization of cross-flow hydrokinetic turbines and vertical axis under conditions of low current velocity (<1 m/s) has been studied. To carry out the characterization of the power stage, two turbines have [...] Read more.
In this research, the influence of blade geometry on the power stage characterization of cross-flow hydrokinetic turbines and vertical axis under conditions of low current velocity (<1 m/s) has been studied. To carry out the characterization of the power stage, two turbines have been used. The first has three straight blades and corresponds to a SC-Darrieus-type rotor, while the second has three corresponding helical blades with a Gorlov-type rotor. The experimental study has been performed by using a hydrodynamic tunnel and a high precision torque meter with an electric brake, which allows one to obtain the necessary mechanical parameters (torque, rotation speed) for the characterization of the power stage. Analyzing the data obtained from the results of the experimental study, it is determined that, for the same water speed, the Gorlov rotor obtains greater mechanical power than the Darrieus type. In all cases, power coefficient values greater than 1 have been obtained, thus verifying the influence of the blocking phenomenon on the performance of the turbines when they are in confined flow conditions. In turn, the TSR values obtained indicate that these turbines will work mainly by lift since they are higher than unity. Full article
Show Figures

Figure 1

21 pages, 3951 KiB
Article
Numerical Prediction on the Dynamic Response of a Helical Floating Vertical Axis Wind Turbine Based on an Aero-Hydro-Mooring-Control Coupled Model
by Yan Li, Liqin Liu, Ying Guo and Wanru Deng
Energies 2022, 15(10), 3726; https://doi.org/10.3390/en15103726 - 19 May 2022
Cited by 7 | Viewed by 2460
Abstract
Considering the aero-hydro-mooring-control coupled performance of a floating Vertical Axis Wind Turbine (VAWT), the numerical model of the floating helical VAWT system is established, and the fully coupled simulation program of the floating helical VAWT is developed. The aerodynamic load of the wind [...] Read more.
Considering the aero-hydro-mooring-control coupled performance of a floating Vertical Axis Wind Turbine (VAWT), the numerical model of the floating helical VAWT system is established, and the fully coupled simulation program of the floating helical VAWT is developed. The aerodynamic load of the wind turbine system is calculated using the unsteady BEM model, and the hydrodynamic load is calculated using the 3D potential theory. The floating foundation is considered as a rigid body, and the blades and tower are considered as flexible bodies. Based on the Kane method of a multi-body system, the dynamic responses of the VAWT could be solved in the time domain. A variable speed control model considering efficiency and load is established to match the rotating speed with the wind speed, and it could maintain the target output power under the influence of turbulent wind and large-scale movement of the floating foundation. The control strategy of limiting the target speed change rate and low-pass filtering is adopted to ensure the rapid regulation of the wind turbine under low wind speed conditions and stable regulation under high wind speed conditions. Full article
(This article belongs to the Special Issue Offshore Floating Wind Farms)
Show Figures

Figure 1

22 pages, 5326 KiB
Article
A Proper-Orthogonal-Decomposition (POD) Study of the Wake Characteristics behind a Wind Turbine Model
by Pavithra Premaratne, Wei Tian and Hui Hu
Energies 2022, 15(10), 3596; https://doi.org/10.3390/en15103596 - 13 May 2022
Cited by 17 | Viewed by 3686
Abstract
A comprehensive study was performed to analyze turbine wake characteristics by using a Proper-Orthogonal-Decomposition (POD) method to identify the dominant flow features from a comprehensive experimental database. The wake flow characteristics behind a typical three-bladed horizontal-axis wind turbine (HAWT) were measured in a [...] Read more.
A comprehensive study was performed to analyze turbine wake characteristics by using a Proper-Orthogonal-Decomposition (POD) method to identify the dominant flow features from a comprehensive experimental database. The wake flow characteristics behind a typical three-bladed horizontal-axis wind turbine (HAWT) were measured in a large-scale wind tunnel with a scaled turbine model placed in a typical offshore Atmospheric Boundary Layer (ABL) wind under a neutral stability condition. A high-resolution Particle Image Velocimetry (PIV) system was used to achieve detailed flow field measurements to characterize the turbulent flows and wake vortex structures behind the turbine model. Statistically averaged measurements revealed the presence of the characteristic helical-tip vortex filament along with a unique secondary vortex filament emanating from 60% of the blade span measured from the hub. Both filaments breakup in the near-wake region (~0.6 rotor diameter downstream) to form shear layers, contrary to previous computational and experimental observations in which vortex filaments break up in the far wake. A Proper-Orthogonal-Decomposition (POD) analysis, based on both velocity and vorticity-based formulations, was used to extract the coherent flow structures, predominantly comprised of tip and midspan vortex elements. The reconstructions showed coherence in the flow field prior to the vortex breakup which subsequently degraded in the turbulent shear layer. The accuracy of the POD reconstructions was validated qualitatively by comparing the prediction results between the velocity and vorticity-based formulations as well as the phase-averaged PIV measurement results. This early vortex breakup was attributed to the reduced pitch between consecutive helical turns, the proximity between midspan filaments and blade tips as well as the turbulence intensity of the incoming boundary layer wind. Full article
Show Figures

Figure 1

12 pages, 509 KiB
Article
Wake Expansion and the Finite Blade Functions for Horizontal-Axis Wind Turbines
by David Wood
Energies 2021, 14(22), 7653; https://doi.org/10.3390/en14227653 - 16 Nov 2021
Cited by 6 | Viewed by 2142
Abstract
This paper considers the effect of wake expansion on the finite blade functions in blade element/momentum theory for horizontal-axis wind turbines. For any velocity component, the function is the ratio of the streamtube average to that at the blade elements. In most cases, [...] Read more.
This paper considers the effect of wake expansion on the finite blade functions in blade element/momentum theory for horizontal-axis wind turbines. For any velocity component, the function is the ratio of the streamtube average to that at the blade elements. In most cases, the functions are set by the trailing vorticity only and Prandtl’s tip loss factor can be a reasonable approximation to the axial and circumferential functions at sufficiently high tip speed ratio. Nevertheless, important cases like coned or swept rotors or shrouded turbines involve more complex blade functions than provided by the tip loss factor or its recent modifications. Even in the presence of significant wake expansion, the functions derived from the exact solution for the flow due to constant pitch and radius helical vortices provide accurate estimates for the axial and circumferential blade functions. Modifying the vortex pitch in response to the expansion improves the accuracy of the latter. The modified functions are more accurate than the tip loss factor for the test cases at high tip speed ratio that are studied here. The radial velocity is important for expanding flow as it has the magnitude of the induced axial velocity near the edge of the rotor. It is shown that the resulting angle of the flow to the axial direction is small even with significant expansion, as long is the tip speed ratio is high. This means that blade element theory does not have account for the effective blade sweep due to the radial velocity. Further, the circumferential variation of the radial velocity is lower than of the other components. Full article
(This article belongs to the Special Issue Wind Turbine Advances)
Show Figures

Figure 1

24 pages, 16658 KiB
Article
Effect of Helix Angle on the Performance of Helical Vertical Axis Wind Turbine
by Unnikrishnan Divakaran, Ajith Ramesh, Akram Mohammad and Ratna Kishore Velamati
Energies 2021, 14(2), 393; https://doi.org/10.3390/en14020393 - 12 Jan 2021
Cited by 38 | Viewed by 9197
Abstract
The energy crisis has forced researchers to look for various non-conventional energy sources. Wind energy is one of the potential sources, and researchers have invested resources in developing different kinds of wind turbines. Vertical axis wind turbines (VAWT) have received less attention than [...] Read more.
The energy crisis has forced researchers to look for various non-conventional energy sources. Wind energy is one of the potential sources, and researchers have invested resources in developing different kinds of wind turbines. Vertical axis wind turbines (VAWT) have received less attention than their horizontal-axis counterparts. A helical-bladed VAWT is preferred because it makes perfect sense as an improvement in design, as they have higher azimuth angles of power generation capabilities. This paper studies the effects of the helix angle of blades in the aerodynamic performance of VAWT using 3D numerical simulations. Three different helix angles of 60°, 90°, and 120° of a three-bladed VAWT operating across different tip speed ratios were studied. Turbulence is modelled using a four-equation transition SST k-ω model (shear stress transport). The 60° helical-bladed VAWT was found to be better performing in comparison with all other helical-bladed and straight-bladed VAWT. The ripple effects on the shaft are also analysed using a standard deviation plot of the moment coefficient generated by a single blade over one complete cycle of its rotation. It was observed that the greater the helix angle, the lower the standard deviation. The paper also tries to analyse the percentage of power generated by each quartile of flow and the contribution of each section of the blade. Ansys FLUENT was employed for the entire study. A comparative study between different helical-bladed VAWT and straight-bladed VAWT was carried out along with wake structure analysis and flow contours for a better understanding of the flow field. Full article
(This article belongs to the Section A3: Wind, Wave and Tidal Energy)
Show Figures

Figure 1

16 pages, 8911 KiB
Article
Full-Scale Wind Turbine Vibration Signature Analysis
by Xavier Escaler and Toufik Mebarki
Machines 2018, 6(4), 63; https://doi.org/10.3390/machines6040063 - 7 Dec 2018
Cited by 29 | Viewed by 7956
Abstract
A sample of healthy wind turbines from the same wind farm with identical sizes and designs was investigated to determine the average vibrational signatures of the drive train components during normal operation. The units were variable-speed machines with three blades. The rotor was [...] Read more.
A sample of healthy wind turbines from the same wind farm with identical sizes and designs was investigated to determine the average vibrational signatures of the drive train components during normal operation. The units were variable-speed machines with three blades. The rotor was supported by two bearings, and the drive train connected to an intermediate three-stage planetary/helical gearbox. The nominal 2 MW output power was regulated using blade pitch adjustment. Vibrations were measured in exactly the same positions using the same type of sensors over a six-month period covering the entire range of operating conditions. The data set was preliminary validated to remove outliers based on the theoretical power curves. The most relevant frequency peaks in the rotor, gearbox, and generator vibrations were detected and identified based on averaged power spectra. The amplitudes of the peaks induced by a common source of excitation were compared in different measurement positions. A wind speed dependency of broadband vibration amplitudes was also observed. Finally, a fault detection case is presented showing the change of vibration signature induced by a damage in the gearbox. Full article
(This article belongs to the Special Issue Multi-Body System Dynamics: Monitoring, Simulation and Control)
Show Figures

Figure 1
