Icing on transmission lines in cold regions can cause asymmetry in the conductor cross-section. This asymmetry can lead to low-frequency, large-amplitude oscillations, posing a serious threat to the stability and safety of power transmission systems. In this study, the aerodynamic characteristics of crescent-shaped and sector-shaped iced eight-bundled conductors were systematically investigated over an angle of attack range from 0° to 180°. A combined approach involving wind tunnel tests and high-precision computational fluid dynamics (CFD) simulations was adopted. In the wind tunnel tests, static aerodynamic coefficients and dynamic time series data were obtained using a high-precision aerodynamic balance and a turbulence grid. In the CFD simulations, transient flow structures and vortex shedding mechanisms were analyzed based on the Reynolds-averaged Navier–Stokes (RANS) equations with the SST k-ω turbulence model. A comprehensive comparison between the two ice accretion geometries was conducted. The results revealed distinct aerodynamic instability mechanisms and frequency-domain characteristics. The analysis was supported by Fourier’s fourth-order harmonic decomposition and energy spectrum analysis. It was found that crescent-shaped ice, due to its streamlined leading edge, induced a dominant single vortex shedding. In this case, the first-order harmonic accounted for 67.7% of the total energy. In contrast, the prismatic shape of sector-shaped ice caused migration of the separation point and introduced broadband energy input. Stability thresholds were determined using the Den Hartog criterion. Sector-shaped iced conductors exhibited significant negative aerodynamic damping under ten distinct operating conditions. Compared to the crescent-shaped case, the instability risk range increased by 60%. The strong agreement between simulation and experimental results validated the reliability of the numerical approach. This study establishes a multiscale analytical framework for understanding galloping mechanisms of iced conductors. It also identifies early warning indicators in the frequency domain and provides essential guidance for the design of more effective anti-galloping control strategies in resilient power transmission systems. Full article

The rapid development of direct current (DC) grids poses significant challenges to the speed, reliability, and selectivity of fault protection systems. These systems are required to identify and distinguish between internal and external faults despite the constraints of limited information and time. This study introduces a non-unit protection scheme based on the classification of two-dimensional feature parameters utilizing the Hilbert–Huang transform (HHT) and a support vector machine (SVM). Through time–frequency analysis of the voltage waveform following DC faults, critical information within the high-frequency component of the fault voltage, specifically, the instantaneous frequency and amplitude of the wavefront, is extracted to distinguish internal from external faults. Two-dimensional feature parameters are associated with signal attenuation and distortion during fault propagation via the transmission path, thereby providing a foundation for precise fault identification. The employment of an SVM ensures the selectivity of this scheme without relying on protection settings. The efficacy of the scheme is validated through simulations conducted using PSCAD/EMTDC across various fault scenarios. Full article

Gravity inversion plays a crucial role in mineral exploration and resource evaluation, yet conventional depth-weighting methods often impose uniform resolution across all depths and fail to effectively delineate anomaly boundaries. This study presents an innovative attentional depth-weighting matrix based on a regularized downward continuation (RDC) mechanism. First, the observed gravity data are projected to greater depths using RDC, which suppresses high-frequency noise amplification. Next, gradient extrema are extracted from each grid cell to identify anomaly boundaries, forming a constant weighting matrix that enhances the focus on target regions. This matrix is then integrated with traditional depth weighting and a minimum-support focusing factor to optimize the inversion process. The proposed method is validated through two synthetic models, demonstrating improved resolution of deeper targets and more accurate amplitude recovery compared to conventional approaches. Further application to the Dahongshan Copper–Iron Ore region in Yunnan, China, reveals a deep intrusive body at approximately 4–5 km depth, extending east–west with a distinct “U”-shaped geometry. These results, consistent with previous geological studies, highlight the method’s ability to enhance deep anomaly characterization while effectively suppressing shallow noise interference. By balancing noise reduction with improved resolution, this approach broadens the applicability of gravity inversion in geological, geothermal, and mineral resource exploration. Full article

In distributed energy grid-connected systems, fast and accurate grid synchronization technology is crucial for system stability. This article proposes an improved phase-locked loop (FECSOGI-PLL) based on frequency error compensation. By introducing an unbiased adaptive frequency compensation mechanism, the SOGI resonant frequency is adjusted in real time to accurately track the input signal. A linear time invariant (LTI) model of the FECSOGI-PLL was established in the article, and its wider stability domain was clarified based on the Routh–Hurwitz criterion. The strong robustness of its fast response under non-ideal conditions, such as frequency jumps and amplitude drops, was verified through simulation and experiments. The core innovation of this study lies in the first implementation of unbiased adaptive regulation of the SOGI resonant frequency through the frequency error compensation mechanism, as well as the system design method based on the extended stability domain, providing theoretical support and engineering practice reference for high robustness power grid synchronization technology. Full article

A grid-forming converter (GFM) controls power output by adjusting the phase angle and amplitude of its output voltage, providing voltage and frequency support to the power system and effectively enhancing system stability. However, it has limitations in current control, influencing the current only indirectly through voltage regulation, which results in weaker control over current waveform quality. In the context of a large number of renewable energy generation units being connected to the grid, harmonics in the grid voltage can lead to excessively high harmonic content in the grid current, exceeding standard limits and causing oscillations. To solve this problem, this paper proposes a control strategy of harmonic voltage feedforward compensation to suppress grid current distortion. The proposed control strategy extracts harmonic voltages from the output port of the GFM converter through a harmonic extraction module, processes them via a feedforward factor, and introduces the resulting signals into the converter’s control loop as feedforward compensation terms. This allows the converter’s output voltage to compensate for the harmonic components in the grid, achieving the improvement of grid current and reducing the total harmonic distortion (THD) value. The effectiveness of the proposed control strategy is verified by simulation results. Full article

The flywheel energy storage system (FESS) of a mechanical bearing is utilized in electric vehicles, railways, power grid frequency modulation, due to its high instantaneous power and fast response. However, the lifetime of FESS is limited because of significant frictional losses in mechanical bearings and challenges associated with passing the critical speed. To suppress the unbalanced response of FESS at critical speed, a damping ring (DR) device is designed for a hybrid supported FESS with mechanical bearing and axial active magnetic bearing (AMB). Initially, the dynamic model of the FESS with DR is established using Lagrange’s equation. Moreover, the dynamic parameters of the DR are obtained by experimental measurements using the method of free vibration attenuation. Finally, the influence of the DR device on the critical speed and unbalanced response of FESS is analyzed. The results show that the designed DR device can effectively reduce the critical speed of FESS, and increase the first and second mode damping ratio. The critical speed is reduced from 13,860 rpm to 5280 rpm. Compared with FESS of the mechanical bearing, the unbalanced response amplitude of the FESS with DR is reduced by more than 87.8%, offering promising technical support for the design of active and passive control systems in FESS. Full article

The penetration of solar energy into centralized electric grids has increased significantly during the last decade. Although the electricity from photovoltaics (PVs) can deliver clean and cost-effective energy, the intermittent nature of the sunlight can lead to challenges with electric grid stability. Smart inverter-based resources (IBRs) can be used to mitigate the impact of such high penetration of renewable energy, as well as to support grid reliability by improving the voltage and frequency stability with embedded control functions such as Volt-VAR, Volt–Watt, and Frequency–Watt. In this work, the results of an extensive experimental study of possible interactions between the unstable grid and two residential-scale inverters from different brands under different active and reactive power controls are presented. Two impedance circuits were installed between Power Hardware-in-the-loop (P-HIL) equipment to represent the impedance in an electric distribution line. Grid voltage and frequency were varied between extreme values outside of the normal range to test the response of the two inverters operating under different controls. The key findings highlighted that different inverters that have met the same requirements of IEEE 1547-2018 responded to grid instabilities differently. Therefore, commissioning tests to ensure inverter performance are crucial. In addition to the grid control, the residential PV installed capacity and physical distances between PV homes and the substation, which impacted the distribution wiring impedance which we characterized by the ratio of the reactive to real impedance (X/R), should be considered when assigning the grid-supporting control setpoints to smart inverters. A higher X/R of 3.5 allowed for more effective control to alleviate both voltage and frequency stability. The elimination of deadband in an aggressive Volt-VAR control also enhanced the ability to control voltage during extreme fluctuation. The analysis of sudden spikes in the grid responses to a large frequency drop showed that a shallow slope of 1.5 kW/Hz in the droop control resulted in a >65% lower sudden reactive power overshoot amplitude than a steeper slope of 2.8 kW/Hz. Full article

Virtual synchronous generators (VSGs) have attracted widespread attention due to their advantage in supporting voltage and frequency of power systems. However, relevant studies have shown that a VSG has similar low-frequency oscillation as synchronous generators, which is more likely to occur under strong grid conditions. In this paper, the linearized mathematical model of a VSG is established by using small-signal analysis; based on this, the physical process of low-frequency oscillation of a VSG is explained from the perspective of vector motion. Firstly, the amplitude and phase motion of the current vector of a VSG under small disturbance are analyzed, then the mechanism of negative damping caused by terminal voltage control is revealed, and the reason why a VSG is more prone to instability under strong grid conditions is explained. Based on these, the influence of control and grid strength on the low-frequency oscillation of a VSG is analyzed. Studies show that the amplitude motion of the output current is the main cause of negative damping, and the oscillation can be suppressed by optimizing the value of key parameters. Full article

When traditional grid-forming converters directly participate in the grid-connected operation of the power grid, due to the lack of a pre-synchronization control system, the voltage amplitude and initial phase on both sides of the grid-connected point will deviate, resulting in voltage and current distortion during grid-connected mode. An active support phase-locked loop free pre-synchronization control strategy based on the third-order model of a synchronous generator is proposed to address the grid-connected problem of the grid-forming converter mentioned above. First, a model of active support control with frequency integral feedback at small signal levels was constructed. The root locus method was employed to examine how system parameters affect the stability of the active support control system. Second, by adding phase pre-synchronization controllers and amplitude pre-synchronization controllers to the active frequency loop and excitation voltage loop of the third-order model, it was ensured that the frequency, phase, and voltage amplitude of the unit are consistent with the power grid, achieving a fast and smooth grid-connected mode of the unit. Finally, by using a DC source to simulate all types of new energy power generation equipment, the active support pre-synchronization control system based on the three-order model of synchronous generator is built in the MATLAB/Simulink simulation environment, and the accuracy and effectiveness of the control strategy in this paper is verified. Full article

Low-frequency oscillation (LFO) poses significant challenges to the dynamic performance of hydropower unit regulation systems (HURS) in hydropower units sharing a tailwater system. Previous methods have struggled to effectively suppress LFO, due to limitations in governor parameter optimization strategies. To address this issue, this paper proposes a governor parameter optimization strategy based on the crayfish optimization algorithm (COA). Considering the actual water diversion layout (WDL) of a HURS, a comprehensive mathematical model of the WDL is constructed and, combined with models of the governor, turbine, and generator, an overall HURS model for the shared tailwater system is derived. By utilizing the efficient optimization performance of the COA, the optimal PID parameters for the HURS controller are quickly obtained, providing robust support for PID parameter tuning. Simulation results showed that the proposed strategy effectively suppressed LFOs and significantly enhanced the dynamic performance of the HURS under grid-connected conditions. Specifically, compared to before optimization, the optimized system reduced the oscillation amplitude by at least 30% and improved the stabilization time by at least 25%. Additionally, the impact of the power grid system parameters on oscillations was studied, providing guidance for the optimization and tuning of specific system parameters. Full article

The effects of harmonics, interharmonics, and subharmonics on low-voltage distribution networks, leading to a deterioration in electrical power quality, have become more evident in recent years. The main harmonic sources are power electronic devices due to their implicit nonlinearity. Interharmonic and subharmonic components are mainly caused by a lack of synchronization between the grid frequency and the switching frequency of the power converters. This can be caused by asynchronous modulated devices, or more commonly by fluctuations in the fundamental grid frequency. Interharmonic currents cause interharmonic voltage distortions that affect grid-synchronized or frequency-dependent systems. The IEC-61000-4-7 proposes a general guide on harmonics, interharmonic measurements, and instrumentation in current supply systems. However, the techniques proposed in the standard are intended for measurement and do not enable a precise identification of the interharmonic components in a signal. This work proposes new definitions for the spectral energy aggrupation to improve signal component detection for the IEC standard. Furthermore, an adaptive Kalman filter algorithm is developed that enables the exact identification in real time of the frequency, amplitude, and phase of these components. The proposed system will become the basis for the implementation of a new range of measurement systems that provide improved accuracy and real-time operation. The work is supported by simulated results analysing various scenarios (including transients after changes in harmonic content in the grid voltage) that demonstrate the effectiveness of the proposed method. Full article

With the rapid development of sensors and other devices, precise control for the generation of new energy, especially in the context of highly stochastic wind power generation, has been strongly supported. However, large-scale wind farm grid connection can cause the power system to enter a low inertia state, leading to frequency instability. Battery energy storage systems (BESSs) have the advantages of a fast response speed and high flexibility, and can be applied to wind farm systems to improve the frequency fluctuation problem in the process of grid connection. To address the frequency fluctuation problem caused by the parameter error of the fuzzy membership function in the fuzzy control of a doubly fed induction generator (DFIG) and a BESS, this paper proposes an improved Artificial Bee Colony (ABC) algorithm based on multi-source sensor data for optimizing the fuzzy controller to improve the frequency control ability of BESSs and DFIGs. A Gaussian wandering mechanism was introduced to improve the ABC algorithm and enhance the convergence speed of the algorithm, and the improved ABC algorithm was optimized for the selection of fuzzy control affiliation function parameters to improve the frequency response performance. The effectiveness of the proposed control strategy was verified on the MATLAB/Simulink simulation platform. After optimization using the proposed control strategy, the oscillation amplitude was reduced by 0.15 Hz, the precision was increased by 40%, and the steady-state frequency deviation was reduced by 26%. The results show that the method proposed in this paper provides a great improvement in the frequency stability of coordinated systems of wind farms and BESSs. Full article

The advent of distributed generation has brought with it a plethora of challenges for the nascent power systems that are being deployed on a large scale. Firstly, the majority of power electronic converters connected to the grid are in current source mode, which results in a lack of inertia and an inability to provide effective inertia or achieve damping support during fluctuations in grid frequency. Secondly, the issue of power quality, caused by the presence of harmonics, is becoming increasingly severe. This is particularly problematic in microgrids or systems with high line impedance, where harmonics can be amplified, thereby further compromising the stability of the power system. To address the deficiency in system inertia, numerous scholars are currently utilizing grid-forming (GFM) technology to achieve virtual inertia. In order to address the issue of system harmonics, it is possible to install active power filter (APF) devices at the point of common coupling (PCC), which serve to mitigate the effects of harmonics. This paper puts forth a proposal for the implementation of an APF with virtual inertia, based on PR + RC composite control. This composite control mechanism serves to enhance the harmonic suppression capabilities of the APF. The introduction of a frequency droop enables the capacitor voltage amplitude to be adjusted during fluctuations in system frequency, thereby achieving virtual inertia and providing active support for system frequency. The experimental results demonstrate that this strategy not only reduces the total harmonic distortion (THD) by 13% in comparison to PI control, indicating excellent harmonic suppression performance, but also allows the system to be inert, achieving positive results in suppressing frequency fluctuations during transients. Full article

With the continuous increase in the installed capacity of new energy systems, the impact of power shocks on grid frequency is becoming more significant, seriously affecting the stability of the grid and thermal power units. For this reason, a mixed variable parameter energy storage-assisted frequency support control method is proposed. This method introduces an integral control mode based on the existing control mode and forms a co-ordinated control mode. The impact of the switching point of the mixed control mode is analyzed, and a new mode switching method is used. The model adjusts the frequency regulation parameters according to the different states of the grid frequency, making the frequency regulation more efficient. Finally, a frequency regulation model that integrates various improvement methods is built, and a 10 min continuous load disturbance is applied to compare and verify the frequency regulation performance of the model as a whole. The results indicate that the proposed control method can significantly improve the quality of grid frequency regulation, reduce the frequency deviation amplitude to 0.00096 p.u., reduce the participation time of thermal power units to 190.8393 s, and reduce the peak output to 0.1934 MW, demonstrating its engineering feasibility. Full article

Numerical calculations were performed to study the vortex-induced vibration (VIV) of a circular cylinder, which was elastically supported by springs of linear and cubic terms. These simulations were conducted at high Reynolds numbers ranging from 4200 to 42,000. To simulate the cylinder’s motion and the associated aerodynamic forces, Computational Fluid Dynamics were employed in conjunction with dynamic mesh capabilities. The numerical method was initially verified by testing it with various grid resolutions and time steps, and subsequently, it was validated using experimental data. The response of cubic nonlinearities was investigated using insights gained from a conventional linear vortex-induced vibration (VIV) system. This 2D study revealed that both the amplitude and frequency of vibrations are contingent on the flow velocity. The highest output was achieved within the frequency lock-in region, where internal resonance occurs. In the case of a hardening spring, the beating response was observed from the lower end of the initial branch to the upper end of the initial branch. The response displacement amplitude obtained for the linear spring case was 27 mm, whereas in the cubic nonlinear case, the value was 31.8 mm. More importantly, the results indicate that the inclusion of nonlinear springs can substantially extend the range of wind velocities in which significant energy extraction through vortex-induced vibration (VIV) is achievable. Full article
