This paper presents some of the most significant findings in the design of a hydraulic servomechanism for flight controls, which were primarily achieved by the first author during his activity in an aviation institute. These results are grouped into four main topics. The first one outlines a classical theory, from the 1950s–1970s, of the analysis of nonlinear automatic systems and namely the issue of absolute stability. The uninformed public may be misled by the adjective “absolute”. This is not a “maximalist” solution of stability but rather highlights in the system of equations a nonlinear function that describes, for the case of hydraulic servomechanisms, the flow-control dependence in the distributor spool. This function is odd, and it is therefore located in quadrants 1 and 3. The decision regarding stability is made within the so-called Lurie problem and is materialized by a matrix inequality, called the Lefschetz condition, which must be satisfied by the parameters of the electrohydraulic servomechanism and also by the components of the control feedback vector. Another approach starts from a classical theorem of V. M. Popov, extended in a stochastic framework by T. Morozan and I. Ursu, which ends with the description of the local and global spool valve flow-control characteristics that ensure stability in the large with respect to bounded perturbations for the mechano-hydraulic servomechanism. We add that a conjecture regarding the more pronounced flexibility of mathematical models in relation to mathematical instruments (theories) was used. Furthermore, the second topic concerns, the importance of the impedance characteristic of the mechano-hydraulic servomechanism in preventing flutter of the flight controls is emphasized. Impedance, also called dynamic stiffness, is defined as the ratio, in a dynamic regime, between the output exerted force (at the actuator rod of the servomechanism) and the displacement induced by this force under the assumption of a blocked input. It is demonstrated in the paper that there are two forms of the impedance function: one that favors the appearance of flutter and another that allows for flutter damping. It is interesting to note that these theoretical considerations were established in the institute’s reports some time before their introduction in the Aviation Regulation AvP.970. However, it was precisely the absence of the impedance criterion in the regulation at the appropriate time that ultimately led, by chance or not, to a disaster: the crash of a prototype due to tailplane flutter. A third topic shows how an important problem in the theory of automatic systems of the 1970s–1980s, namely the robust synthesis of the servomechanism, is formulated, applied and solved in the case of an electrohydraulic servomechanism. In general, the solution of a robust servomechanism problem consists of two distinct components: a servo-compensator, in fact an internal model of the exogenous dynamics, and a stabilizing compensator. These components are adapted in the case of an electrohydraulic servomechanism. In addition to the classical case mentioned above, a synthesis problem of an anti-windup (anti-saturation) compensator is formulated and solved. The fourth topic, and the last one presented in detail, is the synthesis of a fuzzy supervised neurocontrol (FSNC) for the position tracking of an electrohydraulic servomechanism, with experimental validation, in the laboratory, of this control law. The neurocontrol module is designed using a single-layered perceptron architecture. Neurocontrol is in principle optimal, but it is not free from saturation. To this end, in order to counteract saturation, a Mamdani-type fuzzy logic was developed, which takes control when neurocontrol has saturated. It returns to neurocontrol when it returns to normal, respectively, when saturation is eliminated. What distinguishes this FSNC law is its simplicity and efficiency and especially the fact that against quite a few opponents in the field, it still works very well on quite complicated physical systems. Finally, a brief section reviews some recent works by the authors, in which current approaches to hydraulic servomechanisms are presented: the backstepping control synthesis technique, input delay treated with Lyapunov–Krasovskii functionals, and critical stability treated with Lyapunov–Malkin theory. Full article

Fuel electro-hydraulic servo valves are core components in the fuel control system of aero-engines, and their performance directly affects thrust regulation and power output precision. Due to the combustibility of the working medium in fuel systems and the lack of effective circulation filtration, the retention of micron-sized particles within the valve gap can lead to valve spool jamming, which is a critical reliability issue. This study, based on fractal theory and the liquid–solid two-phase flow model, proposes a parametric model for non-ideal surface valve gaps and analyzes the dynamics of particles subjected to drag, lift, and buoyant forces on rough surfaces. By numerically analyzing flow field models with different roughness levels and comparing them with an ideal smooth gap model, the migration characteristics of particles were studied. To verify the accuracy of the model, an upscaled experimental setup was built based on similarity theory, and PIV experiments were conducted for validation. Experimental results show that the particle release position and valve surface roughness significantly affect particle migration time. The weight of the release position on particle migration time is 63%, while the impact of valve surface roughness is 37%. In models with different roughness levels, the particle migration time increases more rapidly for roughness values greater than Ra0.4, while for values less than Ra0.4, the increase in migration time is slower. Furthermore, the study reveals that particle migration trajectories are independent of flow velocity, with velocity only affecting particle migration time. This research provides theoretical support for enhancing the reliability of fuel electro-hydraulic servo valves and offers a new perspective for the design of highly reliable hydraulic components. Full article

To advance the construction of intelligent mining, electro-hydraulic digital control technology has emerged as a critical direction for the digital transformation of mining machinery. This study proposes a digital control scheme based on the pressure state of the system and the operating state of the actuator. The scheme utilises a novel convergence rate sliding film position control method to regulate the system pressure in real time by controlling the pilot valve, which is driven by a permanent magnet synchronous motor (PMSM). Moreover, a prototype of an incremental digital pressure control valve was developed for high-pressure, high water-based working conditions. A simulation model of the valve was established using AMESim/Simulink, and dynamic characteristics under various operating conditions were analyzed. The relative error between simulated and experimental pressure results remained within ±4.7%. Finally, a multi-parameter optimization was conducted using a genetic algorithm. The results demonstrate that the optimized digital pressure control valve achieved a stabilized inlet pressure within 44.8 ms, with a pressure overshoot of 4.1% and a response time of 20.1 ms, exhibiting excellent real-time dynamic pressure regulation capabilities. This study provides a theoretical foundation and practical reference for comprehensive research on pressure control in underground emulsion pump stations. Full article

To improve the dynamic response, linearity, and control accuracy of the YYSCT-250-3 tractor multi-circuit hydraulic output power tester, this study develops a particle swarm optimization (PSO)-tuned fuzzy-proportional–integral–derivative (Fuzzy-PID) control strategy. By modulating the actuator-driven ball valve’s rotation angle (0–90°) in the proportional flow valve, the controller uses both the flow rate error and its rate of change between the setpoint and the flow meter feedback as fuzzy inputs to adjust the PID outputs. A detailed mathematical model of the electro-hydraulic proportional flow system is established, incorporating hydraulic resistance torque on the ball valve spool and friction coefficients to enhance accuracy. Through MATLAB/Simulink (R2022a) simulations, the PSO algorithm optimizes the fuzzy membership functions and PID gains, yielding faster response, reduced overshoot, and minimal steady-state error. The optimized controller achieved relative steady-state flow errors within ±1.0% and absolute flow control errors within ±0.5 L/min, significantly outperforming the traditional PID controller. These results demonstrate that the PSO-optimized Fuzzy-PID approach effectively addresses the flow control challenges of the YYSCT-250-3, enhancing both testing efficiency and precision. This work provides a robust theoretical framework and practical reference for rapid, high-precision flow control in multi-channel hydraulic power testing. Full article

In the development trend of intelligent and high-performance construction machinery, the dual-spool electro-hydraulic valve, as a new-generation core control element, directly affects the operation accuracy and energy-efficiency level of construction machinery. The standard linear extended state observer (LESO) produces relatively serious peaks as the system order increases, which leads to the degradation of the observer’s performance and affects the controller’s accuracy. To solve this problem, this paper innovatively proposes an output feedback control strategy for a cascaded structure observer for the dual-spool electro-hydraulic valve. This paper designs an output feedback controller based on the cascaded structure observer. The uniform exponential stability (USE) criterion ensures that the tracking error of the observer for the system state is bounded. The expected load pressure is constructed based on the expected trajectory to replace the actual load pressure, avoiding the influence of the nonlinear coupling between the load pressure and the input signal on the control system. Finally, a stable output feedback controller is obtained based on the backstepping control method and Hurwitz polynomial stability analysis. This study first applies the cascaded structure observer to the field of dual-spool electro-hydraulic valve control, providing a new theoretical framework and technical path for the high-precision control of the hydraulic system of construction machinery. Theoretical analysis shows that compared with the standard LESO, the cascaded structure observer can significantly reduce the online computational burden and effectively suppress the peak phenomenon, providing stronger estimation ability. Finally, a large number of simulation examples verify the effectiveness and superiority of the output feedback controller based on the cascaded structure observer. In all four test scenarios, the average tracking error of C1 (the output feedback controller designed based on the cascaded structure linear extended state observer) is about 5.1%, the average tracking error of C2 (the output feedback controller designed based on the standard structure linear extended state observer) is about 7.8%, and the average tracking error of C3 (the high-gain PID controller) is about 19.2%. The average control accuracy of the designed C1 controller is improved by 2.7% and 14.1% compared with C2 and C3, respectively. In terms of the estimation of external disturbances, the average error of C1 is 14% and the average error of C2 is 29.6%. The estimation accuracy of the former is improved by 15.6% compared with the latter. Full article

Aiming to solve the difficult problem of the miniaturization of servo valves, this paper designs a subminiature two-dimensional (2D) electro-hydraulic servo valve, which realizes the integration of the pilot stage and the power stage and significantly improves the work-to-weight ratio. Meanwhile, a high-power-density brushless DC motor (BLDC) is adopted as the electro-mechanical converter to further reduce the volume and mass. Firstly, the structure and working principle of the two-dimensional (2D) servo valve are described, and the mathematical model of the electro-mechanical converter is established. Aiming at the special working condition of the electro-mechanical converter with high-frequency oscillation at a small turning angle, this paper designs a position–current double closed-loop PID control algorithm based on the framework of the vector control algorithm (FOC). At the same time, the current feedforward compensation technique is included to cope with the high-frequency nonlinear disturbance problem of the electro-mechanical converter. The stability conditions of the electro-mechanical converter and the main valve were established based on the Routh–Hurwitz criterion, and the effects of the control algorithm of the electro-mechanical converter and the main parameters of the main valve on the stability of the system were analyzed. The dynamic and static characteristics of the 2D valve were simulated and analyzed by establishing a joint simulation model in Matlab/Simulink and AMESim. The prototype was fabricated, and the experimental bench was built; the size of the experimental prototype was 31.7 mm × 29.3 mm × 31 mm, and its mass was 73 g. Under a system pressure of 7 MPa, the flow rate of this valve was 5 L/min; the hysteresis loop of the spool-displacement input–output curve was 4.8%, and the linearity was 2.54%, which indicated that it had the ability of high-precision control and that it was suitable for the precision fluid system. The step response time was 7.5 ms, with no overshoot; the frequency response amplitude bandwidth was about 90 Hz (−3 dB); the phase bandwidth was about 95 Hz (−90°); and the dynamic characterization experiment showed that it had a fast response characteristic, which can satisfy the demand of high-frequency and high-dynamic working conditions. Full article

The independent metering control system is renowned for its ability to independently regulate the flow and pressure of various actuators, achieving high efficiency and energy savings in hydraulic systems. The high-speed digital valve is known for its fast response to control signals and precise fluid control. However, challenges such as jitter in the position control of hydraulic cylinders, unknown dead zone nonlinearity, and time variance in electro-hydraulic proportional systems necessitate further investigation. To address these issues, this study initially establishes an independent metering control system with digital valves. Based on the state space equation and Lyapunov stability judgment conditions, a high-order sliding mode controller is designed. In addition, a radial basis function (RBF) neural network is constructed to approximate uncertainties arising from the modeling process, the accuracy error indicator uses Mean Absolute Error (MAE), and a finite time generalized extended state observer (GESO) is introduced to conduct online disturbance observation for the external disturbances present within the control system. Consequently, a variable structure high-order sliding mode control strategy, augmented by RBF neural networks and finite time generalized extended state observer (RBF-GESO-SMC), is proposed. Finally, simulations and experimental verification are performed, followed by a comprehensive analysis of the experimental results. Compared with the sliding mode control (SMC), the RBF-GESO-SMC diminishes the displacement-tracking control accuracy error by 63.7%. Compared with traditional Proportional-Integral-Derivative (PID) control, it reduces the displacement-tracking control accuracy error by 78.1%. The results indicate that, through the comparison with SMC and PID control, RBF-GESO-SMC exerts significant influence on the improvement of position accuracy, anti-interference ability, transient response performance, and stability. Full article

This article addresses the current issue of energy consumption in the hydraulic drive systems of working machines, with particular emphasis on elevators. This paper describes the results of experimental comparative research and estimation of energy and time consumption for two drive systems of a hydraulic indirect elevator. The purpose of this article is to compare the energy consumption of a typical multi-valve system (MV) system with that of an innovative new electro-hydraulic drive (EHD) system with a variable speed pump. The EHD system uses a frequency converter with an energy recovery module to control the speed of the car in both directions and the return of potential energy during the lowering cycle. The comparison of these drive systems was performed under the same conditions, realizing the same elevator work cycles. This paper proposes methods for estimating the energy consumption of an MV system based on measurement data collected during an experiment. The results indicate that the EHD system was less energy-intensive, even at below 60%. The smaller the load mass, the shorter the operating time of the EHD system compared to the MV system. The introduced coefficients defining the energy consumption per unit of mass and payload displacement showed more than twice the decrease in energy demand during lifting and energy recovery possibility during lowering. The EHD system provides the same coefficient values regardless of the distance traveled, which makes it a predictable system, in contrast to the MV system, especially during lowering cycles. The benefits of the EHD also include a less complex hydraulic system (elimination of most valves). Full article

The electro-hydraulic servo valve is a critical component that transforms electrical signals into hydraulic signals, thereby controlling the hydraulic system. It finds extensive application in precision control systems. The stability of the electro-hydraulic servo valve is primarily influenced by the armature assembly. Unlike integral armature assembly, the separated armature assembly, comprising the armature, spring tube, flapper, and feedback spring, is joined through an interference fit, which introduces prestress within the assembly. The existence of prestress may affect the operational mode of the armature assembly. Consequently, this paper investigates the vibration characteristics of the separated armature assembly under interference fit conditions. Comparative analysis reveals that interference fit indeed generates prestress, which cannot be overlooked. To further validate the reliability of the simulation results, the natural frequency of the separated armature assembly is determined by applying a sweeping frequency signal to the torque motor using an electric drive, thereby verifying the feasibility of the simulation analysis. Additionally, the impact of interference on the vibration characteristics of the separated armature assembly is examined, confirming the accuracy of the simulation analysis method based on the interference fit. The research on vibration characteristics of a separated armature assembly provides technical support for the structural optimization design of the electro-hydraulic servo valve, thereby enhancing its performance. Full article

The article is devoted to designing novel multivariable robust μ-control of an open-circuit axial piston pump. In contrast with classical solutions of displacement volume control, in our case, the hydro-mechanical controller (by pressure, flow rate, or power) is replaced by an electro-hydraulic proportional valve which receives a control signal from an industrial microcontroller. The valve is used as the actuator of the pump swash plate. The pump swash plate swivel angle determines the displacement volume and the flow rate of the pump. The μ-controller design is performed on the basis of a one-input, two-output model with multiplicative output uncertainty. This model is estimated and validated from experimental data at various loads by multivariable identification. The designed control system achieves robust stability and robust performance for the wide working mode of an axial piston pump. To conduct this experimental study, the authors have developed a laboratory test bench, enabling a real-time function of the control system via USB/CAN communication. The designed controller is implemented in a rapid prototyping system, and real-time experiments are performed. They show the advantages of μ-control and confirm the possibility of its implementation in the case of the real-time control of an axial piston pump. Full article

Autonomous tractors are emerging as a pivotal technology in agricultural automation. Precise steering control in these tractors requires high-performance electrohydraulic proportional valves (EHPVs). To optimize EHPV performance and reduce development costs and time, simulation analysis serves as a valuable pre-testing tool. This study aimed to develop a simulation model capable of predicting the hydraulic characteristics of EHPVs under real-world operating conditions. The model was created using AMESim, incorporating actual tractor operating conditions and valve control signals. The proposed model was validated through experiments conducted on a tractor equipped with an EHPV, evaluating hydraulic characteristics across various engine speeds and steering angular velocities. The simulation model was utilized to analyze the priority valve control flow characteristics of the automatic steering system and the hydraulic response of the EHPV under step inputs at specific engine speed points. The results indicate that the simulation model demonstrated a mean absolute percentage error (MAPE) ranging from 7.45% to 9.79% for hydraulic power. A t-test analysis of hydraulic power indicated no statistically significant difference between the simulation and experimental values under all test conditions. The proposed EHPV simulation model can be utilized for the optimal future design of EHPV systems. Full article

The manufacturing precision of electro-hydraulic servo valve sleeves is critical to the performance and longevity of the valves. To ensure the service life of these valves, the valve sleeve is typically made from high-hardness martensitic stainless steel, which is considered a hard-to-cut material. Current honing methods often suffer from inefficiency and instability. This study compares the honing processes using electroplated and sintered oilstones, emphasizing processing efficiency and surface quality. Initially, the morphology of the oilstones was examined. Equivalent honing depth and material removal rate per unit width were developed to characterized material removal. The influence of various parameters on honing depth and material removal rates was explored, along with the surface morphology and roughness after honing. The results indicated that electroplated oilstones achieved a material removal rate 2.5 times higher than sintered oilstones. In contrast, sintered oilstones produced superior surface quality. To optimize both surface quality and efficiency, we proposed a sequential honing method: using electroplated oilstones for significant material removal followed by sintered oilstones for surface finishing, which enhanced efficiency by 1.6 times. Electroplated oilstone has broad application prospects in the field of precision and efficient machining of hydraulic components. Full article

Considering the complexity and difficulty of obtaining certain parameters in the electro-hydraulic proportional control system, a precise transfer function of the system was derived through parameter identification using experimental data obtained from an Amesim simulation model after establishing a basic mathematical model. This approach reduces the reliance on accurate parameters of individual components. A feedforward-feedback composite controller was designed, and its effectiveness was validated in Simulink using the system’s transfer function. Subsequently, the dead zone range of the proportional valve was determined through experiments, and a dead zone compensation strategy was designed, which reduced the time required for the proportional valve to traverse the dead zone by 89.4%. Based on the dead zone compensation, trajectory tracking experiments were conducted to validate the effectiveness of the feedforward-feedback composite controller. Under fixed disturbances, the trajectory tracking error was reduced by 53.8% compared to feedback control. Under time-varying load disturbances, the trajectory tracking error was reduced by 51.2% compared to feedback control. Full article

In this paper, fractional calculus is used to develop a generalized fractional dynamic model of an electrohydraulic system composed of a servo valve and a hydraulic cylinder, where a fractional position controller $P{I}^{\gamma }{D}^{\mu }$ is proposed for minimizing the performance index according to the integral of the time-weighted absolute error (ITAE). First, the general mathematical equations of the cylinder and servo valve are used to obtain the transfer functions in fractional order by applying Caputo’s definition and a Laplace transform. Then, through a block diagram of the closed-loop system without a controller, the fractional model is validated by comparing its performance concerning the integer-order electrohydraulic system model reported in the literature. Subsequently, a fractional PID controller is designed to control the cylinder position. This controller is included in the closed-loop system to determine the fractional exponents of the transfer functions of the servo valve, cylinder, and control, as well as to tune the controller gains, by using the ITAE objective function, with a comparison of the following: (1) the electrohydraulic system model in integer order and the controller in fractional order; (2) the electrohydraulic system model in fractional order and the controller in integer order; and (3) both the system model and the controller in fractional order. For each of the above alternatives, numerical simulations were carried out using MATLAB^®/Simulink^® R2023b and adding white noise as a perturbation. The results show that strategy (3), where electrohydraulic system and controller model are given in fractional order, develops the best performance because it generates the minimum value of ITAE. Full article

During the loading process, significant external position disturbances occur in the electro–hydraulic load simulation system. To address these position disturbances and effectively mitigate the impact of uncertainty on system performance, this paper first treats model parameter uncertainty and external disturbances as lumped disturbances. The various states of the servo valve and the pressures within the hydraulic cylinder chambers are then examined. Building on this foundation, the paper proposes a nonlinear multi-mode variable structure independent load port electro–hydraulic load simulation system that is tailored for specific loading conditions. Secondly, in light of the significant motion disturbances present, this paper proposes an integral sliding mode active disturbance rejection composite control strategy that is based on fixed-time convergence. Based on the structure of the active disturbance rejection control framework, the fixed-time integral sliding mode and active disturbance rejection control algorithms are integrated. An extended state observer is designed to accurately estimate the lumped disturbance, effectively compensating for it to achieve precise loading of the independent load port electro–hydraulic load simulation system. The stability of the designed controller is also demonstrated. The results of the simulation research indicate that when the command input is a step signal, the pressure control accuracy under the composite control strategy is 99.94%, 99.86%, and 99.76% for disturbance frequencies of 1 Hz, 3 Hz, and 5 Hz, respectively. Conversely, when the command input is a sinusoidal signal, the pressure control accuracy remains high, measuring 99.94%, 99.8%, and 99.6% under the same disturbance frequencies. Furthermore, the simulation demonstrates that the influence of sensor random noise on the system remains within acceptable limits, highlighting the effective filtering capabilities of the extended state observer. This research establishes a solid foundation for the collaborative control of load ports and the engineering application of the independent load port electro–hydraulic load simulation system. Full article
