Search Results (59)

Through static bending tests on two full-scale specimens of a new steel grating–UHPC (ultra-high-performance concrete) composite bridge deck, the load–displacement curves, crack propagation, strain distribution, and failure characteristics were analyzed. According to the experimental results, a numerical model was established using ABAQUS software 2021, in which two contact methods were employed to simulate the interfacial connection between UHPC and steel. The results indicate that the surface-to-surface contact method provides better agreement with the experimental data. Subsequently, conducted parameter studies using this model to investigate the impact of key geometric parameters, including section height, flange width, flange thickness, steel bottom plate thickness, and steel web plate thickness, on the flexural performance of the structure. The results demonstrated that the section height and the steel bottom plate thickness had a significant effect on the load-bearing capacity and overall stiffness of the component, while the influence of other parameters was comparatively minor. Finally, based on both experimental and numerical results, a formula for calculating the flexural bearing capacity of steel grating–UHPC composite bridge slabs was proposed, providing a reference for the structural design and promotion of the new composite bridge deck. Full article

Submarine structures are typically classified into pressure hulls and non-pressure hulls. The pressure hull is a critical component designed to withstand external pressure at operational depths while ensuring internal structural integrity. It is generally composed of ring frames and bulkheads. However, in modern large-scale submarines, bulkheads are often replaced with deep frames to improve equipment layout flexibility. Deep frames serve as essential structural reinforcements, compensating for the loss of stiffness due to the absence of bulkheads. Despite their importance, research on the design of deep frames remains scarce, and in the absence of established design standards, engineers rely on conservative approaches based on practical experience. Therefore, the objective of this study is to propose initial scantling formulas for deep frames in submarine pressure hulls based on finite element analysis (FEA) and parametric studies. To this end, six design cases reflecting actual ship design ranges were selected, and the structural integrity of the pressure hull ring frames was verified through material and geometric nonlinear analysis using ANSYS Mechanical APDL. Subsequently, a total of 82,440 parametric studies were conducted with the reinforced shell thickness, effective length, height and thickness of the deep frame web, and the width and thickness of the deep frame flange as variables. As a result, the proposed formulas satisfied all Validation cases in terms of structural integrity and were found to be applicable within the section length range of 1.5 to 2.0 times the pressure hull diameter. The results of this study are expected to be effectively utilized in the initial design of deep frames for submarine pressure hulls. Full article

This paper proposes the use of cross-laminated timber (CLT) panels in conjunction with back-to-back cold-formed steel (CFS) channel or angle sections in combination with laminated veneer lumber (LVL) beam, for composite CFS-timber beams. Under a hogging and sagging moment, part of the CLT panel will act compositely with CFS-LVL in order to resist compression, while the lower part of CFS-LVL web will be in tension. Whilst shear lag effects have been well-researched for concrete-steel composite beams, there has been little research on this for CLT panels working with CFS-LVL sections. In this paper, the finite element method (FEM) is used to determine the effective flange width (FFW) for CFS-timber beams. In conclusion, the obtained result has shown that the EFW increases with any changes that lead to an increase in the ratio of the transverse layer’s depth to the longitudinal layer’s depth. Moreover, combinations of CFS sections with LVL have significantly resulted in the depth-of-beam decrease. Full article

Steel beams with eccentric loads are subjected to combined bending and torsional moments that lead to lateral displacements, unwanted stresses at the top and bottom flanges, and global buckling along their length. To resist these displacements and stresses, horizontal stiffeners were used in the direction of the beam axis at locations of the beam’s web height. To conduct this study, Finite Element Modeling (FEM) was used to simulate these steel beams. The reliability of the FEM results was first verified by comparing them with the results of 25 steel beams that had been experimentally tested in previous studies, and the results showed high accuracy in modeling these steel beams. Secondly, a FEM analysis was performed on 70 steel beams, considering certain variables, namely the locations of the horizontal stiffeners relative to the beam’s web height, the width of the horizontal stiffeners, and the reduction in the spacing between the vertical stiffeners. The results showed that locating the horizontal stiffeners closer to the top or bottom flange enhances the beam’s resistance to eccentric loads. The placement of horizontal stiffeners near the flanges influences the stress distribution at their edges and the overall load capacity, with optimal locations at 10%, 20%, and 90% of the web height. Additionally, combining stiffeners at two web height locations increased capacity synergistically, though less than the sum of their individual effects. Using small-width horizontal stiffeners at low ratios of web height achieved similar efficiency to full-width stiffeners at higher ratios, allowing for material savings. Reducing the distance between vertical stiffeners by half also led to similar improvements to using steel beams with horizontal stiffeners of 20% or 90% of the web height. An interaction diagram was developed to predict the ultimate load capacity of steel beams under combined bending and torsion moments with varying horizontal stiffeners. Full article

This study reveals the Vierendeel mechanism of hybrid high-strength steel composite cellular beams (HHS-CCBs) through experimental investigation and finite element analysis (FEA). The forces acting on the openings of composite cellular beams (CCBs) are further analyzed. A calculation method is developed to evaluate the load-carrying capacity of HHS-CCBs under the combined action of bending moment and shear force, which takes into account the shear contributions of the concrete slab and beam flange at circular openings. The accuracy of the proposed formula and the influence of key parameters on load-carrying capacity are thoroughly examined through FEA. The results indicate that within the range of D = 0.6h_s − 0.7h_s and L = 0.7h_s − 1.0h_s (D and L represent the hole diameter and edge distance, respectively; h_s is the height of the steel beam), stress concentration at the beam-end welds could be avoided, the formation of Vierendeel mechanism at the beam-end opening could be ensured, and excessive reduction in load-carrying capacity could be prevented. Furthermore, the high-strength steel (HSS) flange strength and location had a minimal effect on the failure mode of HHS-CCBs. As the flange strength increased, full plasticity was not achieved in the cross-section, and the load-carrying capacity increased nonlinearly. Asymmetric specimens with HSS in the lower flange only and symmetric specimens with HSS in both the upper and lower flanges exhibited comparable load-carrying capacities. The load-carrying capacity calculation formula is applicable to HHS-CCBs with different section types, provided that circular holes are present in the beam web and Vierendeel mechanism damage occurs. However, the flange width–thickness ratio must not significantly exceed the specified limit. Full article

Construction steel is responsible for considerable amounts of carbon emissions in building sectors, and promoting the low-carbon design of steel components is conducive to the sustainable development of the industry. As one of the most typical components, I/H-beams are widely used in steel structures. In this paper, a new comprehensive index named carbon-capacity ratio (CCR) was proposed considering both mechanical properties and carbon emissions of I/H-beams, based on which the geometry coefficient and material coefficient were derived. Quantitative investigation was then conducted on the geometry coefficient to figure out the effects of different geometry variables, and the geometry criteria for low-carbon design of steel beams were concluded considering different load conditions. Results show that for double-symmetric cross-sections bearing flexural loads, larger flange width and beam height are suggested, while for single-symmetric cross-sections bearing flexural loads, increasing beam height as well as flange width and thickness can all contribute to sustainable beam designs, but adopting large beam height is the most effective. For cross-sections bearing shear loads, increasing beam height and web thickness would be beneficial. The feasible design domain (FDD) for geometry variables was proposed to be predicted with either linear or hyperbolic criteria depending on different loads and cross-sections. Additionally, a qualitative discussion was also given on the material coefficient, and steel with higher strength or that produced from recycled scrap using energy-saving technologies, as well as new prototyping techniques with lower energy and material loss, are recommended for beam fabrication. This study is expected to serve as a preliminary supplement to the blank in current codes or standards for low-carbon design of construction steel. Full article

This paper presents the results of preliminary numerical and experimental studies concerning the sealing performance of static seals (gaskets) with geometrically designed sealing surface microstructures. The concept of the microstructure, inspired by the operating principle of Tesla’s one-way valve, relies on the generation of localized flow circulation within the microchannels formed between the contact surfaces, which increases flow resistance and reduces leakage. CFD simulations were performed to assess the influence of the geometric parameters of the microstructure on the leakage rate. The numerical calculations demonstrated that introducing microstructures into the gap formed between the contact interfaces can significantly reduce leakage, with the most critical geometric parameters being the gap width between the microprotrusions, their packing density, and their height. Experimental studies confirmed the higher sealing performance of structured gaskets compared to quasi-smooth gaskets, particularly at lower contact pressures. An analysis of the effective contact surface revealed that the improvement in tightness is a result of both the local intensification of the contact pressure and the flow effects induced by the microprotrusions. The results obtained confirm that an appropriately designed surface microstructure can substantially enhance the sealing performance of flange-bolted joints, even under relatively low clamping loads. Full article

The study presents an analysis of steel-Ultra-High Performance Concrete (UHPC) composite girders. Five composite girder specimens were designed and tested. Analytical strain solutions for the composite girders under asymmetric axial loading were derived using the energy variation method. Results indicate that asymmetric axial forces significantly exacerbate the shear lag effect. Decreasing the width-to-span ratio reduces the shear lag coefficient, while reducing the width-to-depth ratio increases it. The parametric analysis indicates that, under asymmetric axial loading, increasing the strength of the concrete is an effective method to reduce the shear lag effect of the composite girders. Increasing the thickness of the UHPC slab proves to be effective in reducing the shear lag effect. Furthermore, the study indicates that when the b₂/b₁ ratio is less than 1, it has a tiny impact on the shear lag effect; however, when the b₂/b₁ ratio is greater than 1, the shear lag effect becomes more pronounced with increasing b₂/b₁. Additionally, the thickness of the flange plate and web plate of the steel girder has no significant effect on the shear lag effect. The results of the analysis can provide references for similar designs and constructions of composite structures. Full article

In this study, a new type of novel demountable connector is proposed to enable complete dry connections between concrete beams and slabs, facilitating the full demountable design of these components. To analyze and evaluate the flexural performance of the concrete beams with the novel demountable connectors, a finite element model was developed, which was then validated by previous tests. The results indicate that bolt diameter, bolt strength, channel spacing, and concrete slab thickness have a significant impact on peak load, while concrete beam strength, concrete slab strength, and flange width have minimal influence. Similarly, flexural stiffness is strongly affected by bolt diameter, channel spacing, concrete slab strength, slab thickness, and flange width, whereas bolt strength and concrete beam strength play a lesser role. Notably, the finite element analysis confirms the absence of plastic deformation in most bolts and end plates, ensuring that the flexural components are designed for effective disassembly. A theoretical model for calculating the ultimate flexural moment of demountable concrete beams under different conditions is also proposed, and it agrees with the ultimate flexural moment from numerical analysis. Full article

H-section steel members, as a commonly used load-bearing receiving member in building structures, may be subjected to the impact of accidental loads during their service life, and therefore, the impact loads need to be considered when carrying out the design. In this paper, based on experimental testing, the particle swarm optimization algorithm (PSO) is used to optimize the hyperparameters of the multilayer perceptron (MLP), and a combined prediction model PSO-MLP for H-section steel members subjected to lateral impact loads is proposed to predict the damage of the H-section steel members after impact. The results show that the prediction model based on PSO-MLP can predict the damage of the H-beam columns more accurately, and compared to the random forest model (RF) and the support vector machine (SVM), the PSO-MLP model has better prediction accuracy and robustness. In addition, the effects of different features on the impact performance of the members were analyzed, in which the weakest impact location is 0.57 L away from the fixed end and the effects of axial compression ratio, flange, and web thickness were similar to the results of previous studies; the impact angle showed a strong nonlinear relationship with the critical impact velocity, which the weakest impact angle is around 50° from the strong axle; and the height and width of the cross-section showed a linear enhancement of the impact performance. Full article

The paper presents the effect of the symmetric and asymmetric semi-metallic gasket core shape on the tightness level in bolted flange joints. Experimental tests, as well as numerical calculations based on the finite element method, revealed that the asymmetric gasket core provides a higher strain on the sealing graphite layer and leads to a more uniform distribution of strain on the particular ridges of the core. Furthermore, the leakage rate of the asymmetric gasket was reduced by approximately 60% compared to the symmetric gasket. It was also observed that the uniformity of pressure and strain distribution in a gasket with an asymmetric core occurs over about 80% of the gasket width. The leakage reduction effect in a flange joint sealed with a gasket with an asymmetric core was theoretically explained. As shown, the main leakage flows through the porous structure of the graphite layer, while the leakage path at the interface between the metal rough profile and the graphite layer is several orders of magnitude smaller. Full article

Steel-reinforced concrete (SRC) deep beams have been widely used in engineering applications such as high-rise buildings and long-span bridges, with their structural behavior and mechanical properties attracting significant research attention. To investigate the shear cracking behavior of SRC deep beams, seven specimens with a scale of 0.4 times were designed for static loading tests, and the influence of the shear-span-to-depth ratio λ, the width ratio of the steel flange, and the height ratio of the steel web on the width and spacing of the diagonal crack was considered. The cracking behavior of the diagonal cracks in the shear span area were recorded by the digital image correlation (DIC) technique. The results show the following: (1) the use of the DIC technology revealed the entire process of crack occurrence, development, and evolution and obtained the distribution characteristics of crack development; (2) the steel flange width has a slight effect on the spacing and width of the diagonal cracks. The diagonal crack width increased with the improvement of the height of the steel web, but the influence of the steel web on the spacing of diagonal cracks was not significant. When the height ratio increased from 0.3 to 0.45 and 0.6, the maximum oblique crack width increased by 13% and 14.5%. Based on the above experimental results and relevant analysis conclusions, an improved method was proposed to calculate the diagonal crack width of composite deep beams by further considering the influence of the crack angle. Finally, the experimental results verified its high accuracy in a qualitative analysis. The calculation method proposed in this article can be used to predict and estimate the width of diagonal cracks in SRC deep beams. Full article

The dynamic behavior of three-layer composite beams, consisting of concrete slabs and steel beams, is influenced by the structural configuration of each layer as well as the shear connectors. The interlayer shear stiffness in three-layer composite beams governs their global dynamic behavior, while interlayer slippage-induced localized vibration effects represent a key limiting factor in practical applications. Based on the dynamic test results of steel–concrete double-layer composite beams, the feasibility of a finite element solid model for composite beams, which accounts for interlayer shear connectors and beam body characteristics, has been validated. Utilizing identical modeling parameters, an analytical model for the inherent vibration characteristics of three-layer steel–concrete composite beams has been developed. This study encompasses two types of composite beams: concrete–steel–concrete (CSC) and concrete–concrete–steel (CCS). Numerical simulations and theoretical analysis systematically investigated the effects of interface shear connector arrangements and structural geometric parameters on dynamic performance. Research indicates that the natural frequency of steel–concrete three-layer composite beams exhibits a distinct two-stage increasing trend with the enhancement in interlayer shear stiffness. For CSC-type simply supported composite beams, the fundamental vertical vibration frequency increases by 37.82% when achieving full shear connection at both interfaces compared to the unconnected state, while two-equal-span continuous beams show a 38.06% improvement. However, significant differences remain between the fully shear-connected state and theoretical rigid-bonding condition, with frequency discrepancies of 24.69% for simply supported beams and 24.07% for continuous beams. Notably, CCS-type simply supported beams display a 12.07% frequency increase with full concrete-to-concrete connection, exceeding even the theoretical rigid-bonding frequency value. Longitudinal connector arrangement non-uniformity significantly impacts dynamic characteristics, while the transverse arrangement has minimal influence. Among structural parameters, steel flange plate thickness has the most significant effect, followed by concrete slab width and thickness, with steel web thickness having the least impact. Based on the observation that the first-order vertical vibration frequency of three-layer composite beams exhibits a two-stage decreasing trend with an increase in the span-to-depth ratio, it is recommended that the span-to-depth ratio of three-layer steel–concrete composite beams should not be less than 10. Full article

This study investigates a novel steel grid shear wall (SGSW) structure with lightweight and discrete lateral-resistance members, focusing on its structural behavior in lateral resistance. By comparing the characteristics of the thin steel plate shear wall, the mechanism of the steel grid components in both the tension zone and compression zone was briefly described. The formulas of lateral-resistant capacity and initial stiffness of the SGSW were derived through the static equilibrium method. Then, the influence laws of the span–height ratio, steel member spacing and section size of the steel members on the lateral-resistant performance of the SGSW were determined through a parametric analysis. In addition, the accuracy of the calculation formula was validated. The results showed that the strains of the steel grid components in different positions were all the same when the bending stiffnesses of the edge members were significantly large. The lateral-resistance capacity of the SGSW increased with the span-to-height ratio, while it decreased as the spacing between the steel components increased. Compared with the effects of web height, web thickness and flange width, increasing the flange thickness exhibited the best effects on improving the lateral capacity. As the flange thickness increased from 7 mm to 13 mm, the lateral-resistant capacity showed an improvement of 35.45%. Additionally, the formula derived in this study demonstrated high accuracy and reliability, with the error not exceeding 8% between the formula calculation and the simulation results. Full article

A precast concrete segmental box-girder bridge (PCSBGB) is one of the most popular styles of Accelerated Bridge Construction (ABC). To address some common challenges (low durability, poor integrity, and construction inconvenience) in PCSBGBs, this paper proposes a precast ultra-high-performance concrete (UHPC) segmental box-girder bridge (PUSBGB). In comparison to conventional PCSBGBs that use three-dimensional prestress, the PUSBGB adopts only one-dimensional (longitudinal) prestress. In addition, the thickness of the bottom/top plate and web of the UHPC box-girder are relatively thin, and as a result, the self-weight is significantly reduced. Considering the fact that the thickness of box-girder is thinner than the NC structure, the shear lag effect and risk of girder cracking may correspondingly increase when a PUSBGB is adopted in a long-span bridge. Thus, it is of essential necessity to explore the flexural behavior of a PUSBGB. In this work, a specimen with a scale (1:4) associated with a field bridge (a 102 m long simply supported PUSBGB with externally unbonded tendons) is fabricated and experimentally investigated. The mechanical behaviors of the PUSBGB are discussed, including the failure mode, the crack distribution pattern, the longitudinal strain of the UHPC plate, and the variation of tendon strain. It is found that in the elastic stage, the top slab of the UHPC box girder exhibits a significant shear lag effect, and this phenomenon is even more obvious after cracking. With the development of the cracks, the effective flange width is decreased (with a minimum value of 0.76), and the second-order effect is kept the same before the dominant crack appears (the reduction factor is around 0.95). Moreover, four existing code equations, e.g., ACI 440, ACI 318, ASSHTO, BS 8100, used to predict the stress in the externally unbonded tendons are examined. Furthermore, a finite element analysis (FEA) of the field bridge is conducted, and the theoretical calculation demonstrates that the flexural resistances of the proposed PUSBGB can comply with the design requirements of Chinese code under the ultimate limit states (ULSs). Full article
