Near-bit multi-parameter MWD (measurement while drilling) is a key technology for achieving precise and efficient directional drilling in underground and tunnel engineering. The near-bit multi-parameter MWD method was studied, and a “center + side wall” distributed measurement scheme was proposed, based on an analysis of special application scenarios in underground and tunnel engineering. The transmission characteristics of Bluetooth wireless signals in water were investigated. An analysis of the underwater Bluetooth signal link was conducted. When the transmission distance is 100 mm, the received signal strength is −17.5 dBm, and the link margin is 69.5 dB. Wireless Bluetooth was used to transmit the near-bit data. A Bluetooth wireless communication simulation model was established using ANSYS software, and the influence of transmission power, transmission medium, and transmission distance on the Bluetooth signal strength was analyzed. The results indicate that: (1) the received signal strength increases with transmission power, and appropriately increasing the transmission power can improve the effect of Bluetooth wireless communication and extend the communication distance. (2) When the transmission medium is water, the received signal is unstable, and the echo loss curve shows a high and low oscillation form, presenting a frequency shift feature; when the transmission medium is air, the received signal is relatively stable, and the echo loss curve shows a parabolic form. The echo loss of Bluetooth wireless signal in water transmission is significantly higher than that in air transmission, indicating that the Bluetooth signal attenuates more rapidly when transmitted in water. (3) When the transmission distance increases near the optimal transmission frequency of 2.4 GHz, the echo loss increases accordingly, and the received signal strength of the wireless receiving module gradually decreases. The theoretical analysis, simulation, and indoor test results are in good agreement. The reasonable Bluetooth transmission power is 1 mW, and the transmission distance is 100 mm. After completing the overall scheme design and simulation analysis optimization, the structure, circuit, and program development were carried out, and the near-bit multi-parameter MWD device was developed. A laboratory water supply test was conducted, and the power supply, collection, and wireless transmission were all normal. A drilling test was carried out at an underground engineering of a coal mine in Wuhai City, achieving a drilling depth of 2328 m. A continuous and stable collection of various parameters such as WOB (weight on bit), torque, rotation speed, vibration, and gamma was carried out. A wireless transmission channel for near-bit data was established across the screw drilling tool. It can provide key technical support for the research and development of near-bit MWD in underground and tunnel engineering. Full article

The submarine cable installed in the directional drilling pipeline may face constrained ampacity due to the narrow air gap and complex thermal environment. The current studies have overlooked the axial heat transfer caused by variable burial depth and the influence of deep ground temperature, resulting in inaccurate assessment of the hot spot temperature and hot spot location of submarine cable in the directional drilling pipeline. To address this issue, the distributed parameter electrical circuit model for long-distance submarine cable and the three-dimensional thermal simulation model for the submarine cable landing section were developed to analyze the heat generation and dissipation characteristics of submarine cable in the directional drilling pipeline. Then, the hot spot location of submarine cable in the directional drilling pipeline was identified. Subsequently, an improved thermal rating method based on the quasi-three-dimensional thermal model was proposed to rapidly assess the hot spot temperature for the submarine cable in the directional drilling pipeline. The accuracy of the improved thermal rating method was verified by comparison with the simulation method. Finally, implementation of water circulation was conducted to resolve the overheating issue in the directional drilling pipeline. The investigations in this paper can provide support for the efficient utilization of submarine cable. The improved evaluation method for submarine cable in a directional drilling section proposed in this paper can be regarded as the supplement to the traditional IEC method. Full article

Contactless transmission of mechanical power, which is characteristic of coaxial magnetic gears (CMGs), offers significant advantages over conventional mechanical gears, in particular, reduced maintenance frequency and inherent overload protection. At the same time, there is a lack of design methodologies for this type of gear based on the analysis and systematization of experience gained from already implemented designs. This paper presents a method for determining the maximum magnetic torques of CMGs on the basis of an equivalent magnetic-circuit model. The error associated with the proposed methodology does not exceed ±15%, which enables the influence of geometric parameters and the magnetic properties of materials on the key performance indicators of the gear to be assessed already at the preliminary design stage. A mathematical model of CMG dynamics was also developed, based on a quasi-stationary two-dimensional approximation of the magnetic field, accounting for the geometry of the magnetic circuit, the spatial distribution of the magnetic vector potential, and magnetic-circuit saturation. The proposed mathematical model was verified using the results of physical experiments. The discrepancy between the calculated and experimental values of the torque on the low-speed shaft in the steady state does not exceed 5.5%. Based on the optimization procedure, the dependence of the maximum linear torque density on the outer diameter of the CMG, the number of poles of the high-speed rotor, and the transmission ratio was determined. It was shown that, as the number of poles increases, the linear torque density also increases and, for example, for diameters of approximately 800 mm, it may exceed 100 N·m/m. Full article

A large number of grid-connected inverters have been connected to distribution networks and can be used to mitigate harmonics at the system level. Deploying distributed power electronic devices for harmonic mitigation is a cost-effective solution for distribution networks. However, existing coordination methods typically depend on highly reliable, low-latency communications. Communication delays or interruptions can significantly degrade coordination performance and even exacerbate harmonic distortion. This paper presents a hierarchical, coordinated harmonic compensation method for multiple multifunctional grid-tied inverters (MFGTIs). At the primary control level, harmonic domain virtual admittance is incorporated, enabling each device to adaptively inject harmonic compensation currents using only local measurements, maintaining baseline compensation capability when communication is limited or interrupted. At the secondary control level, a distributed model predictive control (DMPC) scheme is derived from the harmonic steady-state equivalent circuit. The virtual admittance parameters are updated iteratively using measurements exchanged only among neighboring nodes, enabling coordinated sharing of compensation currents without requiring global information or frequent harmonic power flow calculations. Case studies demonstrate that the proposed method reduces nodal harmonic voltages under communication constrained conditions while significantly lowering the computational burden. Full article

A Controllable Line-Commutated Converter (CLCC) is a novel piece of equipment for enhancing the commutation failure resistance of High-Voltage Direct Current (HVDC) transmission systems. Traditional lumped parameter models ignore the high-frequency coupling effects of internal distributed stray capacitances, resulting in insufficient transient simulation accuracy and restricting refined engineering design. Taking the CLCC in the HVDC transformation project as the research object, this paper analyzes the distribution characteristics of stray parameters in a press-pack Insulated Gate Bipolar Transistor (IGBT) under stacked structures. By integrating distributed stray parameter networks with the nonlinear characteristics of the devices, an improved IGBT equivalent circuit model is established, with key parameters identified based on field-measured data. Furthermore, an LCC-CLCC simulation model is built and used to replace the improved IGBT model to conduct short-circuit fault simulation verification. The results demonstrate that the high-fidelity model accurately reproduces transient waveforms under Alternating Current (AC) voltage disturbance and faithfully reflects the actual operating characteristics of a surge arrester and IGBT, thereby effectively compensating for the idealized errors inherent in traditional models. This modeling methodology provides a robust theoretical and simulation foundation for parameter optimization, valve control system design, and the secure operation of a CLCC. Full article

Finite element modeling (FEM) of hybrid bonding stacks for high-density 3D integration suffers from excessive computational load and prohibitive simulation time. To address this critical technical bottleneck, this paper proposes an analytical lumped-distributed equivalent circuit model based on multi-layer structures. The model incorporates both redistribution layer (RDL) parasitics and metal–insulator–semiconductor (MIS) depletion effects for comprehensive signal integrity analysis. Frequency-dependent RLGC electromagnetic parameters were extracted from through-silicon via (TSV) and RDL interconnects. These parameters were numerically calculated using MATLAB R2020a to construct the equivalent circuit model in ADS. The model was subsequently validated against COMSOL finite element simulations. The results demonstrated that the proposed methodology achieved maximum deviations below 5% for all S-parameters in double-layer structures. For 5-layer stacks, errors were controlled within 10% across the 0–40 GHz frequency range. Computation time was reduced from several minutes to seconds. The proposed equivalent circuit method significantly reduces computational time while maintaining accuracy, providing an efficient simulation methodology for signal integrity analysis and verification of hybrid bonding stack structures. Compared to existing single-layer models, this work extends the modeling approach to multi-layer hybrid bonding stacks while comprehensively accounting for both RDL parasitics and MIS depletion effects, addressing a critical gap in the current state of the art. Full article

Models are described for calculating the crack initiation times for Alloy 600 and Type 304 SS in PWR and BWR primary coolant circuits, respectively. In PWRs, initiation is defined in terms of the grain boundary oxidation concept of Scott and Le Calvar, whereas in BWRs, cracks are envisioned to nucleate from corrosion pits. In contrast, in BWRs, we envision cracks to nucleate from corrosion pits, with the difference in the two systems being primarily due to electrochemical factors. Thus, in BWR primary coolant and the absence of hydrogen water chemistry (HWC), the oxidizing conditions due to the radiolytic production of H₂O₂ cause the ECP to be significantly more positive than the critical pitting potential. Accordingly, the nucleation and growth of pits due to passivity breakdown and the establishment of differential aeration between the pit nucleus’s internal and external environments, which results in growth of pits to the critical size necessary to satisfy the Kondo criteria for transition of a pit into a crack, is judged to be a realistic scenario. Contrariwise, in PWR primary coolant, the ECP is so negative [≈−1.0 V_she] due to the large amount of pressurizing H₂ present in the circuit [20–60 cm³(STP)/kg H₂O] that the nucleation and growth of pits is not possible. However, Totsuka and Smialowska found that MA Alloy 600 suffers hydrogen-induced cracking (HIC) at an ECP < −0.85 V_she, demonstrating that, in service with a high hydrogen concentration, brittle fractures will occur. The initiation sites were not identified. The crack initiation models for Alloy 600 in PWRs and Type 304 SS in BWRs reproduce the effects of the following independent variables: applied stress, temperature, cold work, grain boundary segregations, water chemistry, pH, and electrochemical potential. The origins of the observed scatter in experimentally measured crack initiation times are discussed, and the challenges of developing a more general crack initiation model (GCIM) are identified. From a mathematical viewpoint, the most significant challenge arises from the nested distributions involving the many parameters and expressions within the GCIM that are either distributed because of an imprecise definition or because some experimentally determined input parameters are experimentally scattered. Additionally, the evolution of semi-elliptical surface cracks resulting from the electrochemical crack length (ECL) being shorter than the classical mechanical crack length (MCL) must be incorporated if the GCIM is to find utility in the water-cooled nuclear power industry where semi-elliptical surface cracks are normally observed. Full article

Transformers serve as crucial hubs for power transmission, but during no-load energization, the nonlinear magnetization of their cores frequently induces extreme magnetizing inrush currents. Current suppression methods encounter challenges regarding transient feature extraction and excessive circuit complexity. To overcome these limitations, this study develops a high-fidelity model of a 100 kVA transformer using MATLAB/Simulink to investigate the interaction between residual flux and the closing angle. Extensive simulations were executed across a closing phase angle range of 0° to 360° and a residual flux domain of −0.8 p.u. to 0.8 p.u. Furthermore, this study utilizes Wavelet and Clarke transforms to extract characteristic parameters and quantitatively analyze the transients within the energy domain, enabling a multi-scale assessment of the mitigation efficacy based on these extracted features. The analytical results demonstrate that an optimal pre-magnetization distribution of −0.8 p.u. for Phase A, 0 p.u. for Phase B, and 0.8 p.u. for Phase C, coupled with a target closing angle of 330°, achieves the best suppression. This strategy strictly clamps the peak inrush current to 1.5 times the rated current, significantly outperforming conventional demagnetization alone. Consequently, this highly pronounced mitigation effect provides robust support for reliable transformer protection and overall power grid security. Full article

Responding to rapid urbanization, this study examines the trade-offs and synergies of ecosystem services (ESs) at the county scale in the Zhengzhou metropolitan area and constructs an ecological security pattern. Using the InVEST model, we quantified carbon storage (CS), soil conservation (SC), habitat quality (HQ), water yield (WY), and food production (FP). We then analyzed their trade-offs and synergies using the geographically weighted regression model, identified driving factors with an optimal parameter-based geographical detector model, detected ecosystem service bundles via a Self-organizing map model, and constructed an ecological security pattern based on circuit theory. The results showed that: (1) From 2003 to 2023, ES spatial distribution remained stable overall, with weak trade-offs and synergies. Locally, WY and HQ declined, while SC and FP increased. (2) Slope and DEM enhanced SC, whereas urban expansion consistently weakened CS, HQ, and FP. Moreover, slope played an increasingly prominent role in regulating WY. (3) Key synergistic bundles with stable spatiotemporal distribution were identified as ecological sources, leading to the construction of ecological security pattern characterized by “four districts, one corridor, and one belt.” This provides a framework for integrating ecological space protection and restoration into urban development. Full article

Currently, the lack of analysis and applicable circuit models for the evolution of cable joint faults is responsible for explosions or fire accidents in the distribution network system. In this paper, the modeling of high-resistance to low-resistance grounding faults for 10 kV cable joints is investigated. Firstly, the physical evolution from high-resistance to low-resistance grounding faults in 10 kV cable joints is analyzed. Secondly, the common discharge characteristics under different evolution stages are extracted by simulation experiments and fault-recording data. Thirdly, an interface breakdown circuit model and a radial breakdown circuit model are established to quantitatively describe the high-resistance to low-resistance grounding faults of cable joints. Fourthly, the corresponding arc resistance models are proposed, and the controlled parameter values of the models under different evolution stages are given. Finally, the fault identification control model is implemented for relay protection. This paper provides theoretical and modeling support for the fault identification of 10 kV cable joints, filling the knowledge gap of this critical fault type in relay protection. Full article

Memristor-based neuromorphic computing offers a promising pathway for efficient in-memory processing. However, the scalability and reliability of such systems are severely compromised by parasitic resistances (including line and input resistances) in crossbar arrays, which cause significant IR-drop during vector–matrix multiplication (VMM). Existing research often suffers from high computational latency or relies on the precise extraction of parasitic parameters, which is impractical and computationally expensive for large-scale integration. To overcome these limitations, we propose a Parameter-Agnostic Adaptive Compensation (PAAC) method based on a distributed linear approximation model. By analyzing the circuit characteristics, we conquered the challenge of coupling between parasitic effects and output current, deriving a simplified linear relationship that requires no prior knowledge of specific resistance values. The PAAC method involves only a single-step pre-calibration experiment to determine a global compensation factor, achieving an ultra-low computational complexity during inference. We validated the method using a comprehensive two-stage strategy: board-level hardware experiments confirmed its feasibility by reducing current distortion from 71% to 2%, while extensive large-scale HSPICE simulations verified its scalability, restoring classification accuracy from 89% to 95%. This work provides a robust, low-overhead solution that eliminates the dependency on precise parameter modeling, facilitating the realization of large-scale, high-precision neuromorphic hardware. Full article

This work presents the application of a Time-Domain Reflectometry (TDR) inversion algorithm for localizing water along a bi-wire cable acting as a distributed sensing element (SE), and for evaluating the uncertainty of the water position measurement. The TDR inversion relies on a simplified yet effective gray-box circuital model of the measurement system that, without attempting a full-wave electromagnetic (EM) simulation, reproduces with good accuracy any actually observed reflectograms. The model parameters are estimated from a single acquired reflectogram so as to reproduce the measured signal, without a prior EM characterization of the system components. The model provides the water localization and enables extensive simulation campaigns under realistic variations in water position, stimulus pulse duration, and disturbance effects. A specific measurement setup, designed to perform repeated measurements in controlled laboratory conditions, is analyzed in detail as a case study. The water localization error of the measurement system is statistically evaluated in terms of confidence intervals, bias, and standard deviation, by means of simulated measurements of the model, with different water positions and TDR pulse durations. Then, the uncertainty evaluation is validated through 45 actual measurements, using multiple SEs, and the same water positions and pulse durations. The work proves the viability and the performance of the presented TDR inversion method for both localization measurements and for their uncertainty evaluation under different experimental conditions. More generally, it establishes a general framework for TDR measurements and uncertainty evaluation combining physical modeling, simulation-based uncertainty evaluation, and experimental verification. Full article

With the increasing density of transmission lines, line crossings and spans have become more common, and the electromagnetic environment of transmission lines has attracted increasing attention. Investigating the electromagnetic field distribution in transmission line crossing regions is therefore of great significance for line layout and preliminary design. In this study, the parameters of transmission lines in crossing regions are first obtained by parsing the GIM (Grid Information Model) file. A three-dimensional electromagnetic field model of a double-circuit transmission line on the same tower is then established using the finite element method, and the accuracy of the proposed approach is validated by comparison with field measurement data. Based on the developed model, the electric and magnetic field distributions of both the double-circuit transmission line and the crossing region are calculated. Furthermore, the effects of different crossing angles, phase sequence combinations, and voltage levels on the electromagnetic field distribution are systematically investigated. By comparing the electromagnetic field characteristics under different phase sequence schemes, an optimized phase sequence configuration for double-circuit transmission lines and crossing regions is proposed. The results provide a theoretical basis and technical reference for electromagnetic environment assessment and design optimization of transmission lines in crossing regions. Full article

To address the issue of significantly reduced coupling coefficient and limited transmission efficiency in traditional flat solenoid magnetic couplers within wireless power transfer (WPT) systems under horizontal lateral offset conditions, this paper proposes a design method for a concave flat solenoid coil magnetic coupler for engineering applications, aiming to achieve high misalignment tolerance. An equivalent model of the LCC/S compensation circuit is established, its output characteristics are analyzed, and the parameter configuration method for its resonant elements is derived. Secondly, from the perspective of winding arrangement, the mechanism by which the coil winding method, turn spacing, and port concavity angle affect the uniformity of magnetic field distribution and the retention rate of the coupling coefficient is analyzed in detail, and corresponding parameter trade-off and optimization methods are proposed. Subsequently, a simulation model of multiple configuration magnetic couplers is established based on Ansys/Maxwell, comparing the magnetic field distribution and coupling coefficient variation of different structures under horizontal offset conditions. The results show that the concave structure with a non-uniform arrangement and a port concavity angle of 30° can still maintain a high coupling coefficient and stable transmission performance under a maximum horizontal offset equal to 60% of the corresponding transmitter-side characteristic dimension. To achieve lightweight and integrated design, the receiver is designed with a flexible printed circuit board (FPC) coil structure, meeting the miniaturization and high power density requirements of low-to-medium power portable devices. Finally, a 100 W experimental prototype was built. Experimental results show that within an offset range of ±15 mm on the X-axis and ±30 mm on the Y-axis at the receiver, the system output voltage fluctuation is controlled within 4%, and the maximum transmission efficiency reaches 87.3%. These results verify the feasibility and practical applicability of the proposed magnetic coupler with high misalignment tolerance. Full article

To address the low efficiency of finite element modeling and the reliance on manual measurements in electric/magnetic field analysis of complex overhead transmission line structures, this paper develops an IronPython-based automated computational platform within ANSYS Maxwell for 3-D modeling and electric/magnetic field analysis. First, by parsing transmission line data from the Grid Information Model (GIM), a unified coordinate transformation method is proposed to convert geographical coordinates into three-dimensional (3-D) Cartesian coordinates for finite element analysis. Based on the extracted line parameters, conductor sag is calculated and catenary modeling is implemented. An equivalent radius method is also introduced to simplify multi-bundle conductor modeling, enabling fast parametric construction of complex 3-D transmission line models. Second, by combining the IronPython scripting language with the .NET Windows Forms control library, a visualized finite element modeling and computation platform is developed. Finally, a typical double-circuit transmission line on the same tower is taken as a case study to calculate the spatial distribution of electric/magnetic fields. The influence of solution domain size on electric/magnetic field computation results is investigated, and optimal solution domain parameters are determined. The finite element results generated by the developed platform are further validated through comparison with measured data. The results demonstrate good agreement between calculated and measured values, confirming the accuracy and engineering applicability of the developed platform for electric/magnetic environment analysis of overhead transmission lines. Full article
