Search Results (14)

Direct injection of hydrogen at high pressures into an otherwise unmodified heavy-duty diesel engine offers a near-term pathway to near-zero greenhouse gas emissions for commercial vehicles. Hydrogen direct-injection engines maintain diesel-like performance with equal or better thermal efficiency. Supplying the hydrogen for injection pressures of ~30 MPa requires a high-pressure supply. Onboard hydrogen compression enables more complete utilization of the stored compressed hydrogen; however, it introduces a significant parasitic load on the engine. The magnitude of this load depends on factors such as the compressor’s configuration, capacity, pressure ratio, efficiency, and the engine’s operating conditions. This paper presents an exergy analysis of an onboard hydrogen compression system that uses hydraulically driven free-floating pistons, sized for heavy-duty commercial vehicles. Minimizing the parasitic loads from the compressor is essential to retain vehicle performance and maximize system-wide efficiency. The exergy analysis approach provides a comprehensive understanding of the whole compression system by comparably quantifying the losses across all components. A one-dimensional model of the compression system, developed in GT-SUITE^TM and validated with experimental data, is used to quantify the main exergy loss components. Exergy efficiency ranges from 12% to 45% under varying pressure ratios and cycle frequencies, with a pronounced increase in efficiency observed at higher cycle frequencies. Major exergy losses occur in the hydraulic driving system up to 79%, especially during retracting and idle phases for lower pressure ratios and cycle frequencies. Within the compression cylinder, exergy destructions account for less than 10% of the total work input, wherein heat transfer and piston friction are identified as the dominant contributors to exergy destruction, with their effects intensifying at higher pressure ratios. This work highlights the challenges of onboard gas compression and develops a systematic framework that can compare compressor design alternatives for different driving cycles. Full article

Electric wheel loaders (EWLs) have emerged as a pivotal innovation in the 2020s, representing a transformative shift toward high-efficiency, low-emission construction machinery. Despite their growing technological and environmental significance, a systematic synthesis of advancements in EWL design, energy optimization, and intelligent control remains absent in the literature. To bridge this gap, this review critically evaluates over 140 studies for comparative analysis. Building on the authors’ ongoing research, this paper categorizes EWL architectures and examines breakthroughs in hydraulic systems, drivetrain configurations, and bucket dynamics optimization. A dedicated focus is placed on energy-saving strategies, including advancements in battery technology, fast-charging infrastructure, intelligent torque distribution, and data-driven modeling of shoveling and operational resistance. The analysis reveals that integrating optimal control strategies with machine learning algorithms—such as model predictive control (MPC)—is a critical pathway to achieving energy-efficient and assisted driving in next-generation EWLs. Furthermore, this review advocates for the adoption of distributed electro-hydraulic drive systems to minimize hydraulic losses and enable efficient energy recovery during actuator control. By synthesizing these insights, this work not only highlights current technological frontiers but also proposes actionable research directions to accelerate the commercialization of intelligent, sustainable EWLs. Full article

A directional valve is a core component of the electro-hydraulic shakers in fatigue testing machines, controlling the cylinder or motor that drives the piston for reciprocating linear or rotary motion. In this article, a high-speed rotating directional valve with a symmetrical flow channel layout is designed to optimize the force on the valve core of the directional valve. A comparative analysis is conducted on the flow capacity of valve ports with different shapes. A steady-state hydrodynamic mathematical model is established for the valve core, the theoretical analysis results of which are verified through a Computational Fluid Dynamics (CFD) simulation of the fluid domain inside the directional valve. A prototype of the rotatory directional valve is designed and manufactured, and an experimental platform is built to measure the hydraulic force acting on the valve core to verify the performance of the valve. The displacement curves at different commutation frequencies are also obtained. The experimental results show that the symmetrical flow channel layout can significantly optimize the hydraulic force during the movement of the valve core. Under a pressure of 1 MPa, the hydraulic cylinder driven by the prototype can achieve a sinusoidal curve output with a maximum frequency of 60 Hz and an amplitude of 2.5 mm. The innovation of this design lies in the creation of a directional valve with a symmetric flow channel layout. The feasibility of the design is verified through modeling, simulation, and experimentation, and it significantly optimizes the hydraulic forces acting on the spool. It provides us with the possibility to further improve the switching frequency of hydraulic valves and has important value in engineering applications. Full article

The abundance of resources in the deep sea continues to inspire mankind’s desire for exploration. However, the extreme environments pose a huge challenge for designing deep-sea mechanical devices that are primarily driven by hydraulic and electric motor technology. Researchers are beginning to explore more flexible and innovative drive methods suitable for the deep-sea environment. This paper presents a simple joint mechanism based on a paraffin phase change thermal expansion drive. Its unique design combines a flexible cell with an open structure that allows it to adapt to different pressures at different water depths. Paraffin is enclosed in multiple sets of smaller paraffin cells, which act as thermal expansion material for generating hydraulic pressure. The software comsol was used to perform a finite element analysis of the phase change process in paraffin. By fabricating the mechanical structure, the displacement generated by the thermal expansion is amplified and converted, thus enabling a bi-directional rotational displacement output from the joint while reducing the complexity of the structure. The joints in this paper provide a reliable reference for the design of small deep-sea robot drive systems. Full article

Aiming at the requirements of distributed braking and advanced automatic driving, a brake-by-wire unit based on a direct drive pump–valve cooperative is proposed. To realize the wheel cylinder pressure regulation, the hydraulic pump is directly driven by the electromagnetic linear actuator coordinates with the active valve. It has the advantages of rapid response and no deterioration of wheel side space and unsprung mass. Firstly, by analyzing the working characteristics and braking performance requirements of the braking unit, the key parameters of the system are matched. Then, in order to ensure the accuracy of the simulation model, the co-simulation model of the brake unit is established based on the Simulink-AMESim co-simulation platform. Then, the influence law of key parameters on the control performance is analyzed. Finally, the experimental platform of the brake unit is established. The accuracy of the co-simulation model and the feasibility of the brake-by-wire unit based on direct drive pump–valve cooperative are verified through the pressure control experiment and ABS simulation, which shows that the braking unit has good dynamic response and steady-state tracking effect. Full article

The hydrostatic actuation system based on linear actuators improves the complex piston force and long transmission path of the traditional electro-hydrostatic actuator (EHA). However, new nonlinear factors in the linear actuator and direct-driven piston are introduced into the system, which present challenges to system modeling and control. To improve the accuracy of system performance prediction, this paper analyzed the working characteristics of an electromagnetic direct-drive hydrostatic actuation system (EDHAS). A dynamic model of the electromagnetic linear actuator including the LuGre friction model was established. The high-pressure internal leakage of the direct-drive pump was described by an inclined eccentric leakage model. The Karnopp friction model was applied to solve the problem of switching between viscous and sliding friction in a cylinder. The hydraulic components model was established based on AMESim, and the electromagnetic linear actuator model and the system controller model were established in Matlab/Simulink, to establish a refined electromechanical–hydraulic co-simulation model of the EDHAS with electromagnetic, mechanical, hydraulic, and control coupling. A system performance test platform was built. The simulation results of the direct-drive piston displacement, the system pressure, the system flow rate, and the cylinder displacement match well with experimental results, which verifies the validity and accuracy of the refined modeling method. Full article

Offshore wind turbine drive train technology is evolving as developers increase size, aim to maximise availability and adapt to changing electricity grid requirements. This work first of all explores offshore technology market trends observed in Europe, providing a comprehensive overview of installed and planned capacity, showing a clear shift from smaller high-speed geared machines to larger direct-drive machines. To examine the implications of this shift in technology on reliability, stop rates for direct-drive and gear-driven turbines are compared between 39 farms across Europe and South America. This showed several key similarities between configurations, with the electrical system contributing to largest amount of turbine downtime in either case. When considering overall downtime across all components, the direct-drive machine had the highest value, which could be mainly attributed to comparatively higher downtime associated with the electrical, generator and control systems. For this study, downtime related to the gearbox and generator of the gear-driven turbine was calculated at approximately half of that of the direct-drive generator downtime. Finally, from a perspective of both reliability and fault diagnostics at component level, it is important to understand the key similarities and differences that would allow lessons learned on older technology to be adapted and transferred to newer models. This work presents a framework for assessing diagnostic models published in the literature, more specifically whether a particular failure mode and required input data will transfer well between geared and direct-drive machines. Results from 35 models found in the literature shows that the most transferable diagnostic models relate to the hydraulic, pitch and yaw systems, while the least transferable models relate to the gearbox. Faults associated with the generator, shafts and bearings are failure mode specific, but generally require some level of modification to adapt features to available data. Full article

In data-driven bearing fault diagnosis, sufficient fault data are fundamental for algorithm training and validation. However, only very few fault measurements can be provided in most industrial applications, bringing the dynamics model to produce bearing response under defects. This paper built a Modelica model for the whole bearing test rig, including the test bearing, driving motor and hydraulic loading system. First, a five degree-of-freedom (5-DoF) model was proposed for the test bearing to identify the normal bearing dynamics. Next, a fault model was applied to characterize the defect position, defect size, defect shape and multiple defects. The virtual bearing test bench was first developed with OpenModelica and then called in Python with OMPython. For validation of the positive effect of the dynamics model in the direct transfer learning for bearing fault diagnosis, the simulation data from the Modelica model and experimental data from the Case Western Reserve University were fed separately or jointly to train a Convolution Neural Network (CNN). Then the well-trained CNN was transferred directly to achieve the fault diagnosis under the test set consisting of experiment data. Additionally, 157 features were extracted from both time-domain and frequency-domain and fed into CNN as input, and then four different validation cases were designed. The results confirmed the positive effect of simulation data in the CNN transfer learning, especially when the simulation data were added as auxiliary to experimental data, and improved CNN classification accuracy. Furthermore, it indicated that the simulation data from the bearing dynamics model could play a part in the actual experimental measurement when the collected data were insufficient. Full article

Electro-hydraulic compact drives (ECDs) are an emerging technology for linear actuation in a wide range of applications. Especially within the low power range of 5–10 kW, the plug-and-play capability, good energy efficiency and small space requirements of ECDs render this technology a promising alternative to replace conventional valve-controlled linear drive solutions. In this power range, ECDs generally rely on passive cooling to keep oil and system temperatures within the tolerated range. When expanding the application range to larger power classes, passive cooling may not be sufficient. Research investigating the thermal behaviour of ECDs is limited but indeed required for a successful expansion of the application range. In order to obtain valuable insights into the thermal behaviour of ECDs, thermo-hydraulic simulation is an important tool. This may enable system design engineers to simulate thermal behaviour and thus develop proper thermal designs during the early design phase, especially if such models contain few parameters that can be determined with limited information available. Our paper presents a lumped thermo-hydraulic model derived from the conservation of mass and energy. The derived model was experimentally validated based on experimental data from an ECD prototype. Results show good accuracy between measured and simulated temperatures. Even a simple thermal model containing only a few thermal resistances may be sufficient to predict steady-state and transient temperatures with reasonable accuracy. The presented model may be used for further investigations into the thermal behaviour of ECDs and thus toward proper thermal designs required to expand the application range. Full article

In order to ensure good dynamic characteristics, servo valve is usually adopted as the drive part of Stewart manipulator which causes huge power consumption, while direct drive electro-hydraulic servo system has the advantages of energy saving, simple structure, convenient installation, and low failure rate. But its dynamic characteristics are so poor that it can only be applied to occasions where quick response is not needed. On the consideration above, following works are done in this paper. Since current coupling exists in the control system based on the speed of the servo motor as the control input, the control system of the direct drive Stewart manipulator is established based on the current of the servo motor as the control input in which the current coupling can be solved. In order to improve the dynamic characteristics of the direct drive Stewart manipulator, a Proportion Differentiation (PD) plus dynamic pressure feedback control strategy is also put forward in this paper, which is verified by using a simulated hydraulically driven Stewart manipulator. Simulation results show that both dynamic coupling and current coupling are solved and the control strategy proposed in this paper can significantly increase the bandwidths of all degrees of freedom. Full article

Pump controlled and self-contained electro-hydraulic cylinder drives may improve energy efficiency and reduce installation space compared to conventional valve solutions, while being in line with the trend of electrification. The topic has gained increasing interest in industry as well as in academia in recent years. However, this technology has failed to break through in industry on a broad scale, with the reason assumed to be lack of meeting industry requirements. These requirements include high drive stiffness enabling a large application range, and the ability to maintain cooling and filtration in required ranges, enabling proper reliability and durability. Furthermore, at this point the cost of realization of such drives is comparable only to high end valve drive solutions, while not providing dynamics on a similar level. An initiative to improve this technology in terms of a class of drives evolving around a hydraulic cylinder locking mechanism is proposed. The resulting class of drives generally rely on separate cylinder forward and return flow paths, allowing for fluid cooling and filtration as well as control of the drive stiffness. The proposed class of drives is analyzed regarding energy loss and recovery potential, a basic model based control design is realized, and the industrial feasibility of the drive class is considered. It is found that the proposed class of drives may be realized with standard components maintained in their design ranges at competitive costs compared to conventional valve solutions. Furthermore, it is found that pressure levels may be controlled in a proper way, allowing to produce either highly efficient operation or a high drive stiffness. Full article

Pump-controlled hydraulic cylinder drives may offer improved energy efficiency, compactness, and plug-and-play installation compared to conventional valve-controlled hydraulic systems and thus have the potential of replacing conventional hydraulic systems as well as electro-mechanical alternatives. Since the late 1980s, research into how to configure the hydraulic circuit of pump-controlled cylinder drives has been ongoing, especially in terms of compensating the uneven flow requirements required by a differential cylinder. Recently, research has also focused on other aspects such as replacing a vented oil tank with a small-volume pressurized accumulator including the consequences of this in terms of thermal behavior. Numerous references describe the advantages and shortcomings of pump-controlled cylinder drives compared to conventional hydraulic systems or electro-mechanical drives. This paper presents a throughout literature review starting from the earliest concepts based on variable-displacement hydraulic pumps and vented reservoirs to newer concepts based on variable-speed electric drives and sealed reservoirs. By classifying these drives into several proposed classes it is found that the architectures considered in the literature reduce to a few basic layouts. Finally, the paper compares the advantages and shortcomings of each drive class and seek to predict future research tasks related to pump-controlled cylinder drives. Full article

Direct driven hydraulic drives (DDH) have the advantages of compact high power density in hydraulic systems and flexible control of electric motors. These advantages can benefit non-road mobile machinery (NRMM) applications. However, maintaining high efficiency while working in sub-zero conditions with NRMM is challenging. Therefore, this paper investigates the effect of hydraulic oil on the efficiency of a DDH in a cold environment for an NRMM application. In the DDH setup, the speed and position control of a double-acting cylinder was implemented directly with an electric motor drive in a closed-loop system without the conventional control valves. Efficiency measurements of the DDH setup with two oils (conventional multi-grade and high-performance) were conducted under different operating conditions (speed and payload) and environmental conditions (temperature in °C). The paper provides an evaluation of the electro-hydraulic system and a discussion on the usage of hydraulic oil by non-road mobile working machines in sub-zero conditions. An experimental investigation demonstrated an improvement in efficiency of 5%-unit at 22 °C, from 2%-unit to 5%-unit at 3 °C, and of almost a 10%-unit at temperatures below zero (−10 °C) by changing oil. Full article

This paper investigates the effect of extra weight caused by the Direct Driven Hydraulics (DDH) in a micro-excavator. These projects are investigating the implementation of zonal or decentralized hydraulics for non-road mobile machinery (NRMM) and stationary industrial applications. The benefit of DDH is the combination of electric and hydraulic technologies in a compact package compared to conventional hydraulics, which enables a reduction of potential leakage points, flexible tubing, and boosting of the system efficiency due to switching to direct pump control instead of a loss-generating conventional valve-based control. In order to demonstrate these benefits for the excavator case, this paper proposes a system model approach to assess and predict energy consumption of the zonal hydraulics approach implemented with DDH in various working cycles, complemented by a structural analysis. The finite element analysis utilized for this demonstrated that the extra weight and selected location of DDH units do not negatively affect the structure of the excavator. Simulation results demonstrated that the energy consumption is approximately 15% higher with extra weight added by the three DDH units. Although approximately 20% more regeneration energy is produced, taking into account the regeneration energy, the increases in energy consumption are about 12%. Full article
