In large-scale offshore wind power transmission systems, the offshore converter valves are typically based on the half-bridge Modular Multilevel Converter (MMC) topology. This design leads to considerable weight and high costs, presenting a critical bottleneck for the development of offshore wind power transmission. This paper proposes a hybrid topology consisting of paralleled MMCs connected in series with a Diode Rectifier Unit (DRU) to achieve lightweight offshore converter valves. The parallel configuration enhances the steady-state current-carrying capacity of the valve group to match the DRU valve group, and power balance among the paralleled MMCs is realized through an additional DC current-sharing control loop. A calculation method for the main circuit parameters of this lightweight topology is presented, along with a complete parameter calculation process. A design example based on actual engineering capacity is provided. PSCAD simulation results verify that the electrical quantities during steady-state operation of the hybrid topology are consistent with the designed parameters, confirming the correctness of the proposed parameter calculation method. Full article

Photovoltaic (PV) performance in desert environments is significantly hindered by soiling and partial shading. To bridge the gap in empirical data for extreme Saharan conditions, this study presents a novel techno-economic assessment of uniform horizontal shading (UHS) specifically conducted in Mauritania. Controlled outdoor experiments were performed using a 250 W crystalline silicon PV module and a PVPM 2540C I–V curve tracer, applying progressive shading levels from 2.5% to 20%. The novelty of this work lies in the integration of high-resolution experimental I–V/P–V characterization with a localized techno-economic model for five pre-commercial PV plants. It was observed that PV modules are exceptionally sensitive to shading; specifically, a mere 10% shaded area leads to a catastrophic 90% drop in power and current, while the voltage remains remarkably stable. Thermographic analysis further validates the thermal gradients and bypass diode functionality. By quantifying the financial impacts, this research highlights that cumulative economic losses across the five real-world sites reached 87.95%, exceeding 55,000 MRU. These findings provide a strategic framework for optimizing PV systems in arid terrains and offer a robust tool for enhancing the design and operation of large-scale solar applications in desert environments. Full article

Vibrational energy harvesters typically generate only low voltages and low powers, making high-efficiency power conversion essential to extract usable energy from such sources. To address this challenge, suitable rectifier circuits must be designed to operate efficiently under low-voltage conditions. In this study, three rectifier topologies—a standard bridge rectifier and two alternative designs from the literature—were investigated in a two-step methodology: first, measurements were performed in the laboratory using a function generator to simulate controlled excitation conditions, followed by experiments with a real electromagnetic energy harvester. Component-level testing allowed the identification of the most suitable components for each topology, highlighting the influence of parameters such as MOSFET gate-source threshold voltage on overall performance. Using the selected optimal components, the circuits were then compared under varying excitation amplitudes and load conditions. Small modifications were introduced to the literature designs to improve switching behavior and reduce conduction losses. Across all tested conditions, the active-diode rectifier consistently achieved the highest harvested power, demonstrating both the effectiveness of component selection and the practical benefit of the adapted topology. These results provide a systematic basis for designing high-efficiency rectifiers for low-voltage vibrational energy harvesting applications. Full article

The recent advent of charging infrastructure on an Electric Vehicles (EVs) poses a severe problem with effect on the power grid in terms of harmonic distortion, mostly caused by the nonlinear loads on the electric power produced by charging stations, diode bridge rectifiers, and switching converters. These harmonics continuously negatively influence power quality by increasing system and grid current, voltage total harmonic distortion (THD), power factor, and voltage regulation, and lowering the overall efficiency of the system at high rates that exceed IEEE 519 harmonic standards. This paper develops a thorough design and critical analysis of four topologies of harmonic passive filter, including single-tuned filter (STF), double-tuned filter (DTF), high-pass filter (HPF), and C-type high-pass filter (CHPF), to alleviate harmonics and enhance power quality on grid-tied charging stations of electric vehicles. A generalized structure is modeled and simulated in MATLAB/Simulink R2021a at a charging load of an EV charging load for all the filters under the same conditions and evaluated based on the current THD (ITHD), voltage THD (VTHD), input power factor (PF), voltage regulation (VR), and efficiency (η). The findings show that STF has an ITHD of 8.3%, VTHD of 4.6%, PF of 0.92, VR of 6.2%, and efficiency of 91.3%; DTF has an ITHD of 6.1%, VTHD of 3.9%, PF of 0.95, VR of 5.4%, and 93.5%; HPF has an ITHD of 5.6%, VTHD of 3.5%, 0.96 PF, 5.0% of VR, and 94.2% efficiency. The effectiveness of the proposed CHPH is superior to all other traditional approaches and has the lowest ITHD and VTHD, 3.7% and 2.1%, respectively, the highest PF of 0.987, a better VR of 3.8%, and a higher efficiency of 96.2%. The proposed CHPF shows the high-performance characteristics as reflected in the harmonic reduction, improved voltage stability, power factor, and efficiency. The suggested CHPF complies with IEEE 519 standards and provides better grid compatibility with modern EV charging applications. Full article

This research aims to establish design guidelines for a cantilever triple-layer piezoelectric harvester (CTLPH) with tip mass and tip excitation, operating under resonance conditions. The guideline is derived by combining constitutive equations with Euler–Bernoulli beam theory to identify the effective parameters of the CTLPH and, subsequently, the storage voltage after rectification using a germanium diode bridge. The analysis shows that excitation frequency, piezoelectric coefficients, geometrical dimensions, and the mechanical properties of the layers all significantly influence CTLPH performance. The effects of storage capacitance and excitation frequency were experimentally validated through the design, fabrication, and testing of a prototype. Furthermore, the LTC3588 energy storage module was employed to store the generated charge from resonance motion. An advanced non-contact optical method was employed to determine the bending stiffness of the CTLPH. The output power after the energy storage module was measured across a range of resistive loads at frequencies near the resonance condition (f = 65 Hz). Results demonstrate that both excitation frequency and external resistance affect the maximum harvested power. The developed CTLPH achieved an optimum output power of 46.18 ± 0.98 μW at an external resistance of 3 kΩ, which is sufficient to supply micropower sensors. Full article

Imidazopyridines are a versatile class of nitrogen-fused heterocycles bridging medicinal chemistry and materials science. Their π-conjugated framework allows broad structural tuning, yielding diverse biological and photophysical properties. The best-known isomers, imidazo[1,2-a]pyridine and imidazo[1,5-a]pyridine, have been widely studied as pharmacophores and luminescent materials, respectively. The less explored imidazo[4,5-b] and imidazo[4,5-c]pyridines are now emerging as alternative scaffolds with distinctive electronic and functional behavior. This review summarizes synthetic strategies, electronic features, and key applications—from kinase inhibition and antiviral activity to fluorescence imaging, down-conversion, Organic Light Emitting Diode (OLED)/Light-emitting Electrochemical Cell (LEC) and hybrid optoelectronic systems—outlining how imidazopyridines can evolve from molecular frameworks into multifunctional platforms for bioimaging and advanced optoelectronic technologies. Full article

The direct photolithographic patterning of quantum dots (QDs) presents a promising route for high-resolution displays, while the associated loss in electroluminescence efficiency remains a significant challenge. This work addresses this challenge by introducing a fluorinated bisazide-derived photo-crosslinker, which enables high-fidelity patterning while preserving optoelectronic properties. Central to our strategy, this molecularly engineered crosslinker undergoes efficient nitrene-mediated crosslinking upon i-line (365 nm) exposure, forming robust networks between the QDs’ native ligands without compromising their electrical functionality. This approach achieves high-fidelity red, green, and blue (RGB) patterns with individual pixel sizes of 24 μm × 24 μm and a narrow pixel spacing of 2.5 μm. Combined with a Zn_1−xMg_xO electron-transport layer to optimize interfacial charge balance, the resulting red quantum-dot light-emitting diodes (QLEDs) retain an external quantum efficiency of 10.88%, representing 85.67% retention compared to unpatterned devices. This strategy is universally applicable, as demonstrated by the successful operation of green (8.46% external quantum efficiency (EQE)) and blue (2.25% EQE) devices. Our work establishes a scalable, lithography-compatible platform that effectively bridges the gap between high-resolution patterning and high-performance electroluminescence, paving the way for next-generation full-color microdisplays. Full article

Wide-bandgap (WBG) semiconductor materials such as silicon carbide (SiC) and gallium nitride (GaN) are key enablers of power-electronics converters for aerospace platforms, where high efficiency, weight reduction, and thermal robustness are critical requirements. This paper presents the main challenges associated with the use of these technologies, including protection requirements, electromagnetic compatibility, and thermal management, as well as the material advantages that enable higher switching frequencies and lower losses compared to conventional Si technologies. A comparative analysis of semiconductor technologies and suitable power-conversion topologies for the aerospace context is provided. Representative laboratory-scale experimental validation is presented, including the development of a DC–DC boost converter and a DC–AC full-bridge inverter, which are linked through the common DC-link and are used for interfacing batteries and an electrical motor, both based on GaN and SiC diodes. The results demonstrated the correct operation, with stable high-frequency performance under controlled laboratory conditions, supporting aerospace-oriented development, although evaluated in a laboratory environment, confirming the potential of WBG technologies for future power-conversion architectures. Full article

To address the issue of low efficiency in recovering low-frequency vibration energy during vehicle operation, this paper proposes a piezoelectric energy capture harvester based on wheel vibration. The device employs a parallel configuration of dual cantilever beam piezoelectric transducers in its mechanical structure, with additional mass blocks to optimize its resonant characteristics in the low-frequency range. A synchronous switch energy harvesting circuit was designed. By actively synchronizing the switch with the peak output voltage of the piezoelectric element, it effectively circumvents the turn-on voltage threshold limitations of diodes in bridge rectifier circuits, thereby enhancing energy conversion efficiency. A dynamic model of this device was established, and multiphysics simulation analysis was conducted using COMSOL-Multiphysics to investigate the modal characteristics, stress distribution, and output performance of the energy harvester. This revealed the influence of the piezoelectric vibrator’s thickness ratio and the mass block’s weight on its power generation capabilities. Experimental results indicate that under 20 Hz, 12 V sinusoidal excitation, the system achieves an average output power of 3.019 mW with an average open-circuit voltage reaching 16.70 V. Under simulated road test conditions at 70 km/h, the output voltage remained stable at 6.86 V, validating its feasibility in real-world applications. This study presents an efficient and reliable solution for self-powering in-vehicle wireless sensors and low-power electronic devices through mechatronic co-design. Full article

Triboelectric nanogenerators (TENGs) offer intrinsically high open-circuit voltages in the kilovolt range; however, conventional diode rectifier interfaces clamp the voltage prematurely, restricting access to the high-energy portion of the mechanical cycle and preventing delivery-centric control. This work develops a unified physical basis for contact–separation (CS) TENGs by confirming the consistency of the canonical $V_{oc}$–$C_s$ relation with a dual-capacitor energy model and analytically establishing that both terminal voltage and storable electrostatic energy peak near maximum plate separation. Leveraging this insight, a self-powered gas-discharge-tube (GDT) rectifier bridge is devised to replace two diodes and autonomously trigger conduction exclusively in the high-voltage window without auxiliary bias. An inductive buffer regulates the current slew rate and reduces $I^{2}R$ loss, while the proposed topology realizes two decoupled power rails from a single CS-TENG, enabling simultaneous sensing/processing and actuation. A low-power microcontroller is powered from one rail through an energy-harvesting module and executes an operator-based nonlinear controller to regulate the actuator-side rail via a MOSFET–resistor path. Experimental results demonstrate earlier and higher-efficiency energy transfer compared with a diode-bridge baseline, robust dual-rail decoupling under dynamic loading, and accurate closed-loop voltage tracking with negligible computational and energy overhead. These findings confirm the practicality of the proposed self-powered architecture and highlight the feasibility of integrating operator-theoretic control into TENG-driven rectifier interfaces, advancing delivery-oriented power extraction from high-voltage TENG sources. Full article

This paper develops a compact and scalable mathematical model of an AC circuit with an uncontrolled diode bridge rectifier, formulated using dimensionless variables. The model captures the joint influence of supply inductance, resistance, and load parameters on current waveform distortion, harmonic content, and reactive power exchange, which are often simplified or addressed separately in existing studies. Experimental validation confirms the applicability of the model over a wide range of operating conditions and grid strengths. The results provide quantitative characteristics that support the interpretation of power quality measurements and the assessment of how nonlinear loads interact with non-stiff supply sources. The proposed formulation offers an efficient analytical tool for harmonic analysis in distribution networks, particularly where a balance between modelling accuracy and computational effort is required. Full article

Against the backdrop of rapid advances in computing, industry, and electric vehicles, DC–DC buck converters—as core point-of-load regulators—are critical for power supplies in applications with stringent voltage-stability requirements. This paper proposes a two-phase interleaved Buck converter based on positively coupled inductor with a high coupling coefficient. The innovation lies in the positively coupled inductor and two-phase interleaved architecture, where two MOSFETs and two diodes form a similar symmetrical full-bridge interleaved structures together achieve a higher conversion ratio and provide $ZCS$ operation for all power devices, thereby effectively reducing switching losses. Relative to traditional topologies, the proposed converter delivers a higher conversion ratio without extreme duty-cycle operation while improving reliability. After detailing the operating mechanism, we derive the input–output voltage relation, outline controller synthesis guidelines, and specify the soft-switching conditions. From the viewpoint of symmetry, the proposed interleaved converter exploits the electrical and magnetic symmetry between phases to achieve current balancing, extended duty-cycle range and soft-switching. Validation is provided by both a $PSIM$ simulation model and a $270W$ hardware prototype using an $STM32F103ZET6$, which achieves 93.3% peak efficiency at a conversion ratio of 0.45, demonstrating the practicality and effectiveness of the approach. Full article

This paper introduces a new four-switch, high-voltage, high-step-up converter employing two transformers. The topology enables Zero-Voltage Switching (ZVS) across all primary switches for operating conditions ranging from no load to full load. A voltage-quadrupler and a voltage-doubler rectifier are used on the secondary sides of the transformers, enabling reduced turn-off current for the voltage-quadrupler diodes and Zero-Current Switching (ZCS) turn-off for the voltage-doubler diodes, thereby ensuring high efficiency across diverse load levels. Notably, the voltage stress experienced by the voltage-multiplier diodes is significantly lower than the output voltage, thereby rendering the converter exceptionally suitable for high-voltage applications such as electron beam welding (EBW). The voltage gain surpasses that of the conventional phase-shift full-bridge (PSFB) converter, permitting a lower transformer turns ratio and thus reducing winding resistivity. The removal of the substantial output inductor leads to a lighter and more compact design, eliminating insulation concerns associated with inductor windings. This paper details the operation of the proposed converter, supported by experimental results from a 500-W prototype with a 150-V input and 2-kV output, which confirm its high performance and operational advantages. Full article

Low-voltage power converters in the 25–200 V range are increasingly employed in emerging applications such as hybrid electric vehicles (HEVs), photovoltaic systems with battery storage, and electric propulsion systems for recreational boats. In these contexts, 48 V battery systems have become standard, due to safety considerations. Among various converter topologies, H-bridge configurations operating around 100 V DC are widely used in laboratory-scale prototyping. While MOSFETs are the preferred switching devices in this voltage range, due to their high efficiency and fast switching characteristics, they also introduce design challenges related to high current slew rates and associated overvoltage spikes caused by parasitic inductances in the PCB layout. These overvoltages, though modest in absolute terms, can be critical in low-voltage systems, due to the lower device ratings. This paper presents design strategies and layout best practice for a 120 V, 50 A H-bridge converter using 200 V rated MOSFETs. The effectiveness of various mitigation techniques—including the use of ceramic capacitors in parallel with film and electrolytic types, Schottky diodes across MOSFETs, and snubber circuits—is evaluated and experimentally validated on a dedicated prototype. The results highlight the critical role of PCB design in ensuring switching reliability and device protection in low-voltage converter systems. In addition, with the design solutions shown in this study, it was possible to obtain a voltage overshoot during switching of just 165 V with a 120 V DC-link voltage, which guarantees a sufficient safety margin for the MOSFET rated voltage. Full article

Power metal-oxide-semiconductor field-effect transistors (MOSFETs) provide numerous advantages and are widely utilized in various power circuits. The junction temperature plays a critical role in determining the reliability, performance, and operational lifetime of power MOSFETs. Therefore, accurate monitoring of the junction temperature of power MOSFETs is essential to ensure the safe operation of power circuit systems. In bridge or motor drive circuits, MOSFETs often operate in a freewheeling state via the body diode, where the freewheeling current is typically variable. The proposed method for junction temperature measurement utilizes the body diode and is designed to accommodate varying forward currents. It also accounts for the temperature-dependent ideality factor to improve measurement accuracy. By integrating the forward voltage and forward current of the body diode, this approach reduces the required sampling frequency. To validate the method’s effectiveness, three representative types of power MOSFETs, a Si MOSFET (IRF520), a SiC MOSFET (C2M0080120D), and an aerospace-grade radiation-hardened MOSFET (RSCS25045T1RH), were used to measure junction temperatures before and after irradiation. Following ideality factor correction, the maximum absolute error compared to reference measurements from thermocouples and a thermal imager remained within 2 K across the temperature range of 300 K to 420 K. Experimental results confirm the feasibility of the proposed method. Full article
