The microstructure of polyurethane (PU) grouting material is the key determinant of its macroscopic dielectric properties. In this study, based on its microscopic fractal characteristics and combined with effective medium theory and the Menger sponge structure, an n-stage fractal dielectric model was constructed. This model correlates the material’s dielectric response with its fractal dimension and porosity. The fractal dimensions of PU specimens with densities ranging from 0.29734 g/cm³ to 0.41817 g/cm³ were calculated using the box-counting method. Within this density range, the fractal dimension of the PU specimens showed no significant variation, with a calculated value of approximately 2.7355. By approximating the microscopic unit as an n-stage fractal cube based on the Menger sponge structure and incorporating series-parallel dielectric models, an analytical expression for the dielectric constant was derived. A comparison with experimental data shows that the model’s predictions are in good agreement with the measured values, with a mean relative error (MRE) of only 4%. Full article

A flexible piezoresistive material based on vulcanized natural rubber (VNR) and multiwalled carbon nanotubes (MWCNTs) was developed and systematically investigated for strain sensing applications. The nanocomposites were prepared by melting and vulcanizing MWCNT, while keeping the rubber composition constant to isolate the effect of the conductive nanofiller. By scanning electron microscopy, morphological analyses indicated that MWCNTs were dispersed throughout the rubber matrix, with localized agglomerations becoming more evident at higher loadings. In mechanical tests, MWCNT incorporation increases the tensile strength of VNR, increasing the stress at break from 8.84 MPa for neat VNR to approximately 10.5 MPa at low MWCNT loadings. According to the electrical characterization, VNR-MWCNT nanocomposite exhibits a strong insulator–conductor transition, with the electrical percolation threshold occurring between 2 and 4 phr. The dc electrical conductivity increased sharply from values on the order of 10⁻¹⁴ S·m⁻¹ for neat VNR to approximately 10⁻³ S·m⁻¹ for nanocomposites containing 7 phr of MWCNT. Impedance spectroscopy revealed frequency-independent conductivity plateaus above the percolation threshold, indicating continuous conductive pathways, while dielectric analysis revealed strong interfacial polarization effects at the MWCNT–VNR interfaces. The piezoresistive response of samples containing MWCNT exhibited a stable, reversible, and nearly linear response under cyclic tensile deformation (10% strain). VNR/MWCNT nanocomposites demonstrate mechanical compliance and tunable electrical sensitivity, making them promising candidates for flexible and low-cost piezoresistive sensors. Full article

This work systematically investigates photonic nanojet (PNJ) planar arrays formed by periodic arrangements of dielectric microstructures with four geometric configurations: cylinders, cones, truncated pyramids, and pyramids, focusing on the effects of geometry, array arrangement, and array sparsity on PNJ formation and coupling behavior. Full-wave finite-difference time-domain simulations were performed to analyze optical field distributions under different array conditions. The results indicate that under approximately infinite array conditions, different geometries exhibit markedly different coupling responses. Cylindrical and truncated pyramid structures are more susceptible to inter-element scattering, leading to pronounced multistage focusing, whereas pyramid and cone structures maintain higher spatial stability due to dominant localized tip-focusing mechanisms. For the central elements, the maximum PNJ intensity is about 16.4 a.u. for cylindrical structures and 33.5 a.u. for truncated pyramid structures, while significantly higher intensities of approximately 47.5 a.u. and 93 a.u. are achieved for pyramid and cone structures, respectively. In contrast, the FWHM remains nearly constant for all geometries under different array conditions, indicating that lateral focusing is primarily governed by geometry rather than array arrangement. By tuning the array spacing, the inter-element coupling strength can be continuously weakened, and different geometries require distinct sparsity levels to reach the weak-coupling limit. These results establish the dominant role of geometric configuration in PNJ planar arrays and provide guidance for their predictable design. Full article

This study investigates the creepage discharge method applied to a cold cathode to enhance discharge performance. Creepage discharge refers to the movement of electrical discharges along an insulating surface, increasing electron emission from dielectric materials. The research examines discharge behavior by varying the position of a ceramic pipe on the cathode and proposes a new average current calculation method. Findings indicate that when the ceramic pipe tip extends beyond the cathode, discharge intensity increases. The ceramic-covered cathode (CCC) configuration achieved an average discharge current exceeding 600 mA, compared to about 500 mA for the conventional rod-wire cathode (CRC). The CCC design also enabled arc plasma generation at voltages below 5 kV, whereas the CRC required 4–7 kV to achieve similar effects. For industrial applications, the CCC setup produced approximately 700 mA, whereas the CRC reached approximately 600 mA. These results demonstrate that the CCC configuration offers superior discharge current generation and plasma-column discharge. Full article

High-voltage equipment imposes increasingly stringent demands on polymeric insulating materials, particularly in terms of dielectric strength, space charge suppression, thermo-electrical stability, and interfacial reliability. Conventional polymers are prone to critical failure modes under high electric fields, including electrical treeing, partial discharge, interfacial degradation, and thermo-oxidative aging. This review systematically summarizes recent advances in polymer modification strategies specifically designed for high-voltage applications, covering nanofiller reinforcement, plasma surface engineering, and the development of self-healing insulating polymers. Multi-scale structural control and interface engineering, aligned with the specific requirements of high-voltage environments, have emerged as pivotal approaches to enhance insulation performance. Moreover, the integration of artificial intelligence-driven materials design, digital characterization, and application-oriented modeling holds significant promise for accelerating the development of next-generation high-voltage polymeric systems, thereby offering robust materials solutions for the reliable long-term operation of high-voltage equipment. Full article

The development of flexible and self-powered electronic systems requires triboelectric materials that combine high charge retention, mechanical compliance, and stable dielectric properties. Here, we report a redox reaction approach to prepare liquid metal particle-reduced graphene oxide (LMP@rGO) core–shell structures and introduce into a poly(acrylic acid) (PAA) hydrogel to create a high-performance triboelectric layer. The spontaneous interfacial reaction between gallium oxide of LMP and graphene oxide produces a conformal rGO shell while simultaneously removing the native insulating oxide layer onto the LMP surface, resulting in enhanced colloidal stability and a controllable semiconductive bandgap of 2.7 (0.01 wt%), 2.9 (0.005 wt%) and 3.2 eV (0.001 wt%). Increasing the GO content promotes more complete core–shell formation, leading to higher zeta potentials, stronger interfacial polarization, and higher electrical performance. After embedding in PAA, the LMP@rGO structures form hydrogen-bonding networks with the hydrogel nature, improving both dielectric constant and charge retention while notably preserving soft mechanical compliance. The resulting LMP@rGO/PAA hydrogels show enhanced triboelectric output, with the 2.0 wt/vol% composite generating sufficient power to illuminate more than half of 504 series-connected LEDs. All the results demonstrate the potential of LMP@rGO hydrogel composites as promising triboelectric layer materials for next-generation wearable and self-powered electronic systems. Full article

Electric-field-sensitive dielectrics play a crucial role in electric field induction sensing and related capacitive conversion, with interfacial polarization and charge accumulation largely determining the signal output. This paper introduces graphene/transition metal dichalcogenide (TMD) (MoSe₂, MoS₂, and WS₂) heterojunctions as functional fillers to enhance the dielectric response and electric-field-induced voltage output of flexible polydimethylsiloxane (PDMS) composites. Density functional theory (DFT) calculations were used to evaluate the stability of the heterojunctions and interfacial electronic modulation, including binding behavior, charge redistribution, and Fermi level-referenced band structure/total density of states (TDOS) characteristics. The calculations show that the graphene/TMD interface is primarily controlled by van der Waals forces, exhibiting negative binding energy and significant interfacial charge rearrangement. Based on these theoretical results, graphene/TMD heterojunction powders were synthesized and incorporated into polydimethylsiloxane (PDMS). Structural characterization confirmed the presence of face-to-face interfacial contacts and consistent elemental co-localization within the heterojunction filler. Dielectric spectroscopy analysis revealed an overall improvement in the dielectric constant of the composite materials while maintaining a stable loss trend within the studied frequency range. More importantly, calibrated electric field induction tests (based on pure PDMS) showed a significant enhancement in the voltage response of all heterojunction composite materials, with the WS₂-G/PDMS system exhibiting the best performance, exhibiting an electric-field-induced voltage amplitude 7.607% higher than that of pure PDMS. This work establishes a microscopic-to-macroscopic correlation between interfacial electronic modulation and electric-field-sensitive dielectric properties, providing a feasible interface engineering strategy for high-performance flexible dielectric sensing materials. Full article

Adhesive fracture in layered structures is governed by subsurface crack evolution that cannot be accessed using surface-based diagnostics. Methods such as digital image correlation and optical spectroscopy measure surface deformation but implicitly assume a straight and uniform crack front, an assumption that becomes invalid for interfacial fracture with wide crack openings and asymmetric propagation. In this work, terahertz time-domain spectroscopy (THz-TDS) is combined with double-cantilever beam testing to directly map subsurface crack-front geometry in opaque adhesive joints. A strontium titanate-doped epoxy is used to enhance dielectric contrast. Multilayer refractive index extraction, pulse deconvolution, and diffusion-based image enhancement are employed to separate overlapping terahertz echoes and reconstruct two-dimensional delay maps of interfacial separation. The measured crack geometry is coupled with load–displacement data and augmented beam theory to compute spatially averaged stresses and energy release rates. The measurements resolve crack openings down to approximately 100 μm and reveal pronounced width-wise non-uniform crack advance and crack-front curvature during stable growth. These observations demonstrate that surface-based crack-length measurements can either underpredict or overpredict fracture toughness depending on the measurement location. Fracture toughness values derived from width-averaged subsurface crack fronts agree with J-integral estimates obtained from surface digital image correlation. Signal-to-noise limitations near the crack tip define the primary resolution limit. The results establish THz-TDS as a quantitative tool for subsurface fracture mechanics and provide a framework for physically representative toughness measurements in layered and bonded structures. Full article

Plasmonics and metasurfaces (MSs) have emerged as two of the most influential platforms for manipulating light at the nanoscale, each offering complementary strengths that challenge the limits of conventional optical design. Plasmonics enables extreme subwavelength field confinement, ultrafast light–matter interaction, and strong optical nonlinearities, while MSs provide versatile and compact control over phase, amplitude, polarization, and dispersion through planar, nanostructured interfaces. Recent advances in materials, nanofabrication, and device engineering are increasingly enabling these technologies to be combined within unified planar and hybrid optical platforms. This review surveys the physical principles, material strategies, and device architectures that underpin plasmonic, MS, and hybrid plasmonic–dielectric systems, with an emphasis on interface-mediated optical functionality rather than long-range guided-wave propagation. Key developments in modulators, detectors, nanolasers, metalenses, beam steering devices, and programmable optical surfaces are discussed, highlighting how hybrid designs can leverage strong field localization alongside low-loss wavefront control. System-level challenges including optical loss, thermal management, dispersion engineering, and large-area fabrication are critically examined. Looking forward, plasmonic and MS technologies are poised to define a new generation of flat, multifunctional, and programmable optical systems. Applications spanning imaging, sensing, communications, augmented and virtual reality, and optical information processing illustrate the transformative potential of these platforms. By consolidating recent progress and outlining future directions, this review provides a coherent perspective on how plasmonics and MSs are reshaping the design space of next-generation planar optical hardware. Full article

In order to solve the dynamic analysis and interactive imaging control problems in the deformation process of bionic soft lenses, dielectric elastomer (DE) actuators are separated from a convex lens, and data-driven eye-controlled motion technology is investigated. According to the DE properties, which are consistent with the deformation characteristics of hydrogel electrodes, the motion and deformation effect of eye-controlled lenses under film prestretching, lens size, and driving voltage, is studied. The results show that when the driving voltage increases to 7.8 kV, the focal length of the lens, whose prestretching λ is 4, and the diameter d is 1 cm, varies in the range of 49.7 mm and 112.5 mm. And the maximum focal-length change could reach 58.9%. In the process of eye controlling design and experimental verification, a high DC voltage supply was programmed, and eye movement signals for controlling the lens were analyzed by MATLAB software (R2023b). Eye-controlled interactive real-time motion and tunable imaging of the lens were realized. The response efficiency of soft lenses could reach over 93%. The adaptive lens system developed in this research has the potential to be applied to medical rehabilitation, exploration, augmented reality (AR), and virtual reality (VR) in the future. Full article

All-dielectric metasurfaces based on quasi-bound states in the continuum (quasi-BICs) have emerged as a powerful platform for nanophotonic sensing, as they support high-Q resonances and strong near-field enhancements. Herein, we propose and numerically investigate an asymmetric bow-tie metasurface composed of two silicon semi-cylinders with unequal radii and a central bar to achieve a quasi-BIC resonance with a Q-factor of 11,000. The transition mechanism of the BIC modes in the asymmetric bow-tie metasurface is analyzed. Additionally, the spectral features of the asymmetric bow-tie metasurface as a function of the refractive index and temperature of the local environment are also investigated. The proposed structure exhibits a refractive index sensitivity of 454 nm/RIU and a temperature sensitivity of 134 pm/°C. Furthermore, a high figure of merit (FOM) of 3159 RIU⁻¹ is achieved, and the nearly 100% modulation depth maintained across three distinct resonance dips. Our study suggests that the proposed asymmetric bow-tie metasurface offers a promising approach for the development of high-sensitivity biosensing platforms. Full article

This review explores the variety of diamond-based sensing applications, emphasizing their material properties, such as high Young’s modulus, thermal conductivity, wide bandgap, chemical stability, and radiation hardness. These diamond properties give excellent performance in mechanical, pressure, thermal, magnetic, optoelectronic, radiation, biosensing, quantum, and other applications. In vibration sensing, nano/poly/single-crystal diamond resonators operate from MHz to GHz frequencies, with high quality factor via CVD growth, diamond-on-insulator techniques, and ICP etching. Pressure sensing uses boron-doped piezoresistive, as well as capacitive and Fabry–Pérot readouts. Thermal sensing merges NV nanothermometry, single-crystal resonant thermometers, and resistive/diode sensors. Magnetic detection offers FeGa/Ti/diamond heterostructures, complementing NV. Optoelectronic applications utilize DUV photodiodes and color centers. Radiation detectors benefit from diamond’s neutron conversion capability. Biosensing leverages boron-doped diamond and hydrogen-terminated SGFETs, as well as gas targets such as NO₂/NH₃/H₂ via surface transfer doping and Pd Schottky/MIS. Imaging uses AFM/NV probes and boron-doped diamond tips. Persistent challenges, such as grain boundary losses in nanocrystalline diamond, limited diamond-on-insulator bonding yield, high temperature interface degradation, humidity-dependent gas transduction, stabilization of hydrogen termination, near-surface nitrogen-vacancy noise, and the cost of high-quality single-crystal diamond, are being addressed through interface and surface chemistry control, catalytic/dielectric stack engineering, photonic integration, and scalable chemical vapor deposition routes. These advances are enabling integrated, high-reliability diamond sensors for extreme and quantum-enhanced applications. Full article

This study presents the design, optimization, and experimental validation of a dual-band dielectric monopole antenna. The proposed antenna structure consists of three concentric cylindrical dielectric layers, each with independently tunable permittivities and radii. This configuration allows the effective control of electromagnetic performance over distinct frequency bands. To determine the optimal geometric and material parameters, the bio-inspired Honey Bee Mating Optimization (HBMO) algorithm is employed. The optimization process simultaneously maximizes antenna gain and minimizes reflection coefficient in the X and Ku bands. A cost function incorporating both gain and impedance matching criteria is formulated to achieve well-balanced solutions. The final antenna prototype was fabricated using a fused deposition modeling (FDM)-based 3D printer, where the dielectric properties of each layer are adjusted through variable infill rates. Simulated and measured results confirm stable dual-band operation with reflection coefficients below −10 dB, while the maximum in-band realized gains reach approximately 6.6 dBi in the X-band and 7.1 dBi in the Ku-band. These findings demonstrate the effectiveness of the proposed optimization approach and validate the feasibility of using 3D-printed dielectric-loaded structures as an efficient solution for high-frequency and space-constrained communication systems. Full article

Poly(lactic acid) (PLA)-based nanocomposites containing a mixture of graphene nanoplatelets (GNP) and carbon nanotube (CNT) as hybrid fillers were prepared using a solution-assisted sonication process followed by melt processing. The effects of the filler dispersion on dielectric properties and microwave absorbing (MWA) performance were systematically investigated. Two ionic liquids (ILs), trihexyl-(tetra-decyl)phosphonium bis (trifluoromethanesulfonyl)imide (IL1) and 11-carboxyundecyl-triphenylphosphonium bromide (IL2), were employed as dispersing agents for the carbonaceous fillers. Incorporation of IL-treated fillers resulted in enhanced dielectric permittivity and improved MWA performance of the PLA composites. The MWA properties were evaluated in X- band and Ku-band. A minimum reflection loss (RL) of −34 dB and an effective absorption bandwidth (EAB) of 2.1 GHz were achieved for the composite containing GNP/CNT/IL2 (HB3) at a weight ratio of 2.5:0.5:0.5 wt% with one 3 mm thick layer. The superior performance of IL2 is attributed to π-π and π-cation interactions between its phenyl-containing cation and the carbonaceous fillers, as well as improved compatibility with the PLA matrix due to carboxyl groups. Additionally, three-layered composite structures, combining PLA/GNP as the outer layer with IL-assisted hybrid fillers in the core and PLA/CNT at the bottom layer, achieved an extended EAB of 4.5 GHz for GNP/HB2/CNT arrangement and 4.35 GHz for the GNP/HB3/CNT arrangement, driven by enhanced scattering and internal reflection of microwaves. These results demonstrate the potential of IL-assisted hybrid filler dispersion in PLA for developing biodegradable materials with multifunctional applications as charge storage capacitors and microwave absorbing materials for sustainable electronics. Full article

This study examines the effects of temperature, relative humidity, moisture content, and density on the dielectric constant (ε′) and dielectric loss tangent (tan δ) of oak wood lamellae within a frequency range of 0.079 MHz to 25.1 MHz. The hypothesis tested was that increased temperature and moisture content enhance both dielectric polarization and loss, while density acts as a dominant structural determinant of dielectric behaviour. Oak lamellas were conditioned above saturated salt solutions at 20 °C and measured using an Agilent 4285A LCR meter according to ASTM D150-22. Multiple linear regression was used to demonstrate the statistically significant influence of temperature, relative humidity, moisture content, and density on the tested electrical properties of the lamellas. The results showed that the dielectric properties increase with higher sample density and higher air humidity. Temperature also had an influence, but it was significantly smaller, though still statistically significant (p < 0.05). Changes in dielectric properties were most pronounced at frequencies below 1 MHz, suggesting that dipolar and interfacial polarization are greater at lower frequencies. The findings in this paper provide a basis for optimizing the high frequency/dielectric heating process for heating before bending of oak and other similar hardwoods. Full article
