Tunneling modes in all-dielectric one-dimensional photonic crystals can be utilized for multi-channel filtering. However, these tunneling modes generally blue shift upon increasing the incident angle. When hyperbolic metamaterials are introduced into one-dimensional photonic crystals, the competition between the propagation phase shifts in the dielectric materials and hyperbolic metamaterials can result in different angle dependencies, including blue shift, abnormal zero shift, and abnormal red shift. When the reduction in the propagation phase in the dielectric layer exceeds the increment in the propagation phase in the hyperbolic metamaterial, the tunneling modes are blue-shifted; conversely, when the phase increment in the hyperbolic metamaterial exceeds the phase reduction in the dielectric layer, the tunneling modes are abnormally red-shifted. When the phase changes in the two materials are the same, the tunneling modes are angle independent. In this study, we investigated the multiple filtering effects of one-dimensional photonic structures composed of hyperbolic metamaterials. These composed structures exhibited multiple tunneling modes based on one-, two-, or three-angle dependencies and can be applied in novel optical devices with different angle-dependence requirements. Full article

This paper presents the development and analysis of a planar microfluidic microwave sensor featuring three circular complementary split-ring resonators (CSRRs) fabricated on an RO3035 substrate. The sensor demonstrates enhanced sensitivity in characterizing liquids contained in a fine glass capillary tube by leveraging a novel configuration: a central 5-split-ring CSRR with a drilled hole to suspend the capillary, flanked by two 2-split-ring CSRRs to improve the band-stop filtering effect. The sensor’s performance is benchmarked against another CSRR-based microwave sensor with a similar configuration. High linearity is observed (R² > 0.99), confirming its capability for precise ethanol concentration prediction. Compared to the replicated square CSRR design from the literature, the proposed sensor achieves a 35.22% improvement in sensitivity, with a frequency shift sensitivity of 567.41 kHz/% ethanol concentration versus 419.62 kHz/% for the reference sensor. The enhanced sensitivity is attributed to several key design strategies: increasing the intrinsic capacitance by enlarging the effective area and radial slot width to amplify edge capacitive effects, adding more split rings to intensify the resonance dip, placing additional CSRRs to improve energy extraction at resonance, and adopting circular CSRRs for superior electric field confinement. Additionally, the proposed design operates at a lower resonant frequency (2.234 GHz), which not only reduces dielectric and radiation losses but also enables the use of more cost-effective and power-efficient RF components. This advantage makes the sensor highly suitable for integration into portable and standalone sensing platforms. Full article

Microwave dielectric ceramics are indispensable in modern communication technologies, playing a pivotal role in components such as filters, oscillators, and antennas. Among these materials, ZnAl₂O₄ ceramics have garnered attention for their excellent quality factor (Q × f) and low dielectric constant (ε_r). However, their high sintering temperature (~1650 °C) limits practical applications. This study investigates ZnAl_2-x(Zn_0.5Si_0.5)_xO₄ (ZAZS) (x = 0.1–0.9) ceramics, where [Zn_0.5Si_0.5]³⁺ substitutes Al³⁺, to reduce sintering temperature while maintaining high-performance microwave dielectric properties. ZAZS ceramics were synthesized via the solid-state reaction method and characterized for their structural, morphological, and dielectric properties. X-ray diffraction analysis confirmed the formation of a single-phase solid solution up to x = 0.8, with minor secondary phases appearing at x = 0.9. The substitution increased lattice parameters and enhanced material densification, as observed through SEM and relative density calculations. Microwave dielectric measurements showed that ZAZS ceramics achieved a maximum Q × f of 20,200 GHz and a τ_f value reduced to −62 ppm/°C at x = 0.8, while ε_r decreased from 7.90 to 6.98. Bond-valence calculations reveal that the reduction of the average Al/Zn/Si–O bond valence weakens octahedral rigidity, systematically tuning τ_f toward zero. These results demonstrate that ZAZS ceramics, with a reduced sintering temperature of 1400 °C, exhibit excellent potential for application in low-loss microwave devices. Full article

This work presents a comprehensive technological study of dielectric resonator-based microstrip filters (DRMFs), encompassing the design, fabrication, and rigorous characterization of the $T{E}_{01\delta }$ mode. Through systematic coupling analysis, we demonstrate filters featuring novel input–output coupling techniques and innovative implementations of both transmission zeros (4-2-0 configuration) and equalization zeros (4-0-2 configuration), specifically designed for demanding space and radar receiver applications, while the loaded quality factor ($Q_L$) and insertion loss do not match those of dielectric resonator cavity filters (DRCFs), our solution significantly surpasses conventional microstrip filters (MFs), achieving $Q_L$> 3000 compared to typical $Q_L$≈ 200 for coupled-line MFs in X-band. The fabricated filters exhibit exceptional performance as follows: input reflection ($S_{11}$) below −18 dB (4-2-0) and −16.5 dB (4-0-2), flat transmission response ($S_{21}$), and out-of-band rejection exceeding −30 dB. Mechanical tuning enables precise control of input–output coupling, inter-resonator coupling, cross-coupling, and frequency synthesis, while equalization zeros provide tailored group delay characteristics. This study positions DRMFs as a viable intermediate technology for high-performance RF systems, bridging the gap between conventional solutions. Full article

This study presents the development of a discrete algorithm for interpreting ground-penetrating radar (GPR) data in vertically inhomogeneous media for the diagnostics of road structures. Experimental data were obtained using an OKO-2 GPR system, followed by primary radargram processing using the CartScan software. This included noise and interference filtering, as well as the initial estimation of the dielectric permittivity of detected layers. The resulting dataset was used to validate numerical algorithms for solving the forward and inverse problems of geolectrics. The proposed approach is based on minimizing a quadratic misfit functional between the calculated and observed values of the horizontal component of the electromagnetic field. The gradient of the functional required for optimization is obtained via the numerical solution of an adjoint problem. A discrete version of this problem was developed, which satisfies the properties of conservativeness and uniformity according to finite difference theory. The inverse problem reconstruction of dielectric permittivity is considered a non-destructive method for radargram interpretation. Assuming a piecewise-continuous medium structure eliminates the need for computing gradients at material interfaces. The proposed methodology enhances the accuracy and reliability of pavement condition assessment and holds practical value for road infrastructure monitoring. Full article

In this work, we propose and analyze a thermally tunable metasurface based on indium antimonide (InSb), designed to operate in the terahertz (THz) frequency range. The metasurface exhibits dual functionalities: single-band perfect absorption and efficient polarization conversion, enabled by the temperature-dependent permittivity of InSb. At approximately 280 K, InSb transitions into a metallic state, enabling the metasurface to achieve near-unity absorptance (100%) at 0.408 THz under normal incidence, independent of polarization. Conversely, when InSb behaves as a dielectric at 200 K, the metasurface operates as an efficient polarization converter. By exploiting structural anisotropy, it achieves a polarization conversion ratio exceeding 85% over the frequency range from 0.56 to 0.93 THz, while maintaining stable performance for incident angles up to 45°. Parametric analyses show that the resonance frequency and absorption intensity can be effectively tuned by varying the InSb square size and the silica (SiO₂) layer thickness, achieving maximum absorptance at a SiO₂ thickness of 16 μm. The proposed tunable metasurface offers significant potential for applications in THz sensing, imaging, filtering, and wavefront engineering. Full article

Low-dielectric polyimides (PIs) have emerged as essential materials for next-generation microelectronics and communication technologies, yet traditional experimental and theoretical calculation methods for acquiring dielectric constant data face challenges in cost, accuracy, and scalability. This study presents a machine learning (ML) framework that combines polymer domain knowledge with advanced data-driven modeling techniques for accurate prediction of PI dielectric constants at 1 kHz. A dataset of 439 PIs was constructed, and 208 molecular descriptors were derived from SMILES-encoded structures. Through rigorous feature engineering—variance filtering, correlation analysis, and recursive feature elimination—10 key descriptors were identified, capturing electronic and polar interaction, surface area, and structural complexity. Five ML algorithms were evaluated, with Gaussian Process Regression (GPR) achieving superior predictive accuracy (test set: R² = 0.90, RMSE = 0.10). Shapley additive explanations (SHAP) analysis quantifies the contribution of molecular descriptors to PI dielectric constants. By means of SHAP values, it discloses the positive or negative impacts of descriptors on the predictions. Three novel PIs were synthesized for experimental validation, showing strong agreement between predicted and measured dielectric constants (mean percentage deviation: 2.24%). The model demonstrates robust predictions for other structurally similar polymers but reveals a 40% accuracy reduction (R² = 0.60) in 10 GHz cross-frequency predictions, emphasizing the requirement for multi-frequency training datasets to enhance model generalizability. This work advances the research paradigm of polymer dielectric materials and provides a pathway for the rational design of materials guided by machine learning. Full article

In this paper, a capacitively coupled-fed reconfigurable wideband bandpass filter (BPF) is proposed based on liquid crystal (LC) technology, which achieved three transmission poles across varying bias voltages (V_B). An open-ended stepped impedance resonator configuration enables multi-mode resonance, offering significantly wider bandwidth compared to uniform-impedance resonators. The fractional bandwidth (FBW) and transmission pole positions are determined by the impedance ratio of the two resonators, allowing the filter to meet specific design requirements. An analytical methodology employing multilayer transmission line formulations and resonant frequency ratios was used to predict the modal stability of transmission poles under dielectric constant variation, which was subsequently validated through simulation. Experimental results show that the center frequency can be adjusted from 10.76 to 9.47 GHz with a maximum V_B of 30 V, achieving a tuning range of 12.71%. The normalized 3 dB FBW exceeds 64.66%, and the return loss remains above 10 dB from 0 to 30 V, offering the widest FBW among the reported LC BPFs without pole merging or mode collapse. The frequency response of the fabricated filter shows good agreement with the simulation results. Full article

In this paper, we propose a multi-mode switchable ultra-wideband terahertz absorber based on patterned graphene and VO₂ by designing a graphene pattern composed of a large rectangle rotated 45° in the center and four identical small rectangles in the periphery, as well as a VO₂ layer pattern composed of four identical rectangular boxes and small rectangles embedded in the dielectric layer. VO₂ can regulate conductivity via temperature, the Fermi level of graphene depends on the external voltage, and the graphene layer and VO₂ layer produce resonance responses at different frequencies, resulting in high absorption. The proposed absorption microdevices have three modes: Mode 1 (2.52–4.52 THz), Mode 2 (3.91–9.66 THz), and Mode 3 (2.14–10 THz), which are low-band absorption, high-band absorption, and ultra-wideband absorption. At 2.96 THz in Mode 1, the absorption rate reaches 99.98%; at 8.04 THz in Mode 2, the absorption rate reaches 99.76%; at 5.04 THz in Mode 3, the absorption rate reaches 99.85%; and at 8.4 THz, the absorption rate reaches 99.76%. We explain the absorption mechanism by analyzing the electric field distribution and local plasma resonance, and reveal the high-performance absorption mechanism by using the relative impedance theory. In addition, absorption microdevices have the advantages of polarization insensitivity, incident angle insensitivity, multi-mode switching, ultra-wideband absorption, large manufacturing tolerance, etc., and have potential research and application value in electromagnetic stealth devices, filters and optical switches. Full article

In this study, a novel improved ultra-wideband (UWB) antipodal Vivaldi antenna suitable for breast cancer detection via microwave imaging was designed. The antenna was made more directional by adding three pairs of nestings to the antenna fins by adding elliptical patches. The frequency operating range of the proposed antenna is UWB 3.6–13 GHz, its directivity is 11 dB, and its gain is 9.27 dB. The antenna is designed with FR4 dielectric material and dimensions of 34.6 mm × 33 mm × 1.6 mm. It was demonstrated that the bandwidth, gain, and directivity of the proposed antenna meet the requirements for UWB radar applications. The Vivaldi antenna was tested on an imaging system developed using the CST Microwave Studio (CST MWS) program. In CST MWS, a hemispherical heterogeneous breast model with a radius of 50 mm was created and a spherical tumor with a diameter of 0.9 mm was placed inside. A Gaussian pulse was sent through Vivaldi antennas and the scattered signals were collected. Then, adaptive Wiener filter and image formation algorithm delay-multiply-sum (DMAS) steps were applied to the reflected signals. Using these steps, the tumor in the breast model was scanned at high resolution. In the simulation application, the tumor in the heterogeneous phantom was detected and imaged in the correct position. A monostatic radar-based system was implemented for scanning a breast phantom in the prone position in an experimental setting. For experimental measurements, homogeneous (fat and tumor) and heterogeneous (skin, fat, glandular, and tumor) breast phantoms were produced according to the electrical properties of the tissues. The phantoms were designed as hemispherical with a diameter of 100 mm. A spherical tumor tissue with a diameter of 16 mm was placed in the phantoms produced in the experimental environment. The dynamic range of the VNA device used allowed us to image a 16 mm diameter tumor in the experimental setting. The developed microwave imaging system shows that it is suitable for the early-stage detection of breast cancer by scanning the tumor in the correct location in breast phantoms. Full article

The gasification of cellulose typically requires high temperatures (>600 °C) due to the thermal stability of levoglucosan, a major intermediate formed during pyrolysis. In this study, we investigated the gasification behavior of cellulose by combining infrared (IR) heating with low-power dielectric barrier discharge (DBD) plasma treatment. Cellulose filter paper was first pyrolyzed using localized IR irradiation (2 kW for 30 s), generating mist-like volatile products including levoglucosan. These volatiles were then exposed to DBD plasma (16–64 W for 1 or 3 min) under Ar flow. Despite the relatively low estimated gas temperatures below 240 °C in the plasma region, gas yields, including H₂ and CO, increased markedly with discharge power, reaching up to 72.6 wt% at 64 W for 3 min—more than four times that obtained with IR heating alone. These results indicate that DBD plasma facilitates the gasification of pyrolysis volatiles under significantly lower temperature conditions than those required in conventional thermal gasification. This approach may offer a route toward low-temperature biomass gasification with reduced tar, coke, and clinker formation. Full article

In this study, the photonic band structure, transmissivity, and electric field distribution of a two-dimensional photonic crystal coupled waveguide structure are calculated using the supercell technique and finite element method. The waveguide consists of circular $KNb{O}_3$ and functional dielectric cylinders embedded in air. The dielectric constant of a functional medium cylinder is spatially dependent, which is realized through the electro-optic and Kerr effects. The dielectric constant function is defined as ${\epsilon }_c\left(r\right)=k·r+b$ ($0⩽r⩽r_c$), where the coefficient k and parameter b can be adjusted by an external electric field. By tuning k and b, the transmission characteristics of the waveguide, including the propagation direction and light field distribution, exhibit significant adjustability. Specifically, parameter b enhances or suppresses the transmissivity at output ports 1 and 2. By utilizing the regulatory capability of functional media on waveguide transmission characteristics, optical filters with specific filtering functions can be designed. These findings provide novel design strategies for advanced optical devices. Full article

We introduce a novel approach to achieve broadband rainbow trapping in a 2D photonic crystal (PC) platform. By exploiting the concept of valley PCs, we engineer a structure that supports robust topological edge states. A carefully designed rotational angle gradient along the edge state path induces frequency-dependent light localization, forming a topological rainbow with a significantly expanded bandwidth. This phenomenon of topological rainbow trapping is attributed to the interplay between valley-dependent topological edge states and the engineered rotational angle gradient. To further enhance light localization and broaden the trapping spectrum, we incorporate a graded radius profile in the bottom row of dielectric columns. Through a combination of rotational angle modulation and radius grading, we successfully realize broadband rainbow trapping with enhanced light localization. Our findings reveal a broad trapping bandwidth spanning from $0.8314c/a$ to $0.9205c/a$, showcasing the potential of this approach for applications in optical frequency filtering, sensing, and information processing. Full article

Ferroelectric thin films with a high dielectric tunability (η) have great potential in electrically tunable applications, including microwave tunable devices such as phase shifters, filters, delay lines, etc. Using a modified Landau–Devonshire type thermodynamic potential, we show that the dielectric tunability η of a (001) tetragonal ferroelectric film can be analytically solved. After a survey of materials, a large η value above 60% was predicted to be achievable in a (001)-oriented tetragonal Pb(Zr_0.52Ti_0.48)O₃ (PZT) film. Experimentally, (001)-oriented PZT thin films were prepared on LaNiO₃-coated (100) SrTiO₃ substrates by using pulsed laser deposition (PLD). These films exhibited good dielectric tunability (η ~ 67.6%) measured at a small electric field E of ~250 kV/cm (corresponding to 5 volts for a 200 nm thick film). It only dropped down to ~54.2% when E was further reduced to 125 kV/cm (2.5 volts for 200 nm film). The measured dielectric tunability η as functions of the applied electric field E and measuring frequency f are discussed for a 500 nm thick PZT film, with the former well described by the theoretical η(E) curves and the latter showing a weak frequency dependence. These observations validate our integrated approach rooted in a theoretical understanding. Full article

This paper presents a novel ultrathin frequency selective surface (FSS) bandpass filter with an extraordinary wideband tailored for operating within the S-C bands. The filter structure entails a double-layer FSS structure with mutually perpendicular unit cells etched on the top and bottom sides of a 0.003${\lambda }_L$ thick FR4 dielectric substrate, where ${\lambda }_L$ is the free space wavelength at the lowest operating frequency. Thus, both TE and TM polarizations can be covered, ensuring the polarization insensitivity of the structure. The two FSS layers are loaded with resistors to implement the harmonic suppression principle. The overall periodicity is extremely compact, measuring 0.16${\lambda }_L$× 0.16${\lambda }_L$. An equivalent circuit analysis was conducted to comprehensively evaluate the structure and provide design guidelines. Numerical simulations and experimental measurements demonstrated that the proposed filter achieved a −3 dB transmission band spanning from 2 to 6.76 GHz (fractional bandwidth equal to 108.7%) under normal incidence. Moreover, aside from excellent wideband performance, the filter showcased a flat bandpass and stable responses up to 40° of incidence angle. These remarkable capabilities position the proposed filter as a valuable asset in advancing the development of radomes and applications relevant to electromagnetic interference (EMI) shielding, promising significant contributions to the field. Full article
