Search Results (290)

Due to high specific energy absorption, composite/metal hybrid multi-cell thin-walled tubes hold significant potential in the field of automotive passive safety. However, the material coupling effect enhancing SEA often elevated the initial peak crushing force, reducing crushing force efficiency and compromising occupant protection. To balance SEA and CFE, trigger holes were introduced as an induced deformation mechanism for hybrid tubes to reduce IPCF while preserving SEA, with the optimized perforated configuration yielding higher CFE than the non-perforated counterpart. A high-fidelity finite element model of the hybrid tube was developed and experimentally validated, and the influences of induced structural parameters on SEA and CFE were investigated. Given the strong nonlinear coupling between trigger parameters and crashworthiness, a multilayer perceptron surrogate model was constructed using 200 optimal Latin hypercube sampling samples (20 for validation). A Q-learning enhanced particle swarm optimization (QL-PSO) algorithm was adopted for optimization, with reinforcement learning dynamically adjusting PSO parameters to balance global exploration and local exploitation. Finite element simulations validated that the proposed method achieved a favorable SEA-CFE trade-off, with SEA and CFE improved by 12.02% and 16.39% respectively, outperforming reported configurations. Compared with standard PSO, QL-PSO exhibited superior search efficiency and inverse mapping accuracy, with 22% higher optimization efficiency and full compliance with inverse design performance targets. This study provided valuable guidance for the design of thin-walled energy-absorbing structures in multi-material vehicle bodies. Full article

To address the progressive collapse of mountainous stilted RC frames induced by debris flows, this study establishes a three-dimensional refined solid model using ABAQUS. The alternate path method (element removal method) is employed to simulate the failure of ground-floor columns under impact, revealing the underlying damage evolution mechanism. The results indicate that the loss of an edge column compromises structural stability significantly more than that of a corner column. Sequential multi-column failure leads to a nonlinear accumulation of damage; specifically, the simultaneous failure of a ‘corner column and its adjacent edge column’ completely severs the outer load-transfer paths, triggering a drastic inward load redistribution. Furthermore, under extreme scenarios, the maximum structural displacement and nodal stress surge to 66.67 mm and 40 MPa, respectively, while the axial force of the core central column jumps by nearly 150% (reaching 2.67 × 10⁶ N). The crushing of internal central columns due to overloading is identified as the critical mechanism triggering global collapse. Based on these findings, design recommendations are proposed, emphasizing the reinforcement of upstream edge columns and the construction of a ‘component-joint-global’ hierarchical defense system. Full article

In response to the pressing issues of unclear adhesion mechanisms during the soil-removal process in peanut harvesting, poor soil fragmentation quality, and difficulties in separating the pods from the soil. Based on TRIZ theory, this study has innovatively designed a separation device that relies on external forces, such as kneading and squeezing. A mechanical model of soil fragmentation and separation was developed. The key factors affecting the device’s operational performance were identified. Through theoretical analysis and discrete element simulation, this study elucidates the working principle by which the device crushes and separates soil particles using kneading and squeezing forces. Through analysis of one-factor and orthogonal experiments, the optimal operating parameter combination for the device was determined to be: a drum installation clearance of 104.7 mm, a rotational speed difference of 75.2 rpm, and a pattern roughness of Grade III (reticulated). The system’s performance metrics are a soil removal rate of 96.59% and a pod damage rate of 2.48%. Field tests have confirmed that the deviation from simulation results is minimal. The device’s performance meets the requirements of actual production. Full article

Lightweight design and crashworthiness of protective structures are critical for battery safety in electric vehicles (EVs). This study addresses the limited research on cross-sectional shape design of high-strength steel double-cell roll-formed tubes (DCRFTs), widely used in EV bumper beams, battery boxes, and electric bus frames. A parametric design method is proposed based on three parameters: middle flange offset (o), upper deflection angle (α), and lower deflection angle (β). Under the constraints of constant cross-sectional height and enclosed area, this method systematically generates diverse shapes, including square, trapezoid, hexagon, re-entrant hexagon, and various hybrid shapes. Validated finite element models were employed to analyze the deformation modes and crashworthiness of DP980 steel DCRFTs under idealized lateral three-point bending with simple supports. The results indicated that the re-entrant hexagon section reduced maximum deformation (Disp) by 2.95%, peak crushing force (PCF) by 9.53%, and improved crushing force efficiency (CFE) by 13.88% compared to the baseline square section. The parametric study and sensitivity analysis confirmed that the offset (o) was the most critical parameter, contributing over 80% of the variance in Disp, PCF, and CFE. Multi-objective optimization using an RBF surrogate model and the NSGA-II algorithm yielded Pareto optimal solutions. Compared to the baseline, three representative solutions achieved Disp reductions of 11.83–25.10% and CFE improvements of 15.63–22.26%, each with distinct trade-offs among objectives. This work establishes a methodological framework for parametric cross-section design of roll-formed profiles; its extension to realistic boundary conditions will further facilitate practical EV protective structure design. Full article

Driven by the requirements of lightweight design and efficient impact protection, biomimetic hexagonal honeycomb structures have been widely used for energy absorption. However, their dynamic response and energy absorption behavior in underwater environments remain insufficiently understood. To address this gap, this study investigates the impact response and deformation mechanisms of aluminum honeycomb structures under fully submerged conditions relevant to marine engineering. We fabricated honeycomb cores from 5052-H18 aluminum alloy and developed a custom fixture for fluid–structure interaction tests under underwater drop hammer impact conditions. Using force sensors and high-speed photography, we characterized the dynamic impact behavior through load–time and velocity–time responses. Results demonstrate that drainage holes in the support plate serve a dual function: they enable the structure to maintain stable deformation and absorb energy underwater while also significantly enhancing energy absorption capacity. Specifically, the mean crushing force increases by 156.5%, and the energy absorption capacity increases by 333% compared to performance in air. This enhancement arises from the plastic deformation of cell walls and the additional energy dissipation induced by fluid–structure interaction. Overall, this study clarifies the dynamic compression behavior of aluminum honeycombs in underwater environments and demonstrates their potential for marine energy-absorption applications. Full article

To address the low operational efficiency and suboptimal crushing quality of conventional straw crushers, a serrated hammer blade was designed and optimized. The working mechanism of straw crushing and the force interaction between the hammer blade and straw were theoretically analyzed, and a finite element model was established to simulate straw fragmentation under impact. The crushing performances of serrated, rectangular, and stepped hammer blades were comparatively evaluated, and cutting force and cutting time were selected as key response indicators to investigate the effects of structural parameters. Using Latin hypercube sampling and a Kriging surrogate model, the relative importance of hammer blade parameters was quantified, followed by multi-objective optimization using the NSGA-II algorithm. The results indicate that the significance of the influencing factors follows the order of blade thickness, blade width, tooth spacing, and blade length. The optimal hammer blade configuration was determined as 4 mm in thickness, 39 mm in width, and 4 mm in tooth spacing. Crushing experiments demonstrate that, compared with the conventional rectangular hammer blade, the optimized serrated design increases productivity by 17.49% and improves the pass rate by 5.02%. This study provides practical parameter support and technical guidance for the low-cost upgrading and performance improvement of straw crushing equipment. Full article

Traditional lithium-ion battery recycling relies mainly on pyrolysis or chemical leaching to separate current collectors from electrode materials, inevitably resulting in secondary pollution. In contrast, eddy current separation (ECS) applied to crushed lithium-ion battery residues can substantially reduce the introduction of contaminants while minimizing material losses. However, the heterogeneous composition and diverse surface characteristics of crushed battery products, together with the conductivity degradation of electrode materials after long-term use, make conventional empirical particle–trajectory correlations inadequate for accurate optimization of ECS operating parameters. In addition, the coupling between process parameters and the resultant forces acting on conductive particles, as well as the associated separation trajectories, remain insufficiently understood, which severely limits process controllability. A force–trajectory model was therefore developed for spent current collectors and conductivity-degraded LiFePO₄ to describe their particle dynamics in an alternating magnetic field. The results demonstrate that the trajectory of LiFePO₄ is very similar to that of non-conductive materials, thereby facilitating its effective separation from metallic components in battery scrap. Eddy current separation experiments further confirm the accuracy of the model predictions with respect to separation trajectories and the influence of key process parameters. On this basis, optimization of the operating parameters increased the separation efficiency of the cathode material to above 95.1%. The clarified ECS mechanism for current collectors and electrode materials provides new insights into the mechanical pre-sorting and mechanistic understanding of lithium-ion battery fragments, thereby contributing to reductions in contaminant introduction during battery material recycling. Full article

Soft–hard composite strata are widely distributed in the surrounding rock of deep tunnels, which severely reduces TBM excavation efficiency. To elucidate the rock-breaking mechanism of TBM disc cutters in composite strata and to address unresolved issues related to cutter force evolution, a self-developed rotary cutting test platform was employed, and three types of large-scale samples (red sandstone, granite, and red sandstone–granite composites) were prepared, on which systematic rotary rock-cutting experiments were conducted under varying confining pressures, rotational speeds, and penetration depths. The results indicate that rock failure in composite strata exhibits pronounced heterogeneity, with significant stress concentration occurring at soft–hard rock interfaces, leading to abrupt increases in normal force and torque. Penetration depth is the most sensitive factor influencing cutting force and specific energy, followed by confining pressure and rotational speed. The minimum specific energy and maximum rock-breaking efficiency are achieved at a penetration depth of 2.5 mm, a confining pressure of 7 MPa, and a rotational speed of 2.5–3 r/min. Furthermore, a dynamic model describing the evolution of disc cutter normal force and torque at soft–hard rock interfaces was derived based on the CSM theoretical framework, and its validity was verified using the experimental results. Integrating experimental observations with theoretical analysis reveals that rock fragmentation in composite strata is dominated by radial tensile cracking in hard rock and shear-dominated crushing in soft rock, while strong stress perturbations and coupled failure occur at the composite interface. This study clarifies the force evolution and fracture mechanisms of disc cutters operating in composite strata and establishes a reliable dynamic prediction model for cutter loads, providing theoretical support and engineering guidance for TBM parameter optimization and cutterhead design. Full article

This study presents a hybrid experimental–numerical methodology for the preliminary design and optimization of a CFRP crash box intended for high-performance automotive applications. An initial experimental campaign was conducted on frustum-shaped crash boxes manufactured by Pagani Automobili S.p.A., comparing constant and variable thickness configurations through drop tower impact tests to evaluate energy absorption, crushing stability, and failure mechanisms. A lightweight finite element model was developed in Abaqus/Explicit using shell elements and Hashin-based damage criteria, achieving calibration errors below 10% for most parameters and under 15% for peak forces. Geometric enhancements, including continuous flanges, removal of the top surface, and an internal cruciform reinforcement, significantly improved energy absorption (up to 110%) but introduced trade-offs in stroke efficiency and mean force levels. To mitigate these effects, a genetic algorithm was employed to optimize laminate layup by varying ply orientations, resulting in improved stroke efficiency and reduced peak and average forces while maintaining crushing stability. The proposed approach demonstrates that integrating experimental validation with efficient numerical modeling and optimization accelerates the development of lightweight, high-performance crash absorbers, offering a robust framework for motorsport and automotive applications that balances safety, efficiency, and manufacturability. Full article

This study presents a novel bio-inspired multi-cell concave tube (BMCT) inspired by the biomimicry of horse tail grass plants. Following the simulation validation, a comprehensive investigation into the crashworthiness of this structure under axial impact was conducted. Concurrently, both experimental and theoretical analyses were employed to substantiate the reliability of the simulation data. Comparative results concerning crashworthiness indicate that, relative to other structures, the BMCT maintains a relatively constant initial peak force while simultaneously enhancing energy absorption capacity at equivalent mass. Specifically, when compared to corresponding hierarchical multi-cell tubes with the same number of cells, the BMCT exhibits a 41.04% increase in crush force efficiency (CFE) while preserving a relatively unchanged initial peak crushing force (IPCF). Additionally, variations in hierarchical levels yield a 21.22% increase in CFE at the same mass. Full article

Structural failure of the lead-carbon battery casing under external loads poses a serious threat to the safety of its energy storage function. To overcome the limitations of traditional protective casings regarding specific energy absorption (SEA) and crush force efficiency (CFE), this study proposes a novel thin-walled protective structure utilizing graded aperture honeycomb sandwich panels fabricated via additive manufacturing (AM). Finite element (FE) models were established using HyperMesh and validated against experimental data. Subsequently, the impact resistance and energy absorption characteristics of four distinct cellular topologies were systematically investigated under varying pore-size gradients, impact directions, and velocities. Experimental and numerical simulation results indicate that, among the investigated configurations, the triangular honeycomb structure exhibits superior impact resistance and energy absorption capability under both axial and lateral loading conditions. Furthermore, the synergistic enhancement mechanism based on topological configuration and gradient design effectively optimizes the progressive crushing mode, thereby reducing the initial peak crushing force transmitted to the battery and resulting in a pronounced advantage in impact performance. This research provides a novel design approach for optimizing next-generation high-performance, lightweight protection systems for energy storage devices. Full article

Vehicle crush boxes are one of the safety elements used in vehicles to minimize damage that may occur during an accident. The task of crush boxes is to absorb the energy which is generated during an accident. In this study, peak force, energy absorption and specific energy absorption values of cylindrical composite crush boxes, to which 0.25% and 0.50% graphene was added, were experimentally investigated with hydrothermal aging. The composite crush boxes were produced with vacuum infusion method. Glass, aramid and carbon fibers and their hybridizations were used as fibers. During hybridization, the winding order of the fibers was changed from inside to outside. The parameters for hydrothermal aging were selected as 500 h and 1000 h at 60 °C. The highest energy absorption value was obtained in the carbon fiber-reinforced sample CFRPG1H2 with 0.25% graphene-added epoxy resin matrix, aged for 1000 h. The lowest peak strength was observed in the aramid fiber-reinforced sample AFRPG2H2 with 0.50% graphene-added epoxy resin matrix, hydrothermally aged for 1000 h. It was observed that increasing the graphene addition rate reduced the negative effects on aging. It was determined that increasing the graphene ratio by 0.25% had an effect on aging. Full article

Energy-absorbing components should be effective and stable in engineering protective structure designs to reduce collision impacts. However, conventional energy-absorbing structures have considerable potential for optimization for energy dissipation and structural stability. Like other invertebrates, the centipede’s folding mode when moving forward is compatible with the hierarchical folding process when the energy-absorbing structure is impacted; however, this rule has not been thoroughly examined and proven. Based on this gap, this study built a unique biomimetic aluminum foam-filled bidirectional pyramid energy-absorbing structure, analyzed its geometric parameters on crashworthiness, and developed high-performance energy-absorbing components. Experiments and simulations were conducted on a bidirectional pyramid construction with three schemes for filling aluminum foam inspired by the centipede body section and profile. The construction with foam aluminum filling the gap has optimum specific energy absorption and load stability. Additionally, optimizing structural performance is most effective in certain ranges (78° ≤ θ ≤ 87°, t ≤ 0.1 mm, 34 mm ≤ d ≤ 44 mm). With Kriging and NSGA-III multi-objective optimization, the optimized peak crushing force decreases by 11.17% and specific energy absorption increases by 11.67%. The study and optimization process offers a theoretical reference for future high-performance energy-absorbing structures and has significant engineering application potential. Full article

Fiber-reinforced polymers (FRPs) are being increasingly used to replace rebars as reinforcements for concrete. This study evaluated the seismic behavior of concrete walls reinforced with grid-type carbon FRP (CFRP; carbon grid) through quasi-static cyclic tests and compared the results with that of the reinforced concrete (RC) wall. The experimental variables were the ratio of the carbon-grid anchorage length in the foundation to the wall length and the axial force ratio. Based on the results of the quasi-static cyclic tests, the ratio of the equivalent stiffness at the crushing of the compression-edge cover concrete to the initial stiffness of the carbon-grid-reinforced concrete specimens was 0.14 on average. This indicates that the specimens reached their maximum load due to the crushing of the compression-edge cover concrete after a significant reduction in stiffness due to cracking. The skeleton curve for the carbon-grid-reinforced concrete specimens was found to be bilinear, with reduced stiffness due to cracking and failure due to the crushing of the compression-edge cover concrete, making it definable and predictable. Additionally, in specimens with a high axial force or small ratio of the anchorage length in the foundation to the wall length, some of the longitudinal CFRP strands fractured at the same time as they reached the failure load. Moreover, the load at the crushing of the compression-edge cover concrete of the carbon-grid-reinforced concrete specimen increased by 1.10 times with the increase in the axial force ratio and decreased by 0.96 times with the decrease in the ratio of the anchorage length in the foundation to the wall length. It was found to be 0.73–0.80 times the flexural strength based on the assumption of plane sections remaining plane. In comparison with RC specimen, the cumulative absorbed energy of the carbon-grid-reinforced concrete specimen began to decrease after a story drift ratio of 1%, and the cumulative absorbed energy up to the target story drift ratio of 3.0% was found to be 0.60–0.62 times that of the RC specimen. Full article

High-speed train derailments can cause severe vehicle collisions with rail bridges and adjacent infrastructure; however, full-scale evidence for the collision response of trackside intrusion-protection walls and for material measures that limit concrete fragmentation remains scarce. This study addresses this safety-driven knowledge gap by reporting a full-scale collision test of a polyurea-coated reinforced concrete (RC) wall and by clarifying its governing response mechanisms and coating benefits. The inverted T-shaped RC wall was post-anchored to an existing deck and spray-coated with approximately 5 mm polyurea on the collision face and across the wall-footing junction. A 17.68 t container wagon was propelled to 34.59 km/h to reproduce the normal kinetic energy of a representative 68 t KTX car derailing at 300 km/h with a 3° collision angle. High-speed video tracking and post-test mapping captured displacements, rotations, and damage. The wall contained the container wagon without climb-over and without severe local crushing at the collision face; the response was dominated by stable wall-footing rocking, with a peak top displacement of 0.571 m, peak rotation of 19.9°, and residual inclination of approximately 15–17°. The peak collision-force estimate was approximately 1.17 MN, and most input energy (approximately 647–816 kJ) was dissipated through inelastic rocking and sliding while the anchors remained intact. The polyurea layer restrained spalling and fragment release and promoted a more global, repairable rocking-dominated damage state. These results provide rare full-scale benchmarks and mechanistic insight to support performance-based design and retrofit of derailment intrusion-protection walls for improved rail-bridge safety. Full article
