The miniaturization of dielectric sensing has driven the development of both oscillator- and receiver-based sensors. Wide-frequency-range and low-power-consumption voltage-controlled oscillators (VCOs) are required as a reference clock for receiver-based dielectric spectroscopy. In this paper, we propose a switched coupled inductor VCO offering sufficiently wide bandwidth in a power-efficient manner. The proposed switched coupled inductor offers higher coupling factor and mutual inductance compared to direct switched inductor schemes along with a higher quality factor and tuning range. The proposed switched coupled inductor improved the frequency tuning range by 21% compared to the conventional VCO. The measurement results show that the proposed VCO oscillates from 4.7 to 8.8 GHz frequency, suitable for dielectric spectroscopy sensors. With only 4.5 mW power consumption, the proposed VCO can achieve −103.3 dBc/Hz phase noise at 1 MHz offset, with a resulting tuning range figure-of-merit (FOMT) of −187.4 dBc/Hz. Full article

In this paper, the influences of leakage inductances are investigated for the integrated transformer of an input-series flyback converter, in which each input-series circuit is based on the single-switch flyback topology. First, the configuration of this converter is introduced, and a novel multiple-inductor coupling model is proposed for its flyback integrated transformer. Second, the operational process of this converter is analyzed by considering the leakage inductances between the primary and secondary windings of its integrated transformer. Third, the influences of these leakage inductances are analyzed; on this basis, the essential design considerations of the flyback integrated transformer are summarized. Finally, an experimental prototype of this input-series converter is built. Based on this, the analysis is verified by the experimental comparisons among three flyback integrated transformers with various winding layouts. Full article

In this work, a layout-level design methodology is presented for Low-Noise Amplifiers (LNAs), targeting a wide frequency spectrum from RF to millimeter-wave (mmWave) bands, and implemented using a 22 nmFDSOI CMOS process. A nested inductor structure is introduced at RF frequencies to reduce silicon footprint, with magnetic crosstalk effects characterized through electromagnetic (EM) simulations using Ansys^® RaptorX, Release 2024 R2, ANSYS, Inc. and integrated into the design process. Single-ended LNA architectures are employed for RF bands, while at mmWave frequencies, a differential topology is adopted to enhance linearity and enable simultaneous input and output impedance matching. An EM-based verification flow is applied across all designs to ensure RF/mmWave design flow compatibility, simulation accuracy, and enhanced performance. The proposed designs are evaluated using key metrics including input/output matching, reverse isolation, forward gain, noise figure, linearity ($I{P}_1,I{P}_3$), stability factor, power consumption, and total chip area to quantify the efficiency of the proposed methodology. The simulation results demonstrate that nested inductors are highly effective for area reduction in RF LNAs, while differential topologies are more suitable for mmWave designs, providing a unified framework for area-efficient and high performance LNA implementation. Full article

Power converters are essential for solar energy systems but achieving over 96% efficiency at 1 kW and 300 kHz with compact magnetic and EMC compliance remains challenging for high-power-density PV applications. This study presents the design, modeling, and experimental validation of a 1 kW two-phase interleaved boost converter operating from 12 V input to 48 V/20 A output, featuring a single EE32 Litz-wound coupled-core inductor with coupling coefficient k = −0.475 that reduces per-phase current ripple to just 120 mA (0.6% relative) at full load, a load-selective active zero-current switching (ZCS) circuit activated above 5 A threshold via DCR sensing to minimize switching losses without light-load penalties, and digital peak-current control with 2P2Z compensator implemented on an XMC4200 microcontroller, ensuring robust stability. Experimental results demonstrate peak efficiency of 98.6% at approximately 190 W load, full-load efficiency of approximately 96% with total losses limited to 40 W dominated by conduction rather than switching, thermal rise below 80 °C on key components, voltage regulation with less than 1% deviation down to 2 A minimum load, and full compliance with electromagnetic compatibility standards, including EN 55014-1/2 and EN 61000-4-2 ESD testing. The novel integration of selective ZCS, single-core magnetic, and high-frequency operation outperforms prior interleaved boost converters, which typically achieve 94–97% peak efficiency at lower switching frequencies of 20–100 kHz using multiple inductors or complex always-active resonant networks, making this solution particularly suitable for compact photovoltaic micro-converters, electric vehicles, and industrial power supplies requiring high efficiency, reliability, and regulatory compliance. Full article

Against the backdrop of rapid advances in computing, industry, and electric vehicles, DC–DC buck converters—as core point-of-load regulators—are critical for power supplies in applications with stringent voltage-stability requirements. This paper proposes a two-phase interleaved Buck converter based on positively coupled inductor with a high coupling coefficient. The innovation lies in the positively coupled inductor and two-phase interleaved architecture, where two MOSFETs and two diodes form a similar symmetrical full-bridge interleaved structures together achieve a higher conversion ratio and provide $ZCS$ operation for all power devices, thereby effectively reducing switching losses. Relative to traditional topologies, the proposed converter delivers a higher conversion ratio without extreme duty-cycle operation while improving reliability. After detailing the operating mechanism, we derive the input–output voltage relation, outline controller synthesis guidelines, and specify the soft-switching conditions. From the viewpoint of symmetry, the proposed interleaved converter exploits the electrical and magnetic symmetry between phases to achieve current balancing, extended duty-cycle range and soft-switching. Validation is provided by both a $PSIM$ simulation model and a $270W$ hardware prototype using an $STM32F103ZET6$, which achieves 93.3% peak efficiency at a conversion ratio of 0.45, demonstrating the practicality and effectiveness of the approach. Full article

With the development of distributed electric propulsion aircraft, researching airborne high-efficiency, high-power-density, high-gain, high-dynamic and low-ripple, low-stress DC-DC that meets aviation standards is an urgent and profoundly challenging task (Research Background). We propose a new topology to implement related applications. The new topology consists of an interleaved switched-inductor unit for a high-gain, low-ripple, and high-dynamic response, and a switched-capacitor unit for secondary boosting and low voltage stress. This study first analyzes in depth the operating principle and electrical characteristics of the proposed topology in different modes, showing that the proposed topology can achieve an extremely high voltage gain while maintaining low voltage stress. Moreover, the proposed topology employs interleaved inverse coupled inductors to eliminate right-half-plane zero (RHPZ). We establish a universal design guideline for coupled inductors by deriving the equivalent inductance equations, and we implement an ultra-lightweight switched-coupled inductor using planar thin-film integrated magnetic technology. We conduct small-signal modeling to verify the loop characteristics and stability of the proposed converter. Finally, the correctness of the theoretical analysis and the advantages of the proposed converter were verified through a 5000 W experimental prototype and comprehensive comparative experiments. Full article

This paper presents a high-voltage step-up DC-DC converter with an active flexible loop based on the Boost topology. By combining interleaved technology, magnetic integration technology, and voltage doubling capacitor technology, the voltage step-up of the converter is improved, and the duty range of the converter is extended by introducing an active flexible circuit composed of MOSFETs, diodes, and resistors. In addition, a coordinated control strategy of “open loop flexible compensation—closed loop linear compensation” is proposed, which effectively limits the starting inrush current of the converter and improves the dynamic performance. In this paper, the steady-state model of the converter in different duty ranges and the control idea of the coordinated control strategy are analyzed in detail, and a test prototype with a maximum output power of 100 W is built. In the hardware experiment, the steady state of the proposed converter working in different duty ranges and the dynamic start of the converter are tested, which proves the effectiveness of the proposed controller and control strategy. Full article

Multiphase buck converters are critical in data centers and base stations, where their efficiency and thermal performance dictate system reliability. Conventional current-sharing methods fail to equalize power losses under component mismatches, causing localized overheating and efficiency degradation. This paper introduces a dynamic current balancing strategy based on active power loss sharing. A coupled current–temperature–resistance model is developed to dynamically estimate the equivalent resistance of each phase, capturing the behavior of MOSFETs, inductors, and PCB traces. This model enables real-time, loss-based current weight adjustment to actively balance interphase losses. Experimental results demonstrate that the proposed approach improves peak efficiency by up to 3–8.6% and reduces the critical component temperature rise by 11.6 °C under typical loads, confirming its substantial value in enhancing the performance of multiphase power systems. Full article

In order to reduce magnetic components for a current-fed dual active bridge converter, this paper proposes a dual coupled-inductor (DCI) structure, which integrates two DC inductors, one high-frequency transformer, and one leakage inductor into two EE cores. By analyzing the principle of the magnetic components, a derivation process is presented to modify the current-fed dual active bridge converter. To simplify the design and enhance efficiency, an equal air gap length optimization method is proposed. And the geometric parameters with the highest efficiency are optimized based on losses. Finally, the feasibility and effectiveness of the above design were verified through a 1 kW test prototype. Full article

This work introduces a non-isolated high step-up dc-dc interleaved boost converter combining magnetic coupling and voltage multiplier cells (VMCs). The proposed topology features a transformer with two primary windings of equal turns, interconnected to each other, enabling improved current sharing, and multiple secondary windings that contribute to extending the voltage gain. A three-winding coupled inductor is integrated into the design, while VMCs not only boost the output voltage but also significantly reduce the voltage stresses on the switches, eliminating the need for extreme duty ratios. The converter exhibits inherent modularity, allowing for voltage gain adjustments either through the turns ratio of the coupled inductor or by incorporating additional VMCs. An in-depth analysis of the topology is derived, and an experimental prototype rated at 48 V/400 V, 25 kHz, and 1 kW is implemented to verify and validate the theoretical claims, achieving an efficiency of 95.12% at full-load conditions. Full article

Current ringing in dual-active bridge (DAB) converters significantly degrades efficiency and reliability, particularly due to resonant interactions in the magnetic tank impedance network. We propose a novel impedance resonant channel shaping technique to suppress the ringing by systematically modifying the converter’s equivalent impedance model. The method begins with establishing a high-fidelity network representation of the magnetic tank, incorporating transformer parasitics, external inductors, and distributed capacitances, where secondary-side components are referred to the primary via the turns ratio squared. Critical damping is achieved through a rank-one modification of the coupling denominator, which is analytically normalized to a second-order form with explicit expressions for resonant frequency and damping ratio. The optimal series–RC damping network parameters are derived as functions of leakage inductance and winding capacitance, enabling precise control over the effective damping factor while accounting for core loss effects. Furthermore, the integrated network with the damping network dynamically shapes the impedance response, thereby attenuating ringing currents without compromising converter dynamics. Experimental validation confirms that the proposed approach reduces peak ringing amplitude by over 60% compared to the conventional snubber-based methods, while maintaining full soft-switching capability. Full article

Implantable medical devices present several technological challenges, one of the most critical being how to provide power supply and communication capabilities to a device hermetically sealed within the body. Using a battery as a power source represents a potential harm for the individual’s health because of possible toxic chemical release or overheating, and it requires periodic surgery for replacement. This paper proposes a batteryless implantable device powered by an inductive link and equipped with bidirectional wireless communication channels. The device, designed in a 180 nm CMOS process, is based on two different pairs of mutually coupled inductors that provide, respectively, power and a low-bitrate bidirectional communication link and a separate, high-bitrate, one-directional upstream connection. The main link is based on a 13.56 MHz carrier and allows power transmission and a half-duplex two-way communication at 106 kbps (downlink) and 30 kbps (uplink). The secondary link is based on a 27 MHz carrier, which provides one-way communication at 2.25 Mbps only in uplink. The low-bitrate links are needed to send commands and monitor the implanted system, while the high-bitrate link is required to receive a continuous stream of information from the implanted sensing devices. The microchip acts as a hub for power and data wireless transmission capable of managing up to four different neural recording and stimulation front ends, making the device employable in a complex, distributed, bidirectional neural prosthetic system. Full article

Hybrid electric vehicles (HEVs) have gained significant attention for their superior energy efficiency and are becoming a predominant mode of urban transportation. The DC/DC converter plays a critical role in HEV energy management systems, especially in matching the voltage levels between the battery and DC bus. This paper proposes a novel high-gain DC/DC converter with a wide input voltage range based on coupled inductors. The innovation lies in the integration of a resonant cavity and the simultaneous realization of zero-voltage switching (ZVS) and zero-current switching (ZCS), effectively reducing both voltage/current stresses on the power switches and switching losses. Compared with conventional topologies, the proposed design achieves higher voltage gain without extreme duty cycles, improved conversion efficiency, and enhanced reliability. Detailed operating principles are analyzed, and design conditions for voltage stress reduction, gain extension, and soft switching are derived. The simulation model has been conducted in a PSIM environment, and a 300 W experimental prototype, implemented using a dsPIC33FJ64GS606 digital controller, has been established and demonstrates 93% peak efficiency at a 10 times voltage gain. The performance and practical feasibility of the proposed topology have been evaluated by both simulation and experiments. Full article

This paper focuses on the development of a high-conversion-efficiency DC/DC boost converter, which features high-voltage boost ratio conversion and employs soft-switching technology to reduce conversion losses. In the proposed design, the conventional energy storage inductor used in traditional boost converters is replaced with a coupled inductor, and an additional boost circuit is introduced. This configuration allows the converter to achieve a higher voltage conversion ratio under the same duty cycle, thereby enhancing the voltage gain of the converter. Additionally, a resonance branch is incorporated into the converter, and by applying a simple switching signal control, zero-voltage switching (ZVS) of the main switch is realized. To decrease the switching losses typically found in hard-switching high-voltage boost ratio converters, the proposed design enhances overall power conversion efficiency. The operation principle of this novel high-voltage boost ratio soft-switching converter is first examined, followed by the component design process. The converter’s effectiveness is then confirmed through simulation in PSIM. Finally, experimental testing using the TMS320F2809 digital signal processor demonstrates that the main switch achieves ZVS, validating the practical viability of the design. The converter operates under a full load of 340 W, achieving a conversion efficiency of 92.7%, demonstrating the excellent conversion performance of the developed converter. Full article

This paper investigates and characterizes a tunable inductor structure based on coupled-line configurations, referred to as a coupled-line tunable inductor (CLTI). By integrating switches along the coupled-line paths, the mutual inductance can be selectively enabled or disabled, providing a means for active inductance modulation. Spiral inductors with one-turn and two-turn cores were used in conjunction with inner-coupled-line placements to explore different coupling configurations. The test structures were implemented using printed circuit board (PCB) technology, and their performance was analyzed through electromagnetic simulations and vector network analyzer (VNA) measurements. The results confirm that switch-controlled coupled lines enable effective inductance tuning, with a measurable reduction in inductance when the coupled-line path is activated. In the switch-OFF state, only minimal performance degradation was observed due to parasitic effects. These findings provide useful insights into the practical behavior of coupled-line tunable inductors and suggest their applicability in RF circuits and adaptive analog systems, particularly where integration and compact tunability are desired. Full article
