Search Results (69)

Poly(9,9-di-n-octylfluorene) (PFO) suffers from interchain aggregation, which degrades its blue spectral stability and charge transport. To address this, a series of rod-coil diblock copolymers (PFO-b-PMMAs) with varying poly(methyl methacrylate) (PMMA) chain lengths were synthesized via Steglich coupling. The non-conjugated PMMA blocks act as bulky steric spacers in the solid state, effectively suppressing detrimental PFO aggregation and enhancing pure blue emission stability. Furthermore, moderate PMMA blocks (PFO-b-PMMA1 and PFO-b-PMMA2) promote favorable β-phase formation and ordered crystalline packing. This microstructural optimization yields a maximum electron mobility of 1.98 × 10⁻⁶ cm²/(V·s) for PFO-b-PMMA2, markedly higher than the PFO-2 homopolymer (4.13 × 10⁻⁷ cm²/(V·s)). However, an overlong PMMA block (PFO-b-PMMA3) introduces excessive steric hindrance (T_g = 66 °C) that disrupts crystallization, acting as an insulating barrier that reduces mobility. Thus, precisely tuning the non-conjugated block length effectively maximizes both the blue spectral stability and electron transport capabilities of PFO-based materials. Full article

Electrochemical discharge machining (ECDM) with low machining reaction forces is useful for machining hard and brittle materials, which are required in precision equipment. Lathe-type ECD machines have been proposed to machine axisymmetric shapes while reducing cracks caused by thermal expansion, and they are suitable for thin workpiece machining due to the small reaction force. This paper demonstrates the micromachining of non-circular cross-sections using a lathe-type ECD machine equipped with an improved force-controlled tool electrode holder. The tool electrode holder combining a voice coil motor (VCM) with leaf springs arranged in parallel was built. This holder achieves both flexibility in the longitudinal direction of the tool electrode and high rigidity in the lateral direction. The relationship between the VCM current, tool electrode shift within the tool electrode holder, and thrust force was approximated using a polynomial. Consequently, this device allows for the stable, small contact force required in micromachining. An on-machine shape measurement method was also carried out by combining the tool electrode shift with the motion of an XZ stage. As a demonstration for non-circular cross-section machining, a square cross-section was grooved from a cylindrical glass rod. The removal and measurement processes were alternately repeated to achieve precision. During ECDM, the on/off of the DC power supply for ECDM was synchronized with the rotation of the workpiece. The measurement results indicated some dimensional errors, including bulging at the middle of sides and excessive removal at corners. The bulging was mainly caused by drift due to thermal expansion of the stage, as well as tool electrode wear. Since the tool electrode comes into close proximity to with the machined surface, the discharge from the side surface of the tool electrode caused excessive removal at the corners. Full article

Currently, only a limited number of Mark–Houwink–Sakurada (MHS) equations are available for chitin, and their applicability is constrained by the narrow range of suitable solvent systems. The Mark–Houwink–Sakurada (MHS) equation is a widely used and practical approach for estimating polymer molecular weight from intrinsic viscosity measurements, particularly when chromatographic techniques are not readily accessible. This study aimed to establish new MHS equations for chitin to facilitate reliable molecular weight determination across different solvents and temperatures. Chitin samples with varying molecular weights were prepared via H₂O₂ degradation, and their weight-average molecular weights (Mw) were determined by high-performance size-exclusion chromatography (HPSEC). Intrinsic viscosity ([η]) was measured using a capillary viscometer at 25 and 30 °C in three solvent systems: 5% LiCl/N,N-dimethylacetamide (LiCl/DMAc), 8% NaOH/4% urea, and 10% NaOH/0.3% tannic acid (w/w). Double-logarithmic plots of Mw versus [η] were constructed to derive the corresponding MHS equations. At identical molecular weights and temperatures, intrinsic viscosity followed the order: LiCl/DMAc > NaOH/urea > NaOH/tannic acid. Increasing temperature led to higher intrinsic viscosity and conformation parameter (a) values. Chitin dissolved in LiCl/DMAc and NaOH/urea exhibited rod-like conformations, with a values ranging from 0.79 to 0.97, whereas chitin in NaOH/tannic acid displayed random coil behavior (a = 0.56–0.69). These established MHS equations expand the solvent applicability for chitin molecular weight determination and provide insights into its solution conformation under different chemical environments. Full article

This study reports on heat transfer augmentation by knitted wire coil turbulators in a fully developed turbulent regime. Four knitted wire coil turbulators with different wire loop number densities (N = 6, 8, 10, and 12 loops per pitch, with 1.0 pitch = 6.8 mm) were tested. Each was made by winding a 0.7 mm copper wire around a 1.0 mm core rod. Experiments were conducted under a constant 600 W/m² wall heat flux. The flow behaviors observed through a dye injection technique revealed that the wire coil induced secondary flows and developed shear layers, contributing to enhanced heat transfer. Heat transfer improved with increasing wire loop number density. Application of knitted wire coil turbulators increased the Nusselt number (Nu) by 86, 95.4, 103.2, and 109.3% for N = 6, 8, 10, and 12, respectively. This corresponded to increased friction factors (f) by 1.77, 1.97, 2.15, and 2.31 times, respectively. The tube with coils having N = 12 yielded the highest thermal performance index (TPI), 1.4, at a Reynolds number of 5000. The empirical correlations for Nu, f, and TPI showed deviations within ±2.1, ±0.68, and ±2.28%, respectively. Full article

The purpose of this work is to enable the giant magnetostrictive transducer to work efficiently. In this work, the finite element method was used to carry out a dynamic analysis and magnetic analysis of the transducers of GMM rods with different structures, and the transducers of three structural rods were developed, and the output amplitude and impedance of the three transducers were experimentally tested. The results show that the stress of the rod near the end of the tail mass was larger than that near the end of the head mass. The eddy current and hysteresis losses of the transducer were mainly concentrated on the outer diameter surface of the rod, near the cutting slit, and near the connection between the slices. In addition, there is a certain amount of eddy current loss on the magnetic conductor, permanent magnet, and coil. In the transducer with the untreated rod, the resistance and inductance were the smallest. The inductance of the transducers with the sliced rods were greater than those in the transducers with the slit rods. The transducer with the untreated rod has the highest resonant frequency and the smallest output amplitude, the resonant frequency of the transducers with the sliced rods was lower than that of the transducers with the slit rods, while the output amplitude of the transducers with the sliced rods was greater than that of the transducers with the slit rods. The simulated values of the resonant frequency, output amplitude, resistance, and inductance of the transducers of the three structural rods were basically consistent with the tested values. Full article

This article considers a fluxgate magnetometer (FM) that operates based on a new physical principle. The authors analyze how the alternating electric charge potential of a cylindrical metal electrode impacts the structure of a cylindrical permanent magnet made of composite-conducting ferrite. They demonstrate that this impact and permanent magnet structure initiate the emergence of polarons with oscillating magnetism. This causes significant changes in the entropy of indirect exchange and the related sublattice magnetism fluctuations that ultimately result in the generation of circularly polarized spin waves at the spin wave resonance frequency that are channeled and evolve in dielectric ferrite waveguides of the FM. It is demonstrated that these moving spin waves have an electrodynamic impact on the measuring FM coils on the macro-level and perform parametric modulation of the magnetic permeability of the waveguide material. This results in the respective variations of the changeable magnetic field, which is also registered by the measuring FM coils. The authors considered a generalized flow of the physical processes in the FM to obtain a detailed representation of the operating functions of the FM. The presented experimental results for the proposed FM in the field meter mode confirm its operating parameters (±40 μT—measurement range, 0.5 nT—detection threshold). The usage of a cylindrical metal electrode as a source of exciting electrical change instead of a conventional multiturn excitation coil can significantly reduce temperature drift, simplify production technology, and reduce the unit weight and size. Full article

Niobium oxides are promising materials for catalytic applications due to their unique structural versatility and surface chemistry. Nb₂O₅ nanomaterials were synthesized via a solvothermal method at 150 °C using niobium oxalate as a precursor. A comprehensive characterization of the material was performed using electron microscopy, X-ray diffraction, and Raman spectroscopy. The as-prepared nanoparticles primarily crystallized in a mixture of the TT-Nb₂O₅ phase (TT from the German Tief-Tief, meaning “low-low”) and niobic acid, while subsequent thermal treatment at 900 and 1100 °C induced a phase transformation to T-Nb₂O₅ and H-Nb₂O₅, respectively (T from the German Tief, meaning “low”, and H from Hoch, meaning “high”). The as-prepared samples consist of micro-coils composed of interconnected nanometer-scale fibers, whereas the morphology changes into rods when they are treated at 1100 °C. The photocatalytic performance of the nanoparticles was evaluated by comparing the as-prepared and thermally treated samples. The as-prepared nanoparticles exhibited the highest photocatalytic activity under visible illumination, achieving 100% degradation after 180 min. More interestingly, the treatment of the as-prepared material with H₂O₂ modified the surface species formed on the Nb₂O₅, altering the photocatalytic behavior under various illumination conditions. This sample showed the highest photocatalytic activity under UV illumination, reaching 100% degradation after 75 min. On the other hand, the calcined samples are practically inactive, attributed to the loss of active catalytic sites during thermal treatment and phase transformation. Full article

This article develops a new inductive displacement sensor with a segmented multi-group coil structure, which is suitable for the displacement measurement of control rods in nuclear reactors. Each group coil of the sensor consists of two excitation coils and one sensing coil. The excitation and sensing coils are segmented to extend the linearity range of the displacement sensor. It abandons the traditional sensor’s method of using nonlinear compensation to achieve large-stroke displacement measurement. Providing an alternating current (AC) signal to the excitation coil and processing the induced voltage generated by each sensing coil can directly achieve the high-precision measurement of core displacement. The mathematical model of the variations in the sensing coil voltage caused by the movement of the core is established. The impacts of the excitation coil structure, the number of turns of the excitation coil, and the excitation frequency on the output characteristics of the designed sensor are analyzed by finite element simulation. Based on the analysis and design, a sensor prototype is built and tested in the laboratory. The measurement results show that the linearity error is 0.35% and the maximum measuring error can be limited within 1.5 mm, which is sufficient to meet the practical requirements in a nuclear reactor environment. Full article

Superconducting magnets’ coils need rods for suspension in vacuum dewars to minimize heat conduction. Previously, rod sets had to be custom-matched to specific magnet models, hindering interchangeability. However, designing or repairing magnets required new rod manufacturing, which was costly and time-consuming, especially with low-conductivity composite materials. In this study, a design of a multi-branch support structure with various adjustment functions is evaluated, which is applied to a customized MCZ superconducting magnet and tested for a long period. Those obtained results show that a new multi-branch rod design with adjustable functions developed for a custom MCZ magnet could effectively improve material strength utilization to 85.14% and reduce the cross-sectional area by 16.22%. Then, the heat leakage is cut significantly. The 50 K cold shield opening was also reduced by 5196 mm², lowering heat radiation by 45%. The assembly time period was shortened to 47 min. The innovation of this study proved that the novel pulling rod structure addresses the issues of traditional rods. Full article

The design and study of pulsed eddy current sensors for detecting surface defects in small-diameter rods are highly significant. Accurate detection and identification of surface defects in small-diameter rods may be attained by the ongoing optimization of sensor design and enhancement of detection technologies. This article presents the construction of a non-coaxial differential eddy current sensor (Tx-Rx sensor) and examines the detection of surface defects in a small diameter bar. A COMSOL 3D model is developed to examine the variations in eddy current distribution and defect signal characteristics between the plate and rod components. The position of the excitation coil on the bar and the eddy current disruption around the defect are examined. Additionally, a Tx-Rx sensor has been developed and enhanced concerning coil dimensions, coil separation, and elevation height. An experimental system is established to detect bar structures with surface defects of varying depths, and a model correlating differential signal attenuation with defect depth is proposed, achieving a quantitative relative error of less than 5%, thereby offering a reference for the quantitative detection of bar surface defects. Full article

To meet the in-orbit construction needs of super-large spacecraft for ultra-long rod structures, this paper proposes an innovative on-orbit roll forming method for polyetheretherketone (PEEK)-based rod stock. This method ingeniously integrates temperature gradient control into a continuous deformation surface cavity design to achieve an efficient forming of resin rod components. A parametric model of the forming die cavity was established based on the comprehensive bending and downhill methods, and the boundary conditions for the temperature distribution gradient within the cavity were determined. Through the simulation and analysis of the PEEK rod curling and stitching forming process, the influence of the cavity configuration parameters on the forming load was determined. By constructing a test platform for the roll forming characteristics of resin rod components, the effects of different forming methods, stitching temperatures, and feed rates on forming quality and load were verified, and the main factors affecting the width of the welding zone, the roundness of the rod, and the straightness of the weld were analyzed. Experimental results show that the proposed continuous roll forming scheme can achieve an efficient and continuous forming of resin rod structures. When the length of the member is processed to 300 mm, at a formed rod diameter of 20 mm, by employing a cavity deformation zone length of 210 mm, a cavity clearance of 0.1 mm, a sheet width of 61 mm, a feed rate of 1 mm/s, and a sealing zone temperature setting of 335 °C, optimal rod forming quality can be achieved, characterized by a straightness error of 0.0133 ± 0.005 mm and a roundness error of 0.19 ± 0.07 mm. The proposal of this scheme provides a reliable basis for the continuous manufacturing of rod structures in the on-orbit construction of large space structures in terms of both the scheme and the parameter selection. Full article

Conjugated polymers (CPs), in particular poly(p-phenylene vinylene)s (PPVs), are recognized as “smart” materials with potential applications ranging from optoelectronic devices to emergent technologies and to precision medicine. The present communication reports on the synthesis and structural characterization of new dibrominated macromonomers and their derived PPVs, of rod–graft–coil architecture, whose grafted, biocompatible and hydrophilic side chains are either PEG-2000 or poly(2-methyl-2-oxazoline) or poly(2-ethyl-2-oxazoline). The Suzuki–Heck cascade reaction was used for PPVs’ obtainment. After PPVs’ structural characterization using specific techniques (such as ¹H-NMR; GPC), the micellar, fluorescent nanoparticles formed by spontaneous self-assembling during simple direct dissolution in water were evaluated using dynamic light scattering for their size, complementarily combined with Atom Force Microscopy (AFM) for their shape assessing. The PPV micelles’ photophysical properties were revealed using UV-vis spectroscopy and fluorescence measurements. Full article

Electromagnetic tracking (EMT) can benefit image-guided interventions in cases where line of sight is unavailable. However, EMT can suffer from electromagnetic distortion in the presence of metal instruments. Metal instruments are widely used in laparoscopic surgery, ENT surgery, arthroscopy and many other clinical applications. In this work, we investigate the feasibility of tracking such metal instruments by placing the inductive sensor within the instrument shaft. We propose a magnetostatic model of the field within the instrument, and verify the results experimentally for frequencies from 6 kHz to 60 kHz. The impact of the instrument’s dimensions, conductivity and transmitting field frequency is quantified for ranges representative of typical metal instruments used in image-guided interventions. We then performed tracking using the open-source Anser EMT system and quantify the error caused by the presence of the rod as a function of the frequency of the eight emitting coils for the system. The work clearly demonstrates why smaller tool diameters (less than 8 mm) are less susceptible to distortion, as well as identifying optimal frequencies (1 kHz to 2 kHz) for transmitter design to minimise for distortion in larger instruments. Full article

This study introduces an integrated structural optimization design method based on a BP neural network and NSGA-II multi-objective genetic algorithm. Initially, a two-dimensional axisymmetric finite element model of the Giant Magnetostrictive Actuator (GMA) was established, and the coupling simulation of the electromagnetic field, structural field, and temperature field was conducted to obtain the GMA’s performance parameters. Subsequently, the structural parameters of the GMA magnetic circuit, including the magnetic conducting ring, magnetic conducting sidewall, magnetic conducting body, and coil, were used as inputs, and the axial magnetic induction intensity, uniformity of axial magnetic induction intensity, and coil loss on the Giant Magnetostrictive Material (GMM) rod were used as outputs to establish a back propagation (BP) neural network model. This model delineated the nonlinear relationship between structural parameters and performance parameters. Then, the BP-NSGA-II algorithm was applied to perform multi-objective optimization on the actuator’s structural parameters, resulting in a set of Pareto optimal non-dominated solutions, from which a set of optimal solutions was obtained using the entropy weight method. Finally, simulation analysis of this optimal solution was conducted, indicating that under a 5 A power supply excitation, the maximum axial magnetic induction intensity on the optimized GMM rod increased from 0.87 T to 1.12 T; the uniformity of axial magnetic induction intensity improved from 93.1% to 96.5%; and the coil loss decreased from 7.79 × 10⁴ W/m³ to 4.97 × 10⁴ W/m³. Based on the optimization results, a prototype actuator was produced, and the test results of the prototype’s output characteristics proved the feasibility of this optimization design method. Full article
