Search Results (23)

In this study, we propose a bidirectional chemical sensor platform based on a reconfigurable ion-sensitive field-effect transistor (R-ISFET) architecture. The device incorporates Ni-silicide Schottky barrier source/drain (S/D) contacts, enabling ambipolar conduction and bidirectional turn-on behavior for both p-type and n-type configurations. Channel polarity is dynamically controlled via the program gate (PG), while the control gate (CG) suppresses leakage current, enhancing operational stability and energy efficiency. A dual-control-gate (DCG) structure enhances capacitive coupling, enabling sensitivity beyond the Nernst limit without external amplification. The extended-gate (EG) architecture physically separates the transistor and sensing regions, improving durability and long-term reliability. Electrical characteristics were evaluated through transfer and output curves, and carrier transport mechanisms were analyzed using band diagrams. Sensor performance—including sensitivity, hysteresis, and drift—was assessed under various pH conditions and external noise up to 5 V_pp (i.e., peak-to-peak voltage). The n-type configuration exhibited high mobility and fast response, while the p-type configuration demonstrated excellent noise immunity and low drift. Both modes showed consistent sensitivity trends, confirming the feasibility of complementary sensing. These results indicate that the proposed R-ISFET sensor enables selective mode switching for high sensitivity and robust operation, offering strong potential for next-generation biosensing and chemical detection. Full article

Tungsten diselenide (${\mathrm{WSe}}_2$) has emerged as a promising ambipolar semiconductor material for field-effect transistors (FETs) due to its unique electronic properties, including a sizeable band gap, high carrier mobility, and remarkable on–off ratio. However, engineering the contacts to ${\mathrm{WSe}}_2$ remains an issue, and high contact barriers prevent the utilization of the full performance in electronic applications. Furthermore, it could be possible to tune the contacts to ${\mathrm{WSe}}_2$ for effective electron or hole injection and consequently pin the threshold voltage to either conduction or valence band. This would be the way to achieve complementary metal–oxide–semiconductor devices without doping of the channel material.This study investigates the behaviour of two-dimensional ${\mathrm{WSe}}_2$ field-effect transistors with multi-layer palladium diselenide (${\mathrm{PdSe}}_2$) as a contact material. We demonstrate that ${\mathrm{PdSe}}_2$ contacts favour hole injection while preserving the ambipolar nature of the channel material. This consequently yields high-performance p-type ${\mathrm{WSe}}_2$ devices with ${\mathrm{PdSe}}_2$ van der Waals contacts. Further, we explore the tunability of the contact interface by selective laser alteration of the ${\mathrm{WSe}}_2$ under the contacts, enabling pinning of the threshold voltage to the valence band of ${\mathrm{WSe}}_2$, yielding pure p-type operation of the devices. Full article

With the increase in electronic devices across various applications, there is rising demand for selective carrier control. The split-gate consists of a gate electrode divided into multiple parts, allowing for the independent biasing of electric fields within the device. This configuration enables the potential formation of both p- and n-channels by injecting holes and electrons owing to the presence of the two gate electrodes. Applying voltage to the split-gate allows for the control of the Fermi level and, consequently, the barrier height in the device. This facilitates band bending in unipolar transistors and allows ambipolar transistors to operate as if unipolar. Moreover, the split-gate serves as a revolutionary tool to modulate the contact resistance by controlling the barrier height. This approach enables the precise control of the device by biasing the partial electric field without limitations on materials, making it adaptable for various applications, as reported in various types of research. However, the gap length between gates can affect the injection of the electric field for the precise control of carriers. Hence, the design of the gap length is a critical element for the split-gate structure. The primary investigation in this review is the introduction of split-gate technology applied in various applications by using diverse materials, the methods for forming the split-gate in each device, and the operational mechanisms under applied voltage conditions. Full article

In this paper, a new SiGe/Si heterojunction double-gate heterogate dielectric tunneling field-effect transistor with an auxiliary tunneling barrier layer (HJ-HD-P-DGTFET) is proposed and investigated using TCAD tools. SiGe material has a smaller band gap than Si, so a heterojunction with SiGe(source)/Si(channel) can result in a smaller tunneling distance, which is very helpful in boosting the tunneling rate. The gate dielectric near the drain region consists of low-k SiO₂ to weaken the gate control of the channel-drain tunneling junction and reduce the ambipolar current (I_amb). In contrast, the gate dielectric near the source region consists of high-k HfO₂ to increase the on-state current (I_on) through the method of gate control. To further increase I_on, an n⁺-doped auxiliary tunneling barrier layer (pocket)is used to reduce the tunneling distance. Therefore, the proposed HJ-HD-P-DGTFET can obtain a higher on-state current and suppressed ambipolar effect. The simulation results show that a large I_on of 7.79 × 10⁻⁵ A/μm, a suppressed I_off of 8.16 × 10⁻¹⁸ A/μm, minimum subthreshold swing (SS_min) of 19 mV/dec, a cutoff frequency (f_T) of 19.95 GHz, and gain bandwidth product (GBW) of 2.07 GHz can be achieved. The data indicate that HJ-HD-P-DGTFET is a promising device for low-power-consumption radio frequency applications. Full article

We compare the pH sensing performance of non-functionalized carbon nanotubes (CNT) field-effect transistors (p-CNTFET) and CNTFET functionalized with a conjugated polyfluorene polymer (labeled FF-UR) bearing urea-based moieties (f-CNTFET). The devices are electrolyte-gated, PMMA-passivated, 5 µm-channel FETs with unsorted, inkjet-printed single-walled CNT. In phosphate (PBS) and borate (BBS) buffer solutions, the p-CNTFETs exhibit a p-type operation while f-CNTFETs exhibit p-type behavior in BBS and ambipolarity in PBS. The sensitivity to pH is evaluated by measuring the drain current at a gate and drain voltage of −0.8 V. In PBS, p-CNTFETs show a linear, reversible pH response between pH 3 and pH 9 with a sensitivity of 26 ± 2.2%/pH unit; while f-CNTFETs have a much stronger, reversible pH response (373%/pH unit), but only over the range of pH 7 to pH 9. In BBS, both p-CNTFET and f-CNTFET show a linear pH response between pH 5 and 9, with sensitivities of 56%/pH and 96%/pH, respectively. Analysis of the I–V curves as a function of pH suggests that the increased pH sensitivity of f-CNTFET is consistent with interactions of FF-UR with phosphate ions in PBS and boric acid in BBS, with the ratio and charge of the complexed species depending on pH. The complexation affects the efficiency of electrolyte gating and the surface charge around the CNT, both of which modify the I–V response of the CNTFET, leading to the observed current sensitivity as a function of pH. The performances of p-CNTFET in PBS are comparable to the best results in the literature, while the performances of the f-CNTFET far exceed the current state-of-the-art by a factor of four in BBS and more than 10 over a limited range of pH in BBS. This is the first time that a functionalization other than carboxylate moieties has significantly improved the state-of-the-art of pH sensing with CNTFET or CNT chemistors. On the other hand, this study also highlights the challenge of transferring this performance to a real water matrix, where many different species may compete for interactions with FF-UR. Full article

In this paper, we propose and investigate an electrically doped (ED) PNPN tunnel field effect transistor (FET), in which the drain side tunneling barrier width is effectively controlled to obtain a suppressed ambipolar current. We present that the proposed PNPN tunnel FETs can be realized without chemically doped junctions by applying the polarity bias concept to a doped N⁺/P⁻ starting structure. Using numerical device simulations, we demonstrate how the tunneling barrier width on the drain side can be influenced by several design parameters, such as the gap length between the channel and the drain (L_gap), the working function of the polarity gate, and the dielectric material of the spacer. The simulation results show that an ED PNPN tunneling FET with an ED drain, which has been explored for the first time, exhibits a low ambipolar current of 5.87 × 10⁻¹⁶ A/µm at a gap length of 20 nm. The ambipolar current is reduced by six orders of magnitude compared to that which occurs with a conventional ED PNPN tunnel FET with a uniformly doped drain, while the average subthreshold slope and the ON state and OFF state currents remained nearly identical. Full article

Ionospheric ion upflow is an important process for magnetosphere-ionosphere coupling via O⁺ source for the magnetosphere. This process occurs frequently in the subauroral polarization stream (SAPS) region where the SAPS-enhanced ion-neutral frictional heating tends to push ions upward because of enhanced upward pressure gradient force. However, the SAPS-induced neutral wind transport by ion-neutral friction may also play an important role in triggering ion upflow, which has been rarely studied. In this work, the thermosphere-ionosphere-electrodynamics general circulation model (TIEGCM) with/without an empirical SAPS model has been employed to investigate the impacts of SAPS on ion upflow in the topside ionosphere. Our results separate different transport processes in the ion continuity equation, showing that SAPS can accelerate upward ambipolar diffusion along its channel because of ion-neutral frictional heating, but SAPS-induced horizontal neutral wind may have a comparable or even larger contribution to vertical ion drift when SAPS are fully developed. In addition, the neutral wind can induce both upward and downward ion drift in the SAPS region, depending on the direction of the neutral wind and the local geomagnetic declination and inclination. Full article

We propose an ambipolar chitosan synaptic transistor that effectively responds to binary neuroplasticity. We fabricated the synaptic transistors by applying a chitosan electric double layer (EDL) to the gate insulator of the excimer laser annealed polycrystalline silicon (poly-Si) thin-film transistor (TFT) with Ni-silicide (NiSi) Schottky-barrier source/drain (S/D) junction. The undoped poly-Si channel and the NiSi S/D contact allowed conduction by electrons and holes, resulting in artificial synaptic behavior in both p-type and n-type regions. A slow polarization reaction by the mobile ions such as anions (CH₃COO⁻ and OH⁻) and cations (H⁺) in the chitosan EDL induced hysteresis window in the transfer characteristics of the ambipolar TFTs. We demonstrated the excitatory post-synaptic current modulations and stable conductance modulation through repetitive potentiation and depression pulse. We expect the proposed ambipolar chitosan synaptic transistor that responds effectively to both positive and negative stimulation signals to provide more complex information process versatility for bio-inspired neuromorphic computing systems. Full article

We have fabricated α-Sn/Ge quantum well heterostructures by sandwiching nano-films of α-Sn between Ge nanolayers. The samples were grown via e-beam deposition and characterized by Raman spectroscopy, atomic force microscopy, temperature dependence of electrical resistivity and THz time-resolved spectroscopy. We have established the presence of α-Sn phase in the polycrystalline layers together with a high electron mobility μ = 2500 ± 100 cm² V⁻¹ s⁻¹. Here, the temperature behavior of the resistivity in a magnetic field is distinct from the semiconducting films and three-dimensional Dirac semimetals, which is consistent with the presence of linear two-dimensional electronic dispersion arising from the mutually inverted band structure at the α-Sn/Ge interface. As a result, the α-Sn/Ge interfaces of the quantum wells have topologically non-trivial electronic states. From THz time-resolved spectroscopy, we have discovered unusual photocurrent and THz radiation generation. The mechanisms for this process are significantly different from ambipolar diffusion currents that are responsible for THz generation in semiconducting thin films, e.g., Ge. Moreover, the THz generation in α-Sn/Ge quantum wells is almost an order of magnitude greater than that found in Ge. The substantial strength of the THz radiation emission and its polarization dependence may be explained by the photon drag current. The large amplitude of this current is a clear signature of the formation of conducting channels with high electron mobility, which are topologically protected. Full article

This study proposes a bidirectional chemical sensor platform using ambipolar double-gate ion-sensitive field-effect transistors (ISFET) with microwave-assisted Ni-silicide Schottky-barrier (SB) source and drain (S/D) on a fully depleted silicon-on-insulator (FDSOI) substrate. The microwave-assisted Ni-silicide SB S/D offer bidirectional turn-on characteristics for both p- and n-type channel operations. The p- and n-type operations are characterized by high noise resistance as well as improved mobility and excellent drift performance, respectively. These features enable sensing regardless of the gate voltage polarity, thus contributing to the use of detection channels based on various target substances, such as cells, antigen-antibodies, DNA, and RNA. Additionally, the capacitive coupling effect existing between the top and bottom gates help achieve self-amplified pH sensitivity exceeding the Nernst limit of 59.14 mV/pH without any additional amplification circuitry. The ambipolar FET sensor performance was evaluated for bidirectional electrical characteristics, pH detection in the single-gate and double-gate modes, and reliability in continuous and repetitive operations. Considering the excellent characteristics confirmed through evaluation, the proposed ambipolar chemical sensor platform is expected to be applicable to various fields including biosensors. And through linkage with subsequent studies, various medical applications and precision detector operations for specific markers will be possible. Full article

This short critical review is devoted to the synthesis and functionalization of various types of azaacenes, organic semiconducting compounds which can be considered as promising materials for the fabrication of n-channel or ambipolar field effect transistors (FETs), components of active layers in light emitting diodes (LEDs), components of organic memory devices and others. Emphasis is put on the diversity of azaacenes preparation methods and the possibility of tuning their redox and spectroscopic properties by changing the C/N ratio, modifying the nitrogen atoms distribution mode, functionalization with electroaccepting or electrodonating groups and changing their molecular shape. Processability, structural features and degradation pathways of these compounds are also discussed. A unique feature of this review concerns the listed redox potentials of all discussed compounds which were normalized vs. Fc/Fc⁺. This required, in frequent cases, recalculation of the originally reported data in which these potentials were determined against different types of reference electrodes. The same applied to all reported electron affinities (EAs). EA values calculated using different methods were recalculated by applying the method of Sworakowski and co-workers (Org. Electron. 2016, 33, 300–310) to yield, for the first time, a set of normalized data, which could be directly compared. Full article

The Zeeman effect and dust grain alignment are two major methods for probing magnetic fields (B-fields) in molecular clouds, largely motivated by the study of star formation, as the B-field may regulate gravitational contraction and channel turbulence velocity. This review summarizes our observations of B-fields over the past decade, along with our interpretation. Galactic B-fields anchor molecular clouds down to cloud cores with scales around 0.1 pc and densities of 10^4–5 H₂/cc. Within the cores, turbulence can be slightly super-Alfvénic, while the bulk volumes of parental clouds are sub-Alfvénic. The consequences of these largely ordered cloud B-fields on fragmentation and star formation are observed. The above paradigm is very different from the generally accepted theory during the first decade of the century, when cloud turbulence was assumed to be highly super-Alfvénic. Thus, turbulence anisotropy and turbulence-induced ambipolar diffusion are also revisited. Full article

This paper presents a simple and comprehensive model of a dual-gate graphene field effect transistor (FET). The quantum capacitance and surface potential dependence on the top-gate-to-source voltage were studied for monolayer and bilayer graphene channel by using equivalent circuit modeling. Additionally, the closed-form analytical equations for the drain current and drain-to-source voltage dependence on the drain current were investigated. The distribution of drain current with voltages in three regions (triode, unipolar saturation, and ambipolar) was plotted. The modeling results exhibited better output characteristics, transfer function, and transconductance behavior for GFET compared to FETs. The transconductance estimation as a function of gate voltage for different drain-to-source voltages depicted a proportional relationship; however, with the increase of gate voltage this value tended to decline. In the case of transit frequency response, a decrease in channel length resulted in an increase in transit frequency. The threshold voltage dependence on back-gate-source voltage for different dielectrics demonstrated an inverse relationship between the two. The analytical expressions and their implementation through graphical representation for a bilayer graphene channel will be extended to a multilayer channel in the future to improve the device performance. Full article

A reference electrode is necessary for the working of ion-sensitive field-effect transistor (ISFET)-type sensors in electrolyte solutions. The Ag/AgCl electrode is normally used as a reference electrode. However, the Ag/AgCl reference electrode limits the advantages of the ISFET sensor. In this work, we fabricated a two-channel graphene solution gate field-effect transistor (G-SGFET) to detect pH without an Ag/AgCl reference electrode in the electrolyte solution. One channel is the sensing channel for detecting the pH and the other channel is the reference channel that serves as the reference electrode. The sensing channel was oxygenated, and the reference channel was fluorinated partially. Both the channels were directly exposed to the electrolyte solution without sensing membranes or passivation layers. The transfer characteristics of the two-channel G-SGFET showed ambipolar field-effect transistor (FET) behavior (p-channel and n-channel), which is a typical characteristic curve for the graphene ISFET, and the value of V_Dirac was shifted by 18.2 mV/pH in the positive direction over the range of pH values from 4 to 10. The leakage current of the reference channel was 16.48 nA. We detected the real-time pH value for the two-channel G-SGFET, which operated stably for 60 min in the buffer solution. Full article

In this paper, a dual metallic material gate heterostructure junctionless tunnel field-effect transistor (DMMG-HJLTFET) is proposed and investigated. We use the Si/SiGe heterostructure at the source/channel interface to improve the band to band tunneling (BTBT) rate, and introduce a sandwich stack (GaAs/Si/GaAs) at the drain region to suppress the OFF-state current and ambiplolar current. Simultaneously, to further decrease ambipolar current, the gate electrode is divided into three parts namely auxiliary gate (M1), control gate (M2), and tunnel gate (M3) with workfunctions Φ_M1, Φ_M2 and Φ_M3, respectively, where Φ_M1 = Φ_M3 < Φ_M2. Simulation results indicate that DMMG-HJLTFET provides superior performance in terms of logic and analog/RF as compared with other possible combinations, the ON-state current of the DMMG-HJLTFET increases up to $9.04\times 10^{-6}$ A/μm, and the maximum g_m (which determine the analog performance of devices) of DMMG-HJLTFET is $1.11\times 10^{-5}$ S/μm at 1.0V drain-to-source voltage (Vds). Meanwhile, RF performance of devices depends on the cut-off frequency (f_T) and gain bandwidth (GBW), and DMMG-HJLTFET could achieve a maximum f_T of 5.84 GHz, and a maximum GBW of 0.39 GHz, respectively. Full article
