Search Results (41)

Magnetic resonance imaging (MRI) and hyperspectral imaging (HSI) provide complementary information for image-guided neurosurgery, combining high-resolution anatomical detail with tissue-specific optical characterization. This work presents a novel multimodal phantom dataset specifically designed for MRI–HSI integration. The phantoms reproduce a three-layer tissue structure comprising white matter, gray matter, tumor, and superficial blood vessels, using agar-based compositions that mimic MRI contrasts of the rat brain while providing consistent hyperspectral signatures. The dataset includes two designs of phantoms with MRI, HSI, RGB-D, and tracking acquisitions, along with pixel-wise labels and corresponding 3D models, comprising 13 phantoms in total. The dataset facilitates the evaluation of registration, segmentation, and classification algorithms, as well as depth estimation, multimodal fusion, and tracking-to-camera calibration procedures. By providing reproducible, labeled multimodal data, these phantoms reduce the need for animal experiments in preclinical imaging research and serve as a versatile benchmark for MRI–HSI integration and other multimodal imaging studies. Full article

Background/Objectives: Back table fluorescence imaging performed on freshly excised tissue specimens represents a critical step in fluorescence-guided surgery, enabling rapid assessment of tumor margins before final pathology. While most preclinical NIR-II imaging platforms, such as the IR VIVO (Photon, etc.), offer high-resolution and depth-sensitive imaging under controlled, enclosed conditions, they are not designed for intraoperative or point-of-care use. This study compares the IR VIVO with the LightIR system, a more compact and clinically adaptable imaging platform using the same Alizé 1.7 InGaAs detector, to evaluate whether the LightIR can offer comparable performance for back table NIR-II imaging under ambient light. Methods: Standardized QUEL phantoms containing indocyanine green (ICG) and custom agar-based tissue-mimicking phantoms loaded with IR-1048 were imaged on both systems. Imaging sensitivity, spatial resolution, and depth penetration were quantitatively assessed. LightIR was operated in pulse-mode under ambient lighting, mimicking back table or intraoperative use, while IR VIVO was operated in a fully enclosed configuration. Results: The IR VIVO system achieved high spatial resolution (~125 µm) and detected ICG concentrations as low as 30 nM in NIR-I and 300 nM in NIR-II. The LightIR system, though requiring longer exposure times, successfully resolved features down to ~250 µm and detected ICG to depths ≥4 mm. Importantly, the LightIR maintained robust NIR-II contrast under ambient lighting, aided by real-time background subtraction, and enabled clear visualization of subsurface IR-1048 targets in unshielded phantom setups, conditions relevant to back table workflows. Conclusions: LightIR offers performance comparable to the IR VIVO in terms of depth penetration and spatial resolution, while also enabling open-field NIR-II imaging without the need for a blackout enclosure. These features position the LightIR as a practical alternative for rapid, high-contrast fluorescence assessment during back table imaging. The availability of such clinical-grade systems may catalyze the development of new NIR-II fluorophores tailored for real-time surgical applications. Full article

Soft organic gels are commonly used as tissue phantoms for experiments. In the mimic ultrasound imaging field, researchers are developing approaches to modify the acoustic properties of the gels. Introducing oil liquids and hard solid particles are two common methods to tune acoustic and mechanical properties of the soft gels. In this work, the acoustic wave energy loss mechanisms were studied in detail on Agar gel with both micro-Graphite and nano-Alumina particles. Via experimental measurements, the results show that the effective acoustic energy loss is comparable in these two recipes. However, temporal pulse elongation and scattering behaviors were distinguishable. To understand the sound attenuation mechanism in detail, numerical simulations in controlled conditions were conducted, from wavelengths longer than the particle diameter to wavelengths shorter than particles, and we compared perfect bonding and insufficient bonding between the hard particles surrounding gels. Comparing the experimental observations and numerical simulation results, the Agar gel with nano-Alumina presents stronger dispersion-induced energy loss than the Agar gel with micro-Graphite. On the contrary, the Agar gel with micro-Graphite shows more significant scattering-induced destructive interferences than the Agar gel with nano-Alumina. Full article

The paper presents the design, manufacturing, and evaluation of a 3D-printed pancreas phantom model used for preoperative surgical planning and surgical training. Several manufacturing and design alternatives have been explored, leading to the final solution, which consisted of a transparent 3D printed elastic shell of the pancreas, resulting in an empty volume that was filled with a custom hydrogel to ensure an anatomically realistic behaviour. Additionally, specific vascular structures were printed using elastic material and specific colours. The hollow shell of the pancreas and the vascular structures were manufactured using photopolymerisation technology. The hydrogel, which replicates the internal structure of the pancreas, was made from a custom proportion of gelatine, agar, and glycerol. The phantom model of the pancreas was assessed by the surgical team and tested using the PARA-SILSROB parallel robot designed for single-incision surgical procedures. Full article

Little research has focused on using iron nitride as thermoseed particles in magnetic hyperthermia, although magnetite (Fe₃O₄) is commonly used for this purpose. In the present study, we focus on iron nitride, especially ε-Fe_2–3N. ε-Fe_2–3N particles were synthesized from hematite (α-Fe₂O₃) and sodium amide (NaNH₂) under various synthesis conditions, and the heat-generation properties of the particles were investigated to reveal the synthesis conditions that lead to particles with notable heat-generation performance. The particles synthesized at 250 °C for 12 h increased the temperature of an agar phantom by approximately 20 °C under an alternating magnetic field (100 kHz, 125 Oe, 600 s), suggesting that ε-Fe_2–3N particles can be used for magnetic hyperthermia. The analysis results for the particles synthesized under different conditions suggest that the heat-generation properties of ε-Fe_2–3N were affected by several factors, including the nitrogen content, particle size, crystallite size, saturation magnetization, and coercive force. Full article

Breast cancer remains one of the leading causes of death among women globally. Early detection is critical for improving patient outcomes, making the development of accurate and efficient detection methods essential for facilitating timely treatment and enhancing patients’ quality of life. Lesion sites are often associated with localized temperature increases, which can be identified by characterizing thermal gradients using thermometry tools. Ultrasound-based techniques are preferred for obtaining thermal patterns due to their noninvasive, non-ionizing nature and cost-effectiveness compared to methods like magnetic resonance imaging. This study focuses on developing breast tissue models with varying acoustic properties, specifically the speed of sound across temperatures ranging from 32 °C to 36 °C in increments of 0.5 °C for ultrasonic inspection and diagnostic applications. These models simulate healthy and tumorous breast tissue, including the fat, gland, and tumor layers. Signal variations were analyzed using cross-correlation methods to assess the changes in the speed of sound as a function of temperature. The proposed methodology offers a cost-effective, rapid, and precise approach to phantom production, facilitating the detection of temperature changes in 0.5 °C intervals through cross-correlation analysis of the acquired signals. Full article

Skin physiopathological conditions have a strong influence on its biomechanical properties. However, it remains difficult to accurately assess the surface stiffness of soft tissues. The aim of this study was to evaluate the performances of an impact-based analysis method (IBAM) and to compare them with those of an existing digital palpation device, MyotonPro^®. The IBAM is based on the impact of an instrumented hammer equipped with a force sensor on a cylindrical punch in contact with agar-based phantoms mimicking soft tissues. The indicator $\mathsf{\Delta }t$ is estimated by analyzing the force signal obtained from the instrumented hammer. Various phantom geometries, stiffnesses and structures (homogeneous and bilayer) were used to estimate the performances of both methods. Measurements show that the IBAM is sensitive to a volume of interest equivalent to a sphere approximately twice the punch diameter. The sensitivity of the IBAM to changes in Young’s modulus is similar to that of dynamic mechanical analysis (DMA) and significantly better compared to MyotonPro. The axial (respectively, lateral) resolution is two (respectively, five) times lower with the IBAM than with MyotonPro. The present study paves the way for the development of a simple, quantitative and non-invasive method to measure skin biomechanical properties. Full article

This study proposes a high-frequency Pulse Amplitude-Modulation Temporal-Interference (PAM-TI) current stimulation device, which utilizes two sets of Amplitude-modulated transcranial alternating current stimulation (AM-tACS): one AM frequency at f0 (where f0 = 2 kHz) (source 1) and the other AM frequency at f1 = f0 + $△$f (where f1 = 2.01 kHz) (source 2), to generate a $△$f (where $△$f = 10 Hz) envelope modulated at a fc (where fc = 100 kHz) high carrier frequency. The high carrier frequency reduces body impedance and conserves more stimulation power, allowing it to penetrate the skin and reach the subcutaneous region. The proposed PAM-TI technique elevates the two current sources to a 100 kHz carrier frequency. Instead of the challenges associated with generating high-frequency stimulation currents using an MCU and DAC, the proposed PAM-TI stimulation device achieves this by simply utilizing a pair of complementary pulse-width modulations (PWMs). The push–pull technique is employed to balance the charging currents between the anode and cathode, synchronizing the current timing of Source 1 and Source 2 under the fc modulation condition. To minimize signal attenuation, the PAM circuit is integrated directly into the electrode, ensuring the high-frequency signal is generated close to the body and preventing degradation from long wires. Additionally, a dry pin-type spring-loaded electrode is used to reduce interference caused by hair when placed on the head. The device’s validity and current directionality were verified using a scalp tissue-mimicking phantom composed of agar and saline. Full article

Non-invasive transcranial electrical stimulation is a category of neuromodulation techniques used for various disorders. Although medically approved devices exist, the variety of consumer electrical stimulation devices is increasing. Because clinical trials and animal tests are costly and risky, using a brain phantom can provide preliminary experimental validation. However, existing brain phantoms are often costly or require excessive preparation time, precluding their use for rapid, real-time optimization of stimulation settings. A limitation of direct electric fields in a phantom is the lack of 3D spatial resolution. Using well-researched modalities such as transcranial direct current stimulation (tDCS) and newer modalities such as amplitude-modulated transcranial pulsed-current stimulation (am-tPCS), a range of materials was tested for use as electrical phantoms. Based on cost, preparation time, and efficiency, ground beef and agar gel with a 10% salt mix were selected. The measured values for the total dosages were 0.55 W-s for am-tPCS and 0.91 W-s for tDCS. Due to a low gain on the recording electrodes, the signal efficiency measured against the power delivered was 4.2% for tDCS and 3.1% for am-tPCS. Issues included electrodes shifting in the soft material and the low sensitivity of the recording electrodes. Despite these issues, the effective combination of the phantom and recording methodologies can enable low costs and the rapid testing, experimentation, and verification of consumer neuromodulation devices in three dimensions. Additionally, the efficiency factors (EFs) between the observed dosage and the delivered dosage could streamline the comparison of experimental configurations. As demonstrated by comparing two types of electrical neuromodulation devices across the 3D space of a phantom, EFs can be used in conjunction with a cost-effective, time-expedient phantom to rapidly iterate and optimize stimulation parameters. Full article

Background: Traditional gel-based (wet) electrodes for biopotential recordings have several shortcomings that limit their practicality for real-world measurements. Dry electrodes may improve usability, but they often suffer from reduced signal quality. We sought to evaluate the biopotential recording properties of a novel mixed ionic–electronic conductive (MIEC) material for improved performance. Methods: We fabricated four MIEC electrode form factors and compared their signal recording properties to two control electrodes, which are electrodes commonly used for biopotential recordings (Ag-AgCl and stainless steel). We used an agar synthetic skin to characterize the impedance of each electrode form factor. An electrical phantom setup allowed us to compare the recording quality of simulated biopotentials with ground-truth sources. Results: All MIEC electrode form factors yielded impedances in a similar range to the control electrodes (all <80 kΩ at 100 Hz). Three of the four MIEC samples produced similar signal-to-noise ratios and interfacial charge transfers as the control electrodes. Conclusions: The MIEC electrodes demonstrated similar and, in some cases, better signal recording characteristics than current state-of-the-art electrodes. MIEC electrodes can also be fabricated into a myriad of form factors, underscoring the great potential this novel material has across a wide range of biopotential recording applications. Full article

Acoustic aberration, caused by the uneven distribution of tissue speed-of-sound (SoS), significantly reduces the quality of ultrasound imaging. An important approach to mitigate this issue is imaging correction based on local SoS estimation. Computed ultrasound tomography in echo mode (CUTE) is an SoS estimation method that utilizes phase-shift information from ultrasound pulse–echo signals, offering both practical utility and computational efficiency. However, the traditional single-pass CUTE often suffers from poor accuracy and robustness. In this paper, an advanced approach known as iterative CUTE is introduced, which refines SoS estimates through iterative correction of errors and noise, addressing the limitations of traditional single-pass methods. It is argued that traditional precision indicators like root mean square error (RMSE) fall short in adequately reflecting the quality of SoS estimates for imaging correction, and coherence factor (CF) is proposed as a more indicative metric. Performance validation of the iterative CUTE algorithm was conducted using a simulation and agar phantom experiment. The results indicated that the iterative CUTE approach surpasses the single-pass approach, enhancing the average CF for SoS estimates by up to 18.2%. In phantom experiments, imaging corrected with SoS estimates from iterative CUTE reduced the Array Performance Index (API) by up to 40% compared to traditional methods. Full article

Mixed manganese–zinc ferrite nanoparticles coated with PEG were studied for their potential usefulness in MRI thermometry as temperature-sensitive contrast agents. Particles in the form of an 8.5 nm core coated with a 3.5 nm layer of PEG were fabricated using a newly developed, one-step method. The composition of Mn_0.48Zn_0.46Fe_2.06O₄ was found to have a strong thermal dependence of magnetization in the temperature range between 5 and 50 °C. Nanoparticles suspended in an agar gel mimicking animal tissue and showing non-significant impact on cell viability in the biological test were studied with NMR and MRI over the same temperature range. For the concentration of 0.017 mg/mL of Fe, the spin–spin relaxation time T₂ increased from 3.1 to 8.3 ms, while longitudinal relaxation time T₁ shows a moderate decrease from 149.0 to 125.1 ms. A temperature map of the phantom exposed to the radial temperature gradient obtained by heating it with an 808 nm laser was calculated from T₂ weighted spin-echo differential MR images. Analysis of temperature maps yields thermal/spatial resolution of 3.2 °C at the distance of 2.9 mm. The experimental relaxation rate R₂ data of water protons were compared with those obtained from calculations using a theoretical model incorporating the motion averaging regime. Full article

Proton resonance frequency shift (PRFS) is an MRI-based simple temperature mapping method that exhibits higher spatial and temporal resolution than temperature mapping methods based on T1 relaxation time and diffusion. PRFS temperature measurements are validated against fiber-optic thermal sensors (FOSs). However, the use of FOSs may introduce temperature errors, leading to both underestimation and overestimation of PRFS measurements, primarily due to material susceptibility changes caused by the thermal sensors. In this study, we demonstrated susceptibility-corrected PRFS (scPRFS) with a high frame rate and accuracy for suitably distributed temperatures. A single-echo-based background removal technique was employed for phase variation correction, primarily owing to magnetic susceptibility, which enabled fast temperature mapping. The scPRFS was used to validate the temperature fidelity by comparing the temperatures of fiber-optic sensors and conventional PRFS through phantom-mimicked human and ex vivo experiments. This study demonstrates that scPRFS measurements in agar-gel are in good agreement with the thermal sensor readings, with a root mean square error (RMSE) of 0.33–0.36 °C in the phantom model and 0.12–0.16 °C in the ex vivo experiment. These results highlight the potential of scPRFS for precise thermal monitoring and ablation in both low- and high-temperature non-invasive therapies. Full article

Ultrasound-guided techniques are increasingly prevalent and represent a gold standard of care. Skills such as needle visualisation, optimising the target image and directing the needle require deliberate practice. However, training opportunities remain limited by patient case load and safety considerations. Hence, there is a genuine and urgent need for trainees to attain accelerated skill acquisition in a time- and cost-efficient manner that minimises risk to patients. We propose a two-step solution: First, we have created an agar phantom model that simulates human tissue and structures like vessels and nerve bundles. Moreover, we have adopted deep learning techniques to provide trainees with live visualisation of target structures and automate assessment of their user speed and accuracy. Key structures like the needle tip, needle body, target blood vessels, and nerve bundles, are delineated in colour on the processed image, providing an opportunity for real-time guidance of needle positioning and target structure penetration. Quantitative feedback on user speed (time taken for target penetration), accuracy (penetration of correct target), and efficacy in needle positioning (percentage of frames where the full needle is visualised in a longitudinal plane) are also assessable using our model. Our program was able to demonstrate a sensitivity of 99.31%, specificity of 69.23%, accuracy of 91.33%, precision of 89.94%, recall of 99.31%, and F1 score of 0.94 in automated image labelling. Full article

Skin cancer is a significant global health issue, placing a growing burden on individuals and society. Conventional diagnostic methods like visual examination and biopsy have limitations in invasiveness and accuracy. As a result, alternative tools such as infrared thermography have gained attention in skin cancer diagnosis. Tissue-mimicking phantoms have been instrumental in facilitating research in this field, offering controlled environments. While they do not fully replicate human skin complexity, physical skin models provide stability, ease of fabrication, and control over properties. Agarose phantoms are employed in this study. This research focused on testing and comparing cooling techniques for human skin in the context of skin cancer diagnosis using dynamic infrared thermography. Six cooling methods were investigated: a cool pack, an aluminum medal, ice, alcohol, a vortex cooler and a Zimmer Cryo 6 cooler. The experimental setup involved an infrared camera (Optris Xi400) with microscope optics positioned above an agar phantom mimicking flat skin and an ulcerating skin lesion. Based on experiments conducted on the skin phantom, it was observed that convective cooling methods offered more consistent and uniform cooling. Conversely, conductive methods proved effective for flat objects but posed challenges in achieving uniform cooling for bulging skin or ulcerated lesions. Ice or alcohol were deemed unsuitable due to artifacts influencing the infrared radiation and thermal camera view. A decision matrix assessed cooling techniques based on criteria such as uniformity, repeatability, view obstruction, efficiency, workload, patient comfort, clinical suitability, noise exposure, consumables, additional equipment, and price. The Zimmer Cryo 6 cooler emerged as the most suitable cooling method after evaluating various factors. Full article
