Search Results (271)

Deformation monitoring is critical for structural health assessment of operational shield tunnels in urban rail transit. LiDAR point clouds in operating tunnels usually contain auxiliary facilities, occlusions, noise, and uneven point density. Conventional section-by-section ellipse fitting often leads to unstable parameter jumps between adjacent sections. This paper presents a high-precision method to extract lateral deformation from tunnel LiDAR point clouds. First, a point-wise attention Transformer network (PWAT) is proposed based on PointNet++ for lining segmentation, using k-NN adaptive sampling, geometric position encoding, and geometry-constrained multi-head self-attention. Second, a continuity-constrained RANSAC (CC-RANSAC) algorithm is developed to improve ellipse parameter stability by adding continuity penalties between neighboring sections. Experiments were carried out on a Shanghai metro shield tunnel. Results show that PWAT achieves 99.53% overall accuracy and 99.06% mIoU in six-class segmentation. CC-RANSAC reduces the mean residual to 2.0 mm and the center jump rate to 4.2%. Compared with total station data, the mean absolute error and root mean square error are 1.35 mm and 1.68 mm. The proposed method can automatically and accurately extract lateral deformation for operational shield tunnels. Full article

To investigate the deformation law of adjacent metro tunnels under the coupling effect of servo supports and deep foundation pit excavation, this study takes an ultra-deep foundation pit adjacent to Hangzhou Metro Line 2 as the research object. A servo support system was adopted for synchronous active loading during excavation, and field monitoring was conducted to analyze the deformation response of existing operating tunnels before and after servo loading. The results indicate that servo loading significantly reduces the rate of increase in tunnel vertical displacement, horizontal displacement, and horizontal relative convergence. It is found that the servo support closest to the tunnel (i.e., the third servo support in the case) exhibits the most prominent control effect—after loading, the vertical displacement rate of the down-line tunnel decreases from −0.04 mm/d to 0 mm/d, and the horizontal displacement rate is reduced by approximately 70%. Moreover, seven days after loading, the horizontal relative convergence rate of the up-line tunnel tends to be 0 mm/d. Servo supports effectively weaken the tunnel’s deformation development during critical stages of ultra-deep foundation pit construction, enabling active and precise control of adjacent operating metro tunnels. Full article

The impact of short-distance lateral shield tunneling threatens the safety of operational high-speed railways (HSRs). To address the engineering challenge of “how to select isolation pile density under fixed cost constraints,” this study focuses on the Xi’an Metro shield tunnel section passing laterally adjacent to the Daxi and Zhengxi Passenger Dedicated Lines. Under the constraint of identical total economic costs, two isolation pile schemes—low-density and high-density—were established to investigate the control patterns of different densities on HSR bridge piles and surrounding ground surface deformation. A three-dimensional (3D) numerical model was developed for the lateral shield tunneling process. Combined with field-measured data, numerical simulations were conducted for corresponding construction stages to analyze the disturbance effects of shield tunneling on HSR piers and the surrounding ground, as well as the deformation restraint performance of isolation piles. The results indicate that the high-density isolation pile scheme (pile spacing: 2.0 m; pile length: 22 m) provides superior control compared to the low-density scheme (pile spacing: 4 m; pile length: 28 m). Following single- and double-track excavation, the vertical displacement of HSR piers was reduced by 0.6 mm and 1.1 mm, respectively—a reduction of 40–74%. Furthermore, the pier displacement along the depth direction shifted from non-uniform to relatively uniform. The difference in surface settlement between the two schemes was only 0.2 mm, suggesting that isolation pile density has a marginal impact on ground deformation. The horizontal displacement of high-density isolation piles stabilized at 1.7–1.9 mm, with vertical heave ranging from 1.2 to 1.4 mm. The lateral displacement profile exhibited a regular “double-C outward expansion” shape, which is better suited to the characteristics of water-rich sand layers. Initial excavation causes significant disturbance to the original strata, necessitating enhanced stress field protection measures. The high-density scheme is recommended for engineering applications, as it achieves optimal control of bridge pile deformation under cost constraints and meets regulatory specifications. Full article

This paper presents the development of a novel morphing wing prototype with three camber-twist morphing flaps. Reflexed airfoil morphing is achieved by means of two chordwise degrees-of-freedom, thereby decoupling lift from the aerodynamic moment with respect to the aerodynamic centre. The prototype wing design is characterised by a novel morphing flap concept and driven by the boundary conditions pertinent to the wind tunnel testing facilities and the choice of research questions. The flaps’ spanwise ends are adapted to represent a seamless and a discontinuous transition between adjacent flaps. Linear electric motors induce the morphing shapes, equipped with load cells on their respective push rods, for actuator force measurement. Pressure taps are included to measure the pressure distribution along the wing section. Upon manufacturing, preliminary static test results validate the wing’s morphing functionality. The morphing trailing edge demonstrates a range of camber morphing and twist morphing shapes, as well as the ability to support asymmetric morphing between adjacent flaps. Full article

Tunneling activity inevitably induces soil stress redistribution and ground deformation, which may affect adjacent existing pile foundations. Since many previous studies have mainly focused on circular tunnels, the effects of quasi-rectangular shield (QRS) tunneling on adjacent existing pile foundations are not well investigated and understood. In this study, a series of physical model tests were carried out to investigate the response of a single pile and pile group subjected to newly QRS tunneling beneath an existing circular tunnel in dry sand. Two distinct underpass cases were considered: an orthogonal underpass (QRS tunnel axis perpendicular to the circular tunnel axis) and an overlapping underpass (QRS tunnel axis aligned with the circular tunnel axis). The test results indicate that QRS tunneling-induced ground surface settlement and single-pile settlement in the overlapping underpass case were 3.6 and 1.2 times that in the orthogonal underpass case, respectively, with a narrower settlement trough. The axial force distribution along the single pile remained qualitatively consistent in both underpass cases, consistently exhibiting a downward load-transfer mechanism, and further leading to a monotonic growth pattern in axial force with progressive QRS tunnel excavation. The additional stress of the single pile was consistently higher in the overlapping underpass case, which had maximum axial force, negative bending moment, and maximum positive bending moment increases of 20%, 13%, and 6%, respectively, relative to the orthogonal underpass case. The front pile in the pile group exerted a pronounced shielding effect on the rear pile, while the restraining action of the pile cap also contributed measurably to the overall pile responses. Full article

The temperature field characteristics of highway tunnels during fire conditions are investigated in this paper. Numerical simulations coupled with reduced-scale physical model tests were conducted to analyze the thermal characteristics of the tunnel interior and lining structure under various ventilation conditions. Taking the extra-long double-tube highway tunnel as a case study, a numerical model was established using FLUENT to simulate a 100 MW fire under different longitudinal ventilation velocities. Furthermore, a reduced-scale physical model with a geometric similarity ratio of 1:2.7 was fabricated to investigate the effect of lining moisture content on the heat transfer characteristics. It is indicated by the results that high-temperature zones above 800 °C are mainly concentrated within roughly 100 m of the fire source, extending approximately 20 m upstream and 80 m downstream. As the ventilation velocity rises, the high-temperature zone adjacent to the fire source is gradually reduced, the upstream smoke backflow length is shortened, and the downstream thermal influence range is expanded. Obvious spatial variations are observed in the cross-sectional temperature distribution: relatively uniform temperatures are found near the fire source, whereas higher temperatures are observed at the crown in upstream and downstream sections, followed by the haunch and sidewalls. A pronounced thermal lag effect is observed in the lining structure, with both slower heating rates and lower peak temperatures being exhibited at larger distances from the fire source and in linings with higher moisture content. A temperature plateau at around 100 °C is detected, which is mainly attributed to latent heat absorption during moisture evaporation. A more significant temperature gradient through the lining thickness is also caused by a higher moisture content. These findings provide valuable references for tunnel fire safety design, smoke control strategies, and evacuation safety analysis. Full article

In urban subway construction, shield tunneling inevitably passes in close proximity to existing pile foundations, inducing adverse effects on their internal forces and deformations. Taking the twin shield tunnels with small clearance adjacent to the bridge piles as the engineering background, this study establishes a three-dimensional finite element numerical model to investigate the deformation and internal force responses of the adjacent pile foundations under different pile lengths, twin-tunnel construction sequences, and tunnel face pressure conditions. The findings indicate that the primary influence zone affected by twin-tunnel excavation extends approximately twice the tunnel diameter (2D) before and after the pile foundation location. Compared with short piles, longer piles exhibit smaller vertical displacements. Meanwhile, the lateral displacements, additional axial forces and bending moments of medium and long piles increase, with their maximum values occurring near the tunnel centerline. For the near pile, when the right tunnel is excavated first, compared with the condition of the left-tunnel-first excavation, the lateral and vertical displacements slightly increase. In addition, the maximum additional axial force increases by 38.8%, while the maximum additional bending moment decreases by approximately 21%. Tunnel face pressure exerts a moderate influence on the vertical displacement of both the surrounding soil and pile foundation, while its effect on lateral displacement and internal forces is relatively insignificant. The tunnel face pressure within the range of 200 kPa to 300 kPa provides optimal control over pile foundation deformation. Full article

To evaluate the coupled deformation of existing shield tunnels induced by multi-segment excavations with isolation piles, this study develops an integrated analytical framework combining a Kerr three-parameter foundation-plate model with a three-dimensional image-source solution. A closed-form expression for the soil displacement field is first derived by incorporating layered soil conditions, staged excavation, and associated spatial effects. The soil–pile interaction of isolation piles is then modeled using the Kerr foundation, and the flexural response is obtained through variational formulation and finite-difference discretization. These responses are sequentially propagated through the excavation stages, enabling the superposition of multi-pit effects on the final retaining-wall deformation. The image-source method and a volume-equivalent transformation are further used to convert wall deformation into an additional stress field acting on the tunnel, which is ultimately coupled with a tunnel–soil deformation–coordination model to compute horizontal tunnel displacements. This unified workflow establishes a continuous mechanical transfer chain—from excavation-induced soil loss to isolation-pile bending and finally tunnel deformation. Parametric analyses show that lateral displacement of the retaining structure is jointly governed by wall bending and pit-bottom uplift, producing a right-skewed “S-shaped” profile. The bending-moment peak shifts toward earlier-excavated zones, indicating a memory effect of excavation sequencing. Two engineering cases verify that the proposed method accurately reproduces the magnitude and depth of measured wall deflections, while predicted tunnel displacements show a near-Gaussian pattern with high accuracy near the peak. The analytical framework provides a robust theoretical basis for optimizing pit segmentation and excavation sequencing adjacent to shield tunnels. Full article

The deep foundation pit excavation of subway will cause horizontal displacement, uneven settlement and other adverse effects on the adjacent shield. The use of servo steel strut has a certain effect on deflection correction, but the current understanding of the influencing factors of deflection correction is not comprehensive. Based on structural and spatial symmetry, the influence of tunnel depth, tunnel and foundation pit clear distance and deformation control quantity of enclosure structure on deflection correction quantity was studied by symmetrically designed model test and numerical simulation, and the prediction formula of deflection correction quantity considering tunnel and foundation pit clear distance and deformation control quantity of enclosure structure was proposed. The results show that with an increase in the tunnel’s burial depth, deflection correction decreases significantly. When the tunnel is near the foundation pit bottom, there is no significant correction effect, and the control law of the tunnel ground pressure under the servo steel strut loading is consistent with the correction law. Deflection correction is negatively correlated with the tunnel and foundation pit clear distance, and positively correlated with the deformation control of the diaphragm wall. The curve of the deformation control of the enclosure structure and the deflection correction is parabolic. The deflection correction is an exponential function of the ratio of the deformation control of the enclosure structure to the clear distance between the tunnel and the foundation pit, and the servo deflection correction follows a normal distribution along the longitudinal axis of the tunnel, showing obvious symmetry characteristics in the foundation pit influence zone. Full article

The construction of suspension bridges in mountainous expressways often involves tunnel-type anchorages in close proximity to shallow-buried bifurcated tunnels, particularly in soft rock strata with dense overlying structures. This proximity poses significant challenges to construction safety and stability. This study aims to investigate the influence of tunnel-type anchorage construction on the ground surface, surrounding rock, and adjacent bifurcated tunnels under such complex conditions. It was hypothesized that the anchorage load transfer and deformation mechanisms would significantly affect the adjacent tunnel, with potential cumulative effects due to the twin-anchor configuration. To address this, a combined approach of in situ scaled model testing (1:10 scale) and three-dimensional numerical simulation was employed. The model test incorporated monitoring of deformation and stress at key locations (anchor plug, rock mass, and anchor–rock interface) under incremental cable loads. Quantitative results from the model test indicate that at the design load (1P, equivalent to 2016.84 kN per anchor), deformations were minimal (e.g., maximum anchor displacement 0.35 mm). The anchor–rock interface exhibited limited slip (max 0.06 mm at 1P), and contact stresses were highest in the rear part of the anchor plug, indicating a non-uniform load transfer. Under overload conditions, the system reached yield at 7P and peak strength at 10.5P, with measured ground surface cracks up to 5 mm. Numerical simulations, calibrated against the experimental data, revealed that under increasing load (up to 10P), the plastic zones around the two anchors progressively expanded and eventually coalesced, leading to a characteristic “inverted trapezoid” failure pattern propagating to the surface, accompanied by shear failure along the 14° bedding plane. The combined results quantify the progressive interaction between the twin anchorages and the surrounding rock, highlighting the critical role of the anchor–rock interface and the cumulative effect of twin anchors on ground deformation and potential failure mechanisms. This research provides a scientific basis for the design and construction of tunnel-type anchorages in similar challenging geological and spatial settings. Full article

This case highlights the diagnostic value of high-resolution ultrasonography in identifying postoperative injury of the posterior branch of the medial antebrachial cutaneous nerve (MABCN) following cubital tunnel surgery. A 45-year-old man developed localized pain, warmth, and paresthesia extending from the medial epicondyle to the proximal anterior forearm one month after ulnar nerve decompression and anterior transposition. Physical examination revealed focal allodynia and a positive Tinel sign. Because previous surgery may substantially alter the anatomical location of the surrounding nerves, electrodiagnostic localization can be technically challenging and less reliable. Ultrasonography therefore played a key diagnostic role. The images demonstrated the normal sonoanatomy of the MABCN and its anatomical relationship with the basilic vein and ulnar nerve, followed by pathologic findings of focal enlargement of the posterior branch adjacent to postoperative scar tissue. These imaging features, together with a positive sonographic Tinel sign, supported the diagnosis of localized nerve irritation. Ultrasound-guided hydrodissection using 5% dextrose and methylcobalamin resulted in marked clinical improvement, with the Visual Analog Scale pain score decreasing from 9 to 2. This case is particularly illustrative because postoperative injury of the MABCN may mimic recurrent cubital tunnel syndrome yet typically produces purely sensory symptoms confined to the medial elbow region. Targeted ultrasonographic evaluation can reveal subtle postoperative nerve pathology and guide effective ultrasound-guided intervention. Full article

Peptidyl arginine deiminase 4 (PAD4) is a Ca²⁺-dependent enzyme that catalyzes histone citrullination and plays a central role in chromatin decondensation during neutrophil extracellular trap (NET) formation. Dysregulated PAD4-mediated NETosis contributes to the pathogenesis of diverse inflammatory and immune-related diseases, including autoimmune disorders, cancer, and thrombosis. Although several synthetic PAD4 inhibitors have been developed, their therapeutic application has been limited by issues related to selectivity, irreversible covalent reactivity, and suboptimal pharmacokinetic properties, prompting growing interest in natural products as alternative modulators of PAD4 activity and NETosis. This article presents a structural and mechanistic overview of natural products that target PAD4 and regulate NETosis. Based on enzyme kinetics, structural analyses, and functional validation, natural PAD4 modulators are classified into four categories: (i) active-site-directed inhibitors that bind within the U-shaped substrate tunnel, (ii) mixed and active-site-adjacent inhibitors that engage surface pockets flanking the catalytic site, (iii) allosteric and hybrid modulators that bind to regulatory regions distinct from the active site, and (iv) functionally validated PAD4 binders supported by biophysical and cellular evidence. Integration of structural, biochemical, and cellular data highlights that indirect or noncanonical modes of PAD4 regulation represent biologically coherent strategies for controlling pathological NETosis. Full article

Accurate reproduction of deterministic gusts in wind tunnels is essential for studying unsteady aerodynamics and aeroelastic response in aircraft, uninhabited aerial vehicles, and wind turbines. This work presents the design, experimental characterization, and numerical modelling of a low-speed gust generator based on oscillating vanes, capable of producing high-amplitude gusts in strongly unsteady flow regimes. Cross-flow hot-wire measurements are combined with time-accurate computational fluid dynamics simulations to analyze gust formation and propagation. Classical ‘1-cos’ gusts are shown to exhibit pronounced negative velocity peaks associated with start–stop vortex shedding. A modified vane motion protocol is proposed that significantly reduces the negative peak factor while preserving a substantial gust ratio over a wide range of reduced frequencies. Measurements are supplemented with computational fluid dynamics (CFD) simulations. The CFD study included 2D and 3D URANS as well as higher fidelity DES simulations. Flow-field analysis reveals that secondary variations in gust angle arise from nonlinear interactions between vortices shed by adjacent vanes and are influenced by wind-tunnel confinement. The results provide physical insight into the limitations of oscillating-vane gust generators and guidance for the design of high-fidelity gust-generation systems. Full article

Background/Objectives: The anterior cruciate ligament (ACL) plays a key role in knee stability, biomechanics, and proprioception, and is one of the most frequently injured and reconstructed ligaments in both athletes and the general population. The anatomical placement of femoral and tibial tunnels close to the native ACL insertion sites is critical for long-term clinical outcomes and graft survival. This study aimed to define sagittal and coronal ACL alignment and tibial footprint morphology on magnetic resonance imaging (MRI) in healthy knees, to explore sex- and side-related differences, and to provide population-specific reference values. Methods: In this retrospective cross-sectional study, knee MRIs acquired between 2018 and 2021 were screened, and knees with an intact ACL and without deformity or joint pathology that could alter alignment were included. After applying inclusion and exclusion criteria, 636 knees (320 right, 316 left) from 545 individuals (338 women, 298 men; 15–80 years, mean age 34.87 ± 11.65 years) were analyzed. On sagittal images, the sagittal ACL angle (S-ANGLE) was measured on the slice where the ligament appeared maximally visualized. The midpoints of the ACL were identified on two adjacent sagittal slices, and a line drawn through these midpoints was used to represent the central axis of the ligament; the angle between this line and the tibial plateau was recorded as the S-ANGLE. For anteroposterior localization of the tibial footprint, an anteroposterior reference distance (S-long) was defined as the length measured parallel to the tibial plateau, extending from the midpoint of the tibial tuberosity (corresponding to the insertion site of the patellar ligament and used as a topographic anterior landmark) toward the posterior aspect of the proximal tibia. A perpendicular line was drawn from the anterior end of S-long to establish the anterior reference boundary. The distance from this anterior reference line to the midpoint of the ACL tibial footprint along the same anteroposterior axis was defined as S-short. The sagittal footprint percentage (S-PERCENTAGE) was calculated as (S-short/S-long) × 100, representing the size-normalized sagittal anteroposterior position of the ACL tibial footprint midpoint. On coronal images, the ACL–tibial plateau angle (C-ANGLE), mediolateral tibial length (C-LONG), and distance from the medial edge to the ACL insertion (C-short) were obtained; C-PERCENTAGE was calculated analogously. Medial mechanical proximal tibial angle (mMPTA) was used to confirm physiological coronal alignment. Non-parametric tests were applied, with p < 0.05 considered statistically significant. Results: Women had significantly greater sagittal ACL angles than men, whereas anteroposterior distances measured from the midpoint of the tibial tuberosity (used as an anterior topographic landmark) and oriented parallel to the tibial plateau (S-LONG) and mediolateral tibial lengths (C-LONG) and absolute distances to the ACL tibial footprint were larger in men. In contrast, normalized sagittal and coronal footprint percentages (S-PERCENTAGE, C-PERCENTAGE) did not differ meaningfully between sexes, indicating the preservation of the relative ACL tibial insertion site despite size differences. Small but statistically significant side-to-side differences were observed in some coronal parameters; however, absolute differences were small and did not substantially modify the overall alignment pattern. Conclusions: This study provides large-sample, population-specific reference values for ACL orientation and tibial footprint location in both sagittal and coronal planes in healthy knees. The combination of higher sagittal ACL angles and shorter anteroposterior distances reference measured from the midpoint of the tibial tuberosity and oriented parallel to the tibial plateau (S-LONG) in women may represent a structural substrate contributing to the higher ACL injury rates reported in females. The morphometric data presented here may assist in individualized ACL reconstruction planning, MRI-based assessment of tibial tunnel position, and the design of knee-related biomedical implants and devices. Full article

With the intensive development of urban underground space, excavations adjacent to existing tunnels have become increasingly common. This study investigates the response of adjacent tunnels and surrounding soil to multi-step foundation pit excavation and the effect and mechanism of a new capsule technology. Centrifuge model tests and finite element analysis were conducted for models both with and without a capsule. The results show that the soil deformation caused by each excavation step is confined to an influence zone. As the excavation deepens, this influence zone progressively expands. Excavation causes the tunnel to move outward and the retaining wall to rotate clockwise. The results demonstrate that capsule pressurization can effectively reduce the maximum horizontal displacement of the adjacent tunnel by approximately 30–40% compared to the case without reinforcement. Capsule pressurization alters the earth pressure distribution on the retaining wall and reduces tunnel displacement. The effect of the capsule decays with increasing distance from the capsule to the tunnel. The excavation impact propagates to the tunnel via wall–soil and soil–tunnel interactions. Capsule pressurization mitigates the tunnel response by ensuring that the surrounding soil experiences a smaller reduction in horizontal stress and exhibits a higher modulus during subsequent excavation. This enhanced state of the soil produces smaller deformation, which ultimately transfers less of the excavation effect to the tunnel and controls its displacement. The study concludes that the active pressure control offered by the capsule technology is a promising method for protecting existing tunnels during adjacent deep excavations. Full article
