Search Results (59)

The research demonstrates, through simulation and laboratory validation, the development of a low-voltage DC-link (LVDC) back-to-back converter system that enables multi-frequency power transfer. The system operates in two distinct modes, which include a three-phase grid-connected converter transferring fundamental and 5th and 7th harmonic power to a three-phase residential inverter supplying a clean 50 Hz load and another mode that uses a DC–DC buck–boost converter to integrate a battery storage unit for single-phase load supply. The system allows independent control of each harmonic component and maintains a clean sinusoidal voltage at the load side through DC-link isolation. The LVDC link functions as a frequency-selective barrier to suppress non-standard harmonic signals on the load side, effectively isolating the multi-frequency power grid from standard-frequency household loads. The proposed solution fills the gap between the multi-frequency power systems and the single-frequency loads because it allows the transfer of total multi-frequency grid power to the traditional household loads with pure fundamental frequency. Experimental results and simulation outcomes demonstrate that the system achieves high efficiency, robust harmonic isolation, and dynamic adaptability when load conditions change. Full article

This paper presents an adaptive wireless droop control scheme that uses an adaptive virtual resistance to regulate the DC voltage and control the active power. The proposed methodology is implemented to address the power mismatch problem in a fixed-droop control for multi-terminal HVDC (MT-HVDC or MTDC) systems. Each inverter calculates available power and adjusts its output power accordingly while adapting the virtual resistance to mimic the behavior of a mesh system that is based on loading effects. The main objective of this methodology is to increase the reliability of the MTDC system by eliminating the need for fast communication links and ensuring proper power sharing between inverters. Additionally, this communication-free scheme includes a power management algorithm that controls power sharing during peak hours of the inverters among the rectifiers as per mutual agreements between the operators to mitigate the risk of a system overload and optimize the power sharing. A simulation of a five-terminal mesh MTDC system has been verified by using PSCAD/EMTDC to validate the performance and effectiveness of the proposed method. The results show the flexibility and feasibility of the proposed control method in three different modes. Full article

The LLC converter achieves the highest efficiency in resonant operation. Conventionally, the input DC-link voltage is controlled to operate the LLC converter at resonance for the given operating point. However, the DC-link capacitor voltage shows a low-frequency voltage ripple (typically the second harmonic of grid frequency) in cascaded converters so that the LLC has to adapt its switching frequency within the grid period. Conventionally, the LLC converter operates 50% of the time above the resonant frequency of 40 kHz and 50% below resonance. Both operating conditions cause additional losses. However, experimental measurements indicate that the below-resonance operation causes significantly higher losses than above-resonance operation due to much higher primary and secondary transformer currents. It is better to increase the DC-link voltage by 30% of the peak-to-peak low-frequency voltage ripple to mostly avoid below-resonance operation (i.e., from 650 V to 680 V in this case). With the proposed control, the LLC converter operates about 75% of time over resonance and only 25% of time below resonance. The overall efficiency increases from 97.66% to 97.7% for the average operating point with an 80% load current. This corresponds to a 2% total loss reduction. Finally, the peak resonance capacitor voltage decreases from 910 V to 790 V (−13%). Full article

This paper presents a variable step-size efficient learning modified P&O (LMPO) MPPT algorithm and adaptive proportional–integral (API)-based control techniques for a two-stage three-phase grid-integrated photovoltaic (TS-GIPV) system using an LCL filter. The proposed novel controlled technique introduces two-stage systems under different meteorological conditions and load deviations. The two-stage system with the presented control technique includes maximum power point tracking (MPPT) techniques, intermediate DC-link voltage, and grid current synchronization with a voltage source converter (VSC), respectively. This technique is implemented to improve the extract MPP of the solar PV generator system. An innovative grid-side VSC control technique addresses DC link regulation. Furthermore, this method regulates DC link voltage with an outer voltage loop and an inner current loop controller. Distinctively, the proposed technique regulates the inner loop while avoiding the outer loop. A control mechanism uses an API controller to regulate DC link voltage, distribute power, and synchronize grid current in the face of different scenarios. The fluctuating voltage of the DC link will be kept stable through power balancing. Hence, this technique improves the system stability, dynamic response, and component longevity by effectively reducing oscillations in the fluctuating DC link voltage at twice the grid frequency. The total harmonic distortion (THD%) of the grid currents of the PV power generated in the grid is maintained within the recommended limits. The proposed technique is simulated and verified through MATLAB/Simulink 2019b under different scenarios. Full article

Wind energy is essential for promoting sustainability and renewable power solutions. However, ensuring stability and consistent performance in DFIG-based wind turbine systems (WTSs) remains challenging due to rapid wind speed variations, grid disturbances, and parameter uncertainties. These fluctuations result in power instability, increased overshoot, and prolonged settling times, negatively impacting grid compliance and system efficiency. Conventional proportional-integral (PI) controllers are simple and effective in steady-state conditions, but they lack adaptability in dynamic situations. Similarly, artificial intelligence (AI)-based controllers, such as fuzzy logic controllers (FLCs) and artificial neural networks (ANNs), improve adaptability but suffer from high computational demands and training complexity. To address these limitations, this paper presents a hybrid adaptive neuro-fuzzy inference system (ANFIS)-PI controller for DFIG-based WTS. The proposed controller integrates fuzzy logic adaptability with neural network-based learning, allowing real-time optimization of control parameters. Implemented within the rotor-side converter (RSC) and grid-side converter (GSC), ANFIS enhances reactive power management, grid compliance, and overall system stability. The system was tested under a step wind speed signal varying from 10 m/s to 12 m/s to evaluate its robustness. The simulation results confirmed that the ANFIS-PI controller significantly improved performance compared with the conventional PI controller. Specifically, it reduced rotor speed overshoot by 3%, torque overshoot by 12.5%, active power overshoot by 2%, and DC link voltage overshoot by 20%. Additionally, the ANFIS-PI controller shortened settling time by 50% for rotor speed, by 25% for torque, by 33% for active power, and by 16.7% for DC link voltage, ensuring faster stabilization, enhanced dynamic response, and greater efficiency. These improvements establish the ANFIS-PI controller as an advanced, computationally efficient, and scalable solution for enhancing the reliability of DFIG-based WTS, facilitating seamless integration of wind energy into modern power grids. Full article

This paper presents the application of a proposed hybrid control strategy that is designed to enhance the performance and robustness of a grid-connected wind energy conversion system (WECS) using a Five-Phase Permanent Magnet Synchronous Generator (FP-PMSG). The proposed approach combines the second-order terminal sliding mode control technique (SO-STA) with the super-twisting algorithm (STA), with the main goal of benefitting from both their advantages while addressing their limitations. Indeed, the sole application of the SO-STA ensures rapid convergence and robust performances in nonlinear systems, but it leads to chattering and reduces the whole system’s efficiency. Therefore, by incorporating the STA, the obtained hybrid control can mitigate this issue by ensuring smoother control actions and a superior dynamic response. This designed hybrid control strategy improves the adaptability of the control system to wind fluctuations and enhances the system’s robustness against external disturbances and uncertainties, leading to higher reliability and efficiency in the wind energy conversion system. Furthermore, the proposed hybrid control allows optimizing the power extraction and boosting the WECS’s efficiency. It is worth clarifying that, besides this proposed control, a sliding mode controller is used for the grid side converter (GSC) and DC link voltage to ensure stable power transfer to the grid. The obtained simulation results demonstrate the effectiveness of the proposed strategy in improving the stability, robustness, and efficiency of the studied WECS under dynamic conditions, creating a promising solution for control in renewable energy systems operating under severe conditions. Full article

A fuzzy cascaded PI−PD (FCPIPD) controller is proposed in this paper to optimize load frequency control (LFC) in the linked electrical network. The FCPIPD controller is composed of fuzzy logic, proportional integral, and proportional derivative with filtered derivative mode controllers. Utilizing renewable energy sources (RESs), a dual-area hybrid AC/DC electrical network is used, and the FCPIPD controller gains are designed via secretary bird optimization algorithm (SBOA) with aid of a novel objective function. Unlike the conventional objective functions, the proposed objective function is able to specify the desired LFCs response. Under different load disturbance situations, a comparison study is conducted to compare the performance of the SBOA-based FCPIPD controller with the one-to-one (OOBO)-based FCPIPD controller and the earlier LFC controllers published in the literature. The simulation’s outcomes demonstrate that the SBOA-FCPIPD controller outperforms the existing LFC controllers. For instance, in the case of variable load change and variable RESs profile, the SBOA-FCPIPD controller has the best integral time absolute error (ITAE) value. The SBOA-FCPIPD controller’s ITAE value is 0.5101, while sine cosine adopted an improved equilibrium optimization algorithm-based adaptive type 2 fuzzy PID controller and obtained 4.3142. Furthermore, the work is expanded to include electric vehicle (EV), high voltage direct current (HVDC), generation rate constraint (GRC), governor dead band (GDB), and communication time delay (CTD). The result showed that the SBOA-FCPIPD controller performs well when these components are equipped to the system with/without reset its gains. Also, the work is expanded to include a four-area microgrid system (MGS), and the SBOA-FCPIPD controller excelled the SBOA-CPIPD and SBOAPID controllers. Finally, the SBOA-FCPIPD controller showed its superiority against various controllers for the two-area conventionally linked electrical network. Full article

Although the smart grid, equipped with situational awareness and contextual understanding, represents the future of energy management and offers flexible, extensible, and adaptable intelligent grid services, it still shares similarities with traditional systems. For instance, the control performance of the DC (Direct Current) bus voltage will continue to be adversely affected by various uncertain interference factors in the future smart grid. In practice, this often leads to challenges, as inverters typically operate at high frequencies when connected to the grid. Therefore, the ability to effectively suppress fluctuations in DC bus voltage and mitigate their impact, as well as enhance the dynamic performance of the system, will be one of the key indicators for evaluating the upcoming smart grid. Consequently, this paper proposes DC-link Voltage Control using a two-stage Extended State Observer (ESO)-Cascaded Topology Structure in an LCL (Inductive-Capacitive-Inductive) Filtered Photovoltaic Grid-Connected Inverter based on Padé Approximation and Improved Active Disturbance Rejection Control. Results from both simulations and experiments demonstrate that the proposed algorithm performs effectively and is capable of suppressing fluctuations. Full article

Modern electrical power networks make extensive use of high voltage direct current transmission systems based on voltage source converters due to their advantages in terms of both cost and flexibility. Moreover, incorporating a direct current link adds more complexity to the optimal power flow computation. This paper presents a new meta-heuristic technique, named self-adaptive bonobo optimizer, which is an improved version of bonobo optimizer. It aims to solve the optimal power flow for alternating current power systems and hybrid systems AC/DC, to find the optimal location of the high voltage direct current line in the network, with a view to minimize the total generation costs and the total active power transmission losses. The self-adaptive bonobo optimizer was tested on the IEEE 30-bus system, and the large-scale Algerian 114-bus electric network. The obtained results were assessed and contrasted with those previously published in the literature in order to demonstrate the effectiveness and potential of the suggested strategy. Full article

The switched reluctance motor (SRM) has many merits, such as robustness, a simple construction, low cost, and no permanent magnets. However, its deployment in servo applications is restrained due to acoustic noise and torque ripple (TR). This paper presents a new torque control approach for TR reduction in switched reluctance drives. The approach is based on the maximum utilisation of the available dc-link voltage, hence extending the zero torque-ripple speed range. The approach is suitable for an SRM with any number of phases and stator/rotor poles. Soft switching control is deployed, which reduces switching losses. At any instant (regardless of the number of phases being conducted simultaneously), only one phase current is controlled. The well-established torque-sharing function concept is adapted and generalised to cater for more than two phases conducting simultaneously. MATLAB/Simulink confirmation simulations are based on the widely studied four-phase 8/6, 4 kW, 1500 rpm SRM. Full article

The voltage source converter-based multi-terminal DC transmission (VSC-MTDC) system can use additional frequency control to respond to the frequency change of faulty AC system. However, the control coefficient of traditional additional frequency control is mostly fixed, and the control flexibility is insufficient, so it cannot be adjusted adaptively according to the frequency change of the system. Therefore, a frequency control strategy of the VSC-MTDC system based on fuzzy logic control is proposed. Based on the DC voltage slope controller, this strategy introduces an additional frequency controller based on fuzzy logic control, takes the frequency deviation and frequency change rate as the additional controller input, and dynamically adjusts the control quantity through the fuzzy logic control link to realize the adaptive adjustment of the VSC-MTDC system to the AC system’s frequency. Finally, a three-terminal flexible HVDC system is built on the PSCAD/EMTDC simulation platform for simulation verification. The results show that the proposed control strategy can effectively use the flexible DC system to support the frequency of the AC system and significantly improve the frequency stability of the faulty AC system. Full article

This article presents a second-order adaptive fuzzy logic controller (SO-AFLC) to improve the performance of a grid-connected double-fed induction generator (DFIG) in an oscillating water column power plant (OWCPP). The proposed SO-AFLC was used to improve the maximum power point tracking (MPPT), DC link voltage stability, and reactive power tracking for the DFIG oscillating water column power plant. The SO-AFLC reduces oscillations, overshooting, and mean square error. The SO-AFLC improved the mean square error by 40.4% in comparison to the adaptive fuzzy logic controller (AFLC) and by 84.9% in comparison to the proportional–integral differential controllers (PIDs). To validate the simulation results, an experimental investigation was performed on the Dspace DS 1104 control board. The SO-AFLC shows a faster response time, reduced undershooting, lower peak overshooting, and very low steady-state error in terms of DC link voltage, rotor speed, and maximum power point tracking. Moreover, the integral absolute error (IAE) index of the oscillating water column turbine was calculated. This index is meant to evaluate the SO-AFLC’s feasibility against the PID and AFLC under the same wave conditions. Full article

A bidirectional dc–dc converter is used to match the voltage levels between a low-voltage battery and a high-voltage traction machine in an electric vehicle. Using a conventional bidirectional converter with a standard voltage range, there is a limitation to the fine variation in the electric vehicle speed. During the regenerative braking process, when the speed decreases below a certain value, the generated voltage is insufficient to charge the battery, hence the regenerated energy cannot be stored. This paper proposes a novel bidirectional converter featuring three distinct operational modes: boost, buck and buck-boost. In the normal driving mode, it operates as a boost converter, providing double gain and accommodating a wide voltage range. During regenerative braking, the proposed converter switches to the buck or buck-boost mode based on the control algorithm. This adaptation is intended to either decrease the generated voltage to charge the battery effectively or to raise the voltage if it is insufficient for charging the battery. This configuration provides voltage stress of half the dc link voltage on the switches. This paper provides a comprehensive analysis of the proposed circuit, a detailed description of the control strategy with pulse generation logic for all switches and a mode transition algorithm. The simulation results of a circuit operating at a 1500 W power level are presented and compared with those of a standard bidirectional converter. Full article

To ensure fast dynamics and the stability of multiple distributed generator units (DGUs) in DC microgrids, communication links among the controllers of DGUs are generally adopted. However, those communication channels are vulnerable to cyber-attacks. To alleviate this hassle, a Kalman Filter (KF)-based distributed cyber-attack mitigation strategy, which is highly involved in both primary and secondary control, is proposed in this paper. The KF, as a robust state estimator, is utilized to accurately estimate the authentic terminal voltages and currents of the DGUs. Based on the discrepancies between the estimated and measured parameters of the systems under cyber-attacks, the proposed control can adaptively compensate the attack signals via an adaptive proportional integral (API) controller and a fractional API (FAPI) controller in cyber-attack-mitigation layers. The main advantage of using the proposed control scheme compared to conventional schemes is the fast dynamic response. The simulation results verify this merit by comparing the adopted KF and comparing it with conventional artificial neural networks (ANN), while the experimental results validate that effectiveness of the proposed control and showcase the superiority of the FAPI control in terms of its perfect compensation for different types of cyber-attacks. Full article

The paper presents a grid-connected microgrid with a photovoltaic system and a battery as a storage element. The optimal design and control of storage elements and power quality improvement are enhanced using sigmoid-function-based variable step size (SFB-VSS) adaptive LMS control. The DC-link voltage and battery current are enhanced using an ILA-optimization-based PI controller. Comparative analysis shows that an ILA-optimized PI controller improves battery stress and DC-link voltage fluctuations, enhancing overall system stability. The relative percentage error of V_dc is only 0.5714% for ILA-optimized values as compared to GA, PSO, and manually tuned PI gains which are 0.857%, 1.14285%, and 0.86%, respectively. ILA-optimized parameters also enhance battery current, reducing stress on the battery. The system was studied under various dynamic conditions, achieving power balance in all conditions. The system has the capability of seamless transfer of control from GC mode to SA mode when the grid is disconnected. The proposed VSC control shows better performance in steady-state and dynamic conditions, maintaining a THD under 5%, which follows IEEE standard 519, and providing better DC offset rejection, fewer oscillations in the weight component of the load, and better convergence. The proposed control also enhances the frequency of the grid, ensuring a smooth transition between modes. The system is simulated in the MATLAB Simulink environment, and all the optimization techniques were carried out offline. Full article
