Search Results (203)

Search Parameters:
Keywords = Ultra-Wide Bandwidth

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 1145 KiB
Article
Non-Iterative Reconstruction and Selection Network-Assisted Channel Estimation for mmWave MIMO Communications
by Jing Yang, Yabo Guo, Xinying Guo and Pengpeng Wang
Sensors 2025, 25(13), 4172; https://doi.org/10.3390/s25134172 - 4 Jul 2025
Viewed by 243
Abstract
Millimeter-wave (mmWave) MIMO systems have emerged as a key enabling technology for next-generation wireless networks, addressing the growing demand for ultra-high data rates through the utilization of wide bandwidths and large-scale antenna configurations. Beyond communication capabilities, these systems offer inherent advantages for integrated [...] Read more.
Millimeter-wave (mmWave) MIMO systems have emerged as a key enabling technology for next-generation wireless networks, addressing the growing demand for ultra-high data rates through the utilization of wide bandwidths and large-scale antenna configurations. Beyond communication capabilities, these systems offer inherent advantages for integrated sensing applications, particularly in scenarios requiring precise object detection and localization. The sparse mmWave channel in the beamspace domain allows fewer radio-frequency (RF) chains by selecting dominant beams, boosting both communication efficiency and sensing resolution. However, existing channel estimation methods, such as learned approximate message passing (LAMP) networks, rely on computationally intensive iterations. This becomes particularly problematic in large-scale system deployments, where estimation inaccuracies can severely degrade sensing performance. To address these limitations, we propose a low-complexity channel estimator using a non-iterative reconstruction network (NIRNet) with a learning-based selection matrix (LSM). NIRNet employs a convolutional layer for efficient, non-iterative beamspace channel reconstruction, significantly reducing computational overhead compared to LAMP-based methods, which is vital for real-time sensing. The LSM generates a signal-aware Gaussian measurement matrix, outperforming traditional Bernoulli matrices, while a denoising network enhances accuracy under low SNR conditions, improving sensing resolution. Simulations show the NIRNet-based algorithm achieves a superior normalized mean squared error (NMSE) and an achievable sum rate (ASR) with lower complexity and reduced training overhead. Full article
Show Figures

Figure 1

16 pages, 5292 KiB
Article
A Large-Bandwidth Electro-Optic Modulator with U-T Double-Layer Traveling-Wave Electrode Structure Based on Thin-Film Lithium Niobate
by Yuxiang Hao, Haiou Li, Yue Li, Haisheng Li, Yingbo Liu, Jiayu Yang and Liangpeng Qin
Photonics 2025, 12(7), 648; https://doi.org/10.3390/photonics12070648 - 26 Jun 2025
Viewed by 416
Abstract
Thin-film lithium niobate (TFLN) electro-optic modulators serve as critical components in microwave photonic systems. To improve device performance, we developed a U-T double-layer traveling-wave electrode configuration. Using finite element analysis, we systematically simulated and optimized both modulation efficiency and radiofrequency characteristics, ultimately realizing [...] Read more.
Thin-film lithium niobate (TFLN) electro-optic modulators serve as critical components in microwave photonic systems. To improve device performance, we developed a U-T double-layer traveling-wave electrode configuration. Using finite element analysis, we systematically simulated and optimized both modulation efficiency and radiofrequency characteristics, ultimately realizing a low half-wave voltage-length product of 1.77 V·cm, a minimal optical loss of 0.022 dB/cm, and an ultra-wide modulation bandwidth surpassing 100 GHz. Full article
Show Figures

Figure 1

17 pages, 7617 KiB
Article
Design of an Ultra-High-Frequency Through-Core Current Transformer for Cable Partial Discharge Detection
by Hongjing Liu, Hongda Li, Nan He, Jingzhu Teng, Baoqin Cao, Wang Miao, Ruonan Bai, Xianglong Li and Chunjia Gao
Electronics 2025, 14(13), 2547; https://doi.org/10.3390/electronics14132547 - 24 Jun 2025
Viewed by 282
Abstract
Aiming at the problem of the through-core current sensor based on cable partial discharge detection having difficulty in compatibility with high sensitivity and wide detection frequency band, this paper proposes a design method for an ultra-high-frequency through-core current sensor. Firstly, the sensor circuit [...] Read more.
Aiming at the problem of the through-core current sensor based on cable partial discharge detection having difficulty in compatibility with high sensitivity and wide detection frequency band, this paper proposes a design method for an ultra-high-frequency through-core current sensor. Firstly, the sensor circuit model was established, and the relationship between the sensor hardware parameters, and the bandwidth and sensitivity was derived. Subsequently, a multi-objective particle swarm optimization model was established. The sensitivity and bandwidth were taken as the objective functions, and the hardware parameters were regarded as the decision variables. Constraint conditions were set according to the cable size, self-integration working mode, etc. The optimal hardware parameters were obtained through solution and calculation. Finally, an ultra-high-frequency through-core current sensor was fabricated, and the bandwidth and sensitivity of the sensor at different frequencies were tested. The test results of cable partial discharge signals demonstrate that the designed sensor maintains a sensitivity of no less than 20.46 V/A within the 3 MHz to 200 MHz frequency range. This performance not only satisfies the fundamental sensitivity requirement of 5 V/A in the 3–30 MHz band for cable partial discharge detection but also resolves the inherent trade-off between sensitivity and detection bandwidth, exhibiting superior performance compared to conventional sensors. Full article
Show Figures

Figure 1

18 pages, 7017 KiB
Article
Buck Converter with Improved Efficiency and Wide Load Range Enabled by Negative Level Shifter and Low-Power Adaptive On-Time Controller
by Xuan Thanh Pham, Minh Tan Nguyen, Cong-Kha Pham and Kieu-Xuan Thuc
Electronics 2025, 14(12), 2425; https://doi.org/10.3390/electronics14122425 - 13 Jun 2025
Viewed by 548
Abstract
This paper introduces a high-efficiency buck converter designed for a wide load range, targeting low-power applications in medical devices, smart homes, wearables, IoT, and technology utilizing WiFi and Bluetooth. To achieve high efficiency across varying loads, the proposed converter employs a low-power adaptive [...] Read more.
This paper introduces a high-efficiency buck converter designed for a wide load range, targeting low-power applications in medical devices, smart homes, wearables, IoT, and technology utilizing WiFi and Bluetooth. To achieve high efficiency across varying loads, the proposed converter employs a low-power adaptive on-time (AOT) controller that ensures output voltage stability and seamless mode transitions. An adaptive comparator (ACP) with variable output impedance is introduced, offering a variable DC gain and bandwidth to be suitable for different load conditions. A negative-level shifter (NLS) circuit, with its swing ranging from −0.5 V to the battery voltage (VBAT), is proposed to control the smaller power p-MOS transistors. By using an NLS, the chip area, which is mostly occupied by power CMOS transistors, is reduced while the power efficiency is improved, particularly under a heavy load. A status time detector (STD) block which provides control signals to the ACP and NLS for optimized power consumption is added to identify load conditions (heavy, light, ultra-light). By employing a 180 nm CMOS technology, the active chip area occupies about 0.31 mm2. With an input voltage range of 2.8–3.3 V, the controller’s current consumption ranges from 1.2 μA to 16 μA, corresponding to the output load current varying from 12 μA to 120 mA. Although the output load can vary, the output voltage is regulated at 1.2 V with a ripple between 3 and 12 mV. The proposed design achieves a peak efficiency of 96.2% under a heavy load with a switching frequency of 1.3 MHz. Full article
(This article belongs to the Section Microelectronics)
Show Figures

Figure 1

12 pages, 4302 KiB
Article
Design of Ultra-Wideband Low RCS Antenna Based on Polarization Conversion Metasurface
by Haiqing Guo, Ye Zhao, Jiangwei Li, Rui Gao, Zhihui He and Zhimin Yang
Electronics 2025, 14(11), 2204; https://doi.org/10.3390/electronics14112204 - 29 May 2025
Viewed by 332
Abstract
An ultra-wideband and radar cross-section (RCS) antenna array based on polarization conversion metasurface (PCM) is proposed. Firstly, the PCM unit is proposed, and its performance is analyzed. In terms of radiation performance, the −10 dB impedance matching bandwidth of the PCM unit is [...] Read more.
An ultra-wideband and radar cross-section (RCS) antenna array based on polarization conversion metasurface (PCM) is proposed. Firstly, the PCM unit is proposed, and its performance is analyzed. In terms of radiation performance, the −10 dB impedance matching bandwidth of the PCM unit is 8.5–30.2 GHz (a relative bandwidth of 112.1%) and the polarization conversion ratio (PCR) is higher than 90%. In terms of scattering performance, the antenna achieves more than 10 dB RCS reduction in the band of 8.35–30.45 GHz (a relative bandwidth of 113.9%). Secondly, the PCM unit is combined with the microstrip antenna, and its performance is analyzed: the gain of the microstrip antenna is increased by 2.8 dB at 19.5 GHz compared to the antenna without the PCM, and the low-RCS antenna array achieves RCS reduction over 6 dB within the frequency range of 8.3–31.7 GHz (a relative bandwidth of 117%). The antenna array has the advantages of wide bandwidth, high gain, and low RCS. It can be used for radars, aircraft, and stealth platforms. Full article
Show Figures

Figure 1

19 pages, 8477 KiB
Article
Wideband Dual-Polarized PRGW Antenna Array with High Isolation for Millimeter-Wave IoT Applications
by Zahra Mousavirazi, Mohamed Mamdouh M. Ali, Abdel R. Sebak and Tayeb A. Denidni
Sensors 2025, 25(11), 3387; https://doi.org/10.3390/s25113387 - 28 May 2025
Viewed by 636
Abstract
This work presents a novel dual-polarized antenna array tailored for Internet of Things (IoT) applications, specifically designed to operate in the millimeter-wave (mm-wave) spectrum within the frequency range of 30–60 GHz. Leveraging printed ridge gap waveguide (PRGW) technology, the antenna ensures robust performance [...] Read more.
This work presents a novel dual-polarized antenna array tailored for Internet of Things (IoT) applications, specifically designed to operate in the millimeter-wave (mm-wave) spectrum within the frequency range of 30–60 GHz. Leveraging printed ridge gap waveguide (PRGW) technology, the antenna ensures robust performance by eliminating parasitic radiation from the feed network, thus significantly enhancing the reliability and efficiency required by IoT communication systems, particularly for smart cities, autonomous vehicles, and high-speed sensor networks. The proposed antenna achieves superior radiation characteristics through a cross-shaped magneto-electric (ME) dipole backed by an artificial magnetic conductor (AMC) cavity and electromagnetic bandgap (EBG) structures. These features suppress surface waves, reduce edge diffraction, and minimize back-lobe emissions, enabling stable, high-quality IoT connectivity. The antenna demonstrates a wide impedance bandwidth of 24% centered at 30 GHz and exceptional isolation exceeding 40 dB, ensuring interference-free dual-polarized operation crucial for densely populated IoT environments. Fabrication and testing validate the design, consistently achieving a gain of approximately 13.88 dBi across the operational bandwidth. The antenna’s performance effectively addresses the critical requirements of emerging IoT systems, including ultra-high data throughput, reduced latency, and robust wireless connectivity, essential for real-time applications such as healthcare monitoring, vehicular communication, and smart infrastructure. Full article
(This article belongs to the Special Issue Design and Measurement of Millimeter-Wave Antennas)
Show Figures

Figure 1

15 pages, 3629 KiB
Article
Photonic-Aid Flexible Frequency-Hopping Signal Generator Based on Optical Comb Filtering
by Yixiao Zhou, Xuan Li, Shanghong Zhao, Guodong Wang, Ruiqiong Wang, Jialin Ma and Zihang Zhu
Photonics 2025, 12(6), 539; https://doi.org/10.3390/photonics12060539 - 26 May 2025
Viewed by 355
Abstract
A novel photonics-assisted technique for generating reconfigurable frequency hopping (FH) signals is proposed and demonstrated through optical comb filtering (OCF). The arithmetic progression of frequency difference between OCF passbands and optical frequency comb lines is exploited to enable wavelength selection controlled by an [...] Read more.
A novel photonics-assisted technique for generating reconfigurable frequency hopping (FH) signals is proposed and demonstrated through optical comb filtering (OCF). The arithmetic progression of frequency difference between OCF passbands and optical frequency comb lines is exploited to enable wavelength selection controlled by an intermediate frequency signal, with ultra-wideband FH signals subsequently being generated through optical heterodyning. Comprehensive theoretical and numerical investigations are conducted, demonstrating the successful generation of diverse FH waveforms including 5-, 10-, and 25-level stepped frequency signals, Costas-coded patterns, as well as complex wideband signals such as 30 GHz linear frequency modulated and 24 GHz sinusoidal chirped waveforms. Critical system considerations including laser frequency stability, FH speed, and parameter optimization are examined. Wide tunable bandwidth exceeding 30 GHz, good stability, and inherent compatibility with photonic integration is achieved, showing significant potential for advanced applications in cognitive radio and modern radar systems where high-performance frequency-agile signal generation is required. Full article
(This article belongs to the Section Optoelectronics and Optical Materials)
Show Figures

Figure 1

14 pages, 5328 KiB
Article
Design of a Novel Ultra-Wideband Antipodal Vivaldi Antenna Based on Klopfenstein Curve
by Yanxing Zhang and Jinling Zhang
Microwave 2025, 1(1), 4; https://doi.org/10.3390/microwave1010004 - 21 May 2025
Viewed by 865
Abstract
We propose a new ultra-wideband antipodal Vivaldi antenna design based on the Klopfenstein curve, incorporating exponential slots, horns, and apertures to improve the antenna’s return loss and increase its gain in high-frequency bands. The antenna achieves high gain and wide bandwidth characteristics, with [...] Read more.
We propose a new ultra-wideband antipodal Vivaldi antenna design based on the Klopfenstein curve, incorporating exponential slots, horns, and apertures to improve the antenna’s return loss and increase its gain in high-frequency bands. The antenna achieves high gain and wide bandwidth characteristics, with measured −10 dB bandwidth ranging from 2 GHz to 20 GHz, maximum gain of 14 dBi, and gain exceeding 10 dBi from 3.5 GHz to 14 GHz. Full article
Show Figures

Graphical abstract

17 pages, 3364 KiB
Article
Ultra-Wideband Antenna Design for 5G NR Using the Bezier Search Differential Evolution Algorithm
by Georgios Korompilis, Achilles D. Boursianis, Panagiotis Sarigiannidis, Zaharias D. Zaharis, Katherine Siakavara, Maria S. Papadopoulou, Mohammad Abdul Matin and Sotirios K. Goudos
Technologies 2025, 13(4), 133; https://doi.org/10.3390/technologies13040133 - 1 Apr 2025
Cited by 1 | Viewed by 475
Abstract
As the energy crisis is leading to energy shortages and constant increases in prices, green energy and renewable energy sources are trending as a viable solution to this problem. One of the most rapidly expanding green energy methods is RF (RadioFrequency) energy harvesting, [...] Read more.
As the energy crisis is leading to energy shortages and constant increases in prices, green energy and renewable energy sources are trending as a viable solution to this problem. One of the most rapidly expanding green energy methods is RF (RadioFrequency) energy harvesting, as RF energy and its corresponding technologies are constantly progressing, due to the introduction of 5G and high-speed telecommunications. The usual system for RF energy harvesting is called a rectenna, and one of its main components is an antenna, responsible for collecting ambient RF energy. In this paper, the optimization process of an ultra-wideband antenna for RF energy harvesting applications was studied, with the main goal of broadening the antenna’s operational bandwidth to include 5G New Radio. For this purpose, the Bezier Search Differential Evolution Algorithm (BeSD) was used along with a novel CST-Matlab API, to manipulate the degrees of freedom of the antenna, while searching for the optimal result, which would satisfy all the necessary dependencies to make it capable of harvesting RF energy in the target frequency band. The BeSD algorithm was first tested with benchmark functions and compared to other widely used algorithms, which it successfully outperformed, and hence, it was selected as the optimizer for this research. All in all, the optimization process was successful by producing an ultra-wideband optimal antenna operating from 1.4 GHz to 3.9 GHz, which includes all vastly used telecommunication technologies, like GSM (1.8 GHz), UMTS (2.1 GHz), Wi-Fi (2.4 GHz), LTE (2.6 GHz), and 5G NR (3.5 GHz). Its ultra-wideband properties and the rest of the characteristics that make this design suitable for RF energy harvesting are proven by its S11 response graph, its impedance response graph, its efficiency on the targeted technologies, and its omnidirectionality across its band of operation. Full article
Show Figures

Figure 1

17 pages, 6781 KiB
Article
A Transparent and Flexible Absorber for Electromagnetic Interference Suppression, Designed for 5G Communication and Sub-6G Applications
by Senfeng Lai, Huiyuan Fu, Junxian Tan, Jingyi Luo and Bingye Zhou
Electronics 2025, 14(7), 1350; https://doi.org/10.3390/electronics14071350 - 28 Mar 2025
Viewed by 785
Abstract
As 5G technology rapidly advances, the extension of spectrum into millimeter-wave bands enables higher data speeds and reduced latency. However, this frequency expansion introduces significant electromagnetic interference (EMI) issues, particularly in environments with dense equipment and base stations. To tackle these challenges, this [...] Read more.
As 5G technology rapidly advances, the extension of spectrum into millimeter-wave bands enables higher data speeds and reduced latency. However, this frequency expansion introduces significant electromagnetic interference (EMI) issues, particularly in environments with dense equipment and base stations. To tackle these challenges, this paper presents a multilayer transparent ultra-wideband microwave absorber (MA) using indium tin oxide (ITO) that operates between 4 and 26 GHz. This optimized MA design successfully achieves absorption from 4.07 to 25.07 GHz, encompassing both the 5G Sub-6 GHz and n258 bands, with a relative bandwidth of 144% and a minimal thickness of 0.129λL (where λL is the free-space wavelength at the lowest cutoff frequency). For TE and TM polarization with incidence angles ranging from 0° to 45°, the MA demonstrates exceptional performance, maintaining a relative bandwidth exceeding 120%. Notably, for TM polarization with incidence angles between 60° and 70°, the MA can sustain an absorption capacity with a relative bandwidth greater than 100%. By integrating the principles of impedance matching, surface current theory, and equivalent circuit simulation fitting, the absorption mechanism is further analyzed, thereby confirming the reliability of the design. This design offers exceptional wideband absorption, optical transparency, and wide-angle incidence characteristics, demonstrating great potential for applications in electromagnetic stealth, EMI suppression, and electromagnetic compatibility (EMC) in 5G communications. Full article
Show Figures

Figure 1

20 pages, 2546 KiB
Article
A Nonlinear Compensation Method for Enhancing the Detection Accuracy of Weak Targets in FMCW Radar
by Bo Wang, Tao Lai, Qingsong Wang and Haifeng Huang
Remote Sens. 2025, 17(5), 829; https://doi.org/10.3390/rs17050829 - 27 Feb 2025
Cited by 1 | Viewed by 772
Abstract
To achieve precise detection of target geometric features, Ka/W/sub-terahertz band imaging radar systems with ultra-wide instantaneous bandwidth have been developed. Although dechirp-based receiver architectures allow for low-sampling-rate signal acquisition, they require precise linearity in chirp signals, often necessitating precompensation for nonlinear errors. While [...] Read more.
To achieve precise detection of target geometric features, Ka/W/sub-terahertz band imaging radar systems with ultra-wide instantaneous bandwidth have been developed. Although dechirp-based receiver architectures allow for low-sampling-rate signal acquisition, they require precise linearity in chirp signals, often necessitating precompensation for nonlinear errors. While most research addresses polynomial-based error correction, periodic errors remain underexplored, despite their potential to obscure weak targets and introduce spurious ones. This paper proposes a novel software-based correction method that integrates neural networks and joint optimization strategies to correct periodic phase errors. The method first employs neural networks for frequency estimation, followed by phase-matching techniques to extract amplitude and phase data. Parameter estimation is refined using the Adaptive Moment Estimation (ADAM) algorithm and Limited-Memory Broyden–Fletcher–Goldfarb–Shanno (LBFGS) optimization. Nonlinear errors are corrected via matched Fourier transforms. Simulations and experiments demonstrate that the proposed method effectively suppresses spurious targets and enhances the detection of weak targets, demonstrating strong robustness and practical applicability, thereby significantly enhancing the target detection performance of the ultra-wideband radar system. Full article
Show Figures

Figure 1

32 pages, 9855 KiB
Review
A Review of Circuits and Systems for Advanced Sub-THz Transceivers in Wireless Communication
by Runzhou Chen, Boxun Yan and Mau-Chung Frank Chang
Electronics 2025, 14(5), 861; https://doi.org/10.3390/electronics14050861 - 21 Feb 2025
Viewed by 2596
Abstract
Sub-terahertz (sub-THz) frequencies (100–300 GHz) are gaining prominence in the development of next-generation wireless communication systems, promising ultra-high data rates and wide bandwidths essential for applications like 6G networks and beyond. Despite the immense potential of these frequencies, several design and implementation challenges [...] Read more.
Sub-terahertz (sub-THz) frequencies (100–300 GHz) are gaining prominence in the development of next-generation wireless communication systems, promising ultra-high data rates and wide bandwidths essential for applications like 6G networks and beyond. Despite the immense potential of these frequencies, several design and implementation challenges remain, especially in transceiver architectures, high-order modulation, and beam-forming capabilities. In this paper, we survey recent advances in sub-THz transceiver design, with a particular focus on D-band frequencies. We explore the latest developments in circuit performance and architectures, including innovative transmitter and receiver designs that utilize direct-digital modulation (and demodulation) and phased-array systems. To ensure a comprehensive and up-to-date analysis, this work selects over 100 data points from top-tier conferences and journals, with most publications dating within the past five years, reflecting the state of the art in the field. Meanwhile, we discuss practical challenges, future directions, and opportunities to optimize sub-THz systems for high-speed, high-capacity wireless communication. Full article
(This article belongs to the Special Issue Feature Review Papers in Electronics)
Show Figures

Figure 1

23 pages, 8687 KiB
Article
A Low-Voltage Low-Power Voltage-to-Current Converter with Low Temperature Coefficient Design Awareness
by Haoze Chen and Pak Kwong Chan
Sensors 2025, 25(4), 1204; https://doi.org/10.3390/s25041204 - 16 Feb 2025
Cited by 1 | Viewed by 720
Abstract
This paper presents a low-voltage, low-power voltage-to-current converter (V-I Converter) implemented in TSMC 40 nm CMOS technology. Operating at a supply voltage of 0.45 V with an input range of 0.1 V to 0.3 V, the proposed circuit achieves a temperature coefficient of [...] Read more.
This paper presents a low-voltage, low-power voltage-to-current converter (V-I Converter) implemented in TSMC 40 nm CMOS technology. Operating at a supply voltage of 0.45 V with an input range of 0.1 V to 0.3 V, the proposed circuit achieves a temperature coefficient of 54.68 ppm/°C, which is at least 2× better than prior works, ensuring stable performance across a wide temperature range (−20 °C to 80 °C). The design employs a three-stage operational transconductance amplifier (OTA) with a Q-reduction frequency compensation technique to produce programmable output currents while maintaining a power dissipation of less than 2.76 μW. With a bandwidth of 34.45 kHz and a total harmonic distortion (THD) of −56.66 dB at 1 kHz and 0.1 VPP input signal, the circuit demonstrates high linearity and low power consumption under ultra-low voltage design scenarios. These features make the proposed V-I Converter highly suitable for energy-constrained applications such as biomedical sensors, energy harvesting systems, and IoT nodes, where low power consumption and temperature stability are critical parameters. Full article
(This article belongs to the Special Issue Advanced Interface Circuits for Sensor Systems (Volume II))
Show Figures

Figure 1

18 pages, 7712 KiB
Article
Development of a Multi-Channel Ultra-Wideband Electromagnetic Transient Measurement System
by Shaoyin He, Xiangyu Chen, Bohao Zhang and Liang Song
Sensors 2025, 25(4), 1159; https://doi.org/10.3390/s25041159 - 14 Feb 2025
Viewed by 909
Abstract
In complex electromagnetic environments, such as substations, converter stations in power systems, and the compartments of aircraft, trains, and automobiles, electromagnetic immunity testing is crucial. It requires that the electric field sensor has features such as a large dynamic measurement range (amplitude from [...] Read more.
In complex electromagnetic environments, such as substations, converter stations in power systems, and the compartments of aircraft, trains, and automobiles, electromagnetic immunity testing is crucial. It requires that the electric field sensor has features such as a large dynamic measurement range (amplitude from hundreds of V/m to tens of kV/m), a fast response speed (response time in the order of nanoseconds or sub-nanoseconds), a wide test bandwidth (DC to 1 GHz even above), miniaturization, and robustness to strong electromagnetic interference. This paper introduces a multi-channel, ultra-wideband transient electric field measurement system. The system’s analog bandwidth covers the spectrum from DC and a power frequency of 50 Hz to partial discharge signals, from DC to 1.65 GHz, with a storage depth of 2 GB (expandable). It overcomes issues related to the instability, insufficient bandwidth, and lack of accuracy of optical fibers in analog signal transmission by using front-end digital sampling based on field-programmable gate array (FPGA) technology and transmitting digital signals via optical fibers. This approach is effectively applicable to measurements in strong electromagnetic environments. Additionally, the system can simultaneously access four channels of signals, with synchronization timing reaching 300 picoseconds, can be connected to voltage and current sensors simultaneously, and the front-end sensor can be flexibly replaced. The performance of the system is verified by means of a disconnect switch operation and steady state test in an HVDC converter station. It is effectively applicable in scenarios such as the online monitoring of transient electromagnetic environments in high-voltage power equipment, fault diagnosis, and the precise localization of radiation sources such as partial discharge or intentional electromagnetic interference (IEMI). Full article
(This article belongs to the Special Issue Magnetoelectric Sensors and Their Applications)
Show Figures

Figure 1

19 pages, 2276 KiB
Article
A Broadband Mode Converter Antenna for Terahertz Communications
by Biswash Paudel, Xue Jun Li and Boon-Chong Seet
Electronics 2025, 14(3), 551; https://doi.org/10.3390/electronics14030551 - 29 Jan 2025
Viewed by 944
Abstract
The rise of artificial intelligence (AI) necessitates ultra-fast computing, with on-chip terahertz (THz) communication emerging as a key enabler. It offers high bandwidth, low power consumption, dense interconnects, support for multi-core architectures, and 3D circuit integration. However, transitioning between different waveguides remains a [...] Read more.
The rise of artificial intelligence (AI) necessitates ultra-fast computing, with on-chip terahertz (THz) communication emerging as a key enabler. It offers high bandwidth, low power consumption, dense interconnects, support for multi-core architectures, and 3D circuit integration. However, transitioning between different waveguides remains a major challenge in THz systems. In this paper, we propose a THz band mode converter that converts from a rectangular waveguide (RWG) (WR-0.43) in TE10 mode to a substrate-integrated waveguide (SIW) in TE20 mode. The converter comprises a tapered waveguide, a widened waveguide, a zigzag antenna, and an aperture coupling slot. The zigzag antenna effectively captures the electromagnetic (EM) energy from the RWG, which is then coupled to the aperture slot. This coupling generates a quasi-slotline mode for the electric field (E-field) along the longitudinal side of the aperture, exhibiting odd symmetry akin to the SIW’s TE20 mode. Consequently, the TE20 mode is excited in the symmetrical plane of the SIW and propagates transversely. Our work details the mode transition principle through simulations of the EM field distribution and model optimization. A back-to-back RWG TE10-to-TE10 mode converter is designed, demonstrating an insertion loss of approximately 5 dB over the wide frequency range band of 2.15–2.36 THz, showing a return loss of 10 dB. An on-chip antenna is proposed which is fed by a single higher-order mode of the SIW, achieving a maximum gain of 4.49 dB. Furthermore, a balun based on the proposed converter is designed, confirming the presence of the TE20 mode in the SIW. The proposed mode converter demonstrates its feasibility for integration into a THz-band high-speed circuit due to its efficient mode conversion and compact planar design. Full article
(This article belongs to the Special Issue Broadband Antennas and Antenna Arrays)
Show Figures

Figure 1
