Search Results (39)

With the rapid development of lightweight unmanned aerial vehicles (UAVs), the combination of UAVs and ground-moving target indication (GMTI) radar systems has received great interest. However, because of size, weight, and power (SWaP) limitations, the UAV may not be able to equip a highly accurate inertial navigation system (INS), which leads to reduced accuracy in the moving target relocation. To solve this issue, we propose using an image registration algorithm, which matches a Doppler beam sharpening (DBS) image of detected moving targets to a synthetic aperture radar (SAR) image containing coordinate information. However, when using conventional SAR image registration algorithms such as the SAR scale-invariant feature transform (SIFT) algorithm, additional difficulties arise. To overcome these difficulties, we developed a new image-matching algorithm, which first estimates the errors of the UAV platform to compensate for geometric distortions in the DBS image. In addition, to showcase the relocation improvement achieved with the new algorithm, we compared it with the affine transformation and second-order polynomial algorithms. The findings of simulated and real-world experiments demonstrate that our proposed image transformation method offers better moving target relocation results under low-accuracy INS conditions. Full article

With the rapid development of lightweight unmanned aerial vehicles (UAVs), the combination of UAVs and ground moving target indication (GMTI) radar systems has received great interest. In GMTI, moving target relocation is an essential requirement, because the positions of the moving targets are usually displaced. For a multichannel radar system, the position of moving targets can be accurately obtained by estimating their interferometric phase. However, the high position accuracy requirements of antennas and the computational resource requirements of algorithms limit the applications of relocation algorithms in UAV-borne GMTI radar systems. In addition, the clutter’s interferometric phase can be severely affected by the undesired phase error in the site. To overcome these issues, we propose an improved knowledge-based (KB) algorithm. In the algorithm, moving targets can be relocated by comparing their interferometric phase with the clutter’s phase. As for the undesired phase error, the algorithm first employs a random sample consensus (RANSAC) algorithm to iteratively filter the outliers. Compared with other classic relocation algorithms, the proposed algorithm shows better relocation accuracy and can be applied in real-time applications. The performance of the proposed improved KB algorithm was evaluated using both simulated and real experimental data. Full article

In dual-channel synthetic aperture radar (SAR) systems, the estimation of the four-dimensional motion parameters of the ground maneuvering target is a critical challenge. In particular, when spatial degrees of freedom are used to enhance the target’s output signal-to-clutter-plus-noise ratio (SCNR), it is possible to have multiple solutions in the parameter estimation of the target. To deal with this issue, a novel algorithm for estimating the motion parameters of ground moving targets in dual-channel SAR systems is proposed in this paper. First, the random sample consensus (RANSAC) and modified adaptive 2D calibration (MA2DC) are used to prevent the target’s phase from being distorted as a result of channel balancing. To address range migration, the RFRT algorithm is introduced to achieve arbitrary-order range migration correction for moving targets, and the generalized scaled Fourier transform (GSCFT) algorithm is applied to estimate the polynomial coefficients of the target. Subsequently, we propose using the synthetic aperture length (SAL) of the target as an independent equation to solve for the four-dimensional parameter information and introduce a windowed maximum SNR method to estimate the SAL. Finally, a closed-form solution for the four-dimensional parameters of ground maneuvering targets is derived. Simulations and real data validate the effectiveness of the proposed algorithm. Full article

The design and optimization of sensor array configurations is a significant challenge for distributed SAR-GMTI radar systems because the system performance of distributed array radar is a comprehensive result of several conflicting evaluation indicators. This paper developed a multi-objective intelligent optimization method to solve the global optimal problem of array configurations in terms of achieving optimal GMTI performance. Firstly, to formulate the relationship between array configuration and GMTI performance, we established three objective functions derived from evaluating indicators of SAR-GMTI performance. Specifically, in the objective functions, we proposed a novel clutter covariance matrix model that added several typical non-ideal factors of the real-world detection environment. This provides a way to build a bridge between the array configuration, environment clutter, and GMTI performance. Then, we proposed an improved multi-objective snake optimization algorithm (IMOSOA) that combined the Pareto optimization mechanism with snake optimization to solve the multi-objective optimization problem while reconciling the conflicts between different objective functions. Meanwhile, some significant improvements were made to speed up convergence. That is, tent chaotic mapping-based initialization, multi-group coevolution, and individual mutation strategies were applied to solve the non-convergence problem of global searching. Finally, in the case of an airborne SAR-GMTI system, numerical experiments demonstrated that the proposed IMOSOA has superior performance than other contrast methods, especially in terms of GMTI applications. Full article

In recent years, the detection performance of SAR-GMTI (synthetic aperture radar-ground moving target indication) algorithm based on deep learning has always been limited by insufficient measured data due to the heavy operation complexity and high cost of real SAR systems. To solve this problem, this paper proposes an overall DT-based implementation framework for SAR ground moving target intelligent detection tasks. In particular, by virtue of a SAR imaging algorithm, a high-fidelity twin replica of SAR moving targets is established in digital space through parameter traversal based on the prior target characteristics of the obtained measured datasets. Then, the constructed SAR twin datasets is fed into the neural network model to train an intelligent detector by fully learning features of the moving targets and preset the SAR scene in the twin space, which can realize the robust detection of ground moving targets in related practical scenarios with no need for multiple and complex field experiments. Moreover, the effectiveness of the proposed framework is verified on the MiniSAR measured system, and a comparison with traditional CFAR detection method is given simultaneously. Full article

The spaceborne high-resolution and wide-swath synthetic aperture radar (HRWS-SAR) system combined with the ground moving target indication (GMTI) mode provides a promising prospect in the realization of wide-area target surveying and high-resolution target imaging. In this paper, a system design method is proposed for an HRWS-SAR-GMTI system with ideal reconstruction configuration. In the proposed method, the whole azimuth receiving channels are uniformly divided into multiple groups, where HRWS-SAR imaging is implemented in each sub-group and then GMTI processing is performed based on the reconstructed SAR images. Then, an optimal candidate PRF is properly selected with respect to the optimal reconstruction configuration. After that, the digital beam forming scanning on receive (DBF-SCORE) technique is applied to further enlarge the range swath and improve the noise equivalent scattering coefficient (NESZ). Based on the predesigned system, HRWS-SAR image-based GMTI processing can finally be accomplished. The effectiveness of the proposed method is validated by simulated experiments. Full article

Operating mode identification is an important prerequisite for precise deceptive jamming technology against synthetic aperture radar (SAR). In order to solve the problems of traditional spaceborne SAR operating mode identification, such as low identification accuracy, poor timeliness, and limitation to main lobe reconnaissance, an efficient identification method based on sidelobe reconnaissance and machine learning is proposed in this paper. It can identify four classical SAR operating modes, including stripmap, scan, spotlight and ground moving target indication (GMTI). Firstly, the signal models of different operating modes are presented from the perspective of sidelobe reconnaissance. By setting the parameters differently, such as the SAR trajectory height, antenna length, transmit/receive gain and loss, signal–noise ratio, and so on, the feature samples based on multiple parameters can be obtained, respectively. Then, based on the generated database of feature samples, the initialized neural network can be pre-trained. As a result, in practice, with the intercepted sidelobe signal and the pre-trained network, we can precisely infer the SAR operating mode before the arrival of the main lobe beam footprint. Finally, the effect of SNR and the jammer’s position on the identification accuracy is experimentally detailed in the simulation. The simulation results show that the identification accuracy can reach above 91%. Full article

Multi-moving-target imaging in a synthetic aperture radar (SAR) system poses a significant challenge owing to target defocusing and being contaminated by strong background clutter. Aiming at this problem, a new deep-convolutional-neural-network (CNN)-assisted method is proposed for multi-moving-target imaging in a SAR-GMTI system. The multi-moving-target signal can be modeled by a multicomponent LFM signal with additive perturbation. A fully convolutional network named MLFMSS-Net was designed based on an encoder–decoder architecture to extract the most-energetic LFM signal component from the multicomponent LFM signal in the time domain. Without prior knowledge of the target number, an iterative signal-separation framework based on the well-trained MLFMSS-Net is proposed to separate the multi-moving-target signal into multiple LFM signal components while eliminating the residual clutter. It works well, exhibiting high imaging robustness and low dependence on the system parameters, making it a suitable solution for practical imaging applications. Consequently, a well-focused multi-moving-target image can be obtained by parameter estimation and secondary azimuth compression for each separated LFM signal component. The simulations and experiments on both airborne and spaceborne SAR data showed that the proposed method is superior to traditional imaging methods in both imaging quality and efficiency. Full article

Through formation flying, the distributed spaceborne SAR(synthetic aperture radar) system can increase the number of spatial degree of freedoms (DOFs) and provide flexible multi-baselines for SAR-GMTI (ground moving target indication), which improves the system performance. This paper proposes an a priori knowledge-based adaptive clutter cancellation and moving target detection technique applied to the distributed spaceborne SAR-GMTI systems. Firstly, the adaptive clutter cancellation technique is exploited to suppress the ground clutter. A priori knowledge, such as road network information, is integrated to the adaptive clutter cancellation processor to reduce any moving target steering vector mismatch. Secondly, adaptive matched filter (AMF) and adaptive beamformer orthogonal rejection test (ABORT) are exploited as adaptive detection techniques for moving target detection. Due to the dense road network, the moving target steering vector estimation may be ambiguous for the different position and orientation of the roads. The multiple hypothesis testing (MHT) technique is proposed to detect the moving targets and resolve the potential ambiguities. A scheme is exploited to detect, classify, and relocate the moving targets. Finally, simulation experiments and performance analysis have demonstrated the effectiveness and robustness of the proposed technique. Full article

Shadow detection is a new method for video synthetic aperture radar moving target indication (ViSAR-GMTI). The shadow formed by the target occlusion will reflect its real position, preventing the defocusing or offset of the moving target from making it difficult to identify the target during imaging. To achieve high-precision shadow detection, this paper proposes a video SAR moving target shadow-detection algorithm based on low-rank sparse decomposition combined with trajectory area extraction. Based on the low-rank sparse decomposition (LRSD) model, the algorithm creates a new decomposition framework combined with total variation (TV) regularization and coherence suppression items to improve the decomposition effect, and a global constraint is constructed to suppress interference using feature operators. In addition, it cooperates with the double threshold trajectory segmentation and error trajectory elimination method to further improve the detection performance. Finally, an experiment was carried out based on the video SAR data released by Sandia National Laboratory (SNL); the results prove the effectiveness of the proposed method, and the detection performance of the method is proved by comparative experiments. Full article

Medium-Earth-orbit (MEO) synthetic aperture radar (SAR) has the advantages of short revisit time and wide coverage, and thus is a potential tool for implementing ground moving target indication (GMTI) tasks. In the paper, aiming at MEO SAR’s problems of low signal-to-noise ratio and limited computation resource, an efficient imaging method is proposed for MEO multichannel SAR-GMTI systems with relatively low resolution. The proposed imaging method is designed with the consideration of both static scenes and ground moving targets, and it can simultaneously correct the range cell migrations of static scenes and multiple moving targets of no Doppler ambiguity. It needs only four Fourier transforms and twice phase multiplications, and thus is computationally efficient. Moreover, moving targets’ signal characteristics, including the azimuth and range displacements and along-track interferometric phase, in the SAR image obtained by the proposed imaging method are figured out. Experimental results validate the proposed imaging method and the theoretical analyses. Full article

The ground moving-target indication (GMTI) technique can detect civil and military moving targets, which means that this technique has received much attention. Strong clutter background suppression is one of the critical problems in this application. However, the detection performance in heterogeneous environment can be degraded due to the inaccurate estimation of the clutter covariance matrix (CCM). In this paper, we propose a robust GMTI method using a spaceborne dual-platform synthetic aperture radar (SAR) system, which can obtain highly accurate CCM in nonuniform clutter. Firstly, the accurate CCM is estimated based on the SAR image obtained by the former platform. Then, space–time adaptive processing (STAP) is carried out using the obtained the CCM. Finally, the detection threshold is set according to the estimated CCM and detection is executed accurately. Compared with the traditional CCM estimation method in STAP using the clutter nearby the cell under test, this method directly estimates the CCM using the clutter of the cell under test, which can avoid CCM estimation mistakes in heterogeneous clutter environment. The clutter can be whitened and depressed more effectively. Additionally, with the accurate threshold acquired from the CCM, the detection probability can be effectively improved under a certain false-alarm criterion. Based on simulation data, GMTI experiments in a heterogeneous environment such as clutter with strong pollution, junction zone of hot and cold clutter, and clutter with nonuniform power are carried out; the results show that the moving targets can be effectively detected with the proposed method. Full article

Ground moving targets with slow velocity and low radar cross-section (RCS) are usually embedded in the clutter Doppler spectrum. To achieve the detection and estimation of such targets, a novel method operating in the range-Doppler domain is developed for airborne multichannel radar systems. The interferometric phases that are sensitive to moving targets are obtained by coherent difference processing (CDP) for target detection. Moreover, the amplitude is utilized as complementary information to improve the detection performance. Then, a matched filter bank is designed and applied to the CDP processed data to complete the parameter estimation. The proposed method provides the benefits of high efficiency and robustness, since it does not involve matrix inversion, and it does not require homogeneous clutter assumption unlike adaptive algorithms. Experiments on real data acquired by an airborne X-band four-channel radar system demonstrate its effectiveness. Full article

Circular synthetic aperture radar (CSAR), which can observe the region of interest for a long time and from multiple angles, offers the opportunity for moving-target detection (MTD). However, traditional MTD methods cannot effectively solve the problem of high probability of false alarm (PFA) caused by strong clutter. To mitigate this, a novel, three-step scheme combining clutter background extraction, multichannel clutter suppression, and the degree of linear consistency of radial velocity interferometric phase (DLRVP) test is proposed. In the first step, the spatial similarity of the scatterers and the correlation between sub-aperture images are fused to extract the strong clutter mask prior to clutter suppression. In the second step, using the data remaining after elimination of the background clutter in Step 1, an amplitude-based detector with higher processing gain is utilized to detect potential moving targets. In the third step, a novel test model based on DLRVP is proposed to further reduce the PFA caused by isolated strong scatterers. After the above processing, almost all false alarms are excluded. Measured data verified that the PFA of the proposed method is only 20% that of the comparison method, with improved detection of slow and weakly moving targets and with better robustness. Full article

Moving targets are usually smeared and imaged at incorrect positions in synthetic aperture radar (SAR) images due to the target motions during the illumination time. Moreover, a moving target will cause multiple artifacts in the reconstructed image since pulse repetition frequency (PRF) operated in high-resolution wide-swath (HRWS) SAR is very low. In order to reliably indicate moving targets, a robust cancellation algorithm is derived in this paper for clutter suppression in multichannel HRWS SAR, which is free by velocity searching and covariance matrix estimation of clutter plus noise. The proposed multilayer channel-cancellation combined with the deramp processing is designed to sequentially suppress the seriously aliased clutter in HRWS SAR. Experimental results show that the proposed algorithm is efficient and robust in tough situations, and have a superior detection ability in weak targets and low-velocity targets. In addition, the radial velocity estimation algorithm combined with the channel cancellation is exploited to relocate moving targets. The effectiveness of the proposed algorithms is validated by actual spaceborne SAR data acquired by a coordination experiment with two controllable vehicles. Full article
