Accurate cloud detection is critical for quantitative applications of satellite-based advanced imager observations, yet nighttime cloud detection presents challenges due to the lack of visible and near-infrared spectral information. Nighttime cloud detection using infrared (IR)-only information needs to be improved. Based on a collocated dataset from Fengyun-3D Medium Resolution Spectral Imager (FY-3D MERSI) Level 1 data and CALIPSO CALIOP lidar Level 2 product, this study proposes a novel framework leveraging Light Gradient-Boosting Machine (LGBM), integrated with grey level co-occurrence matrix (GLCM) features extracted from IR bands, to enhance nighttime cloud detection capabilities. The LGBM model with GLCM features demonstrates significant improvements, achieving an overall accuracy (OA) exceeding 85% and an F1-Score (F1) of nearly 0.9 when validated with an independent CALIOP lidar Level 2 product. Compared to the threshold-based algorithm that has been used operationally, the proposed algorithm exhibits superior and more stable performance across varying solar zenith angles, surface types, and cloud altitudes. Notably, the method produced over 82% OA over the cryosphere surface. Furthermore, compared to LGBM models without GLCM inputs, the enhanced model effectively mitigates the thermal stripe effect of MERSI L1 data, yielding more accurate cloud masks. Further evaluation with collocated MODIS-Aqua cloud mask product indicates that the proposed algorithm delivers more precise cloud detection (OA: 90.30%, F1: 0.9397) compared to that of the MODIS product (OA: 84.66%, F1: 0.9006). This IR-alone algorithm advancement offers a reliable tool for nighttime cloud detection, significantly enhancing the quantitative applications of satellite imager observations. Full article

All-sky 1 km land surface temperature (LST) data are urgently needed. Two widely applied approaches to derive such LST data are merging thermal infrared remote sensing (TIR)–passive microwave remote sensing (PMW) observations and merging TIR reanalysis data. However, as only the Moderate Resolution Imaging Spectroradiometer (MODIS) is adopted as the TIR source for merging, current 1 km all-sky LST products are limited to the MODIS observation time. Therefore, a gap still remains in terms of all-sky LST data with a higher temporal resolution or at other times (e.g., dawn–dusk time). Under this background, this study merged the observations of the Medium Resolution Spectrum Imager (MERSI-LL) on board the dusk–dawn-orbit Fengyun (FY)-3E satellite and Global Land Data Assimilation System (GLDAS) data to estimate dawn–dusk 1 km all-sky LST using a random forest-based method (RFRTM). The results showed that the model had good robustness, with an STD of 0.62–0.86 K of the RFRTM LST, compared with the original MERSI-LL LST. Validation against in situ LST showed that the estimated LST had an accuracy of 1.34–3.71 K under all-sky conditions. In addition, compared with the dawn–dusk LST merged from MERSI-LL and the Special Sensor Microwave Imager/Sounder (SSMI/S), the RFRTM LST showed better performance in accuracy and image quality. This study’s findings are beneficial for filling the gap in all-sky LST at high spatiotemporal resolutions for associated applications. Full article

The spatial resolution (250–1000 m) of the FY-3D MERSI is too coarse for agricultural monitoring at the farmland scale (20–30 m). To achieve the winter wheat yield (WWY) at the farmland scale, based on FY-3D, a method framework is developed in this work. The enhanced deep convolutional spatiotemporal fusion network (EDCSTFN) was used to perform a spatiotemporal fusion on the 10 day interval FY-3D and Sentinel-2 vegetation indices (VIs), which were compared with the enhanced spatial and temporal adaptive reflectance fusion model (ESTARFM). In addition, a BP neural network was built to calculate the farmland-scale WWY based on the fused VIs, and the Aqua MODIS gross primary productivity product was used as ancillary data for WWY estimation. The results reveal that both the EDCSTFN and ESTARFM achieve satisfactory precision in the fusion of the Sentinel-2 and FY-3D VIs; however, when the period of spatiotemporal data fusion is relatively long, the EDCSTFN can achieve greater precision than ESTARFM. Finally, the WWY estimation results based on the fused VIs show remarkable correlations with the WWY data at the county scale and provide abundant spatial distribution details about the WWY, displaying great potential for accurate farmland-scale WWY estimations based on reconstructed fine-spatial-temporal-resolution FY-3D data. Full article

Fractional vegetation cover (FVC) is a crucial indicator for measuring the growth of surface vegetation. The changes and predictions of FVC significantly impact biodiversity conservation, ecosystem health and stability, and climate change response and prediction. Southwest China (SWC) is characterized by complex topography, diverse climate types, and rich vegetation types. This study first analyzed the spatiotemporal variation of FVC at various timescales in SWC from 2000 to 2020 using FVC values derived from pixel dichotomy model. Next, we constructed four machine learning models—light gradient boosting machine (LightGBM), support vector regression (SVR), k-nearest neighbor (KNN), and ridge regression (RR)—along with a weighted average heterogeneous ensemble model (WAHEM) to predict growing-season FVC in SWC from 2000 to 2023. Finally, the performance of the different ML models was comprehensively evaluated using tenfold cross-validation and multiple performance metrics. The results indicated that the overall FVC in SWC predominantly increased from 2000 to 2020. Over the 21 years, the FVC spatial distribution in SWC generally showed a high east and low west pattern, with extremely low FVC in the western plateau of Tibet and higher FVC in parts of eastern Sichuan, Chongqing, Guizhou, and Yunnan. The determination coefficient R² scores from tenfold cross-validation for the four ML models indicated that LightGBM had the strongest predictive ability whereas RR had the weakest. WAHEM and LightGBM models performed the best overall in the training, validation, and test sets, with RR performing the worst. The predicted spatial change trends were consistent with the MODIS-MOD13A3-FVC and FY3D-MERSI-FVC, although the predicted FVC values were slightly higher but closer to the MODIS-MOD13A3-FVC. The feature importance scores from the LightGBM model indicated that digital elevation model (DEM) had the most significant influence on FVC among the six input features. In contrast, soil surface water retention capacity (SSWRC) was the most influential climate factor. The results of this study provided valuable insights and references for monitoring and predicting the vegetation cover in regions with complex topography, diverse climate types, and rich vegetation. Additionally, they offered guidance for selecting remote sensing products for vegetation cover and optimizing different ML models. Full article

The leaf area index (LAI) is a key indicator of vegetation canopy structure and growth status, crucial for global ecological environment research. The Moderate Resolution Spectral Imager-II (MERSI-II) aboard Fengyun-3D (FY-3D) covers the globe twice daily, providing a reliable data source for large-scale and high-frequency LAI estimation. VI-based LAI estimation is effective, but species and growth status impacts on the sensitivity of the VI–LAI relationship are rarely considered, especially for MERSI-II. This study analyzed the VI–LAI relationship for eight biomes in China with contrasting leaf structures and canopy architectures. The LAI was estimated by adaptively combining multiple VIs and validated using MODIS, GLASS, and ground measurements. Results show that (1) species and growth stages significantly affect VI–LAI sensitivity. For example, the EVI is optimal for broadleaf crops in winter, while the RDVI is best for evergreen needleleaf forests in summer. (2) Combining vegetation indices can significantly optimize sensitivity. The accuracy of multi-VI-based LAI retrieval is notably higher than using a single VI for the entire year. (3) MERSI-II shows good spatial–temporal consistency with MODIS and GLASS and is more sensitive to vegetation growth fluctuation. Direct validation with ground-truth data also demonstrates that the uncertainty of retrievals is acceptable (R² = 0.808, RMSE = 0.642). Full article

This study utilized an infrared spotlight Hyperspectral infrared Atmospheric Sounder (HIRAS) and the Medium Resolution Spectral Imager (MERSI) mounted on FY3D cloud products from the National Satellite Meteorological Center of China to obtain methane profile information. Methane inversion channels near 7.7 μm were selected based on the different distribution of methane weighting functions across different seasons and latitudes, and the selected retrieval channels had a great sensitivity to methane but not to other parameters. The optimization method was employed to retrieve methane profiles using these channels. The ozone profiles, temperature, and water vapor of the European Centre for Medium-Range Weather Forecasts (ECMWF) fifth-generation reanalysis data (ERA5) were applied to the retrieval process. After validating the methane profile concentrations retrieved by HIRAS, the following conclusions were drawn: (1) compared with Civil Aircraft for the Regular Investigation of the Atmosphere Based on an Instrument Container (CARIBIC) flight data, the average correlation coefficient, relative difference, and root mean square error were 0.73, 0.0491, and 18.9 ppbv, respectively, with lower relative differences and root mean square errors in low-latitude regions than in mid-latitude regions. (2) The methane profiles retrieved from May 2019 to September 2021 showed an average error within 60 ppbv compared with the Fourier transform infrared spectrometer (FTIR) station observations of the Infrared Working Group (IRWG) of the Network for the Detection of Atmospheric Composition Change (NDACC). The errors between the a priori and retrieved values, as well as between the retrieved and smoothed values, were larger by around 400–500 hPa. Apart from Toronto and Alzomoni, which had larger peak values in autumn and spring respectively, the mean column averaging kernels typically has a larger peak in summer. Full article

In this paper, a new simultaneous retrieval method of the SIRAW algorithm is introduced and carried out on FY3D/MERSI-II satellite images to obtain the aerosol optical thickness (AOT) and normalized water-leaving radiance (WLR) over the ocean. In order to improve the operation efficiency of SIRAW, a machine learning solver is developed to improve the speed of forward radiative transfer computation during retrieval. Ground-based measurement data from AERONET-OC and satellite products from VIIRS are used for comparative verification. The results show that the retrieved AOT and WLR from SIRAW are both in good agreement with those of AERONET-OC and VIIRS. Further, considering the degradation of the MERSI sensor, a new calibration scheme on 412 nm and 443 nm is adopted and an evaluation is carried out. Inter-comparison of derived WLR between MERSI and VIIRS indicates that the new calibration scheme could effectively improve the WLR retrieval accuracy of MERSI with better consistency to the official data of VIIRS. Therefore, this paper confirms that a simultaneous retrieval scheme combined with effective calibration coefficients can be used for high-precision retrieval of real aerosol and water-leaving radiation. Full article

Land surface temperature (LST) is an important physical quantity in the energy exchange of hydrothermal cycles between the land and near-surface atmosphere at regional and global scales. However, the traditional thermal infrared transfer equation (RTE) and LST retrieval algorithms are always based on the underlying assumptions of homogeneity and isotropy, which ignore the terrain effect influence of a heterogeneous topography. It can cause significant errors when traditional RTE and other algorithms are used to retrieve LST in such mountainous research. In this study, the mountainous thermal infrared transfer model considering terrain effect correction is used to retrieve the mountainous LST using FY-3D MERSI-II data, and the in situ site data are simultaneously utilized to evaluate the performance of the iterative single-channel algorithm. The elevation of this study region ranges from 500 m to 2200 m, whereas the minimum SVF can reach 0.75. Results show that the spatial distribution of the retrieved LST is similar to topographic features, and the LST has larger values in the lower valley and smaller values in the higher ridge. In addition, the overall bias and RMSE between the retrieved LSTs and five in situ stations are respectively −0.70 K and 2.64 K, which demonstrates this iterative single-channel algorithm performs well in taking into account the terrain effect influence. Accuracy of the LST estimation is meaningful for mountainous ecological environmental monitoring and global climate research. Such an adjacent terrain effect correction should be considered in future research on complex terrains, especially with high spatial resolution TIR data. Full article

The acquisition of high-accuracy reflectance in mid-infrared channels is of great significance for the on-orbit cross-calibration of other bands using the mid-infrared band. However, due to the phenomenon that some sensors have a wide range of wavelengths covered by adjacent channels in the mid-infrared band, the traditional method of estimating the mid-infrared reflectivity assumes that the sea surface reflectivity in different mid-infrared bands is equal, which will lead to a large error during calculation. To solve this problem, this study proposes a nonlinear split-window algorithm involving ocean sun glint data to retrieve reflectivity of FY-3D/MERSI-2 channels 20. The results show that the variation range of sea surface reflectivity of channel 20 in the glint area is 10~25%, the mean value of the reflectivity difference obtained by the nonlinear split-window algorithm is 0.27%, and the RMSE is 0.0066. Among the main influencing factors, the atmospheric conditions have the greatest impact, and the effects of the uncertainties in the water vapor content and aerosol optical thickness on the calculation results are 1.16% and 0.34%, respectively. The initial value limits of the mid-infrared sea surface reflectivity also contribute approximately 0.84%, and their contribution to the uncertainty represents one of the main components. This work shows that the nonlinear split-window algorithm can calculate the infrared sea surface reflectivity with high accuracy and can be used as a reference for in-orbit cross-calibration between different bands. Full article

As the non-imaging light of optical instruments, stray light has an important impact on normal imaging and data quantification applications. The FY-3D Medium Resolution Spectral Imager (MERSI) operates in a sun-synchronous orbit, with a scanning field of view of 110° and a surface imaging width of more than 2300 km, which can complete two coverage observations of global targets per day with high detection efficiency. According to the characteristics of the operating orbit and large-angle scanning imaging of MERSI, a stray light radiation model of the polar-orbiting spectrometer is constructed, and the design requirements of stray light suppression are proposed. Using the point source transmittance (PST) as the merit function of the stray light analysis method, the instrument was simulated with all stray light suppression optical paths, and the effectiveness of stray light elimination measures was verified using the stray light test. In this paper, the full-link method of “orbital stray light radiation model-system, internal and external simulation design-system analysis and actual test comparison verification” is proposed, and there is a maximum decrease in the system’s PST by about 10 times after applying the stray light suppression’s optimization design, which can provide a general method for stray light suppression designs for polar-orbit spectral imagers. Full article

In general, the far-infrared channel in the wavelength range of 10.5–12.0 µm plays an auxiliary role in wildfire detection as its sensitivity to high-temperature targets is far lower than the mid-infrared channel in the wavelength range of 3.5–4.0 µm at the same spatial resolution (1 km, which is the spatial resolution of infrared channels in most satellites used for wildfire monitoring in daily operational mode). The Medium-Resolution Spectral Imager II onboard the Fengyun-3D polar orbiting meteorological satellite (FY-3D/MERSI-II) contains far-infrared channels with a spatial resolution of 250 m at the wavelengths of 10.8 μm and 12.0 μm, which promotes the application of far-infrared channels in wildfire monitoring. In this study, the features of FY-3D/MERSI-II far-infrared channels in fire monitoring are discussed. The sensitivity of 10.8 μm (250 m) to fire spots and the influence of solar radiation reflection on the infrared channels are quantitatively analyzed. The method of using 10.8 μm (250 m) as a major data source to detect fire spots is proposed, and several typical wildfire cases are used to verify the proposed method. The results show that the 10.8 μm (250 m) far-infrared channel has the same advantages as the existing method in wildfire monitoring in terms of a more precise positioning of the detected fire pixel, avoiding interference by solar radiation reflections, and reflecting stronger fire regions in large fire fields. Full article

The on-orbit radiometric calibration is a fundamental task in quantitative remote sensing applications. A widely used calibration method is the cross-calibration based on Simultaneous Nadir Observation (SNO), which involves using high-precision reference instruments to calibrate lower-precision onboard instruments. However, despite efforts to match the observation time, spatial location, field geometry, and instrument spectra, errors can still be introduced during the matching processes and linear regression analysis. This paper focuses on the error generated by sample matching and the error fitting method generated by the sample fitting method. An error propagation analysis is performed to develop a generic model for assessing the uncertainty of the SNO cross-calibration method itself in meteorological satellite infrared channels. The model is validated using the payload parameters of the Hyperspectral Infrared Atmospheric Sounder (HIRAS) and the Medium Resolution Spectral Imager (MERSI) instruments aboard the FengYun-3D (FY-3D). Simulation experiments are performed considering typical bright temperatures, different background fields, and varying matching threshold conditions. The results demonstrate the effectiveness of the proposed model in capturing the error propagation chain in the SNO cross-calibration process. The model provides valuable insight into error analysis in the SNO cross-calibration method and can assist in determining the optimal sample matching threshold for achieving radiometric calibration accuracy. Full article

China’s FY-4B satellite, launched on 3 June 2021, is a new-generation geostationary meteorological satellite. The Advanced Geosynchronous Radiation Imager (AGRI) onboard FY-4B has 15 spectral channels, including 2 visible (470 and 650 nm), 1 near infrared (825 nm), and 3 shortwave infrared (1379, 1610, and 2225 nm) bands, which can be used to observe the Earth system with the highest spatial resolution of 500 m and 15 min temporal resolution. In this study, FY-4B/AGRI observations were applied for the first time to monitor cyanobacterial blooms in Lake Taihu, China. The AGRI reflectance at visible and near-infrared bands was first corrected to surface reflectance using the 6S radiative transfer model. Due to the similar spectral reflectance characteristics to those of land-based vegetation, the normalized difference vegetation index (NDVI) and some other remote sensing vegetation indices are usually used for the retrieval of cyanobacterial blooms. The fractional vegetation cover (FVC) of algae, defined as the fraction of green vegetation in the nadir view, was adopted to depict the status and trend of cyanobacterial blooms. NDVI and FVC, the two remote sensing indices developed for the retrieval of land vegetation, were used for the detection of cyanobacteria blooms in Lake Taihu. Finally, the FVC derived from AGRI measurements was compared with that obtained from the Advanced Himawari Imager (AHI) onboard the Himawari-8 satellite to validate the effectiveness of our method. It was found that atmospheric correction can substantially improve the determination of the normalized difference vegetation index (NDVI) values of cyanobacterial blooms in the lake. As a proof of the robustness of the algorithm, the NDVIs are both derived from both AGRI and AHI and their magnitudes are similar. In addition, the distribution of cyanobacterial blooms derived from AGRI FVC is highly consistent with that derived from FY-3D/MERSI and EOS/MODIS. While a lower spatial resolution of FY-4B/AGRI might restrict its capability in capturing some spatial details of cyanobacterial blooms, the high-frequency measurements can provide information for the timely and effective management of aquatic ecosystems and help researchers better quantify and understand the dynamics of cyanobacterial blooms. In particular, AGRI can provide greater details on the diurnal variation in the distribution of cyanobacterial blooms owing to the high temporal resolution. Full article

Satellite data provide crucial information to better understand volcanic processes and mitigate associated risks. In recent years, exploiting the growing number of spaceborne polar platforms, several automated volcanic monitoring systems have been developed. These, however, rely on good geometrical and meteorological conditions, as well as on the occurrence of thermally detectable activity at the time of acquisition. A multiplatform approach can thus increase the number of volcanological-suitable scenes, minimise the temporal gap between acquisitions, and provide crucial information on the onset, evolution, and conclusion of both transient and long-lasting volcanic episodes. In this work, we assessed the capabilities of the MEdium Resolution Spectral Imager-II (MERSI-II) sensor aboard the Fengyun-3D (FY-3D) platform to detect and quantify heat flux sourced from volcanic activity. Using the Middle Infrared Observation of Volcanic Activity (MIROVA) algorithm, we processed 3117 MERSI-II scenes of Mount Etna acquired between January 2020 and February 2023. We then compared the Volcanic Radiative Power (VRP, in Watt) timeseries against those obtained by MODIS and VIIRS sensors. The remarkable agreement between the timeseries, both in trends and magnitudes, was corroborated by correlation coefficients (ρ) between 0.93 and 0.95 and coefficients of determination (R²) ranging from 0.79 to 0.84. Integrating the datasets of the three sensors, we examined the effusive eruption of Mount Etna started on 27 November 2022, and estimated a total volume of erupted lava of 8.15 ± 2.44 × 10⁶ m³ with a Mean Output Rate (MOR) of 1.35 ± 0.40 m³ s⁻¹. The reduced temporal gaps between acquisitions revealed that rapid variations in cloud coverage as well as geometrically unfavourable conditions play a major role in thermal volcano monitoring. Evaluating the capabilities of MERSI-II, we also highlight how a multiplatform approach is essential to enhance the efficiency of satellite-based systems for volcanic surveillance. Full article

NDVI data have been widely used to detect and monitor vegetation status at regional, continental, and global scales. FY-3D MERSI-II NDVI (FNDVI) is a critical operational product used in many studies monitoring ecosystems and agriculture and assessing climate change and its risks, including drought and fire. MERSI-II and MODIS have very similar spectral response functions in the red and near-infrared channels, making MERSI/NDVI an effective replacement for MODIS/NDVI (MNDVI). Therefore, it is critical to conduct a thorough evaluation of the product’s quality. In this study, the consistency characteristics of two normalized difference vegetation index (NDVI) products, FY-3D MERSI-II NDVI and MODIS NDVI, were compared and validated at national and regional scales in China from 2020 to 2021. To assess the consistency of these two NDVI datasets, the correlation coefficient, root-mean-square error, and mean bias error were used. The findings revealed that the spatial distribution patterns of FNDVI and MNDVI were highly consistent across the country at the monthly time scale. The correlation coefficients were greater than 0.9475 for the two years 2020–2021, while the average deviation was between 0.02 and 0.05, and the root-mean-square error was 0.11. Based on the difference in the time consistency between FNDVI and MNDVI, the changes in the monthly NDVI values of the two types of satellites are generally consistent across the country. Among the three typical experimental areas, the relative deviation of the regional time series for products was the highest in Xinjiang. The relative average deviation of FNDVI in other regions was low, and its change trend was consistent with that of MODIS. Full article
