This study investigates the hydrodynamics, oxygen mass transfer, and sodium methyl mercaptan (NaSR) oxidation in a scaled-up airlift loop reactor, aiming to clarify the interplay between operational parameters and reaction efficiency. Computational Fluid Dynamics (CFD) simulations, coupled with the Euler–Euler approach, population balance model (PBM), Higbie’s penetration theory, and Arrhenius-type reaction kinetics, were employed. Experimental determination of reaction kinetics provided foundational data for model validation. Increasing superficial gas velocity Ug enhances $k_{L}a$ magnitude and spatial distribution uniformity, promotes bubble circulation between the riser and downcomer, and improves dissolved oxygen concentration. Numerical simulations showed good agreement with industrial data, confirming their reliability. Notably, at Ug = 0.0045 m/s, insufficient oxygen mass fraction in the downcomer was observed due to slow bubble renewal. The volumetric mass transfer coefficient exhibits larger value in downcomer due to the reasonable liquid turbulence dissipation. These findings provide critical insights for optimizing operational parameters in large-scale airlift reactors for NaSR oxidation. Full article

Mixer-settlers are pivotal in the solvent extraction industry, yet spatial control of agitation to intensity separation remains underexplored. This study proposes a novel strategy by localizing agitation strictly within the dispersion band. Through the developed computational fluid dynamics coupled population balance model (CFD-PBM) resolving droplet breakup/coalescence dynamics and laboratory experiments, it demonstrates that the agitator position critically governs dispersion band thickness and separation efficiency. It should be emphasized there was no significant difference between the experimental and the simulated. Optimal separation is achieved only when the agitation zone overlaps the dispersion band, balancing droplet fragmentation and coalescence while minimizing turbulence in settling regions. Conventional uniform agitation designs are suboptimal due to spatial sensitivity. The CFD-PBM framework establishes a physics-based tool for scalable mixer-settler design, enabling energy-efficient separation by decoupling mixing and settling energetics. This work provides an advanced solution for using the solvent extraction via targeted agitation optimization, emphasizing both scientific rigor and industrial applicability. Full article

During crude oil exploration and extraction, the presence of H₂S not only poses a threat to operational safety but also accelerates equipment corrosion, highlighting the urgent need for efficient and cost-effective processing solutions. This study employs a coupled numerical simulation approach that integrates computational fluid dynamics (CFD) and population balance models (PBM) to systematically investigate the multiphase flow characteristics within SK static mixers. By embedding mass transfer rates and reaction kinetics equations for hydrogen sulfide and sodium hypochlorite into the Euler-Euler multiphase flow model using user-defined functions (UDFs), the effects of equipment structure on the efficiency of the crude oil desulfurization process are examined. The results indicate that the optimized SK static mixer (with 15 elements, an aspect ratio of 1, and a twist angle of 90°) achieves an H₂S removal efficiency of 72.02%, which is 18.84 times greater than that of conventional empty tube reactors. Additionally, the micro-mixing time is reduced to 0.001 s, and the coefficient of variation (CoV) decreases to 0.21, while maintaining acceptable pressure drop levels. Using the CFD-PBM model, the dispersion behavior of droplets within the static mixer is investigated. The results show that the diameter of the inlet pipe significantly affects droplet dispersion; smaller diameters (0.1 and 1 mm) enhance droplet breakup through increased shear force and turbulence effects. The findings of this study provide theoretical support for optimizing crude oil desulfurization processes and are of significant importance for enhancing the economic efficiency and safety of crude oil extraction operations. Full article

In practical engineering applications, the cold storage functional backfill cooling system is prone to pipe clogging due to the agglomeration and crushing effects of the components of the ice particle-containing filling slurry. In addition, the fluidity of the slurry becomes more complex due to the change in the particle size distribution (PSD) during the pipeline transportation of the filling slurry, which limits the practical application effectiveness of the system. In order to promote the application and sustainable development of mining solid waste resources, a CFD–PBM coupling model was established to simulate the flow of the ice-containing filling slurry in horizontal circular tubes. On this basis, the effects of the initial ice content, inlet flow rate, initial particle size of tailings, and filling slurry concentration on the caking phenomenon during pipeline transportation were analyzed. The distribution of the pressure drop along the pipeline was also analyzed and calculated. The results show that the higher the flow velocity, the lower the slurry concentration, the larger the tailings’ particle size, the lower the ice content, and the lower the likelihood of agglomeration during transportation of the filling slurry. Full article

Twin-screw granulation has emerged as a key process in powder processing industries and in the pharmaceutical sector to produce granules with controlled properties. This comprehensive review provides an overview of the simulation techniques and approaches that have been employed in the study of twin-screw granulation processes. This review discusses the major aspects of the twin-screw granulation process which include the fundamental principles of twin-screw granulation, equipment design, process parameters, and simulation methodologies. It highlights the importance of operating conditions and formulation designs in powder flow dynamics, mixing behaviour, and particle interactions within the twin-screw granulator for enhancing product quality and process efficiency. Simulation techniques such as the population balance model (PBM), computational fluid dynamics (CFD), the discrete element method (DEM), process modelling software (PMS), and other coupled techniques are critically discussed with a focus on simulating twin-screw granulation processes. This paper examines the challenges and limitations associated with each simulation approach and provides insights into future research directions. Overall, this article serves as a valuable resource for researchers who intend to develop their understanding of twin-screw granulation and provides insights into the various techniques and approaches available for simulating the twin-screw granulation process. Full article

Pressure hydrometallurgy has attracted much attention for its characteristics, such as the high adaptability of raw materials and environmental friendliness. Flashing (flash boiling or flash evaporation) refers to the phase change phenomenon from liquid to gas triggered by depressurization, which is an important connection between high-pressure processes and atmospheric ones in pressure hydrometallurgy. This paper takes the flashing process in zinc leaching and alumina Bayer processes as examples, describes the flashing process in pressure hydrometallurgy in detail for the first time, and shows the importance of the flashing process in energy recovery, solution concentration, and liquid balance, as well as increasing equipment life. According to solid holdup (the volume percentage of solid), this paper proposes to divide the flashing process into solution flashing (low solid holdup) and slurry flashing (high solid holdup). A further focus is put on reviewing the state of the art of related studies. The results reveal that the research on the flashing process in pressure hydrometallurgy is scarce and often oversimplified, e.g., ignoring the BPE (boiling point elevation) and NEA (non-equilibrium allowance) in solution flashing and the effect of solid particles in slurry flashing. Computational fluid dynamic (CFD) simulation is a promising tool for investigating the flashing process. Based on the progress made in other fields, e.g., seawater desalination, nuclear safety analysis, and engine fuel atomization, we suggest that solution flashing can be studied using the CFD–PBM (population balance model) coupled two-fluid model, since a wide size range of bubbles will be generated. For slurry flashing, the effect of solid holdup on the bubble nucleation rate and mechanism as well as other bubble dynamics processes should be accounted for additionally, for which a quantitative description is still lacking. Meanwhile, data for validating the numerical method are scarce because of the harsh experimental conditions, and further research is needed. In summary, this work presents an overview of the flashing processes in pressure hydrometallurgy and some guidelines for future numerical studies. Full article

Computational fluid dynamics (CFD) and population balance models (PBM) were coupled together for the first time to simulate the synthesis of zirconia nanoparticles in a continuous hydrothermal flow synthesis (CHFS) system with a self-designed confined impinging jet mixing (CJM) reactor. The hydrodynamic and thermodynamic behaviors within the CJM reactor strongly influenced the formation of the ZrO₂ nanoparticles. Crucial parameters, such as velocities, temperatures, mixing conditions, and reaction rates, were analyzed under various supercritical conditions. Temperature and velocity measurements as functions of distance were also investigated. Normal particle size distribution (PSD) patterns were observed in all cases. The mean particle sizes in this study were calculated and compared using PBM aggregation analysis. Full article

The flocculation that takes place in the central feedwell of the thickener plays a crucial role in the coal-slurry thickening process, which is not only complex but also largely influenced by the flow characteristics. A coupled computational fluid dynamics–population balance model (CFD–PBM) was used to model the complex flocculation-thickening behaviour in an industrial-scale gravity thickener. The initialisation parameters of the inlet flow were obtained through self-designed image-recognition experiments, and then the effects of different types of conical deflectors on the floc distribution were simulated and analysed using them. The results showed that, under the condition that the angle of the conical deflector’s sides in the vertical plane was known, a reasonable increase in the height of the bottom surface could reduce the annular spanwise vortices at the underflow of the feedwell, thereby avoiding the erosion of the inlet flow and the annular spanwise vortex on the floc deposition layer. However, excessive height on the part of the conical deflector could affect the flocculation effect of solid particles. For the same central feedwell size of the thickener as in the simulation, the best flocculation effect was achieved at an angle of α = 24° in the vertical plane of the conical deflector. Turbulence regulation of the conical deflector promotes the aggregation of fine particles in the fluid of the feedwell, providing a new method for the intensification of the flocculation-concentration process. Full article

In this study, a three-dimensional CFD transient model is established for predicting species concentration distribution in the biodegradation of phenol in an airlift reactor (ALR). The gas–liquid flow in the ALR is determined by the Euler–Euler method coupled with the standard k-ε model, and the bubble size is predicted by the population balance model (PBM). A turbulent mass diffusivity model is developed to simulate the turbulent mass transfer process and to predict the species concentration distribution. No empirical methods are needed as the turbulent mass diffusivity can be expressed by the concentration variance $\overline{c^2}$ and its dissipation rate ε_c. A good agreement is found between simulated and experimental results in the literature. It is not reasonable to assume a constant turbulent Schmidt number because the calculated distribution of turbulent mass diffusivity is not identical to that of turbulent viscosity. Finally, the hydrodynamic characteristics and biodegradation performance of the proposed model in a novel ALR are compared with that in the original ALR. Full article

When the multiphase pump is running, the internal medium often exists as bubble flow. In order to investigate the bubble occurrence characteristics in the pressurization unit of the multiphase pump more accurately, this paper couples computational fluid dynamics (CFD) with a population balance model (PBM) to investigate the bubble size distribution law of the multiphase pump under different operating conditions, taking into account the bubble coalescence and breakup. The research shows that the mean bubble size in the impeller domain gradually decreases from 1.7013 mm at the inlet to 0.6179 mm at the outlet along the axis direction; the average bubble diameter in the diffuser domain fluctuates around 0.60 mm. The bubbles in the impeller region gradually change from the trend of coalescence to the trend of breakup along the axial and radial directions, and the bubbles in the diffuser tend to be broken by the vortex entrainment. The bubble size development law is influenced by the inlet gas volume fraction (IGVF) and the rotational speed, showing a more obvious rule, where the gas phase aggregation phenomenon enhanced by the increase in IGVF promotes the trend of bubble coalescence and makes the bubble size gradually increase. The increased blade shearing effect with the increase in rotational speed promotes the trend of bubble breakup, which gradually reduces the size of the bubbles. In addition, increasing the bubble coalescence probability is a key factor leading to changes in bubble size; the bubble size development law is not very sensitive to changes in flow, and the bubble size is at its maximum under design conditions. The research results can accurately predict the performance change of the multiphase pump and provide technical guidance for its safe operation and optimal design. Full article

Optimal oxygen supply is vitally important for the cultivation of aerobically growing cells, as it has a direct influence on cell growth and product formation. A process engineering parameter directly related to oxygen supply is the volumetric oxygen mass transfer coefficient $k_{L}a$. It is the influences on $k_{L}a$ and computing time of different interfacial force and population balance models in stirred bioreactors that have been evaluated in this study. For this investigation, the OpenFOAM 7 open-source toolbox was utilized. Firstly, the Euler–Euler model with a constant bubble diameter was applied to a 2$\mathrm{L}$ scale bioreactor to statistically examine the influence of different interfacial models on the $k_{L}a$ value. It was shown that the $k_L$ model and the constant bubble diameter have the greatest influence on the calculated $k_{L}a$ value. To eliminate the problem of a constant bubble diameter and to take effects such as bubble breakup and coalescence into account, the Euler–Euler model was coupled with population balance models (PBM). For this purpose, four coalescence and five bubble breakup models were examined. Ultimately, it was established that, for all of the models tested, coupling computational fluid dynamics (CFD) with PBM resulted in better agreement with the experimental data than using the Euler–Euler model. However, it should be noted that the higher accuracy of the PBM coupled models requires twice the computation time. Full article

Gas–liquid two-phase flow directly determines the efficiency and stability of the aeration tank. In this paper, a gas–liquid two-phase testbed is built to explore the aeration performance and internal flow in an aeration tank, including an inverted-umbrella impeller (immersion depth of 0 mm, rotational speed of 250 r/min). Also, the running process is simulated by computational fluid dynamics (CFD) with a population balance model (PBM), and mass transfer coefficient is compared to the experiment. The experimental results show that there is a big difference in bubble diameter, ranging from 0.4 to 1.6 mm. The simulation shows that the impeller intensely draws air above the free surface into the shallow liquid, and the circulation vortex entrains it to the bottom areas faster. Compared with the experiment, the simulated interfacial area and standard oxygen mass transfer coefficient is 12% more and 3% less, respectively. The results reveal that CFD-PBM coupled model can improve the accuracy of calculation, resulting in the simulation of gas–liquid two-phase flow. Full article

This work aimed to study the bubble distribution in a multiphase pump. A Euler-Euler inhomogeneous two-phase flow model coupled with a discrete particle population balance model (PBM) was used to simulate the whole flow channel of a three-stage gas-liquid two-phase centrifugal pump. Comparison of the computational fluid dynamic (CFD) simulation results with experimental data shows that the model can accurately predict the performance of the pump under various operating conditions. In addition, the liquid phase velocity distribution, gas-phase distribution, and pressure distribution of the second stage impeller at a 0.5 span of blade height under three typical working conditions were compared. Results show that the region with high local gas volume fraction (LGVF) mainly appears on the suction surface (SS) of the blade. With the increase in inlet gas volume fraction (IGVF), vortices and low velocity recirculation regions are generated at the impeller outlet and SS of the blade, the area with high LGVF increases, and gas–liquid separation occurs at the SS of the blade. The liquid phase flows out of the impeller at high velocity along the pressure surface of the blade, and the limited pressurization of fluid mainly happens at the impeller outlet. The average bubble size at the impeller outlet is the smallest while that at the impeller inlet is the largest. Under low IGVF conditions, bubbles tend to break into smaller ones, and the broken bubbles mainly concentrate at the blade pressure surface (PS) and the impeller outlet. Bubbles tend to coalesce into larger ones under high IGVF conditions. With the increase in IGVF, the bubble aggregation zone diffuses from the blade SS to the PS. Full article

The computational fluid dynamics-population balance model (CFD-PBM) has been presented and used to evaluate the bubble behavior in a large-scale high pressure bubble column with an inner diameter of 300 mm and a height of 6600 mm. In the heterogeneous flow regime, bubbles can be divided into “large bubbles” and “small bubbles” by a critical bubble diameter dc. In this study, large and small bubbles were classified according to different slopes in the experiment only by the method of dynamic gas disengagement, the critical bubble diameter was determined to be 7 mm by the experimental results and the simulation values. In addition, the effects of superficial gas velocity, operating pressure, surface tension and viscosity on gas holdup of large and small bubbles in gas–liquid two-phase flow were investigated using a CFD-PBM coupling model. The results show that the gas holdup of small and large bubbles increases rapidly with the increase of superficial gas velocity. With the increase of pressure, the gas holdup of small bubbles increases significantly, and the gas holdup of large bubbles increase slightly. Under the same superficial gas velocity, the gas holdup of large bubbles increases with the decrease of viscosity and the decrease of surface tension, but the gas holdup of small bubbles increases significantly. The simulated values of the coupled model have a good agreement with the experimental values, which can be applied to the parameter estimation of the high pressure bubble column system. Full article

Bioprocesses for the production of renewable energies and materials lack efficient separation processes for the utilized microorganisms such as algae and yeasts. Dissolved air flotation (DAF) and microflotation are promising approaches to overcome this problem. The efficiency of these processes depends on the ability of microorganisms to aggregate with microbubbles in the flotation tank. In this study, different new or adapted aggregation models for microbubbles and microorganisms are compared and investigated for their range of suitability to predict the separation efficiency of microorganisms from fermentation broths. The complexity of the heteroaggregation models range from an algebraic model to a 2D population balance model (PBM) including the formation of clusters containing several bubbles and microorganisms. The effect of bubble and cell size distributions on the flotation efficiency is considered by applying PBMs, as well. To determine the sensitivity of the results on the model assumptions, the modeling approaches are compared, and suggestions for their range of applicability are given. Evaluating the computational fluid dynamics (CFD) of a dissolved air flotation (DAF) system shows the heterogeneity of the fluid dynamics in the flotation tank. Since analysis of the streamlines of the tank show negligible back mixing, the proposed aggregation models are coupled to the CFD data by applying a Lagrangian approach. Full article
