Search Results (24)

This work addresses the issue of closely spaced multi-target localization in distributed MIMO radars using bistatic range (BR) and angle of arrival (AOA) measurements. We propose a two-step method, decomposing the problem into measurement association and individual target localization. The measurement association poses a significant challenge, particularly when targets are closely spaced along with the existence of both false alarms and missed alarms. To tackle this challenge, we formulate it as a clustering problem and we propose a novel clustering algorithm. By carefully defining the distance metric and the set of neighboring estimated points (EPs), our method not only produces accurate measurement association, but also provides reliable initial values for the subsequent individual target localization. Single-target localization remains challenging due to the involved nonlinear and nonconvex optimization problems. To address this, we formulate the objective function as a form of the product of certain local functions, and we design a factor graph-based iterative message-passing algorithm. The message-passing algorithm dynamically approximates the complex local functions involved in the problem, delivering excellent performance while maintaining low complexity. Extensive simulation results demonstrate that the proposed method not only achieves highly efficient association but also outperforms state-of-the-art algorithms and exhibits superior consistency with the Cramer–Rao lower bound (CRLB). Full article

Small targets with low radar cross-section (RCS) and high velocities are very hard to track by radar as long as the frequent variations in speed and location demand shorten the integration temporal window. In this paper, we propose a technique for tracking evasive targets using a continuous wave (CW) radar array of multiple transmitters operating in the millimeter wavelength (MMW). The scheme is demonstrated to detect supersonic moving objects, such as rifle projectiles, with extremely short integration times while utilizing an adaptive processing algorithm of the received signal. Operation at extremely high frequencies qualifies spatial discrimination, leading to resolution improvement over radars operating in commonly used lower frequencies. CW transmissions result in efficient average power utilization and consumption of narrow bandwidths. It is shown that although CW radars are not naturally designed to estimate distances, the array arrangement can track the instantaneous location and velocity of even supersonic targets. Since a CW radar measures the target velocity via the Doppler frequency shift, it is resistant to the detection of undesired immovable objects in multi-scattering scenarios; thus, the tracking ability is not impaired in a stationary, cluttered environment. Using the presented radar scheme is shown to enable the processing of extremely weak signals that are reflected from objects with a low RCS. In the presented approach, the significant improvement in resolution is beneficial for the reduction in the required detection time. In addition, in relation to reducing the target recording time for processing, the presented scheme stimulates the detection and tracking of objects that make frequent changes in their velocity and position. Full article

In this paper, we propose a novel approach for circular Multiple-Input Multiple-Output (MIMO) array imaging, termed the Partial Equivalent Method (PEM), aimed at sidelobe suppression. In our method, the imaging process of the circular MIMO array is initially decomposed into bistatic circular synthetic aperture radar (BCSAR) components with different bistatic angles. Components with larger bistatic angles produce equivalent channels whose wavenumber spectra are concentrated near zero frequency, leading to significant broadening of the main lobe in the corresponding point spread function (PSF). In traditional MIMO imaging, each transmit–receive antenna pair is considered an equivalent channel, and all these channels are utilized for imaging. However, components with large bistatic angles, when integrated into the MIMO imaging output, result in increased sidelobe levels. To address this issue, we employ the PEM to restrict the range of equivalent channels. This method selectively retains effective channels generated by components with specific bistatic angles, effectively mitigating the adverse effects of BCSAR components with larger bistatic angles. Through point target simulations, electromagnetic simulations, and practical experiments, we demonstrate that the PEM significantly reduces sidelobes and enhances image quality in circular MIMO array imaging. Full article

This paper presents a new technique for estimating the two-dimensional direction of departure (2D-DOD) and direction of arrival (2D-DOA) in bistatic uniform planar array Multiple-Input Multiple-Output (MIMO) radar systems. The method is based on the reduced-dimension (RD) MUSIC algorithm, aiming to achieve improved precision and computational efficiency. Primarily, this pioneering approach efficiently transforms the four-dimensional (4D) estimation problem into two-dimensional (2D) searches, thus reducing the computational complexity typically associated with conventional MUSIC algorithms. Then, exploits the spatial diversity of array response vectors to construct a 4D spatial spectrum function, which is crucial in resolving the complex angular parameters of multiple simultaneous targets. Finally, the objective is to simplify the spatial spectrum to a 2D search within a 4D measurement space to achieve an optimal balance between efficiency and accuracy. Simulation results validate the effectiveness of our proposed algorithm compared to several existing approaches, demonstrating its robustness in accurately estimating 2D-DOD and 2D-DOA across various scenarios. The proposed technique shows significant computational savings and high-resolution estimations and maintains high precision, setting a new benchmark for future explorations in the field. Full article

Since there is a frequency offset between each adjacent antenna of FDA radar, there exists angle-range two-dimensional dependence in the transmitter. For bistatic FDA-multiple input multiple output (MIMO) radar, range-direction of departure (DOD)-direction of arrival (DOA) information is coupled in transmitting the steering vector. How to decouple the three information has become the focus of research. Aiming at the issue of target parameter estimation of bistatic FDA-MIMO radar, a real-valued parameter estimation algorithm based on high-order-singular value decomposition (HOSVD) is developed. Firstly, for decoupling DOD and range in transmitter, it is necessary to divide the transmitter into subarrays. Then, the forward–backward averaging and unitary transformation techniques are utilized to convert complex-valued data into real-valued data. The signal subspace is obtained by HOSVD, and the two-dimensional spatial spectral function is constructed. Secondly, the dimension of spatial spectrum is reduced by the Lagrange algorithm, so that it is only related to DOA, and the DOA estimation is obtained. Then the frequency increment between subarrays is used to decouple the DOD and range information, and eliminate the phase ambiguity at the same time. Finally, the DOD and range estimation automatically matched with DOA estimation are obtained. The proposed algorithm uses the multidimensional structure of high-dimensional data to promote performance. Meanwhile, the proposed real-valued tensor-based method can effectively cut down the computing time. Simulation results verify the high efficiency of the developed method. Full article

Based on low-rank matrix reconstruction theory, this paper proposes a joint DOD and DOA estimation method for coherent targets with bistatic coprime array MIMO radar. Unlike the conventional vectorization, the proposed method processed the coprime array with virtual sensor interpolation, which obtained a uniform linear array to generate the covariance matrix. Then, we reconstructed the Toeplitz matrix and established a matrix optimization recovery model according to the kernel norm minimization theory. Finally, the reduced dimension multiple signal classification algorithm was applied to estimate the angle of the coherent targets, with which the automatic pairing of DOD and DOA could be realized. With the same number of physical sensors, the proposed method expanded the array aperture effectively, so that the degree of freedom and angular resolution could be improved significantly for coherent signals. However, the effectiveness of the method was largely limited by the signal-to-noise ratio. The superiority and effectiveness of the method were proved using simulation experiments. Full article

In the past few years, multiple-input multiple-output (MIMO) radar with electromagnetic vector sensor (EMVS) array, or called EMVS-MIMO radar, has attracted extensive attention in target detection. Unlike the traditional scalar sensor-based MIMO radar, an EMVS-MIMO radar can not only provides a two-dimensional (2D) direction finding of the targets but also offers 2D polarization parameter estimation, which may be important for detecting weak targets. In this paper, we investigate into multiple parameter estimations for a bistatic EMVS-MIMO radar in the presence of coherent targets, whose transmitting EMVS and receiving EMVS are placed in an arbitrary topology. Three tensor-aware spatial smoothing estimators are introduced. The core of the proposed estimators is to de-correlate the coherent targets via the spatial smoothing technique and then formulate the covariance matrix into a third-order parallel factor (PARAFAC) tensor. After the PARAFAC decomposition of the tensor, the factor matrices can be obtained. Thereafter, the 2D direction finding can be accomplished via the normalized vector cross-product technique. Finally, the 2D polarization parameter can be estimated via the least squares method. Unlike the state-of-the-art PARAFAC estimator, the proposed estimators are suitable for arbitrary sensor geometries, and they are robust to coherent targets as well as sensor position errors. In addition, they have better estimation performance than the current matrix-based estimators. Moreover, they are computationally efficient than the current subspace methods, especially in the presence of a large-scale sensor array. In addition, the proposed estimators are analyzed in detail. Numerical experiments coincide with our theoretical findings. Full article

In this study, we propose a range detection (RD) ability by a continuous wave (CW) bistatic Doppler radar (RDCWB) of small and fast targets with very high range resolution. The target’s range and velocity are detected simultaneously. The scheme is based on the transmission of a continuous wave (CW) at millimeter wavelength (MMW) and the measurement of the respective Doppler shifts associated with target movements in different directions. The range resolution in this method is determined by the Doppler resolution only, without the necessity to transmit the modulated waveforms as in frequency modulation continuous wave (FMCW) or pulse radars. As the Doppler resolution in CW depends only on the time window required for processing, a very highrange resolution can be obtained. Most other systems that perform target localization use the transmission of wide-band waveforms while measuring the delay of the received signal scattered from the target. In the proposed scheme, the range resolution depends on the processed integration time of the detected signal and the velocity of the target. The transmission is performed from separated antennas and received by a single antenna. The received signal is heterodyned with a sample of the transmitted signal in order to obtain the Doppler shifts associated with the target’s movement. As in a multi-in multi-out (MIMO) configuration, the presented scheme allows for the accumulation of additional information for target classification. Data on the target’s velocity, distance, direction, and instantaneous velocity can be extracted. Using digital processing, with the additional information obtained by analyzing the difference between the resulting intermediate frequencies caused by the Doppler effect, it is possible to calculate the distance between the radar and the target at high resolution in real-time. The presented method, which was tested experimentally, proved to be highly effective, as only one receiver is required for the detection, while the transmission is carried out using a fixed, single-frequency transmission. Full article

In multiple-input-multiple-output synthetic aperture radar (MIMO-SAR) systems, sparse arrays are usually applied, resulting in increased sidelobes of the point spread function. In this paper, a phase shift migration (PSM) imaging algorithm based on the explosion reflection model with modified coherent factor was proposed for sidelobe suppression in MIMO-SAR three-dimensional (3D) imaging application. By defining the virtual difference wavenumber, reconstructing the raw echo by data rearrangement in wavenumber domain, the original coherent factor algorithm operating in spatial domain can be achieved by the PSM algorithm frame in the wavenumber domain, which means two orders of magnitude increase in computational efficiency. The correctness of the theory is verified by simulation. Finally, a bistatic prototype imaging system in the 0.3 THz band was designed for the proof-of-principle experiments. The experimental results show that the proposed algorithm has a 0.948 structural similarity value to the original coherent factor back-projection algorithm (CF-BPA) which means comparable image quality with much superior efficiency. Full article

Ideal transmitting and receiving (Tx/Rx) array response is always desirable in multiple-input multiple-output (MIMO) radar. In practice, nevertheless, Tx/Rx arrays may be susceptible to unknown gain-phase errors (GPE) and yield seriously decreased positioning accuracy. This paper focuses on the direction-of-departure (DOD) and direction-of-arrival (DOA) problem in bistatic MIMO radar with unknown gain-phase errors (GPE). A novel parallel factor (PARAFAC) estimator is proposed. The factor matrices containing DOD and DOA are firstly obtained via PARAFAC decomposition. One DOD-DOA pair estimation is then accomplished from the spectrum searching. Thereafter, the remainder DOD and DOA are achieved by the least squares technique with the previous estimated angle pair. The proposed estimator is analyzed in detail. It only requires one instrumental Tx/Rx sensor, and it outperforms the state-of-the-art algorithms. Numerical simulations verify the theoretical advantages. Full article

In this paper, a joint diagonalization based two dimensional (2D) direction of departure (DOD) and 2D direction of arrival (DOA) estimation method for a mixture of circular and strictly noncircular (NC) sources is proposed based on an L-shaped bistatic multiple input multiple output (MIMO) radar. By making full use of the L-shaped MIMO array structure to obtain an extended virtual array at the receive array, we first combine the received data vector and its conjugated counterpart to construct a new data vector, and then an estimating signal parameter via rotational invariance techniques (ESPRIT)-like method is adopted to estimate the DODs and DOAs by joint diagonalization of the NC-based direction matrices, which can automatically pair the four dimensional (4D) angle parameters and solve the angle ambiguity problem with common one-dimensional (1D) DODs and DOAs. In addition, the asymptotic performance of the proposed algorithm is analyzed and the closed-form stochastic Cramer–Rao bound (CRB) expression is derived. As demonstrated by simulation results, the proposed algorithm has outperformed the existing one, with a result close to the theoretical benchmark. Full article

The direction-of-departure (DOD) and the direction-of-arrival (DOA) are important localization parameters in bistatic MIMO radar. In this paper, we are interested in DOD/DOA estimation of both single-pulse and multiple-pulse multiple-input multiple-output (MIMO) radars. An iterative super-resolution target localization method is firstly proposed for single-pulse bistatic MIMO radar. During the iterative process, the estimated DOD and DOA can be moved from initial angles to their true values with high probability, and thus can achieve super-resolution estimation. It works well even if the number of targets is unknown. We then extend the proposed method to multiple-pulse configuration to estimate target numbers and localize targets. Compared with existing methods, both of our proposed algorithms have a higher localization accuracy and a more stable performance. Moreover, the proposed algorithms work well even with low sampling numbers and unknown target numbers. Simulation results demonstrate the effectiveness of the proposed methods. Full article

We develop a novel approach improving existing target localization algorithms for distributed multiple-input multiple-output (MIMO) radars based on bistatic range measurements (BRMs). In the proposed algorithms, we estimate the target position with auxiliary parameters consisting of both the target–transmitter distances and the target–receiver distances (hence, “double-sided”) in contrast to the existing BRM methods. Furthermore, we apply the double-sided approach to multistage BRM methods. Performance improvements were demonstrated via simulations and a limited theoretical analysis was attempted for the ideal two-dimensional case. Full article

Since second-order statistics-based methods rely heavily on Gaussianity assumption and fractional lower-order statistics-based methods depend on a priori knowledge of non-Gaussian noise, there remains a void in wideband bistatic multiple-input/multiple-output (MIMO) radar systems under impulsive noise. In this paper, a novel method based on Sigmoid transform was used to estimate target parameters, which do not need a priori knowledge of the noise in an impulsive noise environment. Firstly, a novel wideband ambiguity function, termed Sigmoid wideband ambiguity function (Sigmoid-WBAF), is proposed to estimate the Doppler stretch and time delay by searching the peak of the Sigmoid-WBAF. A novel Sigmoid correlation function is proposed. Furthermore, a new MUSIC algorithm based on the Sigmoid correlation function (Sigmoid-MUSIC) is proposed to estimate the direction-of-departure (DOD) and direction-of-arrival (DOA). Then, the boundness of the Sigmoid-WBAF to the symmetric alpha stable ( $S\alpha S$ ) noise, the feasibility analysis of the Sigmoid-WBAF, and complexity analysis of the Sigmoid-WBAF and Sigmoid-MUSIC are presented to evaluate the performance of the proposed method. In addition, the Cramér–Rao bound for parameter estimation was derived and computed in closed form, which shows that better performance was achieved. Simulation results and theoretical analyses are presented to verify the effectiveness of the proposed method. Full article

The unknown mutual coupling effect between antennas significantly degrades the target localization performance in the bistatic multiple-input multiple-output (MIMO) radar. In this paper, the joint estimation problem for the direction of departure (DOD) and direction of arrival (DOA) is addressed. By exploiting the target sparsity in the spatial domain and formulating a dictionary matrix with discretizing the DOD/DOA into grids, compressed sensing (CS)-based system model is given. However, in the practical MIMO radar systems, the target cannot be precisely on the grids, and the unknown mutual coupling effect degrades the estimation performance. Therefore, a novel CS-based DOD/DOA estimation model with both the off-grid and mutual coupling effect is proposed, and a novel sparse reconstruction method is proposed to estimate DOD/DOA with updating both the off-grid and mutual coupling parameters iteratively. Moreover, to describe the estimation performance, the corresponding Cramér–Rao lower bounds (CRLBs) with all the unknown parameters are theoretically derived. Simulation results show that the proposed method can improve the DOD/DOA estimation in the scenario with unknown mutual coupling effect, and outperform state-of-the-art methods. Full article
