Advanced Manufacturing of Nanomaterials

A special issue of Nanomaterials (ISSN 2079-4991). This special issue belongs to the section "Nanofabrication and Nanomanufacturing".

Deadline for manuscript submissions: closed (30 April 2026) | Viewed by 2188

Special Issue Editors

Dr. Sheldon Y. Xie

E-Mail Website
Guest Editor
Department of Engineering Technology and Construction Management, University of North Carolina, Charlotte, NC 28223, USA
Interests: laser processing; AI for materials science; advanced manufacturing
Dr. Bujingda Zheng

E-Mail Website
Guest Editor
Department of Mechanical Engineering, Western New England University, Springfield, MA 01119, USA
Interests: hybrid additive manufacturing; robotics
Dr. Chi Zhang

E-Mail Website
Guest Editor
Hangzhou Institute for Advanced Study, University of Chinese Academy of Sciences, Hangzhou, China
Interests: metalmaterials; nonequilibrium synthesis
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

The past decade has witnessed remarkable progress in nanomaterial synthesis and processing, driven by the emergence of advanced manufacturing techniques. Emerging approaches such as 3D printing, laser processing, flash Joule heating, and microwave-assisted synthesis allow for rapid, energy-efficient, and precisely controlled production of nanostructures with tunable compositions, morphologies, properties, and functionalities. These techniques are opening new pathways for engineering functional nanomaterials for applications in catalysis, energy, separation, medicine, and electronics, among others. Very recently, artificial intelligence (AI) has begun to rapidly transform materials discovery from traditional trial-and-error to data-driven innovation. By leveraging AI in advanced manufacturing, researchers can predict properties, perform inverse design, and guide high-throughput synthesis with unprecedented accuracy and efficiency. Coupled with advances in robotic automation, in situ monitoring, and data analytics, AI-driven manufacturing workflows are accelerating the transition from laboratory research to industrial implementation.

This Special Issue aims to highlight the latest progress in advanced manufacturing of nanomaterials, with an emphasis on both fundamental insights and translational potential. We invite submissions of original research articles, letters, reviews, perspectives, and communications.

Topics of this Special Issue include, but are not limited to, the following:

  • Advanced manufacturing techniques: Three-dimensional printing, laser processing, flash Joule heating, carbothermal shock, microwave, and light-assisted synthesis
  • AI-driven discovery and design: Property prediction, inverse design, automated/autonomous synthesis, and large language models
  • Scalable processes and industrial translation: Roll-to-roll manufacturing, continuous flow synthesis, industrial automation, cost-effective and sustainable large-scale production
  • Advanced characterization: In situ/operando monitoring, high-throughput metrology, and real-time data analysis for process optimization

Dr. Sheldon Y. Xie
Dr. Bujingda Zheng
Dr. Chi Zhang
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 250 words) can be sent to the Editorial Office for assessment.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Nanomaterials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • advanced manufacturing
  • nanomaterials
  • artificial intelligence
  • scalable production
  • autonomous synthesis
  • advanced characterization

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • Reprint: MDPI Books provides the opportunity to republish successful Special Issues in book format, both online and in print.

Further information on MDPI's Special Issue policies can be found here.

Published Papers (4 papers)

Download All Papers
Order results
Result details
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Research

11 pages, 7494 KB
Article
Wafer-Scale Electrical Characterization of Al/AlxOy/Al Tunnel Junctions for Process Monitoring at Room Temperature
by Simon Johann Klaus Lang, Ignaz Eisele, Johannes Weber, Alexandra Schewski, Emir Music, Alwin Maiwald, Martin Hahn, Daniela Zahn, Zhen Luo, Lars Nebrich, Benedikt Schoof, Thomas Mayer, Leonhard Sturm-Rogon, Wilfried Lerch, Rui Nuno Pereira and Christoph Kutter
Nanomaterials 2026, 16(10), 569; https://doi.org/10.3390/nano16100569 - 7 May 2026
Abstract
Josephson junctions are key elements in superconducting qubits. Their efficient wafer-scale characterization is crucial for process control and optimization, motivating analysis approaches that extend beyond conventional cryogenic measurements. In this work, we demonstrate that room temperature (RT) capacitance and current–voltage measurements, combined with [...] Read more.
Josephson junctions are key elements in superconducting qubits. Their efficient wafer-scale characterization is crucial for process control and optimization, motivating analysis approaches that extend beyond conventional cryogenic measurements. In this work, we demonstrate that room temperature (RT) capacitance and current–voltage measurements, combined with appropriate data analysis, enable extraction of relevant junction parameters such as oxide thickness, tunnel coefficient, and interfacial defect density. Furthermore, different charge transport mechanisms can be identified from detailed current–voltage analysis. We evaluate our characterization technique using tunnel junctions fabricated on 200 mm wafers in a complementary metal–oxide–semiconductor (CMOS)-compatible subtractive process. The results show a homogeneous average oxide thickness across the wafer with a variation below 3%. A dependence of the tunnel coefficient on oxide thickness indicates a stoichiometry gradient within the oxide. Additionally, low interfacial defect densities in the range of 70–5000 defects/cm2 are observed in our junctions, increasing with decreasing oxide thickness, suggesting that wet etching used for thickness control introduces interfacial trap states. Our study highlights the importance of advanced RT characterization for extracting tunnel junction parameters on the wafer scale, enabling effective process monitoring and optimization in industrial superconducting qubit manufacturing. Full article
(This article belongs to the Special Issue Advanced Manufacturing of Nanomaterials)
