Zeolitic Membranes for Gas and Liquid Separation: Synthesis and Applications

A special issue of Membranes (ISSN 2077-0375). This special issue belongs to the section "Membrane Applications".

Deadline for manuscript submissions: closed (10 November 2023) | Viewed by 14473

Special Issue Editors

School of Energy, Materials and Chemical Engineering, Hefei University, Hefei 230601, China
Interests: inorganic membrane; zeolite membrane; organic membrane; gas separation; pervaporation; membrane reactor; structure control; SiC membrane
State Key Laboratory of Materials-Oriented Chemical Engineering, College of Chemistry and Chemical Engineering, Nanjing Tech. University, Nanjing 210009, China
Interests: inorganic membrane; zeolite membrane; gas separation; pervaporation; membrane reactor
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Membrane separation is one of the most critical and challenging steps for industrial processes, and zeolite membranes are potential candidates to be used for this application. Zeolites are microporous materials that possess molecular-sieving and selective-adsorption properties. The preparation of a zeolite membrane has advanced our understanding of continuous separation processes, as many milestones have been reached through research and experiments.

This Special Issue on “Zeolitic Membranes for Gas and Liquid Separation: Synthesis and Applications” focuses on the recent theoretical and experimental advances in materials chemistry and membrane synthesis, processing, characterization, simulation, and performance, including the issues faced in the design and growth of membranes for gas and liquid separation applications.

This Special Issue aims to highlight and promote recent advances and to create an overview of research activities on zeolitic membrane processes. The topics of interest include, but are not limited to, the following: zeolite and zeolitic metal–organic frameworks (MOFs) for gas and liquid separation; novel membrane materials; novel membrane formation methods; and modification techniques. Concerning applications, apart from gas separation and liquid separation (pervaporation and filtration), membrane reactors have also been an attractive research topic.

In this Special Issue, original research articles and reviews are welcome. We look forward to receiving your contributions.

Dr. Qing Wang
Dr. Bin Wang
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Membranes is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2200 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • zeolite membrane
  • metal–organic frameworks
  • nanostructured materials
  • mixed-matrix membrane
  • hybrid membrane
  • hollow fiber membrane
  • 2D membrane
  • gas separation
  • liquid separation
  • pervaporation/vapor permeation
  • membrane reactor
  • water treatment
  • desalination
  • CO2 capture
  • synthesis
  • characterization

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (8 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

19 pages, 11288 KiB
Article
Phase Equilibria of the V-Ti-Fe System and Its Applications in the Design of Novel Hydrogen Permeable Alloys
by Yihao Wang, Limin Jia, Erhu Yan, Zhijie Guo, Shuo Zhang, Tangwei Li, Yongjin Zou, Hailiang Chu, Huanzhi Zhang, Fen Xu and Lixian Sun
Membranes 2023, 13(10), 813; https://doi.org/10.3390/membranes13100813 - 27 Sep 2023
Cited by 1 | Viewed by 1324
Abstract
The precise liquidus projection of the V-Ti-Fe system are crucial for designing high-performance hydrogen permeation alloys, but there are still many controversies in the research of this system. To this end, this article first uses the CALPHAD (CALculation of PHAse Diagrams) method to [...] Read more.
The precise liquidus projection of the V-Ti-Fe system are crucial for designing high-performance hydrogen permeation alloys, but there are still many controversies in the research of this system. To this end, this article first uses the CALPHAD (CALculation of PHAse Diagrams) method to reconstruct the alloy phase diagram and compares and analyses existing experimental data, confirming that the newly constructed phase diagram in this article has good reliability and accuracy. Second, this obtained phase diagram was applied to the subsequent development process of hydrogen permeation alloys, and the (Ti65Fe35)100−xVx (x = 0, 2.5, 5, 10, 15, 25) alloys with dual-phase {bcc-(V, Ti) + TiFe} structure were successfully explored. In particular, the alloys with x values equal to 2.5 at.% and 5 at.% exhibit relatively high hydrogen permeability. Third, to further increase the H2 flux permeation through the alloys, a 500-mm-long tubular (Ti65Fe35)95V5 membrane for hydrogen permeation was prepared for the first time. Hydrogen permeation testing showed that this membrane had a very high H2 flux (4.06 mL min−1), which is ca. 6.7 times greater than the plate-like counterpart (0.61 mL min−1) under the same test conditions. This work not only indicates the reliability of the obtained V-Ti-Fe phase diagram in developing new hydrogen permeation alloys, but also demonstrates that preparing tubular membranes is one of the most important means of improving H2 flux. Full article
Show Figures

Figure 1

20 pages, 12066 KiB
Article
Phase Equilibria, Solidified Microstructure, and Hydrogen Transport Behaviour in the V-Ti-Co System
by Erhu Yan, Zhijie Guo, Limin Jia, Yihao Wang, Shuo Zhang, Tangwei Li, Yongjin Zou, Hailiang Chu, Huanzhi Zhang, Fen Xu and Lixian Sun
Membranes 2023, 13(9), 790; https://doi.org/10.3390/membranes13090790 - 12 Sep 2023
Cited by 1 | Viewed by 1215
Abstract
At present, the V-Ti-Co phase diagram is not established, which seriously hinders the subsequent development of this potential hydrogen permeation alloy system. To this end, this article constructed the first phase diagram of the V-Ti-Co system by using the CALculation of PHAse Diagrams [...] Read more.
At present, the V-Ti-Co phase diagram is not established, which seriously hinders the subsequent development of this potential hydrogen permeation alloy system. To this end, this article constructed the first phase diagram of the V-Ti-Co system by using the CALculation of PHAse Diagrams (CALPHAD) approach as well as relevant validation experiments. On this basis, hydrogen-permeable VxTi50Co50−x (x = 17.5, 20.5, …, 32.5) alloys were designed, and their microstructure characteristics and hydrogen transport behaviour were further studied by XRD, SEM, EDS, and so on. It was found that six ternary invariant reactions are located in the liquidus projection, and the phase diagram is divided into eight phase regions by their connecting lines. Among them, some alloys in the TiCo phase region were proven to be promising candidate materials for hydrogen permeation. Typically, VxTi50Co50−x (x = 17.5–23.5) alloys, which consist of the primary TiCo and the eutectic {bcc-(V, Ti) and TiCo} structure, show a high hydrogen permeability without hydrogen embrittlement. In particular, V23.5Ti50Co26.5 exhibit the highest permeability of 4.05 × 10−8 mol H2 m−1s−1Pa−0.5, which is the highest value known heretofore in the V-Ti-Co system. The high permeability of these alloys is due in large part to the simultaneous increment of hydrogen solubility and diffusivity, and is closely related to the composition of hydrogen permeable alloys, especially the Ti content in the (V, Ti) phase. The permeability of this alloy system is much higher than those of Nb-TiCo and/or Nb-TiNi alloys. Full article
Show Figures

Figure 1

26 pages, 2595 KiB
Article
Role of Plasma Membrane at Dielectric Relaxations and Intermembrane Interaction in Human Erythrocytes
by Ivan T. Ivanov and Boyana K. Paarvanova
Membranes 2023, 13(7), 658; https://doi.org/10.3390/membranes13070658 - 11 Jul 2023
Cited by 1 | Viewed by 1439
Abstract
Dielectric relaxations at 1.4 MHz (βsp) and 9 MHz (γ1sp) on the erythrocyte spectrin network were studied by dielectric spectroscopy using dense suspensions of erythrocytes and erythrocyte ghost membranes, subjected to extraction with up to 0.2% volume Triton-X-100. The [...] Read more.
Dielectric relaxations at 1.4 MHz (βsp) and 9 MHz (γ1sp) on the erythrocyte spectrin network were studied by dielectric spectroscopy using dense suspensions of erythrocytes and erythrocyte ghost membranes, subjected to extraction with up to 0.2% volume Triton-X-100. The step-wise extraction of up to 60% of membrane lipids preserved γ1sp and gradually removed βsp-relaxation. On increasing the concentration up to 100 mM of NaCl at either side of erythrocyte plasma membranes, the βsp-relaxation was linearly enhanced, while the strength of γ1sp-relaxation remained unchanged. In media with NaCl between 100 and 150 mM βsp-relaxation became slightly inhibited, while γ1sp-relaxation almost disappeared, possibly due to the decreased electrostatic repulsion allowing erythrocytes to come into closer contact. When these media contained, at concentrations 10–30 mg/mL dextran (MW 7 kDa), polyethylene glycol or polyvinylpyrrolidone (40 kDa), or albumin or homologous plasma with equivalent concentration of albumin, the γ1sp-relaxation was about tenfold enhanced, while βsp-relaxation was strengthened or preserved. The results suggest the Maxwell–Vagner accumulation of ions on the lipid bilayer as an energy source for βsp-relaxation. While βsp-relaxation appears sensitive to erythrocyte membrane deformability, γ1sp-relaxation could be a sensitive marker for the inter-membrane interactions between erythrocytes. Full article
Show Figures

Graphical abstract

14 pages, 4513 KiB
Article
A Facile Way to Fabricate GO-EDA/Al2O3 Tubular Nanofiltration Membranes with Enhanced Desalination Stability via Fine-Tuning the pH of the Membrane-Forming Suspensions
by Chunxiao Ding and Hong Qi
Membranes 2023, 13(5), 536; https://doi.org/10.3390/membranes13050536 - 22 May 2023
Cited by 2 | Viewed by 1563
Abstract
Pristine graphene oxide (GO)-based membranes have proven promising for molecular and ion separation owing to efficient molecular transport nanochannels, but their separation ability in an aqueous environment is limited by the natural swelling tendency of GO. To obtain a novel membrane with anti-swelling [...] Read more.
Pristine graphene oxide (GO)-based membranes have proven promising for molecular and ion separation owing to efficient molecular transport nanochannels, but their separation ability in an aqueous environment is limited by the natural swelling tendency of GO. To obtain a novel membrane with anti-swelling behavior and remarkable desalination capability, we used the Al2O3 tubular membrane with an average pore size of 20 nm as the substrate and fabricated several GO nanofiltration ceramic membranes with different interlayer structures and surface charges by fine-tuning the pH of the GO-EDA membrane-forming suspension (pH = 7, 9, 11). The resultant membranes could maintain desalination stability, whether immersed in water for 680 h or operated under a high-pressure environment. When the pH of the membrane-forming suspension was 11, the prepared GE-11 membrane showed a rejection of 91.5% (measured at 5 bar) towards 1 mM Na2SO4 after soaking in water for 680 h. An increase in the transmembrane pressure to 20 bar resulted in an increase in the rejection towards the 1 mM Na2SO4 solution to 96.3%, and an increase in the permeance to 3.7 L·m−2·h−1·bar−1. The proposed strategy in varying charge repulsion is beneficial to the future development of GO-derived nanofiltration ceramic membranes. Full article
Show Figures

Figure 1

21 pages, 19872 KiB
Article
Diffusion Barriers Minimizing the Strength Degradation of Reactive Air Brazed Ba0.5Sr0.5Co0.8Fe0.2O3-δ Membranes during Aging
by Simone Herzog, Anke Kaletsch and Christoph Broeckmann
Membranes 2023, 13(5), 504; https://doi.org/10.3390/membranes13050504 - 10 May 2023
Viewed by 1491
Abstract
The separation of oxygen from air by means of inorganic ceramic membranes requires gas-tight ceramic–metal joints that enable reliable permeation operation in the oxygen partial pressure gradient at 850 °C. Reactive air brazing is a promising method to solve this challenge. However, reactive [...] Read more.
The separation of oxygen from air by means of inorganic ceramic membranes requires gas-tight ceramic–metal joints that enable reliable permeation operation in the oxygen partial pressure gradient at 850 °C. Reactive air brazing is a promising method to solve this challenge. However, reactive air brazed BSCF membranes suffer from a significant strength degradation that is caused by unhindered diffusion from the metal component during aging. In this study, we investigated how diffusion layers applied on the austenitic steel AISI 314 influence the bending strength of BSCF-Ag3CuO-AISI314 joints after aging. Three different approaches were compared as diffusion barriers: (1) aluminizing via pack cementation, (2) spray coating with NiCoCrAlReY, and (3) spray coating with NiCoCrAlReY and an additional 7YSZ top layer. Coated steel components were brazed to bending bars and aged for 1000 h at 850 °C in air prior to four-point bending and subsequent macroscopic as well microscopic analyses. In particular, coating with NiCoCrAlReY showed low-defect microstructures. The characteristic joint strength was raised from 17 MPa to 35 MPa after 1000 h aging at 850 °C. In addition, the dominant delamination fracture between the steel and the mixed oxide layer, observed in the reference series with uncoated steel, could be replaced by mixed and ceramic fractures of higher strength. The effect of residual joint stresses on the crack formation and path is analyzed and discussed. Chromium poisoning could no longer be detected in the BSCF, and interdiffusion through the braze was effectively reduced. Since the strength degradation of reactive air brazed joints is mainly caused by the metallic joining partner, the findings on the effect of the diffusion barriers in BSCF joints might be transferred to numerous other joining systems. Full article
Show Figures

Graphical abstract

13 pages, 18311 KiB
Article
Preparation and Lithium-Ion Separation Property of ZIF-8 Membrane with Excellent Flexibility
by Jun Zhao, Rongyu Fan, Shengchang Xiang, Jiapeng Hu and Ximing Zheng
Membranes 2023, 13(5), 500; https://doi.org/10.3390/membranes13050500 - 9 May 2023
Cited by 6 | Viewed by 2451
Abstract
Metal-organic framework (MOF) membranes exhibit immense potential for separation applications due to their regular pore channels and scalable pore sizes. However, structuring a flexible and high-quality MOF membrane remains a challenge due to its brittleness, which severely restricts its practical application. This paper [...] Read more.
Metal-organic framework (MOF) membranes exhibit immense potential for separation applications due to their regular pore channels and scalable pore sizes. However, structuring a flexible and high-quality MOF membrane remains a challenge due to its brittleness, which severely restricts its practical application. This paper presents a simple and effective method in which continuous, uniform, defect-free ZIF-8 film layers of tunable thickness are constructed on the surface of inert microporous polypropylene membranes (MPPM). To provide heterogeneous nucleation sites for ZIF-8 growth, an extensive amount of hydroxyl and amine groups were introduced on the MPPM surface using the dopamine-assisted co-deposition technique. Subsequently, ZIF-8 crystals were grown in-situ on the MPPM surface using the solvothermal method. The resultant ZIF-8/MPPM exhibited a lithium-ion permeation flux of 0.151 mol m−2 h−1 and a high selectivity of Li+/Na+ = 1.93, Li+/Mg2+ = 11.50. Notably, ZIF-8/MPPM has good flexibility, and the lithium-ion permeation flux and selectivity remain unchanged at a bending curvature of 348 m−1. These excellent mechanical characteristics are crucial for the practical applications of MOF membranes. Full article
Show Figures

Figure 1

19 pages, 5213 KiB
Article
Efficient Pervaporation for Ethanol Dehydration: Ultrasonic Spraying Preparation of Polyvinyl Alcohol (PVA)/Ti3C2Tx Nanosheet Mixed Matrix Membranes
by Huijuan Tong, Qiao Liu, Nong Xu, Qing Wang, Long Fan, Qiang Dong and Aiqin Ding
Membranes 2023, 13(4), 430; https://doi.org/10.3390/membranes13040430 - 13 Apr 2023
Cited by 4 | Viewed by 2262
Abstract
Polyvinyl alcohol (PVA) pervaporation (PV) membranes have been extensively studied in the field of ethanol dehydration. The incorporation of two-dimensional (2D) nanomaterials into the PVA matrix can greatly improve the hydrophilicity of the PVA polymer matrix, thereby enhancing its PV performance. In this [...] Read more.
Polyvinyl alcohol (PVA) pervaporation (PV) membranes have been extensively studied in the field of ethanol dehydration. The incorporation of two-dimensional (2D) nanomaterials into the PVA matrix can greatly improve the hydrophilicity of the PVA polymer matrix, thereby enhancing its PV performance. In this work, self-made MXene (Ti3C2Tx-based) nanosheets were dispersed in the PVA polymer matrix, and the composite membranes were fabricated by homemade ultrasonic spraying equipment with poly(tetrafluoroethylene) (PTFE) electrospun nanofibrous membrane as support. Due to the gentle coating of ultrasonic spraying and following continuous steps of drying and thermal crosslinking, a thin (~1.5 μm), homogenous and defect-free PVA-based separation layer was fabricated on the PTFE support. The prepared rolls of the PVA composite membranes were investigated systematically. The PV performance of the membrane was significantly improved by increasing the solubility and diffusion rate of the membranes to the water molecules through the hydrophilic channels constructed by the MXene nanosheets in the membrane matrix. The water flux and separation factor of the PVA/MXene mixed matrix membrane (MMM) were dramatically increased to 1.21 kg·m−2·h−1 and 1126.8, respectively. With high mechanical strength and structural stability, the prepared PGM-0 membrane suffered 300 h of the PV test without any performance degradation. Considering the promising results, it is likely that the membrane would improve the efficiency of the PV process and reduce energy consumption in the ethanol dehydration. Full article
Show Figures

Figure 1

19 pages, 6155 KiB
Article
In Situ Incorporation of TiO2@Graphene Oxide (GO) Nanosheets in Polyacrylonitrile (PAN)-Based Membranes Matrix for Ultrafast Protein Separation
by Wei Zhou, Qiao Liu, Nong Xu, Qing Wang, Long Fan and Qiang Dong
Membranes 2023, 13(4), 377; https://doi.org/10.3390/membranes13040377 - 26 Mar 2023
Cited by 2 | Viewed by 1708
Abstract
Organic polymeric ultrafiltration (UF) membranes have been widely used in protein separation due to their advantages of high flux and simple manufacturing process. However, due to the hydrophobic nature of the polymer, pure polymeric UF membranes need to be modified or hybrid to [...] Read more.
Organic polymeric ultrafiltration (UF) membranes have been widely used in protein separation due to their advantages of high flux and simple manufacturing process. However, due to the hydrophobic nature of the polymer, pure polymeric UF membranes need to be modified or hybrid to increase their flux and anti-fouling performance. In this work, tetrabutyl titanate (TBT) and graphene oxide (GO) were simultaneously added to the polyacrylonitrile (PAN) casting solution to prepare a TiO2@GO/PAN hybrid ultrafiltration membrane using a non-solvent induced phase separation (NIPS). During the phase separation process, TBT underwent a sol–gel reaction to generate hydrophilic TiO2 nanoparticles in situ. Some of the generated TiO2 nanoparticles reacted with the GO through a chelation interaction to form TiO2@GO nanocomposites. The resulting TiO2@GO nanocomposites had higher hydrophilicity than the GO. They could selectively segregate towards the membrane surface and pore walls through the solvent and non-solvent exchange during the NIPS, significantly improving the membrane’s hydrophilicity. The remaining TiO2 nanoparticles were segregated from the membrane matrix to increase the membrane’s porosity. Furthermore, the interaction between the GO and TiO2 also restricted the excessive segregation of the TiO2 nanoparticles and reduced their losing. The resulting TiO2@GO/PAN membrane had a water flux of 1487.6 L·m−2·h−1 and a bovine serum albumin (BSA) rejection rate of 99.5%, which were much higher than those of the currently available UF membranes. It also exhibited excellent anti-protein fouling performance. Therefore, the prepared TiO2@GO/PAN membrane has important practical applications in the field of protein separation. Full article
Show Figures

Figure 1
