Research

Jump to: Review

Open AccessArticle

Determination of Diffusion Coefficients of Lithium in Solid Electrolyte LiPON

by

,

,

,

,

Alexander Skundin

and

Ivan Fedorov

Batteries 2021, 7(2), 21; https://doi.org/10.3390/batteries7020021 - 29 Mar 2021

Viewed by 770

Abstract

A structural model of LiPON solid electrolyte, containing elements that simulate drift conductivity, diffusion conductivity, and leakage current was proposed. The dependence of the impedance of the structural model on frequency was calculated, and the parameters of the model at which the theoretical [...] Read more.

A structural model of LiPON solid electrolyte, containing elements that simulate drift conductivity, diffusion conductivity, and leakage current was proposed. The dependence of the impedance of the structural model on frequency was calculated, and the parameters of the model at which the theoretical curve best approximates the experimental Nyquist diagrams were determined. Based on these data, the ion diffusion coefficient and conductivity of LiPON were calculated, which are D₁ = 1.5 × 10⁻¹¹ cm²/s and σ = 1.9 × 10⁻⁶ S/cm, respectively. Full article

(This article belongs to the Special Issue Ionic Transportation Bases in All-Solid-State Batteries)

► Show Figures

Figure 1

Open AccessArticle

Infiltrated and Isostatic Laminated NCM and LTO Electrodes with Plastic Crystal Electrolyte Based on Succinonitrile for Lithium-Ion Solid State Batteries

by

,

,

,

,

,

,

and

Batteries 2021, 7(1), 11; https://doi.org/10.3390/batteries7010011 - 03 Feb 2021

Viewed by 1072

Abstract

We report a new process technique for electrode manufacturing for all solid-state batteries. Porous electrodes are manufactured by a tape casting process and subsequently infiltrated by a plastic crystal polymer electrolyte (PCPE). With a following isostatic lamination process, the PCPE was further integrated [...] Read more.

We report a new process technique for electrode manufacturing for all solid-state batteries. Porous electrodes are manufactured by a tape casting process and subsequently infiltrated by a plastic crystal polymer electrolyte (PCPE). With a following isostatic lamination process, the PCPE was further integrated deeply into the porous electrode layer, forming a composite electrode. The PCPE comprises the plastic crystal succinonitrile (SN), lithium conductive salt LiTFSI and polyacrylonitrile (PAN) and exhibits suitable thermal, rheological (ƞ = 0.6 Pa s @ 80 °C 1 s⁻¹) and electrochemical properties (σ > 10⁻⁴ S/cm @ 45 °C). We detected a lowered porosity of infiltrated and laminated electrodes through Hg porosimetry, showing a reduction from 25.6% to 2.6% (NCM infiltrated to laminated) and 32.9% to 4.0% (LTO infiltrated to laminated). Infiltration of PCPE into the electrodes was further verified by FESEM images and EDS mapping of sulfur content of the conductive salt. Cycling tests of full cells with NCM and LTO electrodes with PCPE separator at 45 °C showed up to 165 mAh/g at 0.03C over 20 cycles, which is about 97% of the total usable LTO capacity with a coulomb efficiency of between 98 and 99%. Cycling tests at 0.1C showed a capacity of ~128 mAh/g after 40 cycles. The C-rate of 0.2C showed a mean capacity of 127 mAh/g. In summary, we could manufacture full cells using a plastic crystal polymer electrolyte suitable for NCM and LTO active material, which is easily to be integrated into porous electrodes and which is being able to be used in future cell concepts like bipolar stacked cells. Full article

(This article belongs to the Special Issue Ionic Transportation Bases in All-Solid-State Batteries)

► Show Figures

Figure 1

Review

Jump to: Research

Open AccessReview

A Performance and Cost Overview of Selected Solid-State Electrolytes: Race between Polymer Electrolytes and Inorganic Sulfide Electrolytes

by

Duygu Karabelli

,

Kai Peter Birke

and

Max Weeber

Batteries 2021, 7(1), 18; https://doi.org/10.3390/batteries7010018 - 05 Mar 2021

Cited by 1 | Viewed by 1335

Abstract

Electrolytes are key components in electrochemical storage systems, which provide an ion-transport mechanism between the cathode and anode of a cell. As battery technologies are in continuous development, there has been growing demand for more efficient, reliable and environmentally friendly materials. Solid-state lithium [...] Read more.

Electrolytes are key components in electrochemical storage systems, which provide an ion-transport mechanism between the cathode and anode of a cell. As battery technologies are in continuous development, there has been growing demand for more efficient, reliable and environmentally friendly materials. Solid-state lithium ion batteries (SSLIBs) are considered as next-generation energy storage systems and solid electrolytes (SEs) are the key components for these systems. Compared to liquid electrolytes, SEs are thermally stable (safer), less toxic and provide a more compact (lighter) battery design. However, the main issue is the ionic conductivity, especially at low temperatures. So far, there are two popular types of SEs: (1) inorganic solid electrolytes (InSEs) and (2) polymer electrolytes (PEs). Among InSEs, sulfide-based SEs are providing very high ionic conductivities (up to 10⁻² S/cm) and they can easily compete with liquid electrolytes (LEs). On the other hand, they are much more expensive than LEs. PEs can be produced at less cost than InSEs but their conductivities are still not sufficient for higher performances. This paper reviews the most efficient SEs and compares them in terms of their performances and costs. The challenges associated with the current state-of-the-art electrolytes and their cost-reduction potentials are described. Full article

(This article belongs to the Special Issue Ionic Transportation Bases in All-Solid-State Batteries)

► Show Figures
