Electricity, Volume 7, Issue 3 (September 2026) – 21 articles

Arc flash faults in industrial substations can release high levels of incident energy, particularly on the line side of incoming circuit breakers, where opening the local breaker alone does not eliminate the source contribution. This paper proposes and experimentally evaluates an IEC 61850-based methodology to mitigate this protection gap by transferring arc flash trip signals between substations using GOOSE messages. The methodology comprises laboratory validation of the complete GOOSE-based protection chain and communication network, followed by validation in an operating industrial substation. Laboratory tests demonstrated satisfactory performance for both homogeneous and multivendor IED configurations, although longer operating times were observed when the test current approached the overcurrent pickup setting. The communication network achieved a mean transfer time of 5.31 ms and a maximum of 6.00 ms. In the industrial case study, the maximum protection operating time was 90 ms. Considering a conservative total fault-clearing time of 107.5 ms, the incident energy was reduced from 7.34 cal/cm² to 2.04 cal/cm², corresponding to a reduction of approximately 72%. These results demonstrate the feasibility of IEC 61850 GOOSE communication for high-speed trip transfer, reducing fault-clearing time and mitigating incident energy under critical line-side fault conditions. Full article

Maintaining frequency stability in modern interconnected power systems (PSs) has become increasingly challenging due to the high penetration of renewable energy sources (RESs) and the dynamic nature of generation and demand. To address these issues, this paper proposes a novel load frequency control strategy that integrates a Dung Beetle Optimizer (DBO)-tuned fractional-order Proportional–Integral–Derivative (FOPID) controller with a newly developed multi-source interconnected power system. This model combines PV, thermal, hydro, nuclear, and advanced storage (HAE and fuel cells). Unlike existing methods, the proposed approach simultaneously leverages DBO’s balanced search mechanism and FOPID’s fractional dynamics to enhance frequency stability under high renewable penetration. The performance of the proposed controller is validated through a comparative analysis with Ant Lion Optimizer (ALO) and Particle Swarm Optimization (PSO) methods. Simulation results show that the DBO-based controller significantly improves dynamic response, achieving reductions in settling time of 9.5% and 4.7% compared to PSO and ALO, respectively. Furthermore, the proposed approach enhances frequency regulation and tie-line power stability over other optimization methods and controllers, demonstrating strong robustness and adaptability for future high-RES power systems. Full article

This study proposes a reproducible exploratory framework to link long-term territorial development with electricity demand in data-scarce contexts, and applies it to Ecuador’s Costa region. The pipeline combines three commonly available input streams: periodic census microdata, an official demand series, and macroeconomic aggregates. Socioeconomic heterogeneity across five non-uniform census rounds (1974, 1982, 1990, 2001, 2010) is summarized through Principal Component Analysis (PCA), and territorial indicators are projected to the demand horizon using a univariate linear trend. Eleven regression specifications are compared on a log-transformed demand variable, and a rolling-origin backtesting scheme plus a 2020–2024 holdout are used for validation. The selected Trend OLS log model attains $R^2=0.551$ and MAPE = 6.08%, and projects a regional demand of approximately 7055 MW by 2050, equivalent to a compound annual growth rate of 3.46%. Beyond the Ecuadorian case, the results show that transparent, low-data pipelines based on harmonized census information, macroeconomic drivers and simple regression models can provide defensible medium- and long-term demand signals for planners in other emerging economies with limited high-frequency data. Full article

The increasing penetration of distributed photovoltaic generation is changing voltage behavior in distribution feeders and creating operational challenges related to voltage violations, losses, curtailment, and hosting capacity. This paper proposes a topology-aware analytical and computational framework for assessing voltage regulation and continuous photovoltaic hosting capacity in distribution feeders with smart-inverter controls. The framework combines topology-dependent voltage sensitivities, balanced steady-state power-flow simulations, explicit inverter apparent-power constraints, and gain indices that quantify the contributions of feeder topology, inverter controls, and their interaction. The IEEE 33-bus and IEEE 69-bus feeders are evaluated under radial and meshed configurations, heavy- and light-load conditions, and four photovoltaic operation modes: no control, Volt–Var, Volt–Watt, and combined Volt–Var/Volt–Watt control. A discrete sweep from 20% to 150% PV penetration is used to characterize voltage, active and reactive losses, and curtailment trends. Hosting-capacity boundaries are subsequently determined through an interval-aware procedure consisting of a one-percentage-point scan followed by bisection refinement to 0.1 percentage point, without assuming a globally monotonic feasibility transition. The results show that the feeder topology strongly affects voltage sensitivity and photovoltaic hosting capacity. The meshed operation generally increases voltage margins, while the interval-aware assessment identifies nonzero feasible penetration ranges, even when the zero-PV operating point is constrained by undervoltage. Volt–Watt achieves the largest hosting-capacity gains at the expense of curtailment, whereas Volt–Var preserves photovoltaic injection but may increase feeder losses. Therefore, hosting capacity should be interpreted jointly with topology, inverter controls, injected power, curtailment, and losses. Full article

This paper presents a low-cost embedded monitoring system for real-time RMS voltage and RMS current acquisition in three-phase electrical networks. The proposed architecture is based on distributed Arduino Nano acquisition nodes equipped with ACS712 Hall-effect current sensors and isolated voltage transformers, while a Raspberry Pi 4 Model B is used as a centralized data acquisition and processing unit through the I²C communication protocol. The embedded acquisition nodes implement timer-controlled analog signal sampling using the internal 10-bit ADC of the ATmega328P microcontroller, allowing real-time acquisition of electrical waveforms for RMS computation. Unlike conventional low-cost IoT electrical monitoring systems focused mainly on basic parameter visualization and wireless communication, the proposed platform emphasizes synchronized three-phase RMS monitoring and experimental validation accuracy under real operating conditions. The proposed monitoring architecture is experimentally benchmarked against a FLUKE 435 professional power quality analyser used as a high-accuracy reference instrument. Experimental results demonstrate that the proposed low-cost embedded architecture can provide RMS voltage and RMS current measurements with acceptable accuracy for educational applications, experimental electrical platforms, and distributed IoT-based monitoring systems. The presented system does not aim to implement a fully IEC 61000-4-30-compliant power quality analyser but rather to validate the feasibility of low-cost embedded RMS monitoring architectures for real-time electrical applications. Full article

With the increase in voltage levels, higher requirements are imposed on the energy-dissipation capability of high-voltage direct current (HVDC) networks. Existing energy-dissipation schemes cannot satisfy the demands of future HVDC systems. In this paper, a composite energy-dissipation branch circuit based on liquid metal, zinc oxide varistors, and damping resistors is proposed for HVDC circuit breakers. First, the self-constricting arc initiation mechanism and energy-dissipation characteristics of gallium–indium–tin liquid metal are studied. The results show that the energy-dissipation process exhibits an obvious stage-wise characteristic. Subsequently, an energy-dissipation topology incorporating liquid metal elements is established. A simulation model for the liquid-metal module is developed using the Mayr arc theory, and the conductance evolution during arc initiation is simulated. The model is combined with a hybrid HVDC circuit breaker model for analysis. Finally, a composite energy-dissipation branch circuit is constructed. The energy allocation among different components and the corresponding power density are evaluated. In the case of connecting three liquid-metal components in series, the energy density reached 0.248 kJ/cm³, representing a 22.2% increase compared to the original. The results support the coordinated application of liquid-metal modules and conventional absorption units in HVDC circuit breakers. Full article

While multi-phase short circuits are reliably cleared by conventional overcurrent relays, single-phase-to-ground faults (SPGFs) in isolated, compensated, or resistance-grounded 6–10 kV distribution networks produce extremely low, highly distorted currents that frequently cause traditional zero-sequence protections to misoperate. Because SPGFs constitute the vast majority of network disturbances, resolving this specific low-current detection challenge remains a critical priority for grid resilience. This paper presents a preselective protection approach based on Vector Analysis of Reactive Asymmetry Current (VARAC), designed for implementation in digital relay protection and automation terminals. Instead of relying primarily on vulnerable zero-sequence quantities, the method derives diagnostic features from the reactive asymmetry structure of three-phase current phasors. A reactive asymmetry matrix is formed from pairwise imaginary cross-products, symmetrized to preserve real eigenvalues and stable modal interpretation. The dominant eigenvalue and eigenvector are then used to quantify fault intensity and directional skew through two decision features: a magnitude-based index and a normalized asymmetry ratio. This enables robust discrimination between normal and faulted operation, including low-current and compensated-fault conditions where conventional criteria lose sensitivity. Simulation and oscillographic evaluations show a clear separation between pre-fault and SPGF regimes, fast onset detection, and improved structural selectivity versus traditional zero-sequence indicators. The proposed algorithm is computationally lightweight and compatible with hierarchical distributed SCADA architectures, supporting coordinated monitoring, diagnostics, and adaptive protection functions in modern medium-voltage networks. Full article

Advanced Metering Infrastructure (AMI) is a key enabler of digital and intelligent power systems, particularly in microgrid environments. However, existing research often addresses AMI from fragmented perspectives, limiting a comprehensive understanding of its role within integrated and data-driven energy systems. This paper presents a structured analysis of AMI based on a bibliometric and thematic review of recent literature, identifying the main research trends, technological drivers, and emerging directions in the field. The results reveal a transition of AMI toward a data-centric platform that supports real-time monitoring, bidirectional energy management, and intelligent decision-making. Key domains include cybersecurity, data analytics, communication systems, and distributed energy integration, while emerging technologies such as artificial intelligence and the Internet of Energy play a critical role in future developments. Finally, the paper outlines key challenges and provides strategic recommendations to support the effective deployment of AMI in microgrids, contributing to the development of resilient and sustainable energy systems. Full article

Load frequency control (LFC) plays a critical role in maintaining frequency stability and regulating power transfer between interconnected areas subjected to continuous load variations. In multi-area systems, disturbances tend to propagate through interconnected tie-lines rather than remaining restricted locally, often leading to slower responses and weak coordination when conventional controllers are employed. In this paper, a two-degrees-of-freedom fractional-order differential integration (2DOF FO-TID) controller is proposed to improve both frequency regulation and dynamic interaction. The structure enables independent tuning of tracking and disturbance rejection, allowing greater flexibility in shaping system response. The controller parameters are optimally tuned by the Artificial Ecosystem Optimization (AEO) algorithm. The proposed approach is evaluated on a two-area hybrid thermal power system incorporating an SMES unit within the MATLAB/Simulink (R2022b) environment and compared with PID, FOPID, and TID controllers under identical conditions. The results indicate that, although some conventional controllers provide faster stabilization in one area, their performance in the interconnected area remains slower. In contrast, the proposed controller achieves more robust behavior across both areas, with the settling time of the second area reduced from about 25 s to nearly 11 s without degrading the response of the first area. These results highlight the importance of coordination in multi-area systems and demonstrate that the proposed approach enhances overall system performance and damping compared to conventional methods. Full article

Discrete-time sliding mode controllers that utilize saturation-based reaching laws require a gain that ensures contraction within the boundary layer in the presence of multiplicative gain uncertainty. The conventional fixed-gain approach does not maintain this property at moderate uncertainty levels. This work introduces a family of admissible reaching gains and identifies a unique optimal gain that guarantees a specified worst-case contraction. The proposed method offers a closed-form solution to the worst-case contraction problem over the gain-uncertainty interval and determines the optimal contraction factor for the saturation-based reaching law for any finite uncertainty ratio. The optimal gain is integrated into a discrete-time integral sliding-mode framework, thereby eliminating the reaching phase. Furthermore, a past-step disturbance estimator with a confidence factor is introduced to prevent error amplification, which reduces the quasi-sliding band from first to second order in the sampling period when the realized gain approximates its nominal value. The effectiveness of the proposed approach is validated through its application to a photovoltaic battery-charging system with a DC–DC boost converter, achieving robust inductor-current regulation across three battery banks under varying irradiance conditions in a switching-level model with parasitic elements. Full article

This article examines the performance of negative-sequence overcurrent protection during short circuits in the presence of current asymmetry caused by single-phase loads, such as those encountered in AC railway traction systems. The impact of unbalanced loads on the generation of negative-sequence currents is analyzed using field test data and a mathematical model. Various operating modes of an electric power network under unbalanced loading conditions are simulated in MATLAB Simulink R2015a. It is shown that under significant load asymmetry, negative-sequence currents can reach magnitudes comparable to those of short-circuit currents, thereby increasing the risk of false protection operation. To address this issue, a modified negative-sequence overcurrent protection scheme is proposed that ensures both sensitivity and selectivity. The modification is based on analyzing the ratio of negative-sequence to positive-sequence current phasors and monitoring the rate of change of the negative-sequence current. A faulted phase selector is also incorporated into the protection scheme. Simulation results confirm the effectiveness of the modified protection in reliably identifying unsymmetrical short circuits under varying unbalanced load conditions, including remote faults with high fault resistance. Full article

This study aims to quantify and compare the reliability of two alternative power system architectures: a conventional configuration based on traditional elements and a future envisioned architecture, where multi-port power converters operate as network nodes. The objective is to evaluate how these two approaches perform relative to each other in terms of reliability, and to determine whether the emerging converter-based structure represents an improvement or a drawback compared with the conventional design. To simplify the analysis and the comparison results, the analysis is presented for a double-fed power system. Both systems were modeled using two-state components characterized by constant failure and re- pair rates. Reliability assessment was carried out using a continuous-time Markov chain (CTMC) approach to derive the key adequacy indices. To validate the analytical results, a non-sequential Monte Carlo Simulation (MCS) was also performed, allowing a direct comparison between stochastic sampling and analytical modeling. The results show that the transformer-based configuration achieves a reliability of 0.9972 compared with 0.9960 for the power-router-based configuration, while also exhibiting lower LOLE and EENS, indicating a modest reliability advantage for the conventional architecture under the adopted assumptions. Full article

Electric vehicle (EV) charging demand introduces significant variability in power systems, requiring forecasting approaches capable of representing both aggregated consumption trends and stochastic charging behaviors. While machine learning methods often provide strong predictive performance, they generally require large datasets and substantial computational resources. This paper proposes a stochastic framework based on compound Poisson and Cox processes to model EV charging demand using real charging station data collected at one-minute resolution. The proposed methodology jointly models charging-event arrivals, charging duration, and charging power through probabilistic distributions calibrated from historical observations. A compound homogeneous Poisson process (CHPP) and a double stochastic compound Poisson process (Cox process) are investigated and compared for the generation of synthetic EV charging profiles and short-term forecasting applications. The framework is validated using 1863 charging sessions recorded at a workplace charging infrastructure composed of 37 charging terminals. Monte Carlo simulations are performed to generate synthetic daily charging profiles and evaluate the capability of the models to reproduce key operational indicators, including daily energy consumption and peak grid power demand. The CHPP process achieves average forecasting errors up to 0.8% for daily energy and 6.2% for maximum grid power demand. The results show that Poisson-based stochastic models can generate diverse and realistic charging profiles while requiring only limited historical data and having low computational complexity. The proposed approach provides an interpretable and computationally efficient probabilistic framework for EV charging demand forecasting, synthetic profile generation, and power system operational studies. Stochastic compound Poisson processes may therefore constitute a valuable tool to support the ongoing electrification of mobility and the digital transformation of future smart grids and smart cities. Full article

It is essential to experimentally evaluate a Switched Reluctance Motor’s (SRM) flux-linkage characteristics to verify that its magnetic behavior aligns with design targets. This paper presents the development of a novel, fully automated custom experimental test bed and a control model capable of characterizing the static self- and mutual flux linkages of a switched reluctance motor. The proposed setup is programmed with MATLAB/Simulink for automatic characterization across various rotor positions and excitation currents, which has not been previously addressed in the literature. The automated measurement algorithm is implemented and validated on a 70 kW, 18/12 propulsion SRM prototype. Flux-linkage data is obtained across a full 360° mechanical rotation, with self-flux linkages measured up to 210 A and mutual flux linkages up to 130 A. Experimental results indicate a maximum 6% deviation from the finite element analysis (FEA) results for mutual flux linkage and below 5% for self-flux linkage. The developed flux-linkage characterization approach demonstrates good accuracy and repeatability, enabling the construction of reliable flux–current–position datasets essential for SRM modeling and validation. Full article

Residential customers are frequently exposed to electricity supply interruptions caused by system failures, natural hazards, or human-related events. Community microgrids have emerged as a promising solution to improve supply reliability. Therefore, this study quantifies the additional cost of guaranteeing different levels of energy self-sufficiency through the optimal design of reliability-constrained community microgrids capable of maintaining electricity supply during outages regardless of when they occur throughout the year. To account for the inherent diversity of residential demand, hundreds of optimization problems were solved, resulting in the design of hundreds of community microgrids. The results indicate that guaranteeing 2 h of self-sufficiency increases annual costs by 14.1% for communities of 20 households. Furthermore, the impact of demand response (DR) on community microgrid planning is also investigated. The findings indicate that the economic benefits of residential DR are limited, not exceeding 4.4% of the total microgrid cost. Full article

Public lighting can account for nearly 40% of municipal energy consumption in some European cities and plays a vital role in road safety, mobility, and the quality of public spaces. Despite notable efficiency gains from the widespread adoption of light-emitting diode (LED) technologies, the technical outputs of standards-based and installation-level assessment methods are not usually simple and communicable energy-performance labels for municipal decision-making. This study addresses this issue by introducing an algorithm-based framework for classifying energy performance in public lighting at the road-segment level. This approach translates existing lighting standards and efficiency indicators into a straightforward and understandable energy label, adapting the energy labelling concept, commonly used for buildings and appliances, to public space infrastructure. This framework is implemented through a national digital platform for public lighting classification, which has already attracted formal interest from more than 100 municipalities, indicating strong institutional uptake. The results indicate that road-segment-level energy classification is feasible and scalable as a voluntary tool to enhance municipal accountability and support informed decision-making. This study concludes that algorithmic energy labels for public lighting can support sustainable urban governance transparency, comparability and decision-making capacity, with future research aimed at building capacity for large-scale implementation and incorporating environmental, human health, and ecological impact considerations into the classification system. Full article

An increase in penetration of photovoltaic (PV) systems in a distribution system causes voltage regulation issues that create serious problems for the On-Load Tap Changer (OLTC) of the power transformer, leading to higher tap-changing frequency and reduced transformer life. Traditional voltage control methods are ineffective when PV penetration exceeds load demand, and more sophisticated control methods are needed. This paper combines a systematic literature review conducted in accordance with the PRISMA 2020 guidelines with a case study on operational issues of OLTC transformers under both normal and non-normal operating conditions. It entails a detailed examination of the effect of PV integration on the operating characteristics of OLTC in a systematic approach and also dwells upon coordination processes between OLTC and Flexible AC Transmission Systems (FACTS) devices, such as Distribution Static Synchronous Compensator (D-STATCOM) or Static VAR Compensator (SVC), which are highly effective in reducing tap operations. The future directions covered in the review include the operation of hybrid systems, cost-effective implementations, weather effects, predictive analytics, adaptive control techniques, etc. The case study included online monitoring of OLTC performance in two scenarios at the cement factory. First, under supply changes and load changes. Second, including PV penetration. The results show that OLTC increases the average daily tapping frequency (90 taps/day) by about 60%, with full PV penetration. It is concluded that this can’t be applied without coordinated control among OLTC, D-STATCOM, and PV inverters to maintain transformer life, improve reliability, and provide stable voltage profiles even under highly variable PV generation conditions. These results aim to provide a comprehensive resource for academics and practitioners, facilitating the advancement of advanced voltage control methods to support the transition to sustainable energy systems. Full article

To address the transient frequency limit violations triggered by the low-inertia characteristics of temporary islanded microgrids formed under extreme disasters, this paper proposes a multi-source collaborative two-stage robust optimization day-ahead scheduling model considering dynamic frequency constraints. Firstly, a collaborative architecture encompassing emergency power vehicles, grid-forming energy storage systems, and flexible loads is constructed. Through collaborative scheduling in the day-ahead pre-scheduling and real-time re-scheduling stages, this architecture effectively avoids the exorbitant costs of physical load shedding under extreme conditions. Secondly, to overcome the limitations of traditional robust box uncertainty sets—which ignore temporal correlations, tend to cause non-physical high-frequency oscillations, and hinder algorithm convergence—a time-correlated uncertainty set based on state-transition auxiliary variables is designed to accurately capture the continuous evolution characteristics of meteorological disturbances. The column-and-constraint generation algorithm is utilized for the solution methodology, combined with the big-M method to transform the subproblem containing bilinear terms into a mixed-integer linear programming model for efficient solving. Simulation results on a modified 33-node test system demonstrate that the proposed model effectively filters out high-frequency oscillation trajectories and significantly improves computational efficiency. Under the worst-case temporal disturbances, the transient frequency drop and the rate of change in frequency are strictly controlled within safe thresholds. Compared to deterministic scheduling and traditional box-based robust models, the proposed scheme effectively balances system security and economic efficiency, demonstrating exceptional system resilience and defense capabilities against varying prediction errors. Full article

In the last fifteen years, Mexico’s National Electric System (Sistema Eléctrico Nacional, SEN) has undergone significant structural changes, including the 2013 energy reform, the 2020 health contingency, ongoing geopolitical pressures, and the 2024 constitutional energy reform. Over this period, electricity consumption grew at an average annual rate of 3.1%, while the generation mix shifted substantially, with solar and wind capacity expanding from negligible levels to a combined output of 38,627 GWh by 2024. Despite these advances, supply reliability remains under pressure, and the growth of renewable deployment has not kept value with declared decarbonization commitments. This study quantifies the gap between the historical growth trajectory of the SEN and the targets established in the national expansion plan, using linear and second-degree polynomial regression models applied to official data series for the period 2010–2024 to assess whether current structural inertia is consistent with Mexico’s declared energy transition commitments. The results indicate that under a trend scenario, renewable installed capacity would reach approximately 34.3% by 2030, with an estimated generation of 112,136 GWh—insufficient to close the gap to sectoral decarbonization goals. The analysis further reveals that the Expansion Plan requires installing nearly twice the annual capacity historically added, posing a financing and institutional challenge that market signals alone cannot resolve. These findings demonstrate that structural inertia, rather than policy ambition, is currently the dominant driver of the evolution of Mexico’s electricity system, and that its energy transition will require deliberate acceleration beyond historical trends. Full article

The rapid expansion of photovoltaic (PV) generation has increased the need for educational and experimental platforms that allow students and researchers to study the dynamics, control strategies, and power conversion stages of grid-connected PV systems under realistic operating conditions. Although Hardware-in-the-Loop (HIL) simulation is widely used to validate power electronic converters and control algorithms, many existing platforms rely on specialized real-time simulators that limit their accessibility in academic environments. This paper presents the design and implementation of a cost-effective HIL simulation platform for grid-connected PV systems intended for research and training applications. The proposed system integrates real hardware under test within a real-time environment that emulates PV array behavior and grid conditions, combining Controller Hardware-in-the-Loop (CHIL) and Power Hardware-in-the-Loop (PHIL) techniques. A Texas Instruments C2000 microcontroller is used as the real-time digital simulator, providing an accessible alternative to conventional real-time simulation platforms. The platform architecture, the real-time PV emulator, and the experimental implementation are described and validated through simulation and experimental results. Finally, guided laboratory practices are presented to support hands-on training in PV systems and power electronics. Full article

Electricity systems are increasingly exposed to demand variability driven by extreme weather conditions, creating significant challenges for maintaining grid reliability and operational stability. Conventional forecasting approaches focus primarily on prediction accuracy and provide limited support for operational decision-making under dynamic conditions. This study proposes a hybrid deep learning framework for smart grid stress prediction and adaptive mitigation under extreme weather. The framework reformulates demand forecasting using residual learning. It further integrates grid stress modelling with control-oriented decision support. A sequence learning architecture with attention is employed to capture temporal demand dynamics, while a continuous Grid Stress Index (GSI) translates predictions into operational indicators of system stress. The model demonstrates stable performance on real-world UK electricity demand data, achieving a mean absolute error of 1827.51 MW and a root mean squared error of 2505.22 MW. Peak demand and ramp behaviour are captured with improved consistency, and grid stress is predicted with a mean absolute error of 0.1246. An adaptive mitigation module translates predicted stress into actionable control, resulting in approximately 5.37% peak demand reduction, with limited impact on ramp smoothing. The results demonstrate that integrating forecasting, stress modelling, and control delivers greater operational value than standalone predictive models. The proposed framework provides a scalable and practical approach for grid-aware decision support under increasing climate-driven demand uncertainty. Full article
